VTech DS8141, DS8141R-2 User Manual

w w w.vtech.c om /hk / tel
Models: DS8141/DS8141R-2
User’s manual
TABLE OF CONTENTS
1.
2. SET UP THE TELEPHONE .......................................................3
2.1 Package Contents .................................................................................... 3
2.2 Location ....................................................................................................3
2.3 Connect the Base Station .........................................................................4
2.4 Connect the Charger Base .......................................................................5
2.5 Connect the Range Extender .................................................................. 6
2.5.1 Location .......................................................................................6
2.5.2 Map The Telephone Base Coverage ............................................ 6
2.5.3 Test the Location ..........................................................................6
2.5.4 Install your Range Extender ......................................................... 7
2.6 Install and Charge the Handset Batteries ................................................. 8
2.7 Installation Options ...................................................................................9
2.7.1 Tabletop to Wall Mount Installation.......................................... 9
2.7.2 Wall Mount to Tabletop Installation ............................................ 11
3. GET TO KNOW YOUR PHONE ................................................12
3.1 Overview of the Handset ........................................................................ 12
3.2 Overview of the Base Station ................................................................. 15
3.3 Overview of the Range Extender ............................................................ 19
3.4 Handset LCD Display Icons and Symbols .............................................. 20
3.5 Menu Structure .......................................................................................21
3.6 Text and Digit Entry Table .......................................................................23
3.6.1 English Character Set ................................................................. 23
4. BLUETOOTH® ..........................................................................24
4.1 Introducing BLUETOOTH® ................................................................... 24
4.2 Important Information .............................................................................24
4.3 BLUETOOTH® Setup ............................................................................. 25
4.3.1 Add a Mobile Phone .................................................................. 25
4.3.2 Add a Headset ..........................................................................26
4.3.3 Auto Connection ........................................................................ 27
4.3.4 BLUETOOTH® Connection from Idle Mode....................... ........27
4.3.5 Device List and Connection .......................................................27
4.3.6 Review the Active Device List ................................................... 28
4.3.7 Connect/disconnect an Active Device ....................................... 28
4.3.8 Remove a Device ...................................................................... 28
4.3.9 Rename a Device .....................................................................29
4.3.10 Replace an Active Device ......................................................... 29
4.3.11 Download Phonebook ............................................................... 30
4.3.12 Interruption to Phonebook Download ........................................ 31
4.3.13 View the Phonebook Download Information .............................. 32
4.3.14 Change PIN ..............................................................................32
5. USING THE PHONE ................................................................33
5.1 Make a Home Call ..................................................................................33
5.1.1 Preparatory Dialing a Home Call................................................33
5.1.2 Direct Dialing a Home Call ......................................................... 33
5.2 Answer a Home Call ...............................................................................33
5.3 End a Home Call ....................................................................................33
5.4 Transfer a Call ........................................................................................ 33
5.5 Call Waiting on the Home Line ...............................................................34
5.6 Make a Mobile Call .................................................................................34
5.1.1 Preparatory Dialing a Mobile Call ........................................... ..34
5.1.2 Direct Dialing a Mobile Call ........................................................ 34
5.7 Answer a Mobile Call ..............................................................................34
5.8 End a Mobile Call ...................................................................................34
5.9 Call Waiting on the Mobile Line ..............................................................35
5.10 Answer an Incoming Mobile Call While on a Home Call ......................... 35
5.10.1 Answer the Incoming Mobile Call ............................................... 35
5.10.2 End the Mobile Call .................................................................... 36
5.10.3 Resume the Home Call on Hold ................................................36
5.11 Answer a Home Call While On a Mobile Call .......................................... 36
5.11.1 Answer the Incoming Home Call ................................................ 36
5.11.2 End the Home Call ..................................................................... 36
5.11.3 Resume the Mobile Call on Hold ................................................ 36
5.12 Conference Calls ....................................................................................37
5.12.1 Conference Home and Mobile Calls ..........................................37
5.12.2 Conference both Home and Mobile Calls ..................................37
5.12.3 Select an Option while on a Conference Call ............................37
5.12.4 End a Conference Call ............................................................... 37
5.12.5 Using the Home and Mobile Lines Together .............................. 37
