Vizio VL260M User Manual

VIZIO VL260M User Manual

Dear VIZIO Customer,

Congratulations on your new VIZIO VL260M television purchase. Thank
you for your support. For maximum benefit of your HDTV, please read
these instructions before making any adjustments, and retain them for
future reference. We hope you will experience many years of enjoyment
from your new VIZIO HDTV High Definition Television.

For assistance, please call [phone] or e-mail us at

www.vizio.com.

To purchase or inquire about accessories and installation services for your
VIZIO HDTV, please visit our website at

www.vizio.com or call toll free at

[phone].

We recommend you register your VIZIO HDTV either at our website

www.VIZIO.com or fill out and mail your registration card. For peace of

mind and to protect your investment beyond the standard warranty, VIZIO
offers on-site extended warranty service plans. These plans give
additional coverage during the standard warranty period. Visit our website
or call us to purchase a plan.

Write down the serial number located on the back of your HDTV.

__ __ __ __ __ __ __ __ __ __ __ __ __

Purchase Date _____________________

VIZIO is a registered trademark of VIZIO, Inc. dba V, Inc.

HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC.

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby Laboratories.

TruSurround HD technology is incorporated under license from SRS Labs, Inc.

THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES USED ARE FOR
ILLUSTRATION PURPOSES ONLY. BRAVO, VIZIO AND THE V LOGO AND WHERE VISION MEETS VALUE AND OTHER VIZIO
TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT SPECIFICATIONS ARE SUBJECT TO
CHANGE WITHOUT NOTICE OR OBLIGATION. © 2009 VIZIO INC. ALL RIGHTS RESERVED.

is a trademark of SRS Labs, Inc.

1

www.VIZIO.com

VIZIO VL260M User Manual

Important Safety Instructions

Your HDTV is designed and manufactured to operate within defined design limits, and misuse
may result in electric shock or fire. To prevent your HDTV from being damaged, the following
rules should be observed for the installation, use, and maintenance of your HDTV. Read the
following safety instructions before operating your HDTV. Keep these instructions in a safe place
for future reference.

! To reduce the risk of electric shock or component damage, switch off the power before

connecting other components to your HDTV.

! Unplug the power cord before cleaning your HDTV. A damp cloth is sufficient for cleaning your

HDTV. Do not use a liquid or a spray cleaner for cleaning your HDTV. Do not use abrasive
cleaners.

! Always use the accessories recommended by the manufacturer to insure compatibility.
! When moving your HDTV from an area of low temperature to an area of high temperature,

condensation may form in the housing. Wait before turning on your HDTV to avoid causing fire,
electric shock, or component damage.

! Use only with the cart, stand, tripod, bracket, or table specified by manufacturer or sold with your

HDTV. When a cart is used, use caution when moving the cart/HDTV combination to avoid injury
from tip-over. Do not place your HDTV on an unstable cart, stand, or table. If your HDTV falls, it
can injure a person and cause serious damage to your HDTV. Use only a cart or stand
recommended by the manufacturer or sold with your HDTV.

! A distance of at least 3 feet should be maintained between your HDTV and any heat source, such

as a radiator, heater, oven, amplifier etc. Do not install your HDTV close to smoke. Operating
your HDTV close to smoke or moisture may cause fire or electric shock.

! Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure

reliable operation of your HDTV and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place your HDTV in a bookcase or cabinet unless proper
ventilation is provided.

! Never push any object into the slots and openings on your HDTV cabinet. Do not place any

objects on the top of your HDTV. Doing so could short circuit parts causing a fire or electric shock.
Never spill liquids on your HDTV.

! Your HDTV should be operated only from the type of power source indicated on the label. If you

are not sure of the type of power supplied to your home, consult your dealer or local power
company.

! Do not apply pressure or throw objects at your HDTV. This may compromise the integrity of the

display. The manufacturer’s warranty does not cover user abuse or improper installations.

! The power cord must be replaced when using different voltage than the voltage specified. For

more information, contact your dealer.

! Your HDTV is equipped with a three-pronged grounded plug (a plug with a third grounding

pin). This plug will fit only into a grounded power outlet. This is a safety feature. If

your outlet does not accommodate the three-pronged, have an electrician install
the correct outlet, or use an adapter to ground your HDTV safely. Do not defeat
the safety purpose of the grounded plug.

! When connected to a power outlet, power is always flowing into your HDTV. To

totally disconnect power, unplug the power cord.

