IOM-WQ-W100T

W100T Twin Alternating Series Softeners

Installation, Operation and Maintenance Manual

Table of Contents

System Speciﬁcation Table ................................2

Safety Information .......................................3

General Warnings .......................................3

How To Use This Manual ..................................4

Pre-Installation Considerations ...................................4

General Installation Instructions ...................................5

W100T System Programming ............................ 6

W100T Quick Programming Guide ..........................6

Regeneration and Error Screens ............................7

Button Operation and Function .............................8

Regeneration Cycles and Times ............................8

User Displays ..........................................9

Conﬁguration Settings ...................................10

Setting Regeneration Cycle Times ..........................14

Installer Display Settings .................................15

Diagnostics ...........................................17

W100T Twin Alternating Softener

WARNING

Read this Manual BEFORE using this equipment. Failure to read and follow all safety and use information

can result in death, serious personal injury, property damage, or damage to the equipment.

Keep this Manual for future reference.

WARNING

You are required to consult the local building and plumbing codes prior to installation. If the information in this manual is not consistent with local building or plumbing codes, the local codes should be followed. Inquire with governing authorities for additional local requirements.

WARNING

Need for Periodic Inspection/Maintenance: This product must be tested periodically in compliance with local codes, but at least once per year or more as service conditions warrant. All products must be retested once maintenance has been performed. Corrosive water conditions, and/or unauthorized adjustments or repair could render the product ineffective for the service intended. Regular checking and cleaning of the product’s internal components helps assure maximum life and proper product function.

HYDROCARBONS SUCH AS KEROSENE, BENZENE, GASOLINE, ETC., MAY DAMAGE PRODUCTS THAT CONTAIN O-RINGS OR PLASTIC COMPONENTS. EXPOSURE TO SUCH HYDROCARBONS MAY CAUSE THE PRODUCTS TO LEAK. DO NOT USE THE PRODUCT(S) CONTAINED IN THIS DOCUMENT ON WATER SUPPLIES THAT CONTAIN HYDROCARBONS SUCH AS KEROSENE, BENZENE, GASOLINE, ETC.

W100T Part List and Drawings ..........................18

Front Cover and Drive Assembly ...........................18

Valve Body Compliance Table ............................. 19

W100T with 1.050” Distributor Tube Opening Identiﬁcation .......19

Drive Cap Assembly, Downﬂow Piston, Upﬂow Piston,

Regenerant Piston and Spacer Stack Assembly ...............20

Twin Transfer ..........................................21

Injector Cap, Injector Screen, Injector, Plug and O-Ring..........23

Injector Order Information ................................24

Reﬁll Flow Control Assembly and Reﬁll Port Plug ...............29

Drain Line – 3/4” .......................................30

Drain Line - 1” .........................................31

V4017-01 T1 Interconnect Fitting Assembly...................32

D1400 1191 In/Out Head ................................33

W100T Control Valve System Description .................34

Drive Assembly ........................................34

Drive Cap Assembly, Main Piston and Regenerant Piston ........34

Spacer Stack Assembly..................................35

Injector Cap, Screen, Injector Plug and Injector . . . . . . . . . . . . . . . . 35

Reﬁll Flow Control Assembly or Reﬁll Port Plug ................35

Drain Line Flow Control and Fitting Assembly .................36

Service Instructions ..................................37

Drive Assembly ........................................37

Drive Cap Assembly, Main Piston and Regenerant Piston ........38

Spacer Stack Assembly..................................39

Injector Cap, Screen, Injector Plug and Injector . . . . . . . . . . . . . . . . 39

Reﬁll Flow Control Assembly or Reﬁll Port Plug ................39

Water Meter...........................................40

Servicing Transfer Cap Assemblies .........................41

Troubleshooting ......................................43

NOTES ..............................................47

System Speciﬁcation Table

A. Models Chart

MINERAL TANK BRINE TANK FLOW RATE & PRESSURE

TANK

SIZE

RESIN

GRAVEL

(LBS.)

TANK

SIZE

SALT

FILL

SERVICE

(GPM)

DROP

(PSI)

BKW

(GPM)

SHIP WT.

(LBS.)

MODEL NO.

CAPACITY

(MAX.)

PIPE SIZE

(IN.)

M2058-W100T 30,000 1 9 x 48 1 15 18 x 40 400 13-19 15-25 2.2 230 M2059-W100T 45,000 1 10 x 54 1.5 20 18 x 40 400 14-21 15-25 2.7 290 M2060-W100T 60,000 1 12 x 52 2 30 18 x 40 400 15-21 15-25 2.7 420 M2063-W100T 75,000 1 13 x 54 2.5 45 18 x 40 400 15-21 15-25 4.2 460

M2066-W100T 90,000 1 14 x 65 3 60 18 x 40 400 17-22 15-25 5.3 500

M2069-W100T 120,000 1 16 x 65 4 80 18 x 40 400 17-24 15-25 7.5 650

M2070-W100T 150,000 1.25” x 1.5” 18 x 65 5 100 24 x 41 600 18-25 15-25 10 890

M2072-W100T 210,000 1.25” x 1.5” 21 x 62 7 100 24 x 50 800 20-27 15-25 12 1160

2 W100T Twin Alternating Series Softeners

Safety Information

This water conditioner’s control valve conforms to UL/CE Standards. Generic valves were tested and certiﬁed for compliance as veriﬁed by the agency listing.

• Please review the entire Installation and Operation Manual before installing the water conditioning system.

• As with all plumbing projects, it is recommended that a trained professional water treatment dealer install the water conditioning system. Please follow all local plumbing codes for installing this water conditioning system.

• This system will not make microbiologically unsafe water safe. Water that is unsafe must be treated separately from this conditioner.

• This water conditioning system is to be used only for potable water.

• Inspect the water conditioning system for carrier shortage or shipping damage before beginning installation.

• Use only lead-free solder and ﬂux, as required by federal and state codes, when installing soldered copper plumbing.

• Use caution when installing soldered metal piping near the water conditioning system. Heat can adversely affect the plastic control valve and bypass valve.

• All plastic connections should be hand tightened. Teﬂon® tape may be used on connections that do not use an O-ring seal. Do not use pipe dope type sealants on the valve body. Do not

use pliers or pipe wrenches.

• Do not use petroleum-based lubricants such as Vaseline, oils or hydrocarbon-based lubricants. Use only 100% silicone lubricants.

• Use only the power transformer supplied with this water conditioning system.

• All electrical connections must be completed according to local codes.

• The power outlet must be grounded.

• Install an appropriate grounding strap across the inlet and

outlet piping of the water conditioning system to ensure that a proper ground is maintained.

• To disconnect power, unplug the AC adapter from its power source.

• Observe drain line requirements.

• Do not support the weight of the system on the control valve

ﬁttings, plumbing, or the bypass.

• Do not allow this water conditioning system to freeze. Damage from freezing will void this water conditioning system’s warranty.

• Operating ambient temperature: 40° to 110°F (5° to 43°C).

• Operating water temperature: 40° to 110°F (5° to 43°C).

• Operating water pressure range : 25 to 120 psi (1.7 to 8.27

bar).

• Observe all warnings that appear in this manual.

• Keep the media tank in the upright position. Do not turn upside

down or drop. Turning the tank upside down or laying the tank on its side can cause media to enter the valve.

• Use only regenerants designed for water conditioning. Do not use ice melting salt, block salt or rock salt. During cold weather it is recommended that the installer warm the valve to room temperature before operating. Teﬂon® is a trademark of E.I. duPont de Nemours.

General Warnings

• The control valve, ﬁttings and/or bypass are designed to accommodate minor plumbing misalignments but are not designed to support the weight of a system or the plumbing.

• HYDROCARBONS SUCH AS KEROSENE, BENZENE, GASOLINE, ETC., MAY DAMAGE PRODUCTS THAT CONTAIN O-RINGS OR PLASTIC COMPONENTS. EXPOSURE TO SUCH HYDROCARBONS MAY CAUSE THE PRODUCTS TO LEAK. DO NOT USE THE PRODUCT(S) CONTAINED IN THIS DOCUMENT ON WATER SUPPLIES THAT CONTAIN HYDROCARBONS SUCH AS KEROSENE, BENZENE, GASOLINE, ETC.

• THIS WATER METER SHOULD NOT BE USED AS THE PRIMARY MONITORING DEVICE FOR CRITICAL OR HEALTH EFFECT APPLICATIONS.

• Do not use Vaseline, oils, other hydrocarbon lubricants or spray silicone anywhere. A silicone lubricant may be used on black o-rings but is not necessary.

• The nuts and caps are designed to be unscrewed or tightened by hand or with the special plastic wrench. If necessary a pliers can be used to unscrew the nut or cap. Do not use a pipe wrench to tighten or loosen nuts or caps. Do not place a screwdriver in the slots on caps and/or tap with a hammer.

• Do not use pipe dope or other sealants on threads. Use Teﬂon tape on the threaded inlet, outlet and drain ﬁttings. Teﬂon tape is not necessary on the nut connection or caps because of o-ring seals.

• After completing any valve maintenance involving the drive assembly or the drive cap assembly and pistons unplug power source jack from the printed circuit board (black wire) and plug back in or press and hold NEXT and REGEN buttons for 3 seconds. This resets the electronics and establishes the service piston position. The display should ﬂash all wording, then ﬂash the software version and then reset the valve to the service position.

• All plumbing should be done in accordance with local plumbing codes. The pipe size for the drain line should be a minimum of ½”. Backwash ﬂow rates in excess of 7 gpm (26.5 lpm) or length in excess of 20’ (6.1m) require ¾” drain line.

• Solder joints near the drain must be done prior to connecting the drain line ﬂow control ﬁtting. Leave at least 6” between the drain line control ﬁtting and solder joints when soldering pipes that are connected on the drain line control ﬁtting. Failure to do this could cause interior damage to the drain line ﬂow control ﬁtting.

• When assembling the installation ﬁtting package (inlet and outlet), connect the ﬁtting to the plumbing system ﬁrst and then attach the nut, split ring and o-ring. Heat from soldering or solvent cements may damage the nut, split ring or o-ring. Solder joints should be cool and solvent cements should be set before installing the nut, split ring and o-ring. Avoid getting primer and solvent cement on any part of the o-rings, split rings, bypass valve or control valve.

• Plug into an electrical outlet.

NOTICE

All electrical connections must be connected according to local codes. (Be certain the outlet is uninterrupted.)

W100T Twin Alternating Series Softeners 3

• Install grounding strap on metal pipes.

General Warnings (continued)

• This glass ﬁlled Noryl1 (or equivalent) fully automatic control valve is designed as the primary control center to direct and regulate all cycles of a water softener or ﬁlter.

• The control valve is compatible with a variety of regenerants and resin cleaners. The control valve is capable of routing the ﬂow of water in the necessary paths to regenerate or backwash water treatment systems. The injector regulates the ﬂow of brine or other regenerants. The control valve regulates the ﬂow rates for backwashing, rinsing, and the replenishing of treated water into a regenerant tank, when applicable.

• Control valve installation is made easy because the distributor tube can be cut ½” above to ½” below the top of tank thread. The distributor tube is held in place by an o-ring seal and the control valve also has a bayonet lock feature for upper distributor baskets.

