VISHAY VSKL240 Technical data

(MAGN-A-PAK

MAGN-A-PAK

Vishay High Power Products

Fast Recovery Diodes, 250 A

TM

Power Modules)

FEATURES

• Fast recovery time characteristics

• Electrically isolated base plate

• Industrial standard package

• Simplified mechanical designs, rapid assembly

• High surge capability

• Large creepage distances

TM

• 3000 V

• UL E78996 approved

• Lead (Pb)-free

• Designed and qualified for industrial level

isolating voltage

RMS

VSK.L240 Series

RoHS

COMPLIANT

DESCRIPTION

The VSK.L240 Series of MAGN-A-PAKsTM uses fast

PRODUCT SUMMARY

I

F(AV)

250 A

recovery power diodes in four basic configurations. The
semiconductors are electrically isolated from the metal base,
allowing common heatsinks and compact assemblies to be
built. Application includes power supplies, battery chargers,
welders, motor controls and general industrial current
rectification. These modules are intended for those
applications where fast recovery characteristics are required.

MAJOR RATINGS AND CHARACTERISTICS

SYMBOL CHARACTERISTICS

I

F(AV)

I

F(RMS)

I

FSM

2

t

I

2

I

√t 3220 2800 kA2√s

V

RRM

T

J

T

C

50 Hz 8000 7500

60 Hz 8400 7850

50 Hz 322 280

60 Hz 294 256

Range - 40 to 150 °C

S10/S20 S30

250 240 A

100 100 °C

392 377

VSK.L240

Up to 2500 V

UNITS

A

kA2s

Document Number: 93164 For technical questions, contact: [e-mail]
Revision: 22-Apr-08 1

www.vishay.com

VSK.L240 Series

Vishay High Power Products

Fast Recovery Diodes, 250 A

(MAGN-A-PAKTM Power Modules)

ELECTRICAL SPECIFICATIONS

VOLTAGE RATINGS

V

MAXIMUM REPETITIVE

TYPE NUMBER

VOLTAGE

CODE

t

rr

CODE

06 S10 600 700

10 S10 1000 1100

VSK.L240

12 S20 1200 1300

14 S20 1400 1500

20 S30 2000 2100

25 S30 2500 2600

FORWARD CONDUCTION

PARAMETER SYMBOL TEST CONDITIONS

Maximum average forward current
at case temperature

Maximum RMS forward current I

Maximum peak, one-cycle forward
non-repetitive, surge current

2

Maximum I

Maximum I

Low level value of threshold voltage V

High level value of threshold voltage V

Low level value of forward slope resistance r

High level value of forward slope resistance r

Maximum forward voltage drop V

t for fusing I2t

2

√t for fusing I2√t t = 0.1 to 10 ms, no voltage reapplied 3220 2800 kA2√s

RRM,

PEAK REVERSE VOLTAGE

V

I

F(AV)

F(RMS)

I

FSM

F(TO)1

F(TO)2

180° conduction, half sine wave

As AC switch 392 377

t = 10 ms

t = 8.3 ms 8400 7850

t = 10 ms

t = 8.3 ms 7100 6600

t = 10 ms

t = 8.3 ms 294 256

t = 10 ms

t = 8.3 ms 208 181

(16.7 % x π x I
T

= TJ maximum

J

(I > π x I
(16.7 % x π x I

f1

T

= TJ maximum

J

(I > π x I

f2

IFM = 800 A, TJ = 150 °C, tp = 10 ms

FM

Average power = V

No voltage
reapplied

100 % V
reapplied

No voltage
reapplied

100 % V
reapplied

F(AV)

), TJ = TJ maximum 1.31 1.31

F(AV)

F(AV)

), TJ = TJ maximum 0.41 0.60

F(AV)

RRM

RRM

< I < π x I

< I < π x I

x I

F(TO)

Sinusoidal half wave,
initial T

F(AV)

, MAXIMUM

V

RSM

NON-REPETITIVE PEAK

REVERSE VOLTAGE

V

= TJ maximum

J

),

F(AV)

),

F(AV)

F(RMS)

2

)

+ rf x (I

I

MAXIMUM

RRM

AT 150 °C

mA

50

VSK.L240

S10/S20 S30

250 240 A

100 100 °C

8000 7500

6750 6300

322 280

228 198

0.98 0.98

0.75 0.97

1.57 1.75 V

UNITS

A

kA2s

V

mΩ

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 93164

2 Revision: 22-Apr-08

VSK.L240 Series

Fast Recovery Diodes, 250 A

Vishay High Power Products

(MAGN-A-PAKTM Power Modules)

