1
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Introduction/Getting Started

Thank you for purchasing a WD SATA RAID Controller. This installation manual provides instructional steps and information to make the installation process of your new WD SATA Controller as quick and easy as possible.
The WD (WD) SATA (SATA) RAID Controller is a cost-effective, high performance RAID controller that adds performance and reliability to PC desktops and/or servers using SATA drives.
The WD SATA RAID Controller has two independent data channels to support a maximum of two SATA drives per card. The WD SATA RAID Controller supports:
! Striping (RAID 0) - Identical drives can read and write data in parallel to increase
performance.
! Mirroring (RAID 1) - Mirroring increases read performance through load balancing and
elevator sorting while creating a complete backup of your files.
A WD SATA RAID Controller striped array can double the sustained data transfer rate of SATA drives.
The WD SATA RAID Controller offers fault tolerant, data redundancy for entry-level network file servers or simply for desktop PC users wanting to continually protect valuable data on their PC. Each model offers RAID 1 mirroring (for two drives).
Should a drive that is part of a mirrored array fail, the WD SATA RAID Controller uses the mirrored drive (which contains identical data) to assume all data handling. When a new replacement drive is later installed, WD SATA RAID Controller rebuilds data to the new drive from the mirrored drive to restore fault tolerance.
The WD SATA RAID Controller bootable BIOS supports individual drives larger than 137 GB. With FAT32 and NTFS partitioning, the array can be addressed as one large single volume.

WD Array Management Software

The WD Array Management Software offers local and remote management as well as monitoring of all WD arrays that exist anywhere on a network. Windows-based GUI provides e-mail notification of all major events/alarms, memory cache management, logging for Windows 2000 servers, array maintenance, rebuild, and access to all components in array (server, controller, data channels, individual drives, and enclosure). For information on using WD Array Management, refer to the WD Array Management Software User Manual, available from support.wdc.com.
INTRODUCTION/GETTING STARTED - 1
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Key Features and Benefits

The following information offers an overview of the major features of your new WD SATA RAID Controller.

Advanced Hardware Design

Features Benefits
Supports 66 MHz PCI bus motherboards (automatically backward compatible with 33 MHz PCI slots)
Supports: data striping (RAID 0) and mirroring (RAID 1)
Supports SATA Specification Burst data transfer rates up to 150 MB/sec from SATA drives to
Independent data channels for SATA drives Drives can multiply their data transfer performance when striped
PCI Plug-n-Play, PCI Interrupt sharing and coexists with motherboard IDE and SCSI controllers
Supports IDE bus master operation Allows multitasking during disk transfers that increase CPU
Utilizes EasyBuild™ automenu from the WD SATA controllerplus onboard BIOS
Displays status and error checking messages during boot
Allows maximum data transfers of up to 266 MB per second (133 MB/s in 33 MHz slot) over the bus to dramatically reduce the time to save and retrieve large files.
Provides dramatic increase in drive performance and/or fault tolerant options. Offers performance customization and data rebuilds from the BIOS menu.
boost overall system performance.
together and each drive uses a separate data channel.
Easy to install; supports two SATA drives while still supporting four devices on the motherboard ATA controller.
efficiency. The CPU is free to process tasks during IDE data transfers through the PCI Bus to/from system memory.
Has "Auto Setup" option for quick and easy array builds.
Notifies user of possible errors and allows for recovery of mirrored drive arrays directly from EasyBuild.
Employs the latest PCI SATA ASIC technology Fully supports SATA specifications with 150 MB/sec timing and
CRC error-checking at high speeds.
Mirroring supports automatic background rebuilds
Fault tolerance can be restored automatically without rebooting.
INTRODUCTION/GETTING STARTED - 2
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Compatibility

Features Benefits
Compliant with PCI v2.3 Local Bus standard Provides highest level of hardware compatibility.
Compliant with SATA Specification 1.0 Provides full compatibility with first generation SATA hard drives.
Compliant with PCI Bus Master standard. PCI Bus Master support
Tested compatibility to coexist with
Provides 32-bit I/O, Bus Master, and Ultra ATA performance for optimal system performance.
Improves system performance of new and existing installations. motherboards that have integrated IDE controllers
Features LBA and Extended Interrupt13 drive translation in controller onboard BIOS
Breaks capacity barriers for support of drives greater than 137 GB
in capacity. Offers flexible storage options for space demanding
applications.

Kit Contents

! WD SATA RAID Controller ! SATA RAID Controller device drivers diskette ! SATA RAID Controller software utility CD ! Quick Install Guide

Operating Systems

WAR NI NG ! Using an operating system not listed below could result in data loss.
The following operating systems are supported:
! Windows ! Windows XP
! Windows 2000
®
2003 Server

System Requirements

Pentium-class system with an available 32-bit PCI expansion slot (2.2- or 2.3-compliant) or 32-bit portion of a 64-bit PCI slot.
INTRODUCTION/GETTING STARTED - 3
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Unpacking and Handling Procedures

WD controllers are precision instruments and should be handled with care during unpacking and installation. These devices can be damaged by rough handling, shock and vibration, or electrostatic discharge (ESD). Be aware of the following precautions:
! Do not unpack the controller until you are ready to install it. Your controller is packaged
in an anti-static bag.
! Save the packaging materials and anti-static bag should you need to return your
controller. Your warranty will be void if your returned controller is shipped in anything other than the original packaging or WD approved materials.
! To avoid ESD problems, ground yourself by touching the metal chassis of the computer
before handling the controller. Articles of clothing generate static electricity. Do not allow clothing to come in direct contact with the controller.
! Handle the controller by its sides only. Avoid touching the circuit board components.

Register Your WD SATA RAID Controller

Take advantage of WD special offers and product updates by registering your new WD SATA RAID Controller online at https://www.wdc.com/en/products/registration.
INTRODUCTION/GETTING STARTED - 4
2
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Disk Array Concepts

About the WD SATA RAID Controller

The WD SATA RAID Controller is a high performance SATA RAID controller that features concurrent data channel operation and onboard BIOS. The channels on the WD SATA RAID Controller support concurrent operation that allows for overlapped I/O under multi­tasking operating systems and sharing the workload between multiple drives.

About Adapter BIOS

The WD SATA RAID Controller card contains a BIOS code that extends the standard disk service routine provided through Int13. The BIOS is bootable for DOS and other operating systems that rely on the system BIOS for drive operation.

EasyBuild Auto Menu Setup

This setup utility is used to build and manage WD SATA RAID Controller disk arrays. The utility is menu driven and features the Auto Setup (1) option that uses a simple, interactive setup process. Once the array is built, all the array members store the configuration information in the drive's reserved area. See “Creating a Disk Array” on page 10 which provides descriptions of individual functions.

Reserve Sector

Array configuration data about the drive member and other members in the disk array are saved on a special location on the hard drives called the reserve sector. If any member of the array becomes corrupt or lost, the redundant configuration data on the other members can be used for rebuilds.
Disk array members do not have a memory of their drive positions. This allows drives to be placed on different WD SATA RAID Controller connectors or cards within the system without reconfiguring or rebuilding.
DISK ARRAY CONCEPTS - 5
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Disk Array Terms

Disk Array Description

A disk array is formed from a group of two or more hard drives that appear to the system as a single drive. The advantage of an array is to provide better throughput performance and/or data fault tolerance.
Better performance is accomplished by sharing the workload among multiple physical drives.
Fault tolerance is achieved through data redundancy operation where if one (or more) drive fails or has a sector failure, a mirrored copy of the data can be found on another drive(s).
For optimal results, select identical SATA drives to install in disk arrays. The drives' matched performance allows the array to function better as a single drive.