• The power adapter comes with a 15 foot power cord and is designed for use with the control valve. The power adapter is for dry location use only. The control valve remembers all settings until the battery power is depleted if the power goes out.

• After the battery power is depleted, the only item that needs to be reset is the time of day; other values are permanently stored in the nonvolatile memory. The control valve battery is not rechargeable but is replaceable.

• No user serviceable parts are on the PC board, the motor or the power adapter. The means of disconnection from the main power supply is by unplugging the power adapter from the wall.

How To Use This Manual

This installation manual is designed to guide the installer through the process of installing and starting up water conditioning systems featuring the ProSense controller. This manual is a reference and will not include every system installation situation. The person installing this equipment should have:

• Training on the control valve.

• Knowledge of water conditioning and how to determine proper

control settings.

• Adequate plumbing skills.

Pre-Installation Considerations

A. Water Pressure

A minimum of 25 pounds of water pressure is required for regeneration valve to operate effectively.

B. Electrical Facilities

A continuous 115 volt, 60 Hertz current supply is required. Make certain the current supply is always hot and cannot be turned off with another switch.

C. Existing Plumbing

Condition of existing plumbing should be free from lime and iron buildup. Piping that is built up heavily with lime and/or iron should be replaced. If piping is clogged with iron, a separate iron ﬁlter unit should be installed ahead of the water softener.

D. Location Of Softener And Drain

The softener should be located close to a drain.

E. Bypass Valves

Always provide for the installation of a bypass valve.

F. Valve to Tank Installation Instructions

1. Spin the valve onto the tank, ensuring the threads are not crossthreaded.

NOTICE

The main control valve and tank adaptor have right-hand threads, or clockwise, to install

2. Rotate the valve freely without using force until it comes to a stop (this position is considered zero).

3. Rotate the valve clockwise from zero, between ¼ turn and ½ turn to fully tighten. No tools are needed. Hand tight is enough. Overtightening may cause valve or tank damage.

NOTICE

If lubricant is required, a silicone compound is strongly recommended. Dow Corning Watts), is recommended for best possible results. Dow Corning Release Compound is used in the manufacture of this control valve. The use of other types of lubricants may attack the control’s plastic or rubber components. Petroleum-based lubricants can cause swelling in rubber parts, including O-rings and seals.

Silicone Compound (available from

Noryl is a trademark of Sabic.

4 W100T Twin Alternating Series Softeners

Pre-Installation Considerations (continued)

G. Pre Installation and Loading of Media

Systems that are 13” in diameter and larger are not loaded with media. These systems must be loaded with media before placing into service. To load a system follow the below steps.

1. Cap the top open end of the distributor tube with tape and plastic sheeting to keep foreign debris from entering the distributor tube. This cap must be secure and not come off during media loading.

2. Place the distributor tube, screen end down, into the mineral tank and center it in the bottom. The top of the distributor tube should be ﬂush with the top of the tank. If 4” x 2.5” tank bushings are used, the distributor tube should be ﬂush with the top of the tank bushing.

3. Make sure the plastic and tape cap is secure to the top of the distributor tube, place a funnel on the top of the tank and load ﬁrst the gravel (if different sizes of gravel are used load the largest gravel ﬁrst, then the smaller gravel) then the resin media into the tank. The cap must not come off of the distributor tube during the loading of the media.

4. Remove the plastic cap from the distributor tube. DO NOT PULL UP ON THE DISTRIBUTOR TUBE when removing the cap. The distributor tube top must remain ﬂush with the top of the tank.

5. Clean any media from the threads and top of the mineral tank.

6. Lubricate the O-rings on the bottom of the control valve (distributor pilot O-ring and top of tank O-ring). Use nonpetroleum based silicone lubricant only.

7. Place the control valve on top of the tank. When doing this step, seat the top of the distributor tube inside the centered O-ring sealed port on the bottom of the valve ﬁrst then press the valve down until the tank threads come in contact with the valve threads. This ensures that the distributor tube is properly seated into the bottom of the control valve. Thread the valve on to the tank clockwise. Be careful not to cross thread the valve or over tighten it. A hand tight snug ﬁt is appropriate for the control valve torque. A wrench is not necessary. Do not use thread sealant or PTFE tape on the valve base threads.

8. The system is now ready for installation. Follow the Installation Section in the Installation, Operation and Maintenance Manual.

WARNING

Do not exceed water pressure of 120 psi (8.2 bar). Do not exceed 110°F (43.3°C). Do not subject unit to freezing conditions.

General Installation Instructions

1. Turn off water heater(s).

2. Turn off the main water supply to the home and open an inside faucet (cold and hot) to relieve any pressure within the plumbing system.

3. Place the system in the desired installation location. Make sure that the location is level and sturdy enough to support the weight of the system once it is in operation.

4. Place the bypass valve in the bypass position.

5. Connect the cold water supply to the inlet of the water conditioning system. While constructing the supply line, install a master supply valve (user supplied) in the supply line and close it.

6. Connect the feed water line to the home to the outlet of the system.

7. Plumb the drain line to an appropriate drain abiding by all local, city, and state codes. Use a 3/4” drain line for backwash ﬂow rates of 7 gpm or for drain lines of 7 gpm and less that exceed 20’ in length. Use a 1” drain line for backwash ﬂow rates of 10 gpm and 12 gpm.

8. Connect the brine tank to the water softener control valve brine inlet port using the factory supplied ﬁttings and tubing. Add enough water to the brine tank so that water covers the top of the air check. DO NOT ADD SALT AT THIS TIME.

9. Open the user supplied feed water valve. Check for leaks and repair as needed.

10. Allow the inside hot and cold faucet to remain open until all air has been purged from the plumbing system. Then close the faucet.

11. Locate Manual Regeneration Options in this manual to see the steps to initiate an Immediate Manual Regeneration. Once you have read that section place the system in backwash and unplug the system from its electrical outlet once it has cycled into the backwash position. This will stall the unit in backwash so all air can be purged from one of the tanks.

12. Adjust the user supplied feed water valve to 1/4 open and place the bypass valve into the service position.

13. Air will come out of the drain line until the backwashing tank is completely purged of air. Then water will ﬂow to drain. Allow water to ﬂow to drain for 15 minutes or until the water to drain is clear of resin color throw.

14. Plug the system back into the electrical outlet and manually cycle it through the remaining regeneration steps until it arrives in the service position.

15. Repeat installation steps 11, 12, 13, and 14 of the General Installation Instructions to purge the air from the second tank.

16. Check for leaks and repair as needed.

17. Installation is now complete and the system is ready for programming and one cycle of brine tank reﬁll so that the correct amount of water is in the brine tank for the ﬁrst regeneration cycle. The brine tank reﬁll must be done after programming the system.

W100T Twin Alternating Series Softeners 5

W100T System Programming

W100T Quick Programming Guide

A quick programming guide has been listed below for convenience speciﬁcally for the W100T series water softening systems. For other programming requirements not listed in the Quick Programming Guide, please see the detailed programming section of this manual.

CHART 1: Configuration Settings

Press and Hold Up and Down for 5 seconds Set 2CS to 10T

Press Next Set 4CS to Volume Arrow Only

Press Next Set 5CS to on 0

Press Next Set 7CS to ﬂash between Off and DP

CHART 2: Regeneration Cycle Times

Press and Hold Next and Down for 5 seconds Set 2CT to SoFT

Press Next Set 3CT backwash length

Press Next Set 4CT draw length

Press Next Set 5CT 2

Press Next Set 6CT rapid rinse length

Press Next Set 7CT brine tank reﬁll length

backwash length

CHART 3: Installer Display Settings

Press and Hold Next and Up for 5 seconds Set 2i to gallons between regenerations

Press Next Set 3i to preferred regeneration day override

Press Next On 0 will appear

6 W100T Twin Alternating Series Softeners

Regeneration and Error Screens

Regen Screen

Displays the time remaining in the current cycle. Pressing REGEN advances to the next cycle.

Error Screen

Alternated ﬂashing Err and error code every 3 seconds. Clear by dissconnecting the power supply at the PC board and reconneting, or press NEXT and REGEN simutaneously for 3 seconds.

In Alternator Systems when a unit is waiting to initiate the ﬁrst cycle step of regeneration, “REGEN PndG” is displayed.

“STbY” is displayed in Alternator Systems when a valve is in Standby state.

“REGEN PndG RINSE FILL” is displayed whenever a zero-capacity tank has transferred to an off-line state and is currently waiting to initiate the second portion of a regeneration cycle. Viewed only when Delayed Rinse and Fill is set to ON.

W100T Twin Alternating Series Softeners 7

Button Operation and Function

Scrolls to the next display.

Pressing once and releasing will schedule a regeneration at the preset delayed regeneration time. Pressing again and releasing will cancel the regeneration.

Pressing and holding for 3 seconds will initiate an immediate regeneration Pressing while in regeneration will advance to the next cycle.

Pressing in the program levels will go backwards to the previous screen

Changes variable being displayed.

Key sequence to lock and unlock program settings.

Holding for 3 seconds initiates a control reset. The software version is displayed and the piston returns to the home/service position, resynchronizing the valve.

Used with valve type 1.0T, holding for at least 3 seconds causes a switch in the tank in Service without cycling the regeneration valve. After tank switch, days remaining and capacity remaining status is retained for each tank until the next regeneration.

Regeneration Cycles and Times

Cycle

1. Backwash 1

2. Regenerant Draw/Slow Rinse (downﬂow)

3. Backwash 2

4. Fast Rinse (downﬂow)

5. Regenerant Reﬁll (with treated water)

6. Service (downﬂow)

The user can initiate manual regeneration. The user has the option to request the manual regeneration at the delayed regeneration time or to have the regeneration occur immediately:

1. Pressing and releasing the REGEN button. “ regeneration time. The user can cancel the request by pressing and releasing the REGEN button.

2. Pressing and holding the REGEN button for approximately 3 seconds will immediately start the regeneration. The user cannot cancel this request, except by resetting the control by pressing NEXT and REGEN simultaneously for 3 seconds.

(upﬂow)

1 - 95

1 - 180

1 - 95

0.1 - 99.9 or OFF

” will ﬂash towards Regen on the display and the regeneration will occur at the delayed

Range of times (min.)

Softening Filtering

1 - 95

N/A

1 - 95

N/A

8 W100T Twin Alternating Series Softeners

User Displays

A. General Operation

When the system is operating, one of ﬁve displays may be shown. Pressing NEXT will alternate between the displays shown below.

User 1

Typical user display. If volume is selected in Conﬁguration Settings Step 4CS, shows volume remaining to regeneration. If volume is not selected in Conﬁguration Settings Step 4CS, this screen will not be shown. If a meter is not used this display will not change.

User 2

Displays number of days to next regeneration.

User 3

Displays ﬂow rate in gallons per minute. If a meter is not used this display will be shown but 0 will be displayed. If 1.0 is selected in Step 2CS an “A” in front of the ﬂow rate indicates that the tank with the control valve on it is in service. If “b” is displayed the tank with the in/out head is in service.

This screen will not be shown if 7 day or 28 day is selected in Conﬁguration Settings Step 4CS.

User 4

Displays total ﬂow in gallons since last reset. If a meter is not used this display will be shown but 0 will be displayed. This screen will not be shown if 7 day or 28 day is selected in Conﬁguration Settings Step 4CS.

PRESS ▼ FOR 3 SECONDS TO RESET TO 0.

