Vizio VW26L User Manual
VIZIO VW26L HDTV10F User Manual
Dear VIZIO Customer,
Congratulations on your new VIZIO VW26L High
Definition LCD Television purchase. Thank you
for your support. For maximum benefit of your set,
please read these instructions before making any
adjustments, and retain them for future reference.
We hope you will experience many years of
enjoyment from your new VIZIO VW26L High
Definition Television.
For assistance, please call 714-668-0588 or email us at
techsupport@vinc.com.
To purchase or inquire about accessories and
installation services for your VIZIO LCD HDTV,
please visit our website at
www.VIZIO.com or
call toll free at 888-VIZIOCE (888-849-4623).
We recommend you register your VIZIO VW26L
HDTV10F either at our website
www.VIZIO.com
or fill in your registration card and mail it in. For
peace of mind and to protect your investment
beyond the standard warranty, VIZIO offers onsite extended warranty service plans. These
plans give additional coverage during the
standard warranty period. Visit our website or call
us to purchase a plan.
Write down the serial number located on the back
of your VW26L.
__ __ __ __ __ __ __ __ __ __ __ __ __ __
Purchase Date _____________________
VIZIO is a registered trademark of V, Inc.
HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Version 2/6/2007 1
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
THIS PRODUCT HAS BEEN DESIGNED AND TESTED FOR COMPLIANCE WITH REGULATORY SAFETY CERTIFICATIONS
This product is designed and manufactured to operate within defined design limits, and misuse may result in electric
shock or fire. To prevent the product from being damaged, the following rules should be observed for the installation,
use and maintenance of the product. Read the following safety instructions before operating the display. Keep these
instructions in a safe place for future reference.
• To avoid the risk of electric shock or component damage, switch off the power before connecting other components to the VW26L LCD
HDTV.
• Unplug the power cord before cleaning the VW26L LCD HDTV. A damp cloth is sufficient for cleaning the VW26L LCD HDTV. Do not
use a liquid or a spray cleaner for cleaning the product. Do not use abrasive cleaners.
• Always use the accessories recommended by the manufacturer to insure compatibility.
• When moving the VW26L LCD HDTV from an area of low temperature to an area of high temperature, condensation may form on the
housing. Do not turn on the VW26L LCD HDTV immediately after this to avoid causing fire, electric shock or component damage.
• Do not place the VW26L LCD HDTV on an unstable cart, stand, or table. If the VW26L LCD HDTV falls, it can injure a person and
cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the VW26L LCD
HDTV.
• A distance of at least 3 feet should be maintained between the VW26L LCD HDTV and any heat source, i.e. radiator, heater, oven,
amplifier etc. Do not install the product close to smoke. Operating the product close to smoke or moisture may cause fire or electric
shock.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of the VW26L LCD
HDTV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the VW26L LCD HDTV in a
bookcase or cabinet unless proper ventilation is provided.
• Never push any object into the slot on the VW26L LCD HDTV cabinet. Do not place any objects on the top of the product. It could short
circuit parts causing a fire or electric shock. Never spill liquids on the VW26L LCD HDTV.
• The VW26L LCD HDTV should be operated only from the type of power source indicated on the label. If you are not sure of the type of
power supplied to your home, consult your dealer or local power company.
• The power cable must be replaced when using different voltage from that specified in the User Manual. For more information, contact
your dealer.
• The VW26L LCD HDTV is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only
into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install
the correct outlet, or use an adapter to ground the appliance safely.
Do not defeat the safety purpose of the
grounded plug.
• Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
• The wall socket shall be installed near the equipment and shall be easily accessible.
• Only the marked power source can be used for the product. Any power source other than the specified one may cause fire or electric
shock.
• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.
• Unplug the unit during a lightening storm or when it will not be used for long period of time. This will protect the VW26L LCD HDTV
from damage due to power surges.
• Do not attempt to repair or service the product yourself. Opening or removing the back cover may expose you to high voltages, the risk
of electric shock, and other hazards. If repair is required, please contact your dealer and refer all servicing to qualified service
personnel.
