VTech DS6672 User Manual

Abridged user’s manual

Compatible with

Hearing Aid T-Coil

TIA-1083

DS6671-2/DS6671-3/DS6671-4/DS6672-4

DECT 6.0 cordless telephone with DECT 6.0 cordless headset and BLUETOOTH® wireless technology

Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech product news.

Telephones identied with this logo have reduced noise and

interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR®

label indicating it meets the latest energy efciency guidelines.

Introduction

To protect our environment and conserve natural resources, this Abridged user’s manual provides you with the basic installation and use instructions. A limited set of features are described in abbreviated form.

Please refer to the online Complete user’s manual for a full set of installation and operation instructions at www.vtechphones.com.

Before using this VTech product, please read Important safety instructions on page 13 of this user’s manual.

ECO mode

This power conserving technology reduces power consumption for optimal battery performance.

The ECO mode activates automatically during calls. When this mode is on, the handset displays ECO.

Home 0:00:01

ECO

10:15PM

12/18

ECO

Parts checklist

Battery Pack / Bloc-piles :

(2.4V Ni-MH)

WARNING / AVERTISSEMENT :

DO NOT BURN OR PUNCTURE BATTERIES.

NE PAS INCINÉRER OU PERCER LES PILES.

Made in China / Fabriqué en chine

THIS SIDE UP / CE CÔTÉ VERS LE HAUT

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

Ear hooks (3) Additional

Ear pad

earbuds (3)

Telephone line cord

Cordless headset with an earbud attached

Head band

Telephone base power adapter

Handset charger and charger adapter

(1 for DS6671-3) (2 for DS6671- 4/DS6672-4)

Telephone base

Handset battery compartment covers

(1 for DS6671-2) (2 for DS6671-3) (3 for DS6671- 4/DS6672-4)

Abridged user’s manual

Telephone base and charger installation

Install the telephone base and charger as shown below.

Handsets

(1 for DS6671-2) (2 for DS6671-3) (3 for DS6671- 4/ DS6672- 4)

Handset batteries

(1 for DS6671-2) (2 for DS6671-3) (3 for DS6671- 4/DS6672-4)

Quick start guide

Click!

Plug!

DSL lter

Click!

Plug!

Even if you do not subscribe to any conventional telephone service, you

• can still use the cell lines alone without plugging in a telephone line cord.

Use only the power adapters and batteries supplied with this product.

• To order a replacement, visit our website at www.vtechphones.com or call 1 (800) 595-9511. In Canada, go to www.vtechcanada.com or call 1 (800) 267-7377.

If you subscribe to telephone service from a cable company or a

• VoIP service provider, contact your cable/VoIP service provider for more information.

Battery installation and charging

Battery Pack / Bloc-piles :

(2.4V Ni-MH)

WARNING / AVERTISSEMENT :

DO NOT BURN OR PUNCTURE BATTERIES.

NE PAS INCINÉRER OU PERCER LES PILES.

Made in China / Fabriqué en chine

THIS SIDE UP / CE CÔTÉ VERS LE HAUT

CR1232

Battery Pack / Bloc-piles :

(2.4V Ni-MH)

WARNING / AVERTISSEMENT :

DO NOT BURN OR PUNCTURE BATTERIES.

NE PAS INCINÉRER OU PERCER LES PILES.

Made in China / Fabriqué en chine

THIS SIDE UP / CE CÔTÉ VERS LE HAUT

CR1232

Battery Pack / Bloc-piles :

(2.4V Ni-MH)

WARNING / AVERTISSEMENT :

DO NOT BURN OR PUNCTURE BATTERIES.

NE PAS INCINÉRER OU PERCER LES PILES.

Made in China / Fabriqué en chine

THIS SIDE UP / CE CÔTÉ VERS LE HAUT

CR1232

Install the battery as shown below.

Click!

Plug!

Light on!

Charge for at least 30 minutes before initial settings.

Charge for 12 hours before initial use.

IMPORTANT:

Check for a dial tone by pressing /HOME, CELL 1 or CELL 2. If you hear a dial tone, the installation is successful.

If you do not hear a dial tone:

Make sure the installation procedures described above are properly done.

• It may be a wiring problem. If you have changed your telephone service to

• digital service from a cable company or a VoIP service provider, the telephone line may need to be rewired to allow all existing telephone jacks to work. Contact your cable/VoIP service provider for more information.

Headset charging

Light on!

Charge for 3 hours before initial use.

Telephone base overview

FIND HANDSET

IN USE light

CELL 1

Handset overview

CHARGE light

CELL 2

Message window

/PLAY/STOP

/SKIP /REPEAT

X/DELETE

/VOL /VOL

ANS ON

PUSH TO TALK

REDIAL/PAUSE

CELL 1

/HOME/FLASH

Dialing keys

/auA

Headset overview

On/Off

VOLUME/ /

MENU/SELECT

CELL 2

OFF/CANCEL

VOLUME/ /CID

HOLD

MUTE/DELETE

Earpiece

Volume/+/-

Rotating clip

Microphone

MUTE/FLASH

RESET recessed button

Headset attachments

Earbud To remove the earbud from the headset earpiece:

Hold both sides of the earbud and then pull the earbud until it separates from the earpiece.

To attach the earbud to the headset earpiece:

Choose an appropriate earbud.

1. Press the earbud towards the earpiece until it clicks into place. Move the earbud

2. around so that the protruding bump on the earbud is pointing towards your mouth when placed on your ear. The protruding bump on the earbud holds the headset securely in your ear.

Protruding bump

Ear hook

To attach the ear hook to the headset:

Remove any headset attachment (earbud excluded) connected to the headset.

1. Insert the ear hook [A] into the rotating clip [B] on the headset until it clicks

2. into place.

[A]

Hook the headset on your right ear. Adjust the angle of the headset until the

[B]

microphone is pointing towards your mouth. Firmly grip the earpiece with one hand whenever adjusting the headset microphone up or down.

To adjust the headset to wear on your left ear:

1. Hold the headset with one hand.

2. Twist the ear hook 180 o clockwise.

Lift the ear hook upward.

3. Push the ear hook downward. 4. Hook the headset on your left ear. Adjust the angle of the headset until the microphone is pointing towards your mouth