RECOVERY CHARACTERISTICS

CODE

MAXIMUM VALUE

AT T

= 25 °C

J

t

AT 25 % I

rr

RRM

(µs)

TEST CONDITIONS

I

pk

SQUARE

PULSE

dI/dt

(A/µs)

V

(V)

r

(A)

S10 1.0

S20 2.0 3.5 250 145

500 100 - 50

S30 3.0 3.6 360 200

BLOCKING

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum peak reverse leakage current I

RMS insulation voltage V

RRM

TJ = 150 °C, leakage current 50 mA

50 Hz, circuit to base, all terminals shorted, 25 °C,

INS

t = 1 s

TYPICAL VALUES

= 150 °C

AT T

J

trr AT 25 % I

RRM

(µs)

2.7 135 100

Q

(µC)

Ir

rr

(A)

I

FM

t

rr

di
dt

I

RM(REC)

3000 V

t

Q

rr

THERMAL AND MECHANICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum junction operating and
storage temperature range

Maximum internal thermal resistance,
junction to case per junction

Thermal resistance,
case to heatsink per module

MAP to heatsink

Mounting torque ± 10 %

busbar to MAP 8 to 10

Approximate weight

, T

T

J

Stg

R

thJC

DC operation 0.125

- 40 to 150 °C

K/W

R

thCS

Mounting surface flat, smooth and greased 0.02

A mounting compound is recommended and
the torque should be rechecked after a

4 to 6

period of about 3 hours to allow for the
spread of the compound.

850 g

30 oz.

Case style MAGN-A-PAK

ΔR CONDUCTION PER JUNCTION

CONDUCTION ANGLE SINUSOIDAL CONDUCTION RECTANGULAR CONDUCTION TEST CONDITIONS UNITS

180° 0.008 0.007

120° 0.010 0.011

T

90° 0.013 0.015

60° 0.019 0.020

30° 0.032 0.033

Note

• The table above shows the increment of thermal resistance R

when devices operate at different conduction angles than DC

thJC

= TJ maximum K/W

J

Nm

Document Number: 93164 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 22-Apr-08 3

VSK.L240 Series

Vishay High Power Products

150

140

130

120

110

100

90

80

Maximum Allowa ble Ca se Temperature (°C)

0 50 100 150 200 250 300

Average Forward Current (A)

Fig. 1 - Current Ratings Characteristics

150

140

130

120

110

100

90

80

Maximum Allowable Case Temp erature (°C)

0 50 100 150 200 250 300 350 400 450

Fig. 2 - Current Ratings Characteristics

V S K. L2 40 . . S10 / S2 0 Se r i e s
R (DC) = 0.125 K/ W

thJC

Conduction Angle

30°

60°

90°

120°

180°

VSK.L240.. S10/ S20 Serie s
R ( D C ) = 0 .12 5 K/ W

thJC

Conduct ion Period

30°

60°

90°

120°

180°

DC

Average Forward Current (A)

Fast Recovery Diodes, 250 A

(MAGN-A-PAKTM Power Modules)

600

500

400

300

RM S Lim it

200

100

0

Maximum Average Forward Power Loss (W)

0 50 100 150 2 00 250 300 350 400

Average Forward Current (A)

Fig. 4 - Forward Power Loss Characteristics

8000

At Any Rated Load Cond ition And With

Rated V Applied Following Surge.

7000

6000

5000

4000

3000

V S K . L2 40 . . S10 / S2 0 Se r i e s

Pea k Ha lf Sine Wa ve Fo rw a rd Curre nt (A)

Pe r Ju nc t io n

2000

110100

Number Of Equal Amplitude Half Cycle Current Pulses (N)

Fig. 5 - Maximum Non-Repetitive Surge Current

DC
180°
120°

90°

60°

30°

VSK.L240..S10/ S20 Se ries
T = 1 5 0° C P e r J u n c t i o n

J

RRM

Conduc tion Period

Initia l T = 150°C

J

@ 60 Hz 0.0083 s
@ 50 Hz 0.0100 s

400

350

300

250

200

150

100

50

0

Maximum Ave rage Fo rwa rd Po we r Lo ss (W)

0 50 100 150 200 250

180°
120°

90°
60°
30°

RM S Li m it

Conduction Angle

VSK.L240..S10/ S20 Se ries
Per J unc t io n T = 150°C

Average Forward Current (A)

J

Fig. 3 - Forward Power Loss Characteristics

8500

Maximum Non Repetitive Surge Current

7500

6500

5500

4500

3500

ine Wave Fo rwa rd Curre nt ( A)

2500

VSK.L240..S10/ S20 Serie s

Pe ak Ha lf S

Pe r Ju nc t i o n

1500

0.01 0.1 1

Versus Pulse Train Duration.