User 5

Shows current time.

B. Setting Time of Day

• Push NEXT until time of day screen is displayed. Press and hold ▲or ▼ until the SET indicator is displayed, and the hour ﬂashes. Press ▲or ▼until the correct hour is displayed.

• Then press NEXT. The minutes will ﬂash. Press ▲or ▼until the correct minute is displayed.

• Press NEXT to return to the Display Screens. Time of day should only need to be set after power outages lasting more than 8 hours, if the battery has been depleted and a power outage occurs, or when daylight saving time begins or ends. If a power outage lasting more than 8 hours occurs, the time of day will ﬂash on and off which indicates the time of day should be reset. If a power outage lasts less than 8 hours and the time of day ﬂashes on and off, the time of day should be reset and the battery replaced.

W100T Twin Alternating Series Softeners 9

Conﬁguration Settings

Step 1CS

Step 2CS

Step 1CS

Step 2CS

Step 3CS

Step 1CS

Step 2CS

Step 3CS

Step 4CS

Step 1CS

Press ▲ and ▼ simultaneously for 5 seconds and release. If screen in Step 2CS does not appear, the lock on the valve is activated. To unlock press ▼, NEXT, REGEN, ▲ in sequence, then press ▲

simultaneously for 5 seconds and release.

Step 2CS

Choose 1.0 for 1”, 1.25 for 1.25”, 1.5 for 1.5”, 2.0L for 2L, 2.0 for 2” valve¹, 1.0 for 1” twin valve2. Press NEXT to go to Step 3CS. Press REGEN to exit Conﬁguration Settings.

NOTICE

When using the CWS200 valve, if “2L” is set instead on “2.0” for valve type, when the valve is in regeneration and the piston drives to the “Draw” cycle the piston will stall and generate a 1002 error code. Clear error code by pressing NEXT and REGEN simultaneously until the valve resets, then re-program to proper valve type setting.

Step 3CS

When 2.0L or 2.0 are selected, an additional screen will appear. It is used to select which size ﬂow meter is to be used with the valve, 1.5 or 2.0.

Press NEXT to go to Step 4CS. Press REGEN to return to previous step.

and ▼

Step 4CS

Press ▲or ▼ to select one of the following:

• If Volume (gallons) is selected the regeneration will occur after the speciﬁc volume has been used or on the day override (if selected) whichever comes ﬁrst.

•If28/Volume(gallons)isselectedtheregenerationwilloccurontheday(1through28)selectedin

Installer Display Settings. If a meter is not used the total ﬂow and ﬂow rate user displays and the volume display in Diagnostics will be shown as 0.

• If 7/Volume (gallons) is selected the regeneration will occur on the selected day(s) of the week (see instructions contained in Installer Display Settings). If a meter is not used the total ﬂow and ﬂow rate user displays and the volume display in Diagnostics will be shown as 0.

• If 28 is selected the regeneration will occur on the day (1 through 28) selected in Installer Display Settings. The total ﬂow and ﬂow rate user displays and the volume display in Diagnostics will not be shown even if a meter is used.

• If 7 is selected the regeneration will occur on the selected day(s) of the week (see instructions contained in Installer Display Settings). The total ﬂow and ﬂow rate user displays and the volume display in Diagnostics will not be shown even if a meter is used.

Press NEXT to go to Step 5CS. Press REGEN to return to previous step.

¹ When using the CWS200 control valve, the circuit board software must have meter selection choices of 2.0 and 2.0L. The CWS200 valve must be set for the 2.0 meter selection during programming. If the software version does not have both the 2.0 and 2.0L selections, consult your equipment supplier for a replacement circuit board. When using the CWS200 valve with older version software that does not have both 2.0 and 2.0L selection choices, the valve must be set to 2.0 during programming. If a CWS200 valve is being used with newer version software that has both 2.0 and 2.0L selection choices, the valve must be set to 2.0L during programming.

For software rev 519.3 or higher.

Step 5CS

Press ▲or ▼ to select to regenerate immediately on 0 or at delayed time. Immediately on 0 can only be selected if Volume (gallons) was selected in step 4CS and a meter must be installed. Delay is the only option for the other Step 4CS selections. Press NEXT to go to Step 6CS. Press REGEN to return to previous step.

10 W100T Twin Alternating Series Softeners

Step 1CS

Step 2CS

Step 3CS

Step 4CS

Step 1CS

Step 2CS

Step 3CS

Step 4CS

Conﬁguration Settings (continued)

Step 6CS

Volume

Only use No Hard Water Bypass Valves or Motorized Alternating Valves (MAV) with these selections. No Hard Water Bypass Valves (1” or 1.25” V3070FF or V3070FM) are not designed to be used with the alternator or separate source functions. The V3063 and V3063BSPT motorized alternating valves are not designed to be used as a no hard water bypass or separate source inlet if the pressure differential is more than 60 psi.

Volume

A. Conﬁguring the Control Valve for No Hard Water Bypass Operation:

Select nHbP for control operation. For no hard water bypass operation the three wire connector is not used.

Selection requires that a connection to MAV or a No Hard Water Bypass Valve is made to the two pin connector labeled ALTERNATOR DRIVE located on the printed circuit board. If using a MAV, the A port of the MAV must be plugged and the valve outlet connected to the B port. When set to nHbP the MAV will be driven closed before the ﬁrst regeneration cycle that is not FILL or SOFTENING or FILTERING, and be driven open after the last regeneration cycle that is not FILL.

NOTE: If the control valve enters into an error state during regeneration mode, the no hard

water bypass valve will remain in its current state until the error is corrected and reset.

Step 6CS

This display will not appear if 1.0 was selected in Step 2CS. Allows selection of one of the following using

▲or ▼

• the Control Valve to have no hard water bypass;

• the Control Valve to act as an alternator; or

• the Control Valve to have a separate source during

the regeneration cycle.

Select OFF when none of these features are used.

B. Conﬁguring the Control Valve for Separate Source Operation:

Select SEPS for control operation. For separate source operation the three wire connector is not used. Selection requires that a connection to a Motorized Alternator Valve (MAV) is made to the two pin

connector labeled ALTERNATOR DRIVE located on the printed circuit board. The C port of the MAV must be connected to the valve inlet and the A port connected to the separate source used during regeneration. The B port must be connected to the feed water supply.

When set to SEPS the MAV will be driven closed before the ﬁrst regeneration cycle, and be driven open after the last regeneration cycle.

NOTE: If the control valve enters into an error state during regeneration mode, the MAV will

remain in its current state until the error is corrected and reset.

C. Selecting the Control Valve to act as an alternator:

519.0 and higher = Use 3-wire Interconnect Cables for all communication between units.

518.3 and lower = Use 2-wire Interconnect Cables for twin alternators with independent ﬂow meters.

Prior to starting the programming steps, connect the interconnect cable to each control valve board’s three pin connector labeled “INTERCONNECT”. Also connect the meter cord to either control valve to the three pin connector labeled “METER”.

Conﬁguration Settings

Installer Display Setting

Step 4CS Select Volume Set Volume

Step 5CS Set regeneration time option to “On O”. Set regeneration time option to “On O”.

Set to ALTA

Step 6CS

Step 2I Enter the Volumetric Capacity for the System

Step 3I Set Day Over ride to “oFF” Set Day Over ride to “oFF”

Connect ALTA valve to the MAV’s A port and connect the MAV’s two pin wire connector to the two pin connector labeled “DRIVE” on the ALTA valve

Valve Programming Steps

Set to ALTb

Connect ALTb valve to the MAV’s B port. No connections between the ALTB valve and the MAV are made.

Enter the Volumetric Capacity for the System (the same as Valve A)

NOTE: If the control valve is in an error state during regeneration mode the MAV will close the B port and keep open the A port

until the error is corrected and reset.

W100T Twin Alternating Series Softeners 11

Conﬁguration Settings (continued)

Retracted

Valve “A” in Service Position = MAV

piston rod Retracted

Valve “B” in Service Position = MAV

Extended

piston rod Extended

NOTICE

Watts W100T Twin alternators can be set up to operate with a day over-ride setting in conjunction with the main volume based regeneration setting. If a system is programmed for twin alternating with a delayed regeneration, a W100T twin alternator can perform an immediate transfer of the MAV to place a fully regenerated tank on-line and have a delayed regeneration time for the exhausted unit. W100T Twin alternators will only count days on the unit that is on-line which will allow the twin alternating system to regenerate based on only a day over-ride setting when programmed to regenerate based on days.

For Watts Twin Alternating systems using W100T, CWS150, and CWS200 valves there will be an option to delay the last two cycles of regeneration (only “Rinse” and “Fill”). This feature splits the regeneration into two portions. The ﬁrst portion of the regeneration will start immediately and all programmed cycles before the “Rinse” and “Fill” cycles will be performed. After all programmed cycles before “Rinse” and “Fill” are completed the control valve will drive to the service position (displaying “Delayed Rinse + Fill Pending”). When the volume of the on-line unit is depleted to 10% of its programmed capacity, the control valve will be triggered to ﬁnish the second portion of the regeneration and complete the “Rinse” and “Fill” cycles and return to Service and be placed into Standby mode, and wait to come on-line for service.

W100T, CWS150,

CWS200 Valves

For Watts Twin Alternating systems using the CWS200 valve, when NEXT is pressed after selecting ALTA or ALTB, a display will allow the user to set the amount of pre-service rinse time for the stand by tank just prior to returning to service.

Press NEXT to go to Step 7CS. Press REGEN to return to previous step.

12 W100T Twin Alternating Series Softeners

CWS200 Valve

Step 1CS

Step 2CS

Step 3CS

Step 4CS

Step 5CS

Conﬁguration Settings (continued)

Step 7CS

Exit to

Display

scrEEns

Step 7CS

Selecting the use of an outside signal to initiate a regeneration: Selection only matters if a connection is made to the two pin connector labeled DP SWITCH located on the printed circuit board. Following is an explanation of the options:

oFF - Feature not used. NOTE: In a twin alternating system each control must

have a separate dP signal or dP switch. One dP signal or one dP switch cannot be used for both controls.

on0 – If the dP switch is closed for an accumulative time of

2 minutes a regeneration will be signaled to the unit. In a twin alternating system the MAV will transition ﬁrst to switch units so that the signaled unit can start regeneration. After the MAV has fully transitioned, the regeneration begins immediately.

NOTE: For W100T-CWS200 control valves

programmed for twin alternating: if the dP function “on0” is set, the Delayed Rinse and Fill feature is not available.

dELy – If the dP switch is closed for an accumulative time of

2 minutes a regeneration will occur at the scheduled delayed regeneration time. In a twin alternating system once the dP switch is triggered the PC Board will display “REGEN TODAY” and when the delayed regen time comes the control will switch tanks and the triggered unit will then go into regeneration.

NOTE: For W100T-CWS200 control valves

programmed for twin alternating: if the dP function “dEL” is set, the Delayed Rinse and Fill feature is not available.

HoLd – If the dP switch is closed a regeneration will be

prevented from occurring while there is switch closure. In a twin alternating system the regeneration of a unit can be prevented upon switch closure. If the unit depletes the capacity down to zero, it will not be allowed to switch tanks to regenerate until the switch is open.

NOTE: For W100T-CWS200 control valves

programmed for twin alternating the Delayed Rinse and Fill feature can be set in conjunction with the “HoLd” if desired.

