WorkCentre® 4250/4260
Black-and-White
Multifunction Printer
WorkCentre
4250 Copier only
A powerful copier with
automatic two-sided
copy and optional
faxing capabilities
WorkCentre
4250
Output Speed
Single Sided Up to 45/55 ppm 8.5 x 11 in.
Up to 43/53 ppm A4 (210 x 297 mm)
Up to 39/40 ppm 8.5 x 14 in.
Automatic Two-Sided Up to 25/36 ppm 8.5 x 11 in.
Up to 24/35 ppm A4 (210 x 297 mm)
Up to 22/35 ppm 8.5 x 14 in.
Paper Handling - Input
Duplex Automatic Document Feeder
Capacity
Sizes Custom Sizes: 2.75 x 6 in. to 8.5 x 14 in. / 70 x 152 mm to 216 x 356 mm
1
100 sheets
WorkCentre
4250S/4260S
A multifunction device
with automatic twosided copy/print/scan,
600-sheet input capacity
and Color Scan to Email,
Scan to Network and Scan
to USB memory drive
WorkCentre
4250S/4260S
WorkCentre
4250X/4260X
All the features of
the WorkCentre 4260S
plus Embedded Fax
and LAN Fax
WorkCentre
4250X/4260X
WorkCentre
4250XF
This configuration adds
three 500-sheet paper
trays and a Finisher
WorkCentre
4250XF
WorkCentre
4260XF
This configuration
adds a 500-sheet paper
tray, 2000-sheet High
Capacity Feeder and
Finisher
WorkCentre
4260XF
Weights 12.5 lb. bond to 28 lb. bond (50 to 120 gsm)
Bypass Tray
Capacity
Sizes Custom Sizes: 3.9 x 5.8 in. to 8.5 x 14 in. (99 x 147 mm to 216 x 356 mm)
Weights 16 lb. bond to 53 lb. bond (60 to 200 gsm)
Media Types Plain paper
1
Paper capacities are based on 20 lb/75 gsm stock; capacities will vary with different weight stocks.
1
100 sheets
Envelopes
Labels
Transparencies
Card Stock
Recycled
Punched
Pre-printed
Heavyweight
Archive
Detailed Specifications 1
WorkCentre® 4250/4260
Tray 1 (Standard)
Capacity
1
Sizes Custom Sizes: 3.9 x 5.8 in. to 8.5 x 14 in. / 99 x 147 mm to 216 x 356 mm
Weights 16 lb. bond to 28 lb. bond (60 to 105 gsm)
Media Types Plain paper
Tray 2 (Standard on 4250XF and 4260XF)
Capacity
1
Sizes Custom Sizes: 3.9 x 5.8 in. to 8.5 x 14 in. / 99 x 147 mm to 216 x 356 mm
Weights 16 lb. bond to 28 lb. bond (60 to 105 gsm)
500 sheets
Envelopes
Labels
Transparencies
Card Stock
Recycled
Punched
Pre-printed
Archive
500 sheets
Media Types Plain paper
Envelopes
Labels
Transparencies
Card Stock
Recycled
Punched
Pre-printed
Archive
Trays 3 and 4 (Standard on 4250XF)
Capacity
1
2 Trays at 500 sheets each
Sizes Custom Sizes: 3.9 x 5.8 in. to 8.5 x 14 in. / 99 x 147 mm to 216 x 356 mm
Weights 16 lb. bond to 28 lb. bond (60 to 105 gsm)
Media Types Plain paper
Envelopes
Labels
Transparencies
Card Stock
Recycled
Punched
Pre-printed
Archive
High Capacity Feeder (Standard on 4260XF)
Capacity
1
2000 sheets
Sizes Custom Sizes: 5.5 x 8.5 in. to 8.5 x 14 in. / 148 x 210 mm to 216 x 356 mm
Weights 16 lb. bond to 28 lb. bond (60 to 105 gsm)
1
Paper capacities are based on 20 lb/75 gsm stock; capacities will vary with different weight stocks.
