PHANTOM Series PS1000

25 Watt VHF/FM

Marine Transceiver

Owner's Manual

Hide away black box VHF specifically designed for vessels with limited mounting space

Supplied with a enhanced RAM+ remote control microphone

RTCM SC-101 DSC Distress call with your exact position

DSC position request/send function and NMEA data input/output to connect to GPS Plotter

DSC Group call feature included

Channel Name, GPS Time or GPS Position Repeating shown on the display

One-button access to Channel 16 and 9

NOAA Weather Alert

Versatile User-programmable Scan, Priority Scan and Dual Watch

Access to all US, Canadian and International Channels

3 year waterproof warranty

with GPS connected

Phantom PS1000

Page 1





TABLE OF CONTENTS

1

GENERAL INFORMATION ......................................................................................

4

2

PACKING LIST ........................................................................................................

4

3

OPTIONS .................................................................................................................

4

4

SAFETY / WARNING INFORMATION......................................................................

5

5

FCC RADIO LICENSE INFORMATION ...................................................................

6

6

FCC NOTICE ...........................................................................................................

7

7

GETTING STARTED ................................................................................................

8



7.1

ABOUT VHF RADIO ......................................................................................

8



7.2

SELECTING AN ANTENNA ...........................................................................

8



7.3

COAXIAL CABLE ............................................................................................

9

8

INSTALLATION ......................................................................................................

10



8.1

LOCATION .....................................................................................................

10



8.2

ELECTRICAL CONNECTIONS .....................................................................

10



8.3

CMP25 RAM+ MICROPHONE INSTALLATION ............................................

11



8.4

ACCESSORY CABLE ...................................................................................

12



8.5

CONNECTION OF GPS WITH NMEA OUTPUT ......................................

13



8.6

CHECKING GPS CONNECTIONS ..............................................................

13



8.7

CHANGING THE GPS TIME .......................................................................

14



8.8

CHANGING COG TO TRUE OR MAGNETIC ...........................................

15



8.9

CHANGING GPS INFORMATION TO VESSEL POSITION OR COG ....

15



8.10 OPTIONAL MMB-84 FLUSH MOUNT INSTALLATION ..............................

16

9

CONTROLS AND INDICATORS ............................................................................

18



9.1

PHANTOM PS1000 TRANSCEIVER ............................................................

18



9.2

CMP25 RAM+ MICROPHONE ......................................................................

20

10

BASIC OPERATION ..............................................................................................

22



10.1

RECEPTION ..................................................................................................

22



10.2

TRANSMISSION ............................................................................................

22



10.3

TRANSMIT TIME-OUT TIMER (TOT) ..........................................................

22



10.4 SIMPLEX / DUPLEX CHANNEL USE ..........................................................

23



10.5 USA, CANADA, AND INTERNATIONAL MODE ..........................................

23



10.6 NOAA WEATHER CHANNELS ....................................................................

23



10.6.1 NOAA Weather Alert ............................................................................

23



10.6.2 NOAA Weather Alert Testing ...............................................................

24



10.7 EMERGENCY (CHANNEL 16 USE) ............................................................

24



10.8

CALLING ANOTHER VESSEL (CHANNEL 16 OR 9) ................................

25



10.9

MAKING TELEPHONE CALLS ..................................................................

