VTECH COMMUNICATIONS LTD.
Distributed in the U.S.A. by VTECH Communications, Beaverton, OR
Distributed in Canada by VTECH Electronics Canada Ltd., Richmond, B.C..
Copyright 1999 for VTECH COMMUNICATIONS LTD.
Printed in Malaysia
91-5081-10-00
ISSUE 0
VT 9125
USER’S MANUAL
VTECH COMMUNICATIONS LTD.
900MHz CALLER ID CORDLESS TELEPHONE
IMPORTANT
BEFORE USING YOUR NEW
PHONE, WE STRONGLY
RECOMMEND YOU READ THIS
MANUAL THOROUGHLY.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
If the power supply cord or plug is damaged or frayed.
Read and understand all instructions.
Follow all warnings and instructions marked on the telephone.
Use only the battery type recommended in the Instruction Manual.Do not use a
lithium battery.
Unplug this telephone from the wall outlet before cleaning. Do not use liquid or
aerosol cleaners, just use a damp cloth for cleaning.
Do not use this telephone near water. For example, do not use near a bath tub,
wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming
pool.
Do not place this telephone on an unstable cart, stand or table. It could fall
causing serious damage impeding operation.
Never place this telephone near or over a radiator or heat register.
Only operate this telephone using the type of power source listed on the marking
label. If you are not sure of the power supply of your home, consult your dealer
or local power company.
Do not overload wall outlets and extension cords as this can result in the risk of
fire or electrical shock.
Never push objects of any kind into this telephone as they can touch dangerous
voltage points or short out parts that could result in a risk of fire or electrical
shock.
Take the phone to a qualified technician when it requires repair work or service.
To reduce the risk of electrical shock, do not disassemble the telephone.
Opening or removing covers can expose you to dangerous voltages or other
risks. Incorrect reassembly can cause electrical shock during subsequent use.
Unplug this telephone from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
If liquid is spilled into the unit.
If the unit is exposed to rain or water.
If the unit does not operate normally by following the operating instructions.
If the unit is dropped or the casing is damaged.
If the unit exhibits a distinct change in performance.
Avoid using the telephone during an electrical storm. There can be a slight risk of
electrical shock from lightning.
Do not use the telephone to report a gas leak if in the vicinity of the leak.
SAVE THESE INSTRUCTIONS
- i -
IMPORTANT SAFETY INSTRUCTIONS
TELEPHONE WIRING AND JACK INSTALLATION
Use caution when installing or modifying telephone lines.
Never install telephone wiring during an electrical storm.
Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
Never touch uninsulated telephone wires or terminals unless the telephone line
is disconnected at the network interface.
To reduce the risk of fire or injury to persons,
read and follow these instructions:
CAUTION
BATTERIES
Disconnect the telephone when replacing batteries or a battery pack.
Use only the battery or battery pack type listed in the Instruction Manual. Do not
.
Do not dispose of batteries or a battery pack in a fire, as they can explode.
Check with local codes for proper battery disposal regulations.
Do not open or mutilate a battery or battery pack. Released electrolyte is
corrosive and can cause damage to the eyes or skin. It can be toxic if swallowed.
Avoid contact with rings, bracelets, keys or other metal objects when handling
batteries. These objects could short out the batteries or cause the conductor to
overheat resulting in burns.
Do not attempt to recharge a battery or battery pack by heating it. Sudden
release of battery electrolyte can cause burns or irritation to the eyes or skin.
Replace all batteries at one time (if your model has more than one). Mixing fresh
and discharged batteries can cause them to rupture.
Observe the proper polarity, or direction, of any battery. Reverse insertion of a
battery or battery pack can prevent charging, and can result in leakage or
explosion.
Remove the batteries or the battery pack if you do not plan to use the phone for
several months at a time. The batteries could leak over that time.
Discard any “dead” batteries or battery pack as soon as possible because they
are likely to leak into the phone.
