VIZIO E24-C1 User Manual

VIZIO

USER MANUAL

Model: E24-C1

This product qualiﬁes for ENERGY STAR in the “factory default” setting and this is the setting in which power savings will be achieved. Changing the factory default picture settings or enabling other features will increase power consumption that could exceed the limits necessary to qualify for ENERGY STAR rating. For more information on the ENERGY STAR program, visit www.energystar.gov.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Studio Sound, DTS TruSurround, and DTS TruVolume are trademarks of DTS, Inc. © DTS, Inc. All Rights Reserved.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

HDMI, the HDMI logo and High-Deﬁnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Welcome

THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO HDTV.

To get the most out of your new VIZIO product, read these instructions before using your product and retain them for future reference. Be sure to inspect the package contents to ensure there are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services for your VIZIO product, visit our website at www.VIZIO.com or call toll free at (877) 878-4946.

We recommend that you either:

• Register your VIZIO product at www.VIZIO.com

• Complete and mail the enclosed registration card

Extended Warranties

For peace of mind, and to protect your investment beyond the standard warranty, VIZIO offers on-site extended warranty service plans. These plans provide additional coverage during the standard warranty period. To purchase an extended warranty service plan, visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the accompanying important warning or notice. It is intended to alert you to the presence of important operating instructions.

When you see this symbol, please read the accompanying helpful tip.

IMPORTANT SAFETY INSTRUCTIONS

Your TV is designed and manufactured to operate within deﬁned design limits. Misuse may result in electric shock or ﬁre. To prevent your TV from being damaged, the following instructions should be observed for the installation, use, and maintenance of your TV. Read the following safety instructions before operating your TV. Keep these instructions in a safe place for future reference.

• To reduce the risk of electric shock or component damage, switch off the power before connecting other components to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

• Only use attachments/accessories speciﬁed by the manufacturer.



• Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

• Unplug the power cord before cleaning your TV.

• When moving your TV from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before turning on your TV to avoid causing ﬁre, electric shock, or component damage.

• A distance of at least three feet should be maintained between your TV and any heat source, such as a radiator, heater, oven, ampliﬁer etc. Do not install your TV close to smoke. Operating your TV close to smoke or moisture may cause ﬁre or electric shock.

• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place your TV in a bookcase or cabinet unless proper ventilation is provided.

or local power company.

• Do not apply pressure or throw objects at your TV. This may compromise the integrity of the display. The manufacturer’s warranty does not cover user abuse or improper installations.

• The power cord must be replaced when using different voltage than the voltage speciﬁed. For more information, contact your dealer.

• When connected to a power outlet, power is always ﬂowing into your TV. To totally disconnect power, unplug the power cord.

• The lightning ﬂash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the inside of your TV that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

• Do not overload power strips and extension cords. Overloading can result in ﬁre or electric shock.

• The wall socket should be installed near your TV and easily accessible.

• Only power of the marked voltage can be used for your TV. Any other voltage than the speciﬁed voltage may cause ﬁre or electric shock.

• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.

• Unplug your TV during a lightning storm or when it will not be used for long period of time. This will protect your TV from damage due to power surges.

• Never push any object into the slots and openings on your TV cabinet. Do not place any objects on the top of your TV. Doing so could short circuit parts causing a ﬁre or electric shock. Never spill liquids on your TV.

• Your TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer

• Do not attempt to repair or service your TV yourself. Opening or removing the back cover may expose you to high voltages, electric shock, and other hazards. If repair is required, contact your dealer and refer all servicing to qualiﬁed service personnel.

• WARNING: Keep your TV away from moisture. Do not expose your TV to rain or moisture. If water penetrates into

your TV, unplug the power cord and contact your dealer. Continuous use in this case may result in ﬁre or electric shock.

• Do not use your TV if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to repair your TV yourself.

• Avoid using dropped or damaged appliances. If your TV is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of your TV may cause ﬁre or electric shock.

• Do not install your TV in an area with heavy dust or high humidity. Operating your TV in environments with heavy dust or high humidity may cause ﬁre or electric shock.