Detailed Specifications 2
WorkCentre® 4250/4260
Media Types Plain paper
Card Stock
Recycled
Punched
Pre-printed
Archive
Paper Handling - Output
Standard Output 500 sheets
Finishing Offline Convenience Stapler: 50-sheet, single position (standard on 4260XF)
Print (available with all configurations except Copier only model)
First-Page-Out-Time 4250: As fast as 8 seconds
4260: As fast as 6 seconds
Print Resolution 600 x 600 dpi (up to 1200 x 1200 enhanced image quality)
Memory (Std/max) 256 MB / 512 MB
Processor 500 MHz
Hard Disk Drive 80 GB (Standard)
®
Language Support PostScript
PCL
PCL
3™ compatibility
®
5e emulation
®
6 emulation
Connectivity USB 2.0, 10/100/1000 Base-TX Ethernet
Direct connect via USB (4250 Copier only)
Printing Features
2
Custom page size
Watermark
Secure Print
Sample Set
Delayed Print
Cover Selection
Paper Selection by Attribute
Toner Saver
N-Up
Image Rotation
Saved Settings
Booklet Creation
Fit to New Paper Size
Collation
Print to / From Hard Drive
Print from USB Memory Drive
Print Drivers Microsoft® Windows® 2003 Server/XP/XP Professional/Vista
®
Mac OS
Sun Microsystems Solaris™ 9/10
Linux Red Hat
X version 10.3 and above
®
ES
2
Fedora™ Core 4
SUSE
IBM AIX
HP-UX 11.0/11i
Novell NetWare
SCO
®
5
®
®
(IP only)
Xerox Global Print Driver
Xerox Mobil Express Driver
®
Font Capability 136 PostScript
80 PCL
®
fonts
fonts
2
Print from USB memory drive enables print features on 4250 Copier only model.
Detailed Specifications 3
WorkCentre® 4250/4260
Copy
Document Scanner Duplex Automatic Document Feeder with 100-sheet capacity
Sides (input:output) 1:1, 1:2, 2:2 and 2:1
Quantity 1 to 999
Resolution 600 x 600 dpi
Concurrency Concurrent scanning and printing
First-Copy-Out-Time 4250: As fast as 7 seconds
4260: As fast as 5 seconds
Copy Features Collation
Reduce/Enlarge 25 to 400% (from Platen and ADF)
Book Copying
Mixed-size Originals
Edge Erase
Image Shift
Booklet Creation
Covers
Lighten/Darken
Transparency Separators
Multi-up
ID Card Copy
Copy to Hard Drive
Background Suppression
Poster
Fax
3
Embedded Fax
, LAN Fax (Optional on 4250 Copier only and 4250S/4260S – 1 line), Network Server Fax Enablement (Optional)
Fax Speed 33.6 Kbps
Memory 80 GB (32 MB dedicated fax memory)
Resolution Up to 600 x 600 dpi (superfine) resolution
Compression MH, MR, MMR, JPEG and JBIG
Fax Features Color Fax Send
Address Book
Polling
Mailboxes
Forward to Fax / Email
Secure Fax
4
Scan
Capability Black-and-white and color scanning
Concurrency Scan while the system is printing copy or network print jobs, or while it is transferring scan to network or fax jobs
Input Speed Black-and-white: Scan up to 55 ipm (8.5 x 11)
Black-and-white Text and Photo: Scan up to 55 ipm (8.5 x 11)
Color: Scan up to 25 ipm (8.5 x 11)
3
Analog phone line required
4
Scan to USB memory drive enables scan features on 4250 Copier only model.
