Page 1
PRO GT
PRO GT
TRIPOD KIT
™
Page 2
pro gt
pro gt
TRIPOD KIT
™
The sturdy anodized legs of the Pro GT
TM
tripod combine with a
rugged 3-way pan head to deliver smooth, solid support for your
optics.
3-Way Pan Head
Center Column
Leg Lever
Lock
Balance Hook
Quick-Release
Plate
Center Column
Height Adjustment
Knob
Padded
Leg Wraps
Anodized
Aluminum
Legs
Rubber
Foot
- 2 -
- 3 -
Page 3
pro gt
pro gt
TRIPOD KIT
™
BASIC ADJUSTMENTS
Adjusting the Pan Head
The Pro GT features a 3-way pan head that allows you to quickly
follow the action and easily adjust your viewing angle. For camera
use, this head allows you to choose
between horizontal and vertical
plate alignments.
Pan and Tilt Action
You can control all of the pan and
tilt action with just one hand. To
make any horizontal or vertical
adjustments, twist the handle
counter-clockwise to free the pan
head’s movement. When in desired
position, twist handle clockwise to
lock.
Plate Angle
Lock
Control pan and tilt action with the handle.
Attaching Optics to the Tripod
1. Flip the plate lever
lock outward to the free
position and remove the
Quick-Release
Plate
Tripod Mount
Bolt
Plate Lever
Lock
quick-release plate.
2. Attach the plate to your
optic or camera. Be sure
to tighten the tripod mount
bolt from the bottom side
of the plate and fl ip the D
ring so it lies fl at.
3. Place the quick-release
Flip the plate lever to lock/unlock plate.
plate back into the plate
holder. Flip the plate lever fully back to the lock position so the
quick-release plate rests securely in the holder.
Caution
To prevent unnecessary damage to your optics, take a few seconds to
remove your optic from the tripod before you move to a new location.
Spotting scopes and other optics may become damaged if carried
while attached to the tripod. The quick-release plate makes this
easy—and quick!
TIP: Purchase additional quick-release plates for your optics so it is
easy for you to switch equipment.
- 4 -
- 5 -
Page 4
pro gt
pro gt
TRIPOD KIT
™
Adjusting the Tripod Legs
The Pro GT features sturdy anodized legs for reliable performance.
Padded upper sections provide a comfortable grip and carry.
Center Column
Loosen the center column
height adjustment knob to
change the relative height
of the tripod head. To help
stabilize the tripod in windy
conditions, hang a weight
from the balance hook. (Page
3)
Leg Length
Each tripod leg extends to a maximum of three sections. To adjust
the length of a leg section, fl ip the leg lever up to unlock. Slide the
leg section out to the desired length
and fl ip the leg lever back down to lock
in place.
Flip lever to
lock/unlock.
Center Column
Height
Adjustment
Knob
Padded
Leg Wrap
Leg Lever
Lock
THE VIP WARRANTY
We build products based on our commitment to your absolute
satisfaction. That’s why Vortex tripods are unconditionally guaranteed
and we make this Very Important Promise to you—a Very Important
Person.
Rest assured that in the event your tripod becomes damaged or is
defective, Vortex Optics will repair or replace it at no charge to you.
If we cannot repair your tripod, we will replace it with a product in
perfect working order and equal or better physical condition. Call
Vortex Optics at 800-426-0048 for prompt, professional, and friendly
service.
Vortex Optics
2120 West Greenview Drive
Middleton, WI 53562
service@vortexoptics.com
Visit www.vortexoptics.com for more information. Canadian
customers may visit www.vortexcanada.net for customer service
information.
Note: The VIP Warranty does not cover loss, theft, deliberate
damage, or cosmetic damage that does not hinder the
performance of the product.
Unlimited
Unconditional
Lifetime Warrant y
- 6 -
- 7 -
Page 5
THE FORCE OF OPTICS
®
#PRO-2-14A