Disk Array Member

The individual hard drives in an array are called members. Each member of a specific disk array has coded in its reserved sector configuration information that identifies the drive as a member. All disk members in a formed disk array are recognized as a single physical drive to the system.

Disk Array Types

For most installations, the EasyBuild setup Auto Setup (1) option will configure your system.
There are two disk array types (RAID 0 and 1) in two categories that can be installed on the WD SATA RAID Controller. Striping is in the Performance category while Mirroring is in the Fault Tolerance category.
Disk arrays within the Performance and Fault Tolerance categories conform to the Redundant Array of Independent Disks technology, or RAID. The RAID levels supported are 0 and 1.
RAID Level Performance Fault Tolerance Capacity No. of Drives
RAID 0 (Striping) Highest No No. Drives x
Smallest Size
RAID 1 (Mirroring) Normal Yes Smallest Size Drive 2
1 to 2
DISK ARRAY CONCEPTS - 6
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

About RAID Levels

Striping (RAID 0)

Reads and writes sectors of data interleaved between multiple drives. When any disk member fails, it affects the entire array. Performance is better than a single drive since the workload is balanced between the array members.
This array type is for high performance systems. Identical drives are recommended for performance as well as data storage efficiency. The disk array data capacity is equal to the number of drive members times the smallest member capacity. For example, one 100 GB and three 120 GB drives will form a 400 GB (4 x 100 GB) disk array.
Stripe Size - A value can be set from 16 KB to 128 KB sector size. The size can directly affect performance. In the EasyBuild BIOS, the default is 64 KB.
Data
1
3
5
7
2
4
6
8
Stripe
Disk Drives

Mirroring (RAID 1)

Writes duplicate data on to a pair of drives while reads are performed in parallel. RAID 1 is fault tolerant because each drive of a mirrored pair is installed on separate IDE channels. If one of the mirrored drives suffers a mechanical failure (for example, spindle failure) or does not respond, the remaining drive will continue to function. This is called Fault Tolerance. If one drive has a physical sector error, the mirrored drive will continue to function.
Data Mirror
1
2
3
4
Disk Drives
On the next reboot, the EasyBuild utility will display an error in the array and recommend replacing the failed drive. Users should replace the failed drive as soon as possible. Due to redundancy, the drive capacity of the array is half the total drive capacity. For example, two 100 GB drives that have a combined capacity of 200 GB would have 100 GB of usable storage. With drives of different capacities, there may be unused capacity on the larger drive.
1
2
3
4
DISK ARRAY CONCEPTS - 7
3
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Installing the SATA RAID Controller

IMPORTANT: This WD SATA RAID Controller supports the following installation configurations: single drive non-RAID, RAID 1, and RAID 0. When installing a single SATA hard drive, follow the non-RAID installation instructions in section 2 below. The single drive install is not supported in RAID because this setup requires the simultaneous formatting of two drives.

Back Up Your Data

Before performing any hardware installation, protect your data by backing up your existing hard drive before installing your new WD hard drive. Most operating systems include a backup utility. Refer to your operating system or utilities documentation for procedures.

Physical Installation

If you wish to include your current bootable SATA drive as part of a bootable Mirrored (RAID 1) array on your WD SATA RAID Controller, you MUST install the Windows 2000, 2003 Server, or XP driver software FIRST onto this drive while it is still attached to your existing hard drive controller (see “Installing Software Drivers” on page 15).
Each WD SATA RAID Controller supports up to two SATA hard drives. For optimal performance, install two identical SATA drives of the same model and capacity. The drives' matched performance allows the array to function better as a single drive. If you are striping (RAID 0) for performance, use up to two new drives. If mirroring (RAID 1) for protection, you can use two new drives OR use an existing drive and a new drive (the new drive must be the same size or larger than the existing drive).
1. Power off the computer and unplug the power cord.
2. Remove the system cover (refer to your system manual for instructions).
3. Remove the inside slot cover of an available 32-bit PCI slot (or 32-bit portion of a 64-bit PCI slot) on the motherboard.
4. Install the WD SATA RAID Controller into the open slot. Secure the bracket to the system's frame (see Figure 1).
Figure 1. Installing the WD SATA RAID Controller
INSTALLING THE SATA RAID CONTROLLER - 8
WD SERIAL ATA RAID CONTROLLER
USER MANUAL
5. Connect your system case's 2- or 4-pin LED cable to the LED connector on the WD SATA RAID Controller.
6. Attach one SATA data cable to each SATA hard drive. Then attach the other end(s) of the cable(s) to the connector(s) on the WD SATA RAID Controller.
Note: The WD SATA RAID Controller is a PCI Plug-n-Play (PnP) device. No changes are necessary in the Motherboard CMOS Setup for resources or drive types in most applications..
Port 2
(Serial)
Management
connector
Figure 2. WD SATA RAID Controller Connectors
Port 1
(Serial)
After completing the physical installation process above, you must create an array before installing an operating system on the drive(s) or using an existing operating system on a drive. Proceed to “Creating a Disk Array” on page 10.
INSTALLING THE SATA RAID CONTROLLER - 9
4
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Creating a Disk Array

The WD SATA RAID Controller allows the creation of one or two drives in a striped array, or two drives in a mirrored array. You can also install a single, non-RAID drive and connect it to the WD SATA RAID Controller.
Use the onboard EasyBuild™ BIOS utility to create a RAID disk array using the attached drives. There are five different ways to create this array:
! Single (non-RAID) ! Performance (RAID 0) ! Security, using two new SATA hard drives (RAID 1, recommended) ! Security, using an existing SATA hard drive and a new SATA drive (RAID 1) ! Security, using Quick Initialization (RAID 1)
Follow the first three steps below prior to executing the steps for each of the different setup options above.
1. Boot your system. If this is the first time you have booted with the WD SATA RAID Controller and drives installed, the WD onboard BIOS will display the following screen.
WD SATA RAID controller (c)2003 Western Digital Technologies, Inc. All Rights Reserved
No array defined . . .
Press <Ctrl-F> to enter EasyBuild (tm) Utility Or press <ESC> key to continue booting the system
2. Press CNTL+F or CNTL+A (depending on the BIOS screen displayed by your controller) to display the EasyBuild Utility Main Menu.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Main Menu]
Auto Setup . . . . . . . . . . . . [1]
View Drive Assignments . . . . . . [2]
Define Array . . . . . . . . . . . [3]
Delete Array . . . . . . . . . . . [4]
Rebuild Array . . . . . . . . . . [5]
[Keys Available]
Press 1...5 to Select Option [ESC] Exit
3. To begin the process of creating an array, do the following:
- To create a single SATA drive non-RAID array, press 3.
- To create all other types of RAID arrays, press 1 to display the Auto Setup Options
Menu (see screen below). This is the fastest and easiest method for creating your first RAID array.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Auto Setup Options Menu]
Optimize Array for: Performance
[Auto Setup Configuration]
Mode . . . . . . . . . . . . Stripe
Spare Drive . . . . . . . . . . . . 0
Drives used in Array . . . . . . . 2
Array Disk Capacity . . . . . 160048
[Keys Available]
CREATING A DISK ARRAY - 10
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Setting Up a Single SATA Non-RAID Drive

