VTech VT1010, VT1010T, VT1515, VT1616 User Manual

User’s manual
www.vtech.com
Model: VT1010/VT1010T VT1515/VT1616
DECT
www.vtech.com
I
Important Safety Instructions .......................................1
Setting up the telephone.................................... 2
Package Contents ........................................................3
Location ........................................................................3
Connecting the telephone ............................................3
Connecting the base station ........................................3
Installing and charging the batteries ............................4
Getting to know your phone .............................. 5
Overview of the handset ..............................................5
Overview of the base station ........................................6
Displays, keys , icons ...................................................7
Using your phone................................................ 9
Make a call ....................................................................9
Preparatory Dialing.......................................................9
Direct Dialing ................................................................9
Call from the phonebook ..............................................9
Call from the calls log ...................................................9
Call from the redial list .................................................9
Call timer .......................................................................9
An
swer a call ..............................................................10
End a call ....................................................................10
Adjust Earpiece and Handsfree Volume ....................10
Mute a call ..................................................................10
Set the Silent Mode ....................................................10
Turn on the Keypad Lock............................................10
Make an internal call
(for VT1010T / VT1515 / VT1616 only) ....11
Intercom Another Handset
(for VT1010T / VT1515 / VT1616 only) .......................11
Call All Handsets Transfer an External Call to another handset
(for VT1010T / VT1515 / VT1616 only ) ..................... 11
Make a 3 -way Conference Call
(for VT1010T / VT1515 / VT1616 only ) .................... 11
Redial ................................................................. 12
Redial the last number ...............................................12
Redial a number from the Redial list .......................... 12
Store a Redial Number into the Phonebook ..............12
Delete a
Redial Number .............................................12
Delete the Entire Redial List .......................................12
Call List .............................................................. 13
Caller display ( Network Dependent ) ........................14
View the Call List ........................................................13
Store a Call List Number into the Phonebook ...........13
Delete an entry in the Call List ...................................14
Delete the entire list of the Call List ...........................14
View the Details OF THE Call List Entry ....................14
Phonebook ......................................................... 15
Private Phonebook .....................................................15
Add a New Phonebook Entry .....................................15
View a Phonebook Entry ............................................ 15
Edit a Phonebook Entry.............................................. 15
Delete A phonebook Entry .........................................16
Delete the Entire Private Phonebook .........................16
Check the Phonebook U
sage ....................................16
Text and Digit Entry Table .......................................... 17
www.vtech.com
II
Table of contents
Base Settings .................................................... 18
Dial Type .....................................................................18
Change the dial mode ................................................18
Change the system PIN Code ....................................18
Paging (Find the handset) ..........................................18
Handset Settings .............................................. 19
Alarm Settings ............................................................19
Turn on/off the Alarm .................................................. 19
Set the Alarm Time ..................................................... 19
Ringer Setup ...............................................................20
Set the Ringer Melody for Internal Calls ....................20
Set the Ringer Melody for External Calls ...................20
Set the Ringer Volume ...............................................20
Tone Setup .................................................................21
Set Key Tone ..............................................................21
Set Battery Tone .........................................................21
Set Out Of Range Tone ..............................................21
Set the Handset Language ........................................22
Rename the Handset .................................................22
Set Handset Display ...................................................22
Set the Auto Answer ...................................................23
Date and Time Settings .................................... 23
Change the Date Format ............................................23
Change the Time Format ...........................................23
Set the Time ...............................................................24
Set the Date ................................................................24
Reset your Phone .......................................................24
Troubleshooting ................................................ 25
Technical Specication ..............................................26
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of re, electric shock and injury, including the following:
1)
1
Read and understand all the instructions.
2) Follow all warnings and instructions marked on the product.
3) Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4) Do not use this product near water (for example, near a bath tub, kitchen si
nk, swimming pool).
5) Do not overload wall outlets and extension cords as this can result in the risk of re or electric shock.
6) Unplug this product from the wall outlet and refer servicing to Vtech under the following conditions:
When the power supply cord or plug is damaged or frayed.
If the product does not operate normally by following the operating instructions.
If the product has been dropped and the cabinet has been damaged.
If the product exhibits a distinct change in perf
ormance.
7) Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.
8) Do not use the telephone to report a gas leak in the vicinity of the leak.