26



10.10 OPERATING ON CHANNELS 13 AND 67 ..............................................

26



10.11 DUAL WATCH (TO CHANNEL 16) ...........................................................

26



10.12 SCANNING ..................................................................................................

27



10.12.1 Selecting the Scan Type ......................................................................

27



10.12.2 Memory Scanning (M-SCAN) .............................................................

27



10.12.3 Priority Scanning (P-SCAN) ................................................................

28



10.13 NAVIGATION INDICATION.......................................................................

29

Page 2



Phantom PS1000





TABLE OF CONTENTS



11 DIGITAL SELECTIVE CALLING ............................................................................

30

11.1 GENERAL ......................................................................................................

30

11.2 DSC SCAN ....................................................................................................

31

11.3 MARITIME MOBILE SERVICE IDENTITY (MMSI) ........................................

32

11.3.1 What is an MMSI?.................................................................................

32

11.3.2 Programming the MMSI ......................................................................

32

11.4 DSC DISTRESS CALL .................................................................................

33

11.4.1 Tansmitting a DSC Distress Call ........................................................

33

11.4.2 Cancel a DSC Distress Call ..............................................................

34

11.4.3 Receiving a DSC Distress Call ..........................................................

34

11.4.4 Receiving a DSC Distress Relay Call...............................................

34

11.5 ALL SHIPS CALL .........................................................................................

35

11.5.1 Transmitting an All Ships Call ............................................................

35

11.5.2 Receiving an All Ships Call ...............................................................

35

11.6 INDIVIDUAL CALL ........................................................................................

36

11.6.1 Setting up the Individual / Position Call Directory .............................

36

11.6.2 Setting up Individual Ringer ...............................................................

37

11.6.3 Setting up Individual / Group Call Ringer ..........................................

37

11.6.4 Transmitting an Individual Call ...........................................................

38

11.6.5 Receiving an Individual Call ...............................................................

39

11.6.6 Setting up the Call Waiting Function ................................................

40

11.7 GROUP CALL ...............................................................................................

40

11.7.1 Setting up a Group Call .....................................................................

40

11.7.2 Transmitting a Group Call ..................................................................

41

11.7.3 Receiving a Group Call ......................................................................

42

11.8 POSITION REQUEST ...................................................................................

42

11.8.1 Setting up Position Reply ...................................................................

42

11.8.2 Transmitting a Position Request to Another Vessel.........................

43

11.8.3 Receiving a Position Request ............................................................

44

11.9 POSITION SEND ..........................................................................................

45

11.9.1 Setting up Position Send Ringer .......................................................

45

11.9.2 Transmitting a DSC Position Send Call ............................................

45

11.9.3 Receiving a DSC Position Send Call ...............................................

46

12 RADIO SETUP MODE ...........................................................................................

48

12.1 LCD DIMMER ...............................................................................................

48

12.2 LCD CONTRAST ..........................................................................................

48

12.3 TIME OFFSET ..............................................................................................

49

12.4 CHANGING GPS INFORMATION TO VESSEL POSITION OR COG .... 50

12.5 CHANGING COG TO TRUE OR MAGNETIC ................................................

50

12.6 SCAN TYPE ..................................................................................................

51

12.7 KEY BEEP (ON/OFF) ...................................................................................

51

12.8 WX ALERT (ON/OFF) ..................................................................................

52

12.9 CHANNEL NAME CHANGE ........................................................................

52

12.10 EXTERNAL SPEAKER SELECTION .........................................................

53

13 MAINTENANCE .....................................................................................................

54

13.1 REPLACEMENT PARTS ..............................................................................

54

13.2 FACTORY SERVICE ....................................................................................

54

14.3 TROUBLESHOOTING CHART ....................................................................

55

14 CHANNEL ASSIGNMENTS ...................................................................................

56

15 WARRANTY ...........................................................................................................

62

16 SPECIFICATIONS..................................................................................................

65

Phantom PS1000

Page 3

1 GENERAL INFORMATION

The Phantom PS1000 is an RTCM SC-101 DSC Hide away black box VHF specifically designed for vessels with limited mounting space. It is supplied with a RAM+ microphone that can control all radio, DSC (including Distress), from any remote location aboard, at the Nav station, cockpit, tower or lower helm station.

The Phantom PS1000 also has Standard’s DSC position polling feature, which will allows you to contact another vessel equipped with a DSC radio that has this feature and show that vessels position on the display of the RAM+. When interfaced with a Standard Horizon GPS chart plotter the polled vessels position will also show up on the display of the chart plotter.

2 PACKING LIST

When the package containing the transceiver is first opened, please check it for the following contents:

Phantom PS1000 Transceiver

CMP25 Remote-Access Microphone (RAM+ Mic, Black/White)

Power Cord

Mounting Bracket and hardware

Owner’s Manual

DSC Warning Sticker

3 OPTIONS

MMB-84 ..........................................................................