5.13 Handsfree ...............................................................................................38
5.14 Earpiece / Handsfree Volume ................................................................. 38
5.15 Silencing the Ringer ...............................................................................38
5.16 Auto Answer ............................................................................................ 39
5.17 Lock Keypad ...........................................................................................39
5.18 Call Timer ...............................................................................................39
5.19 Out of Ranger Warning ........................................................................... 39
5.20 Mute ........................................................................................................39
5.20.1 Mute a Call ................................................................................. 39
5.20.2 Take a Call off Mute ...................................................................39
5.21 Hold ........................................................................................................ 40
5.21.1 Place a Home Call on Hold ........................................................ 40
5.21.2 Resume a Home Call on Hold ...................................................40
5.21.3 Place a Mobile Call on Hold ....................................................... 40
5.21.4 Resume a Mobile Call on Hold ..................................................40
5.22 Equalizer .................................................................................................40
5.23 Chain Dialling .........................................................................................41
5.23.1 Access a Number in the Phonebook while on a Call .................41
5.23.2 Access a Number in the Call List while on a Call ....................... 41
5.23.3 Access the Redial List while on a Call .......................................41
5.24 Redial .....................................................................................................42
5.24.1 Review the Redial List ...............................................................42
5.24.2 Dial a Redial Entry .....................................................................42
5.24.3 Save a Redial Entry to the Phonebook ...................................... 43
5.24.4 Delete a Redial Entry ................................................................. 44
5.25 Find Handset (Paging) ............................................................................ 44
5.25.1 Start Paging ...............................................................................44
5.25.2 End Paging ................................................................................44
5.26 Power Fail Back-Up ................................................................................ 45
5.26.1 Set Power Fail Back-Up Mode ................................................... 45
5.26.2 Make a Call Using Power Fail Back-Up Mode ........................... 46
5.26.3 Answer a Call Using Power Fail Back-Up Mode ........................ 46
6. PHONEBOOK ..........................................................................47
6.1 Create and Review Entries ..................................................................... 47
6.1.1 Create a New Entry in the Home Phonebook ............................ 47
6.2 Add a Predialled Telephone Number to the Phonebook ......................... 48
6.3 View the Phonebook ...............................................................................49
6.4 3-character Alphabetical Search ............................................................. 50
6.5 Dial, Edit or Delete a Phonebook ........................................................... 50
6.5.1 Dial a Phonebook Entry .............................................................50
6.5.2 Edit a Phonebook Entry .............................................................51
6.5.3 Edit the Type of a Phonebook Entry...........................................51
6.5.4 Delete a Phonebook Entry ......................................................... 52
6.5.5 Remove a Downloaded Phonebook ..........................................52
6.6 Speed Dial ..............................................................................................52
6.6.1 Assign a Speed Dial Phonebook Entry ...................................... 52
6.6.2 View the Speed Dial Phonebook................................................53
6.6.3 Dial a Speed Dial Entry .............................................................. 53
6.6.4 Reassign a Speed Dial Entry ..................................................... 53
6.6.5 Delete a Speed Dial Entry .......................................................... 54
7. NETWORK SERVICE ..............................................................55
7.1 Calling Number Display ..........................................................................55
7.1.1 View the Call List........................................................................55
7.1.2 Dial a Call List Entry ................................................................... 56
7.1.3 Save a Call List Entry to the Phonebook ...................................56
7.1.4 Delete a Single Entry in the Call List .......................................... 57
7.1.5 Delete the Entire Call List ..........................................................57
7.2 Voicemail Indicator ................................................................................57
8. PHONE SETTINGS ..................................................................59
8.1 Ringer Volume ........................................................................................59
8.2 Ringer Tone ............................................................................................60
8.3 Low Battery Tone .................................................................................... 60
8.4 No Coverage Tone .................................................................................. 60
8.5 Display Alert ............................................................................................ 61
8.5.1 Missed Call Indicator .................................................................. 61
8.5.2 No Line Indicator ........................................................................ 61
8.5.3 Download Fail ............................................................................62
8.6 Date and Time ........................................................................................ 62
