Venta LP60, LPH60, LW62, LW62T, LW60T User Manual
...
RAUMLUFTEXPERTEN SEIT 1981
LP60
EN USER MANUAL
FR MODE D‘EMPLOI
ES MANUAL DEL USUARIO
PL INSTRUKCJA OBSŁUGI
Made in Germany
Premium Qualität
EN
Please note the fold-out
pages!
FR
Respecter les consignes des
pages dépliantes !
ES
¡Tenga en cuenta las páginas
desplegables!
PL
Proszę zwrócić uwagę na
rozkładane strony!
Page 1
Page 1
Página 1
Strona 1
EG-Konformitätserklärung
Declaration of conformity
Der Hersteller / Inverkehrbringer
The manufacturer / distributor
Name / Anschrift:
Name / adress
Venta-Luftwäscher GmbH
Weltestr. 5
88250 Weingarten
erklärt hiermit, dass folgende Produkte in der gelieferten Ausführung
hereby declares that the following products
Produktbezeichnung:
Product
Typenbezeichnung:
Typ e
Luftreiniger / Luftbefeuchter
Air Pur ier / Humi dier
LP60; LPH60 // LW60T, LW62T, LW62
Seriennummer:
Serial number
LP60:
LPH60:
from 16xxxxxxx
from 16xxxxxxx
LW60T: from 16xxxxxxx
LW62T: from 16xxxxxxx
LW62: from 17xxxxxxx
ab Herstellungsdatum:
Production date
01/2017
den Bestimmungen folgender EU-Richtlinien entspricht:
comply with the following EU directives
2014/3 0/EU EMC
2014/35/EU LVD
2014/53/EU RED
Folgende harmonisierte Normen wurden angewendet:
The following standards are consider ed:
EN 55014-1:2006 + A1:2009
+ A2:2011 CISPR 14-1:2016
EN 55014-2:2015
CISPR 14-2 (ed.2):2015
EN 60335-2-98:2003+A1:05+A2:08
EN 60335-2-65:2003+A1:08+A11:12
EN 60335 -1:2012
EN 62233:2008
ETSI EN 301 489-17 V2.2.1:2012
Diese EG-Konformitätserklärung verliert ihre Gültigkeit, wenn das Produkt ohne
Zustimmung umgebaut oder verändert wird.
This EC- declaration becomes invalid if the product is altered or modied without per mission.
Weingarten, 01.02.2018
Ort, Datum Unterschrift
Place, D ate Signature
1
2
7
3
4
5
6
1.
2.
0201
8
9
10
11
12
03
04
04
06
05
BA
THANK YOU!
We are convinced that the Venta Purier will exceed your expectations and we
hope you enjoy our product.
PLEASE register your Venta:
www.venta-luftwaescher.de/produktregistrierung-deutschland
Please read these operating instructions completely, keep them for later use, and
follow the safety instructions.
The most current version of the operating manual can be found on
our website at www.venta-luftwaescher.de
TABLE OF CONTENTS
Scope of delivery 1
Symbols 1
Safety instructions 2
Intended use 3
Technical data 3
Overview 4
Putting into operation 4
Functions, settings & displays 5
Troubleshooting 6
Cleaning & maintenance 6
Accessories 7
Venta fragrances 7
About your privacy 7
Guarantee 8
Disposal 8
SCOPE OF DELIVERY
1 × Venta Purier LP60
2 × Premium VENTAcel H13 lter
(pre-assembled)
2 × Pre-lter (pre-assembled)
1 × Remote control
If any parts are missing or damaged,
please contact
service@venta-luftwaescher.de
1 EN
SYMBOLS
Please read these operating in-
structions carefully and keep
them for later use.
Attention! Danger of accident
and injury as well as property
damage possible.
Do not use the appliance out-
doors or in damp locations.
SAFETY INSTRUCTIONS
∙ This appliance is not suitable for use
by children over the age of 8 years
and people with restricted physical,
sensory, or mental capacities or lack
of experience and knowledge unless
they are supervised or have received
instructions on the use of the appliance and understand the existing
hazards.
∙ The appliance is not a toy for children.
∙ Cleaning and user maintenance may
not be performed by children under
the age of 8 years or without supervision.
∙ Keep the appliance and its power ca-
ble out of the reach of children under
the age of 8 years.