• Keep the product away from moisture. Do not expose this appliance to rain or moisture. If water penetrates into the product, unplug
the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock.
• Do not use the product if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your
dealer immediately. Do not try to repair the product yourself.
• Avoid using dropped or damaged appliances. If the product is dropped and the housing is damaged, the internal components may
function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of the product may cause
fire or electric shock.
• Do not install the product in an area with heavy dust or high humidity. Operating the product in environments with heavy dust or high
humidity may cause fire or electric shock.
• Follow instructions for moving the product. Ensure that the power connector and any other cables are unplugged before moving the
product.
• Hold the power connector when removing the power cable. Pulling the power cable itself may damage the wires inside the cable and
cause fire or electric shock. When the product will not be used for an extended period of time, unplug the power connector.
• To avoid risk of electric shock, do not touch the connector with wet hands.
• Insert batteries in accordance with instructions. Incorrect polarities may cause damage and leakage of the batteries, operator injury
and contamination the remote controller.
• If any of the following occurs please contact the dealer:
o The power connector fails or frays.
o Liquid sprays or any object drops into the VW26L LCD HDTV.
o The Display is exposed to rain or other moisture.
o The Display is dropped or damaged in any way.
o The performance of the Display changes substantially.
Version 2/6/2007 2
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during a lightning storm or when it is left unattended or unused for long
periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or where it could fall into such power
lines or circuits.
Remember, the screen of the coaxial cable is intended to be connected to earth in the building
installation.
Version 2/6/2007 3
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
Opening the Package
Your VIZIO VW26L HDTV10F and its accompanying accessories are carefully packed in a cardboard
carton that has been designed to protect it from transportation damage. Now you have opened the carton
check that the VW26L HDTV10F is in good condition and that all of the accessories are included.
The screen can easily be scratched or broken so please handle the product gently and never place the
HDTV with the glass facing downwards on a surface without protective padding.
IMPORTANT: Save the carton and packing material for future shipping.
Package Contents
VIZIO VW26L HDTV10F
VIZIO Remote Control
Power Cord
VIZIO Bezel and Screen Cleaning Cloth
This User Manual
Quick Setup Guide
Registration Card
VIZIO Warranty and Repair Information
VIP Services Brochure
Additional Certified Accessories for the VIZIO
VW26L HDTV10F are sold separately
Wall Mounts
High Definition Cables
Extra or replacement Remote
VIZIO also offers Installation Services and Extended Warranty Services for your VIZIO VW26L HDTV10F
To purchase or inquire about additional accessories and services for your VIZIO product, visit our web
site at www.VIZIO.com
Version 2/6/2007 4
or call us toll free at 888-VIZIOCE (888-849-4623)
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
Installation Preparation
Please read this user manual carefully before installing your VIZIO HDTV.
The power consumption of the TV is about 105W, please use the power cord designated for TV. When
an extension cord is required, use one with the correct power rating. The cord must be grounded and the
grounding feature must not be defeated.
The TV should be installed on a flat surface to avoid tipping. For proper ventilation, you must allow space
between the back of the TV and the wall. If you would like to mount your TV on the wall, please see
below ‘Preparing Your LCD HDTV for Wall Mounting’ for additional information. Avoid installing the TV in
places with high humidity, dust or smoke so as not to shorten the service life of the electronic components.
Install the TV in landscape orientation; any 90˚ clockwise or counter-clockwise installation may induce
poor ventilation and excessive component damage.
VIZIO offers professional installation services. Please contact VIZIO for more information on these
services at 888-VIZIOCE (888-849-4623) or www.VIZIO.com
.
