1 About this document

1 About this document

1.1 Function

is operating instructions manual provides all the information you

Th
need for mounting, connection and setup as well as important
instructions for maintenance and fault rectification. Please read this
information before putting the instrument into operation and keep this
manual accessible in the immediate vicinity of the device.

1.2 Target group

This operating instructions manual is directed to trained qualified
personnel. The contents of this manual should be made available to
these personnel and put into practice by them.

1.3 Symbolism used

Information, tip, note

This

symbol indicates helpful additional information.

Caution: If this
result.
Warning: If this warning is ignored, injury to persons and/or serious
damage to the instrument can result.
Danger: If this warning is ignored, serious injury to persons and/or
destruction of the instrument can result.

applications

Ex

Th

symbol indicates special instructions for Ex applications.

is

l List

The dot set in front indicates a list with no implied sequence.

warning is ignored, faults or malfunctions can

à Action

This a

rrow indicates a single action.

1 Sequence

Numbers set in front indicate successive steps in a procedure.

28258-EN-081209

4 VEGABAR 61 • Foun

dation Fieldbus

2 For your safety

2 For your safety

2.1 Auth

All operations described in this operating instructions manual must be
carried out only by trained specialist personnel authorised by the plant
operator.

During work on and with the device the required personal protective
equipment must always be worn.

orised personnel

2.2 Appropriate use

VEGABAR 61 is a pressure transmitter for measurement of gauge
pressure, absolute pressure and vacuum.

You can find detailed information on the application range in chapter

"Product description".

Operational reliability is ensured only if the instrument is properly used
according to the specifications in the operating instructions manual as
well as possible supplementary instructions.

For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbitrary
conversions or modifications are explicitly forbidden.

2.3 Warning about misuse

Inappropriate or incorrect use of the instrument can give rise to
application-specific hazards, e.g. vessel overfill or damage to system
components through incorrect mounting or adjustment.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

2.4 General safety instructions

This is a high-tech instrument requiring the strict observance of
standard regulations and guidelines. The user must take note of the
safety instructions in this operating instructions manual, the country­specific installation standards as well as all prevailing safety
regulations and accident prevention rules.

The instrument must only be operated in a technically flawless and
reliable condition. The operator is responsible for trouble-free
operation of the instrument.

During the entire duration of use, the user is obliged to determine the
compliance of the required occupational safety measures with the
current valid rules and regulations and also take note of new
regulations.

s 5

2 For your safety

2.5 Safety appro

The safety approval markings and safety tips on the device must be
observed.

val markings and safety tips

2.6 CE conformity

This device fulfills the legal requirements of the applicable EC
guidelines. By attaching the CE mark, VEGA provides a confirmation
of successful testing. You can find the CE conformity declaration in the
download area of

2.7 Fulfillment o

With respect to compatibility, the NAMUR recommendation NE 53 is
fulfilled. This applies also to the corresponding indicating and
adjustment components. VEGA instruments are generally upward and
downward compatible.

l Sensor software for DTM VEGABAR 61 HART, PA or FF
l DTM VEGABAR 61 for adjustment software PACTware
l Indicating and adjustment module for sensor software

The parameter adjustment of the basic sensor functions is independ­ent of the software version. The range of available functions depends
on the respective software version of the individual components.

The software version of VEGABAR 61 can be determined as follows:

l via PACTware
l on the type label of the electronics
l via the indicating and adjustment module

You can view all software histories on our website

se of this advantage and get registered for update information

Makeu
via e-mail.

www.vega.com.

f NAMUR recommendations

www.vega.com.

2.8 Safety instructions for Ex areas

Please note the Ex-specific safety information for installation and
operation in Ex areas. These safety instructions are part of the
operating instructions manual and come with the Ex-approved
instruments.

2.9 Safety instructions for oxygen applications

For instruments in oxygen applications the special instructions in
chapters "Storage and transport", "Mounting" as well as "Technical
data" under "Process conditions"must be noted. Furthermore the valid
national regulations, implementation instructions and memorandums
of the BG (professional assoc.) must be noted.

6 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

2 For your safety

2.10 Environmental instructions

Protection
is why we have introduced an environment management system with
the goal of continuously improving company environmental protection.

The environment management system is certified according to DIN
EN ISO 14001.

Please help us fulfil this obligation by observing the environmental

instructions in this manual:

l Chapter "Packaging, transport and storage"
l Chapter "Disposal"

of the environment is one of our most important duties. That

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 7

3

2

1

3 Product description

3 Product description

Scope of delivery

Components

3.1 Configurat

ion

The scope of delivery encompasses:

l VEGABAR 61 pressure transmitter
l Documentation

- this operating instructions manual

- Test certificate for pressure transmitters

- Ex specific safety instructions (with Ex versions), if necessary

further certificates

- Operating instructions manual 27835 "Indicating and adjust-

ment module PLICSCOM" (optional)

- Supplementary instructions manual 31708 "Heating for in-

dicating and adjustment module" (optional)

- Supplementary instructions manual "Plug connector for con-
tinuously measuring sensors" (optional)

VEGABAR 61 consists of the following components:

l Process fitting with measuring cell
l Housing with electronics, optionally available with plug connector
l Housing cover, optionally available with indicating and adjustment

module

The components are available in different versions.

Fig. 1: Example of a VEGABAR 61 with flange
plastic housing

1 Housing cover with integrated indicating and adjustment module (optional)
2 Housing with electronics
3 Process fitting with measuring cell

Type label

The type label contains the most important data for identification a nd
use of the instrument:

l Sensor type

8 VEGABAR 61 • Foun

connection DN 50 PN 40 and

28258-EN-081209

dation Fieldbus

3 Product description

Supplementary label

"Oil and grease-free for
oxygen applications"

Application area

Functional principle

l Article number instrument
l Technic

al data: Measuring range, process pressure, process

temperature, signal output, voltage supply, protection, protection
class

l Order number
l Article numbers documentation
l Serial number

With the serial number, you can access the delivery data of the
instrument via

www.vega.com, "VEGA T

ools" and "serial number

search". In addition to the type label outside, you can also find the

serial number on the inside of the instrument.

Instruments in the version "Oil and grease-free for oxygen applica-
tions" are equipped with a supplementary label. The supplementary

label contains instructions on oil and grease-free parts of the
instrument.

3.2 Principle of operation

The VEGABAR 61 is a pressure transmitter with isolating diaphragm
for pressure measurement of highly corrosive and hot liquids.

The sensor element for measuring ranges up to 60 bar is the
CERTEC

hydrostatic pressure of the product or the process pressure causes a
capacitance change in the measuring cell via the metal process
diaphragm and the isolating system.

The sensor element for measuring ranges from 100 bar is a wire strain
gauge (DMS) on the rear of the process diaphragm. There, the
process pressure causes a resistance change, which is converted into
an appropriate output signal.

®

measuring cell with rugged ceramic diaphragm. The

1)

Power supply and bus
communication

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

Power is supplied via the H1 Fieldbus. A two-wire cable according to
Fieldbus specification serves as carrier of both power and digital data
for multiple sensors. This cable can be operated in two versions:

l via an H1 interface card in the control system and additional power

supply

1)

The isolating system protects the sensor against corrosive products and
high temperatures. By selecting suitable diaphragm materials and isolating
liquids, systems with a temperature resistance up to 400 °C (752 °F) can be
achieved.

s 9

3 Product description

l via a Linking device

with HSE (High speed
Ethernet) and addition-

al power supply ac­cording to IEC 61158-2

DD/CFF

The DD (Device Descriptions) and CFF (capability files) necessary for
planning and configuration of your FF (Foundation Fieldbus) commu­nication network are available in the download area of the VEGA
homepage www.vega.com un
Foundation Fieldbus". The appropriate certificates are also available
there. A CD with the appropriate files and certificates can be ordered
via e-mail under [e-mail] or by phone from one of the VEGA
agencies under the order number "DRIVER.S".

The backlight of the indicating and adjustment module is powered by
the sensor. Prer equisite is a certain level of operating voltage.