∙ Improper use can damage the appli-
ance and cause physical injuries.
∙ Read the operating instructions com-
pletely before putting the appliance
into operation and keep them for later
reference.
∙ Plug the appliance into suitable power
outlets only – the mains voltage must
correspond to the nameplate data on
the appliance.
∙ Disconnect the power plug before
every cleaning or maintenance operation or transportation of the appliance.
∙ Never use the Purier if it has a dam-
aged power cable.
∙ Spare power cables must conform
with the type ‘cold device plug with
clover leaf coupling IEC 320 C5’
dropped or damaged in any other
way.
∙ Electrical appliances should only be
repaired by professional specialists.
Amateur repairs could result in considerable danger to the user.
∙ Do not sit on the appliance and do
not place any objects on it.
∙ Do not put any foreign objects into
the appliance.
∙ Do not immerse the appliance in
water or any other liquid.
∙ Never disconnect the power plug by
pulling on the cable or disconnect the
power plug from the power supply
outlet with wet hands.
∙ The Purier should only be operated
when it is completely assembled.
∙ Place the Purier on a stable surface
which is at and dry.
∙ Ensure that the appliance is spaced
at least 20 cm away from and 50 cm
above any other objects, such as furniture and walls.
∙ Set up the device so that it cannot be
knocked over, and so that no one can
trip over it or its cable.
∙ Disconnect the power plug from the
power supply outlet when the appliance is not in use.
∙ Never cover or block the vents to pre-
vent overheating/damage to the appliance.
∙ Never use the Purier if it has been
2GBVenta LP60
INTENDED USE
The Venta Purier is a domestic appliance for cleansing the air in homes, o-
ces and leisure facilities.
Using the appliance for something
other than the intended purpose can
endanger health and lives. This includes
use under the following conditions:
The appliance is not suitable for outdoor
areas.
∙ in rooms or locations where there is
risk of explosion and/or where there
Any other use or modication of the appliance is considered to be improper
use. The manufacturer is not liable for
any damage or injuries resulting from
improper use.
is an aggressive atmosphere.
∙ in rooms where there is a high con-
centration of solvents.
∙ in the vicinity of swimming pools or
other wet areas.
TECHNICAL DATA
Model LP60
For rooms* ≤ 75 m²
Mains voltage 220-24 0 V 50 /
Speeds 5
60 Hz
Sound level 19/ 29 /40/4 6/ 51 d B( A)
Dimensions 61 × 30 × 52 cm
Weight approx. 13 kg
Motor output approx. 7/8/14/21/33 W
Boost 60 dB(A) & 59 W
Premium VENTAcel H13 Filter ≥ 99.95 % total ltration capacity down
to 0,07 microns
* based on a ceiling height at a max of 2,5 m,
Room size conformity depending on the room air pollution:
- Light room air pollution: Room size conformity up to approx. 75 m² (> AQI 0 – 100)
- Medium room air pollution: Room size conformity up to approx. 50 m² (> AQI 101 – 200)
- Severe room air pollution: Room size conformity up to approx. 25 m² (> AQI 201 – 500)
3 GB
OVERVIEW
1 Display
2 On/o switch
3 Fragrance/lter compartment
4 Fragrance holder
5 Pre-lter
6 Premium VENTAcel H13 Filter
01 06
01 Unpack the appliance and set it up. Open the fragrance/lter compartment
02 Re-insert the VENTAcel lter 6+10 and pre-lter 5+9.
03 Close the fragrance/lter compartment 3+7.
04 Inserting the fragrance: Open the fragrance/lter compartment 3 or 7.
PUTTING INTO OPERATION
Attention! Make sure that the appliance is switched o and the
power plug is disconnected.
3+7, remove the pre-lter 5+9, the VENTAcel lter 6+10 and unpack them.
Twist open the fragrance cap and insert it into the fragrance holder 4/8.
Insert up to three fragrances into the fragrance holder 4+8. Close the
fragrance/lter compartment 3/7.
7 Fragrance/lter compartment
8 Fragrance holder
9 Pre-lter
10 Premium VENTAcel H13 Filter
11 Cable compartment
12 Remote control
05 The display 1 can be adjusted to three positions.
06 The power cable can be adjusted to the desired length by winding it up in
the cable compartment 11
Attention! The coupling of the mains cable must be plugged rmly into the
device!