Flush-Mount Bracket

CT-100 ...............................................

23 feet Extension Cable for RAM+ Mic

MLS-310 ...........................................

External Speaker with 10 Watt Amplifier

MLS-300 .......................................................................

External Loudspeaker

101W .......................................................................

White Extension Speaker

Page 4



Phantom PS1000





4 SAFETY / WARNING INFORMATION

This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control the exposure conditions of its passengers and bystanders by maintaining the minimum separation distance of 0.6 m (2 feet).

Failure to observe these restrictions will result in exceeding the FCC RF exposure limits.

Antenna Installation:

The antenna must be located at least 0.6 m (2 feet) away from passengers in order to comply with the FCC RF exposure requirements.

ON-LINE WARRANTY REGISTRATION

Please visit www.standardhorizon.com to register the Phantom PS1000 Marine VHF. It should be noted that visiting the Web site from time to time may be beneficial to you, as new products are released they will appear on the Marine Division of Vertex Standard Web site.

PRODUCT SUPPORT INQUIRIES

If you have any questions or comments regarding the use of the Phantom PS1000, you can visit the Marine Division of Vertex Standard Web site to send an E-Mail or contact the Product Support team at 800-767- 2450 M-F 7:00-5:00PST.

Phantom PS1000



Page 5





5 FCC RADIO LICENSE INFORMATION

Vertex Standard radios comply with the Federal Communication Commission

(FCC) requirements that regulate the Maritime Radio Service.

STATION LICENSE

An FCC ship station license is no longer required for any vessel traveling in U.S. waters (except Hawaii) which is under 20 meters in length. However, any vessel required to carry a marine radio on an international voyage, carrying a HF single side band radiotelephone or marine satellite terminal is required to have a ship station license. FCC license forms, including applications for ship (506) and land station licenses can be downloaded via the Internet at www.fcc.gov/forms. To obtain a form from the FCC, call (888) 225-5322.

RADIO CALL SIGN

Currently the FCC does not require recreational boaters to have a Ship Radio Station License. The USCG recommends the boats registration number and the state to be used.

CANADIAN SHIP STATION LICENSING

You may need a license when traveling in Canada. If you do need a license contact their nearest field office or regional office or write:

Industry Canada

Radio Regulatory Branch

Attn: DOSP

300 Slater Street

Ottawa, Ontario

Canada, KIA 0C8

FCC / INDUSTRY CANADA INFORMATION

The following data pertaining to the transceiver is necessary to fill out the license application.

Type Acceptance .........................................................................

FCC Part 80

Output Power ...............................................

1 Watt (low) and 25 Watts (high)

Emission .........................................................................

16K0G3E, 16K0G2B

Frequency Range .....................................................

156.025 to 163.275 MHz

FCC Type Number....................................................................

K6630053X30

Industry Canada Type Approval .............................................

511B-30053X30

Page 6



Phantom PS1000





6 FCC NOTICE

NOTICE

Unauthorized changes or modifications to this equipment may void compliance with FCC Rules. Any change or modification must be approved in writing by Marine Division of Vertex Standard.

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Phantom PS1000



Page 7





7 GETTING STARTED

7.1 ABOUT VHF RADIO

The radio frequencies used in the VHF marine band lie between 156 and 158

MHz with some shore stations available between 161 and 163 MHz. The marine VHF band provides communications over distances that are essentially “line of sight” (VHF signals do not travel well through objects such as buildings, hills or trees). Actual transmission range depends much more on antenna type, gain and height than on the power output of the transmitter. On a fixed mount 25W radio transmission expected distances can be greater than 15 miles.

