Operating Instructions
Electronics module
VEGAFLEX series 80
Document ID: 43656
Contents
Contents
1 About this document
1.1 Function ............................................................................. 3
1.2 Target group ....................................................................... 3
1.3 Symbolism used ................................................................. 3
2 For your safety
2.1 Authorised personnel ......................................................... 4
2.2 Appropriate use .................................................................. 4
2.3 Approvals ........................................................................... 4
2.4 Environmental instructions ................................................. 4
3 Product description
3.1 Conguration ...................................................................... 5
3.2 Principle of operation .......................................................... 5
3.3 Packaging, transport and storage ....................................... 5
4 Mounting
4.1 General instructions ........................................................... 7
4.2 Mounting preparations ....................................................... 7
4.3 Mounting steps ................................................................... 7
5 Setup
5.1 Setup preparations ........................................................... 10
5.2 Setup steps ...................................................................... 10
6 Maintain
6.1 How to proceed in case of repair ...................................... 11
7 Dismounting
7.1 Dismounting steps ............................................................ 12
7.2 Disposal ........................................................................... 12
8 Supplement
8.1 Technical data .................................................................. 13
43656-EN-121113
Editing status: 2012-11-12
2
Electronics module • VEGAFLEX series 80
1 About this document
1 About this document
1.1 Function
This operating instructions manual provides all the information you
need for mounting, connection and setup as well as important instruc-
tions for maintenance and fault rectication. Please read this information before putting the instrument into operation and keep this manual
accessible in the immediate vicinity of the device.
1.2 Target group
This operating instructions manual is directed to trained qualied
personnel. The contents of this manual should be made available to
these personnel and put into practice by them.
1.3 Symbolism used
Information, tip, note
This symbol indicates helpful additional information.
Caution: If this warning is ignored, faults or malfunctions can result.
Warning: If this warning is ignored, injury to persons and/or serious
damage to the instrument can result.
Danger: If this warning is ignored, serious injury to persons and/or
destruction of the instrument can result.
Ex applications
This symbol indicates special instructions for Ex applications.
List
•
The dot set in front indicates a list with no implied sequence.
Action
→
This arrow indicates a single action.
1 Sequence
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of batteries and accumulators.
43656-EN-121113
Electronics module • VEGAFLEX series 80
3
2 For your safety
2 For your safety
2.1 Authorised personnel
All operations described in this operating instructions manual must
be carried out only by trained specialist personnel authorised by the
plant operator.
During work on and with the device the required personal protective
equipment must always be worn.
2.2 Appropriate use
The components such as electronics module, accumulator insert,
emitting electronics, housing or process components described in
this manual are replacement components for existing sensors.
2.3 Approvals
Depending on the version, instruments with approvals can have
deviating technical data. For these instruments, the corresponding
approval documents must be observed. These documents are part of
the scope of delivery or can be downloaded from www.vega.com via
"VEGA Tools" and "serial number search" as well as via "Downloads"
and "Approvals".
2.4 Environmental instructions
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental protection. The environment management system is certied according
to DIN EN ISO 14001.
Please help us full this obligation by observing the environmental
instructions in this manual:
Chapter "Packaging, transport and storage"
•
Chapter "Disposal"
•
43656-EN-121113
4
Electronics module • VEGAFLEX series 80
Scope of this operating
instructions manual
3 Product description
3 Product description
3.1 Conguration
This operating instructions manual applies to electronics modules
with the following hardware and software versions:
Hardware from 1.0.0
•
Software from 1.0.0
•
Scope of delivery
Application area
Packaging
Transport
Transport inspection
The scope of delivery encompasses:
Electronics module
•
Documentation
•
– this operating instructions manual
– Ex-specic "Safety instructions" (with Ex versions)
– Label "Observe safety instructions electronics module" (with Ex
versions)
– if necessary, further certicates
3.2 Principle of operation
The electronics module is suitable for exchange in sensors of series
VEGAFLEX 80. You can nd the available versions in chapter "Mount-
ing preparations".
3.3 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.
The packaging of standard instruments consists of environmentfriendly, recyclable cardboard. For special versions, PE foam or PE
foil is also used. Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out under consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or concealed defects must be appropriately dealt with.
Storage
43656-EN-121113
Electronics module • VEGAFLEX series 80
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
Not in the open
•
Dry and dust free
•
Not exposed to corrosive media
•
Protected against solar radiation
•
Avoiding mechanical shock and vibration
•
5
3 Product description
Storage and transport
temperature
Storage and transport temperature see chapter "Supplement -
•
Technical data - Ambient conditions"
Relative humidity 20 … 85 %
•
43656-EN-121113
6
Electronics module • VEGAFLEX series 80
Sensor serial number
4 Mounting
4 Mounting
4.1 General instructions
The new electronics module must be loaded with the order and factory data of the sensor. These are the options:
At the factory by VEGA
•
Or on site by the user
•
Information:
When loading on site, rst of all the order data must be downloaded
from the Internet (see "Setup").
In both cases, the sensor serial number is necessary. The serial numbers are stated on the type label of the instrument, inside the housing
or on the delivery note.
Caution:
The order data and company data contain important presettings for
the sensor. A reliable operation and a correction of the measurement
is not possible without these data.
Warning:
Switch o voltage supply before starting the mounting procedure. The
replacement electronics must only be mounted in idle condition.
Non-observance will damage the electronics!
The safety-relevant data for explosion protection of the electronics
module supplied later can deviate from the data of the previously
installed electronics module. If the electronics modue supplied later,
is installed in a certied, explosion-protected sensor, it is absolutely
necessary to observe the instrument "Safety instructions" attached to
the supplied electronics module! The attached label must be applied
on the sensor housing.