8.6.1 Set the Date Format ................................................................... 63
8.6.2 Set the Time Format ..................................................................63
8.6.3 Set the Date and Time ............................................................... 63
8.7 Auto Answer ............................................................................................ 64
8.8 Rename Handset or the Telephone base .............................................. 64
8.9 Key Tone ................................................................................................. 65
8.10 Flash Time ..............................................................................................65
8.11 Voice Announce Caller ID ....................................................................... 66
8.12 Reset ...................................................................................................... 67
9. ANSWERING MACHINE ........................................................68
9.1 Answer On/Off ....................................................................................... 68
9.2 Outgoing Message ................................................................................69
9.2.1 Play Your Outgoing Message .................................................... 69
9.2.2 Record Your Own Outgoing Message ....................................... 69
9.2.3 Delete Your Outgoing Message ................................................ 70
9.3 Message Playback .................................................................................70
9.4 Delete All Old Messages ........................................................................72
9.5 Record and Play Memos ........................................................................ 73
9.6 Answering Machine Settings ..................................................................73
9.7 Call Screening ........................................................................................ 73
9.8 Number of Ringers .................................................................................74
9.9 Remote Access Code .............................................................................74
9.10 Message Alert Tone ................................................................................ 75
9.10.1 Temporarily Turning off the Message Alert Tone ........................ 75
9.11 Recording Time ....................................................................................... 76
9.12 Answering System and Voicemail ........................................................... 76
9.12.1 Using the Answering System and Voicemail Together ............... 77
9.12.2 Message Capacity .....................................................................77
9.12.3 Voice Prompts ............................................................................ 77
9.12.4 Call screening at the Telephone Base or Handset ..................... 77
9.12.5 Call Intercept .............................................................................. 78
9.13 Remote Access ....................................................................................... 78
9.13.1 Remotely Access the Answering System ................................... 78
9.13.2 Remote Commands ................................................................... 78
10. ADDITIONAL HANDSETS .......................................................80
10.1 Transfer a Call ........................................................................................ 80
10.2 Join a Call in Progress ............................................................................ 80
10.3 Intercom ..................................................................................................80
10.3.1 Initiate an Intercom Call .............................................................81
10.3.2 Answer an Intercom Call at the Destination Device ................... 81
10.3.3 Silence an Intercom Call ............................................................ 81
10.3.4 Mute while on an Intercom Call .................................................. 81
10.3.5 End an intercom Call at the Destination Handset ......................82
10.3.6 End an Intercom Call at the Telephone Base ............................. 82
10.4 Answer an Incoming Call during an Intercom Call .................................. 82
10.4.1 Answer a Home Call during an Intercom Call ............................ 82
10.4.2 Answer a Mobile Call during an Intercom Call ........................... 82
10.5 Call Transfer Using Intercom ..................................................................83
10.5.1 Transfer an Outside Call ............................................................ 83
10.6 Registration ............................................................................................85
10.6.1 Easy Registration for Additional Handset ................................... 85
10.6.2 Register an Additional Handset through the Menu ....................85
10.7 Deregister Handsets ...............................................................................86
11. RANGE EXTENDER ................................................................... 87
11.1 Setup your Ranger Extender .................................................................. 87
11.1.1 Automatic Registration ...............................................................87
11.1.2 Manual Registration .................................................................. 87
11.2 System Expansion ..................................................................................88
12. DEFAULT SETTINGS ..............................................................89
13. TROUBLESHOOTING .............................................................90
14. TECHNICAL SPECIFICATIONS ..............................................93
15. CARE AND MAINTENANCE INSTRUCTIONS .......................94
11
1.
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of re, electric shock and injury, including the following:
Read and understand all the instructions.
Follow all warnings and instructions marked on the product.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Do not use this product near water (for example, near a bath tub, kitchen sink, swimming pool).
Do not expose the telephone to direct sunlight or extreme cold environment. Do not put the telephone close to heating sources such as radiators, cookers, etc.
Do not overload wall outlets and extension cords as this can result in the risk of re
or electric shock.