! The lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of un-isolated, dangerous
voltage within the inside of your HDTV that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.

! The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and servicing instructions in the literature

2

www.VIZIO.com

VIZIO VL260M User Manual

accompanying your HDTV.

! Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
! The wall socket should be installed near your HDTV and easily accessible.
! Only power of the marked voltage can be used for your HDTV. Any other voltage than the

specified voltage may cause fire or electric shock

! Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power

cord during electrical storms.

! Unplug your HDTV during a lightning storm or when it will not be used for long period of time.

This will protect your HDTV from damage due to power surges.

! Do not attempt to repair or service your HDTV yourself. Opening or removing the back cover may

expose you to high voltages, electric shock, and other hazards. If repair is required, contact your
dealer and refer all servicing to qualified service personnel.

! Keep your HDTV away from moisture. Do not expose your HDTV to rain or moisture. If water

penetrates into your HDTV, unplug the power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.

! Do not use your HDTV if any abnormality occurs. If any smoke or odor becomes apparent, unplug

the power cord and contact your dealer immediately. Do not try to repair your HDTV yourself.

! Avoid using dropped or damaged appliances. If your HDTV is dropped and the housing is

damaged, the internal components may function abnormally. Unplug the power cord immediately
and contact your dealer for repair. Continued use of your HDTV may cause fire or electric shock.

! Do not install your HDTV in an area with heavy dust or high humidity. Operating your HDTV in

environments with heavy dust or high humidity may cause fire or electric shock.

! Follow instructions for moving your HDTV. Ensure that the power cord and any other cables are

unplugged before moving your HDTV.

! When unplugging your HDTV, hold the power plug, not the cord. Pulling on the power cord may

damage the wires inside the cord and cause fire or electric shock. When your HDTV will not be
used for an extended period of time, unplug the power cord.

! To reduce risk of electric shock, do not touch the connector with wet hands.
! Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to

leak which can damage the remote control or injure the operator.

! If any of the following occurs, contact the dealer:

o The power cord fails or frays.
o Liquid sprays or any object drops into your HDTV.
o Your HDTV is exposed to rain or other moisture.
o Your HDTV is dropped or damaged in any way.
o The performance of your HDTV changes substantially.

Version 5/29/2009 3

www.VIZIO.com

VIZIO VL260M User Manual

Television Antenna Connection Protection

External Television Antenna Grounding

If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during
a lightning storm or when it is left
unattended or unused for long periods
of time, unplug the TV from the wall
outlet and disconnect the antenna or
cable system.

Power Lines

Do not locate the antenna near
overhead light or power circuits, or
where it could fall into such power
lines or circuits.

Remember, the screen of the coaxial cable is intended to be connected to earth in the building
installation.

4

www.VIZIO.com

VIZIO VL260M User Manual

Advisory of the DTV Transition

The nationwide switch to digital television broadcasting will be complete on June 12, 2009, but your local
television stations may switch sooner. After the switch, analog-only television sets that receive TV
programming through an antenna will need a converter box to continue to receive over-the-air TV. Watch
your local stations to find out when they will turn off their analog signal and switch to digital-only
broadcasting. Analog-only TVs should continue to work as before to receive low power, Class A or
translator television stations and with cable and satellite TV services, gaming consoles, VCRs, DVD
players, and similar products.

For additional information, please contact the parties listed below, as appropriate:

FCC (US Federal Communications Commission)
http://www.fcc.gov/
Phone: 1-888-CALL-FCC (1-888-225-5322)
TTY: 1-888-TELL-FCC (1-888-835-5322)
Fax: [phone]
E-mail: [e-mail]

NTIA (National Telecommunications and Information Administration)
http://www.ntia.doc.gov/
1-888-DTV-2009

Listings of US Television Stations
http://www.high-techproductions.com/usTVstations.htm

Note: Your VIZIO HDTV is capable of receiving Digital Broadcasts, and no Digital Converter Box is

required.

Note: The Federal Communications Commission (FCC), the Consumer Electronics Association (CEA)

and the Consumer Electronics Retailers Coalition (CERC) have made a new tip sheet available for digital
television (DTV) retailers to reproduce and distribute to consumers on the sales floor. The file may be
downloaded online at www.dtv.gov. While you’re there, check out the other useful information in the FCC
is making available to consumers interested in learning more about the analog to digital transition.