To set up a single SATA drive non-RAID array, follow these steps:
1. Press the ARROW keys to highlight the array number you wish to define, then press ENTER to make your selection. The Define Array Definition Menu appears.
2. Move to RAID Mode and press the SPACEBAR to cycle through array types until it says Stripe. Leave Stripe Block size and Gigabyte Boundary at their default values.
3. Move to Drive Assignments, highlight a drive, and press the SPACEBAR to change one drive to Y. Select a drive on SATA drive channel 1 or 2.
4. Press CTRL+Y to save the array information. The Define Array Menu appears again with the new array defined.
5. Press the ESC key twice to exit the EasyBuild utility. Your system will reboot automatically. After reboot, the EasyBuild BIOS will appear showing your newly created array.
WD SATA RAID Controller (c)2003 Western Digital Technologies, Inc. All Rights Reserved
ID MODE SIZE TRACK-MAPPING STATUS 1 * 1+0 Stripe 80024M 611/128/32 Functional
Press <Ctrl-F> to enter EasyBuild(tm) Utility...
Once the drive has been created, format and partition it as a new single hard drive. Use a Windows boot disk, or boot to a Windows 2003 Server, XP, or 2000 operating system CD to partition and format the new drive in Disk Management.
Proceed to “Installing Software Drivers” on page 15 and follow the instructions for WD SATA RAID Controller driver installation during Windows setup.

Creating an Array for Performance (RAID 0)

To create an array for best performance, follow these steps:
1. Press the SPACEBAR until Performance appears under the Optimize Array for section.
2. Press CTRL+Y to save and create the array.
3. Follow the directions on-screen to reboot your system.
Once the array has been created, format and partition the array as if it were a new single hard drive. Use a Windows boot disk, or boot to a Windows 2003 Server, XP, or 2000 operating system CD to partition and format the new array in Disk Management.
For bootable drive arrays, go to“Installing Software Drivers” on page 15 and follow the instructions for WD SATA RAID Controller driver installation during Windows setup.
CREATING A DISK ARRAY - 11
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Creating a Security Array with Two New Drives (RAID 1 recommended)

Under the Security setting, WD SATA RAID Controller permits two drives to be used for a single mirrored array.
Note: When creating a Security array with new drives, a feature called Gigabyte Boundary will automatically be set to ON.
To create an array for data protection using new hard drives, follow these steps:
1. Press the SPACEBAR until Security appears under the Optimize Array for section.
2. Press CTRL+Y to save your selection.
3. The window below will appear.
Do you want the disk image to be duplicated to another or do quick initialize or create only? Y - Create and Duplicate N - Create Only I - Create and Quick Initialize
4. Press N for the Create Only option.
5. A window will appear almost immediately confirming that your Security array has been created. Press any key to reboot the system.
Array has been created. <Press Any Key to Reboot>
Once the array has been created, format and partition the array as if it were a new single hard drive. Use a Windows boot disk, or boot to a Windows 2003 Server, XP, or 2000 operating system CD to partition and format the new array in Disk Management.
For bootable drive arrays, go to “Installing Software Drivers” on page 15 and follow the instructions for WD SATA RAID Controller driver installation during Windows setup.

Creating a Security Array with an Existing Data Drive

Under the Security setting, WD SATA RAID Controller permits two drives to be used for a single Mirrored array in Auto Setup.
Use this method if you wish to use a drive in a single Mirrored array that already contains data and/or is the bootable system drive in your system. You will need another SATA drive of identical or larger storage capacity to set up the array.
CAUTION: If you are creating a Security array using an existing hard drive, back up any important data. Failure to do so could result in data loss.
If you wish to include your current bootable drive as part of a bootable Mirrored (RAID 1) array on your WD SATA RAID Controller, do NOT connect the hard drive to the WD SATA RAID Controller yet.
FIRST, you MUST install the Windows 2003 Server, XP, or 2000 driver software on your existing hard drive. See “Installing Software Drivers” on page 15 for instructions on WD SATA RAID Controller driver installation during Windows setup.
CREATING A DISK ARRAY - 12
WD SERIAL ATA RAID CONTROLLER
USER MANUAL
Follow these steps to create a security array with an existing hard drive:
1. Press the SPACEBAR to choose Security under the Optimize Array for section.
2. Press CTRL+Y to save your selection. The window below will appear.
Do you want the disk image to be duplicated to another or do quick initialize or create only? Y - Create and Duplicate N - Create Only I - Create and Quick Initialize
3. Press Y for the Create and Duplicate option. The window below will appear asking you to select the Source drive to use. EasyBuild will copy all data from the Source drive to the Target drive.
Source Disk
Channel:ID Drive Model Capacity (MB)
----- ----- -----
Target Disk
Channel:ID Drive Model Capacity (MB)
----- ----- -----
Channel:ID Drive Model Capacity (MB) 1 : WD WD740GD-00DAC3 74025 2 : WD WD740GD-00DAC3 74025
] Up [] Down [ESC] Exit [Ctrl-Y] Save
[
[Please Select A Source Disk]
4. Use the arrow keys to choose which drive contains the existing data to be copied. If you have two identical hard drives, determine which hard drive contains existing data via channel ID (Channel 1 or 2). These are concurrent with the physical ports on the WD SATA RAID Controller that the hard drives are connected to. Port 1 = Channel 1 and Port 2 = Channel 2 (see step 6 under “Installing the Serial ATA RAID Controller” on page 8).
5. Press CTRL+Y to save selection and start duplication. The following progress screen will appear.
Start to duplicate the image . . . Do you want to continue? (Yes/No) Y - Continue N - Abort
6. Select Y to continue. If you choose N, you will be returned to step 1.
7. Once complete, the following screen will appear confirming that your Security array has been created. Press any key to reboot the system.
Array has been created. <Press Any Key to Reboot>
The computer should now boot to the operating system on the source drive (now duplicated to the target drive). The source drive will have no visible changes other than in Device Manager where the drive will be listed as the new array instead of a single drive model.
Note: Disk duplication may take up to several hours depending on how much data will be copied to the target drive. For example, 120 GB of data will take an average of one to two hours to be duplicated in a newer computer system.
CREATING A DISK ARRAY - 13
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Creating a Security Array with Quick Initialization

Under the Security setting, the WD SATA RAID Controller permits two drives to be used for a single Mirrored array in Auto Setup.
Use this setting to create a mirrored (RAID-1) array with one or two existing hard drives containing data that you do not want to keep. This method erases the first data block from your existing drives.
CAUTION: Using the Quick Initialization option on existing drives will result in the loss of all data on those drives.
Note: When creating a Security array with new drives, a feature called Gigabyte Boundary will automatically be set to ON.
To create an array for data protection using two new SATA hard drives, follow these steps:
1. Press the SPACEBAR to choose Security under the Optimize Array for section.
2. Press CTRL+Y to save your selection. The window below will appear.
Do you want the disk image to be duplicated to another or do quick initialize or create only? Y - Create and Duplicate N - Create Only I - Create and Quick Initialize
3. Press I for Create and Quick Initialize.
4. A window will appear almost immediately confirming that your Security array has been created. Press any key to reboot the system.
Array has been created. <Press Any Key to Reboot>
Once the array has been created, format and partition the array as if it were a new single hard drive. Use a Windows boot disk, or boot to a Windows 2003 Server, XP, or 2000 operating system CD to partition and format the new array in Disk Management.
For bootable drive arrays, go to “Installing Software Drivers” on page 15 and follow the instructions for WD SATA RAID Controller driver installation during Windows setup.
CREATING A DISK ARRAY - 14
5
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Installing Software Drivers

Following are driver installation procedures for the Windows operating systems that support the WD SATA RAID Controller. The WD SATA RAID Controller software drivers for Windows are included on the diskette.
Drivers and installation instructions for other operating systems are downloadable from our Web site at support.wdc.com.