• Follow instructions for moving your TV. Ensure that the power cord and any other cables are unplugged before moving your TV.

• When unplugging your TV, hold the AC/DC power adapter, not the cord. Pulling on the power cord may damage the wires inside the cord and cause ﬁre or electric shock. When your TV will not be used for an extended period of time, unplug the power cord.

• This apparatus shall not be exposed to dripping or splashing and no objects ﬁll with liquids, such as vases, shall be placed on the apparatus.

• The mains plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• CAUTION - These servicing instructions are for use by qualiﬁed service personnel only. To reduce the risk of electric shock, do not perform any servicing other than

that contained in the operating instructions unless you are qualiﬁed to do so.

• The lightning ﬂash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electrical shock to persons.

• To reduce risk of electric shock, do not touch the connector with wet hands.

• Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to leak which can damage the remote control or injure the operator. Do not expose batteries to excessive heat such as sunshine, ﬁre or the like.

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your TV.

- Your TV is exposed to rain or other moisture.

- Your TV is dropped or damaged in any way.

- The performance of your TV changes substantially.

TELEVISION ANTENNA CONNECTION PROTECTION

If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements of the grounding electrode.

Ground Clamp

Lightning Protection

For added protection of the TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.

Power Lines

Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits. Remember, the screen of the coaxial cable is intended to be connected to earth in the building installation.

Antenna Lead In Wire

Electric Service Equipment

Antenna Discharge Unit (NEC Section 810-20)

Grounding Conductors (NEC Section 810-21)

Ground Clamps

Power Service Grounding Electrode System

(NEC ART 250, part H)

Table of Contents

Installing the TV ................................................ 3

Inspecting the Package Contents ..................................... 3

Installing the TV ................................................................... 3

Installing the TV Stand .....................................................3

Installing the TV on a Wall ................................................ 6

Controls and Connections .............................. 7

Rear Panel ..........................................................................7

Side Panel ........................................................................... 8

Front Panel ..........................................................................9

Remote Control ..................................................................10

Replacing the Batteries ...................................................11

Connecting Your Devices ................................. 12

Connecting a Device ......................................................... 12

Connecting a Device - Audio and Video Cable Types ...13

Connecting a Computer ...................................................15

Connecting an Audio Device ............................................16

Connecting an Audio Device - Audio Cable Types .........17

Connecting an Audio Device - ARC ................................ 18

Without HDMI ARC ............................................................ 18

With HDMI ARC ................................................................. 18

Connecting to your Network .............................................. 19

Connecting to a Wired Network (Best) ...........................19

Connecting to a Wireless Network ..................................19

Completing the First-Time Setup ...................... 20

Using the On-Screen Menu .............................. 22

Navigating the On-Screen Menu .......................................22

Changing the Input Source ...............................................23

Changing the Screen Aspect Ratio ................................... 23

Viewing Video with the Menu Open .................................. 24

Adjusting the Picture Settings ............................................25

Adjusting the Advanced Picture Settings ........................26

Adjusting the Professional Picture Settings ...................... 27

Adjusting the Color Tuner Settings ..................................27

Creating a Custom Picture Mode ...................................30

Renaming a Custom Picture Mode ................................. 31

Locking a Custom Picture Mode .....................................31

Deleting a Custom Picture Mode ....................................32

Adjusting the Audio Settings .............................................. 33

Changing the Equalizer Settings ..................................... 34

Deleting the Custom Audio Mode ...................................34

Setting Timers ...................................................................... 35

Setting the Sleep Timer .................................................... 35

Setting the Auto Power Off Feature ..................................35

Using the Network Connection Menu ................................ 36

Connecting to a Wireless Network ..................................36

Changing the Manual Setup Settings .............................36

Finding MAC Addresses for Network Setup .....................37

Connecting to a Hidden Network ...................................37

Setting Up the Tuner............................................................38