9) Use only the supplied NiMH (Nickel Metal Hydride) batteries! The operation periods for the handsets are only applicable with the default battery capacities
10)The use of other battery types or non-rechargeable batteries/primary cells can be dangerous. These may cause
interference
and/or unit damages. The manufacturer will not be held liable for damage arising from such non-compliance.
11)Do not use third party charging bays. The batteries may be damaged.
12)Please note the correct polarity while inserting the batteries.
13)Do not immerse batteries in water, do not place in re.
If you have questions about this product, or having difficulty with setup or operation, call our Vtech Electronics ( HK LTD).
Customer Ser vice Centre : 852-2776 3223
Technic
al Inquiry Hotline : 852-2667 7433
IMPORTANT SAFETY INSTRUCTIONS
www.vtech.com
2
Installation
Setting up the telephone
Package contents
The package for the VT1010/V T1010T/VT1515/VT1616 contains the following items:
VT1010
• 1 Handset
• 1 Base station
• 1 AC power adapter
• 1 Telephone line cord
• 2 rechargeable batteries
• 1 English user manual and
1 Chinese user manual
Location
The maximum range between the base station and the handset is approximately 300 meters. Depending on the surrounding conditions as well as spatial and structural factors, the range may be reduced. The
range
indoors is normally less than outdoors.
• 2 Handsets
• 1 Base station
• 2 AC power adapters
• 1 Telephone line cord
• 1 Charger
• 4 rechargeable batteries
• 1 English user manual and
1 Chinese user manual
VT1010T
• 3 Handsets
• 1 Base station
• 3 AC power adapters
• 1 Telephone line cord
• 2 Chargers
• 6 rechargeable batteries
• 1 English user manual and
1 Chinese user manual
VT1515 / VT1616
www.vtech.com
3
Before you can start using your telephone you must plug in the telephone connection cords and the mains cable.
Connecting the base station
1) Plug the power supply & line cord into the base station.
2) Plug the power supply & line cord into the wall socket.
3) Always use the cables provided in the box.
• Your
telephone will not function if the mains plug or adapter is not plugged in. Thus, rst charge the battery before you connect the unit with the telephone network. The unit will fu
nction only if it is charged completely.
Connecting the telephone
Socket for telephone
connection cord
Socket for mains cable
www.vtech.com
4
Installation
1) Slide open the battery compartment cover.
2) Place the 2 batteries as indicated. Respect polarity.
3) Slide the battery compar tment cover back.
4) Put the handset on the base and charge for 14 hours rst time. A beep indicates that the handset is properly placed on the base or charger.
Installing and charging the batteries
Use only the power pack provided for the base station. Use only NiMH rechargeable batteries.
www.vtech.com
5
1. LEFT SOFT KEY (MENU/OK)
In idle mode: Press to access the main menu In sub-menu mode: Press to conrm the selection During a call: Press to access Phonebook/ Redial List/ Call List/ Intercom
2. RIGHT SOFT KEY (CLEAR/BACK/MUTE/ INTERCOM)
In main menu mode: Press to go back to idle screen In sub-menu mode: Press to go back to previous level In sub-menu mode: Press and hold to go back to idle screen In editing / predialing mode: Press to clear a character / digit In editing / predialing mode: Press and hold to delete all the characters / digits During a call: Press to mute / unmute the microphone In idle mode: Press to intercom another handset
3. UP
In idle mode: Press to access the call list In menu mode: Press to scroll up the menu items In menu mode: Press and hold continuously to perform a continuous up-scrolling of the menu. In Phonebook list / Redial list / Calls log: Press to scroll up the list During a call: Press to increase the volume In ringing: Press to increase the ringer volume
4. DOWN
In idle mode: Press to access the redial list In menu mode: Press to scroll down the menu items In menu mode: Press and hold continuously to perform a continuous down-scrolling of the menu. In Phonebook list / Redial list / Calls log: Press to scroll down the list During a call: Press to decrease the volume In ringing: Press to decrease the ringer volume
5. TALK ON
In idle / predialing mode : Press to make a call In Redial list / Calls Log / Phonebook entry: Press to make a call to the selected entry in the list During ringing: Press to answer a call
6. TALK OFF
During a call: Press to end a call and go back to idle screen In menu / editing mode: Press to go back to idle screen In idle mode: Press and hold to power off the handset In idle mode (when the handset is powered off): Press to power on the handset
7. ALPHANUMERIC KEYPAD, * (STAR), # (HASH)
Press to insert a digit / character / * / # * key in idle mode: Press and hold to turn off the ringer * key during a call (in Pulse mode): Press to switch to tone mode # key in Idle mode: Press and hold to turn on / off the keypad lock 0 key in idle / predialing / number editing mode
: Press and
hold to insert a pause
8. SPEAKERPHONE
During a call: Press to turn on / off the speakerphone. In Idle mode / predialing mode / Redial list / Calls Log / Phonebook entry: Press to make a call with speakerphone During ringing: Press to answer a call with speakerphone
9. PHONEBOOK
In idle mode: Press to access the phonebook list
10. FLASH
In idle / predialing mode: Press to insert a flash During a call: Press to dial a flash
11. MICROPHONE
12. EARPIECE
Getting to know your phone
Overview of the handset
1
2 3 4
5
6
7
8
9
10
11
12
www.vtech.com
6
Telephone settings
1. PAGE
Press the Page on the base station to page your handset. It will ring for approximately 60 seconds. Press on the handset or on the base to stop the paging.