Do not store this phone, or any batteries or battery pack, in a high temperature
area. Batteries stored in a freezer or refrigerator should be protected from
condensation during storage and defrosting. Batteries and battery packs should
be stabilized at room temperature before using.
once it outlives its usefulness. Depending upon your local and state law, it might
be illegal to dispose of this battery into a municipal waste system. Check with
your local solid waste company for more information on your recycling options
for the battery pack.
use lithium batteries
Cordless Telephone only: Your battery pack is rechargeable and can be recycled
- ii -
Table of Contents
TABLE OF CONTENTS
2
i
IMPORTANT SAFETY INSTRUCTIONS
TABLE OF CONTENTS
iii
GETTING TO KNOW YOUR NEW PHONE
Unpacking Your Phone
Using Your Phone’s Features
1
1
SETTING UP YOUR PHONE
Step 1. Choose a Central Location for the Base
Step 2. Plug in the Cords
Step 3. Add the Battery to the Handset
Step 4. Select Tone or Pulse Service
Step 5. Set Ringer On or Off
Step 6. Select Prompt Language
4
4
6
7
7
7
4
OPERATING YOUR PHONE
Dialing
Using Short-Cut Dialing Methods
Using Call Records
Using Redial
Using Speed Dialing
Storing Your Speed Dial List
Using the Speed Dial List
Reading the Call Timer
Finding Clear Reception
Reaching Maximum Range
Using Traditional Dialing
Using Pre-dial
Transferring a Caller ID Call Record
Paging and Finding the Handset
Using Flash
Using Temporary Tone Service
Adjusting Handset Volume
8
8
8
8
9
9
9
9
9
10
1 1
1 1
12
12
12
12
12
12
USING CALLER ID AND CALL WAITING ID
Receiving New Calls
Viewing Call Records
Dialing from Call Records
Saving Call Records
Reading Display Messages
Deleting Call Records
13
13
14
15
15
16
13
Creating Your VIP List
Reviewing Your VIP List
SETTING UP VIP DISTINCTIVE RING
17
17
17
SPEED DIALING IN A ChAIN
TROUBLESHOOTING
FCC REQUIREMENTS
LIMITED WARRANTY
18
19
21
23
- iii -
Getting to Know Your New Phone
GETTING TO KNOW YOUR NEW PHONE
UNPACKING YOUR PHONE
In addition to this manual,check that you have the following accessories:
Your new VT 9125 gives you the ultimate in cordless telephone sound quality with
the luxury of Caller ID and Call Waiting ID.
If this is your first cordless telephone, you’ll soon discover that your telephone is
similar to regular telephones, except without the cord. Some key features are:
50 name & number call records
9-number Personal Directory
Direct storage from call records
to Directory
Visual Message Waiting alert
VIP distinctive ring
3-position handset volume
Hearing-aid compatible
Page/Find handset locator function
Auto and manual channel selection
Audible out of range alert
Low battery alert
Bi-directional handset charging
Bilingual prompts
Unlikeregulartelephones,yourcordlesstelephonedoesnotworkduringpowerfailures.
Becauseof this restriction, we do not recommendyou haveonly cordlesstelephones in
yourresidence.
7Foot
Telephone Cord
Memory Number
Index Sheet
M1
M4
M5
M6
M7
M8
M9
M2
M3
M1
M4
M5
M6
M7
M8
M9
M2
M3
Battery Cover
for Handset
Model No.: NP 600,
B-650 or
3N-600AACL
Rating: 3.6V 600mAh
Battery Pack
Model No.: NP 915
INPUT: AC 120V, 60Hz
OUTPUT: DC 9V, 400mA
Polarity: Center Positive
AC Adapter
Mounting
Bracket
- 1 -
78
PQRS
TUV
9
WXYZ
4
5
GHI
JKL
6
MNO
3
DEF
1
2
ABC
DELETE
MEM
REDIAL
CHAN
FLASH
PHONE
OFF
CID
Your VT 9125 comes with a handset and a base.
Your handset can be placed in the base either facing up or facing down.