W100T Twin Alternating Series Softeners 13

Press NEXT to exit Conﬁguration Settings. Press REGEN to return to previous step.

Setting Regeneration Cycle Times

Step 1CT

Step 3CT

Step 1CS

Step 2CS

Step 3CS

Step 4CS

Set

Volume

X1000 Regen

Flow

Rate

Step 1CT

Step 2CT

PM Days To

Time

Step 4CT

Regen

Backwash Brine Rinse Fill

Step 1CT

Press NEXT and ▼ simultaneously for 5 seconds and release. If screen in Step 2CT does not appear, the lock on the valve is activated. To unlock press ▼, NEXT, REGEN, ▲ in sequence, then press NEXT and ▼ simultaneously for 5 seconds and release.

Step 2CT

Select between SOFTENING or FILTERING. When set to FLTr, only Steps 3CT and 6CT are available. Press NEXT to go to Step 3CT. Press REGEN to exit Regeneration Cycle Times.

Step 3CT

Adjust the length of the backwash from 1-95 minutes using ▲or ▼.

Press NEXT to go to Step 4CT. Press REGEN to return to previous step.

Step 4CT

Adjust the length of the regenerant draw from 1-180 minutes using ▲or ▼.

Step 5CT

Step 6CT

Step 7CT

Press NEXT to go to Step 5CT. Press REGEN to return to previous step.

Step 5CT

Adjust the length of the second backwash from 1-95 minutes using ▲or ▼.

Press NEXT to go to Step 6CT. Press REGEN to return to previous step.

Step 6CT

Adjust the length of rinse from 1-95 minutes using ▲or ▼.

Press NEXT to go to Step 7CT. Press REGEN to return to previous step.

Step 7CT

Adjust the length of ﬁll from 0.1-99.0 minutes or OFF. CWS200 valves are shipped from the factory with a reﬁll ﬂow control of 2.2 gpm (8.3 lpm). All other control valves are shipped from the factory with a reﬁll ﬂow control of 0.5 gpm (1.9 lpm).

EXIT TO DISPLAY SCREENS

Press NEXT to exit Regeneration Cycle Times. Press REGEN to return to previous step.

14 W100T Twin Alternating Series Softeners

Installer Display Settings

Step 1I

One of three sets of displays will be shown depending on what was selected in Conﬁguration Settings Step 4CS.

A. Volume (Gallons) selected in Conﬁguration Settings Step 4CS

Step 1I

To enter Installer Display press NEXT and ▲ simultaneously for 5 seconds and release.

Step 2I

Volumetric capacity in gallons to regeneration. Press NEXT to go to Step 3I. Press REGEN to exit Installer Display.

Step 3I

Adjust day override from 1 - 28 or OFF. Press NEXT to go to Step 4I. Press REGEN to return to previous step.

Step 4I

Use ▲or ▼ to set the regen hour. Press NEXT to go to Step 5I. Press REGEN to return to the

previous step.

Step 5I

EXIT TO DISPLAY SCREENS

Use ▲or ▼ to set the regen minutes. Press NEXT to exit Installer Display. Press REGEN to return to previous step.

B. 28 Day or 28/Volume (Gallons) selected in Conﬁguration Settings Step 4CS

Step 1I

Step 2I

Step 3I

Step 1I

To enter Installer Display press NEXT and ▲ simultaneously for ﬁve seconds and release.

Step 2I

Adjust days from 1 - 28. Press NEXT to go to Step 3I. Press REGEN to exit Installer Display.

Step 3I

Use ▲or ▼ to set time of the regen hour. Press NEXT to go to Step 4I. Press REGEN to return to previous step.

Step 4I

EXIT TO DISPLAY SCREENS

W100T Twin Alternating Series Softeners 15

Use ▲or ▼ to set the regen minutes. Press NEXT to exit Installer Display. Press REGEN to return to previous step.

Step 1I

Installer Display Settings (continued)

C. 7 Day or 7/Volume (Gallons) selected in Conﬁguration Settings Step 4CS

Step 1I

To enter Installer Display press NEXT and ▲ simultaneously for 5 seconds and release.

Step 2I

Step 3I

Step 4I

Step 2I

Use ▲or ▼ to set the current day of the week.

Default = 2 (Monday)

1 = SUNDAY

2 = MONDAY

3 = TUESDAY

4 = WEDNESDAY

5 = THURSDAY

6 = FRIDAY

7 = SATURDAY

Press NEXT to go to Step 3I. Press REGEN to exit Installer Display.

Step 3I

Scroll through days 1 to 7 using NEXT. Use ▲or ▼ to turn regen on or off for each individual day (regen indicator on means regeneration will happen). After completing the 7th day, press NEXT to go to Step 4I. Press REGEN to go to previous display.

Step 4I

Use ▲or ▼ to set the regen hour. Press NEXT to go to Step 5I. Press REGEN to go to previous display.

EXIT TO DISPLAY SCREENS

Step 5I

Use the ▲or ▼ to set the regen minutes. Press NEXT to exit Installer Display. Press REGEN to return to previous display.

16 W100T Twin Alternating Series Softeners

Diagnostics

Step 1D

Step 2D

Step 3D

Step 1D

Press ▲ and ▼ simultaneously for 5 seconds and release. Then press ▲ and ▼ simultaneously for 3 seconds and release. If screen in Step 2D does not appear the lock on the valve is activated. To unlock press ▼, NEXT, REGEN, ▲ in sequence, then press ▲ and ▼ simultaneously for 5 seconds and release. Then press ▲ and ▼ simultaneously for 3 seconds and release.

Step 2D

Display shows the number of days since a regeneration last occurred. Press NEXT to go to Step 3D. Press REGEN to exit Diagnostics.

Step 3D

Display shows the volume of water treated in gallons treated since the last regeneration. If Volume (gallons), 28/Volume (gallons), or 7/Volume (gallons) was selected in Step 4CS and no meter is installed this display will read 0. Press NEXT to go to Step 4D. Press REGEN to return to previous step.

Step 4D

Step 5D

Step 4D

Display shows the days in service since start up. Press NEXT to go to Step 5D. Press REGEN to return to previous step.

Step 5D

Display shows the total number of regeneration cycles since start up. Press NEXT to exit Diagnostics. Press REGEN to return to previous step.

EXIT TO DISPLAY SCREENS

W100T Twin Alternating Series Softeners 17

W100T Part List and Drawings

Front Cover and Drive Assembly

Drawing No. Order No. Description Quantity

1 V3175EE-01 W100T Front Cover Assembly 1

2 V3107-01 W100T Motor 1

3 V3106-01 W100T Drive Bracket & Spring Clip 1

4 V3408EE-03BOARD W100T THRU 2L/2 EEPCBRD MAV/ALT REPL 1

5 V3110 W100T Drive Gear 12x36 3

6 V3109 W100T Drive Gear Cover 1

Not Shown

Not Shown V3178 W100T Drive Back Plate 1

Refer to Control Valve Service Manual for other drawings and part numbers.

V3186 W100T AC ADAPTER 120V-12V

V3186-01 W100T AC ADAPTER CORD ONLY

AC Adapter U.S. International

Supply Voltage 120 V AC 230V AC Supply Frequency 60 Hz 50 Hz Output Voltage 12 V AC 12 V AC Output Current 500 mA 500 mA

When replacing the battery, align

positives and push down to fully seat.

Battery Fully Seated

Correct Battery

Orienta

tion

Battery replacement is

3 volt lithium coin cell

type 2032.

18 W100T Twin Alternating Series Softeners

Valve Body Compliance Table



Application Injector and/or Plug(s) Main Piston

1” Downﬂow Softener or Regenerating Filter

1” Backwash Only Filter

1” Upﬂow Softener

Injector in “DN” hole, Plug in “UP” hole

Plug in “DN” and “UP” holes, Install Reﬁll Port Plug

Injector in “UP” hole, Plug in unlabeled hole

V3011 V3174 V3005 V3031

V3011 None V3005 V3031

V3011-01 V3174 V3005 V3031

Regenerant

Piston

Stack Body*

W100T with 1.050" Distributor Tube Opening Identiﬁcation



Spacer Color: Grey

1.25"



1.25"

NOTE: The downﬂow piston is a solid amber color. The upﬂow piston is black and amber.

W100T Twin Alternating Series Softeners 19

Drive Cap Assembly, Downﬂow Piston, Upﬂow Piston, Regenerant Piston and Spacer Stack Assembly

Drawing No. Order No. Description Quantity

1 V3005 W100T Spacer Stack Assembly 1

2 V3004 Drive Cap ASY 1

3a V3011* W100T Piston Downﬂow ASY

3b V3011-01* W100T Piston Upﬂow ASY

4 V3174 W100T Regenerant Piston 1

5 V3135 O-ring 228 1

*V3011 is labeled with DN and V3011-01 is labeled with UP. Upﬂow option is not applicable to EA, EE or EI control valves.

NOTE: The regenerant piston is not used in backwash only applications.

Refer to programming and Cover Drawing Manual

20 W100T Twin Alternating Series Softeners

Twin Transfer

W100T Twin Alternating Series Softeners 21

Twin Transfer (continued)

Drawing No. Order No. Description Quantity

1 V3470 SCREW BHC 1/4-20 X 1 SS 12 2 V3724 WASHER FLAT SS 1/4 12 3 V4005-01 T1 TRANSFER CAP ASY 1 4 V4029 O-RING 236 2 5 V4015 T1 TRANSFER SPRING 2 6 V4014 T1 TRANSFER SPRING SUPPORT 2 7 V4036 T1 ROTOR DISK ASY 2 8 V3105 O-RING 215 (DISTRIBUTOR TUBE) 1

9 V3180 O-RING 337 1 10 V4016 T1 TRANSFER SEAL 6 11 V3031 T1 BODY SFT WTR REGEN 1 12 V4023 T1 TRANSFER DRIVE SHAFT ASY 1 13 V3287 O-RING 110 2 14 V4006-01 T1 TRANSFER DRIVE CAP ASY 1 15 V4011-01 T1 TRANSFER DRIVE GEAR ASY 1 16 V4012 T1 TRANSFER DRIVE GEAR AXLE 1 17 V4013 T1 TRANSFER REDUCTION GEAR 1 18 V3264 CWS200 BYPASS REDUCTION GEARAXLE 3 19 V3110 W100T DRIVE REDUCING GEAR 12X36 3 20 V3262-01 1.5” & 2” ALT/2BY REDUCGEARCVRASY 1 21 V3592 SCREW #8-1 PHPN T-25 SS 3 22 V4049 T1 COVER ASSEMBLY 1

NOT SHOWN V4043 T1 TRANSFER MOTOR ASY 1 NOT SHOWN V3151 W100T NUT 1 QC 1 NOT SHOWN V4055* TWIN TANK METER ASY 1 NOT SHOWN V4017-01 T1 INTERCONNECT FITTING ASY 1

NOT SHOWN D1400 1191 IN/OUT HEAD 1

*THIS WATER METER SHOULD NOT BE USED AS THE PRIMARY MONITORING DEVICE FOR CRITICAL OR

HEALTH EFFECT APPLICATIONS.