Please remove the protective foil for
battery and remote control.
Connect the power plug and switch on the
appliance at the on/o switch 2 or with the
remote control 12.
ON/OFF
Set fan stage
4GBVenta LP60
FUNCTIONS, SETTINGS & DISPLAYS
FI LTER
CHANGE
1
TEMPERATURE
2
3
4
SPEED 3
BOOST ON
TIMER 1 h
°C
OK
AIR QUALITY
OFF
AUTO
SLEEP MODEOFF
CHILD LOCKOFF
5
6
7
8
9
The preferred setting can be selected or changed by briey touching the respective
function.
Function Setting
1 Temperature Display temperature. Hold for 3 sec. to switch back and
forth between °C and °F.
2 Speed Fan stage 1 (weak) – 5 (strong).
3 Boost OFF/ON
Max. purifying capacity
4 Timer OFF / 1 / 3 / 5 / 7 / 9 h (hours)
The appliance shuts o automatically after the preset hours
have expired.
5 Air quality RED (poor) – GREEN (very good)
6 Auto OFF Appliance operates with preset fan stage 1 – 5.
ON The appliance automatically regulates the fan stages
depending on the air quality in the room.
7 Sleep mode OFF/ON
Appliance reduces the fan stage to 1 and dims the display.
5 GB
8 Child lock OFF/ON
Hold for 3 sec. to activate/deactivate the key lock.
9 Notes Display and conrmation of information messages.
A B
Note/Interval Actions
A Filter Change Open the fragrance/lter compartment 3+7, remove
B Recommendation:
CLEANING & MAINTENANCE
Attention! Make sure that the appliance is switched o and the
power plug is disconnected.
the pre-lter 5+9. Remove the VENTAcel lter 6+10
and replace it. Re-assemble the device and touch
the OK indicator in the display again and hold it for 3
seconds until it disappears.
The lifespan of the VENTAcel lter is 1 year (with 24/7 operation) and
depends on the number of operating hours and the air quality in the room
(a reminder will appear on the interactive display).
Open the fragrance/lter compartment 3+7, remove the
every 1–2 months
or as required
pre-lter 5+9 and vacuum or rinse it o. Please note: the
pre-lter must be completely dry before it is installed.
Re-assemble the appliance.
TROUBLESHOOTING
Problem Solution
Appliance does not function. Connect the power plug.
Connect the power cable coupling to the
appliance.
Please contact VENTA customer service if you are unable to eliminate a problem
with the help of this information:
Tel. +49 751 5008 88
service@venta-luftwaescher.de
6GBVenta LP60
ACCESSORIES
Item Packaging unit/(pcs.)
Filter
Premium VENTAcel H13 lter
VENTAcel lter
VENTAcarb lter
VENTAcel & VENTAcarb Filterset
Fragrances 3
Accessories can be purchased through participating retailers or directly from
Venta Airwasher.
1 / 2
1
1
1
VENTA FRAGRANCES
Distinctive fragrances are specially developed and formulated for Venta Luft-
wäscher GmbH. These fragrances are made of 100 % essential oils and scents
inspired by nature.
Application area: use only in the provided fragrance holder of the Airwasher/
Purier (LW60T WiFi, LW62 WiFi, LW62T WiFi, LP60 WiFi, LPH60 WiFi). Please
adhere to the directions in the operating manual. Do not use force to open the
fragrance Puri-Pod. Waste disposal: you may dispose of depleted fragrance PuriPods in your household waste. Shelf life: After opening, use within 20 days. Dosage: the intensity of the fragrance can be adjusted by turning the fragrance cap.
ABOUT YOUR PRIVACY
Your information will be held by Venta Luftwäscher GmbH for marketing and
servicing purposes. If your personal details change, if you change your mind
about any of your marketing preferences or if you have any queries about how
we use your information, please let us know by contacting
Venta Luftwäscher GmbH Weltestraße 5 88250 Weingarten Germany,
or by calling the VentaCare Customer Service:
+49 751 5008 88.
Or you can email us at service@venta-luftwaescher.de
For more information on how we protect your privacy, please see our privacy
policy on www.venta-luftwaescher.de
7 GB
Loading...