Version 5/29/2009 5

www.VIZIO.com

VIZIO VL260M User Manual

Table of Contents

Important Safety Instructions.....................................................................................................................2

Television Antenna Connection Protection ............................................................................................... 4

Advisory of the DTV Transition..................................................................................................................5

Opening the Package................................................................................................................................8

TV Setup and Stand Assembly .................................................................................................................9

Setting Up Your HDTV ............................................................................................................................10

Wall Mounting your HDTV.......................................................................................................................10

CHAPTER 1 BASIC CONTROLS AND CONNECTIONS ....................................... 11

Front Panel ..............................................................................................................................................11

Side Panel Controls.................................................................................................................................11

Rear Panel Connections..........................................................................................................................12

VIZIO Remote Control.............................................................................................................................13

Insertion of Batteries in the Remote Control ........................................................................................... 14

Remote Control Range ........................................................................................................................14

VIZIO Remote Control Precautions .....................................................................................................14

CHAPTER 2 CONNECTING EQUIPMENT ........................................................... 15

Which Video Connection Should I Use? .................................................................................................15

Connecting Your Cable or Satellite Box..................................................................................................16

Using HDMI (Best) ...............................................................................................................................16

HDMI Connections for Cable or Satellite Boxes with DVI ...................................................................17

Using Component Video (Better).........................................................................................................17

Using S-Video (Better).........................................................................................................................18

Using Composite Video (Good) ...........................................................................................................18

Using Coaxial (Antenna) (Good)..........................................................................................................18

Connecting Coaxial (RF) .........................................................................................................................19

Using Your Antenna or Digital Cable for Standard TV or Digital TV) ..................................................19

Using the Antenna or Cable through Your VCR..................................................................................19

Connecting Your DVD Player..................................................................................................................20

Using HDMI (Best) ...............................................................................................................................20

HDMI Connections for DVD Players with DVI .....................................................................................20

Using Component Video (Better).........................................................................................................21

Using S-Video (Better).........................................................................................................................21

Using Composite (AV) Video (Good)...................................................................................................22

Connecting Your VCR or Video Camera.................................................................................................22

Optical Output of audio received with HD Programs............................................................................... 23

Connecting a Computer...........................................................................................................................23

Preset PC Resolutions.........................................................................................................................24

Resolution through RGB Input.............................................................................................................24

CHAPTER 3 USING YOUR HDTV THE FIRST TIME ........................................... 25

Setup Wizard ...........................................................................................................................................25

Select Input Source .................................................................................................................................27

Fine Tuning the picture............................................................................................................................27

Setting the Time Zone ............................................................................................................................27

Watching a TV Program ..........................................................................................................................27

Adjusting Basic HDTV Settings...............................................................................................................27

Program Information................................................................................................................................27

CHAPTER 4 ADVANCED ADJUSTMENT OF HDTV ...........................................27

Using the On Screen Display (OSD).......................................................................................................27

Picture Menu ...........................................................................................................................................27

Picture Mode........................................................................................................................................27

6

www.VIZIO.com

VIZIO VL260M User Manual

Backlight ..............................................................................................................................................27

Brightness ............................................................................................................................................ 27

Contrast ...............................................................................................................................................27

Color.....................................................................................................................................................27

Tint ....................................................................................................................................................... 27

Sharpness............................................................................................................................................ 27

Advanced Video................................................................................................................................... 27

Reset Picture Mode ............................................................................................................................. 27

Audio Menu ............................................................................................................................................. 27

Equalizer .............................................................................................................................................. 27

Balance ................................................................................................................................................ 27

SRS TSHD........................................................................................................................................... 27

Digital Audio Out .................................................................................................................................. 27

Speakers.............................................................................................................................................. 27

Lip Sync ............................................................................................................................................... 27

Reset Audio Mode ............................................................................................................................... 27

TV Menu .................................................................................................................................................. 27

Tuner Mode.......................................................................................................................................... 27

Auto Search ......................................................................................................................................... 27

Partial Channel Search........................................................................................................................ 27

Skip Channel........................................................................................................................................ 27

MTS......................................................................................................................................................27

Time Zone............................................................................................................................................ 27

Daylight Saving .................................................................................................................................... 27

Channel Info......................................................................................................................................... 27

Setup Menu .............................................................................................................................................27

Language ............................................................................................................................................. 27

Sleep Timer.......................................................................................................................................... 27

Wide..................................................................................................................................................... 27