Version 2/6/2007 5
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
Table of Contents
Chapter 1 Basic Controls and Connections.................................................................. 8
1.1 Front Panel..........................................................................................................................................................8
1.2 Right Side Panel Controls ...................................................................................................................................8
1.3 Left Side Connections .........................................................................................................................................8
1.4 Rear Panel Connections .....................................................................................................................................9
1.5 VIZIO Remote Control.......................................................................................................................................10
1.5.1 Insertion of Batteries in the Remote Control ..............................................................................................12
1.5.2 Remote Control Range ..............................................................................................................................12
1.5.3 VIZIO Remote Control Precautions ...........................................................................................................12
Chapter 2 Connecting Equipment .................................................................................. 13
2.1 Which Video Connection Should I Use?............................................................................................................13
2.2 Coaxial (RF) ......................................................................................................................................................14
2.2.1 Using Your Antenna or Digital Cable for DTV............................................................................................14
2.2.2 Using Your Antenna or Cable for TV .........................................................................................................15
2.2.3 Using the Antenna or Cable through your VCR .........................................................................................15
2.3 Connecting Your HDTV Set-Top Box ................................................................................................................16
2.3.1 Using HDMI ...............................................................................................................................................16
2.3.2 Using Component Video............................................................................................................................18
2.4 Connecting Your Basic Set-Top Box .................................................................................................................19
2.4.1 Using Composite Video .............................................................................................................................19
2.4.2 Using Coax (RF)........................................................................................................................................19
2.5 Connecting Your DVD Player............................................................................................................................20
2.5.1 Using HDMI ...............................................................................................................................................20
2.5.2 Using Component Video............................................................................................................................21
2.5.3 Using S-Video (AV2)..................................................................................................................................22
2.5.4 Using Composite (AV) Video .....................................................................................................................22
2.6 Connecting Your VCR or Video Camera ...........................................................................................................23
2.7 Connecting Connecting a PC Computer ...........................................................................................................23
2.7.1 Preset PC Resolutions...............................................................................................................................24
2.7.2 Using a PC ................................................................................................................................................24
Chapter 3 Setting Up to Watch Television...................................................................25
3.1 Basic LCD HDTV Start Up ................................................................................................................................25
3.2 Watching a TV Program ....................................................................................................................................27
3.3 Adjusting Basic HDTV Settings .........................................................................................................................27
3.4 Program Information..........................................................................................................................................28
3.5 Information on HDTV Status .............................................................................................................................28
Chapter 4 Advanced Adjustment of HDTV...................................................................29
4.1 Using the On Screen Display (OSD) .................................................................................................................29
4.2 DTV / TV Input Picture Adjustment....................................................................................................................30
4.2.1 Picture Mode .............................................................................................................................................30
4.2.2 Backlight ....................................................................................................................................................30
4.2.3 Contrast .....................................................................................................................................................31
4.2.4 Brightness..................................................................................................................................................31
4.2.5 Sharpness .................................................................................................................................................31
4.2.6 Color ..........................................................................................................................................................31
4.2.7 Tint.............................................................................................................................................................32
4.2.8 Color Temperature.....................................................................................................................................32
4.2.9 Advanced Setting ......................................................................................................................................33
4.3 DTV / TV Input Audio Adjustment......................................................................................................................34
4.3.1 Volume ......................................................................................................................................................34
4.3.2 Treble ........................................................................................................................................................34
4.3.3 Bass...........................................................................................................................................................34
4.3.4 Balance......................................................................................................................................................35
4.3.5 Surround....................................................................................................................................................35
4.4 TV Setup ...........................................................................................................................................................35
4.4.1 TV Input .....................................................................................................................................................35
4.4.2 Auto Search...............................................................................................................................................35
4.4.3 Skip Channel .............................................................................................................................................36
4.4.4 Time Zone .................................................................................................................................................36
Version 2/6/2007 6
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