Selecting a Tuner Input ....................................................38

Scanning for Channels .................................................... 38

Adding New Channels ....................................................39

Skipping Channels...........................................................40

Listening to Alternate Audio ...............................................41

Changing the Analog Audio Language .........................41

Changing the Digital Audio Language ...........................41

Setting Up Closed Captioning ...........................................42

Changing the Appearance of Digital Closed Captions . 42

Renaming Devices on the Input Menu ..............................44

Changing the TV Settings ................................................... 45

Viewing System Information ............................................45

Using the Parental Controls .............................................46

Accessing the Parental Controls Menu ........................... 46

Enabling or Disabling Program Ratings ........................... 46

Locking and Unlocking Channels ...................................46

Blocking and Unblocking Content by Rating ..................47

Changing the Parental Control Passcode ......................47

Resetting the Content Locks ............................................ 47

Changing the On-Screen Menu Language ....................48

Setting the Time & Local Settings.....................................48

Adjusting the CEC Settings ..............................................49

Turning the Power Indicator On or Off ............................. 49

Using the Reset & Admin Menu .......................................... 50

Using the Hot Keys............................................................56

Using the Fullscreen V.I.A. Plus Apps Window ..................... 57

Fullscreen V.I.A. Plus Apps Window Overview .....................58

Customizing the V.I.A. Plus Apps Window ...........................59

Adding an App to the My Apps Tab ................................59

Deleting an App from the My Apps Tab ..........................59

Moving an App in My Apps ............................................. 60

Troubleshooting & Technical Support .............. 61

Speciﬁcations ................................................... 64

Limited Warranty ............................................... 66

Legal & Compliance ........................................ 67

Restoring the TV to Factory Default Settings .................... 50

Using the Guided Setup Menu ........................................ 50

Using Guided Setup .........................................................50

Using the Info Window ........................................................51

Using the USB Media Player ............................. 52

Using the USB Media Player ................................................ 52

Preparing Your USB Drive to Play USB Media .................... 52

Playing USB Media ...........................................................52

Removing the USB Drive from the TV ................................52

Using VIZIO Internet Apps Plus® (V.I.A. Plus) ...... 56

Using the V.I.A. Plus App Dock ............................................56

Installing the TV

INSPECTING THE PACKAGE CONTENTS

Before installing your new TV, take a moment to inspect the package contents. Use the images below to ensure nothing is missing or damaged.

VIZIO LED HDTV with Stand

Remote Control

with Batteries

INSTALLING THE TV

After removing the TV from the box and inspecting the package contents you can begin installing the TV. Your TV can be installed in two ways:

• On a ﬂat surface, using the included stand

• On a wall, using a VESA-standard wall mount (not included)

Installing the TV Stand

Your TV includes a stand designed to support the weight of the TV and keep it from falling over. However, the TV can still fall over if:

• It is placed on an uneven, unstable, or non-level surface

• It is pushed, pulled, or otherwise improperly moved

• If an earthquake occurs and the TV is not properly secured

Power Cord

4 x T4 12mm

Phillips Screws

PACKAGE CONTENTS

Quick Start Guide

TV ON STAND

To install the base:

1. Place the TV screen-down on a clean, ﬂat surface. To prevent scratches or damage to the screen, place the TV on a soft surface, such as a blanket.

2. Align the stand and hook it into the bottom of the TV as shown.

3. Using a Phillips screwdriver, tighten four (4) T4 12mm screws into the base to secure it to the TV.

When you are ﬁnished, place the TV on a stable, level surface. To ensure proper ventilation, leave at least 1” of space between the back of the TV and any other objects (walls, etc).

Installing the TV on a Wall

To mount your TV on a wall, you will need a wall mount. Consult the information below to ﬁnd the appropriate mount for your TV model:

Installing a TV on a wall requires lifting. To prevent injury or damage to the TV, ask someone to help you.

E24-C1

Screw Size: M4

Hole Pattern: 100mm (V) x 100mm (H)

Be sure the mount you choose is capable of supporting the weight of the TV. After you have determined that you have the correct mount for your TV, you can begin the installation.

To install your TV on a wall:

1. Disconnect any cables connected to your TV.

2. Place the TV face-down on a clean, ﬂat, stable surface. Be sure the surface is clear of debris that can scratch or damage the TV.