22 W100T Twin Alternating Series Softeners

Injector Cap, Injector Screen, Injector, Plug and O-Ring

Drawing No. Order No. Description Quantity

1 V3176 INJECTOR CAP 1 2 V3152 O-RING 135 1

3 V3177-01 INJECTOR SCREEN CAGE 1 4 V3010-1Z W100T INJECTOR ASY Z PLUG 1

V3010-1A W100T INJECTOR ASY A BLACK V3010-1B W100T INJECTOR ASY B BROWN V3010-1C W100T INJECTOR ASY C VIOLET V3010-1D W100T INJECTOR ASY D RED V3010-1E W100T INJECTOR ASY E WHITE

Not Shown

* The injector plug and the injector each contain one 011 (lower) and 013 (upper) o-ring.

NOTICE

For upﬂow position, injector is located in the up hole and injector plug is in the other hole. Upﬂow option is not applicable to EA, EE or EI control valves.

For a ﬁlter that only backwashes, injector plugs are located in both holes.

V3010-1F W100T INJECTOR ASY F BLUE V3010-1G W100T INJECTOR ASY G YELLOW V3010-1H W100T INJECTOR ASY H GREEN

V3010-1I W100T INJECTOR ASY I ORANGE V3010-1J W100T INJECTOR ASY J LIGHT BLUE

V3010-1K W100T INJECTOR ASY K LIGHT GREEN

V3170 O-RING 011

V3171 O-RING 013

* *

W100T Twin Alternating Series Softeners 23

Injector Order Information

Injector Order Number Injector Color

V3010-1A Black 6" 8"

V3010-1B Brown 7" 9"

V3010-1C Violet 8" 10"

V3010-1D Red 9" 12"

V3010-1E White 10" 13"

V3010-1F Blue 12" 14"

V3010-1G Yellow 13" 16"

V3010-1H Green 14" 18"

V3010-1I Orange 16" 21"

V3010-1J Light Blue 18"

V3010-1K Light Green 21"

Actual tank size used may vary depending on the design and application of the system. Tank diameter is an approximation for the following:

1. Downﬂow softener using standard mesh synthetic cation exchange media regenerating with sodium chloride.

2. Upﬂow softener using standard mesh synthetic cation exchange media regenerating with sodium chloride, an inlet water pressure of 30 to 50 psi (2.1 to 3.4 bar) and water temperature of 60°F (15.6°C) water or warmer. Higher pressures or lower temperatures would need smaller injectors to avoid lifting the bed.

Typical Tank Diameter

Down Up*

*Not applicable for EA, EE or EI control valves.

24 W100T Twin Alternating Series Softeners

W100T Twin Alternating Series Softeners 25

26 W100T Twin Alternating Series Softeners

W100T Twin Alternating Series Softeners 27

28 W100T Twin Alternating Series Softeners

Reﬁll Flow Control Assembly and Reﬁll Port Plug

Drawing No. Order No. Description Quantity

1 V3195-01 W100T Reﬁll Port Plug Asy

2 H4615 Elbow Locking Clip 1

3 JCP-P-6 Polytube insert 3/8” 1

4 JCPG-6PBLK Nut 3/8” 1

5 H4613 Elbow Cap 3/8” 1

6 V3163 0-ring 019 1

7 V3165-01* W100T RFC Retainer Asy (0.5 gpm) 1

8 V3182 W100T RFC 1

9 V3330-01 W100T Brine Elbow Asy w/RFC 3/8" 1

Not Shown V3552 W100T Brine Elbow Asy w/RFC 1/2" Option

Not Shown H4650 Elbow ½” with nut and insert Option

*Assembly includes V3182 W100T (0.5 gpm) RFC.

This part is required for backwash only systems

Water

Flow

Proper RFC orientation

directs rell water ow

towards the washer face with rounded edge and text.

W100T Twin Alternating Series Softeners 29

Drain Line – 3/4”

Drawing No. Order No. Description Quantity

1 H4615 Elbow Locking Clip 1 2 PKP10TS8-BULK Polytube insert 5/8 Option 3 V3192 W100T Nut ¾ Drain Elbow Option

4* V3158-01 W100T Drain Elbow ¾ Male 1

5 V3163 O-ring 019 1

6* V3159-01 W100T DLFC Retainer ASY 1

V3162-007 W100T DLFC 0.7 gpm for ¾ V3162-010 W100T DLFC 1.0 gpm for ¾ V3162-013 W100T DLFC 1.3 gpm for ¾ V3162-017 W100T DLFC 1.7 gpm for ¾ V3162-022 W100T DLFC 2.2 gpm for ¾ V3162-027 W100T DLFC 2.7 gpm for ¾

*4 and 6 can be ordered as a complete assembly - V3331 W100T Drain Elbow and Retainer Asy

Valves are shipped without drain line ﬂow control (DLFC) - install DLFC before using. Valves are shipped without ¾ nut for drain elbow (polytube installation only) and 5/8" polytube insert (polytube installation only).

V3162-032 W100T DLFC 3.2 gpm for ¾ V3162-042 W100T DLFC 4.2 gpm for ¾ V3162-053 W100T DLFC 5.3 gpm for ¾ V3162-065 W100T DLFC 6.5 gpm for ¾ V3162-075 W100T DLFC 7.5 gpm for ¾ V3162-090 W100T DLFC 9.0 gpm for ¾ V3162-100 W100T DLFC 10.0 gpm for ¾

One DLFC must be used if ¾ ﬁtting is used

Water

Flow

Proper DLFC orientation

directs water ow towards

the washer face with rounded edge.

30 W100T Twin Alternating Series Softeners

Drain Line - 1”

Drawing No. Order No. Description Quantity

1 H4615 Elbow Locking Clip 1

2 V3008-02 W100T Drain FTG 1 Straight 1 3* V3166 W100T Drain FTG Body 1 1 4* V3167 W100T Drain FTG Adapter 1 1 5* V3163 0-ring 019 1 6* V3150 W100T Split Ring 1 7* V3151 W100T Nut 1” QC 1 8* V3105 O-ring 215 1

V3190-090 W100T DLFC 9.0 gpm for 1 V3190-100 W100T DLFC 10.0 gpm for 1 V3190-110 W100T DLFC 11.0 gpm for 1

* Can be ordered as a set. Order number V3008-02, description: W100T Drain FTG 1 Straight.

V3190-130 W100T DLFC 13.0 gpm for 1 V3190-150 W100T DLFC 15.0 gpm for 1 V3190-170 W100T DLFC 17.0 gpm for 1 V3190-200 W100T DLFC 20.0 gpm for 1 V3190-250 W100T DLFC 25.0 gpm for 1

One DLFC must be used if 1” ﬁtting is used

Water

Flow

Proper DLFC orientation

directs water ow towards

the washer face with rounded edge.

W100T Twin Alternating Series Softeners 31

V4017-01 T1 Interconnect Fitting Assembly

Drawing No. Order No. Description Quantity

1 V3151 W100T Nut 1" Quick Connect 4 2 V3150 W100T Split Ring 4 3 V3105 O-Ring 215 4 4 V4017 T1 Interconnect Fitting 2

A. Fitting Installation Instructions:

• Installation ﬁttings are designed to accommodate minor plumbing misalignments, but are not designed to support the weight of a system or the plumbing.

• Slide nut on ﬁrst, then the split ring and o-ring.

• Hand tighten the nut only.

The V4017-01 can be used on tanks up to 10” in diameter.

If using 12” diameter tanks or larger V4052 PIPE PVC SCH 80 1-1/4X 20 (36 pieces per box) may be purchased and combined with two V3007-07 W100T FTG 1.25&1.5 PVC SLVNT ASY. The V4052 PIPE PVC SCH 80 1-1/4X 20 can be cut to the desired length.

32 W100T Twin Alternating Series Softeners

D1400 1191 In/Out Head

Drawing No. Order No. Description Quantity

1 V3180 O-Ring 337 1 2 V3105 O-Ring 215 (Distributor Tube) 1

W100T Twin Alternating Series Softeners 33

W100T Control Valve System Description

The W100T control valves consist of the following components:

1. Drive Assembly

2. Drive Cap Assembly, Main Piston and Regenerant Piston

3. Spacer Stack Assembly

4. Injector Cap, Screen, Injector Plug and Injector

Drive Assembly

The drive assembly consists of the following parts:

• Drive Bracket

• Printed Circuit (PC) Board

• Motor

• Drive Gears

• Drive Gear Cover

The drive bracket holds the PC board, the motor, the drive gears and the drive gear cover in place.

The PC board receives and retains information, displays the information, determines when to regenerate and initiates regeneration. The display shows different types of information in the initial system set up (for softeners or ﬁlters), installer display settings, diagnostics, valve history or user display settings.

The PC board powers the motor. The PC board’s two-prong jack connects wires to the direct current (DC) motor. The motor is held in place on the drive bracket by a spring-loaded clip and a small bulge in the plastic, which ﬁts in one of the slots on the motor housing. The motor turns drive gears that drive the piston to cycle positions for backwashing, regeneration, rinsing, reﬁll or service. The motor is fully reversible (turns both ways) and changes direction of rotation to change the direction of piston motion. The motor is easily replaced if necessary.

5. Reﬁll Flow Control Assembly or Reﬁll Port Plug

6. Drain Line Flow Control and Fitting Assembly

7. Water Meter

8. Twin Transfer Valve

There are three drive gears held in place by the drive gear cover. All three drive gears are the same size. A reﬂective coating is applied to the gears. As the center drive gear turns a light shines on the coating and a light sensing diode determines if a light pulse was returned. The PC board counts the pulses and determines when to stop driving the motor.

Drive Cap Assembly, Main Piston and Regenerant Piston

The drive gears turn the main gear of the drive cap assembly, which moves the piston. The screw-driven, horizontally moving piston stops at speciﬁc positions to direct the ﬂow of water to backwash, regenerate, rinse or reﬁll. The PC board determines the position of the piston by counting pulses produced when the piston is moved. An optical sensor looking at one of the reduction drive gears generates these pulses. Each cycle position is deﬁned by a number of pulses. The counter is zeroed each time the valve goes to the service position. The PC board ﬁnds the service position by noting the increase in current delivered to the motor when the mechanical stop at the service position is reached. This method of controlling piston position allows for greater ﬂexibility and requires no switches or cams (U.S. Patent 6444127).

One of two main pistons is always used:

1. A 1.25" diameter downﬂow piston is used when the W100T control valve is used as a downﬂow softener, regenerating ﬁlter or nonregenerating ﬁlter.

2. A 1.25" diameter upﬂow piston is used when the W100T control valve is used as an upﬂow softener. Upﬂow option not applicable for EA, EE or EI control valves.

If the control valve is used as a softener or a regenerating ﬁlter, a regenerant piston must be attached to the main piston. If the control valve is to be used on a system that does not require a regenerant to be added, the regenerant piston must be removed.

34 W100T Twin Alternating Series Softeners

Spacer Stack Assembly

The spacer stack assembly provides the necessary ﬂow passage for water during the different cycles. The all-plastic spacer stack assembly (U.S. Patent 6402944) is a one-piece design which allows the stack to be removed using your ﬁngers.

The exterior of the stack is sealed against the body bore with self lubricating EPDM o-rings, while the interior surface is sealed against the piston using slippery self cleaning directional (one-way) silicone lip seals. The lip seals are clear in color and have a special slippery coating so

that the piston does not need to be lubricated.