Pulse Train Duration (s)

Initial T = 150°C

No Vo ltag e Reap plie d

Rated V Reapplied

J

RRM

Fig. 6 - Maximum Non-Repetitive Surge Current

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 93164

4 Revision: 22-Apr-08

VSK.L240 Series

(MAGN-A-PAKTM Power Modules)

150

140

130

120

110

100

90

80

Maximum Allowable Case Temperature (°C)

0 50 100 150 200 250

Average Forward Current (A)

Fig. 7 - Current Ratings Characteristics

150

140

130

120

VSK.L240..S30 Serie s
R ( D C ) = 0. 12 5 K / W

thJC

Conduction Angle

30°

60°

V SK .L 24 0 .. S3 0 Se r ie s
R (DC) = 0.125 K/W

thJC

Conduction Period

Fast Recovery Diodes, 250 A

90°

120°

180°

Vishay High Power Products

550

DC

500

180°
120°

450

90°

400

60°
30°

350

300

250

RM S Li mi t

200

150

100

50

0

Maximum Average Forward Power Loss (W)

0 50 100 150 200 250 300 350 400

Average Forward Current (A)

Fig. 10 - Forward Power Loss Characteristics

7000

6000

5000

At Any Rated Loa d Condition And With

Ra ted V App lied Following Surge.

RRM

Conduction Period

V SK . L 24 0. . S3 0 Se r i e s
Pe r Ju nc t i o n
T = 150°C

J

Initia l T = 150°C

J

@ 60 Hz 0.0083 s
@ 50 Hz 0.0100 s

110

100

90

80

Maximum Allowable Case Temperature (°C)

0 50 100 150 200 250 300 350 400

30°

60°

90°

120°

180°

Average Forward Current (A)

Fig. 8 - Current Ratings Characteristics

400

350

300

250

200

150

100

Maximum Average Forward Power Loss (W)

180°
120°

90°
60°
30°

RM S Lim i t

Conduction Angle

VSK.L240..S30 Serie s

50

0

0 50 100 15 0 200 25 0

Average Forward Current (A)

Pe r J unc ti o n
T = 15 0° C

J

Fig. 9 - Forward Power Loss Characteristics

DC

4000

3000

VSK.L240..S30 Series

Pe a k Ha lf Sin e Wav e Fo rward Curre nt ( A)

Per Junc t io n

2000

110100

Number Of Equal Amplitude Half Cycle Current Pulses (N)

Fig. 11 - Maximum Non-Repetitive Surge Current

8000

Maximum Non Repetitive Surge Current

7000

6000

5000

4000

3000

VSK.L240..S30 Series

2000

Pe r Ju nc t io n

Pe a k Ha lf Sine Wave Forward Current (A)

1000

0.01 0. 1 1

Versus Pu lse Tra in Dura tio n.

Pu l se Tr a in Du r a t i o n ( s)

Init ia l T = 150°C

No Vo l t a g e Rea pp lie d

Rated V Reapplied

J

RRM

Fig. 12 - Maximum Non-Repetitive Surge Current

Document Number: 93164 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 22-Apr-08 5

VSK.L240 Series

Vishay High Power Products

10000

V S K. L2 40 . . S1 0 / S2 0 Se r i e s
Pe r Ju nc t io n

1000

T = 2 5° C

J

T = 1 50 ° C

Instantaneous Forward Current (A)

100

11.522.533.5

Instantaneous Forward Voltage (V)

Fig. 13 - Forward Voltage Drop Characteristics

10000

VSK.L240..S30 Serie s
Pe r Ju nc t io n

1000

Instantaneous Forward Current (A)

100

0.5 1 1.5 2 2.5 3 3.5 4 4.5

Instantaneous Forward Voltage (V)

Fig. 14 - Forward Voltage Drop Characteristics

J

T = 25 ° C

J

T = 15 0° C

J

Fast Recovery Diodes, 250 A

(MAGN-A-PAKTM Power Modules)

110

100

90

80

70

60

50

40

30

20

10

Ma ximum Rev e rse Re c ov ery C urren t - Irr (A)