3. Remove the base by loosening and removing the screws.

4. Attach your TV and wall mount to the wall, carefully following the instructions that came with your mount.

Use only with a UL-listed wall mount bracket rated for the weight/load of this TV. See

page 64

for the weight of this TV.

Appendix B - Speciﬁcations on

WALL MOUNT SCREW LOCATIONS

Controls and Connections

Ethernet - Connect an Ethernet cable from a home network.

RGB PC - Connect a VGA cable from a computer.

PC Audio In - Connect a 3.5mm audio cable from a PC.

Coaxial - Connect a coaxial cable from cable, satellite, or antenna.

USB - Connect a USB thumb drive to play photo, music, or video.

Head Set - Connect a head set or other device with a 3.5mm jack.

Component/Composite - Connect a component or composite device.

HDMI - Connect an HDMI device.

REAR PANEL

POWER - Press and hold to turn TV off or on.

INPUT - Press to change input source.

SIDE PANEL

FRONT PANEL

REMOTE SENSOR & POWER INDICATOR When using the remote, aim it directly at this sensor. If the base is installed, the remote must be at or above the level of the sensor.

The power indicator lights up for a few seconds when the TV is powered on. To keep the power indicator on when the TV is on, see

or Off on page 49.

Turning the Power Indicator On

FRONT PANEL

REMOTE CONTROL

APP LAUNCHER

Quickly launch the pictured App.

INPUT

Change the currently-displayed input.

A/V CONTROLS

Control USB media player.

CLOSED CAPTIONS

Open the closed caption menu.

EXIT

Close the on-screen menu.

Select the highlighted menu option.

BACK

Go to the previous on-screen menu.

VOLUME UP/DOWN

Increase or decrease loudness of

the audio.

MUTE

Turn the audio off or on.

NUMBER PAD

Manually enter a channel.

WIDE

Switch the display mode.

POWER

Turn the TV on or off.

INFO Display the info window.

Display the on-screen menu.

ARROW Navigate the on-screen menu.

GUIDE

Display the info window.

V BUTTON Open the V.I.A. Plus Dock.

CHANNEL UP/DOWN

Change the channel.

LAST Return to the channel last viewed.

DASH

Use with number pad to manually enter a digital sub-channel. (For example, 18-4 or 18-5.)

REMOTE CONTROL

Replacing the Batteries

1. Remove the battery cover.

2. Insert two batteries into the remote control. Make sure that the (+) and (-) symbols on the batteries match the (+) and (-) symbols inside the battery compartment.

3. Replace the battery cover.

Connecting Your Devices

CONNECTING A DEVICE

Your TV can be used to display output from most devices.

1. Verify that your device has a video port that matches an available port on the TV (HDMI, Component, etc).

2. Turn the TV and your device off.

3. Connect the appropriate cable (not included) to the TV and the device.

Cable/Satellite Box

4. Turn the TV and your device on. Set the TV’s input to match the connection you used (HDMI-1, HDMI-2, etc.).

DVD/Blu-ray Player

HDMI CABLE • DIGITAL

• HD VIDEO (1080p)*

BEST

COMPONENT CABLE

BETTER

COAXIAL CABLE

BETTER

• HD AUDIO

• ANALOG

• HD VIDEO (1080i)*

• STEREO AUDIO

• ANALOG

• HD VIDEO (1080i)*

• STEREO AUDIO

Game Console

BACK OF TV

AV CABLE • ANALOG

GOOD

* Maximum Resolution

• VIDEO (480i)*

• STEREO AUDIO

COAXIAL CABLE

CONNECTING A DEVICE - AUDIO AND VIDEO CABLE TYPES

AV CABLE

AV cables (or Composite cables) are the traditional way of connecting your devices to your TV. Video signals are sent over the yellow connector while audio is sent over the red and white connectors.

• Video Resolutions up to 480i

• Analog Connection

• Audio and Video Signals

Y L R

COAXIAL CABLE

Coaxial cables are are the traditional way of connectiong antennas and cable television signals to your TV. Coaxial cables carry both audio and video signals through a single connector.

