Western Digital My Book Premium Edition II Quick Install Guide

My Book
Premium Edition™ II
Quick Install Guide
External Desktop
Kit Contents
My Book Premium Edition II
Installation and software CD
Kit Contents
•My Book
• FireWire
Premium Edition
®
800 cable
• FireWire 400 cable
• USB 2.0 certified cable
• AC adapter with power cord
• Installation and software CD
• Quick Install Guide
Compatibility
II triple interface dual-drive storage system with RAID
EN
Quick Install Guide
AC Power Adapter
FireWire 800 Cable
FireWire 400 Cable
Windows
®
Macintosh
®
• Available USB or FireWire port • Available USB or FireWire port
• Windows 2000/XP
•Mac
®
OS X 10.3 or later
Note: Compatibility may vary depending on user’s hardware configuration and operating system.
Important: For highest performance and reliability, it is recommended that you install the latest updates and service pack (SP). For Windows, go to the Start menu and select Windows Update. For Mac, go to the Apple menu and select
Software Update.
About Your Drive
My Book Premium Edition II is preformatted for Windows (NTFS) and is pre-configured for RAID 0 (Striped) mode for maximum capacity and accelerated performance. This product also supports RAID 1 (Mirrored) mode for data protection. For more information on this product including instructions on changing the RAID configuration or drive format, refer to the user manual included on the CD.
Note: For instructions on repartitioning and reformatting the drive to HFS+ (Journaled) prior to installation, see knowledge base answer ID 287 at support.wdc.com.
USB Cable
My Book Premium Edition II | 1
Installing the Drive
Windows
Important: You must first install the drive utilities on the included CD before connecting the unit.
1. Turn on your computer.
2. Insert the software CD into the CD-ROM drive.
3. The CD autoruns and drive utilities are installed automatically. If a security alert is displayed during this installation, click Accept or Continue.
Note: If AutoPlay is disabled on your computer, you must run the CD manually.
4. A menu displays a list of options including software, documentation, and a registration link. Click My Book RAID Manager to install this utility.
5. When finished, click any other selection of your choice; otherwise, click Quit to close the menu.
6. Connect the unit’s power cord and interface cable (USB, FireWire 800, or FireWire 400) as shown, after which the unit mounts to the system.
My Book is now ready for use. For further information including product features, utilities, RAID configuration, drive replacement, and troubleshooting, refer to the user manual provided on the CD.
My Book Premium Edition II | 2
Macintosh
1. Turn on your computer.
2. Insert the software CD into the CD-ROM drive.
3. Double-click the CD-ROM drive icon, the My Book drive icon, then the Mac folder, which contains the software for this device.
4. Double-click My Book RAID Manager to install this program into the Applications folder.
5. WD Button Manager Software disk image contains the installer required to enable the capacity gauge and Safe Shutdown
. Double-click this icon to install the program into the Applications folder.
6. If you want to install the backup software now, double-click the WD Backup™ icon in the Mac folder and follow the instructions as prompted.
7. Connect the unit’s power cord and interface cable (USB, FireWire 800, or FireWire 400) as shown, after which the unit mounts to the system.
My Book is now ready for use. For further information on this product including drive features, utilities, RAID configuration, drive replacement, and troubleshooting, refer to the user manual provided on the CD.
