THANK YOU!
We are convinced that the Venta Airwasher will exceed your expectations and we
hope you enjoy our product.
Please read these operating instructions completely, keep them for later use, and
follow the safety instructions.
TABLE OF CONTENTS
Scope of delivery 1
Symbols 1
Safety instructions 2
Overview 6
Intended use 6
Putting into operation 7
Functions & settings 8
WiFi setup 9
Venta app 10
Cleaning & maintenance 11
Troubleshooting 12
Technical data 12
Accessories 13
Venta Aromatherapy 13
About your privacy 13
Service Option: Venta Airwasher 14
Warranty 14
SCOPE OF DELIVERY
1 × Venta Airwasher Kuube XL-T
1 × Hygiene Disc (pre-assembled)
1 × UVC lamp (pre-assembled)
1 × Remote control
If any parts are missing or damaged,
please contact
Venta Air Technologies Inc.
at (888) 333 8218 or
www.venta-usa.com
1 US
SYMBOLS
Please read these operating
instructions carefully and keep
them for later use.
Attention! Danger of accident
and injury as well as property damage possible.
Do not use the appliance
outdoors or in damp locations.
READ ALL INSTRUCTIONS: IMPORTANT
SAFEGUARDS | WARNING!
∙ It is important that you read, fully un-
derstand, and observe the following
safety precautions and warnings.
Read these instructions periodically.
Careless or improper use of your
Venta Airwasher may cause serious
or even fatal injury. Keep this User
Manual with your Airwasher. Be sure
anyone using your Airwasher understands the information contained in
this manual.
∙ Children should not be allowed to op-
erate the Airwasher.
∙ Always switch the motor o and un-
plug the power cord from the AC
outlet before relling it with water or
Venta Cleaner, or before moving, or
handling the unit.
∙ Plug into 120 V AC outlet only. Do not
use your Airwasher if the power cord
or plug is damaged. Unplug a damaged power cord immediately from
the AC outlet and let it replace only
by Venta. Do not replace a damaged
power cord by yourself.
∙ Do not attempt any repair work. Main-
tenance or servicing the Venta Airwasher, other than described in this
user manual, should only be done by
Venta. Any modication to your Venta
Airwasher is extremely dangerous
and voids your warranty.
∙ Do not insert any objects into the air
intake of the unit. It may damage the
fan blades or cause injuries. After the
motor is switched o, the fan continues to rotate for a short period of
time.
∙ Do not use or store this product
where it can fall or be pulled into a
bath tub, sink, water, or other liquid.
Do not reach for a unit that has fallen
into water or other liquid. Do not immerse in water or other liquid, even
when the unit is unplugged at that
time. Moisture can cause an electric
shock hazard when the unit is again
plugged into the AC outlet. Wipe
moisture o the unit with a dry cloth.
Do not handle the power cord or the
unit with wet hands.
∙ Use only genuine Venta fragrances.
∙ Do not add fragrance oil to the water.
This may impair the function of the
Hygiene Disc.
∙ Only use original Venta additives.
Venta Air Technologies Inc. accepts
no liability for damage which may be
caused by the use of other additives.
∙ Never overll the Airwasher.
∙ Never transport or overbalance the
Airwasher with a lled water basin.
Read and follow separate instructions and Warnings for Venta Hygiene
Disc, Venta Cleaner and Venta Fragrances. Please contact Venta Air
Technologies Inc. at (888) 333 8218
or www.venta-usa.com for additional
information.
Please visit our website
(www.venta-usa.com) to check for the
latest version of this User Manual.
2USVenta Kuube XL-T
SAFETY PRECAUTIONS
FOR INSTALLATION / WARNING
∙ Plug the power cord into a wall socket
with the power specications of the
product or higher and use the socket
for this appliance only. In addition, do
not use an extension cord.
Sharing a wall socket with other appliances using a multi outlet power strip
or extending the power cord may re-
sult in electric shock or re.
Do not use an electric transformer. It
may result in electric shock or re.
If the voltage/frequency/rated current
condition is dierent, it may cause
electric shock or re.
FOR INSTALLATION / WARNING
∙ Do not install this appliance near a
heater, inammable material. Do not
install this appliance in a humid, oily or
dusty location, in a location exposed
to direct sunlight and water (rain
drops). Do not install this appliance in
a location where gas may leak.
Failure to do so may result in electric
shock or re.
FOR INSTALLATION / CAUTION
∙ The appliance should be installed in
a place where the power cord of the
product can be easily pulled out.
Failure to do so may result in electric
shock or re due to electric leakage.
∙ Install your appliance on a level and
hard oor that can support its weight.