New Windows Server 2003 Installation

The following details the installation of the WD SATA RAID Controller drivers while installing Windows Server 2003.
1. Start the installation by booting from the drivers diskette. Press F6 after the message "Press F6 if you need to install third party SCSI or RAID driver" appears.
2. When the Windows Server 2003 Setup window is generated, press S to specify an Additional Device(s).
3. Choose Win .NET 2003 WD SATA RAID Controller from the list that appears on screen, then press ENTER.
4. Press S to use the driver on the diskette, then press ENTER to continue with installation. The Windows Server 2003 Setup screen will appear again and display the following message: "Setup will load support for the following mass storage devices." The list will include Win .NET 2003 WD SATA RAID Controller.
Note: If there are any additional devices to be installed, specify them now. When all devices are specified, continue to the next step.
5. From the Windows Server 2003 Setup screen, press ENTER. Setup will now load all device files and then continue the Windows Server 2003 installation.

Existing Windows Server 2003 Installation

After installing the WD SATA RAID Controller and rebooting your system, Windows Server 2003 setup will show a Found New Hardware dialog box.
1. Insert the WD SATA RAID Controller device drivers diskette into the floppy drive.
2. Choose Install the software automatically and press ENTER.
3. Choose Win .NET 2003 WD SATA RAID controller from the list that appears on screen, then press ENTER.
4. If using a driver that has not been digitally signed by Microsoft, you will be asked if you want to continue the installation. Click Continue.
5. When the New Hardware Wizard has finished installing the WD SATA RAID Controller software, click Finish.
INSTALLING SOFTWARE DRIVERS - 15
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Confirming Windows 2003 Server Driver Installation

1. Right-click on the My Computer icon and select Manage from the popup menu.
2. From the left panel, select Device Manager.
3. Click the + in front of SCSI and RAID controllers. "Win .NET 2003 WD SATA RAID Controller" should appear.

New Windows XP Installation

The following intructions detail the installation of the WD SATA RAID Controller drivers while installing Windows XP onto the newly created array.
1. Start the installation by booting from the drivers diskette. Press F6 after the message "Press F6 if you need to install third party SCSI or RAID driver" appears.
2. When the Windows XP Setup window is generated, press S to specify an Additional Device(s).
3. Choose WinXP WD SATA Controller from the list that appears on screen, and then press the ENTER.
4. Press S to use the driver on the diskette, then press ENTER to continue with installation.
5. The Windows XP Setup screen will appear again saying "Setup will load support for the following mass storage devices:" The list will include "WinXP WD SATA RAID Controller."
Note: If there are any additional devices to be installed, specify them now. When all devices are specified, continue to the next step.
6. In the Windows XP Setup screen, press ENTER. Setup will now load all device files and then continue the Windows XP installation.

Existing Windows XP Installation

After installing the WD SATA RAID Controller and rebooting your system, Windows XP setup will show a Found New Hardware dialog box.
1. Insert the WD SATA RAID Controller drivers diskette into the floppy disk drive.
2. Choose Install the software automatically and press the ENTER key.
3. Choose WinXP WD SATA RAID Controller from the list that appears on screen, and then press the ENTER key.
4. If using a driver that has not been digitally signed by Microsoft, you will be asked if you want to continue the installation. Click Continue.
5. When the New Hardware Wizard has finished installing the WD SATA RAID Controller software, click Finish.
INSTALLING SOFTWARE DRIVERS - 16
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Confirming Windows XP Driver Installation

1. Right-click on the My Computer icon and select Manage from the popup menu.
2. From the left panel, select Device Manager.
3. Click the + in front of SCSI and RAID controllers. "WinXP WD SATA RAID Controller" should appear.

New Windows 2000 Installation

The following details the installation of the WD SATA RAID Controller drivers while installing Windows 2000.
1. Start the installation by booting from the drivers diskette. Press F6 after the message "Press F6 if you need to install third party SCSI or RAID driver" appears.
2. When the Windows 2000 Setup window is generated, press S to specify an Additional Device(s).
3. Choose Win2000 WD SATA RAID Controller from the list that appears on screen then press ENTER.
4. The Windows 2000 Setup screen will appear again saying "Setup will load support for the following mass storage devices:" The list will include "Win2000 WD SATA RAID Controller."
Note: If there are any additional devices to be installed, specify them now. When all devices are specified, continue to the next step.
5. From the Windows 2000 Setup screen, press ENTER. Setup will now load all device files and then continue the Windows 2000 installation.
INSTALLING SOFTWARE DRIVERS - 17
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Existing Windows 2000 Installation

After installing the WD SATA RAID Controller and rebooting your system, Windows 2000 setup will show a New Hardware Found dialog box.
1. Choose Add New Hardware Wizard from the list, and then press ENTER.
2. Choose Add/Troubleshoot a device and click Next. The new hardware wizard will show device list
3. Choose Mass Storage controller and click Next. At the following screen click Finish.
4. Choose Display a list the known drivers for this device so that I can choose a specific driver then click Next.
5. When the Windows 2000 supported SCSI adapter drivers list appears, click Have disk.
6. Insert the WD SATA RAID Controller diskette into the floppy disk drive.
7. Choose Win2000 WD SATA RAID Controller from the list that appears on screen, then click Next.
8. Click Yes to confirm continue the installation and copy the driver to system.
9. Remove the diskette and click Finish to restart the system. Windows 2000 will then restart for the driver installation to take effect.

Confirm Windows 2000 Driver Installation

1. Right-click on the My Computer icon and select Manage from the popup menu.
2. From the left panel, select Device Manager.
3. Click the + in front of SCSI controllers. Win2000 WD SATA RAID Controller should appear.
INSTALLING SOFTWARE DRIVERS - 18
6
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

EasyBuild Options and Features

Viewing Drive Array Assignments

EasyBuild can be used to display an array's status, which drives are assigned to an array, and array information.
The View Drive Assignments option (2) in the Main Menu displays whether drives are assigned to a disk array or are unassigned. Under the Assignment column, drives are labeled with their assigned disk array or shown as Free if unassigned. Unassigned drives are not accessible by the OS. The menu also displays the data transfer mode that relates to speed used by each drive (U5 refers to 100 MB/sec transfers, U4 refers to 66 MB/sec transfers, etc.)
Note: The WD SATA RAID Controller will display SATA drive(s) as a U6 transfer mode (133 MB/sec.) which is incorrect. This does not mean that the drive(s) are running in ATA 133 mode. The controller is not setup for displaying the drive(s) as ATA 150 or 150 MB/sec. because there is not a specification for this transfer speed to date. The drive(s) will work at their correct speed of 150 MB/sec while being displayed incorrectly.
To access the Assignments for the drives attached to the controller, follow the steps in this section.
1. Boot the computer and press the CTRL+A keys to display the FastBuild Utility Main Menu.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Main Menu]
Auto Setup . . . . . . . . . . . . [1]
View Drive Assignments . . . . . . [2]
Define Array . . . . . . . . . . . [3]
Delete Array . . . . . . . . . . . [4]
Rebuild Array . . . . . . . . . . [5]
[Keys Available]
Press 1...5 to Select Option [ESC] Exit
2. Press 2 to View Drive Assignments. The screen below displays. Here, you can see that there are two WD 74 GB drives connected that have been assigned to "Array 1."
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[View Drive Assignments]
Channel:ID Drive Model Capacity(MB) Assignment Mode 1 : WD740GD-00DAC3 74025 Array 1 U 2 : WD740GD-00DAC3 74025 Array 1 U 3 : 4 :
[Keys Available]
] Up [] Down [ESC] Exit Mode (U=UDMA, D=DMA)
[
EASYBUILD OPTIONS AND FEATURES - 19
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Deleting An Array

