Xerox B605V_S Product Data Sheet

XEROX® VERSALINK® PRINTER AND MULTIFUNCTION PRINTER
Configurable, connected and highly capable.
B600/B605
ConnectKey
ConnectKey
Technology
®
®
Xerox® VersaLink® B600 Printer and Xerox® VersaLink® B605 Multifunction Printer
For a black-and-white printer or multifunction printer,
the VersaLink B600/B605 is anything but basic. In fact,
VersaLink sets a new standard for what you can expect
in workgroup productivity from Xerox. Home or away, this
highly configurable, cloud-connected workplace assistant
delivers completely new capabilities that go far beyond
the competition—at a competitive price.
EASY, SMART AND SECURE.
Right out of the box, you’ll count on your VersaLink B600 or B605 to consistently and flawlessly perform the tasks that make your business work more efficiently. From IT-free installation wizards, to step-by-step configuration options, you’re ready to go—hassle free.
Completely re-engineered for superior reliability, the VersaLink B600 and B605 feature a new hardware design with fewer moving parts, strengthened paper-path components, and a more advanced Hi-Q LED print head.
VersaLink devices are loaded with features and time-saving Xerox technologies designed to speed up information sharing and reduce inefficient workflows. Ensure information accuracy with Scan and Fax preview1, and do more with scanned documents with built-in optical character recognition (OCR)1.
When it comes to safeguarding critical information, VersaLink devices deliver a spectrum of stringent security features, including Secure Print and card authentication to control access.
CUSTOMIZABLE, APP-BASED
FUNCTIONALITY.
With the customizable, capacitive 7-inch color touchscreen (5-inch on the B600), you can tap, swipe and pinch your way through tasks and functions with mobile-like ease.
Preloaded Xerox® ConnectKey® Apps help optimize office efficiency, and on-screen access to the extensive Xerox App Gallery provides expanded functionality—like the
Xerox® Easy Translator Service app1, which quickly translates scanned documents into numerous languages.
Speed through tasks by saving common settings as presets for simple, single-touch job setup. With Simple ID, individual users and groups enter a user ID and password once, and then enjoy fast, secure, easy access to task-specific presets and commonly used apps on a personalized home screen.
CLOUD AND MOBILE CONNECTIVITY.
The VersaLink B600 Printer and VersaLink B605 Multifunction Printer gives you the freedom to work where and how you want— with out-of-the-box connectivity to Google Drive™, Microsoft® OneDrive® and DropBox™, and access to additional options through the Xerox App Gallery.
The ability to connect and print from multiple devices is key for today’s worker, and VersaLink devices meet the challenge with Apple® AirPrint®, Google Cloud Print™, Xerox® Print Service Plug-in for Android™, Near Field Communication (NFC) Tap-to-Pair and Mopria®, plus optional Wi-Fi and Wi-Fi Direct.
Learn more about why Xerox is the only choice for today’s mobile professionals by visiting www.xerox.com/mobile.
1
Scan Preview available for all VersaLink B605
configurations; Fax Preview available for VersaLink multifunction printers with faxing capabilities.
To learn more about VersaLink device features, go to
www.xerox.com/VersalinkEG
XEROX® CONNECTKEY®
TECHNOLOGY—THE NEXUS
OF YOUR COMPLETE
PRODUCTIVITY ECOSYSTEM
From Xerox—the company that created the modern workplace—we present the next revolution in workplace productivity. With a consistent user experience across a wide range of devices, mobile and cloud connec tivity and a growing library of apps to expand func tionality, you’ll work faster, better and smarter.
Intuitive User Experience
An entirely new—and yet entirely familiar way to interact that includes a tablet-like experience with gesture-based touchscreen controls and easy customization.
Mobile and Cloud Ready
Instant connec tivity to cloud an d mobile devices right from the user interface, with access to pre-loaded, cloud-hosted services that let you work where, when and how you want.
Benchmark Security
Full multi-level protection for both documents and data, ready to guard against and eliminate emerging threats and meet or exceed regulatory compliance.
Enable s Next Generation Services
Work more efficiently and manage resources more effectively. Easy integration of Xerox® Managed Print Services enables remote monitoring of service delivery and consumables.