4.2 Mounting preparations
Assignment
The electronics modules are adapted to the respective sensor. First
of all check by means of the following lists if you are using a suitable
electronics module.
FX-E.80H for version 4 … 20 mA/HART (two-wire/four-wire/Mod-
•
bus)
FX-E.80A for version 4 … 20 mA/HART with SIL qualication
•
FX-E.80P for version Probus PA
•
FX-E.80F for version Foundation Fieldbus
•
4.3 Mounting steps
Mounting steps
43656-EN-121113
Electronics module • VEGAFLEX series 80
The electronics module is installed in the electronics compartment.
The following illustrations show the respective position of the electronics compartment in the single or double chamber housing.
7
4 Mounting
1
Fig. 1: Single chamber housing
1 Position of the electronics compartment
1
Fig. 2: Double chamber housing
1 Position of the electronics compartment
Proceed as follows:
1. Switch o power supply
2. Unscrew housing cover of the electronics compartment
3. Remove the terminal blocks according to the operating instructions manual of the respective sensor
4. Loosen the two holding screws with a screwdriver (Torx size T 10
or Phillips size 4)
1
+
( )
(-)
1
2
567
8
2
Fig. 3: Loosening the holding screws
1 Electronics module
2 Screws (2 pcs.)
5. Pull the previous electronics out by using the dismounting tool.
6. Insert the new electronics module carefully.
43656-EN-121113
7. Screw in the two holding screws and tighten them
8. Attach the terminal blocks according to the operating instructions
manual of the respective sensor
9. Screw the housing cover back on
The electronics exchange is now nished.
8
Electronics module • VEGAFLEX series 80
4 Mounting
As a rule, an exchange of electronics must be documented internally
when Ex applications are involved.
43656-EN-121113
Electronics module • VEGAFLEX series 80
9
5 Setup
With sensor serial number
5 Setup
5.1 Setup preparations
If you have ordered the electronics module by stating the sensor
serial number, it is ready for the setup steps after installation and
connection to power supply.
Without sensor serial
number
Parameter adjustment
If you have ordered the electronics module without stating the sensor serial number or you are using a suitable electronics module
from stock, you rst have to load the sensor data after installation.
Move via www.vega.com to the item "serial number search". The
order data of the sensor will be displayed after entering the serial
number.
Below the order data you will nd "Sensor data for Service-DTM" as
XML le. This le includes all sensor-specic parameters as well as
the data of the factory setting.
Load this le with "Save target as" on your PC. Start PACTware and
under "Instrument data" go to the menu item "Additional functions",
then to "Electronics exchange". Transfer the XML le to the sensor.
5.2 Setup steps
If the instrument is used in the same application after the electronics
exchange, the previous parameter adjustment of the instrument must
be restored. For this purpose, you can use the import function of the
adjustment software PACTware with the device DTMs or the copy
function of the indicating and adjustment module.
Information:
It is recommended to recreated an existing false signal suppression
after an electronics exchange. If this is not possible, for example,
because the vessel is lled, the false signal suppression can be
imported also via the DTM. However, the false signal suppression
should be updated or recreated next time when the vessel is empty.
10
43656-EN-121113
Electronics module • VEGAFLEX series 80
6 Maintain
6 Maintain
6.1 How to proceed in case of repair
You can nd a repair form as well as detailed information on how to
proceed under www.vega.com/downloads and "Forms and certi-
cates".
By doing this you help us carry out the repair quickly and without having to call back for needed information.
If a repair is necessary, please proceed as follows:
Print and ll out one form per instrument
•
Clean the instrument and pack it damage-proof
•
Attach the completed form and, if need be, also a safety data
•
sheet outside on the packaging
Please contact for the return shipment the agency serving you. You
•
can nd the agency on our home page www.vega.com.
43656-EN-121113
Electronics module • VEGAFLEX series 80
11
7 Dismounting
7 Dismounting
7.1 Dismounting steps
Warning:
Before dismounting, be aware of dangerous process conditions such
as e.g. pressure in the vessel, high temperatures, corrosive or toxic
products etc.
Take note of chapters "Mounting" and "Connecting to power supply"
and carry out the listed steps in reverse order.
7.2 Disposal
The instrument consists of materials which can be recycled by specialised recycling companies. We use recyclable materials and have
designed the electronics to be easily separable.
Correct disposal avoids negative eects on humans and the environ-
ment and ensures recycling of useful raw materials.
Materials: see chapter "Technical data"
If you have no way to dispose of the old instrument properly, please
contact us concerning return and disposal.
WEEE directive 2002/96/EG
This instrument is not subject to the WEEE directive 2002/96/EG and
the respective national laws. Pass the instrument directly on to a specialised recycling company and do not use the municipal collecting
points. These may be used only for privately used products according
to the WEEE directive.
12
43656-EN-121113
Electronics module • VEGAFLEX series 80
8 Supplement
8 Supplement
8.1 Technical data
Technical data
The technical data are listed in the operating instructions manual of the respective sensor.
43656-EN-121113
Electronics module • VEGAFLEX series 80
13
Notes
14
43656-EN-121113
Electronics module • VEGAFLEX series 80
Notes
43656-EN-121113
Electronics module • VEGAFLEX series 80
15
Printing date:
All statements concerning scope of delivery, application, practical use and operating conditions of the sensors and processing systems correspond to the information
available at the time of printing.
Subject to change without prior notice
© VEGA Grieshaber KG, Schiltach/Germany 2012
VEGA Grieshaber KG
Am Hohenstein 113
77761 Schiltach
Germany
Phone +49 7836 50-0
Fax +49 7836 50-201
E-mail: info.de@vega.com
www.vega.com
43656-EN-121113
Loading...