The Delete Array Menu option (4) allows for deletion of a disk array. Do not continue unless the data on the drives have been backed up, or is no longer important and can be erased. Make sure to record all array information including the array type, disk members, and stripe block size in case you wish to undo a deletion.
CAUTION: If you delete an array by accident, immediately create a new Array with the exact same array type, disk members, and stripe block size. Instructions for this are listed in “Creating a Disk Array” on page 10. This action may recover the deleted array.
1. Boot the computer and press the CTRL+A keys to display the FastBuild Utility Main Menu.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Main Menu]
Auto Setup . . . . . . . . . . . . [1]
View Drive Assignments . . . . . . [2]
Define Array . . . . . . . . . . . [3]
Delete Array . . . . . . . . . . . [4]
Rebuild Array . . . . . . . . . . [5]
[Keys Available]
Press 1...5 to Select Option [ESC] Exit
2. Press 3 to Delete Array.
3. To delete an array, highlight the Array you wish to delete and press the DELETE key.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Delete Array Menu]
Array No RAID Mode Total Drv Capacity(MB) Status Array 1 Stripe 2 148050 Functional Array 2 ———— ———— ———— ———— Array 3 ———— ———— ———— ———— Array 4 ———— ———— ———— ————
[Keys Available]
] Up [] Down [ESC] Exit [Del] Delete
[
4. The Array Definition menu appears showing which drives are assigned to this array.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Delete Array Menu]
Array No RAID Mode Total Drv Capacity(MB) Status Array 1 Stripe 2 148050 Functional
Stripe Block: 64 KB Gigabyte Boundary: OFF
[Drive Assignments]
Channel:ID Drive Model Capacity(MB) Assignment 1 : WD WD740GD-00DAC3 74025 Y 2 : WD WD740GD-00DAC3 74025 Y
5. Press
CTRL+Y to confirm Yes to the warning message and continue array deletion.
Are you sure you want to delete this array? Press Ctrl-Y to Delete, others to Abort
6. After deleting the array, create a new array using the Auto Setup menu from the EasyBuild Main Menu outlined in “Creating a Disk Array” on page 10.
EASYBUILD OPTIONS AND FEATURES - 20
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Rebuilding a Mirrored Array

If you receive an error message when booting your system from the WD SATA RAID Controller's BIOS, this may mean that one of the drives attached to the controller may be malfunctioning, or the array may have become unstable. Immediately test the drives to determine which drive is causing the error and replace if necessary. Once the drive is replaced or the drives are deemed correct and free of defect, use the steps listed in this section to rebuild the Drive Array.
1. On bootup, the WD SATA RAID controller's BIOS will display an error message identifying which drive has failed. Please take note of this drive and document for future use.
2. Press CTRL+A to enter the EasyBuild Main Menu.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Main Menu]
Auto Setup . . . . . . . . . . . . [1]
View Drive Assignments . . . . . . [2]
Define Array . . . . . . . . . . . [3]
Delete Array . . . . . . . . . . . [4]
Rebuild Array . . . . . . . . . . [5]
[Keys Available]
Press 1...5 to Select Option [ESC] Exit
3. Press 3 to select Define Array.
4. Select the failed array and identify the Channel and ID of the failed drive.
5. Power off the computer and physically remove the failed hard drive.
6. Replace the drive with an identical model.
Note: If you have tested the drive and it is deemed error free, you will not need to replace the drive. Simply install the drive back onto the RAID Controller exactly how it was before and continue with the steps that follow.
7. Reboot the system and enter the EasyBuild Main Menu by pressing CTRL+A.
8. Press 5 to select Rebuild Array.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Rebuild Array Menu]
Array No RAID Mode Total Drv Capacity(MB) Status Array 1 Mirror 2 148050 Critical Array 2 ———— ———— ———— ———— Array 3 ———— ———— ———— ———— Array 4 ———— ———— ———— ————
[Keys Available]
] Up [] Down [ESC] Exit [Enter] Select
[
9. Highlight the array in which the utility is displaying the status as Critical by using the up or down
ARROW keys.
EASYBUILD OPTIONS AND FEATURES - 21
WD SERIAL ATA RAID CONTROLLER
USER MANUAL
10. Press ENTER. The following screen displays.
EasyBuild(tm) Utility 2.xx (c)2003 Western Digital Technologies, Inc.
[Rebuild Array Menu]
Array No RAID Mode Total Drv Status Array 2 Mirror 2 Critical
Stripe Block: Not Available Gigabyte Boundary: ON
[Select Drive for Rebuild]
Channel:ID Drive Model Capacity(MB) 1 : WD WD740GD-00DAC3 74025
[Keys Available]
] Up [] Down [ESC] Exit [Enter] Select
[
11. Under Select Drive for Rebuild, highlight the replacement drive by using the up or down
ARROW keys.
12. Press ENTER and confirm that the data will be copied on to the selected drive. All data on the replacement drive will be written over with mirrored information from the array drive. A progress bar appears.
13. Once the rebuild process is complete, reboot the system. The WD SATA RAID controller's BIOS will now display the drive with no errors.
Note: Disk Duplication (rebuilding) may take up to several hours depending on how much data will be copied to the new drive. For instance, 120 GB of data would take one to two hours on average to be duplicated in a newer computer system.
EASYBUILD OPTIONS AND FEATURES - 22
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Reserve Sector Implementation

Array configuration data about the drive member (each physical drive on the WD SATA RAID Controller) and other members in the disk array are saved on a special location on the hard drives called the Reserve Sector. If any member of the array becomes corrupt or lost, the redundant configuration data on the other members can be used for rebuilds. Disk array members do not have a memory of their drive positions. This allows drives to be placed on different WD SATA RAID Controller connectors or cards within the system without reconfiguring or rebuilding.
Note: If you use any Third Party Software to re-partition a RAID array, you stand the chance of erasing or destroying the data contained in the Reserve Sector. This could consequentially destroy the data contained on the drive.
In some cases the Reserve Sector can be infected or damaged by drive failure, virus, etc. Listed below are steps on deleting and rebuilding the reserve sector on the drives attached to the WD SATA RAID Controller.
CAUTION: Before removing the Reserve Sector of the drive(s), back up any existing data. Removal of the Reserve Sector of any drive may permanently delete all existing data on the hard drive.
For Mirrored arrays (RAID 1), remove the Reserve Sector from the mirrored drive first (this will appear during Step 3 below) then rebuild the mirrored array. Remove the Sector on the Master Drive only as a last resort.
For Striped arrays (RAID 0), removing the Reserve Sector from any of the drives that are striped will destroy the arrayed data.
To remove the Reserve Sector, follow these steps:
1. During boot up, press CTRL+A to enter the EasyBuild BIOS utility.
2. Press 2 to View Drive Assignments.
3. Press ARROW up or down keys to highlight the drive where you wish to remove the Reserve Sector.
4. Press ALT+F1. The highlighted drive will start blinking on the screen.
5. Press
CTRL+TAB. A message will appear that says the reserved sector (which is where array
information is kept) on the disk will be wiped.
6. Press Y to confirm.
7. Take the appropriate action:
- For striped arrays, repeat this process for each member of the particular array that is
having a problem. When you are finished, press the Esc key twice to reboot.
- For mirrored arrays, press the Esc key twice to reboot.
8. After rebooting, use EasyBuild to re-create the array outlined in “Creating a Disk Array” on page 10.
EASYBUILD OPTIONS AND FEATURES - 23
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Gigabyte Boundary