Injector Cap, Screen, Injector Plug and Injector

The screen, injector and/or injector plug(s) are installed under the injector cap in an easy to access location on top of the valve. The injector cap contains four slots so no water accumulates in the cap. The injector cap is designed to be hand tightened.

Under the injector cap there is an easy to clean removable screen to prevent fouling of the injector. There are two holes under the injector cap labeled “DN” and “UP”. The holes will be ﬁlled with a plug or an injector.

The plug (Order # V3010-1Z) prevents water from traveling a certain pathway. The injector lets water pass through the pathway. The selfpriming injector increases the velocity of the water, creating a zone of negative pressure that draws in the concentrated liquid regenerant, such as sodium chloride (brine), potassium permanganate, etc. The regenerant blends with the stream of water, which passes through the media to regenerate the bed.

The injector provides a consistent regenerant/water mixture ratio over the entire operating pressure range of the control valve. The injector provides good performance in a variety of applications, which may involve elevated drain lines and long regenerant draw lengths. Injectors are chosen by knowing the type, amount, and regenerant ﬂow rate for a particular type of media. Guidelines can be found in the media manufacturer’s literature. The color coded injectors give different regenerant draw, slow rinse and total ﬂow rates over the pressure range. See injector graphs (pages 25-28) for total, slow rinse and draw ﬂow rates.

The control valve has been manufactured to be one of the following:

• regeneration downﬂow W100T (for softeners or regenerating ﬁlters install injector in DN location, plug in UP location)

• regeneration upﬂow W100T (upﬂow option is for softeners only, which are not EA, EE or EI control valves. Install injector in UP location,

plug in other hole location)

• no regenerant W100T (both the DN and UP holes have injector plugs installed) and plug installed for the reﬁll elbow

NOTICE

It is okay to ﬁeld convert valves from upﬂow to downﬂow and vice versa with the W100T valve as long as software supports upﬂow brine.

Reﬁll Flow Control Assembly or Reﬁll Port Plug

The reﬁll ﬂow control assembly consists of a reﬁll ﬂow elbow, reﬁll ﬂow control retainer assembly, reﬁll ﬂow control, polytube insert and nut assembly. The reﬁll ﬂow control retainer ﬁts in the reﬁll elbow. The reﬁll ﬂow control retainer houses the reﬁll ﬂow control which controls the ﬂow rate when the regenerant tank is being reﬁlled. The reﬁll ﬂow control is a ﬂexible washer-like part with a small oriﬁce and a precision molded contour that delivers a steady 0.5 gpm regenerant tank reﬁll rate at varying inlet pressures. Reﬁll is accomplished with treated water.

The reﬁll ﬂow control assembly is installed in an easy to access reﬁll elbow located on top of the control valve. The reﬁll ﬂow control assembly is attached to the control valve with a locking clip. The locking clip allows the elbow to rotate 270 degrees so the outlet can be orientated towards the regenerant tank.

The control valve has a standard reﬁll elbow to which a 3/8” ﬂexible tube can be connected. An optional elbow can be ordered which accommodates a ½” ﬂexible tube for a high regenerant draw rate situation. Both elbows use the same reﬁll ﬂow control and retainer.

If the control valve is to be used as a non-regenerant ﬁlter control valve, the reﬁll elbow is removed and replaced with a reﬁll port plug P/N V3195-01.

W100T Twin Alternating Series Softeners 35

Drain Line Flow Control and Fitting Assembly

The drain line ﬂow control assembly includes a drain line ﬂow control and a ﬁtting. The drain line ﬂow control allows proper media bed expansion by regulating the ﬂow rate to the drain. The drain line ﬂow control is a ﬂexible washer-like part with an oriﬁce and a precision molded contour. The ﬂow rates are within ± 10% over the pressure range of 20 psi to 125 psi (1.4 bar to 8.6 bar). See table for ﬂow rate information.

A. Drain Line Flow Control and Fitting Assembly Information

Drain Line Fitting

¾” V3162-007 007 0.7 2.6

¾” V3162-010 010 1.0 3.8

¾” V3162-013 013 1.3 4.9

¾” V3162-017 017 1.7 6.4

¾” V3162-022 022 2.2 8.3

¾” V3162-027 027 2.7 10.2

¾” V3162-032 032 3.2 12.1

¾” V3162-042 042 4.2 15.9

¾” V3162-053 053 5.3 20.1

¾” V3162-065 065 6.5 24.6

¾” V3162-075 075 7.5 28.4

¾” V3162-090 090 9.0 34.1

¾” V3162-100 100 10.0 37.9

1” V3190-090 090 9.0 34.1

1” V3190-100 100 10.0 37.9

1” V3190-110 110 11 41.6

1” V3190-130 130 13 49.2

1” V3190-150 150 15 56.8

1” V3190-170 170 17 64.3

1” V3190-200 200 20 75.7

1” V3190-250 250 25 94.6

Drain Line Flow Control Order

No.

Number on Drain Line Flow Control

Backwash Flow Rate

(gpm)

Backwash Flow Rate

(lpm)

The drain line ﬂow control and ﬁtting are located on top of the control valve and replaceable without the use of special tools.

The drain line ﬂow control can be installed in the standard ¾” drain line elbow, which accommodates 5/8” polytube or ¾” NPT drain line connections. The optional nut and polytube insert for the ¾” drain line elbow is designed for use with ﬂexible polytube only. The ¾” drain line elbow can be rotated 180 degrees so the outlet can be orientated to the nearest drain. The same retainer is used for all drain line ﬂow controls for the ¾” ﬁtting. Drain line ﬂow controls designed for the 3/4” ﬁtting are available for ﬂow rates ranging from 0.7 to 10 gpm (2.6 to 37.9 lpm).

An optional 1” straight drain line ﬁtting is available to accommodate drain line ﬂow rates ranging from 9 to 25 gpm (34.1 to 94.6 lpm). This ﬁtting is straight but still connects to the control valve using the same locking clip. The drain line ﬂow control is located between two ﬁtted parts (i.e. the ﬁtting acts as the retainer). The nut is unscrewed to access the drain line ﬂow control.

36 W100T Twin Alternating Series Softeners

Service Instructions

Drive Assembly

Remove the valve cover to access the drive assembly.

Disconnect the power source plug (black wire) from the PC board prior to disconnecting the motor or water meter plugs from the PC board. The power source plug connects to the four-pin jack. The motor plug connects to the two-pin jack on the left-hand side of the PC board. The water meter plug (gray wire) connects to the three-pin jack on the far right-hand side of the PC board.

The PC board can be removed separately from the drive bracket but it is not recommended. Do not attempt to remove the display panel from the PC board. Handle the board by the edges. To remove the PC board from the drive bracket, unplug the power, water meter and motor plugs from the PC board. Lift the middle latch along the top of the drive bracket while pulling outward on the top of the PC board. The drive bracket has two plastic pins that ﬁt into the holes on the lower edge of the PC board. Once the PC board is tilted about 45° from the drive bracket it can be lifted off of these pins. To reinstall the PC board, position the lower edge of the PC board so that the holes in the PC board line up with the plastic pins. Push the top of the PC board towards the valve until it snaps under the middle latch, weave the power and water meter wires into the holders and reconnect the motor, water meter and power plugs.

The drive bracket must be removed to access the drive cap assembly and pistons or the drive gear cover. It is not necessary to remove the PC board from the drive bracket to remove the drive bracket. To remove the drive bracket start by removing the plugs for the power source and the water meter. Unweave the wires from the side holders. Two tabs on the top of the drive back plate hold the drive bracket in place. Simultaneously lift the two tabs and gently ease the top of the drive bracket forward. The lower edge of the drive bracket has two notches that rest on the drive back plate. Lift up and outward on the drive bracket to disengage the notches.

To reassemble, seat the bottom of the drive bracket so the notches are engaged at the bottom of the drive back plate. Push the top of the drive bracket toward the two latches. The drive bracket may have to be lifted slightly to let the threaded piston rod pass through the hole in the drive bracket. Maintain a slight engaging force on top of the drive bracket while deﬂecting the bracket slightly to the left by pressing on the side of the upper right corner. This helps the drive gears mesh with the drive cap assembly. The drive bracket is properly seated when it snaps under the latches on the drive back plate. If resistance is felt before latching, then notches are not fully engaged, the piston rod is not in hole, the wires are jammed between the drive bracket and drive back plate, or the gear is not engaging the drive cap assembly.

To inspect the drive gears, the drive gear cover needs to be removed. Before trying to remove the gear cover, the drive bracket must be removed from the drive back plate. (Refer to the instructions above regarding removing the drive bracket from the drive back plate. The drive gear cover can be removed from the drive bracket without removing the motor or the PC board.) The drive gear cover is held in place on the drive bracket by three clips. The largest of the three clips is always orientated to the bottom of the drive bracket. With the PC board facing up, push in and down on the large clip on the drive gear cover. Handle the cover and the gears carefully so that the gears do not fall off the pegs in the cover.

Replace broken or damaged drive gears. Do not lubricate any of the gears. Avoid getting any foreign matter on the reﬂective coating because dirt or oils may interfere with pulse counting.

The drive gear cover only ﬁts on one way, with the large clip orientated towards the bottom. If all three clips are outside of the gear shroud on the drive bracket the drive gear cover slips easily into place.

The drive bracket does not need to be removed from the drive plate if the motor needs to be removed. To remove the motor, disconnect the power and motor plugs from the jacks on the PC board. Move the spring clip loop to the right and hold. Rotate the motor at least a ¼ turn in either direction so the wires are vertical (up & down) before gently pulling on the wire connectors to remove the motor. Pulling directly on the wires without rotating the motor may break the wires off the motor.

Replace the motor if necessary. Do not lubricate the motor or the gears. To reinstall the motor, move the spring clip loop to the right and hold. Gently turn the motor while inserting so that the gear on the motor meshes with the gears under the drive gear cover. Release the spring clip loop and continue to rotate the motor until the wires are horizontal and the motor housing engages the small plastic bulge inside the drive bracket motor retainer. Reconnect the motor plug to the two-pronged jack on the lower left side of the PC board. If the motor will not easily engage with the drive gears when reinstalling, lift and slightly rotate the motor before reinserting. Reconnect the power plug.

Replace the valve cover. After completing any valve maintenance involving the drive assembly or the drive cap assembly and pistons unplug power source jack from the printed circuit board (black wire) and plug back in or press and hold NEXT and REGEN buttons for 3 seconds.This resets the electronics and establishes the service piston position. The display should ﬂash all wording, then ﬂash the software version and then reset the valve to the service position.

W100T Twin Alternating Series Softeners 37

Drive Cap Assembly, Main Piston and Regenerant Piston

The drive assembly must be removed to access the drive cap assembly. The drive cap assembly must be removed to access the piston(s). The drive cap assembly is threaded into the control valve body and seals with an o-ring. To remove the drive cap assembly use the special plastic wrench or insert a ¼” to ½” ﬂat blade screwdriver into one of the slots around the top 2” of the drive cap assembly so it engages the notches molded into the drive back plate around the top 2” of the piston cavity. The notches are visible through the holes. Lever the screwdriver so the drive cap assembly turns counter clockwise. Once loosened unscrew the drive cap assembly by hand and pull straight out.