Unplug this product from the wall outlet and refer servicing to VTech under the
following conditions:
When the power supply cord or plug is damaged or frayed.
If the product does not operate normally by following the operating instructions.
If the product has been dropped and the cabinet has been damaged.
If the product exhibits a distinct change in performance.
Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
Use only the supplied NiMH (Nickel Metal Hydride) batteries! The operation periods for the handsets are only applicable with the default battery capacities.
The use of other battery types or non-rechargeable batteries/primary cells can be dangerous. These may cause interference and/or unit damages. The manufacturer will not be held liable for damage arising from such non-compliance.
Do not use third party charging bays. The batteries may be damaged.
Please note the correct polarity while inserting the batteries.
Do not immerse batteries in water, do not place in re.
1.
2.
3.
4.
5.
6.
7.
•
•
•
•
8.
9.
10.
11.
12.
13.
14.
22
DISPOSAL WARNING
When this crossed-out wheeled bin symbol is attached to a product, it means the product is covered by the European Directive 2002/96/EC.
All electrical and electronic products/battery should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.
The correct disposal of your old appliance/battery will help prevent potential negative consequences for the environment and human health.
For more detailed information about disposal of your old appliance/battery, please
contact your city ofce, waste disposal service or The Shop where you purchased the
product.
If you have questions about this product, or having difculty with setup or operation,
call or Customer Service Centre.
Customer Service Hotline: (852) 2666 5558
Technical Inquiry Hotline: (852) 2667 7433
1.
2.
3.
3
SET UP THE TELEPHONE
2. SET UP THE TELEPHONE
2.1 Package Contents
The package contains the following items:
Handset (1 for DS8141, 2 for DS8141R-2)
1 Base unit
1 AC power adaptor
2 Telephone line cords
NiMH rechargeable battery pack (1 for DS8141, 2 for DS8141R-2)
Charger (1 for DS8141R-2)
Charger AC power adaptor (1 for DS8141R-2)
Range extender and power adaptor (1 for DS8141R-2)
User’s manual
1 Warranty card
2.2 Location
For maximum coverage and reduce the interference, here are some guidelines you
should consider when you place the base unit:
- Place your telephone within 2 metres of the mains power socket and telephone socket so that the cables will reach.
- Make sure it is at least 1 metre away from other electrical appliances to avoid interference. Your telephone works by sending radio signals between the handset and base. The strength of the signal depends on where you locate the base. Putting it as high as possible ensures the best signal.
- The maximum range between the base station and the handset is approximately 300 metres.
If the reception for a base unit location is not satisfactory, move it to another location for better reception.
Depending on the surrounding conditions as well as spatial and structural factors, the range may be reduced. The range indoors is normally less than outdoors.
•
•
•
•
•
•
•
•
•
•
SET UP THE TELEPHONE
4
2.3 Connect the Base Station
Insert the DC plug of the power adapter and the telephone line cord into the base station, as shown above.
Insert the other end of the power adapter into the wall outlet and the telephone
line cord into a telephone wall jack. If you have DSL high speed internet service, a DSL lter (not included) is required.
noteS
Always use the cables supplied with the product.
Use only the power adapter supplied with the base station.
1.
2.
1.
2.
Telephone line cord
Mains power wall socket
If you have ADSL high speed Internet service, an ADSL
lter (not included)
is required.
Mains power cable
Telephone wall socket
5
SET UP THE TELEPHONE
2.4 Connect the Charger Base (only for model with additional handset)
Plug the mains power cable into the charger base, plug the other end into the mains power wall socket and switch the power on.
note
Ensure power cord is fed through slot on the charger so unit sits ush with the desk.
Mains power wall socket
Mains power cable
6
2.5 Connect the Range Extender (only for model with range extender)
2.5.1 Location
To get the best operating conditions for the Range Extender, it is important to place it
correctly. Here are a few tips for placing the Range Extenders:
Place the Range Extender as high as possible, but at least 2 metres off the ground.
Make sure you have good reception from the telephone base.
Make sure the location is close to a corresponding mains socket. Never install
electrical cords across a trafc area: they can create a trip hazard or become damaged and create a re or electrical hazard.