Input Naming........................................................................................................................................ 27

CC (Closed Caption)............................................................................................................................ 27

H/V Position ......................................................................................................................................... 27

Parental................................................................................................................................................ 27

System Info .......................................................................................................................................... 27

System Reset....................................................................................................................................... 27

CHAPTER 5 UNDERSTANDING VIEWING FEATURES ....................................... 27

Viewing Modes ........................................................................................................................................27

CHAPTER 6 MAINTENANCE AND TROUBLESHOOTING .................................... 27

Maintenance ............................................................................................................................................ 27

Troubleshooting Guide ............................................................................................................................27

Telephone & Technical Support.............................................................................................................. 27

Compliance.............................................................................................................................................. 27

FCC Class B Radio Interference Statement ........................................................................................... 27

SPECIFICATIONS ............................................................................................ 27

LIMITED PRODUCT WARRANTY....................................................................... 27

VIZIO RETURN POLICY.................................................................................... 27

INDEX ............................................................................................................. 27

Version 5/29/2009 7

www.VIZIO.com

VIZIO VL260M User Manual

Opening the Package

Your HDTV and its accompanying accessories are carefully packed in a cardboard carton that has been
designed to protect it from transportation damage. Once you have opened the carton, check that your
HDTV is in good condition and that all of the contents are included.

The glass surface can easily be scratched or broken, so handle your HDTV gently and never place your
HDTV with the glass facing downwards on a surface without protective padding.

IMPORTANT: Save the carton and packing material for future shipping.

Package Contents

! VIZIO VL260M

! Stand and thumb screw

! VIZIO remote control VR2
! AA batteries for the remote control (2)
! Power cord
! This user manual
! Quick Setup Guide
! Registration Card

Additional certified accessories for your HDTV are
sold separately:

! Wall mounts
! High Definition cables
! Extra or replacement remote control

VIZIO also offers installation services and extended warranty services for your HDTV.

To purchase or inquire about additional accessories and services for your VIZIO HDTV, visit our web site
at www.VIZIO.com or call us toll free at 888-VIZIOCE (888-849-4623)

Caution:

of the display. The manufacturer’s warranty does not cover user abuse or improper installations.

Do not apply pressure or throw objects at your HDTV. This may compromise the integrity

8

www.VIZIO.com

VIZIO VL260M User Manual

TV Setup and Stand Assembly

Note: We strongly recommend that two people perform the setup and assembly due to the weight and

size of the TV.

To unpack the TV and stand base:

1. Remove the remote control, batteries, and power cord from the foam end caps.

2. Remove the top foam end cap.

3. Remove the stand from the bottom foam end cap.

4. Remove the TV from the box and lay it face down on a clean, flat surface.

Note: Make sure that the surface is free of debris to prevent the TV screen from getting scratched.

To attach the TV stand base:

1. Slide the stand base onto the stand neck (already connected to TV).

2. On the bottom of the base, insert the thumb screw and tighten. Move the TV into an upright
position.

Bottom view

Vizio TV

(back)

Stand Neck

(already attached
to TV)

Stand Base

Version 5/29/2009 9

www.VIZIO.com

VIZIO VL260M User Manual

Setting Up Your HDTV

! Read this user manual carefully before installing your HDTV.
! The power consumption of your HDTV is about 73W (AVG). Use the included power cord. When

an extension cord is required, use one with the correct power rating. The cord must be grounded
and the grounding feature must not be compromised.

! Your HDTV should be installed on a flat surface to avoid tipping.
! For proper ventilation, you must allow space between the back of your HDTV and the wall.
! If you want to mount your HDTV on the wall, see below for additional information.
! Avoid installing your HDTV in places with high humidity, dust, or smoke so you do not shorten the

service life of the electronic components.

! Install your HDTV in a level, landscape orientation, with the VIZIO logo at the bottom to prevent

poor ventilation and excessive component damage.

VIZIO offers professional installation services. Contact VIZIO for more information on these services at
888-VIZIOCE (888-849-4623) or www.VIZIO.com.

Wall Mounting your HDTV

Your HDTV can be mounted on the wall for viewing. If you choose to mount your HDTV on the wall, follow
the instructions below.

1. Remove the stand base and neck:
a. Disconnect the cables from your HDTV.
b. Place your HDTV face down on a soft, flat surface to

prevent damage to the screen.

c. Remove the six (6) screws holding the stand neck,

and then remove the neck and base.