Gateway to New Possibilities
Instantly extend your capabilities with access to the Xerox App G aller y, featuring real-world apps designed to optimize digital workflows. Commission our network of partners to design innovative, business­specific solutions.
Find out more about how you’ll work smarter at www.connectkey.com.
6
6
2
2
1
3
4
5
Xerox® VersaLink® B600 Printer
Pri nt.
1 500-sheet output tray on VersaLink B600 and
400-sheet output tray on VersaLink B6 05, both
with full tray sensors.
2 The internal card reader is located next to the
touch screen on the VersaLink B605 and the Car d
Reader Bay / internal card reader compartment
is located behind the touch screen on VersaLink B600 (External Card Reader/RFID Kit is required when Finisher/Mailbox is included).
3 A front-side USB port2 allows users to quickly print
from or scan to3 any standard USB memory device.
4 150-sheet Bypass Tray handles media sizes
from 3 x 5 in. to 8.5 x 14 in./76 x 127 mm to 216 x 356 mm.
Xerox® VersaLink® B605 Multifunction Printer
Print. Copy. Scan. Fa x. Email.
6
1
2
3
3
4
5
9
7
5 Tray 1 handles up to 550 sheet s with custom
sizes of 2.5 x 8.5 in. to 8.5 x 14 in./76 x 127 mm to 216 x 356 mm.
6 The 100 -sheet Single -pass Duplex Automatic
Document Feeder (DADF) scans two-sided
originals for copy, scan and fax jobs.
7 The optional cabinet (includes Caster Base)
provides storage for toner car tridges and other supplies.
8 The High Capacity Feeder (includes Caster Base)
adds up to 2,000 sheets with standard sizes of
8.5 x 11 in./A4.
2
10
4
5
11
3
4
5
9
9
8
9 Add up to 4 additional 550-sheet paper trays
that handle sizes from 2.5 x 8.5 in . to 8.5 x 14 in./ 76 x 127 mm to 216 x 356 mm (maximum of 2 additional trays with optional cabinet, ma ximum of 1 additional tray with High Capacity Feeder).
10 The optional finisher collates and staples sets
of up to 50 sheets and includes a 500-sheet output tray.
11 The optional mailbox includes 4 bins and each
tray can handle up to 100 sheets .
3
USB por ts can be disabled
4
VersaLink B605 only
INTRODUCING TOUCHSCREEN SUPERIORITY.
Meet the industry’s most advanced color touchscreen interface. Whether 7-inch (B605) or 5-inch (B600), it’s a user experience that sets a higher standard for customization, personalization and versatility.
By presenting a familiar “mobile” experience—with support for gestural input and task­focused apps that share a common look and feel— fewer steps are needed to complete even the most complex jobs.
A highly intuitive layout guides you through every ta sk from start to finish, with a natural hierarchy placing critical functions near the top of the screen and commonly used options front and center. Don’t like where a function or app is located? Customize the layout to make it yours.
This unmatched balance of hardware technology and software capability helps everyone who interacts with the VersaLink B600 Printer and VersaLink B605 Multifunction Printer get more work done, faster.
Xerox® VersaLink® B600/B605
The VersaLink B600 Printer and B605 Multifunction Printer are built on Xerox® ConnectKey® Technology. For more information, visit www.connectkey.com.