2. Charging cradle for the handset.
Getting to know your phone
Overview of the base station
Page key
Charging cradle for the handset.
www.vtech.com
7
Getting to know your phone Displays, keys, icons
The LCD display gives you information on the current status of the telephone.
Scroll up / down the menu items / Phonebook list / Redial list / Call List
Steady when the handset is in range of the base. Flash when out of range of the base or not registered to the base.
Steady when an intercom is in progress. Flash when there is an incoming internal call.
Indicate a call is in progress.
Indicate that handsfree is being used.
Indicate that the ringer is switched off.
Steady when an alarm is set. Flash when the alarm time set before reaches.
Indicate that the keypad is locked.
Icon Description:
www.vtech.com
8
Telephone settings
Indicate when the battery is fully charged. Flash when the unit performs initial charging.
Indicate when the battery needs charging. Flash when low battery power level is detected.
Indicate when more characters are existed before the text currently displayed.
Indicate when more characters are existed after the text currently displayed.
Press to select more menu options if applicable
Press to conrm the current selection if applicable.
Press to conduct Intercom call when idle
Press to go back to previous menu level or cancel the current action if applicable
Press to clear a character or stop the alarm if applicable, press to mute / unmute during a call.
(MENU)
(INT)
(BACK)
www.vtech.com
9
Using your phone
Make a Call Preparatory Dialing
Enter the phone number and press or to dial the number. Press to clear the entry.
Direct Dialing
Press or to take the line and enter the phone number.
Call from the phonebook
Press to access the phonebook and press / to select the desired phonebook entry. Press or to dial out to the selected phonebook entry. Alternatively, press /OK to access the phonebook to get the desired phonebook entry.
Call from the calls log
Press to access the call log and press / to select the desired calls log entry. Press or to dial out to the selected calls log entry. Alternatively, press /OK> to access the calls log from the main menu.
Call from the redial list
Press to access the redial list and press / to select the desired redial number. Press or to dial out to the selected redial number. Alternatively, press to access the redial list from the main menu.
Call timer
Your handset automatically times the duration of every call. The call timer will display a few seconds after the call has made. It is shown in hours, minutes and seconds format (HH:MM:SS).
www.vtech.com
10
Telephone settings
Answer a Call
If the handset is not on the charging cradle:
When the phone rings, press
/ to answer a call.
If the handset is on the charging cradle or the base station and if AUTO ANSWER is set to ON:
When the phone rings, pick up the handset to answer a call.
End a Call
During a call connection, press to end the call.
OR
Put the handset on the base station to end the call.
Adjust Earpiece and Handsfree Volume
There are 5 levels (VOLUME 1 to VOLUME 5) to choose from for each of earpiece and handsfree volume.
During a call:
Press
/ to select volume 1-5. The current setting is shown. When you end the call, the setting will remain
at the last selected level.
Mute a Call
You can talk to someone nearby without letting the caller hear you during a call.
During a call:
Press
to mute the microphone and “MUTED” will display on the LCD. Your caller cannot hear you. Press
again to unmute the microphone.
Set the Silent Mode
In idle, press and hold to turn off the handset ringer. The icon is displayed on the LCD.
Turn on the Keypad Lock
In idle, press and hold to turn on the keypad lock. The icon is displayed on the LCD
www.vtech.com
11
Make an Internal Call ( For VT1010T / VT1515 / VT1616 only )
This feature is only applicable when there are at least two registered handsets. It allows you to make internal calls, transfer external calls from one handset to another handset and make conference calls. If the called handset is not answered within 20 seconds, the called handset will stop ringing and the calling handset will return to standby mode.