The data for power supply are specified in chapter "Technical data".

The optional heating requires its own power supply. You can find

further details in the supplementary instructions manual "Heating for
indicating and adjustment module".

This function is generally not available for approved instruments.

der "Services - Downloads - Software -

3.3 Operation

VEGABAR 61 can be adjusted with different adjustment media:

l with indicating and adjustment module
l with the suitable VEGA DTM in conjunction with an adjustment

software according to the FDT/DTM standard, e.g. PACTware and
PC

l a configuration tool

The entered parameters are generally saved in VEGABAR 61,
optionally also in the indicating a nd adjustment module or in
PACTware.

3.4 Packaging, transport and storage

Packaging

10 VEGABAR 61 • Foun

Your instrument was protected by packaging during transport. Its

capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.

28258-EN-081209

dation Fieldbus

3 Product description

Transport

Transport inspection

Storage

Storage and transport

temperature

The packaging of standard instruments consists of environment­friendly, recyclabl

e cardboard. For special versions, PE foam or PE foil
is also used. Dispose of the packaging material via specialised
recycling companies.

Instruments for oxygen applications are sealed in PE foil and provided
with a label "Oxygen! Use no Oil". Remove this foil just before
mounting the instrument! See instruction under "Mounting".

Transport must be carried out under consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.

The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or
concealed defects must be appropriately dealt with.

Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.

Unless otherwise indicated, the packages must be stored only under
the following conditions:

l Not in the open
l Dry and dust free
l Not exposed to corrosive media
l Protected against solar radiation
l Avoiding mechanical shock and vibration

l Storage and transport temperature see chapter "Supplement -

Technical data - Ambient conditions"

l Relative humidity 20 … 85 %

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 11

4 Mounting

4 Mounting

Suitability for process

conditions

Diaphragm pro­tection

Mounting position

Moisture

4.1 General ins

Make sure that all parts of the instrument in contact with the measured
product, especially the sensor element, process seal and process
fitting, are suitable for the existing process conditions such as process
pressure, process temperature as well as the chemical properties of
the medium.

You can find the specifications in chapter "Technical data" in the or on
the type label.

Caution:

After removal
not be pressed.

Select an installation position you can easily reach for mounting and
connecting as well as later retrofitting of an indicating and adjustment
module. The housing can be rotated by 330° without the use of any
tools. You can also install the indicating and adjustment module in four
different positions (each displaced by 90°).

Use the recommended cables (see chapter "Connecting to power
supply") and tighten the cable gland.

You can give your instrument additional protection against moisture
penetration by leading the connection cable downward in front of the
cable entry. Rain and condensation water can thus drain off. This
applies mainly to outdoor mounting as well as installation in areas
where high humidity is expected (e.g. through cleaning processes) or
on cooled or heated vessels.

tructions

of the diaphragm protective cover, the diaphragm must

Fig. 2: Measures against moisture

12 VEGABAR 61 • Foun

penetration

28258-EN-081209

dation Fieldbus

2

1

2

2

2

1

1

1

4 Mounting

Ventilation

Ventilation for the measuring cell is realised by means of a filter
element
electronics housing is realised via an additional filter element in the
area of the cable glands.

Fig. 3: Position of the filter
1 Filter element for ventilation of the electronics housing
2 Filter element for ventilation of the measuring cell

Informa

Mak
operation. A pressure washer must not be used for cleaning.

in the socket of the electronics housing. Ventilation for the

elements

tion:

sure that the filter elements are always free of buildup during

e

With instrument versions in protection IP 66/IP 68, 1 bar, the ventilation
is realised via the capillaries in the fix connected cable. The filter
elements are replaced by blind stoppers.

Temperature limits

Higher process temperatures often mean also higher ambient
temperatures. Make sure that the upper temperature limits stated in
chapter "Technical data" for the environment of the electronics housing
and connection cable are not exceeded.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 13

1

2

4 Mounting

Fig. 4: Temperature ranges
1 Process temperature
2 Ambient

temperature

Oxygen applica­tions

Welding the socket

Sealing/Screwing in

threaded versions

Danger:

Instruments
unpacked just before mounting. After the protective cover of the
process fitting has been removed, the label "O₂" on the process fitting
is visible. Contamination by oil, grease and dirt should be avoided.
Danger of explosion!

in the version "Oil and grease free for oxygen" should be

4.2 Mounting steps

For mounting VEGABAR 61, a welded socket is required. You can find
these components in the supplementary instructions manual "Welded

socket and seals".

Seal the thread with teflon, hemp or a similar resistant seal material on
the process fitting thread 1½ NPT.

à Screw VEGABAR 61 into the welded socket. Tighten the hexagon

on the process fitting with a suitable wrench. Wrench size, see
chapter "Dimensions".

Warning:

housing must not be used to screw the instrument in! Applying

The

tightening force can damage internal parts of the housing.

4.3 Mounting steps, tube isolating diaphragm

The isolating systems are temperature and pressure-aged at 80 °C
and 18 bar. The zero point is adjusted at 22 °C ±2 °C and a torque of
275 Nm. The defined installation position is: Tube isolating diaphragm
horizontally, VEGABAR 61 vertically.

28258-EN-081209

14 VEGABAR 61 • Foun

dation Fieldbus

4 Mounting

Wall mounting

For mounting, proceed

1 Position VEGABAR 61 with tube isolating diaphragm
2 Tighten the threaded fittings step-by-step once on the right and on

the left

3 Hold VEGABAR 61, to avoid distortion from the defined installation

position.

Caution:

Apart from
permanently under torsion.

4 Check current after mounting. The current must be between 3.9

Information:

By slight
exactly to 20 mA.

mounting, the tube isolating diaphragm must not be

and 4.1 mA. In case of a deviating value, losen threaded fitting and
mount again.

ly increasing or reducing the torque, the current can be set

as follows:

4.4 Mounting steps external housing

1 Mark the holes according to the following drilling template
2 Depending on the mounting surface, fasten the wall mounting

plate with 4 screws

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 15

90 mm (3.54")

R 3,5 mm

(0.14")

3mm

(0.12")

70 mm (2.76")

8 mm

(0.32")

93 mm (3.66")

110 mm (4.33")

4 Mounting

Fig. 5: Drilling template - wall mounting

plate

Tip:

Mount

the wall mounting plate so that the cable entry of the socket

housing points downward. The socket housing can be displaced by
180° to the wall mounting plate.

ning:

War

Th

four screws of the socket housing must only be hand-screwed. A

e

torque > 5 Nm (3.688 lbf ft) can damage the wall mounting plate.

16 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

5 Connecting to power supply

5 Connecting to power supply

Note safety instructions

Take note of

safety instruc­tions for Ex ap­plications

Select power supply

Selecting connection

cable

5.1 Preparin

Always keep in mind the following safety instructions:

l Connect only in the complete absence of line voltage
l If overvoltage surges are expected, overvoltage arresters should

be installed according to Foundation Fieldbus specification

Tip:

We recomm

In hazardous areas you should take note of the appropriate

regulations, con
and power su pply units.

The instrument requires a operating voltage of 9 … 32 V DC.
Operating voltage and the digital bus signal are carried on the same
two-wire connection cable. Power is supplied via the H1 power supply.

Connection is carried out with screened cable according to Fieldbus

specification.

Use cable withround cross-section. A cable outer diameter of 5 … 9 mm
(0.2 … 0.35 in) ensures the seal effect of the cable gland. If you are

using cable with a different diameter or cross-section, exchange the
seal or use a suitable cable gland.

Make sure that the entire installation is carried out according to the
Fieldbus specification. In particular, make sure that the termination of

the bus is done with appropriate terminating resistors.

g the connection

end VEGA overvoltage arrester B63-32.

formity and type approval certificates of the sensors

Cable gland ½ NPT

Cable screening and

grounding

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

On the instrument with cable entry ½ NPT and plastic housing there is

a metallic ½" threaded insert moulded into the plastic housing.

Caution:

No greas
steel tube into the threaded insert. Standard grease can contain
additives that corrode the connection between threaded insert and
housing. This would influence the stability of the connection and the
tightness of the housing.

