ViewSonic ViewFun 3D Snap Digital Camera, ViewFun 3D Snap 3DSC5 Datasheet

ViewFun™ 3D Snap

3D Digital Camera

3DSC5

Take 3D pictures your way!

Now, you are in charge of exciting multi-dimension

entertainment with ViewSonic’s new ViewFun™ 3D

Snap camera. With two 5 Megapixel sensors built-

in, you can easily capture awesome 3D photos

and 3D videos. No need for special glasses, just

playback to preview in 3D instantly on the 2.4" LCD

screen. You can easily switch between 2D and 3D

with one quick click. ArcSoft® Wizard embedded

with ViewFun 3D Snap allows you to enjoy 3D

images and videos on a standard PC or notebook

with the included red/cyan glasses. Even upload

and share your videos on YouTube 3D using one

simple click with intuitive and intelligent software

included. This compact camera will make

entertaining and sharing fun in full 3D, a snap!

You Choose the Shot

Capture all the moments you cherish in full
exciting 3D. A simple click switches between
3D or 2D mode! You’ll never miss the action.
The ViewFun 3D Snap is ready to record every
precious memory in 3D. From sports events, to
your child’s soccer practice or the good times
your friends and families enjoy together, you’ll
be able to shoot and share it all with the new
ViewFun 3D Snap.

Ready For YouTube 3D or Facebook

The new ViewSonic ViewFun 3D Snap is
integrated with ArcSoft Wizard. One button
is all it takes to upload your 3D videos to
YouTube 3D or Face book. View your 3D
videos with red/cyan glasses—it’s just that
simple and fun. We make it easy to share all
your 3D images with the ViewFun 3D Snap!

See It Instantly in 3D

2.4” LCD onboard preview screen lets you
view your 3D photos or videos without the use
of 3D glasses.

3DSC5

ViewFun 3D Snap

Now Playing On Your PC or TV

3DSC5 is compatible with most new 3D HDTV’s.
With intuitive ArcSoft® software Wizard onboard
the 3DSC5, you can also easily enjoy 3D playback
on your regular 2D PC or TV with the included
red/cyan glasses.

J

K

O

P

A – Power Button

B – Shutter Button
C – 2.4" LCD Screen
D – Power Indicator Light

E – Record Video Button

F – 2D/3D Switch Button

A B

DC

L

Q

G – Control Button: Zoom In,

Zoom Out, Flash, Menu

H – Play Button
I – Delete Button
J – Battery

K – SD Cart Slot

NM

L – Lens

M – Flash
N – Lens
O – USB Port
P – Mini HD Port
Q – Speaker

3D By NVIDIA

Compatible with the NVIDIA® Vison Kit* for
awesome 3D effects using 3D shutter glasses.
* Not Included

IMAGE SENSOR 5 Megapixels;

1/2.5" CMOS (2592x1944) x2

RESOLUTION Camcorder HD 720p 30f (1280x720)

Camera 5M (2592x1944), 3M, 5M, 12M

FILE FORMAT Video MP4

Photo JPEG

VIDEO FRAME RATE 30 frames per second

3D/2D CAPTURE Switchable

E

F

G

H

I

MEMORY Internal N/A

External SD/SDHC card slot – supports
256MB up to 32GB SDHC

DISPLAY Type 2.4" 3D TFT LCD supports

3D and 2D display modes

LENS Type Fixed Focus lens x2

Focus Range 1 m – 8∞

Aperture Range F3.0

Digital Zoom 4X

MODES Night Shot Mode Automatic

White Balance Automatic

Exposure Control Automatic

Date Stamp Yes

Microphone Stereo microphone built-in

Self Timer 10 sec

Power Save Mode 3 minute

AUDIO Output Speaker 0.5w x 1

INTERFACE Output Mini HDMI, USB 2.0

Input Card Slot (SD/SDHC) x1

BATTERY NP40 720Ah Li-ion rechargeable

DIMENSIONS Physical 4.18" x 0.85" x 2.69"

(WxHxD) (106mm x 21.6mm x 68.2mm)

Packaging 6.7" x 5.2" x 3.1"
(169mm x 131mm x 79mm)

WEIGHT Net 0.3 lb. (0.12 kg)

Gross 1.0 lb. (0.45 kg)

PACKAGE CONTENTS Camera, USB extension cable,

red/cyan glasses, rechargeable
battery, strap, User’s Manual

WARRANTY 1-year limited warranty