10 20 30 40 50 60 70 80 90 100

Ra te Of Fa ll Of Forw ard Current - di/ d t (A/ µs)

Fig. 16 - Reverse Recovery Current Characteristics

500

VSK.L240..S20

450

T = 1 5 0 ° C

J

400

350

300

250

200

150

100

50

0

0 50 100 150 200

Ma ximum Re verse Re c ov er y C harg e - Q rr (µC)

Ra t e O f Fa ll O f Fo rw a rd C u r r e n t - d i / d t ( A/ µ s)

Fig. 17 - Reverse Recovery Charge Characteristics

I = 1000A

FM

500A

200A

100A

50A

VSK.L240. .S10 Ser ie s

T = 15 0 ° C

J

I = 1000A

FM

500A

200A

100A

50A

150

VSK.L240..S10

140

T = 150° C

130

J

120
110
100

90
80
70
60
50
40
30
20
10

10 20 30 40 50 60 70 80 90 100

Ma ximum Reverse Rec overy Cha rge - Q rr (µC)

Ra te Of Fa ll Of Forwa rd C urre nt - di/ d t (A/ µs)

I = 1000A

FM

500A

200A

100A

50A

Fig. 15 - Reverse Recovery Charge Characteristics

300

VSK.L240. .S20
T = 150 °C

J

250

200

150

100

50

0

Maximum Reverse Rec overy Current - Irr (A)

050100150200

Rate Of Fall Of Forward Current - di/dt (A/µs)

I = 1 000A

FM

500A

200A

100A

50A

Fig. 18 - Reverse Recovery Current Characteristics

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 93164

6 Revision: 22-Apr-08

VSK.L240 Series

Fast Recovery Diodes, 250 A

Vishay High Power Products

(MAGN-A-PAKTM Power Modules)

500

450

400

350

I = 1000A

FM

500A

100A

300

250

200

150

100

50

0

0 50 100 150 200

Ma ximum Rev erse Rec ove ry Ch arg e - Qrr (µC)

Rate Of Fall Of Forward Current - di/ dt (A/µs)

VSK.L240.. S30 Serie s
T = 150 °C

J

Fig. 19 - Reverse Recovery Charge Characteristics Fig. 20 - Reverse Recovery Current Characteristics

1E5

1E4

1E3

1E2

0.01

0.02

0.04

0.4

0.2

0.1

4

2

1

20 joule s p er pu lse

10

300

I = 1 00 0A

FM

250

200

150

100

50

0

Ma xim u m Reverse Rec ove ry Current - Irr (A )

0 50 100 150 200

VSK.L240.. S30 Se ries
T = 150 °C

J

Rate Of Fall Of Forward Current - di/dt (A/µs)

20 joules per pulse

10

4

2

1

0.4

0.2

0.1

0.04

0.02

0.01

500A

100A

Peak Forward Current (A)

1E1

1E0

1E1 1E2 1E3 1E

VSK.L240. .S10/ S20
Si n u so i d a l Pu l se

tp

T = 15 0 ° C

J

Pu lse Ba sew i d th ( µs)

Fig. 21 - Maximum Forward Energy Power Loss Characteristics

1E5

1E4

1E3

Pea k Forw ard C urre nt (A )

1E2

1E1 1E2 1E3 1E4

VSK.L240..S10/ S20
Sinusoid al Pulse

tp

T = 9 0 ° C

C

20000

5000

1500

25001000 0

1000

Pulse Basewidth (µs)

200

1E1

1E4

4

50 Hz400

1E4

1E11E21E31E4

1E11E21E31E4

1E1

Fig. 22 - Frequency Characteristics

VSK.L240..S10/S20
Trapezoidal Pulse

tp

T = 150 °C

J

VSK.L240. .S10/ S2 0
Si n u so i d a l Pu ls e

tp

T = 100 °C

C

Pu lse Ba se w id t h ( µ s)

1000

Pulse Ba se w id th (µ s)

400

50 Hz

200150025001000020000 5000

Document Number: 93164 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 22-Apr-08 7

VSK.L240 Series

Vishay High Power Products

1E5

1E4

1E3

Pea k Fo rwa rd C urre nt (A )

1E2

1E1 1E2 1E3 1E4

1E5

1E4

1E3

1E2

VSK.L240. .S10/ S20
Trapezoidal Pulse

tp

T = 90 °C

C

0.04

0.02

0.01

Pulse Ba se w id t h (µ s)