In systems with potential equalisation, connect the cable screen
directly to ground potential at the power supply unit, in the connection
box and at the sensor. The screen in the sensor must be connected
directly to the internal ground terminal. The ground terminal outside on
the housing must be connected to the potential equalisation (low
impedance).

e should be used when screwing the NPT cable gland or

s 17

5 Connecting to power supply

Select connec­tion cable for Ex
applications

Single/Double chamber
housing

In systems without potential equalisation, connect
directly to ground potential at the power supply unit and at the sensor.
In the connection box or T-distributor, the screen of the short stub to
the sensor must not be connected to ground potential or to another
cable screen. The cable screens to the power supply unit and to the
next distributor must be connected to each other and also connected
to ground potential via a ceramic capacitor (e.g. 1 nF, 1500 V). The low
frequency potential equalisation currents are thus suppressed, but the
protective effect against high frequency interference signals remains.

The total capacitance of the cable and of all capacitors must not exceed

10 nF in Ex

Take note of the corresponding installation regulations for Ex

appl
currents flow over the cable screen. In case of grounding on both sides
this can be achieved by the use of a capacitor or a separate potential
equalisation.

applications.

ications. In particular, make sure that no potential equalisation

the cable screen

5.2 Connection procedure

Proceed as follows:

1 Unscrew the housing cover
2 If an indicating and adjustment module is installed, remove it by

turning it slightly to the left.

3 Loosen compression nut of the cable entry
4 Remove approx. 10 cm of the cable mantle, strip approx. 1 cm

insulation from the individual wires

5 Insert the cable through the cable gland into the sensor
6 Lift the opening levers of the terminals with a screwdriver (see

following illustration)

7 Insert the wire ends into the open terminals according to the wiring

plan

8 Press down the opening levers of the terminals, you will hear the

terminal spring closing

9 Check the hold of the wires in the terminals by lightly pulling on

them

10 Connect the screen to the internal ground terminal, connect the

outer ground terminal with potential equalisation

11 Tighten the compression nut of the cable entry. The seal ring must

completely encircle the cable

12 Screw the housing cover on

28258-EN-081209

18 VEGABAR 61 • Foun

dation Fieldbus

IP 68 version with exter-
nal housing

5 Connecting to power supply

The electrical connection is finished.

Fig. 6: Connection steps 6 and 7

Proceed

as follows:

1 Loosen the four screws on the housing socket with an Allen key

size 4

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 19

3

2

1

5 Connecting to power supply

2 Remove the housing socket from the mounting plate

Fig. 7: Components of the
1 Screws
2 Wall mounting plate
3 Cable gland

3 Loop the connection cable through the cable entry on the housing

base

2)

external housing for plics®devices

Information:

The

cable gland can be mounted in three positions each displaced by

90°. Simply exchange the cable gland against the blind plug in the
suitable thread opening.

4 Connect the wire ends as described under "Single/Double

chamber housing" according to the numbering

5 Connect the screen to the internal ground terminal, connect the

outer ground terminal above on the housing to potential equal­isation

6 Tighten the compression nut of the cable entry. The seal ring must

completely encircle the cable

7 Attach the mounting plate again and tighten the screws

The electrical connection of the sensor to the external housing is

hence ready.

28258-EN-081209

2)

The connection cable is already preconfectioned. If necessary, shorten it to
the requested length, cut the breather capillaries clean. Remove approx.
5 cm of the cable mantle, strip approx. 1 cm insulation from the ends of the
individual wires. After shortening the cable, fasten the type plate with sup­port back onto the cable.

20 VEGABAR 61 • Foun

dation Fieldbus

1 2

4

3

5 Connecting to power supply

Housing overview

5.3 Wiring plan, single

The following illustrations apply to the non-Ex as well as to the Ex-ia
version.

Fig. 8: Material versions, single chamber
1 Plastic
2 Aluminium
3 Stainless steel
4 Stainless steel casting

chamber housing

housing

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 21

I²C

3

4

5

1

2

Display

Ty p:

1 2 5 6 7 8

Bus

Sim.

I2C

Display

1

1 2 5

6 7 8

5 Connecting to power supply

Electronics and connec­tion compartment

Wiring plan

Fig. 9: Electronics and connection
1 Plug connector for VEGACONNECT (I²C interface)
2 Spring-loaded terminals for connection of the external indication VEGADIS

61

3 Ground terminal for connection of the cable screen
4 Spring-loaded terminals for Foundation Fieldbus connection
5 Simulation switch ("on" = mode for simulation release)

Fig. 10: Wiring plan, single chamber
1 Voltage supply/Signal output

5.4 Wiring plan, double chamber housing

The following illustrations apply to the non-Ex as

compartment, single chamber housing

housing

well as to the Ex-ia

version.

28258-EN-081209

22 VEGABAR 61 • Foun

dation Fieldbus

1

2

3

4

6

5

4

I2C

1 2

3

I²C

1

2

4

Display

Typ :

1 2 5 6 7 8

Bus

Sim.

Housing overview

Electronics compart-

ment

5 Connecting to power supply

Fig. 11: Double chamber housing
1 Housing
2 Blind stopper or plug M12 x 1 for VEGADIS 61 (optional)
3 Housing cover, electronics compartment
4 Filter element for pressure compensation of the electronics housing
5 Filter element for pressure compensation of the measuring cell
6 Cable entry or plug

cover, connection compartment

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

Fig. 12: Electronics compartment, double chamber housing
1 Simulation switch ("on" = mode for simulation release)
2 Connection for VEGACONNECT (I²C interface)
3 Internal connection cable to the connection compartment

s 23

3

1

2

Display

1 2

I²C

I2C

1

1 2

5 Connecting to power supply

Connection compart­ment

Wiring plan

Fig. 13: Connection compartment, double chamber
1 Plug connector for VEGACONNECT (I²C interface)
2 Ground terminal for connection of the cable screen
3 Spring-loaded terminals for voltage supply

Fig. 14: Wiring plan, double chamber
1 Voltage supply/Signal output

housing

housing

28258-EN-081209

24 VEGABAR 61 • Foun

dation Fieldbus

1 2 3

4

5

4

I2C

1 2

3

I²C

1

2

4

Display

Typ :

1 2 5 6 7 8

Bus

Sim.

Housing overview

Electronics compart-

ment

5 Connecting to power supply

5.5 Wiring plan double chamber housing Ex d

Fig. 15: Double chamber housing
1 Housing
2 Blind stopper or plug M12 x 1 for VEGADIS 61 (optional)
3 Housing cover, electronics compartment
4 Filter element for air pressure compensation
5 Cable gland

cover, connection compartment

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

Fig. 16: Electronics compartment, double chamber
1 Simulation switch ("on" = mode for simulation release)
2 Connection for VEGACONNECT (I²C interface)
3 Internal connection cable to the connection compartment

s 25

housing

1

2

1 2

1

1 2

5 Connecting to power supply

Connection compart­ment

Wiring plan

Fig. 17: Connection compartment double
1 Spring-loaded terminals for power supply and cable screen
2 Ground terminal for connection of the cable screen

Fig. 18: Wiring plan double
1 Voltage supply/Signal output

chamber housing Ex d

chamber housing Ex d

5.6 Wiring plan - version IP 66/IP 68, 1 bar

This version is only available for instruments with absolute pr essure
measuring ranges.

28258-EN-081209

26 VEGABAR 61 • Foun

dation Fieldbus

+

-

1

2

Wire assignment, con­nection cable

Overview

5 Connecting to power supply

Fig. 19: Wire assignment, connection cable
1 brown (+) and
2 Shielding

blue (-) to power supply or to the processing system

5.7 Wiring plan, external housing with version IP 68

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

Fig. 20: VEGABAR 61 in IP 68 version 25 bar, non-Ex
external housing

and

axial

s 27

cable outlet,

I²C

Display

Typ :

1 2 5 6 7 8

Bus

Sim.