7.2 SELECTING AN ANTENNA

Marine antennas are made to radiate signals equally in all horizontal directions, but not straight up. The objective of a marine antenna is to enhance the signal toward the horizon. The degree to which this is accomplished is called the antenna’s gain. It is measured in decibels (dB) and is one of the major factors in choosing an antenna. In terms of effective radiated power (ERP), antennas are rated on the basis of how much gain they have over a theoretical antenna with zero gain. A 3 foot, 3dB gain antenna represents twice as much gain over the imaginary antenna.

Typically a 3 foot 3dB gain stainless steel whip is used on a sailboat mast. The longer 8 foot 6dB fiberglass whip is primarily used on power boats that require the additional gain.

Page 8



Phantom PS1000





7.3 COAXIAL CABLE

VHF antennas are connected to the transceiver by means of a coaxial cable – a shielded transmission line. Coaxial cable is specified by it’s diameter and construction.

For runs less than 20 feet, RG-58/U, about 1/4 inch in diameter is a good choice. For runs over 20 feet but less than 50 feet, the larger RG-8X or RG-213/U should be used for cable runs over 50 feet RG-8X should be used. For installation of the connector onto the coaxial cable refer to the figure below.

Adapter

1/16''

3/4''

3/4'' 1 1/8''

1/8''

3/8'' 5/8''

To get your coax cable through a fitting and into your boat’s interior, you may have to cut off the end plug and reattach it later. You can do this if you follow the directions that come with the connector. Be sure to make good soldered connections.

Phantom PS1000



Page 9





MLS-310 External Speaker GPS Navigation Receiver

8 INSTALLATION

8.1 LOCATION

The radio can be mounted at any angle. Choose a mounting location that:

is far enough from any compass to avoid any deviation in compass reading due to the speaker magnet

allows connection to a power source and an antenna

It is recommended not to mount the antenna closer than three feet from the Phantom PS1000.

Note: To insure the radio does not affect the compass or radios performance is not affected by the antenna location, temporarily connect the radio in the desired location and:

a.Examine the compass to see if the radio causes any deviation

b.Connect the antenna and key the radio. Check to ensure the radio is operating correctly by requesting a radio check.

8.2ELECTRICAL CONNECTIONS

CAUTION

Reverse polarity connections will damage the radio!

Connect the CMP25 RAM+ microphone, power cord, and antenna to the radio as shown bellow:

Antenna

Water proof

CMP25 RAM+ MIC

Deck Outlet

Accessory Cable

Fuse



Red Black

Power Source

Figure 1. General Installation

1.Mount the antenna at least 3 feet away from the radio. At the rear of the radio, connect the antenna cable. It must have a PL259 connector. RG-8/U coaxial cable must be used if the antenna is 25 feet or more from the radio. RG58 cable can be used for distances less than 25 feet.

Page 10

Phantom PS1000

2.Connect the red power wire to a 13.8 VDC ±20% power source. Connect the black power wire to a negative ground.

3.If an optional remote extension speaker is to be used, refer to next section for connections.

4.It is advisable to have a Certified Marine Technician check the power output and the standing wave ratio of the antenna after installation.

8.3 CMP25 RAM+ MICROPHONE INSTALLATION

1.Connect the RAM+ MIC Cable to the RAM MIC CONNECTOR on the rear panel of the Phantom PS1000, then tighten the Cable Nut (See Figure 2).

2.Referring to Figure 3, make a 1.2” (30 mm) hole in the wall, then insert the RAM+ MIC Cable into this hole. Connect the Gasket and Mount Base to the RAM+ MIC Cable Connector using the Nut.

3.Drill the four Screw holes (approx. 2 mm) on the wall, then install the Mounting Base to the wall using four screws.

4.Connect the CMP25 RAM+ Microphone to the RAM+ MIC Cable Connector. The installation is now complete.

5.Wires for a external speaker are provided on the RAM+ mic cable. Connect any 8 Ohm external speaker. When connected the RAM+ controls the volume level of this speaker.

Figure 2

EXP SP Cable for the RAM+ MIC

Wall

Gasket

Cap

RAM MIC Cable

Mounting Bracket

Nut

Figure 3

Phantom PS1000



Page 11





RAM+ or External Speaker Selection

By default the CMP25 RAM+ internal speaker is turned on, however using the

RAM+ mic this speaker can be turned off so the external speaker can be used.