The drive cap assembly contains the drive cap, the main drive gear, drive cap spline, piston rod and various other parts that should not be dissembled in the ﬁeld. The only replaceable part on the drive cap assembly is the o-ring. Attached to the drive cap assembly is the main piston (downﬂow or upﬂow) and if a regenerant is used, a regenerant piston. Upﬂow is not applicable to EA, EE or EI control valves.

The regenerant piston (the small diameter one behind the main piston) is removed from the main piston by pressing sideways and unsnapping it from its latch. Chemically clean in dilute sodium bisulﬁte or vinegar, or replace the regenerant piston if needed. To remove the main piston fully extend the piston rod and then unsnap the main piston from its latch by pressing on the side with the number. Chemically clean in dilute sodium bisulﬁte or vinegar, or replace the main piston.

Reattach the main piston to the drive cap assembly. Reattach the regenerant piston (if needed) to the main piston. Reinsert the drive cap assembly and piston into the spacer stack assembly and hand tighten the drive cap assembly. Continue to tighten the drive cap assembly using a screwdriver as a ratchet until the black o-ring on the spacer stack assembly is no longer visible through the drain port. Excessive force can break the notches molded into the drive back plate. Make certain that the main drive gear still turns freely. The exact position of the piston is not important as long as the main drive gear turns freely.

Reattach the drive assembly to the control valve and connect all plugs. After completing any valve maintenance involving the drive assembly or the drive cap assembly and pistons unplug power source jack from the printed circuit board (black wire) and plug back in or press and hold NEXT and REGEN buttons for 3 seconds. This resets the electronics and establishes the service piston position. The display should ﬂash all wording, then ﬂash the software version and then reset the valve to the service position.

38 W100T Twin Alternating Series Softeners

Spacer Stack Assembly

To access the spacer stack assembly remove the drive assembly, drive cap assembly and piston. The spacer stack assembly can be removed easily without tools by using thumb and foreﬁnger. Inspect the black o-rings and clear lip seals for wear or damage. Replace the entire stack if necessary. Do not disassemble the stack.

The spacer stack assembly may be chemically cleaned (dilute sodium bisulﬁte or vinegar) or wiped with a soft cloth.

The spacer stack assembly can be pushed in to the control valve body bore by hand. Since the spacer stack assembly can be compressed it is easier to use a blunt object (5/8” to 1-1/8” in diameter) to push the center of the assembly into the control valve body. The assembly is properly seated when at least four threads are exposed (approximately 5/8”). Do not force the spacer stack assembly in. The control valve body bore interior can be lubricated with silicone to allow for easy insertion of the entire stack.

Reattach the drive cap assembly and piston(s) and the drive assembly.

After completing any valve maintenance involving the drive assembly or the drive cap assembly and pistons unplug power source jack from the printed circuit board (black wire) and plug back in or press and hold NEXT and REGEN buttons for 3 seconds. This resets the electronics and establishes the service piston position. The display should ﬂash all wording, then ﬂash the software version and then reset the valve to the service position.

Injector Cap, Screen, Injector Plug and Injector

Unscrew the injector cap and lift off. Loosen cap with special plastic wrench or pliers if necessary. Attached to the injector cap is a screen. Remove the screen and clean if fouled.

The plug and/or injector can be pried out with a small screwdriver. The plug can be wiped clean. If the plug leaks replace the entire plug. The injector consists of a throat and a nozzle. Chemically clean the injector with vinegar or sodium bisulﬁte. The holes can be blown out with air. Both pieces have small diameter holes that control the ﬂow rates of water to insure that the proper concentration of regenerant is used. Sharp objects, which can score the plastic, should not be used to clean the injector. Scoring the injector or increasing the diameter of the hole could change the operating parameters of the injector.

NOTICE

Two holes are labeled DN and UP. Check for compliance. Refer to Valve Body Compliance Table at the begining of this manual.

Push the plug(s) and/or injectors ﬁrmly in place, replace the screen and hand tighten the injector cap.

Reﬁll Flow Control Assembly or Reﬁll Port Plug

To clean or replace the reﬁll ﬂow control, pull out the elbow-locking clip and then pull straight up on the elbow. Replace the elbow locking clip in the slot so that it is not misplaced. Twist to remove the white ﬂow control retainer. The ﬂow control can be removed by prying upward through the side slots of the retainer with a small ﬂat blade screwdriver.

Chemically clean the ﬂow control or the white ﬂow control retainer using dilute sodium bisulﬁte or vinegar. Do not use a wire brush. If necessary, replace the ﬂow control, o-ring on the ﬂow control retainer, or the o-ring on the elbow.

Reseat the ﬂow control so the rounded end is visible in the ﬂow control. Reseat the white ﬂow control retainer by pushing the retainer into the elbow until the o-ring seats. Remove locking clip, push down on elbow to reseat and insert locking clip.

Do not use Vaseline, oils, or other unacceptable lubricants on o-rings. A silicone lubricant may be used on the o-ring on the elbow or the white retainer.

W100T Twin Alternating Series Softeners 39

Water Meter

The water meter assembly is connected to the PC board by a wire. If the entire water meter assembly is to be replaced, remove the control valve cover and disconnect the power source and water meter plugs from the PC board. Unlatch the drive assembly and lean it forward. Unthread the water meter wire from the side of the drive assembly and through the drive back plate. To reinstall, rethread the water meter wire through the drive back plate and the side of the drive assembly. Reattach the drive assembly and the water meter and power plugs.

NOTICE

THIS WATER METER SHOULD NOT BE USED AS THE PRIMARY MONITORING DEVICE FOR CRITICAL OR HEALTH EFFECT APPLICATIONS.

•OperatingPressures:

20 PSI Minimum / 125 PSI Maximum

•Operatingtemperatures:

40°F MINIMUM / 110°F MAXIMUM.

If no water meter wire is visible, then a plug is installed, not a water meter.

The water meter wire does not need to be removed from the PC board if the water meter is only being inspected and cleaned. To remove the water meter assembly, unscrew the meter cap on the left side of the control valve. Pliers may be used to unscrew the nut if necessary.

With the nut removed, a slot at the top of the water meter is visible. Twist a ﬂat blade screwdriver in the slot between the control valve body and the meter. When the meter is part way out it is easy to remove the water meter from the housing. Once the water meter is removed from the control valve body, gently pull forward on the turbine to remove it from the shaft.

Do not use a wire brush to clean the turbine. Wipe with a clean cloth or chemically clean in dilute sodium bisulﬁte or vinegar. The turbine can be immersed in the chemical. Do not immerse electronics. If the turbine is scored or damaged or the bearings on the turbine are worn, replace the turbine.

Do not lubricate the turbine shaft. The turbine shaft bearings are prelubricated. Do not use Vaseline, oils, or other unacceptable lubricants on the o-ring. A silicone lubricant may be used on the black o-ring.

Reinsert the water meter into the side slot. Hand tighten the nut. Do not use a pipe wrench to tighten nut.

40 W100T Twin Alternating Series Softeners

Servicing Transfer Cap Assemblies

Release locking tabs from each side to remove back plate.

The control valves backplate must be removed ﬁrst to allow access to removing the transfer cap assembly.

Hold slight downward pressure on the top left corner of the backplate while using a thin ﬂat screwdriver or knife blade to push in on the locking tabs, this will release the backplate and it will twist to the left off of the valve body. For removal of the drive motor side you will need to remove the drive cover assembly to access the motorized drive. The drive motor can be removed by pressing the spring clip loop to the right then rotate the motor a ¼ turn and pull outward to remove the motor from the reducing gear cover assembly. Remove the three Phillips head stainless steel screws that retain the reducing gear cover to the drive cap. Once the cover is removed you have access to the reducing drive gears simply slide them off of the gear axles with your ﬁngers to inspect / check them there are 3 small black gears with foil decals and 1 larger

black reducing gear. Remove the large white drive gear from the stainless steel drive shaft. To remove the large white transfer drive gear ﬁrmly grab the outside edge of the gear with your ﬁngers and pull it outward away from the control valve assembly. Now you can use a 5/32” or 4mm allen wrench to remove the ¼-20 screws that retain the transfer drive cap assemblies on both sides of the valve.

Once the screws are removed from retaining the inlet side transfer valve cap and the outlet drive motor transfer cap from the control valve the cap will spring out away from the valve body. At this point the transfer discs may be removed by pulling the discs outward off of the shaft away from the valve body with your hand. With the disc out you can inspect the ﬂat surface area to be sure it’s clean and smooth free of any debris or scratches. Note that the disc is keyed to the drive shaft so that it will only assemble in one orientation. The transfer discs may be chemically cleaned with a dilute sodium bisulfate solution, vinegar or just wiped with a soft clean cloth.

Seal "Lip" feature

To remove seals gently pull out on the outer lip of the seal to lift the seal out from its cavity being careful not to damage the face surface of the seal. To reassemble re-seat seals into the seal cavity of the control valve body being sure that the lip of the seal is facing outward. With seals in place put a thin ﬁlm of Dow #7 on the tops of the seals and the ﬂat surface of the discs. Prior to reinstalling the discs the drive shaft should be removed and the O-rings cleaned, inspected and lubricated with Dow #7. The shaft can then be installed into the disc prior to installation. With the outlet disc assembled to the shaft the orientation of the shaft to inlet disc can be assured by installing the set with the through hole on the outlet disc at the 6 o’clock position.

The easiest thing would be to remove both disc drives and assemble the outlet side ﬁrst. Then each disc could be ﬁtted on the shaft individually. At this point the transfer valve cap assemblies can be reinstalled.

W100T Twin Alternating Series Softeners 41

Servicing Transfer Cap Assemblies (continued)

NOTE: That both transfer caps only mount in one orientation. Prior to installation of cap assembly be sure to check that the

BE SURE NOT TO USE ANYTHING HYDROCARBON BASED SUCH AS VASELINE OR PETROLEUM JELLY TO LUBRICATE PLASTIC COMPONENTS OR O-RINGS AS THEY WILL BE DAMAGED BY THE HYDROCARBONS AND POTENTIALLY CAUSE FAILURES THAT CAN RESULT WITH LEAKS.

Noting the one possible orientation of the transfer drive cap, use one hand to press in and support the transfer drive cap while using the opposing hand to start two screws in, one on the top and one opposing it on the bottom. Tighten the screws in evenly so the cap seats the O-ring without getting pinched or damaged. Screws should only be hand tightened with a 5/32” or 4mm allen wrench, DO NOT OVER

TIGHTEN SCREWS.

stainless steel spring and the plastic spring support is in place attached to the inside of the cap assembly. Next you can wipe the outside edge of the O-ring on the cap and the inside mating area of the valve with a clean cloth & re-apply a thin layer of silicone lubricant like Dow #7.

CAUTION

NOTICE

Be careful and make sure the meter cable doesn’t get under the drive cap while tightening as it will result in damaging the cable.

Position the large white drive gear with the “A” pointing toward the 1 o’clock position and then press it onto the stainless steel drive shaft, make sure it snaps & locks into position.

NOTICE

The white drive gear is splined to the drive shaft and will only assemble in one orientation. Because of this it is not necessary that the discs and gear be exactly positioned, the positioning needs to be approximate but they have to ﬁt on the shaft.

Next install the larger black reducing gear onto the stainless steel shaft, then install the remaining smaller reducing gears from left to right. Re-install

"A" text orientated towards 1 o'clock

Splines can only fit one direction on shaft.