The Gigabyte Boundary feature is designed for mirrored arrays (RAID 1) in which a drive has failed and the user cannot replace the drive with the same capacity or larger drive. Instead, the Gigabyte Boundary feature permits the installation of a replacement drive that is slightly smaller (within 1 GB) than the remaining working drive (for example, an 80.5 GB drive would be rounded down to 80 GB).
This can be helpful in the event that a drive fails and an exact replacement model is no longer available. Without this feature enabled, the WD SATA RAID Controller will NOT permit the use of a replacement drive that is slightly smaller than the remaining working drive.
For the Gigabyte Boundary feature to work, the Gigabyte Boundary feature must be set to ON when the original mirrored array is created. When enabled, the Gigabyte Boundary feature rounds the drive capacity of both drives to the common whole GB drive size. For example, with the Gigabyte Boundary feature enabled, the remaining working drive can be
80.5 GB and the replacement drive can be 80.3, since both are rounded down to 80 GB. This
permits the smaller drive to be used. Please note that users will lose a small amount of available storage capacity from both drives to arrive at a common drive size.
Note: Gigabyte Boundary is automatically disabled when creating a mirrored array (RAID 1) from an existing drive (versus using two brand new drives). This protects the existing drive's partition table to maintain data integrity.
EASYBUILD OPTIONS AND FEATURES - 24
7
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Tr o u b l e s h o o t i n g & Ti p s

This section is used to assist with troubleshooting conflicts and WD SATA RAID Controller installation problems. Also refer to our product support Web site at support.wdc.com.
The section is divided into the following categories:
! Motherboard Issues ! System CMOS Issues ! Drive Errors ! Operating System Errors ! Audio/Video Editing Tips.

Motherboard Issues

Freeing Additional IRQ Resources

Since the WD SATA RAID Controller supports PCI Interrupt sharing, it is possible to use IRQs already assigned to another PCI card. Interrupt Sharing is not supported with onboard IDE controllers. If the onboard IDE controller(s) are not used, you may disable the controllers to free IRQ 14 and/or 15.

Configuring PCI IRQ Resources

Setting the IRQ for a particular PCI slot will be different depending on the motherboard BIOS. This setting is usually made in the PCI Configuration and/or Plug and Play (PnP) section of the motherboard BIOS setup. There are three common methods that motherboard BIOS's handle assignment of IRQs to PCI slots:
Specifically assigning an IRQ to a particular slot - You can tell the motherboard to use IRQ 10 for PCI slot 1, IRQ 11 for PCI slot 2, etc.
! Listing which IRQs are available to be assigned to the PCI slots - This BIOS has an
option where you specify 1st Available IRQ, 2nd Available IRQ, etc. The BIOS then scans the PCI slots for PCI cards and assigns these IRQs in the order that it finds the PCI cards.
Consult your motherboard manual for information that is specific to your motherboard.

Intermittent Data Problems

Overclocking the PCI bus may cause the system to hang or data corruption. If you experience either of these problems and you are overclocking the PCI bus, set the PCI bus back to its normal setting to see if this is causing the errors.
TROUBLESHOOTING & TIPS - 25
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

System CMOS Issues

Set Motherboard CMOS Boot sequence to boot to WD SATA RAID Controller

On some Motherboard BIOS, it is necessary to set the Boot sequence to SCSI, A:, C: since the WD SATA RAID Controller is identified as a SCSI card.

Motherboard CMOS displays C: or D: drive failure during startup

See the Drive-Related Errors section.

Using an Onboard IDE Card with WD SATA RAID Controller

If an onboard IDE controller is installed with hard drives, enable support in the Motherboard Standard CMOS Setup for the drives. Note that the onboard IDE hard drives will then be the bootable hard disk unless the system BIOS has a boot sequence setting with the option to specify booting to a different device.

Drive-Related Errors

Critical Array Status Error Reported During Boot

If a critical status error message appears on the WD SATA RAID Controller BIOS startup screen for a mirrored array (see below), there is a drive in the array that has failed or is not responding. The WD SATA RAID Controller will identify the failed drive by channel number. The mirrored array has lost its fault tolerance, but will still perform normal drive reads and writes.
Operation aborted because EasyBuild encountered an error as follows:
Location: Channel 2 Array Status: Critical
Please retry using Promise Array Management utility to recover all data. Reboot the system by pressing
Try powering the system off and on to reset the drive. Also confirm that cables are properly attached and the drive is receiving power. If the drive still appears to have failed, refer to the Rebuilding an Array option in the WD Array Management utility as detailed in the WD Array Management User Manual.

Drive Cannot Be Formed Into An Array

Hard drives must be SATA and free of media defects to be added into an array. New, identical drives should be used for each array. Re-secure data and power cabling while checking for proper alignment. Typically, Pin 1 of the drive is closest to the power connector.

System CMOS Displays C: or D: Drive Failure During Startup

Do not reference C: or D: in the Motherboard Standard CMOS for drives attached to the WD SATA RAID Controller controller. Only enter drive information in the Motherboard CMOS for drives attached to the onboard IDE controller.

FDISK Reports a Much Lower Drive Capacity if a Single Physical Drive or a Striped Array Exceeds 64 GB

Due to a limitation with FDISK, the utility reports only the storage capacity that exceeds 64 GB. This is a cosmetic, not actual, limitation. Simply create a single DOS drive partition, reboot, and then format the partition. The Format command will recognize the total capacity of the partition accurately. Windows 2000 will now recognize the total capacity of your array.
TROUBLESHOOTING & TIPS - 26
WD SERIAL ATA RAID CONTROLLER

Unable to Partition or Format Array

USER MANUAL
This condition may occur when the Reserve Sector of one of the drives has become corrupt or bad. Removing the Reserve Sector will remedy any issue related directly to a Bad Reserve Sector.
CAUTION: Before removing the Reserve Sector of the drive(s), back up any existing data. Removal of the reserve sector of any drive permanently deletes all existing data on the hard drive.
For Mirrored arrays (RAID 1), remove the Reserve Sector from the mirrored drive first (this will appear during Step 3 below) then rebuild the mirrored array. Remove the Sector on the Master Drive only as a last resort.
For Striped arrays (RAID 0), removing the Reserve Sector from any of the drives that are striped will destroy the arrayed data.
To remove the Reserve Sector, follow these steps:
1. During boot up, press CTRL+F or CTRL+A to enter the EasyBuild BIOS utility.
2. Choose option 2, View Drive Assignments.
3. Press arrow keys to highlight the drive from which you wish to remove the reserve sector.
4. Press ALT+F1. The highlighted drive will start blinking on the screen.
5. Press CTRL+TAB. A message will appear that says the reserved sector (which is where array information is kept) on the disk will be wiped.
6. Press Y to confirm.
7. Take the appropriate action:
- For striped arrays, repeat this process for each member of the particular array that is
having a problem. When you are finished, press the ESC key twice to reboot.
- For mirrored arrays, hit the ESC key twice to reboot.
8. After rebooting, use EasyBuild to re-create the array.
- For striped arrays, use FDISK and FORMAT after setting up the array.
- For mirrored arrays, rebuild the mirrored array.