4

5

6

1

2

3

5 Connecting to power supply

Electronics and connec­tion compartment

Fig. 21: Electronics and connection
1 Plug connector for VEGACONNECT (I²C interface)
2 Spring-loaded terminals for connection of the external indication VEGADIS

61

3 Cable gland to VEGABAR
4 Ground terminal for connection of the cable screen
5 Spring-loaded terminals for Foundation Fieldbus connection
6 Simulation switch ("on" = mode for simulation release)

compartment, single chamber housing

28 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

1 2 3 4

6

3

4

1

2

5

I2C

Display

1

1 2 5

6 7 8

Terminal compartment,
housing socket

5 Connecting to power supply

Wiring plan external
electronics

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

Fig. 22: Connection of the
1 Brown
2 Blue
3 Yellow
4 White
5 Shielding
6 Breather capillaries

Fig. 23: Wiring plan external
1 Power supply

sensor in the housing socket

electronics

s 29

5 Connecting to power supply

Switch on phase

5.8 Switch on pha

se

After VEGABAR 61 is connected to voltage supply or after voltage
recurrence, the instrument carries out a self-check for approx. 30
seconds. The following steps are carried out:

l Internal check of the electronics
l Indication of the instrument type, the firmware as well as the

sensor TAGs (sensor designation)

l Status byte goes briefly to fault value

Then the current measured value will be displayed and the
corresponding digital output signal will be outputted to the cable.

3)

3)

The values correspond to the actual measured level as well as to the set­tings already carried out, e.g. default setting.

30 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

6 Set up with the indicating and adjustment module PLICSCOM

6 Set up with the indicating and adjustment

module PLICS

6.1 Short description

COM

Function/Configuration

Mount/Dismount indicat-

ing and adjustment
module

The indicating and adjustment module is used for measured value
display, adjustment and diagnosis. It can be mounted in the following
housing versions and instruments:

®

l All sensors of the plics

in the double chamber housing (optionally in the electronics or
connection compartment)

l External indicating and adjustment unit VEGADIS 61

From a hardware version …- 01 or higher of the indicating and
adjustment module resp. …- 03 or higher of the corresponding sensor
electronics, an integrated backlight can be switched on via the
adjustment menu. The hardware version is stated on the type label of
the indicating and adjustment module or the sensor electronics.

Note:

You can find det
instructions manual "Indicating and adjustment module".

ailed information on adjustment in the operating

instrument family, in the single as well as

6.2 Insert indicating and adjustment module

The indicating and adjustment module can be inserted into the sensor
and removed again at any time. It is not necessary to interrupt the
power supply.

Proceed as follows:

1 Unscrew the housing cover
2 Place the indicating and adjustment module in the desired position

on the electronics (you can choose any one of four different
positions - each displaced by 90°)

3 Press the indicating and adjustment module onto the electronics

and turn it to the right until it snaps in.

4 Screw housing cover with inspection window tightly back on

Removal is carried out in reverse order.

The indicating and adjustment module is powered by the sensor, an

additional connection is not necessary.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 31

6 Set up with the indicating and adjustment module PLICSCOM

Fig. 24: Mounting the indicating

and adjustment module

Note:

If you inte

nd to retrofit the instrument with an indicating and adjustment

module for continuous measured value indication, a higher cover with
an inspection glass is required.

28258-EN-081209

32 VEGABAR 61 • Foun

dation Fieldbus

1.1

2

3

1

6 Set up with the indicating and adjustment module PLICSCOM

6.3 Adjustment system

Key functions

Adjustment system

Fig. 25: Indicating and adjustment
1 LC display
2 Indication of the menu item number
3 Adjustment keys

l [OK] key:

- Move to the menu overview

- Confirm selected menu

- Edit parameter

- Save

l [->] key to

- menu change

- list entry

value

select:

elements

- Select editing position

l [+] key:

- Chang

l [ESC] key:

- interrupt input

e value of the parameter

- jump to the next higher menu

The sensor
adjustment module. The LC display indicates the individual menu
items. The functions of the individual keys are shown in the above
illustration. Approx. 10 minutes after the last pressing of a key, an
automatic reset to measured value indication is triggered. Any values
not confirmed with [OK] will not be saved.

is adjusted via the four keys of the indicating and

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 33

6 Set up with the indicating and adjustment module PLICSCOM

Level or process pres­sure measurement

Parameter ad­justment "Level
measurement"

6.4 Setup procedur

e

VEGABAR 61 can be used for level as well as for process pressure
measurement. Default setting is level measurement. The mode can be
changed in the adjustment menu.

Depending on the application only the respective subchapter "Level or
process pressure measurement" is of importance. There, you find the
individual adjustment steps.

Level measurement

Set up VEGABAR 61 in the following sequence:

1 Selecting adjustment unit/density unit
2 Carry out position correction
3 Carrying out min. adjustment
4 Carrying out max. adjustment

In the menu item "Adjustment unit" you select the physical unit in which
the adjustment should be carried out, e.g. mbar, bar, psi…

The position correction compensates the influence of the mounting
position or static pressure on the measurement. It does not influence
the adjustment values.

Information:

The

steps 1, 3 and 4 are not necessary for instruments which are

already preset according to customer specifications!

You can find the data on the type label on the instrument or in the
menu items of the min./max. adjustment.

The indicating and adjustment module enables the adjustmetn without
filling or pressure. Thanks to this, you can carry out your settings
already in the factory without the instrument having to be installed.

The actual measured value is also displayed in the menu items for
min./max. adjustment.

Select unit

In this menu item you select the adjustment unit as well as the unit for
the temperature indication in the display.

To select the adjustment unit (in the example switching over from bar
to mbar) you have to proceed as follows:

4)

1 Push the [OK] button in the measured value display, the menu

overview is displayed.

4)

Selection options: mbar, bar, psi, Pa, kPa, MPa, inHg, mmHg, inH

O.

mmH

2

34 VEGABAR 61 • Foun

O,

2

dation Fieldbus

28258-EN-081209

6 Set up with the indicating and adjustment module PLICSCOM

▶

Basic adjustment
Display
Diagnostics
Service
Info

2 Confirm the menu "Basic adjustment" with [OK], the menu item

"Unit" will be displayed.

Unit
Unit of measurement

▼

bar

Temperature unit
°C

▼

3 Activate the selection with [OK] and select "Units of measure-

ment with [->].

4 Activate the selection with [OK] and select the requested unit with

[->] (in the example mbar).

5 Confirm with [OK] and move to position correction with [->].

The adjustment unit is hence switched over from bar to mbar.

Information:

When switch

ing over to adjustment in a height unit (in the example

from bar to m), the density also has to be entered.

Proceed as follows:

1 Push the [OK] button in the measured value display, the menu

overview is displayed.

2 Confirm the menu "Basic adjustment" with [OK], the menu item

"Units of measurement" will be displayed.

3 Activate the selection with [OK] and select the requested unit with

[->] (in the example m).

4 Confirm with [OK], the submenu "Density unit" appears.

Unit of measurement

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

Density unit

▶

kg/dm³
pcf

5 Select the requested unit, e.g. kg/dm³ with [->] and confirm with

[OK], the submenu "Density" appears.

Unit of measurement

Density

0001000
kg/dm³

6 Enter the requested density value with [->] and [+], confirm with

[OK] and move to position correction with [->].

s 35

P

6 Set up with the indicating and adjustment module PLICSCOM

The adjustment unit is hence switched over from bar to m.

Proceed

as follows to select the temperature unit:

à Activate the selection with [OK] and select "Temperature unit

with [->].

à Activate the selection with [OK] and select the requested unit with

[->] (e.g. °F).

à Confirm with [OK].

The temperature unit is hence switched over from °C to °F.

5)

Carry out position cor­rection

Carrying out min. ad­justment

Proceed as follows:

1 Activate in the menu item "Position correction" the selection with

[OK].

Position correction
Offset

=
+0000 mbar

53 mbar

2 Select with [->], e.g. to accept actual measured value.

Position correction
Accept current measured

value?

