e-Series Interface
Operators Guide
C1256-0001
C1256-0002
Accessories
www.ocon.com
Copyright © 2012
All rights reserved.
Original Instructions: English
All rights reserved throughout the world. No part of this document may
be stored in a retrieval system, transmitted, copied or reproduced in any
way, including, but not limited to, photocopy, photograph, magnetic or
other record without the prior agreement and permission in writing of
the Vitec Group plc.
Disclaimer
The information contained in this manual is believed to be correct at
the time of printing. Vitec Videocom Ltd reserves the right to make
changes to the information or specications without obligation to notify
any person of such revision or changes. Changes will be incorporated
in new versions of the publication.
We are making every effort to ensure that our manuals are updated on
a regular basis to reect changes to product specications and features.
Should this manual not contain information on the core functionality of
your product, please let us know. You may be able to access the latest
revision of this manual from our website.
Vitec Videocom Ltd. reserves the right to make changes to product
design and functionality without notication.
Trademarks
All product trademarks and registered trademarks are the property of
The Vitec Group Plc.
All other trademarks and registered trademarks are the property of their
respective companies.
Head e-Series
Interface
120EXe
C1226-0001
C1256-0001 1,800,000 1,800,000
C1256-0002 3,600,000 3,600,000
Pan Encoder
Resolution, CPR
Tilt Encoder
Resolution, CPR
Note: All resolutions stated are after quadrature decoding.
VARIANTS
Published by:
Vitec Videocom Limited
Supports Technical Publications Department
William Vinten Building, Western Way
Bury St Edmunds
Suffolk IP33 3TB
Email: technical.publications@vitecgroup.com
1
Height
Width
Length
Weight
Payload
Cleaning instructions
No serviceable parts
Operating temperature
Head fixing type
Colour
Dry the product after use
in wet conditions
Lubrication
Download
Service centre
Don’t leave in direct sunlight
Serviceable item
Tilt
Diameter
Camera Plate
Do not attach items to the pan bar
No heavy items on the spreader
Tripping hazard
Ensure leg clamps are secure
Hold the pan bar
Hold the camera
Use only genuine parts
Depth
Service Level Spares
Power requirement
Foot type
Tiping Pedestal
User Level Spares
Fitting Guide Available
Ventilation
!
!
Read the manual
Height
Width
Length
Caution
Warning
Weight
Payload
Cleaning instructions
No serviceable parts
Operating temperature
Head fixing type
Colour
Dry the product after use
in wet conditions
Don’t leave in direct sunlight
Serviceable item
Drag
Counterbalance
Tilt
Diameter
Camera Plate
Do not attach items to the pan bar
No heavy items on the spreader
Tripping hazard
Ensure leg clamps are secure
Hold the pan bar
Hold the camera
Use only genuine parts
Depth
Foot type
User Level Spares
Fitting Guide Available
!
!
Read the manual
Height
Width
Length
Caution
Warning
Weight
Payload
Cleaning instructions
No serviceable parts
Serviceable item
Drag
Counterbalance
Tilt
Diameter
Camera Plate
Do not attach items to the pan bar
No heavy items on the spreader
Tripping hazard
Ensure leg clamps are secure
Hold the pan bar
Depth
!
!
Read the manual
Height
Width
Length
Caution
Warning
Weight
Payload
No serviceable parts
Drag
Counterbalance
Tilt
Diameter
Camera Plate
Do not attach items to the pan bar
No heavy items on the spreader
Tripping hazard
Depth
!
!
Read the manual
Caution
Warning
Drag
Counterbalance
SAFETY NOTICES
!
Caution
Warning
Counterbalance
Warning symbols used in these instructions
Safety warnings and cautions are included in these
instructions. These safety instructions must be followed to
!
avoid possible personal injury and avoid possible damage to
the product.
Important information on the safe installation and operation of this
product. Read this information before operating the product. Save
these instructions for future reference.
Follow all warnings marked on the product and within these
instructions.
This product is not waterproof. Do not expose this product to
rain, water, extreme humidity or moisture.
Clean using a soft damp cloth. Do not use solvents.
No regular servicing required.
Should the product become defective, contact your local
service centre.
Usage
This product is designed for use with OConnor e-series pan and tilt
heads. The product allows operators to convert analogue head output to
quadrature encoder output.
2 3
Shoulder mounts x 2.........1
Velcro® strap...............2
Screw and washer ..........3
e-Series head cable . . . . . . . . . 4
Serial number ..............5
Product compliance labels . . . . 6
Quadrature encoder output port.... 1
Power LED ....................2
Pan LED ...................... 3
Tilt LED....................... 4
Head input .................... 5
COMPONENTS AND CONNECTIONS
ELECTRICAL CONNECTIONS
OPTIONAL ITEMS
MOUNTING
e-Series head cable
1.5 m length - V3980-5052-9150
2.5 m length - V3980-5052-9250
DB15 Encoder breakout cable
V3990-5261
1
2
TOOLS REQUIRED
3 mm Allen key
4 5
STATUS LIGHTS
PIN-OUT CONNECTIONS
LED CONDITION STATUS
POWER
PAN/TILT
(ANY COLOUR)
KEY
Solid
Constant ash
Single ash
Off
5v Present
5v Not present
Normal (signal level 110% to 135%)
Optimum (signal level 90% to 110%)
Normal (signal level 70% to 90%)
Acceptable (signal level 50% to 70%)
Low (signal level <50%)
Index mark detected
Error (over signal)
Error (over speed)
Error (signal level <20%)
PIN DESCRIPTION
1
GND
2
5V
3
PAN Z-
4
PAN Z+
5
PAN B-
6
PAN B+
7
PAN A-
8
PAN A+
9
N/C
10
GND
11
5V
12
TILT Z-
13
TILT Z+
14
TILT B-
15
TILT B+
16
TILT A-
17
TILT A+
18
N/C
19
N/C
PIN DESCRIPTION
1
GND
2
+5V
3
PAN V0-
4
PAN V0+
5
PAN V1-
6
PAN V1+
7
PAN V2-
8
PAN V2+
9
TILT V0-
10
TILT V0+
11
TILT V1-
12
TILT V1+
13
TILT V2-
14
TILT V2+
15
RS232 Tx
16
RS232 Rx
6 7
!