Array Constantly Goes Into Critical or Offline Mode During Reboot

See Unable to Partition or Format Array above.

Cannot Rebuild Mirrored (RAID 1) Array

See Unable to Partition or Format Array above.

Fatal Errors or Data Corruption are Constantly Reported When Reading or Writing to Drive Array

See Unable to Partition or Format Array above.
TROUBLESHOOTING & TIPS - 27
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Operating System-Related Issues

The Operating System no longer boots after creating a Mirrored Array using your existing boot drive using Windows 98/NT4/2000/XP/2003 Server

This is due to Drive Geometry issues. You can verify this if you move the original drive back to the onboard controller and it boots successfully. Each controller can view a drive differently. This can be an issue for a new controller that loads the original Master Boot Record (MBR) and then has a problem translating the MBR or the operating system boot record.
For Windows 2000, XP, and 2003 Server, a clean install of the operating system is recommended. This action restores the MBR and OS boot record and requires repartitioning and formatting of the drive.

WD Windows driver does not appear in Device Manager

Windows may already be listing the controller under Other Devices instead of the Hard disk controllers section.
1. In Device Manager under Other Devices to see if it lists a PCI Card or RAID controller. If so, highlight this listing and click on the Properties button then click on the Driver tab.
2. Depending on your version of Windows, choose either Change Driver or Update Driver.
3. Follow the on-screen prompts to complete installation of the driver. If Windows asks if you want to test if the device can be removed safely, click Cancel. Reboot the system to complete installation of the driver.

"Inaccessible Boot Device" Message Appears During Floppyless Install of Windows 2000, XP, or Server 2003

The F6 key was not pressed at the appropriate time. Reboot the system, and press the F6 key when the message "Setup is inspecting your computer's hardware configuration..." appears in Windows NT4 or the message "Press F6 if you need to install third party SCSI or RAID driver" appears in Windows 2000, XP or Server 2003.

"No Hard Drives Found" Message Appears During CD-ROM Install of Windows 2000, XP, or Server 2003

The F6 key was not pressed at the appropriate time. Reboot the system, and press the F6 key when the message "Setup is inspecting your computer's hardware configuration..." appears in Windows NT4 or the message "Press F6 if you need to install third party SCSI or RAID driver" appears in Windows 2000, XP or Server 2003.
TROUBLESHOOTING & TIPS - 28
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Performance Tips

Here are some tips that may optimize performance in a RAID 0 striped array. If you are using an audio/video-editing card, we also recommend reviewing your card's documentation for additional information.

Use WD SATA RAID Controller as D: or other non-bootable drive in a Striped Array

For Audio/Video editing, keep the original system boot drive on the standard IDE controller as C: drive. Partitioning software such as FDISK will see the array as one physical drive, D: or later. This will prevent file fragmentation and provide better accessibility to the array.

Optimize Array for "Performance"

The EasyBuild BIOS Utility autosetup menu allows optimizing the array for Performance applications such as A/V Editing. The default Performance setting (Striping) selects a Stripe Block size of 64. This larger block size is recommended for the data streaming requirements of A/V editing. You may select an even larger block size in manual mode (see Chapter 3).
EasyBuild(tm) BIOS Version 1.xx (Build xxxx) (c)2003 Western Digital Technologies, Inc. All Rights Reserved
[Auto Setup Options Menu]
Optimize Array for: Performance
[Auto Setup Configuration]
Mode . . . . . . . . . . . . . Stripe
Stripe Block Size . . . . . . . . . 64
Drives used in Array . . . . . . . 2
Array Disk Capacity . . . . . . 160048
[Keys Available]
] Up [] Down [←, →, Space] Change Option [ESC] Exit [Ctrl-Y] Save
[

Change Setting of PCI Bus Utilization

Certain brands of video capture cards can produce a glitch on play back of .AVI files. A setting of Less for PCI Bus utilization reduces the time which WD SATA RAID Controller occupies on the PCI bus and frees that time for use by other PCI devices and will eliminate the glitch dropout effect on playback.
1. Run WD Array Management Software. Click on the controller icon in Tree View to display Options in Information View.
2. The PCI bus utilization slider is located at the bottom of the window. Move the slider to the left to reduce the time WD SATA RAID Controller occupies the PCI bus. Then, click Commit.
Once a PCI bus setting has been selected, no reboot is required.
TROUBLESHOOTING & TIPS - 29
8
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Frequently Asked Questions

This section lists frequently asked questions involving pre-installation, drive issues, installation, and post-installation.

Pre-Installation

(Speed, Device Types, Capacity, Cabling)

Q: What kind of hard drives can I use for a WD SATA RAID Controller array?

A: You can use any SATA hard drive(s) to create arrays on the WD SATA RAID Controller. You should use matching drives for multiple-drive arrays to maximize capacity usage as well as performance.

Q: Will ACPI work with hard drives on the WD SATA RAID Controller?

A: Yes.

Q: Can I use ATAPI devices on the WD SATA RAID Controller?

A: No. The WD SATA RAID Controller does not support ATAPI devices.

Q: Will the WD SATA RAID Controller work with 66MHz PCI bus speed?

A: Yes, the WD SATA RAID Controller is designed to accommodate the newer PCI bus speed and is backward compatible with 33 MHz speeds.

Q: How can I change the resources that the WD SATA RAID Controller uses?

A: The WD SATA RAID Controller is fully Plug and Play (PnP). This means all the resources that it uses are given to it by the PnP BIOS on the motherboard. The WD SATA RAID Controller does support IRQ sharing, but this will not work unless ALL the concerned devices support the feature. If your motherboard allows you to control the assignment of these resources, you may be able to remedy the problem by:
! Changing the IRQ assignments to the PCI slots in the motherboard BIOS during boot
up.
! Reset the configuration data in your CMOS. This is usually an option in the PnP section
of your CMOS.
Otherwise, re-install the WD SATA RAID Controller to a different PCI slot.
FREQUENTLY ASKED QUESTIONS - 30
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Q: How does the WD SATA RAID Controller provide storage and/or data protection?

A: WD SATA RAID Controller implements two different types of RAID levels as follows:
RAID 0 (Stripe)
For capacity - The WD SATA RAID Controller array will be as big as the smallest hard drive in the array times however many hard drives are in the array. Any larger hard drives will simply be truncated. The truncated space on the bigger hard drives will then be unusable.
For sustained data transfers - Using WD SATA RAID Controller, a RAID 0 array consisting of two hard drives will transfer at about twice the speed of the slowest hard drive in the array. A RAID 0 array consisting of four hard drives will transfer at about three times the speed of the slowest hard drive in the array.
RAID 1 (Mirror)
For capacity - The WD SATA RAID Controller array will be as big as the smallest hard drive in the array. The larger hard drive will simply be truncated. The truncated space on the bigger hard drive will then be unusable.
For sustained data transfers - The WD SATA RAID Controller array will write data at the rate of the slowest hard drive in the array. The WD SATA RAID Controller array will read data at twice the rate of the slowest hard drive in the array.

Drive Issues

Q: Can I add a drive to a WD SATA RAID Controller RAID array via hot-swap and dynamically adjust the array size/configuration?

A: No. The WD SATA RAID Controller system does not support dynamically adjustable RAID size/configurations.

Q: Do the HDDs on the WD SATA RAID Controller have to be the same size?