Failure to do so may result in abnormal vibrations, noise, or problems
with the product.
∙ There should be over 6 in. space
around the appliance.
If space for air intake is not enough,
humidication capacity may decrease.
If the appliance is too near wall side,
the wall paper may get damaged.
∙ When installing the product, make
sure that no heavy objects are on the
power cord.
Failure to do so may result in electric
shock or re.
FOR POWER CORD / WARNING
∙ Unplug the product, and then remove
foreign substances (dust, moisture,
etc.) of the power plug terminal or
power plug connection part with a
dry cloth on a regular basis.
Otherwise, electric shock or re may
occur.
∙ When the product, power plug or
power cord is damaged, contact your
nearest service center.
∙ Plug the power plug into the wall
socket rmly. Do not use a damaged
power plug, damaged power cord or
loose wall socket.
Failure to do so may result in electric
shock or re.
∙ When unplugging the product, do not
pull the power cord. Grip the power
plug, and then pull the power plug.
Otherwise, electric shock or re may
occur.
∙ Do not pull or excessively bend the
power cord. Do not twist or tie the
power cord.
∙ Do not hook the power line over a met-
al object, place a heavy object on the
power cord, insert the power line between objects, or push the power cord
into the space behind the appliance.
This may result in electric shock or re.
3 US
FOR POWER CORD / CAUTION
∙ When the Airwasher will not be used
for a long period of time or during a
thunder or lightning storm, disconnect the power supply.
Failure to do so may result in electric
shock or re.
∙ It is dangerous when the power cable
gets damaged, therefore contact a
service center or qualied experts for
the repair.
SAFETY PRECAUTIONS
FOR OPERATION /WARNING
∙ If the appliance is ooded, turn o the
appliance and contact a service center.
∙ If the appliance generates a strange
noise, a burning smell or smoke, disconnect the power supply immediately and contact a service center.
Failure to do so may result in electric
shock or re.
∙ When gases (city gas, profane gas,
etc.) leak, do not touch the power
cord. Immediately ventilate the area
and contact a service center or a
qualied technician.
Do not use a ventilating fan.
If there is a spark, explosion or re
may occu r.
∙ Do not unplug the appliance during
operation.
When plugging the appliance in again,
ame may occur and it may result in
electric shock or re.
∙ When a repair is needed, contact the
service center.
∙ Failure to do so may result in a pro-
duct malfunction, water leakage,
electric shock or re.
∙ Do not touch the power plug with wet
hands.
This may result in electric shock.
∙ Do not apply a force to or pull the
product using excessive force.
This may result in re, injury, or a
problem with the product.
∙ After unpacking the Airwasher, keep
all packaging materials out of the
reach of children.
If a child places a bag over its head, it
may suocate.
∙ Do not insert your ngers or a foreign
substance into the air inlet or outlet.
Take special care that children do not
injure themselves by inserting their
ngers into the product.
∙ Do not place an object near the out-
door unit that makes it possible for
children to climb onto the machine.
The child could fall and injure them-
selves or the product may fall over
and injure the child.
∙ Do not put other foreign materials
such as metal into the product.
This may result in electric shock or injury.
∙ If water has entered the power supply
module, unplug the power cable and
dry the product completely before use.
Failure to do so may result in electric
shock or re.
∙ Do not place heavy objects on the
product.
Failure to do so may result in a prod-
uct malfunction or noise.
∙ Do not attempt to repair, disassem-
ble, or modify the product yourself.
Failure to do so may result in electric
shock, re, a product malfunction or injury.
4USVenta Kuube XL-T
∙ If a foreign substance such as water
has entered the product, disconnect
the power supply and contact the
service center.
Failure to do so may result in electric
shock or re.
SAFETY PRECAUTIONS
FOR OPERATION / CAUTION
∙ Keep a distance of about 6.6 ft. from
other electric appliances such as a
TV, video or audio device etc.
Failure to do so may result in reduced
video quality or noise.
∙ Leave a space greater than 2 in. (6 in.
or more is recommended) between
the product and the wall.
∙ Do not spray volatile material such as
insecticide onto the product.
∙ As well as being harmful to humans,
this may also result in electric shock,
re or a product malfunctions.
∙ Do not tilt or turn the product upside
down while the product is connected
to the wall outlet.
Failure to do so may result in a mal-
function or re.
∙ Do not put the product into water.
This may result in a product malfunction
∙ Do not place the product on the edge
of a desk or table.
∙ Do not stand on top of the product or
place objects (such as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the
product.
This may result in electric shock, re,
a product malfunction or injury.
∙ Do not operate the product with wet
hands.
This may result in electric shock.