Note: To remove the base from the neck, unscrew thumbscrew

on bottom.

2. Mount your HDTV on the wall:
a. Attach your HDTV to a wall mount (sold separately)

using the mounting holes in the back panel of your
HDTV.

b. Read the instructions that came with your specific

wall mount to properly hang your HDTV.

10

www.VIZIO.com

VIZIO VL260M User Manual

Chapter 1 Basic Controls and Connections

Front Panel

POWER ‘VIZIO’ LIGHT– The VIZIO name lights
white when powered on and orange when
powered off.

REMOTE CONTROL SENSOR – Point the
remote control directly at this window for the best
response to the remote signal.

Side Panel Controls

HEADPHONE – Connect your headphones here for personalized
listening without disturbing others.

POWER (

Press the button again to turn the HDTV off.

MENU – This button activates the On Screen Display (OSD). If a sub­menu is active, pressing this button will proceed to the next level.

CH !/" – Use these buttons to step up or down the TV channels.
While the OSD is active, these buttons function as up and down
controls in the OSD menus.

VOL + / - – Use these buttons to increase or decrease the speaker
volume. While the OSD is active, these buttons function as left and
right controls in the OSD menus.

INPUT (ENTER) –

! Repeated pressing of this button steps through the input sources in

the following sequence: TV,
AV, Component, RGB, HDMI1
and HDMI2. Once you have
stepped through the entire

sequence, you will return to the beginning.

! If a sub-menu is active, pressing this button will return to the

previous menu level.

! Additionally, when the OSD is active, this button confirms the

menu function to be adjusted.

) – Switch the HDTV on by pressing the button once.

Version 5/29/2009 11

www.VIZIO.com

VIZIO VL260M User Manual

Rear Panel Connections

1. SERVICE ONLY – Do not use. For service technician use only.

2. HDMI 1 – Connect digital video devices such as DVD multimedia players or set top box through
this all digital connector.

3. RGB PC – Connect the video and audio from a computer here. A cable with a 1/8” mini plug
stereo connector at the end connecting to the TV is needed if sound is also transmitted with this
signal.

4. DTV/TV – Connect to an antenna or digital cable (not a cable box) for Digital TV. For digital TV
stations in your area visit www.antennaweb.org.

5. S-VIDEO/AV – Connect composite or S-Video video devices, such as a VCR or video game.
Use the white and red connectors to connect the external audio from the same source.

6. HDMI 2 - Connect another digital video device such as a DVD multimedia player or set top box
through this all digital connector. For users who want to connect to a DVI enabled device, use a
DVI-HDMI cable and connect the analog audio output of the device to the L+R AUDIO here.
Your VIZIO Certified HDMI and HDMI-DVI cables are available for purchase from
www.VIZIO.com or by calling 888-VIZIOCE (888-849-4623).

7. COMPONENT (YPb/CbPr/Cr with Audio L/R) – Connect component video devices such as a
DVD Player or set top box here.

8. OPTICAL OUT – When digital TV is selected for viewing, the audio associated with the
programming will be available on the SPDIF Optical connector for connection to your home
theater system.

12

www.VIZIO.com

VIZIO Remote Control

GUIDE – This button displays program information.

VIZIO VL260M User Manual

POWER (

) – Press this button to turn the TV on from the

Standby mode. Press it again to return to the Standby mode.

TV – Press this button to select TV.
AV – Press this button to select the AV (either Composite or S-

Video) input.

COMP – Press the button to select the Component input.
HDMI – Press this button to select the HDMI input. By pressing it

repeatedly you will go through all HDMI inputs in sequence.
MENU – Use this button for the On-Screen Display (OSD) menu.

Press the button to select a feature after it has been highlighted.

!"# $ -These buttons are used to navigate the OSD menu.

They are used as value settings when the slide bar is shown on the
screen and option settings to turn a feature off or on.

MUTE – This button turns the sound on and off.
LAST – This button recalls the previously viewed channel. If the On-

Screen Display (OSD) menu is being used, this button will allow you
to get back to previous menu screen or out to your program when
you press it repeatedly.

VOL !/" – This button turns the volume up or down.
CH !/" – This button turns the channels up or down.
NUMBER BUTTON PAD – Use these buttons to select a channel or

enter a password.
INPUT –Repeatedly pressing this button will step you through the

input sources in the following sequence: TV, AV, Component, RGB,
HDMI1, and HDMI2. The sequence will then be repeated.