▶

Accept
Edit

3 Confirm with [OK] and move to min.(zero) adjustment with [->].

Proceed as follows:

1 Edit the % value in the menu item "Min. adjustment" with [OK].

Min. adjustment

+000.0 %

=

+0000.0 mbar

0000.0 mbar

2 Set the requested percentage value with [+] and [->].
3 Edit the requested mbar value with [OK].
4 Set the requested mbar value with [+] and [->].
5 Confirm with [+] and move to max. adjustment with [->].

The min. adjustment is finished.

Information:

adjustment with filling, you simply enter the displayed actual

For an
measured value. If the adjustment ranges are exceeded, the message
"Outside parameter limits" appears. The editing procedure can be

5)

Selection options: °C, °F.

36 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

6 Set up with the indicating and adjustment module PLICSCOM

Carrying out max. ad­justment

aborted with [ESC] or the d

isplayed limit value can be accepted with

[OK].

Proceed as follows:

1 Edit the % value in the menu item "Max. adjustment" with [OK].

Max. adjustment

+100.0 %

=

+1000.0 mbar

0000.0 mbar

Information:

The

displayed pressure for 100 % corresponds to the nominal

measuring range of the sensor (in the above example 1 bar =

1000 mbar).

2 Set the requested percentage value with [->] and [OK].
3 Edit the requested mbar value with [OK].
4 Set the requested mbar value with [+] and [->].
5 Confirm with [OK] and move to the menu overview with [ESC].

The max. adjustment is finished.

Information:

For an

adjustment with filling, you simply enter the displayed actual
measured value. If the adjustment ranges are exceeded, the message
"Outside parameter limits" appears. The editing procedure can be
aborted with [ESC] or the displayed limit value can be accepted with

[OK].

Parameter ad­justment "Proc­ess pressure
measurement"

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

Process pressure measurement

Set up VEGABAR 61 in the following sequence:

1 Select application "Process pressure measurement"
2 Select the unit of measurement
3 Carry out position correction
4 Carrying out zero adjustment
5 Carrying out span adjustment

In the menu item "Adjustment unit" you select the physical unit in which
the adjustment should be carried out, e.g. mbar, bar, psi…

The position correction compensates the influence of the mounting
position or static pressure on the measurement. It does not influence
the adjustment values.

In the menu items "zero" and "span" you determine the span of the
sensor, the span corresponds to the end value.

s 37

6 Set up with the indicating and adjustment module PLICSCOM

Information:

steps 1, 3 and 4 are not necessary for instruments which are

The
already preset according to customer specifications!

You can find the data on the type label on the instrument or in the
menu items of the zero/span adjustment.

The indicating and adjustment module enables the adjustmetn without
filling or pressure. Thanks to this, you can carry out your settings
already in the factory without the instrument having to be installed.

The actual measured value is displayed in addition to the menu items
for zero/span adjustment.

Select application

"Process pressure
measurement"

Select unit

VEGABAR 61 is preset to application "Level measurement". Proceed
as follows when switching over to application "Process pressure
measurement":

1 Push the [OK] button in the measured value display, the menu

overview is displayed.

2 Select the menu "Service" with [->] and confirm with [OK].

Basic adjustment
Display
Diagnostics

▶

Service
Info

3 Select the menu item "Application" with [->] and edit with [OK].

ning:

War

Note

warning: "Output can change".

the

4 Select with [->] "OK" and confirm with [OK].
5 Select "Process pressure" from the list and confirm with [OK].

In this menu item you select the adjustment unit as well as the unit for
the temperature indication in the display.

To select the adjustment unit (in the example switching over from bar
to mbar) you have to proceed as follows:

6)

1 Push the [OK] button in the measured value display, the menu

overview is displayed.

▶

Basic adjustment
Display
Diagnostics
Service
Info

28258-EN-081209

6)

Selection options: mbar, bar, psi, Pa, kPa, MPa, inHg, mmHg, inH

O.

mmH

2

38 VEGABAR 61 • Foun

O,

2

dation Fieldbus

P

6 Set up with the indicating and adjustment module PLICSCOM

Carry out position cor­rection

2 Confirm the menu "Basi

c adjustment" with [OK], the menu item

"Unit" will be displayed.

Unit
Unit of measurement

bar

▼

Temperature unit
°C

▼

3 Activate the selection with [OK] and select "Units of measure-

ment with [->].

4 Activate the selection with [OK] and select the requested unit with

[->] (in the example mbar).

5 Confirm with [OK] and move to position correction with [->].

The adjustment unit is hence switched over from bar to mbar.

Proceed as follows to select the temperature unit:

7)

à Activate the selection with [OK] and select "Temperature unit

with [->].

à Activate the selection with [OK] and select the requested unit with

[->] (e.g. °F).

à Confirm with [OK].

The temperature unit is hence switched over from °C to °F.

Proceed as follows:

1 Activate in the menu item "Position correction" the selection with

[OK].

Position correction
Offset

=
+0000 mbar

53 mbar

2 Select with [->], e.g. to accept actual measured value.

Position correction
Accept current measured

value?

▶

Accept
Edit

3 Confirm with [OK] and move to min.(zero) adjustment with [->].

Carrying out zero ad­justment

Proceed as follows:

1 Edit the mbar value in the menu item "zero" with [OK].

7)

Selection options: °C, °F.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 39

P

P

6 Set up with the indicating and adjustment module PLICSCOM

Zero adjustment

000.0 %

=

+0000.0 mbar

0000.0 mbar

2 Set the requested mbar value with [+] and [->].
3 Confirm with [+] and move to span adjustment with [->].

The zero adjustment is finished.

Information:

The

zero adjustment shifts the value of the span adjustment. The span,
i.e. the difference between these values, however, remains un­changed.

Information:

For an

adjustment with pressure, you simply enter the displayed actual
measured value. If the adjustment ranges are exceeded, the message
"Outside parameter limits" appears. The editing procedure can be
aborted with [ESC] or the displayed limit value can be accepted with

[OK].

Carrying out span ad­justment

Proceed as follows:

1 Edit the mbar value in the menu item "span" with [OK].

Span adjustment

100.0 %

=

+1000.0 mbar

0000.0 mbar

Information:

displayed pressure for 100 % corresponds to the nominal

The
measuring range of the sensor (in the above example 1 bar =

1000 mbar).

2 Set the requested mbar value with [->] and [OK].
3 Confirm with [OK] and move to the menu overview with [ESC].

The span adjustment is finished.

Information:

adjustment with pressure, you simply enter the displayed actual

For an
measured value. If the adjustment ranges are exceeded, the message
"Outside parameter limits" appears. The editing procedure can be
aborted with [ESC] or the displayed limit value can be accepted with

[OK].

28258-EN-081209

40 VEGABAR 61 • Foun

dation Fieldbus

6 Set up with the indicating and adjustment module PLICSCOM

Copy sensor data

This function enables reading out parameter adjustment data as well

g parameter adjustment data into the sensor via the indicating

as writin
and adjustment module. A description of the function is available in the
operating instructions manual "Indicating and adjustment module".

The following data are read out or written with this function:

l Measured value presentation
l Adjustment
l Damping
l Linearisation curve
l Sensor-TAG
l Displayed value
l Unit of measurement
l Language

The following safety-relevant data are not read out or written:

l PIN
l Application

Copy sensor data

Copy sensor data?

Reset

Basic adjustment

If the "Reset" is carried out, the sensor resets the values of the
following menu items to the reset values (see chart):

Menu section Function Reset value

Basic settings Unit of measurement bar

Temperature unit °C

Zero/Min. adjustment Measuring range begin

Span/Max. adjustment Measuring range end

Density 1 kg/l

Density unit kg/l

Damping 0 s

Linearisation linear

Sensor-TAG Sensor

Display Displayed value AI-Out

The values of the following menu items are not reset with "Reset:

8)

Menu section Function Reset value

Basic settings Position correction no reset

Display Lighting no reset

Service Language no reset

8)

Sensor-specific basic adjustment.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 41

6 Set up with the indicating and adjustment module PLICSCOM

Menu section Function Reset value

pplication no reset

A

Factory setting

Like basic adjustment, furthermore special parameters are reset to
default values.