Intercom Another Handset ( For VT1010T / VT1515 / VT1616 only )
1. In idle mode, press and the registered handsets will display except the calling handset.
2. Enter the desired handset number to intercom with.
3. The called handset rings and press on the called handset to establish the internal call.
Transfer an External Call to another handset ( For VT1010T / VT1515 / VT1616 only )
During an external call:
1. Press
and / to select INTERCOM.
2. Press <OK> to select the desired handset to intercom with.
3. The external call is put on hold automatically and the called handset rings.
4. Press
on the called handset to establish an internal call.
5. Press
on the calling handset or put the calling handset on the charging cradle to end the current call with
the external party.
6. The external call is transferred to the called handset.
Make a 3-way Conference Call ( For VT1010T / VT1515 / VT1616 only )
The conference call feature allows one external call to be shared with two handsets (in intercom). The three parties can share the conversation and no network subscription is required.
During an external call:
1. Press
and / to select INTERCOM.
2. Press <OK> to select the desired handset to intercom with.
3. The external call is put on hold automatically and the called handset rings.
4. Press
on the called handset to establish an internal call.
5. Press and hold
on the calling handset to establish the conference call.
Any handset hangs up during a conference call will leave the other handset still in connection with the external call.
If only two
handsets are registered to the base station, press <INT> will connect to another handset immediately.
www.vtech.com
12
Telephone settings
Redial the last number
You can redial up to 5 of the last numbers called. If you have stored a name in the phonebook to go with the number, the name will be displayed instead. The most recent last number will display at the top of the redial list.
Redial a Number from the Redial List
1. In idle mode, press to access the redial list.
2. Press / to browse the redial list.
3. Press / to dial to the selected redial number.
Store a Redial Number into the Phonebook
1. In idle mode, press to access the redial list ,
2. Press / to select the desire number
3. Press
and / to select ADD TO PB.
4. Press OK to enter the name.
5. Press OK or
to edit the redial number to store into the phonebook.
6. Press OK to select phonebook melody.
7. Press OK and / to browse the melody list. The respective melody will be played when browsing the melody list.
8. Press OK to conrm.
Delete a Redial Number
1. In idle mode, press to access the redial list
2. Press
/ to select the desire number
3. Press
and / to select DELETE.
4. Press OK to conrm.
Delete the Entire Redial List
1. In idle mode, press to access the redial list
2. Press
/ to select the desire number
3. Press
and / to select DELETE ALL.
4. Press OK to conrm.
Redial
If there are
no numbers in the redial list, the display shows “EMPTY”.
www.vtech.com
13
Caller display (Network Dependent)
This feature is available if you have subscribed the Caller Line Identication service with your network service
provider. Your phone can store up to 10 unanswered calls with date/time information in the calls log. The number
will be shown on the LCD when the phone is ringing. If the number matches with one of the entries in your Private
Phonebook, the caller’s name stored in the private phonebook will be displayed alternatively with the number. The handset will ring with the melody associated with that phonebook entry.
If the caller number is disabled to send caller information, “WITHHELD” will display. If the caller number is not provided, “UNAVAILABLE” will display. If the caller is from network public phone, “PUBLIC” will display. In standby, if three unanswered calls are received, “03 NEW CALLS” will be displayed.
View the Call List
All unanswered calls are saved in calls log with the latest call putting at the top of the list. When the call list is full, the
oldest call will be replaced by a new call. The unanswered call which has not been read is marked with a <* icon> at
the centre of the bottom line of the display.
