Page 1
DutchWest
Cast Iron Non-Catalytic Wood Stoves
High marks for the lowest
emissions in the industry.
Page 2
Medium Dutchwest
Non-catalytic Wood Stove
Dutchwest Wood Stoves
Excellent EPA rating is just a start
Dutchwest non-catalytic Wood Stoves earn high marks with the EPA for their
outstanding emissions performance. In fact, Dutchwest stoves are among the
cleanest in the wood stove industry with emissions of less than 1.5 grams/hr.!
Combine that with classic styling, sturdy cast iron construction, remarkable
state-of-the-art features and efficiency, and you have a wood stove that canʼt be
beat!
Three sizes are available (small, medium and large) to suit any heating need.
Convenient
side-loading
Large glass front doors allow for maximum viewing and an optional convection
air blower augments the superior radiant heating ability of cast iron construction
to deliver heat throughout your home.
Page 3
The EVERBURN System
This system is designed to produce cleaner
emissions and longer burn times, similar to
a catalytic system. Gases produced from
burning wood are mixed with just the right amount of air to ensure
hey are burned completely, producing clean emissions and efficient
t
warmth. The state-of-the-art design of the EVERBURN non-catalytic
Combustion System enables our Dutchwest Cast Iron stoves to burn
more steadily and longer on a single load of wood compared to other
non-catalytic stoves.
Non-catalytic Wood Stove
Large Dutchwest
Dutchwest Advantages
• EVERBURN non-catalytic combustion system – A stable long burning non-catalytic combustion system with similar
emissions to a catalytic woodstove, as low as 1.31 grams/hr.
• Durable refractory lining provides a durable insulated firebox while protecting the stoveʼs cast iron parts.
• Front & side-loading – The stoves convenient side loading feature provides easy access when loading the stove.
• Leg levelers – Allows the stove to be installed on uneven or rough surfaces.
• Ash pan – Convenient ash disposal.
• “Fall away” handle – Cool to the touch “fall away” handles are easily stowed at the side of the stove.
• Ash lip – Large ash lip adds to the stoves cleanliness by catching ashes when using the front-loading door.
• Large glass – Large clean glass area.
• Top and rear reversible flue collar – The top and rear reversible flue collar design allows you to choose between the
top and rear venting configurations.
• 100% outside air connection standard – An outside air connection with a 3-inch diameter equipment connection
flange is standard with the stove. A 3-inch outside air kit is required to complete outside air installation. The 100%
outside air connection ensures that all of the air necessary to support combustion in the stove is taken from outside
the home. No room air is used to support the fire.
• Beautiful andirons. Besides their decorative appeal, they help contain wood load.
Optional Accessories:
• Fan kit with rheostat
• Side heat shield
• Flue collar heat shield
• Outside air termination kit
• Mobile home kit - 2477 stove only (U.S. and Canada)
Page 4
utchwest Cast Iron Non-Catalytic Wood Stoves
D
odels • 2477 • 2478 • 2479
M
Ser i ous S t ove s for Ser i o us H e atin g
he Dutchwest Non-catalytic Wood Stove line combines classic styling and innovation with solid cast iron
T
construction. Three sizes are available (small, medium and large) to suit any heating need. Large glass
front doors allow for maximum viewing and our unique fan system provides the smartest heat distribution ever.
MODEL Small (2477) Medium (2 4 7 8 ) L a rge (2479)
A 24" (610 mm) 26³ ⁄₄" (683 mm) 29¹⁄ ₄" (743 mm)
B 24¹⁄₂ " (622 mm) 27¹⁄ ₄" (695 mm) 29³⁄₄" (756 mm)
C 29³⁄₄ " (756 mm) 29³⁄₄" (756 mm) 3 2¹⁄₂ " (826 mm)
D 23" (584 mm) 2 3" (584 mm) 24¹⁄ ₂" (622 mm)
E 17¹ ⁄₂" (445 mm) 17 ¹⁄₂" (445 mm) 19 " (483 mm)
F 27 " (686 mm) 2 7¹⁄₄" (692 mm) 30 ¹⁄₄" (768 mm)
G 30¹⁄₂" (775 mm) 30¹⁄ ₂" (775 mm) 34" (864 mm)
H 5³⁄₄" (146 mm) 5³⁄₄ " (146 mm) 5³⁄₄ " (146 mm)
DW Cast Small (2477) DW Cast Medium (2478) DW Cast Large (2479)
Maximum Heat Output 35,000 BTU's/hr. 40,000 BTU's/hr. 55,000 BTU's/hr.
Efficiency Rating 63%* 63%* 63%*
EPA Emissions Rating** 1.41 grams/hr. 1.49 grams/hr. 1.31 grams/hr.
Heating Capacity 700-1,400 sq. ft. 800-1,600 sq. ft. 1,000-2,400 sq. ft.
Wood Capacity # of lbs. 20-25 lbs. 25-30 lbs. 30-35 lbs.
Log Size (inches) 19” 20-22” 22-24”
Burn Time Up to 8 hrs. Up to 10 hrs. Up to 14 hrs.
Flue Collar Size 6” 6” 6”
Bottom Heat Shield YES YES YES
* Efficiency rating for these models is the EPA default figure
** Under specific conditions used during EPA emissions testing
CENTER OF FLUE COLLAR, REAR EXIT
DUTCHWEST NON-CATALYTIC WOOD STOVES
YOU R DE ALE R
© 2007 CFM Corporation - All rights reserved. Dutchwest by Vermont Castings®is a registered trademark of
CFM Corporation. In the interest of constant product improvements, we reserve the right to change specifications
without notice. Before installations, please read Installation Instructions and check all local Building Codes and Gas
Regulations. Please see your Dealer or visit www.vermontcastings.com for complete warranty information.
GK004-1000-9116
