VEGA HAN 7D User Manual

Supplementary instructions
Plug connector Harting HAN 7D
for level sensors
Document ID:
34456
1 Contents

Contents

1 For your safety
1.1 Appropriate use . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 General safety instructions . . . . . . . . . . . . . . . . . . . .
1.3 Safety instructions for Ex areas . . . . . . . . . . . . . . . . .
2 Connecting to power supply
2.1 Wiring plan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Supplement
3.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editing status: 2012-02-06
2 Plug connector Harting HAN 7D for level sensors
34456-EN-120222

1 For your safety

1 For your safety

1.1 Appropriate use

The plug connectors belong to the accessories for level, switching and pressure sensors. They provide a detachable connection to power supply/signal processing for level switches.

1.2 General safety instructions

The safety information in the operating instructions manual of the respective sensor must be noted.

1.3 Safety instructions for Ex areas

Please note the Ex-specic safety information for installation and operation in Ex areas. These safety instructions are part of the operating instructions manual and come with the Ex-approved instruments.
For instruments with Exd or StEx approval, the use of plug connectors is not allowed.
34456-EN-120222
Plug connector Harting HAN 7D for level sensors 3
4
3
5
1
2
678
3
2
7
1
4
5
6
8

2 Connecting to power supply

Transistor output
2 Connecting to power supply

2.1 Wiring plan

Each respective wiring plan shows the assignment of the individual pins of the plug connector to the respective signal outputs. The chart shows the assignment of the individual contact pins to the terminals of the sensor electronics.
Caution:
With mains supply (230 V), the switching circuit must be diverted from the supply circuit.
Fig. 1: Top view of the plug connector
1 + (Pin 1) 2 Transistor output (Pin 2) 3 Transistor output (Pin 3) 4 - (Pin 4) 5 free (Pin 5) 6 free (Pin 6) 7 free (Pin 7) 8 Screen (Pin 8)
Contact pin
Pin 1 Black 1 1 1
Pin 2 Blue 4 2 2
Pin 3 Red 3 7 -
Pin 4 Yellow 2 6 -
Pin 8 Green/yellow
4 Plug connector Harting HAN 7D for level sensors
Colour ­connection cable
Terminal, electronics module
VEGACAP, VEGAWAVE, VEGAVIB, VEGA-
SWING, VEGAKON
VEGAMIP R61, R62
VEGAMIP T61
34456-EN-120222
4
3
5
1
2
678
3
2
7
1
4
5
6
8
Relay output
2 Connecting to power supply
Fig. 2: Top view of the plug connector
1 + (Pin 1) 2 - (Pin 2) 3 free (Pin 3) 4 Relay output (Pin 4) 5 Relay output (Pin 5) 6 Relay output (Pin 6) 7 free (Pin 7) 8 Screen (Pin 8)
Contact pin
Colour ­connection
Terminal, electronics module
cable
VEGACAP, VEGAWAVE,
VEGAMIP R61, R62
VEGAVIB, VEGA-
SWING, VEGAKON
Pin 1 Black 1 1 1
Pin 2 Blue 2 2 2
Pin 4 Yellow 3 3 -
Pin 5 White 4 4 -
Pin 6 Grey 5 5 -
Pin 8 Green/yellow
VEGAMIP T61
34456-EN-120222
Plug connector Harting HAN 7D for level sensors 5
4
3
5
1
2
678
3
2
7
1
4
5
6
8
2 Connecting to power supply
Two-wire output, con­tactless electronic switch, NAMUR output
Fig. 3: Top view of the plug connector
1 + (Pin 1) 2 - (Pin 2) 3 free (Pin 3) 4 free (Pin 4) 5 free (Pin 5) 6 free (Pin 6) 7 free (Pin 7) 8 Screen (Pin 8)
Contact pin plug Colour - connection
cable
Pin 1 Black 1
Pin 2 Blue 2
Pin 8
Green/yellow
Terminal, elec­tronics module
34456-EN-120222
6 Plug connector Harting HAN 7D for level sensors

3 Supplement

3 Supplement

3.1 Technical data

Materials
Contact support Polyamide Contact copper alloy, hard silver plated 0.3 µm Ag Plug housing Aluminium die-casting Housing seal NBR
Temperature range
Plug connector - separate -25 +125 °C (-13 +257 °F) Plug - mounted on the sensor the lowest temperature is applicable
Electrical data
Operating current Reference voltage 250 V With mains supply (230 V), the switching circuit must be diverted from the supply circuit.
Insulation resistance > 10000 Ω Reference surge voltage 0.8 kV, 1.2 µs, 50 µs
Protection rating
Plug connector - separate (locked status) Plug connector - mounted on the sensor (connected status)
1)
10 A
IP 65 (with seal screw)
The lowest protection category applies
1)
Up to 45 °C (113 °F) ambient temperature, see derating of the manufacturer.
34456-EN-120222
Plug connector Harting HAN 7D for level sensors 7
3 Supplement
8 Plug connector Harting HAN 7D for level sensors
34456-EN-120222
3 Supplement
34456-EN-120222
Plug connector Harting HAN 7D for level sensors 9
3 Supplement
10 Plug connector Harting HAN 7D for level sensors
34456-EN-120222
3 Supplement
34456-EN-120222
Plug connector Harting HAN 7D for level sensors 11
VEGA Grieshaber KG
ISO 9001
Am Hohenstein 113 77761 Schiltach
Germany Phone +49 7836 50-0 Fax +49 7836 50-201 E-mail: info.de@vega.com
www.vega.com
Printing date:
All statements concerning scope of delivery, application,
practical use and operating conditions of the sensors and
processing systems correspond to the information avail-
able at the time of printing.
© VEGA Grieshaber KG, Schiltach/Germany 2012
Subject to change without prior notice 34456-EN-120222