1. Press to access the call list.OR Press and / to select CALL LIST.
2. Press / to select the desired entry.
Store a Call List Number into the Phonebook
1. Press to access the call list.OR Press and / to select CALL LIST.) 2 Press / to select the desired entry.
3. Press and / to select ADD TO PB.
4. Press OK to enter the name.
5. Press OK and the selected call list number is displayed.
6. Edit the number if necessary.
7. Press OK and / to select the melody.
8. Press OK to conrm.
Call List
www.vtech.com
14
Telephone settings
Delete an entry in the Call List
1. Press to access the call list.OR Press and / to select CALL LIST.)
2. Press / to select the desired entry.
3. Press and / to select DELETE.
4. Press to conrm.
Delete the entire list of the Call List
1. Press to access the call list.OR Press and / to select CALL LIST.
2. Press / to select the desired entry.
3. Press and / to select DELETE ALL.
4. Press OK to conrm.
5. Press OK to re-conrm.
View the Details of the Call List Entry
1. Press to access the call list.OR Press and / to select CALL LIST Press and / to select DETAILS.
2. Press and / to select the desired entry.
3. Press and / to select DETAILS.
4. Press the date and time of the selected call list entry display.
www.vtech.com
15
Your phone can store up to 20 private phonebook entries with names and numbers. Each phonebook entry
can have a maximum of 20 digits for the phone number and 12 characters for the name. You can also select different ring tones for your phonebook entries. Phonebook entries are stored alphabetically by name.
Add a New Phonebook Entry
In idle:
1. Press to access the phonebook, or Press and / to select main menu item and then press OK to access the phonebook.
2. Press to select ADD.
3. Press OK to enter the name.
4. Press OK to enter the number.
5. Press OK and / to select the desired ringtone for your phonebook entry.
6. Press OK to store the phonebook entry.
View a Phonebook Entry
In idle:
1. Press to access the phonebook.
2. Press / to select the desired phonebook entry.
3. Press and / to select VIEW.
4. Press / to review the name, number and melody of the selected phonebook entry.
Edit a Phonebook Entry
In idle:
1. Press to access the phonebook.
2. Press / to select the desired phonebook entry.
3. Press and / to select EDIT.
4. Press the current contents of the selected phonebook entry displays.
5. Edit the name and press OK.
6. Edit the number and press OK
Phonebook
Private Phonebook
Press
/ to move through other phonebook entries.
www.vtech.com
16
Telephone settings
7. Select the ringtone and press <OK> to conrm.
Delete a Phonebook Entry
In idle:
1. Press to access the phonebook.
2. Press / to select the desired phonebook entry.
3. Press and / to select DELETE.
4. Press OK to conrm.
Delete the Entire Private Phonebook
1. Press to access the phonebook.
2. Press and / to select DELETE ALL.
3. Press OK to conrm.
4. Press OK to re-conrm.
Check the Phonebook Usage
You can check how many phonebook entries have been occupied in your phone and how many phonebook entries are available for you to store in the phonebook.
1. Press to access the phonebook.
2. Press and / to select PB STATUS.
3. Press OK to conrm.
www.vtech.com
17
Text and Digit Entry Table
The following tables show you where each letter and punctuation character can be found. Respective character table will be used when corresponding menu language is selected. This will be helpful when storing a name in the phonebook and renaming your handset.
In editing mode, a cursor is displayed to indicate the current text entry position. It is positioned at the right of the last character entered.
Writing Tips:
1. Once a character is selected, the cursor will move to the next position after a short pause.
2. You can move the cursor within the text by / to amend the text entr y.
3. Press to delete the last character.
4. Press and hold to delete the entire text string.
Particular key characters table:
www.vtech.com
18
Telephone settings
Base Settings
Dial Type ( Preset to TONE )
Change the dial mode
1. Press and / to select BS SETTINGS.
2. Press OK and
/ to select DIAL MODE.
3. Press OK and / to select TONE or PULSE.
4. Press OK to conrm.
Change the system PIN Code
A 4-digit system PIN code is used for changing the system settings of the base station. It is used to protect your phone against unauthorized use. The default system PIN code is 0000.
1. Press
and / to select BS SETTINGS.
2. Press OK and / to select CHANGE PIN.
3. Press OK and you are requested to enter the 4-digit system PIN.
4. Enter the old system PIN.
5. Press OK and enter the new system PIN.
6. Press OK and enter the new system PIN again.
7. Press OK to conrm.
Paging (Find the Handset)
You can locate the handset by pressing on the base station. All the handsets registered to the base will produce the paging tone and “PAGING…” is displayed on the LCD. You can stop the paging by pressing
on
any handset or
on the base again.
If the new PIN entered in Step 6 is not matched with the new system PIN entered in Step.
If there is
an incoming call during paging, the phone will ring with the incoming call instead of paging.
www.vtech.com
19
Handset Settings
Alarm Settings
You can use this phone to set an alarm clock. When an alarm is set, the displays on the LCD. When the alarm time is reached, the and “ALARM ON” ash on the LCD ringing with the alarm melody for a duration of 45 seconds. You can press any key to disable the alarm. If snooze function is activated, the alarm will sound again at the end of the snooze period of seven minutes. You can also press and hold to terminate the snooze function.