1. Press and hold down the [CALL(SET)MENU] key until

RADIO SETUP” menu appears.

2.Press the [CALL(SET)MENU] key, then press the [ ] or [ ] key to select “EXT SPK” menu.

3. Press the [CALL(SET)MENU] key.

4. Press the [ ] or [ ] key to turn the External Speaker “on.” 5. Press the [CALL(SET)MENU] key to store the selected set-

ting.

6. Press the [16/9] key to return to radio operation.

8.4 ACCESSORY CABLE

Blue: NMEA IN (+) from GPS navigation receiver Green: NMEA IN (–) from GPS navigation receiver Gray: NMEA OUT (+) to GPS navigation receiver Brown: NMEA OUT (–) to GPS navigation receiver

When connecting the GPS navigation receiver, strip off about 1 inch (2.5 cm) of the specified wire’s insulation, then splice the ends together using proper waterproofing techniques.

GPS Receiver

Blue

NMEA OUT ( )

Green

NMEA OUT ( )

Gray

NMEA IN (

)

Brown

NMEA IN (

)

Wire Color/Description

Connection Examples

BLUENMEA Input (+)

Connect to NMEA (+) output of GPS

GREEN - NMEA Input (–)

Connect to NMEA (–) output of GPS

GRAYNMEA Output (+)

Connect to NMEA (+) input of GPS

BROWN-NMEA Output (–)

Connect to NMEA (–) input of GPS

Page 12



Phantom PS1000





8.5 CONNECTION OF GPS WITH NMEA OUTPUT

Manufacturer/Model

Wires

PS1000



Green

Green

STANDARD HORIZON

Blue

Gray



Brown

Blue

Furuno GP30, 36

White

Blue



Blue

Green

Furuno GP1650, 1850

White

Blue



Black

Green

Garmin Fixed Mounts

Blue

Blue









Black (GND)

Green

Garmin Portables

Brown

Blue



Black (GND)

Green

JRC GPS500

Yellow

Blue



Green

Green

JRC 100 SERIES

Green

Blue



Black

Green

JRC 200 SERIES

White

Blue









Black

Green

Lowrance Fixed Mount

White

Blue



Black (GND)

Green

Manufacturer/Model

Wires

PS1000

Lowrance Portable

Orange

Blue



Black (GND)

Green

Magellan Fixed Mount

Gray

Blue



Black (GND)

Green

Magellan Portable

Orange

Blue



Black (GND)

Green

Northstar

Yellow

Blue









Black (GND)

Green

Raytheon 420

Yellow

Blue



Brown

Green

Raytheon 520 / 620

Blue

Blue



Brown

Green

Raytheon RL SERIES

White

Blue



Brown

Green

Simrad

White

Blue



Brown

Green

Sitex Neptune, Nautilus

Gray

Blue



Brown

Green

The GPS must have the NMEA Output turned on and set to 4800 Baud in the setup menu. If there is a selection for parity select none.

For further information on interfacing /setting up your GPS. Please contact the manufacturer of the GPS receiver.

Phantom PS1000 can read NMEA-0183 version 2.0 or higher.

The NMEA supported sentences are:

Input: GLL, GGA, RMC and GNS (RMC sentence is recommended)

Output:DSC and DSE

(DSC sentences to Standard Horizon Plotter for Position Polling)

If you have further inquires, please feel free to contact Product Support at:

Phone: (800) 767-2450

Email: marinetech@vxstdusa.com

8.6 CHECKING GPS CONNECTIONS

After battery, GPS and the RAM+ microphone(s) have been connected, press the power switch on the Phantom PS1000 and press and hold the power key on a RAM+ mic, a small satellite icon will apper on the top right

corner of the LCD display. To see additional GPS information, press the [NAV] key momentarily. The Phantom PS1000 shows “time,” “latitude,” and “Longitude” alternately every two seconds.