9)

Pointer

The min. and max. distance values are reset to the actual value.

Optional settings

Additional adjustment and diagnosis options such as e.g. scaling,
simulation or trend curve presentation are shown in the following menu
schematic. You will find a detailed description of these menu items in
the operating instructions manual "Indicating and adjustment module".

9)

Special parameters are parameters which are set customer-specifically on
the service level with the adjustment software PACTware.

42 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

P

6 Set up with the indicating and adjustment module PLICSCOM

Basic adjustment

▶

Basic adjustment
Display
Diagnostics
Service
Info

Unit
Unit of measurement

bar

▼

Temperature unit
°C

▼

Damping

0 s

Display

Basic adjustment

▶

Display
Diagnostics
Service
Info

1.1

1.5

1

2

6.5 Menu schem

atic

Information:

Depending on the version and application, the highlighted menu
windows are not always available.

Position correction
Offset

=

0.2 mbar
0000 mbar

Linearisation curve

linear

▼

1.2

1.6

Min. adjustment

000.0 %

=

0.0 mbar

0.0 mbar

Sensor-TAG

Sensor

1.3

1.7

Max. adjustment

100.00 %

=

100.00 mbar

0.0 mbar

1.4

Displayed value

AI-Out

2.1

Lighting

Switched off

2.4

▼

Diagnostics

Basic adjustment
Display

▶

Diagnostics
Service
Info

Pointer

p-min.: -5.8 mbar
p-max.: 167.5 mbar

T-min.: -12.5 °C
T-max.: +85.5 °C

3.1

3

Sensor status

3.2

OK

Trend curve

Start trend curve?

3.3.1

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 43

6 Set up with the indicating and adjustment module PLICSCOM

Service

Basic adjustment
Display
Diagnostics

▶

Service
Info

4

Simulation

Start simulation

PIN

Info

Basic adjustment
Display
Diagnostics
Service

▶

Info

Device-ID

Sensor-TAG

Sensor characteristics

Display now?

Enable?

4.2

▼

4.5

5.1

5.4

Reset

Select reset

Application

Level

5

Sensor type

Serial number

12345678

4.3

▼

4.6

5.2

Language

Deutsch

Date of manufacture
e.g. 16. May 2008
Software version
e.g. 3.50

4.3

5.2

Copy sensor data

Copy sensor data?

Last change using PC

e.g. 16. May 2008

4.4

5.3

44 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

6 Set up with the indicating and adjustment module PLICSCOM

6.6 Saving the pa

It is recommended noting the adjusted data, e.g. in this operating
instructions manual and archive them afterwards. They are hence
available for multiple use or service purposes.

If VEGABAR 61 is equipped with an indicating and adjustment module,
the most important data can be read out of the sensor into indicating
and adjustment module. The procedure is described in the ope rating
instructions manual "Indicating and adjustment module" in the menu
item "Copy sensor data". The data remain there permanently even if
the sensor power supply fails.

If it is necessary to exchange the sensor, the indicating and adjustment
module is inserted into the replacement instrument and the data are
written into the sensor under the menu item "Copy sensor data".

rameter adjustment data

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 45

3

1

2

1

2

3

4

OPEN

TWIST

USB

LOCK

7 Setup with PACTware

and other adjustment programs

Internal connection via
I²C interface

External connection via
I²C interface

7 Setup with PACTware and

other adjustment

programs

7.1 Connecting the PC

Fig. 26: Connection of the PC via VEGACONNECT directly
1 USB cable to the PC
2 VEGACONNECT
3 Sensor

to the sensor

46 VEGABAR 61 • Foun

Fig. 27: Connection via I²C connection cable
1 I²C bus (com.) interface
2 I²C connection cable of VEGACONNECT
3 VEGACONNECT
4 USB cable to the PC

on the sensor

28258-EN-081209

dation Fieldbus

7 Setup with PACTwa

Necessary components:

l VEGABAR 61
l PC with PA
l VEGACONNECT
l Power supply unit or processing system

CTware and suitable VEGA DTM

re and other adjustment programs

7.2 Parameter adjustment with PACTware

Further setup steps are described in the operating instructions manual

"DTM Collection/PACTware" attached to each CD and which can also
be downloaded from our homepage. A detailed description is available
in the online help of PACTware and the VEGA DTMs.

Note:

Keep in mind
actual version must be used.

All currently available VEGA DTMs are provided in the DTM Collection
on CD and can be obtained from the responsible VEGA agency for a
token fee. This CD includes also the up-to-date PACTware version.
The basic version of this DTM Collection incl. PACTware is also
available as a free-of-charge download from the Internet.

Go via

that for setup of VEGABAR 61, DTM-Collection in the

www.vega.com an

d "Downloads" to the item "Software".

7.3 Parameter adjustment with AMS™

For VEGA sensors, instrument descriptions for the adjustment
program AMS™ are available as DD. The instrument descriptions are
already implemented in the current version of AMS™. For older
versions of AMS™, a free-of-charge download is available via Internet.

www.vega.com an

Go via

d "Downloads" to the item "Software".

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

7.4 Saving the parameter adjustment data

It is recommended to document or save the parameter adjustment
data. They are hence available for multiple use or service purposes.

The VEGA DTM Collection and PACTware in the licensed, profes­sional version provide suitable tools for systematic project documen­tation and storage.

s 47

8 Maintenance and fault rectificati

8 Maintenance and fault rectification

8.1 Maintain

on

Maintenance

Cleaning

Reaction when malfunc-

tions occur

Causes of malfunction

Fault rectification

used in the correct way, no special maintenance is required in

When
normal operation.

In some applications, product buildup on the sensor diaphragm can
influence the measuring result. Depending on the sensor and
application, take precautions to ensure that heavy buildup, and
especially a hardening thereof, is avoided.

If necessary, clean the transmitter. Make sure that the materials are
resistant against the cleanig, see resistance list under "Services" on

"

www.vega.com". The appl
special cleaning instructions for each application. Please ask the
VEGA agency serving you.

ication variety of VEGABAR 61 requires

8.2 Remove interferences

The operator of the system is responsible for taken suitable measures
to remove interferences.

A maximum of reliability is ensured. Nevertheless, faults can occur
during operation. These may be caused by the following, e.g.:

l Sensor
l Process
l Power supply
l Signal processing

The first measures to be taken are to check the output signals as well
as to evaluate the error messages via the indicating and adjustment
module. The procedure is described below. Further comprehensive
diagnostics can be carried out on a PC with the software PACTware
and the suitable DTM. In many cases, the causes can be determined
in this way and faults can be rectified.

24 hour service hotline

Checking Foundation
Fieldbus

48 VEGABAR 61 • Foun

However, should these measures not be successful, call the VEGA

service hotline in urgent cases under the phone no. [phone].

The hotline is available to you 7 days a week round-the-clock. Since
we offer this service world-wide, the support is only available in the
English language. The service is free of charge, only the standard
telephone costs will be charged.

? When an additional instrument is connected, the H1 segment fails.

l Max. supply current of the segment coupler exceeded

à Measure the current consumption, reduce size of segment

28258-EN-081209

dation Fieldbus

8 Maintenance and fault rectificati

on

Fault messages via the
indicating/adjustment
module

? Measured value on the indicating and adjustment module does not

correspond

l The menu item "Display - Display value" is not set to "AI-Out"

à Check values and correct, if necessary

to the value in the PLC

? Instrument does not appear during connection setup

l Incorrect termination

à Check termination at the beginning and end points of the bus

and terminate, if necessary, according to the specification

l Instrument not connected to the segment

à Check and correct

In Ex applications, the regu

lations for the wiring of intrinsically safe

circuits must be observed.

? E013

l no measured value available

à Exchange instrument or return instrument for repair

10)

? E017

l Adjustment span too small

à repeat with modified values

? E036

l no operable sensor software

à Carry out a software update or send the instrument for repair

Reaction after fault rec­tification

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

? E041

l Hardware error, electronics defective

à Exchange instrument or return instrument for repair

? E113

l Communication conflict

à Exchange instrument or return instrument for repair

Depending on the failure reason and measures taken, the steps

described in chapter "Set up" must be carried out again, if necessary.