Turn on/off the Alarm
1. Press and / to select HS settings.
2. Press OK and / to select Alarm.
3. Press OK and / to select ON/OFF.
4. Press OK to conrm.
Set the Alarm Time
1 Press and / to select HS SETTINGS 2 Press OK and / to select ALARM. 3 Press OK and / to select ON/OFF. 4 Press OK to conrm. 5 Enter the alarm time 6 Press OK to set the snooze function. 7 Press OK and / to select SNOOZE ON or SNOOZE OFF.
8. Press OK to conrm.
Note:
a. Key press is still applicable if handset keypad is locked and when the alarm time is reached. b. The alarm volume level is the same as the settings of the handset ringer volume. If the handset ringer is set to VOLUME
OFF, the alarm still sounds at VOLUME 1 level.
c. During an external call or internal call, if an alarm is set and when the alarm time is reached, the and “ALARM ON”
will still ash. An alarm tone will be emitted from the earpiece to notify user the alarm time is reached. Once user
press any key or press and hold to disable the alarm, it will rever t to the call duration screen.
d. During paging or ringing, the alarm will not sound when the alarm time is reached. However, if snooze function is
enabled, the alarm will sound again at the end of the snooze period provided that it’s not ringing or in paging mode at the end of the snooze period.
• If ON is
selected, you will be asked to set the alarm time.
www.vtech.com
20
Telephone settings
Set the Ringer Melody for Internal Calls
1. Press and / to select HS SETTINGS.
2. Press OK and / to select RING SETUP.
3. Press OK and / to select INT RING.
4. Press OK and / to select the desired ringer melody (a total of 10 melodies for your selection) for
setting ringer melody for internal calls.
5. Press OK to conrm.
Set the Ringer Melody for External Calls
1. Press and / to select HS SETTINGS.
2. Press OK and / to select RING SETUP.
3. Press OK and / to select EXT RING.
4. Press OK and / to select the desired ringer melody (a total of 10 melodies for your selection) for
setting ringer melody for external calls.
5. Press OK to conrm.
Set the Ringer Volume
1. Press and / to select HS SETTINGS.
2. Press OK and / to select RING SETUP.
3. Press OK and / to select RING VOLUME.
4. Press OK and / to select the desired ringer volume (a total of 6 ringer volume levels including VOLUME OFF).
If VOLUME OFF is selected, <Ringer Off> icon will display.
5. Press OK to conrm.
Ringer Setup
• The respective ringer melody will be played while browsing the melody list.
• The respective ringer melody will be played while browsing the melody list.
• The respective ringer volume will be played during your selection.
www.vtech.com
21
Tone Setup
A single beep is emitted when you press a key. You can turn on or off the key tone. You can also turn on the alert tones when low battery and out of range are detected.
Set Key Tone
1. Press and / to select HS SETTINGS.
2. Press OK and / to select TONE SETUP.
3. Press OK and / to select KEY TONE
4. Press OK and / to turn on or off these tones.
5. Press OK to conrm.
Set Battery Tone
1. Press and / to select HS SETTINGS.
2. Press OK and / to select TONE SETUP.
3. Press OK and / to select BATTERY TONE
4. Press OK and / to turn on or off these tones.
5. Press OK to conrm.
Set Out Of Range Tone
1. Press and / to select HS SETTINGS.
2. Press OK and / to select TONE SETUP.
3. Press OK and / to select OUT OF RANGE
4. Press OK and / to turn on or off these tones.
5. Press OK to conrm.
www.vtech.com
22
Telephone settings
Set the Handset Language
1. Press and / to select HS SETTINGS.
2. Press OK and / to select LANGUAGE.
3. Press OK and / to select the desired language.
4. Press OK to conrm.
Rename the Handset
1. Press and / to select HS SETTINGS.
2. Press OK and / to select RENAME HS.
3. Press OK and enter the name of your handset.
4. Press OK to conrm.
Set Handset Display
You can choose to display time or handset name in your idle screen.
1. Press and / to select HS SETTINGS.
2. Press OK and / to select HS DISPLAY.
3. Press OK and / to select HANDSET NAME or TIME.
4. Press OK to conrm.
www.vtech.com
23
Set the Auto Answer
If you turn on the Auto Answer, you can pick up the call from the cradle without pressing any key.