To hide the navigation information, press the [NAV] key again.

Phantom PS1000



Page 13





8.7 CHANGING THE TIME OFFSET

A GPS supplies UTC time to the radio. To show the correct time an offset will need to be entered using the following proceedure.

1. Press and hold down the [CALL(SET)MENU] key until “RADIO SETUP” menu appears.

2. Press the [CALL(SET)MENU] key, then press the [ ] or [ ] key to select “TIME” menu.

3. Press the [CALL(SET)MENU] key.

4. Press the [ ] or [ ] key to select time offset from UTC. See illustration below to find your offset time from UTC. If “00” is assigned, the time is the same as UTC (Universal Time Coordinated or GMT Greenwich Mean Time).

5. Press the [CALL(SET)MENU] key to store the time offset. 6. Press the [16/9] key to return to radio operation.

OFFSET TIME TABLE

Page 14



Phantom PS1000





8.8 CHANGING COG TO TRUE OR MAGNETIC

Allows customizing the NAV data showing GPS Course Over Ground (COG).

Factory default is “True,” however, following the steps below the COG can be changed to “Magnetic.”

1. Press and hold down the [CALL(SET)MENU] key until “RADIO SETUP” menu appears.

2. Press the [CALL(SET)MENU] key, then press the [ ] or [ ] key to select “MAGNETIC” menu.

3. Press the [CALL(SET)MENU] key.

4. Press the [ ] or [ ] key to select “on (Magnetic)” or “of (True).”

5. Press the [CALL(SET)MENU] key to store the selected setting.

6. Press the [16/9] key to return to radio operation.

8.9 CHANGING GPS INFORMATION TO

VESSEL POSITION OR COG

Allows customizing the NAV data showing GPS Information. Factory default is “Your Vessel’s Current Position,” however, following the steps below the GPS Information can be changed to Cruise Information (COG: Course Over Ground and SOG: Speed Over Ground).”

1.Press and hold down the [CALL(SET)MENU] key until

RADIO SETUP” menu appears.

2.Press the [CALL(SET)MENU] key, then press the [ ] or [ ] key to select “NAV DISPLAY” menu.

3. Press the [CALL(SET)MENU] key.

4. Press the [ ] or [ ] key to select “Pos (Your Vessel’s Current Position)” or “Cru (Course Over Ground).”

5. Press the [CALL(SET)MENU] key to store the selected setting.

6. Press the [16/9] key to return to radio operation.

Phantom PS1000



Page 15





8.10 OPTIONAL MMB-84 FLUSH MOUNT INSTALLATION

1.To assist in flush mounting, a template has been included. Use this template to find the mounting location.

2.Use the template to mark the location where the rectangular hole is to be cut. Confirm the space behind the dash or panel is deep enough to accommodate the transceiver (at least 15 cm deep).

There should be at least 1 cm between the transceiver’s heatsink and any wiring, cables or structures.

3.Cut out the rectangular hole and insert the transceiver.

4.Fasten the brackets to the sides of the transceiver with the lock washer nut combination; so that the mounting screw base faces the mounting surface (see Figure 4).

5.Turn the adjusting screw to adjust the tension so that the transceiver is tight against the mounting surface.

Bracket

Adjusting Screw

Lock-washer nut combination

Figure 4. MMB-84 Flush Mount Installation

Page 16



Phantom PS1000





MEMO

Phantom PS1000



Page 17





9 CONTROLS AND INDICATORS

NOTE

This section defines each control, switch, and connector of the Phantom PS1000 Transceiver and CMP25 RAM+ Microphone. For detailed operating instructions refer to section “10. BASIC OPERATION.”

9.1 PHANTOM PS1000 TRANSCEIVER

























































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































Page 18





















Phantom PS1000





PWR key

NOTE

The Phantom PS1000 is designed to be flush mounted or bracket mounted in a dry cool area when there is limited mounting areas. When it is bracket mounted the power switch on the Phantom PS1000 is not used instead use the PWR key located on the top of the RAM+ mic(s).

