Vizio VA370M User Manual

SETUP (Cont.)

1. The Initial Setup Wizard should appear on-screen (see Fig. 1). Select your desired language.

2. Choose Home mode for optimal energy savings

(see Fig. 2).

VA370M

Fig. 1

HELP TOPICS

PROGRAM YOUR CABLE OR SATELLITE REMOTE

Fig. 2

IF YOU'RE CONNECTING USING A CABLE OR SATELLITE BOX:

1. Exit the Setup Wizard.

2. Set your input source to match the device you’re connecting to.

3. You’re done! Enjoy the show.

IF YOU'RE CONNECTING USING A CABLE FROM THE WALL OR ANTENNA:

1. Choose between Antenna or Cable to match your input source (see Fig. 3).

Fig. 3

Fig. 4

Call your Cable or Satellite provider to determine if you need a 3, 4 or 5-digit code. Refer to the following chart of VIZIO codes and follow your provider's instructions to program your Cable or Satellite remote.

SERVICE PROVIDER

CABLE 11758, 10178, 10128 1758, 0178, 0128

DIRECT TV

DISH NETWORK 627

5-DIGIT CODES 4-DIGIT CODES 3-DIGIT CODES

11758, 10178, 10128 1758, 0178, 0128

2. Begin the scan for channels

Note: Your Service Provider may provide access to HD channels during the channel scan. Please be patient and wait for 100% completion.

3. Once the scan is complete, follow the on-screen instruction to exit the Initial Setup wizard

(see Fig. 5).

(see Fig. 4).

Fig. 5

PROBLEM SOLUTION

Make sure the power button is ON (the VIZIO logo glows white). Make sure the AC power cord is securely connected to the AC

No Power

Picture is blurry or fuzzy/ image quality issues

socket and try plugging the TV directly into the wall. Plug another electrical device (like a radio) to the outlet to verify the outlet is supplying power.

For the best image quality, view HD wide screen programs where possible. If HD content is not available, view Standard Definition from a digital source. Standard analog TV will always be noticeably inferior to HD because your digital flat panel TV has video that is many times better than old TVs, and thus you can see interference and deficiencies you did not know you had.

EXTENDED WARRANTIES

Protect your VIZIO product with up to 5 years of added

repair service! Extended coverage begins when the

manufacturer's warranty expires so you’ll receive

maximum protection!

Visit us online at:

www.VIZIO.com

or Call:

LEARN MORE

Refer to your User Manual for in-depth descriptions or

more information.

and special offers.

Cannot change channels up and down with direct cable hookup from wall or antenna

Cannot return to the Setup Wizard

Screen is displaying blue/no signal and/or turning off after a few seconds

Panoramic mode is not available

Press the MENU button. Use the arrows to navigate to the TV TUNER MENU. Highlight the first option, called Tuner Mode. Select the appropriate input by using the left and right arrows. Once Tuner Mode is correct, highlight "AutoSearch", then press the right arrow.

The Setup Wizard is no longer accessible after being run once, but all of the same settings can still be changed. Press the MENU button to access them. For channel scan, see the above topic.

Your TV may be on an inactive input. After powering on the TV, press the INPUT button on your remote repeatedly until a picture re-appears. If this does not work, try it a second time but press the button slower this time; it can take as long as 30 seconds for the image to reappear.

When the TV displays an HD resolution the Panoramic viewing mode will not be available.

888.849.4623

For more info on Extended Warranties

www.VIZIO.com

Black or gray bars on top, bottom, and/or sides of picture

Try setting your TV to wide or zoom mode; the image should fill the screen. If you still see bars, they are part of the image the TV is receiving. Cable and satellite boxes may add black bars to the picture, especially when HDMI cables are used. For more information, please contact your service provider.