20 joules per pulse

10

4

2

1

0.4

0.2

0.1

1000

Fast Recovery Diodes, 250 A

(MAGN-A-PAKTM Power Modules)

VSK.L240..S10/ S20
Trapezoidal Pulse

tp

T = 100 °C

50 Hz400

20015002500

E1 1 E2 1 E3 1 E4

1E1

Fig. 23 - Frequency Characteristics

0.02

0.01

C

2500

1500

Pulse Basewidth (µs)

1

0.4

0.2

0.1

0.04

1000

10

4

2

400

200

20 jou les per p ulse

50 Hz

Pea k For w ard Cu rr e n t ( A)

1E1

1E0

1E1 1E2 1E3 1E

VSK.L240..S30

Sinu soidal Pulse

tp

T = 15 0 ° C

J

Pu l se Ba se w i d th ( µ s)

Fig. 24 - Maximum Forward Energy Power Loss Characteristics

1E5

VSK.L240.. S30

Si n us o i d a l Pu l se

tp

T = 90 °C

C

1E4

1E3

400

Peak Forward Current (A)

1E2

1E1 1E2 1E3 1E4

150025001000020000 5000

1000

200

Pulse Basewidth (µs)

Fig. 25 - Frequency Characteristics

50 Hz

1E4

VSK.L240..S30
Trapezoidal Pulse

tp

T = 150 °C

J

4

1

1E11E21E31E4

Pulse Base w id th (µ s)

VSK.L240..S30
Si n us o i d a l Pu l se
T = 10 0 ° C

tp

C

20000

10000

5000

2500

1500

1000

400

200

50 Hz

1E1 1E2 1E3 1E4

Pulse Basewidth (µs)

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 93164

8 Revision: 22-Apr-08

VSK.L240 Series

Fast Recovery Diodes, 250 A

(MAGN-A-PAKTM Power Modules)

1E5

VSK.L240..S30
Trapezoidal Pulse
T = 90 °C

tp

C

1E4

1E3

Pea k Fo rw a rd C urre nt ( A)

1E2

1E11E21E31E4

150025005000

1000

Pu lse Ba se w i d th ( µ s)

1

St e a d y St a t e V a l u e :

R = 0.125 K/ W

thJC

thJC

(DC Operation)

0.1

200

50 Hz

400

Fig. 26 - Frequency Characteristics

Vishay High Power Products

VSK.L240..S30
Tr a p e z o i d a l Pu l s e
T = 1 0 0 ° C

C

tp

2500

5000

1 E1 1 E2 1 E3 1 E4

1500

Pu lse Ba se w id t h (µ s)

4001000

200

50 Hz

0.01

0.001

Transient Thermal Impedance Z (K/ W)

0.0001

0.0001 0.001 0.01 0.1 1 10 100

Fig. 27 - Thermal Impedance Z

ORDERING INFORMATION TABLE

Device code

VSK D L 240 - 25 S30

1 - Module type

2 - Circuit configuration (see end of datasheet)

3

- L = Fast recovery diode

4 - Current rating

5 - Voltage code x 100 = V

6 -t

VSK.L240. . Serie s
Pe r Jun ct io n

Square Wave Pulse Duration (s)

Characteristics

thJC

51324

6

(see Voltage Ratings table)

RRM

code (see Recovery Characteristics table)

rr

S10 = 1000 ns
S20 = 2000 ns
S30 = 3000 ns

Document Number: 93164 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 22-Apr-08 9

VSK.L240 Series

Vishay High Power Products

Fast Recovery Diodes, 250 A

(MAGN-A-PAKTM Power Modules)

CIRCUIT CONFIGURATION

VSKD... VSKE...

~

~

+

+

-

-

Dimensions http://www.vishay.com/doc?95086

VSKC... VSKJ...

+

+

-

-

LINKS TO RELATED DOCUMENTS

-

-

-

-

+

+

+

+

+

-

+

-

www.vishay.com For technical questions, contact: [e-mail]
10 Revision: 22-Apr-08

Document Number: 93164

Legal Disclaimer Notice

Vishay

Disclaimer

All product specifications and data are subject to change without notice.

Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf
(collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein
or in any other disclosure relating to any product.

Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any
information provided herein to the maximum extent permitted by law. The product specifications do not expand or
otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed
therein, which apply to these products.

No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any conduct of Vishay.

The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless
otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such
applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting
from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding
products designed for such applications.

Product names and markings noted herein may be trademarks of their respective owners.

Document Number: 91000 www.vishay.com
Revision: 18-Jul-08 1