Turns the transceiver on and off. To turn the transceiver on, press and hold this key until this switch illuminates orange. To turn it off, press and hold this key until the illumination turns off. When the power is turned on, the transceiver is set to the last selected channel.

This switch is connected in parallel with the switch with the same name on the front panel of the CMP25 RAM+ Microphone.

RAM+ MIC CONNECTOR

Connects the Phantom PS1000 to the CMP25 RAM+ Microphone.

ACCESSORY CONNECTION CABLE

Connects the Phantom PS1000 to a GPS. See section “3. OPTION” for a list of speakers STANDARD HORIZON offers.

DC INPUT CABLE

Connects the radio to a DC power supply capable of delivering 12V DC.

ANTENNA JACK

Connects an antenna to the transceiver. Use a marine VHF antenna with an impedance of 50 ohms.

Phantom PS1000



Page 19





9.2 CMP25 RAM+ MICROPHONE

SQUELCH CONTROL (SQL) Activates the squelch adjusting mode.

Press this key to activate the squelch adjusting mode. Press the [ ] or [ ] key to adjust the squelch.

VOLUME KEY (VOL)

Activates the volume adjusting mode.

Press this key to activate the volume adjusting mode. Press the [ ] or [ ] to adjust the volume.

MEM IC

SCAN DW

CALL NAV SET

MENU

WX

U.I.C

16

9

POWER SWITCH (PWR)

Press and hold down this key to turn to the transceiver and RAM+ Mic on and off.

PTT (Push-To-Talk) SWITCH

Activates transmission.

[H/L] KEY

Toggles between high and low power. When the [H/L] key is pressed while the transceiver is on channel 13 or 67, the power will temporarily switch from “LO” to “HI” power until the PTT is released. The [H/L] key does not function on transmit inhibited and low power only channels.

[ ] / [ ] KEY

These keys are used to select channels, adjust the volume and squelch level, and to choose the item selection of different functions (such as the

DSC operation).

[16/9] KEY

Immediately recalls channel 16 from any channel location. Holding down this key recalls channel 9. Pressing the [16/9] key reverts to the previous selected working channel.

Secondary use

Press and hold the [16/9] key then press the [WX] key to switch the USA,

International or Canadian channels.

Page 20



Phantom PS1000





KEY PAD

[SCAN] Key

Starts and stops scanning of programmed channels.

If held while the [ ] or [ ] key is pressed, the radio will show the channels programmed in scan memory. This function will not work if

the unit is scanning.

NOTE: The priority channel is Channel 16 only.

Secondary use

Press and hold the [SCAN] key to program the current channel into the Scan Memory.

[CALL(SET)MENU] Key

The [CALL(SET)MENU] key functions as the enter key.

Secondary use

Press the [CALL(SET)MENU] key to access the DSC OPERATION menu. The “INDIVIDUAL CALL,” “GROUP CALL,” “ALL SHIP CALL,” “POSITION REQUEST,” and “POSITION SEND” functions can be accessed from the DSC OPERATION menu.

Press and hold the [CALL(SET)MENU] key to access the RADIO SETUP (refer ro section “8. ) or DSC SETUP menu (refer ro section 7).

[DW(IC)] Key

Watches for a transmission on CH16 and another selected channel until either signal is received. (Dual watch)

NOTE: When the DSC SCANNING feature is enabled (see section “7.2 DSC SCAN”), the radio watches for a transmission on CH16, another selected channel, and CH70 until either signal is received (Triple watch).

[NAV] Key

Press the [NAV] key, when connected to the GPS receiver, the LCD displays Position Information or Cruise Information from the GPS.

[WX] Key

Immediately recalls the previously selected US NOAA weather channel from any channel location.

Secondary use

Holding down the [16/9] key while pressing the [WX] key switch the Channel Group.

[DISTRESS] KEY

Used to send a DSC Distress Call. To send the distress call refer to section “11.4.1. Transmitting a DSC Distress Call.”

Phantom PS1000



Page 21





+ 47 hidden pages