4.4.5 Daylight Saving..........................................................................................................................................36
4.5 DTV / TV Input Parental Control........................................................................................................................36
4.5.1 Channel Block ...........................................................................................................................................36
4.5.2 TV Rating...................................................................................................................................................38
4.5.3 Movie Rating..............................................................................................................................................38
4.5.4 Blocked Unrated Programming..................................................................................................................39
4.5.5 Change the Password ...............................................................................................................................39
4.6 Input Setup........................................................................................................................................................40
4.6.1 Language...................................................................................................................................................40
4.6.2 Sleep Timer ...............................................................................................................................................40
4.6.3 Wide Format ..............................................................................................................................................40
4.6.4 Analog Closed Caption ..............................................................................................................................41
4.6.5 Digital Closed Caption ...............................................................................................................................41
4.6.6 Digital Closed Caption Style ......................................................................................................................41
4.6.7 Reset All Settings ......................................................................................................................................41
4.7 HDMI Input Picture Adjustment .........................................................................................................................42
4.8 HDMI Input Audio Adjustment ...........................................................................................................................42
4.9 HDMI Input Setup..............................................................................................................................................42
4.10 Video Input Picture Adjustment .......................................................................................................................43
4.11 Video Input Audio Adjustment .........................................................................................................................43
4.12 Video Input Setup............................................................................................................................................43
4.13 Video Input Parental Control ...........................................................................................................................44
4.14 PC Input Picture Adjustment ...........................................................................................................................44
4.14.1 Auto Adjust ..............................................................................................................................................44
4.14.2 Backlight ..................................................................................................................................................44
4.14.3 Contrast ...................................................................................................................................................44
4.14.4 Brightness................................................................................................................................................45
4.14.5 Color Temperature...................................................................................................................................45
4.14.6 H-SIZE.....................................................................................................................................................46
4.14.7 H. Position ...............................................................................................................................................46
4.14.8 V. Position ...............................................................................................................................................46
4.14.9 Fine Tune ................................................................................................................................................46
4.15 PC Input Audio Adjustment .............................................................................................................................46
4.16 PC Input Setup................................................................................................................................................46
4.17 Understanding Viewing Modes........................................................................................................................47
4.17.1 Setting the Sleep Timer ...........................................................................................................................48
4.18 Using a Cable or Satellite Remote ..................................................................................................................48
Chapter 5 Maintenance and Troubleshooting............................................................. 48
5.1 Maintenance......................................................................................................................................................48
5.2 Troubleshooting Guide ......................................................................................................................................49
5.3 Telephone & Technical Support ........................................................................................................................50
5.4 Compliance .......................................................................................................................................................51
5.5 FCC Class B Radio Interference Statement......................................................................................................51
Chapter 6 Miscellaneous Information ........................................................................... 52
6.1 Specifications ....................................................................................................................................................52
6.2 Glossary – Standard Definitions ........................................................................................................................53
6.3 Index .................................................................................................................................................................54
Version 2/6/2007 7
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
Chapter 1 Basic Controls and Connections
1.1 Front Panel
Remote Control Sensor – This is the window through which
all of the remote control signals pass to the sensor. Point the
remote control directly at this window for the best response to
the remote signal.
Power ‘HDTV’ light – When plugged into your power outlet,
the HDTV name on the stand will glow red when the HDTV is
powered off.
1.2 Right Side Panel Controls
Power ( ) – Switch the VW26L on by pressing the button
once. Press the button again to the VW26L off.
MENU – This button activates the On Screen Display (OSD). If
a sub-menu is active, pressing this button will return to the
previous menu level.
CH +/- (▲/▼) – Use these buttons to step up or down the TV
channels. While the OSD is active, these buttons function as
up and down controls in the OSD menus.
VOL +/- (◄/►) – Use these buttons to increase or decrease to
the speaker volume. While the OSD is active, these buttons
function as left and right controls in the OSD menus.
INPUT – Repeated pressing of this buttons steps through the
input sources in the following sequence: TV, AV1, AV2 (SVideo or Video), Component 1, Component 2, HDMI 1, HDMI 2,
and RGB. Once you have stepped through the entire sequence,
you will return to the beginning.
Additionally, when the OSD is active, this button confirms the
menu function to be adjusted. When the OSD is not active,
pressing this button will display the current input mode.
1.3 Left Side Connections
1. AV2 In – Connect the secondary source for composite
video devices, such as a VCR or video game. Use the
white and red connectors to connect the external audio
from the same source. The orange color band on the
side of the TV indicates this connection. The S-Video, if
connected, will take priority over AV1 RCA connector.
2. Headphone – Connect your headphone here.
3. SERVICE – This custom communication port is for factory
service only.