Allow at least 11 metres between the Range Extenders (if you are installing the
Range Extenders across multiple oors, remember to allow 11 metres vertically as
well).
Avoid sources of electrical interference, such as hi- systems, ofce equipment or
microwave ovens.
Avoid heat sources and direct sunlight.
Avoid things that can interfere with radio signals, such as metal doors, thick walls, niches and cupboards.
2.5.2 Map The Telephone Base Coverage
To nd the best location for the Range Extender, you need to determine the telephone
base coverage area.
Stand near the telephone base and make a call.
Walk away from the telephone base with the handset.
Make a note where the signal becomes weaker.
note
The optimum location for the Range Extender is as far from the telephone base as
possible while still maintaining a “good” signal, or just inside the location where the
signal became weaker.
2.5.3 Test the Location
To test the location:
Plug the AC adaptor into the Range Extender.
Hold the Range Extender in the place where you plan to mount it. The LED should remain on and steady, indicating that the Range Extender has a good signal from the telephone base.
•
•
•
•
•
•
•
1.
2.
3.
1.
2.
7
SET UP THE TELEPHONE
2.5.4 Install your Range Extender
Plug the mains power cable into the Range Extender in its nal location, plug the other
end into the mains power wall socket and switch the power on.
Or if you want to mount the Range Extender on a wall:
Plug the mains power cable into the Range Extender, thread the cable through the locking slot and then bundle the power cable with a twist tie.
Put the wall mount slot on the back of the Range Extender over the screw heads and slide the Range Extender down into place.
1.
2.
note
Be sure the wall material can hold the weight of the Range Extender. Never install a Range Extender in damaged or decaying wall material.
3. Plug the other end of the mains power cable into the mains power wall socket and switch the power on.
note
Before using the Range Extender, you need to register the Range Extender to the telephone base. Refer to Chapter 11 (page 87) for details.
8
2.6 Install and Charge the Handset Batteries
Slide open the battery compartment cover.
Place the supplied rechargeable battery in the battery compartment, with the battery connector plugged in, as shown.
Slide the battery compartment cover back on until it clicks into place.
Place the handset on the base to charge for at least 16 hours. The Charging LED lighting up indicates that the handset is properly placed on the base.
noteS
Use only the supplied NiMH rechargeable batteries.
If you do not use the handset for a long time, disconnect and remove the batteries to prevent possible leakage.
1.
2.
3.
4.
1.
2.
9
2.7 Installation Options
Your telephone base is ready for tabletop use. If you want to mount your telephone on a wall, follow the steps below to connect the telephone base with a standard dual-stud telephone wall mounting plate. You may need a professional to install the wall mounting plate.
2.7.1 Tabletop to Wall Mount Installation
Unplug the power adaptor from the mains socket. Unplug the telephone line cord
from the wall socket (or DSL lter). Make sure the telephone line cord and the
power cord are routed through the grooves at the bottom of the telephone base accordingly.
1.
2. Press down on the tabs of the wall mount bracket as indicated to release it from tabletop orientation.
SET UP THE TELEPHONE
10
3. Rotate the wall mount bracket down and push it into the telephone base until it clicks into place.
4. Plug the telephone line cord into the wall socket. Plug the power adaptor into a mains socket not controlled by a wall switch. Align the slots on the back of the telephone base with the studs of the wall mounting plate. Make sure the telephone line cord does not get caught between the wall mount plate and the telephone base.
5. Slide the telephone base down until it locks securely. Bundle the telephone line cord and power adaptor cord neatly with twist ties.
11
2.7.2 Wall Mount to Tabletop Installation
To change the telephone base from the wall mount position to tabletop position, follow the steps below.
If the telephone line cord and power adaptor cord are bundled, untie them rst.
Push the telephone base up to remove it from wall. Unplug the telephone line cord
(or DSL lter) from the wall. Unplug the power adaptor from the mains socket.
1.
2.
3. Gently pull upward to release the wall mount bracket. Rotate the wall mount bracket up to tabletop position and push it into the telephone base until it clicks into place.