∙ This appliance is not intended for use
by persons with reduced physical,
sensory or mental capabilities, or lack
of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
∙ For use in Europe: This appliance can
be used by persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Chil-
dren shall not play with the appliance.
∙ Do not look directly at the UVC light.
∙ Do not manipulate the UVC unit in any
way.
∙ Never operate the device in case of a
defective cable or damaged UVC tube.
FOR CLEANING / WARNING
∙ Do not clean the product by spray-
ing water directly onto it. Do not use
benzene, thinner, acetone or alcohol
to clean the product.
This may result in discoloration, defor-
mation, damage, electric shock or re.
∙ Disconnect the power cord and stop
the fan operation before cleaning the
product.
Failure to do so may result in electric
shock or re.
5 US
OVERVIEW
1 Display
2 On/o switch
3 Evaporator compartment
4 Water tank
5 Disc stack
6 Water basin
7 Fragrance compartment
8 Fragrance holder
9 UVC lamp
10 Cable compartment
11 Hygiene Disc (pre-assembled)
12 Remote control
13 Transportation wheels
CHECK BEFORE USE
INSTALL ATION STATUS
Ensure that the following installation requirements have been satised.
∙ The product should be installed on an even, level oor.
∙ There should be no objects blocking the air intake and outlet.
∙ The installation site should be dry and there should be no inammable
substances around it.
∙ The product should be installed at least 2 in. (6 in. is recommended) from
the wall.
∙ When replacing the integrated Hygiene Disc, make sure to remove the plastic
packaging of the new Hygiene Disc.
POWER CORD AND POWER OUTLET
∙ Be sure to use a dedicated 120 V electrical outlet. (When the power is applied,
the product enters the standby state.)
∙ Unplug the power cord if it will not be used for a long period of time.
6USVenta Kuube XL-T
01 08
01 Unpack the appliance and set it up.
02 Open the evaporator compartment 3 and remove the water tank 4.
03 Open the water tank 4 and ll up to the MAX marker with water.
04 Close the water tank 4 securely.
05 Insert the water tank 4 into the water basin 6 and close the evaporator
06 Inserting the fragrance: Open the fragrance compartment 7. Twist open the
07 The display 1 can be adjusted to three positions.
08 The power cable can be adjusted to the desired length by winding it up in
PUTTING INTO OPERATION
Attention!
Make sure that the appliance is switched o and the power cord is
disconnected.
compartment 3.
fragrance cap and insert it into the fragrance holder 8. Insert up to three
fragrances into the fragrance holder 8. Close the fragrance compartment 7.
the cable compartment 10.
Move the appliance with the transportation wheels 13 to the desired place.
Lift the appliance slightly on the right sight.
Attention! The coupling of the mains cable must be plugged rmly into the device!
Please remove the protective foil for battery and remote
control of the remote control.
Connect the power plug and switch on the appliance
at the on/o switch 2 or with the remote control 12.
ATTENTION! It may take about a minute for the device
to start and for the “Fill Tank” indicator in red or yellow to
be extinguished. A gurgling sound may be heard, but this does not represent a
quality defect.
Description of UVC lamp
The Airwasher features a built-in UVC lamp 9. The UVC lamp is designed for a
hygienically awless operation of the Airwasher and prevents the formation of
germs and bacteria in the water. It is active for 4 hours a day.
Attention! Disconnect from the mains before performing any cleaning work. Do
not look directly at the UVC light.
7 US
ON/OFF
Set fan stage
FUNCTIONS, SETTINGS & DISPLAYS
FILL TANK
CHANGE HYGIENE DISC
CLEANING
CLOSE DOOR
1
HUMIDITY
%
TEMPERATURE
5
°F
2
3
4
SPEED 3
HUMIDITY 50%
TIMER 1h
10
OK
SLEEP MODEOFF
CLEANING
9 11
AUTOOFF
CHILD LOCKON
The preferred setting can be selected or changed by briey touching the
respective function.
Function Setting
1 Air humidity Display air humidity.
2 Speed Fan stage 1 (weak) – 5 (strong).
3 Humidity 30 - 70 % (in 5 % increments) If the specied
humidity is reached, the disc stack will not turn.
4 Timer OFF / 1 / 3 / 5 / 7 / 9 h (hours)
The appliance shuts o automatically after the preset hours have expired.
5 Temperature /
Comfort zone
Temperature: Hold for 3 sec. to switch back and
forth between °F and °C.
Comfort zone: If the white dot is moving inside the
green circle, the relative humidity and room temperature will be in the „comfort zone“ where one can
feel comfortable.