1. Press and / to select HS SETTINGS.
2. Press OK and / to select AUTO ANSWER.
3. Press OK and / to turn on or off the auto answer feature.
4. Press OK to conrm.
Date and Time Settings
You will need to set the correct time and date so that you know when you received answering machine (applicable to model with answering machine) or call list entries.
Change the Date Format
1. Press and / to select HS SETTINGS.
2. Press OK and / to select DATE & TIME.
3. Press OK and / to select DATE FORMAT.
4. Press / to select your desired date format (DD-MM-YY or MM-DD-YY).
5. Press OK to conrm.
Change the Time Format
1. Press and / to select HS SETTINGS.
2. Press OK and / to select DATE & TIME.
3. Press OK and / to select TIME FORMAT.
4. Press / to select your desired time format (12 HR or 24 HR).
5. Press OK to conrm.
• If time has been set before, the current time will display, other wise,
“HH:MM” will
display.
www.vtech.com
24
Telephone settings
If date has
been set before, the current date will display, other wise,
“DD -MM-YY”
will display.
Set the Time
1. Press and / to select HS SETTINGS.
2. Press OK and / to select DATE & TIME.
3. Press OK and / to select SET TIME.
4. Press OK to enter the time information. The time entered will be in the format follow the TIME FORMAT you
set before.
5. Press OK to conrm.
Set the Date
1. Press and / to select HS SETTINGS.
2. Press OK and / to select DATE & TIME.
3. Press OK and / to select SET DATE.
4. Press OK to enter the date information. The time entered will be in the format follow the DELETE FORMAT
you set before.
5. Press OK to conrm.
Reset your Phone
You can reset your phone to the default settings. After reset, all you personal settings and call list entries will be deleted, but your phonebook remains unchanged.
1. Press and / to select DEFAULT.
2. Press OK and you are requested to enter the 4-digit system PIN.
3. Enter the 4-digit system PIN.
4. Press OK to conrm.
5. Press OK to re-conrm.
www.vtech.com
25
If you have difficulty with your phone, please try the suggestions listed below:
Problem Cause Solutions
No dialing tone when pressing
key
a. The connection cord of the
base station is not plugged in.
b. T h e a dapt er c o r d i s n ot
pl u g ged in c o r r e c t l y in the base station.
c. The line is busy, as another
handset is used.
d. Wro ng connection cord (no
Euro AS)
a. Check the connections. Unplug
.sniam eht ni kcab gulp dna Check that the telephone line cord has been plugged into the base station and the phone socket.
b.
Check the base station power jack and the adaptor plug
(remove an plug-in).
c. W a i t u n t i l t h e l i n e i s
unoccupied.
d. Use th
e original connection
cord.
When connect to a PBX, no and/or wrong connection after dialing.
Dialing prex is needed. Insert the dialing prex
“SEARCHING” is displayed.
a. Base station out of range. b. Base station not connected
to mains.
Reduce the range. Connect base station to mains.
The call does not work.
Service not activated or wrong operator or wrong setting
Check your Subscription with network or change the dial mode.
No display.
Empty battery Recharge battery
Please contact
the technical support of the network provider for further information.
This telephone is not equipped with a grounding function! Therefore some of the functions may be limited when used in PBX systems. For technical support, call VTech Technical Inquiry Hotline Tel: 852-2667 7433.
Troubleshooting
www.vtech.com
26
Technical specifications
Stand: DECT
Number of channels: 10
Frequency: 1880MHz bis 1900MHz
Range: up to 300 meters outdoors, up to 50 metes indoors
Base station power supply:
230V 300mA
Charger station power supply: 230V 200mA
Handsets operationg time: standby / talk time approx. 100hrs / approx. 10hrs
Battery charging time: approx. 16hours
Base station dimensions: Width / depth / height = 130x101.6x66 mm
Charger station dimensions: Width / depth / height = 72.6x85.0x44.9 mm
Handset station dimensions: Width / depth / height = 46.1x29.3x155 mm
We
ight of a base: 134.3g (without adaptor)
Weight of a handset: 116.26g (with battery)
Weight of a charger: 40.3g (without adaptor)
Power pack: HongKong
VTech Electronics (HK) Ltd.
21/F, C.N.T. House, No. 120 Johnston Road,Wan Chai, Hong Kong.
Customer Service Center Tel: 852-2776 3223
Technical Inquiry Hotline Tel: 852-2667 7433
91-002202-010-100
Loading...