• HD Video Resolutions up to 1080i

• Analog Connection

• Audio and Video Signals

GOOD BETTER

COMPONENT VIDEO

CONNECTING A DEVICE - AUDIO AND VIDEO CABLE TYPES

COMPONENT CABLE

Component cables are designed to carry high deﬁnition video signals along with additional audio connections. Colors are delivered with color information split up three different ways over three connectors for video (separated into Red, Blue and Green signals) and the left and right audio connectors (Red and White).

• HD Video Resolutions up to 1080i

• Analog Connection

• Audio and Video Signals

R L Pr/Cr Pb/Cb Y

HDMI CABLE

HDMI is the intelligent, all-digital interface that delivers both dazzling quality and unmatched ease of use. HDMI technology transmits crystal-clear digital video along with multi-channel surround audio. HDMI-connected devices have the ability to automatically adjust themselves for optimal viewing.

• HD Video Resolutions up to 1080p

• HD Audio

• Digital Connection

• Audio and Video Signals

HDMI

BETTER

BEST

CONNECTING A COMPUTER

Your TV can be used to display output from a personal computer.

To use your TV as a PC display:

1. Connect a VGA cable (not included) to your PC and the RGB port on the back of the TV. This cable transmits video.

2. Connect a 3.5mm cable (not included) to your PC and the PC Audio In port on the back of the TV. This cable transmits audio.

3. Set your PC’s resolution to match the resolution of your TV. See

Appendix B - Speciﬁcations.

Personal Computer

AUDIO

3.5mm Cable

VIDEO

VGA Cable

CONNECTING AN AUDIO DEVICE

Your TV can output sound to an audio device, such as a receiver or sound bar.

1. Verify that your device has a video port that matches an available port on the TV (HDMI or RCA).

2. Turn the TV and your audio device off.

3. Connect the appropriate cable (not included) to the TV and the device.

Home Audio Receiver

4. Turn the TV and your device on.

HDMI CABLE

BEST

VIZIO Sound Bar

• CEC 2-WAY COMMUNICATION

• 2.0-5.1 DIGITAL AUDIO

• PCM, DTS, DOLBY DIGITAL

BACK OF TV

3.5MM CABLE

GOOD

• ANALOG STEREO CONNECTION

• 2.0 CHANNEL

CONNECTING AN AUDIO DEVICE - AUDIO CABLE TYPES

3.5MM CABLE

3.5mm cables are the traditional way of connecting your devices to your audio device. Audio signals are sent over a single cable.

• Quality Stereo Connection

• 2.0 Channel

• Analog Connection

• Audio Signal Only

3.5mm

HDMI CABLE

HDMI technology transmits crystal-clear digital multi-channel surround audio through a single HDMI cable. Audio Return Channel-enabled (ARC) TVs allow audio to be sent over an already connected HDMI cable, eliminating the need for a separate audio cable. See

Audio Device - ARC

• CEC 2-way Communication (Auto setup)

• PCM, DTS, Dolby Digital

• 2.0-5.1 Scaleable Lossless Digital Audio Connection

• Audio and Video Signals

on page 18.

HDMI

Connecting an

GOOD

BEST

CONNECTING AN AUDIO DEVICE - ARC

Without HDMI ARC With HDMI ARC

VIZIO Internet Apps Plus

Without an HDMI ARC setup, your TV will transmit audio signals from the built-in tuner and VIA apps to your home audio receiver through a separate audio connection.

3.5mm (Audio)

Your Home Audio Receiver

Built-in Tuner

Your TV

HDMI

Built-in Tuner

Your TV

HDMI

Your Home Audio Receiver

VIZIO Internet Apps Plus

With an HDMI ARC setup, the audio connection between your TV and home audio receiver can be removed. The HDMI cable will transmit audio signals to and from your TV with an all-digital audio/video connection.

HDMI

Your Blu-ray Player

HDMI

Your Blu-ray Player

+ 53 hidden pages