Version 2/6/2007 8
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
1.4 Rear Panel Connections
1 2
1. AC IN – Plug-in the supplied AC Power Cord here.
2. HDMI 1 – Connect the primary source for digital video such as a DVD multimedia player or
set top box through this all digital connector. The white color band on the rear of the TV
indicates this connection. Your VIZIO Certified HDMI cables are available for purchase from
www.VIZIO.com
3. HDMI 2 – Connect the secondary source for digital video such as a DVD multimedia player or
set top box through this all digital connector. The white color band on the rear of the TV
indicates this connection. For users who want to connect to a DVI enabled device, use a
DVI-HDMI cable and connect the Analog Audio output of the device to the L+R AUDIO here. .
Your VIZIO Certified HDMI and HDMI-DVI cables are available for purchase from
www.VIZIO.com
4. RGB PC – Connect the video and audio from a computer here. The blue color band on the
rear of the TV indicates this connection.
5. COMPONENT (YPb/CbPr/Cr with Audio L/R) – Connect the primary source for component
video devices such as a DVD Player or set top box here. From left to right, use green for Y,
blue for Pb (or Cb), red for Pr (or Cr), white for left audio and red for right audio inputs. The
green color band on the rear of the TV indicates this connection.
6. DTV – Connect to an antenna or digital cable (out-of-the-wall, not from Cable Box) for Digital
TV.*
7. AV1 In – Connect the primary source for composite video devices, such as a VCR or video
game. Use the white and red connectors to connect the external audio from the same source.
The yellow color band on the rear of the TV indicates this connection.
* For digital TV stations in your area visit www.antennaweb.org
or by calling 888-VIZIOCE (888-849-4623).
or by calling 888-VIZIOCE (888-849-4623).
3
4
.
5
7
6
Version 2/6/2007 9
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
1.5 VIZIO Remote Control
Remote LED – Blinks when the remote operates.
POWER – Press this button to turn the TV on from the Standby mode.
Press it again to return to the Standby mode.
Number Button Pad – Use these buttons to select a channel or enter a
password.
INPUT – This button allows the user to cycle through the inputs.
- (Dash) – When selecting a digital channel directly use this button for the
separation of main and sub-channels. For example, channel 28-2 would
be selected by the button sequence 2 8 ENTER 2.
CH (+ or -) – These buttons change the channels up or down.
LAST – This button recalls the previously viewed channel.
MUTE – This button turns the sound on and off. VOL (+ or -) – These
buttons turn the volume up or down.
MENU – Use this button for the On-Screen Display (OSD) menus.
INFO – This button displays the image and system information display.
GUIDE – This button displays program information. Note: this button is
only functional for DTV.
EXIT – This button exits the On-Screen Display (OSD) menus.
- These buttons navigate the On-Screen Display (OSD).
OK – Use this button to select your chosen option in On-Screen Display
(OSD) menus.
NOTE: Your Remote Control may
look like this.
Version 2/6/2007 10
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
WIDE – This button cycles through the available screen formats. The options for SD (Standard Definition
4:3) are Normal and Panoramic. . The options for HD (High Definition 16:9) and RGB PC are 4:3 and
16:9.
SLEEP – This button allows the user to select the sleep options by
adjusting the timer for 30, 60, 90 or 120 minutes.
MTS – This button will select the MTS options of Stereo, SAP or Mono in
TV mode and alternate audio channels, where available, in DTV mode.
CC – This button will select the Closed Caption mode. The options are
OFF, CC1, CC2, CC3 or CC4.
TV – Press this button to select TV.
AV – Repeated pressing of this button will switch between AV1 (Composite,
yellow RCA) and AV2 (Composite, yellow RCA and S-Video) inputs.
COMPONENT – Press this button to select the Component (YPbPr) input.
HDMI – Repeated pressing of this button will switch between HDMI 1 and
HDMI 2 inputs.
ZOOM (- and +) – These buttons have no effect because this function is
not available on this HDTV.
FREEZE – This button has no effect because this function is not available
on this HDTV.
RGB – This button selects an RGB Analog component such as a PC.
PIP – This button has no effect because this function is not available on
this HDTV.
PIP CH (- and +) – These buttons have no effect because this function is
not available on this HDTV.
AUDIO – This button has no effect because this function is not available on
this HDTV.