8.3 Exchanging the electronics module

In case of a defect, the electronics module can be exchanged by the
user against an identical type. If no electronics module is available on
side, the module can be ordered for the VEGA agency serving you.

10)

Fault message can also appear if the pressure is higher than the nominal
range.

s 49

8 Maintenance and fault rectificati

on

Load sensor software to
PC

Prepare update

Load software into sen-

sor

Ordering and exchange are possible with or withou

t sensor serial

number. The electronics module with serial number includes order­specific data such as factory setting, seal material etc. These are not
included in the electronics module without serial number.

The serial number is stated on the type label of VEGABAR 61 or on the
delivery note.

8.4 Software update

The following components are required to update the sensor software:

l Sensor
l Power supply
l VEGACONNECT
l PC with PACTware
l Current sensor software as file

At "

www.vega.com/downloads" go
instruments and sensors" the suitable instrument series . Load the zip
file via the right mouse key with "Save target as" e.g. on the desktop of
your PC. Extract all files available in the zip file, e.g. to the desktop.

Connect the sensor to power supply and provide connection from PC
to the instrument via VEGACONNECT. Start PACTware and provide
connection to the sensor, e.g. via the VEGA project assistant. Close
the parameter window of the sensor, as far as open.

Go in the PACTware menu bar to "Instrument data", "Additional
functions" and "Update instrument software".

PACTware checks now the actual hardware and software version of
the sensor and displays the data. This procedure lasts approx. 60 s.

Push the button " Update software" and select the previously
extracted hex file. Then the software update can be started. Further
files are installed automatically. Depending on the sensor, this
procedure lasts a pproximately 1 h.

to "Software". Select under "plics

8.5 Instrument repair

If a repair is necessary, please proceed as follows:

You can download a return form (23 KB) from our Internet homepage

www.vega.com under: "Dow
form".

By doing this you help us carry out the repair quickly and without
having to call back for needed information.

l Print and fill out one form per instrument
l Clean the instrument and pack it damage-proof
l Attach the completed form and, if need be, also a safety data

sheet outside on the packaging

50 VEGABAR 61 • Foun

nloads - Forms and certificates - Repair

28258-EN-081209

dation Fieldbus

8 Maintenance and fault rectificati

on

l Please ask the agency serving you for the address of your return

shipment. You

can find the respective agency on our website

www.vega.com under: "Company - VEGA worldwide"

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 51

9 Dismounting

9 Dismounting

9.1 Dism

Warning:

Before dismounting, be aware of dangerous process conditions such
as e.g. pressure in the vessel, high temperatures, corrosive or toxic
products etc.

Take note of chapters "Mounting" and "Connecting to power supply"
and carry out the listed steps in reverse order.

ounting steps

9.2 Disposal

The instrument consists of materials which can be recycled by
specialised recycling companies. We use recyclable materials and
have designed the electronics to be easily separable.

WEEE directive 2002/96/EG

This instrument is not subject to the WEEE directive 2002/96/EG and
the respective national laws. Pass the instrument directly on to a
specialised recycling company and do not use the municipal collecting
points. These may be used only for privately used products according
to the WEEE directive.

Correct disposal avoids negative effects to persons and environment
and ensures recycling of useful raw materials.

Materials: see chapter "Technical data"

If you have no possibility to dispose of the old instrument

professionally, please contact us concerning return and disposal.

52 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

10 Supplement

10 Supplement

10.1 Technical

General data

Pressure type Gauge pressure or gauge pressure

Measuring principle Depending on the measuring range ceramic-

Communication interface I²C bus

Materials and weights

Material 316L corresponds to 1.4404 or 1.4435

Materials, wetted parts

- Process fitting 316L

- Diaphragm 316L, Hastelloy C276, Hastelloy C2, Tantalum,

Materials, non-wetted parts

- Electronics housing Plastic PBT (polyester), Alu die-casting powder-

- External electronics housing plastic PBT (Polyester)

- Socket, wall mounting plate external

electronics housing

- Seal between housing socket and wall

mounting plate

- Seal ring, housing cover NBR (stainless steel housing), silicone (Alu/plastic

- Inspection window in housing cover for

indicating and adjustment module

- Ground terminal 316Ti/316L

- Connection between IP 68 transmitter

and external electronics housing

- Type plate support with IP 68 version on

cable

Weight approx. 0.8 … 8 kg (1.764 … 17.64 lbs), depending on

data

capacitive or st rain gauge (DMS), each with
isolating system

Titanium, PTFE on 316Ti, 316L with gold-coating,
Hastelloy C4

coated, 316L

plastic PBT (Polyester)

TPE (fixed connected)

housing)

Polycarbonate (UL-746-C listed)

PUR, FEP, PE

PE hard

process fitting

Output variable

Output

- Signal digital output signal, Foundation Fieldbus protocol

- Physical layer according to IEC 61158-2

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 53

90 %

100 %

10 %

t

t

T

A

t

t

S

2

1

10 Supplement

Channel Numbers

- Channe

l 1 Primary Value

- Channel 2 Secondary Value 1

- Channel 3 Secondary Value 2

- Channel 4 Temperature Value

Transmission rate 31.25 Kbit/s
Current value 10 mA, ±0.5 mA

Dynamic behaviour output

Run-up time approx. 10 s

Fig. 28: Sudden
1 Process variable

2 Output signal

change

the process variable, dead time tT, rise time tAand step response time t

of

S

Dead time ≤ 150 ms
Rise time ≤ 100 ms (10 … 90 %)
Step response time ≤ 250 ms (ti: 0 s, 10 … 90 %)
To this amounts the reaction time of the isolatng system. This time varies from values < 1 s with

compact isolating diaphragms up to several seconds with capillary systems.

Example: Flange isolating diaphragm DN 80, filling silicone oil KN 2.2, capillary length 10 m,
measuring range 1 bar

Process temperature Reaction time

40 °C approx. 2 s

20 °C approx. 3 s

-20 °C approx. 11 s

Damping (63 % of the input variable) 0 … 999 s, adjustable

54 VEGABAR 61 • Foun

dation Fieldbus

28258-EN-081209

10 Supplement

Input variable

Adjustme

nt

Adjustment range of the min./max. adjustment relating to the nominal measuring range:

- percentage value -10 … 110 %

- pressure value -20 … 120 %

Adjustment range of the zero/span adjustment relating to the nominal measuring range:

- zero -20 … +95 %

- Span -120 … +120 %

11)

- Difference between zero and span max. 120 % of the nominal range

Adjustment range with measuring ranges from 100 bar, relating to the nominal measuring range:

- zero/Min. -5 … +95 %

- span/Max. -5 … +105 %

Recommended max. turn down 10 : 1 (no limitation)