4. See Connect the Base Station on page 4.
SET UP THE TELEPHONE
12
3. GET TO KNOW YOUR PHONE
3.1 Overview of the Handset
1. RIGHT SOFT KEY
Press to select a menu item displayed above the key.
While in a menu: Press to select an item or save an entry or setting.
2. MUTE/DELETE
During a call: Press to mute the microphone.
While predialling: Press to delete digits.
While reviewing the redial list, phonebook or calling number display history: Press
to delete an individual entry.
While entering or editing a phonebook entry: Press to erase a digit or character.
While the handset is ringing: Press to silence the ringer temporarily.
During message or outgoing message playback: Press to delete a message or
outgoing message.
13
GET TO KNOW YOUR PHONE
3. DIR/UP/VOLUME+
Press to scroll up while in menus.
During a call or message playback: Press to increase the listening volume.
Press to show phonebook entries when the telephone is not in use.
While entering names or numbers in the phonebook: Press to move the cursor
to the left.
4. CID/DOWN/VOLUME
-
Press to scroll down while in menus.
During a call or message playback: Press to decrease the listening volume.
Press to show the calling number display history when the telephone is not in use.
While entering names or numbers in the phonebook: Press to move the cursor
to the right.
5. TALK OFF/CANCEL
While using menus: Press to cancel an operation, back up to the previous
menu, or exit the menu display.
Press and hold to return to idle mode.
During a call: Press to hang up.
Press and hold while the telephone is not in use to erase the displayed messages (XX Missed calls and Download fail).
While the handset is ringing: Press to silence the ringer temporarily.
6. ALPHANUMERIC KEYPAD
In idle / pre-dial / editing mode / during a call: Press to enter characters /
numbers.
In idle / pre-dial / during a call : Press * to insert a “*”.
In idle mode: Press and hold * to lock the keypad.
In idle / pre-dial mode / during a call: Press # to insert a “#”.
During a call: Press and hold 2 during a conversation to answer Call-Waiting.
Press and hold 3 to commence 3-Way-Chat.
7. EQ
During an outside call, intercom call, message or outgoing message playback:
Press to change the quality of the audio to best suit your hearing.
8. REDIAL/PAUSE
Press repeatedly to view the last 10 numbers dialled.
While entering numbers: Press and hold to insert a dialling pause.
14
9. SPEAKER
Press to make or answer a home or mobile call using the speakerphone.
Press to turn on the handset speakerphone.
Press again to resume normal handset use.
10. HOME/RECALL (FLASH)
Press to make or answer a home call.
During a home call: Press to answer an incoming call when you hear a call waiting alert.
Flashes quickly when there is an incoming home call or when the answering system is recording a call.
Flashes slowly when a home call is on hold.
11. MOBILE
Press to make or answer a mobile call.
During a mobile call: Press to answer an incoming call when you hear a call waiting alert.
Flashes quickly when there is an incoming mobile call.
Flashes slowly when a mobile call is on hold.
12. LEFT SOFT KEY
While in a menu: Press to go back to previous menu.
13. CHARGE LIGHT
On when the handset is charging in the telephone base or charger.
15
GET TO KNOW YOUR PHONE
3.2 Overview of the Base Station
1. DEVICE 1/DEVICE 2 LIGHTS
On when the telephone base is paired and connected with a BLUETOOTH
®
device.
Flash alternately while pairing a BLUETOOTH® device.
2. REPEAT
Press to repeat a message or press twice to play the previous message.
3. DELETE
Press to delete the message currently playing.
When the phone is not in use, press twice to delete all previously reviewed messages.
While entering names or numbers: Press to delete a digit or a character.
While reviewing the redial list, phonebook or call list: Press to delete an
individual entry.
While predialling: Press to delete a digit.
4. SKIP
During message playback: Press to skip to the next message.
5. PLAY/STOP
Press to play messages.
Press to stop message playback.
1
2
3
4
5
6
7
9 8
1011
12
16
6. ANSWER ON
Press to turn the answering system on or off.
7. HOME/SPEAKER
Press to make or answer a home call.
Flashes quickly when there is an incoming home call.
