Vtech SN1197, SN6127, SN1196, SN6187, SN6196 User Manual

...

Compatible with

Hearing Aid T-Coil

TIA-1083

™

CareLine

User’s manual

SN6107

DECT 6.0 accessory handset for use with VTech models SN1157/SN1196/SN1197/SN6127/ SN6146/SN6147/SN6187/SN6196/ SN6197

Congratulations

on purchasing your new VTech product. Before using this telephone, please read Important safety instructions on page 9 of this manual.

This manual has instructions on how to set up and register your new handset. For complete instructions on using the handset, see the Abridged user’s manual that came with your telephone base.

You may also view or download the online Complete user’s manual for a full set of installation and operation instructions at www.vtechphones.com. In Canada, visit www.vtechcanada.com.

Telephones identiﬁed with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it meets the latest energy efﬁciency guidelines.

Registration

Product news

Learn about the latest VTech products.

Parts checklist

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

Cordless handset Handset charger and

charger adapter

User’s manual

Battery compartment cover

User’s manual

Battery

Handset battery installation

Plug the battery connector

1. Place the battery with securely into the socket.

2. the label THIS SIDE UP facing up and the wires inside the battery compartment.

Slide the battery compartment cover towards the center

3. of the handset until it clicks into place.

Handset charger installation

Install the charger

1. Place the handset in as below.

Electrical outlet not controlled by a wall switch

Handset charger power adapter

2. the handset charger to charge.

Handset battery charging

Once you have installed the battery, the handset indicates the battery status. If necessary, place the handset in the handset charger to charge. The battery is fully charged after 11 hours of continuous charging.

Battery indicators Battery status Action

The screen is blank, or displays Place in charger and ﬂashes.

The screen displays Low battery and ﬂashes.

The screen displays HANDSET X.

The battery has no or very little charge. The handset cannot be used.

The battery has enough charge to be used for a short time.

The battery is charged.

Charge without interruption (about 30 minutes).

To keep the battery charged, place it in the handset charger when not in use.

Add and register a handset

You can add new handsets to your telephone system. Each handset must be registered with the telephone base before use. When ﬁrst purchased, each expansion handset shows To register HS, see manual. The new handset should be charged without interruption for at least 30 minutes before registering it to the telephone base.

Make sure the handset is out of the handset charger and is put near the telephone base. Make sure the handset shows

To register HS, see manual before you begin registration.

To register a handset to your SN1157/SN1196/SN1197/ SN6146/SN6147/SN6196/SN6197 telephone base:

Press MENU on the telephone base

1. when idle.

Scroll to Settings, then press SELECT.

2. Scroll to Registration, then press

SELECT. The telephone base shows

Registering... Please wait.

Press QUIET# on the cordless

4. handset. The handset shows

Registering... Please wait. Then HANDSET X Registered appears on

the cordless handset and the telephone base, and both devices beep. The handset is now registered with the telephone base. It takes up to 60 seconds to complete registration.

If registration fails, the telephone base displays Registration failed and you hear an error tone. Start again from Step 1 above.

To register a handset to your SN6127/SN6187 telephone base:

Put the handset into the telephone

•

base. The base IN USE light turns solid red. The handset shows

Registering... Please wait. Then HANDSET X Registered appears on

the cordless handset. The handset beeps and is now registered with the telephone base. It takes up to 60 seconds to complete registration.

If registration fails, the handset displays Registration failed and you hear an error tone. Start again from Step 1 above.

Deregister devices

If you want to replace a device, or reassign the designated device number of a registered device, you must deregister all devices that are registered to the telephone base. Then register each device individually.

To deregister all devices from your SN1157/ SN1196/SN1197/SN6146/SN6147/SN6196/SN6197 telephone base:

Press and hold FIND HS at the side of the telephone

1. base for about 10 seconds until the telephone base shows Registering... Please wait followed by Deregister all devices?, then release FIND HS.

Immediately press YES or FIND HS.

2. All handsets show To register HS, see manual. The

3. deregistration process takes about 10 seconds to complete.

To deregister all devices from your SN6127/SN6187 telephone base:

Press and hold /FIND HANDSET at the side of the

1. telephone base for about 10 seconds until the telephone base IN USE light turns solid red and then ﬂashes red, then release /FIND HANDSET.

Immediately press /FIND HANDSET.

2. All handsets show To register HS, see manual. The

3. deregistration process takes about 10 seconds to complete.

You cannot deregister all devices if any system device is in use.