ConnectKey
Technology
®
DEVIC E SPECIF ICATIONS
Speed Up to 58 ppm letter/Up to 55 ppm A4
1
Duty Cy cle
VersaLink B600 Printer DN, DT, DX, DXF, DXP VersaLink B605 Multifunction Printer S, X, SF, SP, XF, XP, XTF, XTP
Up to 250,000 page s/month
1
Processor/Memory/Hard Drive 1.05 GHz ARM Dual Core/2 GB/Optional 250 GB HDD 1.05 GHz ARM Dual Core/2 GB/250 GB HDD Connectivity Ethernet 10/100/1000 Base-T, High-speed USB 3.0, Wi-Fi 802.11n and Wi-Fi Direc t with optional Wi-Fi Kit (concurrent wired and wireless connections
Controller Features Unified Address Book (B605), Configuration Cloning, Scan Preview (B605), Xerox Extensible Interface Platform®, Xerox® App Gallery, Xerox® Standard
Paper Handling
Paper Input Standard NA
Optional Up to 4 Additional Trays (1 Additional Tray standard on B60 0/DT): Up to 550 sheets each; Custom sizes: 3 x 7.5 in. to 8.5 x 14 in./76 x 190 mm to 216 x
suppor ted), NFC Tap-to-Pair
Accounting, Online Support (accessed from the user interface and print driver)
Single-Pass Duplex Automatic Document Feeder (DADF): 10 0 shee ts;
Bypa ss Tray : Up to 150 sheets; Cus tom sizes: 3 x 5 in. to 8.5 x 14 in./76 x 127 mm to 216 x 356 mm Tra y 1: Up to 550 sheets; Custom sizes: 3 x 7.5 in. to 8.5 x 14 in./76 x 190 mm to 216 x 356 mm
Custom sizes: 5.5 x 5.5 in. to 8.5 x 14 in./140 x 140 mm to 216 x 356 mm
356 mm High Capacity Feeder (Standard on DX, DXF and DXP): Up to 2,000 sheets;
Standard sizes: 8.5 x 11 in./A4
High Capacity Feeder (Standard on XTF and XTP): Up to 2,000 sheets; Standard sizes: 8.5 x 11 in./A4
Paper Output Standard 500 sheets 400 sheets without finishing options; 500 sheets with finishing options
Optional Finisher (Standard on DXF, not available on DXP): 50 0-sheet tray, 50 -sheet
stapling
Mailbox (Standard on DXP, not available on DXF): Four 100-sheet bins
Finisher (Standard on SF, XF, XTF; not available on S, X , SP, XP, XTP):
500-sheet tray, 50-sheet stapling Mailbox (Standard on SP, XP, XTP, not available on S , X, SF, XF, XTF): Four 100-sheet bins
Automatic Two-sided Output Standard Copy and Print Resolution Print: Up to 1200 x 1200 dpi Print: Up to 1200 x 1200 dpi; Copy: Up to 600 x 6 00 dpi First-page-out Time Print: As fast as 6.3 se conds Print: A s fast as 7.5 seconds; Copy: As fast as 5.8 seconds from the Platen Page Description Languages PCL® 5e/PCL 6/PDF/XPS/TIFF/JPEG/HP-GL/Adobe® PostScript® 3™
INTUITIVE USER EXPERIENCE
Customize and Personalize Walkup customization, Personalize Home Screen by User, Multiple Home Screens with Simple ID, Customize by Site, Function or Workflow with Xerox App
Print Drivers Job Identification, Bi-directional Status, Job Monitoring, Xerox® Global Print Driver® and Mobile Express Driver
Gallery and Xerox® App Studio
®
Xerox® Embedded Web Server PC or mobile—Status Information, Responsive Design, Settings, Device Management, Cloning Preview NA Preview of S can/Fax with Zoom, Rotate, Add Page Print Features Print from USB, Secure Print, S ample Set, Personal Print, Saved Job, Xerox® Earth Smart Driver Settings, Job Identification, Booklet Creation, Store and Recall
Scan NA Optical Charac ter Recognition (OC R), Scan to USB/Email/Network (FTP/
2
Fax
MOBILE AND CLOUD READY
Driver Settings, Bi-directional Real-time Status, Scaling, Job Monitoring, Application Default s, Two-sided Printing (as default), Skip Blank Pages, Draft Mode
SMB), Scan File Formats: PDF, PDF/A, XPS, JPEG, TIFF; Convenience Features: Scan to Home, Searchable PDF, Single/Multi-Page PDF/XPS/TIFF/Password
NA Fax Features (B605/ X, XF, XP, XTF, XTP only): Walk-up Fax (includes LA N Fax,
Protected PDF
Direct Fax, Fax Forward to Email)
Mobile Printing Apple® AirPrint®5, Google Cloud Print™ Ready, Xerox® Print Service and Mopria® Print Service Plug-ins for Android™ Mobility Options @PrintByXerox3, Xerox® Mobile Print and Mobile Print Cloud4, Connec t via NFC/Wi-Fi Direct Printing4, Xerox® Mobile Link App (B605)3.
