Westinghouse WST2019W User Manual

intelliBLEND

the blender with a brain

™

WST2019W

You can be sure...if it’s Westinghouse

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions

should always be followed including the following:

1. Read all instructions.

2. To protect against risk of electrical shock do not put cord, plugs, or appliance in water or other liquid.

3. Close supervision is necessary when any appliance is used by or near children.

4. Unplug from outlet when not in use, before putting on or taking off parts, and before cleaning.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Contact Consumer Service for examination, repair or electrical or mechanical adjustment.

7. The use of attachments, including canning jars, not recommended by the manufacturer may

cause a risk of injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter.

10. Do not let cord contact hot surface, including the stove.

11. Keep hands and utensils out of the container while blending to reduce the risk of severe injury to persons or damage to the blender. A scraper may be used but must be used only when the blender is not running.

12. Blades are sharp. Handle carefully.

13. To reduce the risk of injury, never place cutter-assembly blades on base with out jar properly attached.

14. Always operate blender with cover in place.

15. When blending hot liquids, remove center piece of two piece cover.

SAVE THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

ADDITIONAL IMPORTANT SAFEGUARDS

1. All users of this appliance must read and understand this Owner’s Manual before operating

or cleaning this appliance.

2. The cord to this appliance should be plugged into a 120V AC electrical outlet only.

3. Do not leave this appliance unattended during use.

4. If this appliance begins to malfunction during use, immediately turn the unit OFF and unplug

the cord. Do not use or attempt to repair the malfunctioning appliance.

5. IF this appliance falls or accidentally becomes immersed in water, unplug it immediately. DO

NOT REACH INTO THE WATER! Do not use this appliance after it has fallen into or becomes immersed in water.

6. To reduce the risk of injury to persons or property, never use this appliance in an

unstable position.

7. Do not use this appliance for other than its intended use.

8. DO NOT USE IF CONTAINER IS CRACKED OR CHIPPED.

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric

shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

SHORT CORD INSTRUCTIONS

A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. Longer detachable power-supply cords or extension cords are available and may be used if care is exercised in their use. If a longer detachable power-supply cord or extension cord is used, (1) the marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance, and (2) the cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.

PLASTICIZER WARNING

CAUTION: To prevent Plasticizers to migrate from the finish of the countertop or tabletop or other furniture, place NON-PLASTIC coasters or placemats between the appliance and the finish of the countertop or tabletop. Failure to do so may cause the finish to darken, permanent blemishes may occur or stains can appear.

INTRODUCTION:

Congratulations on your purchase of the Westinghouse IntelliBLEND blender! This state-of-the-art appliance combines blending versatility, innovative computer technology, and remarkable ease-of-use in order to provide you with the latest in simple and elegant food preparation.

FEATURES

The blender has five speeds - mix, chop, blend, puree and ice crush - along with a pulse function that allows you to generate a burst of power when needed. This range of speeds gives you the ability to prepare a wide variety of foods, from frozen smoothies to soups, sauces, dips, spreads, salad dressings and more.

But your Westinghouse Intelliblend has something extra - an onboard computer chip with over 400 recipes stored in memory. Using the recipe screen and its liquid crystal display (LCD), you can scroll easily through the database and search for recipes by type of food, name of recipe, or even the main ingredient. In just seconds you’ll be able to find a recipe that suits your needs, and your Westinghouse IntelliBLEND will give you detailed instructions explaining exactly how to prepare it. It couldn’t be easier!

Getting to know your Westinghouse

Cap P/N 70957

Lid P/N 70958W

Glass Blending Jar

P/N 70959

Rubber Gasket

P/N 70960

Blade Assembly

P/N 70961

Retaining Ring

P/N 70962W

Recipe Screen

with LCD Display

Blender Base

Speed Control Buttons

ON and Off Buttons

Stainless Steel

Blending Jar

P/N 70959SS

WST2019W IntelliBLEND Blender

The Westinghouse IntelliBLEND blender should include the following parts. If any of the following are missing, contact consumer service:

BEFORE FIRST USE

Caution: Use extreme care when handling the Blade Assembly. Do not touch blades with your fingers. The blades are very sharp and can cause injury if touched.

1. Carefully unpack the Blender.

2. Wash the Container, Lid Cap and Blade Assembly in warm, soapy water. Rinse and dry thoroughly.

3. Clean the Blender Base with a moistened cloth.

DO NOT IMMERSE THE BASE IN WATER.

INSTRUCTIONS FOR USE

Note: Before each use make sure blender is unplugged.

ASSEMBLY

CAUTION: Use extreme care when handling the Blade Assembly. Do not touch the Blades with your fingers. The Blades are very sharp and can cause injury if touched.

1. Place the Blender Base on a clean, dry and sturdy surface.

2. Place the Blade Assembly in the Retaining Ring, and fit the Rubber Gasket over the Blade Assembly as shown in the figure.

3. With the blades and gasket inside the Retaining Ring, hold the jar over the ring and turn the ring counter clockwise onto the bottom of the jar. The gasket should lie flat between the balde assembly and the bottom of the jar. Make sure the retaining ring is firmly screwed onto the bottom of the jar; otherwise it may come loose while the motor is on.

4. Place the jar onto the blender base carefully, making sure it is firmly seated. Use a gently rocking motion if necessary - do not twist.

5. Attach the transparent cap to the plastic blender lid with a one-quarter turning motion.

6. Plug the blender cord into a 120 volt AC electrical outlet. You are now ready to operate your blender.

BLENDER OPERATION:

1. Before turning the blender on, make sure the blender base is placed on a flat, dry surface and the power cord is plugged into an 120V AC electrical outlet.

2. Make sure the blender jar is properly positioned on the base.

3. Add the required ingredients to the blender jar. If you are blending both liquid and solid ingredients, liquid ingredients should be added first. This will allow you to use the tick marks on the blender jar as liquid volume measurement guides if desired. It also provides more consistent blending and reduces the stress placed on the motor. Solid ingredients can be added by dropping them through the lid with the detachable cap removed.

NEVER PUT YOUR HANDS IN THE BLENDER JAR WHILE THE BLENDER IS PLUGGED IN.

4. Small amounts of liquid ingredients can be measured in the detachable cap, which holds up to two fluid ounces and has tick marks for measuring smaller amounts.

5. Always place the lid on the blender jar before blending.