PIP INPUT – This button has no effect because this function is not
available on this HDTV.
PIP SIZE – This button has no effect because this function is not available
on this HDTV.
MODE – Use this button to change the picture mode from Custom,
Standard, Movie and Game.
SWAP – This button has no effect because this function is not available on
this HDTV.
Version 2/6/2007 11
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
1.5.1 Insertion of Batteries in the Remote Control
Insert two AA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the
batteries with the (+) and (-) symbols inside the battery compartment. Re-attach the battery cover.
Precautionary Tips for Inserting the Batteries:
Only use the specified AA batteries.
Do not mix new and old batteries. This may result in cracking or leakage
that may pose a fire risk or lead to personal injury.
Inserting the batteries incorrectly may also result in cracking or leakage
that may pose a fire risk or lead to personal injury.
Dispose of the batteries in accordance with local laws and regulations.
Keep the batteries away form children and pets.
1.5.2 Remote Control Range
Point the remote control at the remote control sensor to transmit the commands.
Do not place any obstacles between the remote control and the receiver window.
The effective range of the remote control is approximately 26 feet (8 meters) from the front of the receiver
window, about 13 feet (4 meters) when 30° to the left and right, 20° up and down.
1.5.3 VIZIO Remote Control Precautions
The remote control should be kept dry and away from heat sources. Avoid humidity.
If the TV responds erratically to the remote control or does respond at all, check the batteries. If the
batteries are low or exhausted, replace them with fresh batteries.
When not using the remote control for a long period of time, remove the batteries.
Do not take the batteries apart, heat them, or throw them into a fire.
Do not subject the remote control to undue physical stress, such as striking or dropping it.
Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp cloth.
Version 2/6/2007 12
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
Chapter 2 Connecting Equipment
2.1 Which Video Connection Should I Use?
The VIZIO VW26L has six different ways to connect your video equipment from a basic connection to the
most advanced for digital displays.
Rear
Connection
Quality (type)
Connector
Panel
Color
Codes
Description
Best
(digital)
Best
(digital)
- - - - - - - - - - - Good
(analog)
Best
(analog)
Better
(analog)
White
Black
Blue
Green
HDMI (High-Definition Multimedia Interface) - It is
the first and only industry-supported, uncompressed,
all-digital audio/video interface. HDMI provides an
interface between any audio/video source, such as a
set-top box, DVD player, or A/V receiver and an
audio and/or video monitor, such as a digital
television (DTV), over a single cable.
DTV Coaxial RF. When used for MPEG2 encoded
bit streams from ATSC broadcast programming, this
input takes advantage of the High Definition content.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
TV Coaxial RF. This is the connection for standard
NTSC TV using antenna or cable.
RGB PC (VGA) – This video input has separate red,
green and blue color components. The signal
carries horizontal and vertical sync information on
the green signal. This is most commonly used for
PC input.
Component - The video signal is separated into
three signals, one containing the black-and-white
information and the other two containing the color
information. This enhancement over S-Video takes
advantage of the superior picture provided by
progressive scan DVD players and HDTV formats.
S-Video (AV2) - The video signal is separated into
two signals, one containing the black-and-white
information and the other containing the color
information. Separating the color in this way avoids
‘cross color’ effects where closely spaced black and
white lines are erroneously displayed in color. It also
enables text to be displayed more sharply.
Composite (AV1/2) - The complete video signal is
carried through this single pin connector. This is the
most commonly used video connection.
Good
(analog)
Good
(analog)
Red
Yellow
and
Orange
Note: For more info refer to the Quick Start Guide
Version 2/6/2007 13
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
2.2 Coaxial (RF)
2.2.1 Using Your Antenna or Digital Cable for DTV
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or digital cable (outof-the-wall, not from the Cable Box) to the DTV/TV CABLE/ANTENNA
connector.
3. Turn on the power to the HDTV.
4. Select DTV using the INPUT button on the remote or side of the HDTV, or
directly by pressing the TV button on the Remote Control.
