Unit Information
Limited 1 Year Warranty
50-60Hz – 800 Watts – 6 Amps.
Adjustable Temperature Range
90˚F - 176˚F (32˚C - 80˚C)
Timer Up To 40 Hours
10 Tray Food Dehydrator
WDH10 - 037463
1
2
3
Graphic By: Sandra A. Montysko Revised March 4, 2020 Approved 3/4/2020 Page 1 of 4
7
8
10 Tray Food Dehydrator
WDH10
4
5
6
Red Panel Lead
13
12
15
16
11
10
9
14
19
20
18
17
27
26
NEMA 5-15
Back Plate Bracket
25
Black Cord Lead
30
31
24
23
28
22
29
37
21
33
32
34
35
Page 2 of 4 Revised March 4, 2020
36
Catalog/Model
WDH10
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790
Tele. 1-800-269-6640
www.waringcommercialproducts.com
Illustration# Part# Description
1 037448 Foot
2 037462 Drying Tray
3 037461 Drip Tray
4 037441 Rear Screen
5 037449 Screw
6 003507 Washer
7 037439 Control Panel Assembly
8 037440 Screw
9 037437 Heater
10 037455 Ceramic Insulator Set
11 037458 Washer
12 037454 Lock Washer
(4 required)
(4 required)
(4 required)
(4 required)
(2 required)
(2 required)
(10 required)
(2 required)
Fax 860-496-9017
13 037453 Hex Nut
(2 required)
14 037438 Motor
15 037454 Lock Washer
16 037453 Hex Nut
(4 required)
(8 required)
17 037442 Wiring Cover
18 037445 Washer
19 037444 Spring Washer
20 037443 Screw
(6 required)
(6 required)
(6 required)
21 037446 6" Rubber Sleeve
22 037457 Screw
23 037458 Washer
(2 required)
(6 required)
24 037456 Thermal Cut Off
25 037455 Ceramic Insulator Set
26 037454 Lock Washer
(2 required)
(2 required)
27 037453 Hex Nut
28 013731 Wire Ties
(4 required)
(5 required)
29 012409 Small Crimp Connector
30 037459 Strain Relief
Revised March 4, 2020 Page 3 of 4
Catalog/Model
WDH10
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790
Tele. 1-800-269-6640
www.waringcommercialproducts.com
Illustration# Part# Description
31 037460 Cord
32 037464 Back Plate Assembly
33 037452 Screw
34 037451 Screw
35 037447 Counter Stop
36 037454 Lock Washer
37 037453 Hex Nut
(9 required)
(3 required)
Fax 860-496-9017