A: The HDDs that you use with the WD SATA RAID Controller do not have to be the same size. If the sizes differ, the WD SATA RAID Controller will truncate the bigger hard drive so the drives match. The resulting difference in hard drive space is unusable, so avoid using hard drives of significantly different capacities.

Q: I already have an array on an existing WD SATA RAID Controller. Can I move that array to my new WD SATA RAID Controller?

A: Yes. All WD SATA RAID Controllers read the arrays the same way and can be moved from one controller to another.

Q: Can I take a drive used in a WD SATA RAID Controller array and access it directly with a different controller, such as the one integrated on the motherboard?

A: Only Single-drive striped (RAID 0) and Mirrored (RAID 1) array configurations allow the drive(s) to be accessed individually on another controller. Multiple-drive striped (RAID 0) will not work.
FREQUENTLY ASKED QUESTIONS - 31
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Q: If I have a problem with one of the drives on the WD SATA RAID Controller, how can I low-level format it to correct the problem?

A: Do NOT do this. Low-level formatting is unnecessary and generally does not correct problems commonly experienced during use.
Errors such as bad sectors or ECC/CRC failure are best remedied by completely replacing the drive. For this reason, do NOT low-level format the drives attached to the WD SATA RAID Controller.

Q: Do I have to install disk management software on my array to access the full storage capacity of drives?

A: No. Disk management software will only complicate things. The array should be fully addressable by your OS as it is. Remember that some operating systems have varying limits on the sizes of partitions and logical drives that can be defined. Consult your OS documentation about partitioning larger drives.

Q: What system BIOS setup settings do I use for the drives on the WD SATA RAID Controller?

A: None. The drives on the WD SATA RAID Controller are supported by the WD SATA RAID Controller BIOS and/or OS drivers, not by your system BIOS.

Q: How do I partition/format my WD SATA RAID Controller RAID array?

A: The WD SATA RAID Controller represents the array as a single hard drive to your system. Therefore, anything that you can do to a single hard drive you can do to a WD SATA RAID Controller array. For example, you should use the FDISK and FORMAT utilities to partition/format the array. You can partition the array as you see fit. You can format the array with any file system you wish.

Installation Issues

(Capacity, Booting)

Q: Why are some drives recognized by the WD SATA RAID Controller Array Setup utilities with only partial capacity?

A: Some hard drives ship with a jumper that reduces the addressable capacity of the drive to prevent problems with older systems that don't support larger drives. Consult your hard drive documentation to set the jumper so that you can use the full capacity of the drive.

Q: How can I change the system boot sequence to boot from the WD SATA RAID Controller array?

A: The boot sequence is controlled by the system BIOS. As far as the system BIOS is concerned, the WD SATA RAID Controller and defined arrays are categorized as a SCSI device. This allows you to set the boot sequence in your BIOS setup utility to boot from SCSI first, rather than IDE.
If there are multiple SCSI add-in controllers in the system, then the boot sequence among them will be determined exclusively by their PCI slot priority. PCI slot #1 will be first, slot #2 second, etc. Put the WD SATA RAID Controller in the PCI slot where it will be accessed ahead of other SCSI controllers if you want to boot from the array.
FREQUENTLY ASKED QUESTIONS - 32
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Q: How can I change the boot sequence between a PCI SCSI card and the WD SATA RAID Controller RAID array?

A: Since all PCI devices are Plug and Play, it is difficult to determine which device is addressed first. Some newer motherboard BIOSs have advanced options that identify devices and allow you to select which device will be assigned resources first. Otherwise you may have to physically switch the device cards on the PCI slots so that the boot device is in the highest priority slot number (see previous question).

Post-Installation

Q: Why can't I see the drives on the WD SATA RAID Controller under FDISK?

A: You have not created an array yet. If no array has been created, the system will not recognize drive(s) attached to the WD SATA RAID Controller.
FREQUENTLY ASKED QUESTIONS - 33
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Appendix A: Regulatory Compliance

FCC Class B Information

This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
! Reorient or relocate the receiving antenna. ! Increase the separation between the equipment and receiver. ! Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
! Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
The user may find the following booklet prepared by the Federal Communications Commission helpful: “How to Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the US Government Printing Office, Washington, DC 20402. Stock No. 004-000-00345-4.

CSA Notice

Le prent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B préscrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.
This digital apparatus does not exceed the Class B limits for radio noise for digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

CE Compliance For Europe

Verified to comply with EN55022 for RF Emissions and EN50082-1 for Generic Immunity, as applicable.
APPENDIX A: REGULATORY COMPLIANCE - 34
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Appendix B: Warranty Information

Obtaining Service

WD (WD) values your business and always attempts to provide you the very best of service. If this Product requires maintenance, either contact the dealer from whom you originally purchased the Product or visit our product support Web site at support.wdc.com for information on how to obtain service or a Return Material Authorization (RMA). If it is determined that the Product may be defective, you will be given an RMA number and instructions for Product return. An unauthorized return (i.e., one for which an RMA number has not been issued) will be returned to you at your expense. Authorized returns must be shipped in an approved shipping container, prepaid and insured, to the address provided on your return paperwork. Your original box and packaging materials should be kept for storing or shipping your WD product. To conclusively establish the period of warranty, check the warranty expiration (serial number required) via support.wdc.com. WD shall have no liability for lost data, regardless of the cause, recovery of lost data, or data contained in any Product placed in its possesssion.

1 Year Limited Warranty

WD warrants that the Product, in the course of its normal use, will be free from defects in material and workmanship for a period of one (1) year and will conform to WD's specification therefor. This limited warranty period shall commence on the purchase date appearing on your purchase receipt.
WD shall have no liability for any Product returned if WD determines that the Product was stolen from WD or that the asserted defect a) is not present, b) cannot reasonably be rectified because of damage occurring before WD receives the Product, or c) is attributable to misuse, improper installation, alteration (including removing or obliterating labels), accident or mishandling while in your possession. Subject to the limitations specified above, your sole and exclusive warranty shall be, during the period of warranty specified above and at WD's option, the repair or replacement of the Product. The foregoing warranty of WD shall extend to repaired or replaced Products for the balance of the applicable period of the original warranty or ninety (90) days from the date of shipment of a repaired or replaced Product, whichever is longer.
The foregoing limited warranty is WD's sole warranty and is applicable only to products sold as new. The remedies provided herein are in lieu of a) any and all other remedies and warranties, whether expressed, implied or statutory, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose, and b) any and all obligations and liabilities of WD for damages including, but not limited to accidental, consequential, or special damages, or any financial loss, lost profits or expenses, or lost data arising out of or in connection with the purchase, use or performance of the Product, even if WD has been advised of the possibility of such damages.
In the United States, some states do not allow exclusion or limitations of incidental or consequential damages, so the limitations above may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
APPENDIX B: WARRANTY INFORMATION - 35
WD SERIAL ATA RAID CONTROLLER
USER MANUAL

Appendix C: WD Service and Support

If you need additional information or help during the installation or normal use of this product, visit our product support Web site at support.wdc.com to choose from the following options:
! Warranty Services–Obtain warranty information, warranty status, product replacement,
RMA status, and shipping and packaging information.
! Downloads Library–Download installation software and drivers. ! Technical Information–Get access to product specifications, technical tips, and online
forum.
! Knowledge Base–Explore our expert knowledge base and frequently asked questions
(FAQs).
! Service & Support Options–Look up available service and support options in your
region.
! Contact Support–Contact a support representative by phone or e-mail.
APPENDIX C: WD SERVICE AND SUPPORT - 36
Loading...
