PRODUCT SPECIFICATIONS
Type or Model __________________________________ Qty ____________
VOLT® Low Voltage Landscape Lighting
Conehead Path & Area Lights – 310 Series
Product Description
The Conehead Path & Area Light is a high-quality outdoor light
that is great for illuminating smaller areas. Featuring a tall
stem and a simple, yet attractive hat; this luminaire projects
a beam of illumination with a diameter of 12 ft.
Corrosion-resistant internal components and an easy-tochange bulb socket-and-enclosure ensure years of optimal
performance – carries an lifetime warranty.
Product Dimensions
7”
2 3/4”
22 1/4”
Features & Benets
◗ Solid Brass or Copper Construction
◗ Pre-aged nish; with a natural patina that does not
corrode.
◗ Stem is 1-inch thick and includes extra-long (1-inch) strip
resistant threading for greater stability
◗ Beryllium copper socket – more corrosion resistant than
copper
◗ Silicone plug at lead wire exit prevents ground moisture
and insects from entering luminaire through the stem
◗ Machine threaded body screws tight onto an O-ring for a
moisture tight design
Specications
◗ Construction: Cast Brass or Copper
◗ Finish: Bronze, Powder Coated Black, or Raw Copper
◗ Lead Wire: 48” (standard) or 25’ (optional) 16AWG, SPT-2
◗ Mounting: 10” Hammer® Stake with cutout for wire exit
◗ Glass or Lens: Clear protective polycarbonate lens
◗ Light Source (Sold Separately): Bi-Pin (LED or Halogen)
◗ Maximum Lamp Rating: 20 Watts
◗ Operating Voltage: 12V AC
◗ Powered by: VOLT’s Low Voltage Transformer
Warranty
Lifetime Warranty
Certications
Max 20 Watts
File #E466348
LISTED
Max 20 Watts
File #E466348