USING YOUR PHONE’S FEATURES
ON THE BASE
IN USE / CHARGING
Light
PAGE
Button
TONE / PULSE
Switch
Charge Contacts
Antenna
MESSAGE /
NEW CALL
Light
Easy-to-read
character &
digit LCD
Caller ID Button
Function Buttons
Function Buttons
Handset
Dialing Buttons
VT 9125 TELEPHONE
Getting to Know Your New Phone
PAGE button - Helps you find the handset. If you
press the button once, the handset sends an audible beep.
If you press and hold the button for more than two seconds,
the handset beeps for 20 seconds.
PAGE
MESSAGE / NEW CALL light - Comes on steadily when
there is a new voice mail left in the optional answering service
provided by your local telephone company. Blinks when
there are unreviewed call recordsat the handset.
used or when the handset is being charged.
IN USE / CHARGE light - Comes on whenever this phone is
TONE
0
#
OPER
- 2 -
ON THE HANDSET
Getting to Know Your New Phone
THE CALLER ID BUTTONS
THE FUNCTION BUTTONS
REDIAL button - Redials your last outbound call or inserts
CHAN button - Allows you to change among 20 channels for clearer reception.
DELETE button - Removes records from the Call Records or from memory dialing.
a pause in a number when entering numbers into memory.
THE DIALING BUTTONS
SWITCHES
Caller ID Buttons
Function Buttons
Dialing Buttons
CID button - Turns your call records on for review.
Also initiates menu programming.
CID
TONE OPER
0
#
display the Name & Number Screen of your call records.
Call Review buttons( and )- Scroll through
CID
your call records after you press . These buttons
TONE
#
CALL BACK# OPTIONS ( )
button - Select the local
number or long distance number of a call record before
dialing.
OPER
0
FLASH
PHONE
PHONE/ FLASH button - Turns the phone on so you can dial
or talk, and allows you to switch between a call and a
Waiting call. Lights up when you are talking on the handset.
OFF
OFF button - Ends a call, or any phone function. It also
clears the display of incoming caller’s information for privacy.
MEM
DELETE
CHAN
REDIAL
MEM button -Allows you to review stored numbers, and save numbers
in the Speed Dial List. After pressing CID, allows you to set Ringer, select prompt
Language and program numbers for VIP Distinctive Ring.
Dialing buttons - Control manual dialing. If you use
Rotary / Pulse dialing, allows you to set your phone
for temporary tone service.
TONE
78
PQRS
TUV
9
WXYZ
4
5
GHI
JKL
6
MNO
3
DEF
1
2
ABC
0
TONE OPER
#
Volume switch - Allows you to adjust the handset volume
LOW MID HIGH
to , , or .
Volume Switch on Handset
HIGH
MID
LOW
- 3 -
Now that you’ve checked the contents of the carton, it only takes a few steps to set
up your phone.
You can set your telephone on a tabletop or you can mount the phone on a wall.
This section instructs you how to install your telephone for either desk-top or wall
mount use.
STEP 1. CHOOSE A CENTRAL LOCATION FOR THE BASE
STEP 2. PLUG IN THE CORDS
ForUseonaTabletop:
It is optional to install the mounting bracket.
If you do...
1. Place the mounting bracket over the top
half of the base with the hooks in the middle
square slots. (The mounting bracket fits
only one way into slots.)
2. Snap the bracket onto the phone.
3. Take one end of the long telephone line
cord and plug it into the jack labeled
on the base.
4. Plug the other end of the phone cord into
the wall outlet.
TELCO
Setting Up Your Phone
SETTING UP YOUR PHONE
5. Plug the AC adapter tip into the jack on the base. Be sure that the tip is
securely plugged into the jack.
6. Take the large end of the AC adapter and plug it into a wall outlet. Be sure that the
wall outlet is not controlled by a light switch.
DC 9V
The base should be away from all other electronic equipment such as the
microwave, personal computer, stereo, television, VCR or other cordless telephones.
It is also a good idea to place the unit away from noisy areas, or from heat sources
such as a radiator or direct sunlight.
TELEPHONE
WALL OUTLET
TELEPHONE
CORD
DC9V
JACK
BASE
AC ADAPTER
120V WALL
OUTLET
TELCO
JACK
- 4 -
Loading...