Detailed Specifications 4
WorkCentre® 4250/4260
Resolution 600 x 600 dpi
400 x 400 dpi
300 x 300 dpi (color maximum)
200 x 200 dpi
100 x 100 dpi
72 x 72 dpi
Maximum Scan Area 8.58 x 15.75 in. / 218 x 400 mm
Network Protocol FTP
HTTP
HTTPS
SMB
File Formats TIFF
Multipage TIFF
JPEG
PDF
Supported Scan
Destinations
Scan to Email
Network Scanning
Network Scan to TWAIN/WIA applications
Scan to USB Memory Drive
4
Scan to Email Direct document email from device•
Manual or directory Exchange/Notes/LDAP address searching•
“From” field auto-populated from LDAP (only when authentication is used)•
Network Scanning Uses templates to send scanned images to predefined locations
Scan to USB Scans can be loaded directly onto a user’s portable USB storage device
Scanning Solutions
®
Scan to PC Desktop
Personal Edition (1 Seat)
A desktop and server-based offering that provides document imaging, archiving, editing and organization tools
ScanSoft PaperPort – image viewing and file management software•
ScanSoft OmniPage (for desktop/client installation) – OCR and file format conversion software•
Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox •
WorkCentre to individual desktops
Accounting
5
Xerox Standard Accounting
Tracking Copy, Print, Fax and Scan usage
Accounting Up to 500 User accounts
Up to 250 General accounts
Up to 250 Group accounts
Features Enable/disable via the web UI or the GUI in tools, admin can manage the feature remotely via the web UI, Data
can be exported via a CSV file, user required to enter XSA ID into the print driver when submitting a print job,
similar to secure print.
Network Accounting
Enablement (Optional)
Enhanced Network Accounting with up to the minute data on how the device is being used; comprehensive
management and enterprise scale tracking and reporting of device usage of copy, print, scan and server fax.
Various options available through Xerox Alliance Partner solutions. For details visit www.xerox.com
Accounting Control Xerox Standard Accounting
Network Accounting (with third party integration)
Supports Foreign Device Interface
4
Scan to USB memory drive enables scan features on 4250 Copier only model.
5
Not available on 4250 Copier only model.
Detailed Specifications 5
WorkCentre® 4250/4260
Security
Security Features WorkCentre 4250 Copier only
Image overwrite security
Secure Print (enabled with Print
from USB Memory Drive)
Secure Fax (enabled when Fax Kit
is added)
Device Management
®
Xerox CentreWare
Web
A web-based server application for network administrators that permits web browser-based device management •
from any workstation, whether running Windows or UNIX or any other operating system
Works with any SNMP-managed printer from any manufacturer•
Provides help with device discovery and installations, health checks and troubleshooting, and device upgrades, as •
well as basic accounting and asset management
®
Xerox CentreWare
Internet Services - Integrated Device Web Page
Device Status Web server embedded
Tray status/contents•
Consumables status•
WorkCentre 4250S/4260S, 4250X/4260X, 4250XF/4260XF
Image overwrite security
Network Authentication
802.1x
SNMPv3
Audit log
HTTPS (SSL)
Secure Print
Secure Fax (enabled when Fax Kit is added)
IPSec
Secure LDAP
IPv6
Xerox Secure Access
6
Print Queue Viewing Complete job print queue management—hold, release, promote and delete
Job Submission Print-ready files (PS, PCL, TIFF, PDF)
Output feature selection
Device Administration Allows simple, remote installation setting of configuration options and management of the device
Browsers Windows
Microsoft® Internet Explorer
Macintosh
®
XP, 2000: Netscape Navigator®, Firefox
®
9.x/OS X: Netscape Navigator® 6.x, Apple® Safari™, Firefox
®
®
Linux: Netscape® 6.x
Device Specifications
Duty Cycle
4250: Up to 200,000 pages per month
4260: Up to 250,000 pages per month
Recommended Monthly Print Volume
4250: Up to 20,000 pages per month
4260: Up to 30,000 pages per month
Rated Engine Life
Up to 1,500,000 pages
6
Without EIP functionality.
