1. Introduction
Product Description
Congratulations on your purchase of the ViewEra V141 series LCD
monitor. It incorporates high quality display into a small light-weighted
module. It has power-saving capabilities and emits no radiation. You will
certainly benefit from this monitor in lots of ways; to name some of them:
comfort, safety, space-saving and environmental protection.
This LCD monitor incorporates 14 color active matrix
thin-film-transistor (TFT) liquid crystal display to provide superior display
performance. Its maximum resolution of XGA 1024 x 768 is ideal for
displaying complex graphics and high definition images. Its other outstanding
capabilities include audio system and OSD (On Screen Display) controls.
Package Contents
Included with your LCD monitor as following items
14 TFT LCD monitor
15 pin D-sub VGA signal cable
Audio cable
AC power cord
AC/DC Adaptor
Users manual
Product Features
High brightness, high contrast, wide viewing angle TFT LCD
display supports resolution up to XGA 1024 × 768. @ 60Hz.
Compatible with VESA standards.
Built-in speakers with volume control.
Power management system conforms to VESA DPMS standard.
Advanced OSD control for picture quality adjustment.
Slim bezel design.
4
Screen Cleaning Techniques
1. Gently clean the screen with a clean camel hair lens brush, or a soft, clean,
lint-free cloth, to remove dust and other particles that can scratch the
screen.
2. Do not apply pressure to the screen surface when wiping it clean.
3. Do not pour or spray any liquid directly onto the screen or casing. Chemical
cleaners have been reported to damage the screen or case of the LCD
monitor.
Additional
Read all of these instructions and save them for later use.
Follow all warnings and instructions on the product.
1. Product
Do not block the vent holes in the case.
Do not insert sharp objects or spill liquid into the LCD monitor
through cabinet slots. They may cause accident fire, electric shock
or failure.
Disconnect the power plug from the AC outlet if you will not use it
for an extended period of time.
Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltage points or
other risks.
Do not touch the screen directly with your fingers. You may
damage the screen, and oil from your skin is difficult to remove.
Do not apply pressure to screen. The LCD panel is very delicate.
2. Power
Use the type of power indicated on label.
3. Plugs
Do not remove any of the prongs of the monitors three-pronged
power plug.
Disconnect the power plug from the AC outlet under following
conditions
If you will not use it for an extended period time.
When the power cord or plug is damaged or frayed.
5
If the product does not operate normally when the operating
instructions are followed. Adjust only those controls that are
covered by the operating instructions. Improper adjustment of
other controls may result in damage and will often require
extensive work by a qualified technician.
If the product exhibits a distinct change in performance,
service may be required.
4. Power and extension cords
Do not allow anything to rest on the power cord.
Do not locate this product where persons will walk over the cord.
Use the proper power cord with correct attachment plug type. If the
power source is 120V AC, use a power cord that has UL and C-UL
approvals. If the power source is a 240V AC supply, use the tandem
(T blade) type attachment plug with ground conductor power cord
that meets the respective European countrys safety regulations,
such as VDE for Germany.
Do not over load wall outlets or power cords. Ensure that the total
of all units plugged into the wall outlet does not exceed 10 amperes.
Ensure that the total ampere ratings on all units plugged into the
extension cord is not above the cords rating.
If the power supply cord, which came with your monitor, is to be
connected to the PC instead of the wall outlet, Use an UL/TUV
approved computers with receptacle rated 100~240V AC, 50/60Hz,
1.0A (minimum) only.
5. Environment
Place the monitor on a flat and leveled surface.
Place the monitor in a well-ventilated place.
Keep the monitor away from:
Overly hot, cold or humid places, places directly under sunlight,
dusty surroundings, equipment that generate strong magnetic fields.
Please adjust the frequency to 60 Hz after setting up the LCD monitor.
Then push the OSD menu button and use the auto adjust function to find
the best mode of your computer.