Cloud Connectors
BENCHMARK SECURITY
3
Visit www.xerox.com/officemobileapps for available apps. Print from/Scan to6 Google Drive™, Microsoft® OneDrive®, Dropbox™, Microsoft O ffice 365®, Box®, Xerox® DocuShare® and more
Network Security IPsec, HTTPS, encrypted email. Network Authentication, SNMPv3, SSL/TLS, Security Certificates, Automatic Self-Signed Certificate Device Access Firmware Verification, User access and internal firewall, Port/IP/Domain Filtering, Audit Log, Access Controls, User Permissions, Smart Card Enabled
Data Protection Setup/S ecurity Wizard s, Job Level Encr yption via HTTPS/IPPS submission, Encrypte d hard disk (AES 256-bit, FIPS 140-2) and image overwrite, Common
(CAC/PIV/.NET), Xerox® Integrate d Card Reader Bay
Criteria Certification (ISO 15408) (undergoing evaluation)
Document Security Secure Print, S ecure Fax (B605), Secure Scan (B605), Secure Email (B605), Password Protected PDF (B605)
ENABLES NEXT GENERATION SERVICES
Print Management Xerox® Print Management and Mobility Suite4, Configuration Cloning, Xerox® Standard Accounting, Equitrac4, Y Soft4 and more Managing Print Xerox® Device Manager, Xerox® Suppor t Assistance, Auto Meter Read, Managed Print Services tools Sustainability Cisco EnergyWise®, Earth Smart Printing, Print User ID on margins
GATEWAY TO NEW POSSIBILIT IES
Cloud Services Xerox® Easy Translator (B605)4, Xerox® Healthcare MFP (B605 – U.S. only)4, many additional service s available Xerox App Gallery Many apps and cloud services available. Visit www.xerox.com/appgallery for a growing selection of Xerox® apps available for adding functions.
1
Maxim um volume capac ity expecte d in any one month. N ot expected to be susta ined on a regular ba sis; 2 Require s analog phone l ine; 3 Free optional dow nload; 4 Purcha sed option;
5
Visit www.apple.com for AirPrint C ertification list; 6 Scan to av ailable for B605.
Certifications
To view the latest list of certifications, go to
www.xerox.com/OfficeCertifications.
Supplies
Standard Capacity Toner Cartridge: Black: 10,300 pages7 106R 03940 High Capacity Toner Cartridge: Black: 25,900 pages7 106R 03942 Extra High Capacity Toner Cartridge: Black: 46,700 pages7 106R03944 Drum Cartridge: 60,000 page s8 101R00582
Options
550-sheet Feeder 097S04949 High Capacity Feeder (2,000 sheets) 097S04948 Stand/Cabinet 097S04955 Caster Base 097S04954 Finisher (500 sheets, 50-sheet stapler) 097S04952 4-Bin Mailbox (100 sheets per bin) 097S04953 Wireless Network Adapter (Wi-Fi Kit) 497K16750 Produc tivity Kit with 250 GB HDD 497K18360 RFID Card Re ader Kit 497K18380
7
Average s tandard page s. Declared Yield in accordance w ith ISO/IEC 19752. Y ield will v ary based on image, are a coverage and print mode.
8
Approx imate pag es. Declare d yield will var y depend ing on job run length and me dia size/orientation and m achine speed .
Configurations vary by geography.
For more detailed specifications, go to www.xerox.com/VersalinkB600Specs or www.xerox.com/VersalinkB605Specs. For more information, visit us at www.xerox.com/office.
©2017 Xerox Corpo ration. All r ights reser ved. Xerox®, Xero x and Design®, Cen treWare®, DocuSh are®, Global Pr int Driver®, Mob ile Express Driver ®, Versa Link® and Xerox E xtensible Int erface Plat form® are trade marks of Xerox Co rporation in t he United State s and/or other countr ies. The infor mation in this br ochure is subje ct to change wi thout notice. 10/ 17 BR21761 VB6BR- 01UA
