Waring WCT855 Instruction Manual

Heavy-Duty Commercial Toasters

Tostadoras comerciales de servicio pesado

Grille-pain commerciaux à usage intensif

WCT800 SERIES

Operating Manual

Manual de instrucciones

Manuel d’utilisation

For your safety and continued enjoyment of this product,

always read the instruction book carefully before using.

Para su seguridad y para disfrutar plenamente de este producto,

siempre lea las instrucciones cuidadosamente antes de usarlo.

An que votre appareil vous procure en toute sécurité beaucoup de satisfaction,

lire attentivement le mode d’emploi avant de l’utiliser.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be taken, including the following:

READ ALL INSTRUCTIONS.

2. Do not touch hot surfaces. Use handles or knobs.

3. Always unplug from outlet prior to handling or cleaning.

4. To protect against risk of electrical hazards, do not immerse cord, plug, or any part of the Waring® toaster in water or other liquids.

5. This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instructions concerning use of the appliance by a person responsible for their safety.

6. Children should be supervised to ensure that they do not play with the appliance.

7. Unplug from outlet when not in use and before cleaning. Allow unit to cool before cleaning or handling.

8. Do not operate any appliance with a damaged cord or plug or after the appliance has been dropped or damaged in any way, or if it is not operating properly. Return the toaster to the nearest Waring authorized service facility for examination, repair, or adjustment.

9. The use of attachments not recommended or sold by Waring may cause injury.

10. Do not use outdoors.

11. Do not let cord hang over edge of table or countertop, or touch hot surfaces.

12. Do not place on or near a hot gas or electric burner or in a heated oven.

13. Do not use this toaster for other than its intended use.

14. FIRE MAY OCCUR IF THE TOASTER IS COVERED OR TOUCHING

FLAMMABLE MATERIALS SUCH AS DRAPERIES OR WALLS WHEN IN OPERATION. DO NOT OPERATE UNDER WALL CABINETS.

15. Oversize foods, metal foil packages or utensils must not be inserted in a toaster as they may involve a risk of re or electrical shock.

16. Do not attempt to dislodge food when toaster is plugged into electrical outlet.

17. To avoid possibility of re, do not leave toaster unattended during use.

18. Put this list in a safe place – do not discard.

19. Do not store or use gasoline or other ammable vapors or liquids in the vicinity of this or any other appliance.

SAVE THESE INSTRUCTIONS

For Commercial Use

WCT800 SERIES TOASTERS

1) Electronic Browning Control

2) Slide-out Crumb Tray

3) Toaster Slot

4) Carriage Control Lift Lever

5) 3 ft. Power Cord (not shown)

6) Bread/Bagel Switch

(For WCT850 only)

Conforms to ANSI/UL STD 197

Speciﬁcations

Phase Model Amps Watts

1 WCT800 19 2200 60 120 3 ft. 5-20P 1 WCT800RC 15 1800 60 120 3 ft. 5-15P

WCT800RCND

1 1 WCT805 10/12 1 WCT805B 13 2700 60 208 3 ft. 6-20P 1 WCT810 17 2025 60 120 3 ft. 5-20P 1 WCT815 8/9 2025 60 240 3 ft. 6-15P 1 WCT815B 10 2025 60 208 3 ft. 6-15P 1 WCT820 12.5 1500 60 120 3 ft. 5-15P

1 WCT825 6.25 1500 60 240 3 ft. 6-15P 1 WCT825B 7.2 1500 60 208 3 ft. 6-15P 1 WCT850 13.5 2800 50/60 208 3 ft. 6-20P 1 WCT850RC 15 1800 50/60 120 3 ft. 5-15P 1 WCT855 11.25 2700 50/60 240 3 ft. 6-15P

1 WCT850RCND 11.5 1380 50/60 120 3 ft. 5-15P

12 1440 60 120 3 ft. 5-15P

2028/2700

Frequency

(Hz)

60 208/240 3 ft. 6-15P

Voltage Cord

Plug

Supply

Grounding Instructions

For your protection, the Waring® Commercial toasters are supplied with a molded 3-prong grounding-type plug and should be used in combination with a properly connected grounding-type outlet. Use of any other voltage or altering of the plug or cord may damage the unit, will void warranty and may cause injury.

120V 120V 208/240V 208/240V

NEMA 5-15P NEMA 5-20P NEMA 6-15P NEMA 6-20P

3 ft. Cord with Plug Conguration

Special Cord Set Instructions

A short power-supply cord is provided to reduce the risks result from becoming entangled in or tripping over a longer cord.

Extension cords may be used if care is exercised in their use. If an extension cord is used, the marked electrical rating of the

extension cord must be at least as great as the electrical rating of the appliance, and the longer cord should be arranged so that it will not drape over the countertop or table top where it can be pulled on by children or tripped over. If the appliance is of the grounded type, the extension cord should be a grounding type 3-wire cord.

Operation

1. Put toaster on counter or at, dry surface near electrical outlet.

2. Place bread in all the slots, set both browning controls and push down the carriage control levers. The toasted bread will automatically rise when the bread cycle is complete.

3. The regular slots toast both sides of bread, while bagel slots toast only on one side.

4. To stop toasting mid-cycle, just lift up the carriage control lever.

5. WCT810/WCT815/WCT815B:

The sliced side of bagels and buns needs to face to the left.

Arrows on toaster indicate toasting side.

WCT820/WCT825/WCT825B: The sliced side of bagels and buns should follow the diagram

on the top panel of the toaster.

WCT850: To toast both sides of bread, switch must be

positioned on the bread selection. To toast only one side, switch must be positioned on the bagel selection. The sliced side of bagels and buns should follow the diagram on the top panel of the toaster.

CAUTION: The removable crumb tray must be completely inserted before toaster can be operated. If the tray is removed for cleaning, ensure that it is replaced before using toaster. Crumb tray is dishwasher safe.

Cleaning and Maintenance

Let toaster cool before any cleaning operation.

1. To clean outer surface: Let toaster cool. Unplug power cord. Wipe down exterior with damp cloth. Prevent liquid from running into toaster slots. Before using, allow toaster’s outer surface to dry.

2. To clean crumb tray: Remove the crumb tray and discard crumbs. Wipe crumb tray clean and replace in toaster. Never operate the toaster without the crumb tray in place. Crumb tray is dishwasher safe.

3. To remove any pieces of bread remaining in the toaster, unplug toaster, turn the toaster upside down and gently shake. Never insert any metal or sharp instrument into the toaster slots. This could damage the toaster and cause a safety hazard.

4. Any other servicing should be performed by an authorized service representative.

Warning – To prevent electric shock, unplug before cleaning.