NOTE: After completing any valve maintenance involving the valve drive assembly or the transfer drive assembly please press

and hold the NEXT & the REGEN buttons simultaneously for 3 to 5 seconds to perform a soft reset which will synchronize the control valves positions.

the grey reducing gear cover over the gears and afﬁx with the 3 stainless steel screws. Now you can re-install the drive motor by pressing the spring clip loop to the right then rotate the motor as you are inserting it so the gear of the motor meshes properly with the reducing gears. Release the spring clip loop and rotate the motor untill the motor housing engages with the plastic nub inside the housing that holds the motor in place and make sure that the top of the motor is ﬂush with the top of the grey gear housing. Press the drive motor wires down into the strain relief of the drive cap, now you can re-install the cover assembly.

42 W100T Twin Alternating Series Softeners

Troubleshooting

Problem Possible Cause Solution

1. No Display on PC Board

2. PC Board does not display correct time of day

a. No power at electric outlet a. Repair outlet or use working outlet

b. Control valve Power Adapter not plugged

into outlet or power cord end not connected to PC board connection

c. Improper power supply c. Verify proper voltage is being delivered

d. Defective Power Adapter d. Replace Power Adapter

e. Defective PC Board e. Replace PC Board

a. Power Adapter plugged into electric outlet

controlled by light switch

b. Tripped breaker switch and/or tripped GFI b. Reset breaker switch and/ or GFI

c. Power outage c. Reset time of day. If PC Board has

d. Defective PC Board d. Replace PC Board

a. Meter is not connected to meter

connection on PC Board

b. Restricted/ stalled meter turbine c. Remove meter and check for rotation

b. Plug Power Adapter into outlet or

connect power cord end to PC Board connection

to PC Board

a. Use uninterrupted outlet

switch

battery back up present the battery may be depleted. See Front Cover and Drive Assembly drawing for instructions.

a. Connect meter to three pin connection

labeled METER on PC Board

or foreign material

4. Control valve regenerates at wrong time of day

5. Time of day ﬂashes on and off

6. Control valve does not regenerate automatically when the REGEN button is depressed and held.

7. Control valve does not regenerate automatically but does when the REGEN button is depressed and held.

c. Meter wire not installed securely into three

pin connector

d. Defective meter d. Replace meter

e. Defective PC Board e. Replace PC Board

a. Power outage a. Reset time of day. If PC Board has

b. Time of day not set correctly b. Reset to correct time of day

c. Time of regeneration set incorrectly c. Reset regeneration time

d. Control valve set at “on 0” (immediate

regeneration)

e. Control valve set at “NORMAL + on 0”

(delayed and/ or immediate)

a. Power outage a. Reset time of day. If PC Board has

a. Broken drive gear or drive cap assembly a. Replace drive gear or drive cap

b. Broken Piston Rod b. Replace piston rod

c. Defective PC Board c. Defective PC Board

a. Meter is not connected to meter

connection on PC Board

b. Restricted/ stalled meter turbine b. Remove meter and check for rotation

c. Incorrect programming c. Check for programming error

d. Meter wire not installed securely into three

pin connector

e. Defective meter e. Replace meter

f. Defective PC Board f. Replace PC Board

c. Verify meter cable wires are installed

securely into three pin connector labeled METER

battery back up present the battery may be depleted. See Front Cover and Drive Assembly drawing for instructions.

d. Check programming setting and reset

to NORMAL (for a delayed regen time)

e. Check programming setting and reset

to NORMAL (for a delayed regen time)

battery back up present the battery may be depleted. See Front Cover and Drive Assembly drawing for instructions.

assembly

a. Connect meter to three pin connection

labeled METER on PC Board

or foreign material

d. Verify meter cable wires are installed

securely into three pin connector labeled METER

W100T Twin Alternating Series Softeners 43

Problem Possible Cause Solution

8. Hard or untreated water is being delivered

9. Control valve uses too much regenerant

10. Residual regenerant being delivered to service

11. Excessive water in regenerant tank

12. Control valve fails to draw in regenerant

13. Water running to drain

a. Media is exhausted due to high water

usage

b. Meter not registering b. Remove meter and check for rotation

c. Water quality ﬂuctuation c. Test water and adjust program values

d. No regenerant or low level of regenerant in

regenerant tank

e. Control fails to draw in regenerant e. Refer to Trouble Shooting Guide

f. Insufﬁcient regenerant level in regenerant

tank

g. Damaged seal/stack assembly g. Replace seal/stack assembly

h. Control valve body type and piston type

mix matched

i. Fouled media bed i. Replace media bed

a. Improper reﬁll setting a. Check reﬁll setting

b. Improper program settings b. Check program setting to make sure

c. Control valve regenerates frequently c. Check for leaking ﬁxtures that may

a. Low water pressure a. Check incoming water pressure

b. Incorrect injector size b. Replace injector with correct size for

c. Restricted drain line c. Check drain line for restrictions or

a. Improper program settings a. Check reﬁll setting

b. Plugged injector b. Remove injector and clean or replace

c. Drive cap assembly not tightened in

properly

d. Damaged seal/ stack assembly d. Replace seal/ stack

e. Restricted or kinked drain line e. Check drain line for restrictions or

f. Plugged backwash ﬂow controller f. Remove backwash ﬂow controller and

g. Missing reﬁll ﬂow controller g. Replace reﬁll ﬂow controller

a. Injector is plugged a. Remove injector and clean or replace

b. Faulty regenerant piston b. Replace regenerant piston

c. Regenerant line connection leak c. Inspect regenerant line for air leak

d. Drain line restriction or debris cause excess

back pressure

e. Drain line too long or too high e. Shorten length and or height

f. Low water pressure f. Check incoming water pressure

a. Power outage during regeneration a. Upon power being restored control will

b. Damaged seal/ stack assembly b. Replace seal/ stack assembly

c. Piston assembly failure c. Replace piston assembly

d. Drive cap assembly not tightened in

properly

a. Check program settings or diagnostics

for abnormal water usage

or foreign material

accordingly

d. Add proper regenerant to tank

number 12

f. Check reﬁll setting in programming.

Check reﬁll ﬂow control for restrictions or debris and clean or replace

h. Verify proper control valve body type

and piston type match

they are speciﬁc to the water quality and application needs

be exhausting capacity or system is undersized

– water pressure must remain at minimum of 25 psi

the application

debris and clean

c. Re-tighten the drive cap assembly

debris and or straighten drain line

clean or replace

d. Inspect drain line and clean to correct

restriction

– water pressure must remain at minimum of 25 psi

ﬁnish the remaining regeneration time. Reset time of day.

d. Re-tighten the drive cap assembly

44 W100T Twin Alternating Series Softeners

Problem Possible Cause Solution

a. Motor not inserted full to engage pinion,

motor wires broken or disconnected

14. E1, Err – 1001, Err – 101 = Control unable to sense motor movement

b. PC Board not properly snapped into drive

bracket

c. Missing reduction gears c. Replace missing gears

a. Foreign material is lodged in control valve a. Open up control valve and pull out

b. Mechanical binding b. Check piston and seal/ stack

15. E2, Err – 1002, Err – 102 = Control valve motor ran too short and was unable to ﬁnd the next cycle position and stalled

c. Main drive gear too tight c. Loosen main drive gear. Press NEXT

d. Improper voltage being delivered to PC

Board

a. Motor failure during a regeneration a. Check motor connections then Press

b. Foreign matter built up on piston and

16. E3, Err – 1003, Err – 103 = Control valve motor ran too long and was unable to ﬁnd the next cycle position

stack assemblies creating friction and drag enough to time out motor

c. Drive bracket not snapped in properly and

out enough that reduction gears and drive gear do not interface

W100T Twin Alternating Series Softeners 45

a. Disconnect power, make sure motor is

fully engaged, check for broken wires, make sure two pin connector on motor is connected to the two pin connection on the PC Board labeled MOTOR. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

b. Properly snap PC Board into drive

bracket and then Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

piston assembly and seal/ stack assembly for inspection. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

assembly, check reduction gears, check drive bracket and main drive gear interface. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

d. Verify that proper voltage is

being supplied. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

b. Replace piston and stack assemblies.

Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

c. Snap drive bracket in properly then

Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

Problem Possible Cause Solution

17. Err – 1004, Err – 104 = Control valve motor ran too long and timed out trying to reach home position

18. Err -1006, Err – 106,

Err - 116 = MAV/ SEPS/ NHBP/ AUX MAV

valve motor ran too long and unable to ﬁnd the proper park position

Motorized Alternating Valve = MAV

Separate Source = SEPS

No Hard Water Bypass = NHBP

Auxiliary MAV = AUX MAV

a. Drive bracket not snapped in properly and

out enough that reduction gears and drive gear do not interface

a. Control valve programmed for ALT A or b,

nHbP, SEPS, or AUX MAV with out having a MAV or NHBP valve attached to operate that function

b. MAV/ NHBP motor wire not connected to

PC Board

c. MAV/ NHBP motor not fully engaged with

reduction gears

d. Foreign matter built up on piston and

stack assemblies creating friction and drag enough to time out motor

a. Snap drive bracket in properly then

Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

a. Press NEXT and REGEN buttons for

3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect. Then reprogram valve to proper setting

b. Connect MAV/ NHBP motor to

PC Board two pin connection labeled DRIVE. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

c. Properly insert motor into casing,

do not force into casing Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

d. Replace piston and stack assemblies.

Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

19. Err – 1007, Err – 107,

Err - 117 = MAV/ SEPS/ NHBP/ AUX MAV

valve motor ran too short (stalled) while looking for proper park position

Motorized Alternating Valve = MAV

Separate Source = SEPS

No Hard Water Bypass = NHBP

Auxiliary MAV = AUX MAV

a. Foreign material is lodged in MAV/ NHBP

valve

b. Mechanical binding b. Check piston and seal/ stack

a. Open up MAV/ NHBP valve and check

piston and seal/ stack assembly for foreign material. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

assembly, check reduction gears, drive gear interface, and check MAV/ NHBP black drive pinion on motor for being jammed into motor body. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect.

46 W100T Twin Alternating Series Softeners

NOTES

W100T Twin Alternating Series Softeners 47

WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

For more information: www.watts.com/prop65

LIMITED WARRANTY: Certain Watts products come with a limited warranty from Watts Regulator Co. Other products may have no warranty or are covered by the original manufacturer’s

warranty only. For specic product warranty information, please visit www.watts.com or the published literature that comes with your product. Any remedies stated in such warranties are exclusive and are the only remedies for breach of warranty. EXCEPT FOR THE APPLICABLE PRODUCT WARRANTY, IF ANY, WATTS MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. TO THE FULLEST EXTENT

PERMITTED BY APPLICABLE LAW, WATTS HEREBY SPECIFICALLY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND IN NO EVENT SHALL WATTS BE LIABLE, IN CONTRACT, TORT, STRICT LIABILITY OR UNDER ANY OTHER LEGAL THEORY, FOR INCIDENTAL, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR PROPERTY DAMAGE, REGARDLESS OF WHETHER IT WAS INFORMED ABOUT THE POSSIBILITY OF SUCH DAMAGES.

A Watts Water Technologies Company

USA: Tel.(800)659-8400•www.watts.com

Canada: Tel.(888)208-8927•www.watts.ca

Watts W100T User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
