CareLine
™
Quick start guide
SN6187
Register online to get an additional
3-month warranty!
Go to www.vtechphones.com to register your
product for enhanced warranty support and latest
VTech product news.
For abridged instructions, see the Abridged user’s
manual in the product package. For complete
instructions, see the online Complete user’s manual
at www.vtechphones.com.
Basic steps to set up and operate
Basic installation
Telephone base installation
•
Handset battery installation
•
Handset charger installation
•
Pendant charger installation
•
Pendant lanyard
•
Pendant belt clip
•
Common settings
Set date and time
•
Set speed dial number for pendant
•
Common operations
Voice command
•
Make, answer or end a call
•
Answering system
•
Reminders
•
Telephone base installation
Plug!
Plug!
Click!
Plug the DSL
filter into the
telephone
wall jack.
Click!
i
If you subscribe to telephone service from a cable
company or a VoIP service provider, contact your cable/
VoIP service provider for more information.
1
Handset battery installation
1
2
Plug!
3
Click!
2
Handset charger installation
1
Plug!
2
Light on!
Charge for at least
30 minutes before
initial settings.
3
Pendant charger installation
1 2
3
Light on!
Charge for at
least 30 minutes
before use.
4
Pendant lanyard
Necklace
Press down
Press down to
adjust the length.
to remove the
necklace.
Pendant belt clip
Remove the necklace of the pendant lanyard or the
whole pendant lanyard before you use the pendant
belt clip.
Click!
5
Set date and time
If you subscribe to caller ID
service, the date and time are
set automatically with each
incoming call. You can also set
the date and time manually.
Press MENU >>
1.
Scroll to Set date/time >>
Press SELECT.
Enter the month (MM),
2.
date (DD) and year (YY) >>
Press SELECT.
Enter the hour (HH) and minute (MM) >>
3.
Scroll to AM or PM >> Press SELECT.
Ringers
>Set date/time
SET DATE
MM/DD/YY
6
Set speed dial number for pendant
We recommend you store two
contacts that you may need
to call them more often or
immediately to speed dial keys
1 and 2 on the pendant.
Use a handset to set the speed
dial numbers.
Press MENU >>
1.
Scroll to Pendant >>
Press SELECT.
Scroll to Memory 1 or
2.
Memory 2 >> Press SELECT.
Enter the number >>
3.
Press SELECT.
Enter the name >>
4.
Press SELECT.
Set date/time
>Pendant
MEMORY 1 NUMBER
_
MEMORY 1 NAME
_
7
Voice command
By saying certain commands to the pendant, you
can hear information such as the date or time, or
call speed dial numbers, or even review call log,
messages or reminders.
Press the VOICE key on either side of the
pendant. After you hear a beep, say your
command to the pendant.
What can I say?
VOICE
VOICE
Press
8
Voice command
Common commands:
What can I say?
To hear a list of voice commands.
What time is it?
To hear the current time.
What date is it?
To hear the current date.
Call speed dial X.
To call a speed dial number.
Intercom all.
To send out intercom request to
all devices.
Cancel.
To return to idle mode.
9
Voice command
Reminders:
Press VOICE and say to
Review reminders.
review today’s upcoming reminders.
During the playback, press VOICE and say one of
the following commands:
What can I say?
To hear a list of voice commands.
Skip reminder.
To skip to the next reminder.
Repeat reminder.
To repeat the reminder.
Stop.
To stop the playback.
Cancel.
To continue the playback.
10
Voice command
Messages:
Press VOICE and say .
Review messages.
During the playback, press VOICE and say one of
the following commands:
What can I say?
To hear a list of voice commands.
Skip message.
To skip to the next message.
Repeat message.
To repeat the message.
Slow playback.
To slow down the message.
To resume to normal speed,
press VOICE and
say .
Stop.
To stop the playback.
Play normal.
Delete.
To delete the playing message.
Cancel.
To continue the playback.
11
Voice command
Call log:
Press VOICE and say .
Review call log.
During the playback, press VOICE and say one of
the following commands:
What can I say?
To hear a list of voice commands.
Skip call log.
To skip to the next call log entry.
Repeat call log.
To repeat the call log.
Stop.
To stop the playback.
Cancel.
To continue the playback.
Call back.
The system will ask, “Would you like
to call XXX?”
Say to call the number.
•
Yes.
Say to return to the playback.
•
No.
12
Make, answer or end a call
Press to make or answer
•
a call.
During a call, press to
•
answer an incoming call when
you receive a call waiting alert.
Press to end a call.
•
Press any dialing key to
•
answer a call.
13
Make, answer or end a call
Press to answer or
•
end a call.
Press to call
•
speed dial 1.
Press to call
•
speed dial 2.
14
Answering system
Turn the answering system on/off
Press /ANS ON/OFF on the telephone base to
•
turn the answering system on or off.
Record an announcement
Press MENU >> Scroll to Answering sys >>
1.
Press SELECT three times.
After the tone, speak towards the microphone.
2.
Press 5 when done.
3.
15
Answering system
Message playback
Press once to repeat
•
the playing message.
Press twice to play
•
the previous message.
Press X to delete the
•
playing message.
Press to skip to the
•
next message.
Press to play
•
messages.
Press to stop
•
message playback.
Press to improve
•
the playback clarity and
loudness.
Press or to adjust
•
the listening volume.
Press to slow down
•
the message playback.
16
Reminders
The reminder feature helps remind you of important
events. You can set the reminder to remind you only
once, or in daily, weekly or monthly bases. Once you
set the reminder, the system will play your recorded
reminder to alert you at your designated times of an
important event.
Press MENU >> Scroll to Reminder >>
1.
Press SELECT.
Scroll to Set reminder >> Press SELECT.
2.
Enter the month (MM), date (DD) and year (YY)
3.
>> Press SELECT.
Enter the hour (HH) and minute (MM) >>
4.
Scroll to AM or PM >> Press SELECT.
After the tone, speak towards the microphone.
5.
Press 5 when done.
6.
Scroll to the desired frequency >> Press SELECT.
7.
IMPORTANT!
Refer to the online Complete user’s manual for a full set of
installation and operation instructions. For manual download
or customer service, visit our website at
www.vtechphones.com or call 1 (800) 595-9511. In Canada,
go to www.vtechcanada.com or call 1 (800) 267-7377.
17