!
Read the manual
Height
Caution
Warning
Drag
Counterbalance
Tilt
!
!
Read the manual
Height
Width
Caution
Warning
Drag
Counterbalance
Tilt
Diameter
!
!
Read the manual
Height
Width
Length
Caution
Warning
Drag
Counterbalance
Tilt
Diameter
Camera Plate
!
!
Read the manual
Height
Width
Length
Caution
Warning
Weight
Drag
Counterbalance
Tilt
Diameter
Camera Plate
Do not attach items to the pan bar
No heavy items on the spreader
Depth
Drag
Tilt
Diameter
Camera Plate
Do not attach items to the pan bar
No heavy items on the spreader
Tripping hazard
Ensure leg clamps are secure
Hold the pan bar
Hold the camera
Use only genuine parts
Service Level Spares
Power requirement
Foot type
Tiping Pedestal
User Level Spares
Fitting Guide Available
Adhesive
Hints
Heavy lift
Caution - Heavy lift
Battery
Level bubble
Click-a-part
Brands
Torque
T
Service bulletin
Maintenance manual
Video
Reference Library
Spares Library
Compliance
Lubrication
A
L
!
!
Read the manual
Height
Width
Length
Caution
Warning
Weight
Payload
Cleaning instructions
No serviceable parts
Operating temperature
Serviceable item
Drag
Counterbalance
Tilt
Diameter
Camera Plate
Do not attach items to the pan bar
No heavy items on the spreader
Tripping hazard
Ensure leg clamps are secure
Hold the pan bar
Hold the camera
Depth
GENERAL NOTICESTECHNICAL DATA AND SPARES
TECHNICAL DATA
47 mm (1.85 in.)
87 mm (3..43 in.)
113 mm (4.45 in.)
525 g (18.25 oz)
Power requirement: 5V +/- 10%, <500 mA
0 °C to +60 °C (32 °F to 140 °F)
SPARES
8 9
Fixing Spares Kit
V4082-1900
e-Series head cable (standard)
V3980-5052-9075
Declaration of Conformity
Vitec Videocom Limited declares that this product
has been manufactured in accordance with BS
EN ISO 9001:2008 and is in compliance with the
essential requirements and other relevant provisions
of the Machinery Directive 2006/42/EC. A copy of the
Declaration of Conformity is available upon request.
Caring for the environment by recycling
Waste Electrical and Electronic Equipment (WEEE)
Directive (2002/96/EC)
This symbol marked on the product or its packing
indicates that this product must not be disposed of
with general household waste. In some countries or
European Community regions, separate collection
electrical and electronic waste products. The recycling of materials will
help conserve natural resources and help prevent potentially negative
consequences for the environment and human health.
Visit our website for information on how to safely dispose of this product
and its packaging.
In countries outside the EU:
Dispose of this product at a collection point for the recycling of
electrical and electronic equipment according to your local government
regulations.
ROHS Compliance Statement
Vitec Videocom Limited is compliant with the European Union Directive
2002/95/EC Restrictions of Hazardous Substances (RoHS) that
restricts the use of hazardous substances in Electrical and Electronic
Equipment.
systems have been set up to handle the recycling of
HEADQUARTERS
2701 N. Ontario St.
Burbank, CA 91504
USA
Tel: +1 818 847 8666
Fax: +1 818 847 1205
USA
709 Executive Blvd
Valley Cottage, NY 10989
USA
Tel: +1 845 268 0100
Fax: +1 845 268 0113
UK
William Vinten Building
Western Way
Bury St Edmunds
Suffolk IP33 3TB
Tel: +44 1284 752 121
Fax: +44 1284 750 560
BRAZIL
Vitec Group Brazil
Vitec Brazil Tecnologias Ltda.
Rua Quintana, 950 - cj.32
Brooklin - São Paulo - Brasil
Cep 04569-011
Tel. +55 11 5102 4001
CHINA
Room 706, Tower B
Derun Building
YongAn Dongli A No. 8
Jianwai Ave., Chaoyang District
Beijing, China 100022
Tel: +86 10 8528 8748
Fax: +86 10 8528 8749
FRANCE
171 Avenue des Grésillons
92635 GENNEVILLIERS Cedex
France
Tel. +33 820 821 336
Fax. +33 825 826 181
GERMANY
Gebäude 16
Planiger Straße 34
55543 Bad Kreuznach
Germany
Tel. +49 671/483 43 30
Fax. +49 671/483 43 50
Erfurter Straße 16
85386 Eching
Germany
Tel. +49 89/321 58 200
Fax. +49 89/321 58 227
JAPAN
Vinten Japan KK
3-1-38 Shiba Koen
Minato-ku, Tokyo 105-0014
Japan
Tel. +81 3 5733 6410
Fax +81 3 5733 6425
SINGAPORE
6 New Industrial Road
#02-02 Hoe Huat Industrial
Building
Singapore 536199
Tel. +65 6297 5776
Fax. +65 6297 5778
OConnor
™
AVitec Group brand
Copyright © 2012 The Vitec Group plc Publication no. C1256-4980/2
Loading...