- (DASH) – When selecting a digital channel directly, use this button
for the separation of main and sub-channels. For example, channel
28-2 would be selected by the button sequence 2 8 DASH 2.

Version 5/29/2009 13

www.VIZIO.com

VIZIO VL260M User Manual

Insertion of Batteries in the Remote Control

Insert two AA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the
batteries with the (+) and (-) symbols inside the battery compartment. Re-attach the battery cover.

Precautionary Tips for Inserting the Batteries:

! Only use the specified AA batteries.

! Do not mix new and old batteries. This may result in cracking or

leakage that may pose a fire risk or lead to personal injury.

! Inserting the batteries incorrectly may also result in cracking or

leakage that may pose a fire risk or lead to personal injury.

! Dispose of the batteries in accordance with local laws and

regulations.

! Keep the batteries away from children and pets.

Remote Control Range

Point the remote control at the remote control sensor to transmit the commands.
Do not place any obstacles between the remote control and the receiver window.
The effective range of the remote control is approximately 30 feet (10 meters) from the front of the

receiver window, 30° to the left and right, 20° up and down.

VIZIO Remote Control Precautions

The remote control should be kept dry and away from heat sources. Avoid humidity.
If the TV responds erratically to the remote control or does not respond at all, check the batteries. If the

batteries are low or exhausted, replace them with fresh batteries.
When not using the remote control for a long period of time, remove the batteries.
Do not take the batteries apart, heat them, or throw them into a fire.
Do not subject the remote control to undue physical stress, such as striking or dropping it.
Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp cloth.

14

www.VIZIO.com

VIZIO VL260M User Manual

Chapter 2 Connecting Equipment

Which Video Connection Should I Use?

The VIZIO HDTV has six different ways to connect your video equipment from a basic connection to the
most advanced for digital displays.

Connection

Quality (type)

Best

(digital)

Best

(digital)

- - - - - - - - - - -
Good

(analog)

Best

(analog)

Better

(analog)

Good

(analog)

Connector Description

HDMI provides an interface between any audio/video

source, such as a set-top box, DVD player, or A/V receiver
and a digital television (DTV), over a single cable.

Connect a digital or analog antenna cable or coaxial cable
to watch TV programming.

RGB PC (VGA) – This is most commonly used for PC input.

Component - Component video provides a sharper image
than composite video and S-video because the three video
signals are transmitted via three separate channels.

S-Video (AV) - Combining the three video signals into two
channels, S-Video provides a sharper image than
Composite video, but is not as good as Component video.

Composite (AV) - All three video signals are combined into
one channel, thus making the image less sharp than
Component or S-Video.

Note: For more info refer to the Quick Start Guide

Version 5/29/2009 15

www.VIZIO.com

VIZIO VL260M User Manual

Connecting Your Cable or Satellite Box

You have four options for connecting your cable or satellite box to your HDTV: HDMI, Component,
Composite, or Coax (RF). Based on your home theater configuration, you can decide which option is the
right one for you. Refer to your set-top box user manual for more information about the video output
requirements or consult your cable or satellite operator.

Using HDMI (Best)

Cable and Satellite Boxes that have an HDMI digital interface should be connected to the HDMI input of
the HDTV for optimal results.

Note: To maintain the display quality, use a VIZIO certified HDMI cable. This cable is available in 6, 15,

and 30 foot lengths. See www.vizio.com or call 1-888-VIZIOCE (1-888-849-4623) for details.

SET TOP BOX

1. Turn off the power to the HDTV and HDTV Set-Top Box.

2. Connect an HDMI cable to the HDMI output of your HDTV Set-Top Box and the other end to an
HDMI input on the back of the HDTV.

3. Turn on the power to the HDTV and HDTV Set-Top Box.

4. Select HDMI 1 or HDMI 2 using the INPUT button on the remote control, or directly by pressing
the HDMI button on the remote control.

Note:

! The HDMI input on the HDTV supports High-bandwidth Digital Content Protection (HDCP).

HDCP encrypts the transmission between the video source and the digital display for added
security and protection.

! If you are already using the HDMI1 input for another device, or you do not want to use the HDMI1

input for the Set-Top Box, you can connect the Set-Top Box to another HDMI connection.

! Refer to your HDTV Set-Top Box user manual for more information about the video output

requirements of the product or consult your cable or satellite operator.

16

www.VIZIO.com