Note:
a) Not all digital TV broadcasts are High Definition (HD). Refer to the
program guides, or consult your cable, satellite or TV station operator.
b) Digital broadcasts are not available in all areas. Refer to
www.antennaweb.org
c) Make sure the antenna and coaxial cable are correctly grounded.
d) For Professional antenna installation contact us at www.VIZIO.com
call 1-888-VIZIOCE (1-888-849-4623).
for detailed information.
or
Version 2/6/2007 14
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
2.2.2 Using Your Antenna or Cable for TV
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or cable (out-of-thewall, not from the Cable Box) to the DTV/TV CABLE/ANTENNA connector
at the rear of the HDTV
3. Turn on the power to the HDTV.
4. Select TV using the INPUT button on the remote or side of the HDTV, or
directly by pressing the TV button on the Remote Control.
2.2.3 Using the Antenna or Cable through your VCR
1. Turn off the power to the HDTV and VCR.
2. Connect the “Output to TV”, “RF Out” or “Antenna Out” connector on the
rear of your VCR to the DTV/TV CABLE/ANTENNA connector at the rear of
the HDTV.
3. Turn on the power to the HDTV and VCR.
4. Select TV using the INPUT button on the remote or side of the HDTV, or
directly by pressing the TV button on the Remote Control.
Note: If you have an off-air antenna or cable TV, connect
it to the “Antenna In” connector on the rear of your VCR.
Version 2/6/2007 15
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
p
2.3 Connecting Your HDTV Set-Top Box
2.3.1 Using HDMI
HDTV Set-Top Boxes that have a HDMI digital interface should be connected to the HDMI input of the
LCD HDTV for optimal results.
Connecting your HDTV Set-Top Box (Best):
Note: To maintain the display quality, use a VIZIO certified HDMI cable that is 10 meters.
See www.VIZIO.com or call 1-888-VIZIOCE (1-888-849-4623) for details.
1. Turn off the power to the HDTV and HDTV Set-Top Box.
2. Connect a HDMI cable to the HDMI output of your HDTV Set-Top Box and the other end to
the HDMI 1 Input (white color area) at the rear of the HDTV.
3. Turn on the power to the HDTV and HDTV Set-Top Box.
4. Select HDMI 1 using the INPUT button on the remote or side of the HDTV, or directly by
pressing the HDMI button on the Remote Control.
Note:
a) The HDMI 1 and HDMI 2 inputs on the HDTV supports High-bandwidth Digital
Content Protection (HDCP). HDCP encrypts the transmission between the video
source and the digital display for added security and protection.
b) If you are already using the HDMI 1 input for other equipment you can use the
HDMI 2 input.
c) Refer to your HDTV Set-Top Box user manual for more information about the
video output requirements of the product or consult your cable or satellite
o
erator.
Version 2/6/2007 16
www.VIZIO.com
VIZIO VW26L HDTV10F User Manual
For HDTV Set-Top Boxes with DVI:
1. Turn off the power to the HDTV and HDTV Set-Top Box.
2. Using a HDMI-DVI cable, connect the DVI end to your HDTV Set-Top Box and the HDMI end
to the HDMI2 Input (white color area) at the rear of the HDTV.
3. Using an audio cable (white and red connectors), connect the cable to the audio output
connectors associated with the DVI output on your HDTV Set-Top Box and connect the other
end to the audio connectors associated with the HDMI 2 input (white area) at the rear of the
HDTV.
4. Turn on the power to the HDTV and HDTV Set-Top Box.
5. Select HDMI 2 using the INPUT button on the remote or side of the HDTV, or directly by
pressing the HDMI button on the Remote Control.
Note: The HDMI Input is for HD Video and will only support 640x480, 800x600, 1024x768 and 1366x768
at 60Hz from a PC. Use the RGB PC input for a greater selection of PC formats.
Note:
a) The HDMI input on the HDTV supports High-bandwidth Digital Content Protection
(HDCP). HDCP encrypts the transmission between the video source and the
digital display for added security and protection.
b) Refer to your HDTV Set-Top Box user manual for more information about the
video output requirements of the product or consult your cable or satellite operator.
Version 2/6/2007 17
www.VIZIO.com
Loading...