6
7
8
6 Auto OFF Appliance operates with preset fan stage 1 – 5.
ON The appliance automatically regulates the fan
stages depending on the air quality in the room.
8USVenta Kuube XL-T
7 Sleep mode OFF/ON Appliance reduces the fan stage to 1 and
dims the display. The fan power can be manually
changed if desired.
8 Child lock OFF/ON
Hold for 3 sec. to activate/deactivate the key lock.
9 Cleaning Cleaning program
The cleaning process requires (1) 8.5 . oz bottle of
Venta Cleaner. Please follow the instructions on the
display. Duration approx. 4 h.
10 Notes Display and conrmation of information messages.
11 WiFi Display and setup of WiFi connection.
grey: WiFi disabled
green: WiFi connected, local
blue: WiFi connected, full access
red: WiFi disconnected. Please check the WiFi
conguration for network and login data. Follow the
instructions on WiFi setup.
WIFI SETUP
WIFI CONFIGURATION
WIRELESS NETWORK
Select network:
VE NTA
LOGIN CREDENTIALS
Security type:
PSK:
Access:
WPA / WPA2
***********
INTERNET ACCESS
full access
CONNECTCLOSE
Holding WiFi display 11 for three seconds will bring up the WiFi conguration.
Choose your network from the “Select network” drop-down list. The “Security
type” is set automatically as soon as the network is selected. Enter your WiFi
password/WiFi security code into the “PSK” eld (ASCII input mode) and conrm
9 US
it with the ENTER key. If your password contains special characters that are not
represented on the keyboard, you can generate your entire password as a HEX
code at the following website: www.venta-usa.com
Now enter your generated HEX code into the “PSK” eld (HEX input mode) and
conrm it with the ENTER key. Under “Access”, select the internet access privile-
ges you desire.
full access: Access to all convenience functions in the app.
local access: local access to app use.
To establish a WiFi connection, conrm with the CONNECT button.
Green WiFi display: WiFi connection established (local access)
Blue WiFi display: WiFi connection established (full access)
Red WiFi display: no WiFi connection. Double-check your network and WiFi
password.
Grey WiFi display: WiFi disabled
Actuating the CLOSE button calls up the device’s control panel.
WiFi can be enabled or disabled by touching the WiFi display 11 on the appliance. If WiFi is disabled, the appliance will not connect to the Venta app.
VENTA APP
The device functions can be expanded and
controlled with the Venta app. The Venta app
is available for smartphones and tablets. You
can download the Venta app at the following
website: www.venta-usa.com or
Then follow the instructions on your smartphone/tablet screen. When a connection is being established between the app and the device, a signal tone is
emitted. Now conrm connection establishment to your smartphone/tablet on
your device.
WIFI-AUTHORISATION
INCOMING WIFI REQUEST.
<Your Venta-App Connection>
ALLOW ACCESS?
YES NO
10USVenta Kuube XL-T
A B
Note/Interval Actions
A Fill Tank Water tank 4 empty, ll with fresh water. Yellow: hu-
CLEANING & MAINTENANCE
Transportation WARNING! Always switch o the motor and unplug
the power cord from the A/C outlet before moving the Venta Air-
wa s he r.
midication is still taking place. Red: no humidication
is taking place.
Cleaning The cleaning process requires (1) 8.5 . oz. bottle of
Venta Cleaner. Please run the cleaning program by
pressing the button CLEANING 9. Please follow the
instructions on the display. Duration approx. 4 h.
Attention! Make sure that the appliance is switched o and the
power cord is disconnected.
B Change Hygiene
Disc
The lifespan of the Hygiene Disc is approx. 3 months (with 24/7 operation)
and can be aected by the hardness and quality of the water being used
as well as the amount of time the unit is in operation (a reminder will appear on the interactive display).
The Hygiene Disc can be disposed with household refuse.
Recommendation: every 10–14
days
Any residue in the water basin and on the disc stack (white, greenyellowish or brown deposits or discolorations) do NOT impair the function
of the device.
Recommendation
every 3 years
Open the evaporator compartment 3. Remove the
disc stack 5 and unlock the drive wheel. Remove
the Hygiene Disc 11 and replace it. Re-assemble the
device and touch the OK indicator in the display again
and hold it for 3 seconds until it disappears.
Empty the residual water out of the water tank 4 and
water basin 6. Clean the water basin 6, disc stack 5
and the water tank 4 under fresh, owing water. Fill the
water tank 4 up to the MAX marker with fresh water.
The intensity of the UVC lamp is exhausted after
approx. 3 years. That is why the UVC lamp should be
changed every 3 years. Read the maintenance instructions before opening the device. The UVC lamp is
accompanied by an instruction manual.
11 US
Loading...