Detailed Specifications 6
WorkCentre® 4250/4260
Power Consumption
Printing 794 watts
Standby 111 watts
Power save 20 watts
Warm up
(from power save)
Warm up
(from power on)
Operating Temperature
First Print: As fast as 32 seconds
User Interface ready and programmable: 2 seconds
First Print: 73 seconds (maximum)
User Interface ready and programmable: 54 seconds (maximum)
50° to 90° F (10° to 32° C)
Range
Storage Temperature
-4° to 104° F (20° to 40° C)
Range
Maximum Humidity
20% to 80%
Range
Dimensions and Weights Width Depth Height Weight
4250 Copier/
24.5 in. / 622 mm 19 in. / 483 mm 25.5 in. / 648 mm 97 lbs / 44 kg
4250S/4260S
4250X/4260X 24.5 in. / 622 mm 19 in. / 483 mm 25.5 in. / 648 mm 98 lbs / 44.5 kg
4250XF/4260XF 39.5 in. / 1003 mm 26 in. / 660 mm 46 in. / 1168 mm 205 lbs / 93 kg
Package Dimensions Width Depth Height Weight
4250 Copier/
32.1 in. / 815 mm 23.7 in. / 602 mm 27.6 in. / 701 mm 113.8 lbs / 51.6 kg
4250S/4260S
4250X/4260X 32.1 in. / 815 mm 23.7 in. / 602 mm 27.6 in. / 701 mm 114.4 lbs / 51.9 kg
4250XF/4260XF 26 in. / 660 mm 34.5 in. / 876 mm 80 in. / 2,032 mm 278.8 lbs / 126.5 kg
Certifications
FCC Part 15, Class A, FCC Part 68, Listed UL 60950-1/CSA 60950-1-03, CE Mark applicable to Directives 2006/95/EC,
2004/108/EC and 1999/5/ EC, Section 508 ADA, Cerner Tested and Certified
What Comes in the Box
WorkCentre 4250/4260
Starter Toner cartridge (12,000 print capacity)
Drum cartridge (80,000 yield)
8
7
Software and documentation CD, User manual, Quick Installation guide and Warranty booklet
Power cord
Fax phone cord (X and XF configurations)
7
Declared Yield in accordance with ISO/IEC 19752. Yield will vary based on image, area coverage and media used.
8
Yield will vary depending on job run length, media size and orientation.
Detailed Specifications 7
WorkCentre® 4250/4260
Supplies and Options Description Order Number
Toner Cartridge – approx. 25,000 pages
Drum Cartridge – approx. 80,000 pages
Maintenance Kit – 200,000 pages
7
8
8
Network Accounting Enablement 098S04928
Network Fax Server Enablement 098S04931
Fax Kit (Parallel) 097N01685
Fax Kit (Serial) 097N01686
256 MB Memory Upgrade 098N02200
500-Sheet Paper Tray 097N01524
Two Tray Stand (Trays 3 and 4) 097S03677
2000-Sheet High Capacity Feeder 097N01684
Finisher 097N01715
Staple Cartridge 008R12941
106R01409
113R00755
115R00063
Country of Origin
Manufactured in Korea
7
Declared Yield in accordance with ISO/IEC 19752. Yield will vary based on image, area coverage and media used.
8
Yield will vary depending on job run length, media size and orientation.
Supplies Recycling Program
Consumables for the WorkCentre 4250/4260 are part of the Xerox Green World Alliance
Supplies Recycling Program. For more information, please visit the Green World Alliance website
at www.xerox.com/gwa.
©2010 Xerox Corporation. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Xerox Corporation.
®
and XEROX and Design®, CentreWare® and WorkCentre® are trademarks of Xerox Corporation in the U.S. and/or other countries. Adobe® and
Xerox
®
3™ are registered trademarks or trademarks of Adobe Systems, Incorporated. PCL® is a registered trademark of Hewlett-Packard. As an ENERGY
PostScript
®
partner, Xerox Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency. ENERGY STAR and the
STAR
ENERGY STAR mark are registered U.S. marks. All other trademarks are the property of their respective manufacturers. The information in this brochure is
subject to change without notice. 8/10 610P729759G W60SS-01UH
Loading...