Flashes slowly when a home call is on hold.
8. MOBILE
Press to make or answer a mobile call.
During a mobile call: Press to answer an incoming call when you hear a call waiting
alert.
Flashes quickly when there is an incoming mobile call.
Flashes slowly when a mobile call is on hold.
9. HEADSET
Press to transfer a call from the telephone base to a connected BLUETOOTH® headset.
Press to use a connected BLUETOOTH® headset.
Press to end a call while you are using the BLUETOOTH
®
headset.
10. ALPHANUMERIC KEYPAD
In idle / pre-dial / editing mode / during a call: Press to enter characters / numbers.
In idle / pre-dial / during a call : Press * to insert a “*”.
In idle / pre-dial mode / during a call: Press # to insert a “#”.
During a call: Press and hold 2 during a conversation to answer Call-Waiting. Press
and hold 3 to commence 3-Way-Chat.
11. HOLD
During a call: Press to place a call on hold.
12. PAGE/HANDSET LOCATOR
Press to page all system handsets.
Press and hold to begin handset deregistration.
17
GET TO KNOW YOUR PHONE
13. LEFT SOFT KEY
While in a menu: Press to go back to previous menu.
14. CID/DOWN
Press to scroll down while in menus.
Press to show the call list when the telephone is not in use.
While entering names or numbers in the phonebook: Press to move the cursor to
the left.
15. CANCEL
While in a menu: Press to exit without making changes or press and hold to return
to idle mode.
Press and hold while the telephone is not in use to erase the displayed messages.
16. DIR/UP
Press to scroll up while in menus.
Press to show phonebook entries when the telephone is not in use.
While entering names or numbers in the phonebook: Press to move the cursor to
the right.
17. RIGHT SOFT KEY
Press to select a menu item displayed above the key.
While in a menu: Press to select an item or save an entry or setting.
13 14
15
16 17
21
20
18
19
18
18. RECALL/FLASH
During a home call: Press to answer an incoming call when you hear a call waiting alert.
19. MUTE
During a call: Press to mute the microphone.
While the telephone base is ringing: Press to silence the ringer temporarily.
20. VOLUME UP/DOWN
Press to adjust the volume during message playback.
Press to adjust the volume during a call.
When the phone is not in use, press to adjust the telephone base ringer volume for
all lines.
21. REDIAL/PAUSE
Press repeatedly to view the last 10 numbers dialled.
While entering numbers: Press and hold to insert a dialling pause.
19
GET TO KNOW YOUR PHONE
3.3 Overview of the Range Extender
1. Setup Button Combined with LED Indicator
The SETUP button is used to initiate registration/deregistration process. The LED indicator is used to show the link or usage status of the Range Extender.
LED
Description
Colour Pattern
- - Powered off.
Red Long Flash The Range Extender is not registered.
Red/Blue Toggle The Range Extender is in registration mode.
Blue Triple Flash Registration is completed successfully.
Blue Steady On Good link to the telephone base.
Purple Steady On Weak link to the telephone base.
Red Steady On No link to the telephone base.
Blue Double Flash The Range Extender is in use with good link to
the telephone base.
Purple Double Flash The Range Extender is in use with weak link to
the telephone base.
1
20
3.4 Handset LCD Display Icons and Symbols
The screen display gives you information on the current status of the telephone.
ANS ON
1 2
On steadily when the home line is in use or there is an incoming home call.
1
2
On steadily when a mobile line is in use or there is an incoming mobile call.
1 2
There are BLUETOOTH® connected devices on the active devices list.
1 2
There are BLUETOOTH® disconnected devices on the active devices list.
1
2
On steadily when a wireless BLUETOOTH® headset is in use on the home line.
(ashing)
Battery is low; place handset in telephone base or charger to recharge.
Battery is charging.
The speakerphone is in use.
On steadily if the home and mobile ringers are turned off. Flashes if only one ringer is turned off.
New voicemail received from your telephone service provider.
ANS ON The answering system is turned on.
New message in the answering system.
NEW New call list - Missed and new calls.
MUTE Microphone is muted.
MUTE
NEW
1
2
1 2
1
2
21
GET TO KNOW YOUR PHONE
3.5 Menu Structure
In idle mode, press MENU to enter the menu. Refer to the following table for the menu structure.
Key Press
Main Menu PLAY MESSAGES ANSWERING SYS PHONEBOOK
Sub menu X new messages
Y old messages
Review answering sys
Under a selected answering sys
entry:
OUTGOING MSG
DELETE ALL OLD
RECORD MEMO
ANSWER ON/OFF
ANS SYS SETUP
Review phonebook list
Under a
phonebook entry:
HOME
MOBILE 1/2/3/4
CALL LOG Intercom Ringers Set date/time
HOME
MOBIEL 1/2/3/4
RINGER VOLUME
RINGER TONE
LOW BATTERY
NO COVERAGE
p
q
p
q
p
q
MENU
p
q
p
q
p
q
p
q
22
p
q
p
q
HS SETTINGS Info Services
DISPLAY ALERTS
TIME FORMAT
DATE FORMAT
AUTO ANSWER
REGISTER
RENAME HANDSET
AUTO ANSWER
REGISTER
RENAME HANDSET
KEY TONE
FLASH TIME
ANNC CALLER ID
POWER OUTAGE
RESET
C.W. On
C.W. Off
Chk Call Wait
Call Return
CF Imm. On
CF Imm. Off
Chk CF Imm.
23
GET TO KNOW YOUR PHONE
3.6 Text and Digit Entry Table
The following table shows you where each letter and punctuation character can be found. Respective character table will be used when corresponding menu language is selected. This will be helpful when storing a name in the contacts or renaming your handset.
In editing mode, a cursor is displayed to indicate the current text entry position. It is positioned at the right of the last character entered.
noteS
Once a character is selected, the cursor will move to the next position after a short pause.
You can move the cursor within the text by pressing / to amend the text entry.
Press to delete the last character.
Press and hold to delete the entire text string.
3.6.1 English Character Set
Key Alphanumeric Editing
(For phonebook name editing and renaming handset)
Key Press
1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th 11th
1 1 . - ‘ ( ) * # & / ,
2 A B C a b c 2
3 D E F d e f 3
4 G H I g h i 4
5 J K L j k l 5
6 M N O m n o 6
7 P Q R S p q r s 7
8 T U V t u v 8
9 W X Y Z w x y z 9
0
Space
0
*
#
1.
2.
3.
4.
24
4. BLUETOOTH
®
4.1 Introducing BLUETOOTH®
Your new telephone system with BLUETOOTH® wireless technology has the following
features:
• Pair up to 4 BLUETOOTH® enabled devices (mobile phones or headsets) with the telephone base.
• Connect a maximum of 2 mobile phones to make and receive mobile calls. Only one mobile phone can be active on a call at a time.
• Connect a BLUETOOTH® enabled headset for making and receiving home calls.
• Conference mobile and home calls.
• Make and receive calls using your mobile phone plan with your cordless system handsets.
4.2 Important Information
• After plugging in the telephone base, wait at least 20 seconds before connecting a BLUETOOTH® device. The screen shows Bluetooth system busy if you try to connect too soon.
• Refer to the user’s manual of your BLUETOOTH® enabled mobile phone or headset for more information about how that device uses BLUETOOTH® connectivity.
• BLUETOOTH® wireless technology operates within a short range (up to 9 metres) from the telephone base. Keep connected mobile phones and headsets within this range.
• If your mobile phone has poor reception in your home, the telephone cannot improve the reception. However, if you have a location in your house with better reception, you can leave your mobile phone in that location while you use the mobile line. In order for this to work, the mobile phone must be within 4.5 metres of the telephone base for optimal performance.
• Charge your mobile phone while it is connected to the telephone base. Your mobile phone’s battery discharges faster while it is connected to the telephone base via BLUETOOTH® wireless technology.
• Monitor your mobile phone’s usage, because minutes may be deducted from your mobile plan for the duration of all mobile calls, depending on the terms of your plan.
The BLUETOOTH® word mark and logos are owned by Bluetooth SIG, Inc.
Loading...
+ 71 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