Nominal measuring ranges and overload resistance

Nominal range Overload, max. pressure Overload, min. pressure

Gauge pressure

0 … 0.4 bar/0 … 40 kPa 30 bar/3000 kPa -0.8 bar/-80 kPa

0 … 1 bar/0 … 100 kPa 35 bar/3500 kPa -1 bar/-100 kPa

0 … 2.5 bar/0 … 250 kPa 50 bar/5000 kPa -1 bar/-100 kPa

0 … 100 bar/0 … 10 MPa 200 bar/20000 kPa -1 bar/-100 kPa

0 … 250 bar/0 … 25 MPa 500 bar/50 MPa -1 bar/-100 kPa

0 … 400 bar/0 … 40 MPa 800 bar/80 MPa -1 bar/-100 kPa

0 … 5 bar/0 … 500 kPa 65 bar/6500 kPa -1 bar/-100 kPa

0 … 10 bar/0 … 1000 kPa 90 bar/9000 kPa -1 bar/-100 kPa

0 … 25 bar/0 … 2500 kPa 130 bar/13000 kPa -1 bar/-100 kPa

0 … 60 bar/0 … 6000 kPa 200 bar/20000 kPa -1 bar/-100 kPa

-1 … 0 bar/-100 … 0 kPa 35 bar/3500 kPa -1 bar/-100 kPa

-1 … 1.5 bar/-100 … 150 kPa 50 bar/5000 kPa -1 bar/-100 kPa

-1 … 5 bar/-100 … 500 kPa 65 bar/6500 kPa -1 bar/-100 kPa

-1 … 10 bar/-100 … 1000 kPa 90 bar/9000 kPa -1 bar/-100 kPa

-1 … 25 bar/-100 … 2500 kPa 130 bar/13000 kPa -1 bar/-100 kPa

-1 … 60 bar/-100 … 6000 kPa 200 bar/20000 kPa -1 bar/-100 kPa

-0.2 … 0.2 bar/-20 … 20 kPa 30 bar/3000 kPa -1 bar/-100 kPa

-0.5 … 0.5 bar/-50 … 50 kPa 35 bar/3500 kPa -1 bar/-100 kPa

0 … 2.5 bar/0 … 250 kPa 50 bar/5000 kPa -1 bar/-100 kPa

Absolute pressure

0 … 1 bar/0 … 100 kPa 35 bar/3500 kPa

0 bar abs.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

11)

Values less than -1 bar cannot be set.

s 55

10 Supplement

Nominal range Overload, max. pressure Overload, min. pressure

0 … 2.5 bar/0 … 250 kPa 50 bar/5000 kPa

0 … 5 bar/0 … 500 kPa 65 bar/6500 kPa

0 … 10 bar/0 … 1000 kPa 90 bar/9000 kPa

0 … 25 bar/0 … 2500 kPa 130 bar/13000 kPa

0 … 60 bar/0 … 6000 kPa 200 bar/20000 kPa

0 … 100 bar/0 … 10 MPa 200 bar/20000 kPa

0 … 400 bar/0 … 40 MPa 800 bar/80000 kPa

0 bar abs.

abs.

0 bar

0 bar abs.

0 bar abs.

0 bar abs.

0 bar abs.

0 bar abs.

Reference conditions and actuating variables (similar to DIN EN 60770-1)

Reference conditions according to DIN EN 61298-1

- Temperature +18 … +30 °C (+64 … +86 °F)

- Relative humidity 45 … 75 %

- Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig)

Determination of characteristics Limit point adjustment according to IEC 61298-2

Characteristics linear

Reference installation position upright, diaphragm points downward

Influence of the installation position depending on the isolating diaphragm version

Deviation determined according to the limit point method according to IEC 60770

12)

Applies to digital interfaces (HART, Profibus PA, Foundation Fieldbus) as well as to analogue
current output 4 … 20 mA. Specifications refer to the set span. Turn down (TD) is the relation
nominal measuring range/set span.

Deviation

- Turn down 1 : 1 up to 5 : 1 < 0.1 %

- Turn down > 5 : 1 < 0.02 % x TD

Deviation with absolute pressure measuring range 0.1 bar

- Turn down 1 : 1 up to 5 : 1 < 0.25 %

- Turn down > 5 : 1 < 0.05 % x TD

Influence of the product or ambient temperature

Applies to instruments with digital signal output (HART, Profibus PA, Foundation Fieldbus) as well
as to instruments with analogue current output 4 … 20 mA. Specifications refer to the set span.
Turn down (TD) = nominal measuring range/set span.

12)

Incl. non-linearity, hysteresis and non-repeatability.

56 VEGABAR 61 • Foun

dation Fieldbus

28258-EN-081209

10 Supplement

Thermal change zero zignal, reference

- In the compensated temperature range

temperature 20 °C (68 °F):

< 0.05 %/10 K x TD

0 … +100 °C (+32 … +212 °F)

- Outside the compensated temperature

typ. < 0.05 %/10 K x TD

range

Applies also to instruments with analogue 4 … 20 mA current output and refers to the set span.

Thermal change, current output < 0.15 % at -40 … +80 °C (-40 … +176 °F)

Long-term stability (similar to DIN 16086, DINV 19259-1 and IEC 60770-1)

Applies to digital interfaces (HART, Profibus PA, Foundation Fieldbus) as well as to analogue
current output 4 … 20 mA. Specifications refer to the set span. Turn down (TD) = nominal
measuring range/set span.

Long-term drift of the zero signal < (0.1 % x TD)/year

Ambient conditions

Ambient, storage and transport temperature

- Standard version -40 … +80 °C (-40 … +176 °F)

- Version for oxygen applications

- Versions IP 66/IP 68, 1 bar and IP 68, PE

13)

-40 … +60 °C (-40 … +140 °F)

-20 … +60 °C (-4 … +140 °F)

connection cable

- Versions IP 66/IP 68, 1 bar and IP 68,

-20 … +80 °C (-4 … +176 °F)

PUR connection cable

Additional temperature influence by isolating diaphragm

The specifications refer to diaphragm material 316L as well as isolating liquid silicone oil. They are
only used for estimation. The actual values depend on the diameter, material and strength of the
diaphragm as well as the isolating liquid. They are available on request.

Temperature coefficient of the isolating diaphragm in mbar/10 K with

- Flange DN 25 PN 40, Form C, DIN 2501 4.8

- Flange DN 40 PN 40, Form C, DIN 2501 1

- Flange DN 50 PN 40, Form C, DIN 2501 2

- Flange DN 50 PN 40 with extension

1.9

50 mm

- Flange DN 50 PN 40 with extension

1.9

100 mm

- Flange DN 50 PN 40 with extension

2.1

200 mm

- Flange DN 80 PN 40, Form C, DIN 2501 0.4

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

13)

Up to 60 °C (140 °F).

s 57

10 Supplement

- Flange 1" 150 lbs RF

ANSI B16.5; with

1.8

extension 2", 3"

- Flange 2" 150 lbs RF ANSI B16.5; with

2

extension 2"

Temperature coefficient of a cooling ele-

0.1 … 1.5

ment, depending on the diaphragm-ø

Temperature coefficient of a 1 m long

0.1 … 15

capillary line, depending on the diaphragm-ø

Process conditions

The specifications to the pressure stage and the product temperature are used as an overview.
The specifications of the type label are applicable.

Product temperature depending on the isolating liquid (temperature: p

< 1 bar/14.5 psi)

14)

> 1 bar/14.5 psi/p

abs

abs

- silicone oil KN2.2 -40 … +150 °C/-40 … +150 °C
(-40 … +302 °F/-40 … +302 °F)

- Silicone oil KN2.2 and cooling element

or capillaries

-40 … +200 °C/-40 … +150 °C
(-40 … +392 °F/-40 … +302 °F)

- Vegetable oil -10 … +130 °C/-10 … +130 °C (14 … +266 °F/
14 … +266 °F)

- Water and glycerine -10 … +120 °C (+14 … +248 °F)

- High temperature oil KN3.2 and cooling

element

- High temperature oil KN3.2 and cooling

element 300 mm or capillaries

-10 … +200 °C/-10 … +200 °C (+14 … +392 °F/
+14 … +392 °F)

-10 … +400 °C/-10 … +200 °C (+14 … +752 °F/
+14 … +392 °F)

- Halocarbon oil KN21 -40 … +150 °C/-40 … +80 °C
(-40 … +302 °F/-40 … +176 °F)

- Halocarbon oil KN21 for oxygen appli-

cations

-40 … +60 °C/-40 … +60 °C
(-40 … +140 °F/-40 … +140 °F)

- Silicone-free liquid KN70 -40 … +70 °C (-40 … +158 °F), no vacuum

- med. white oil KN62 and cooling element -15 … +150 °C/-15 … +150 °C (+5 … +302 °F/

+10 … +302 °F)

- Med. white oil KN62 (FDA) and cooling

element

- Med. white oil KN62 (FDA) and temper-

ature adapter 300 mm

- Med. white oil KN62 (FDA) and capil-

laries 3 m

-15 … +200 °C/-15 … +150 °C (+5 … +392 °F/
+10 … +302 °F)

-15 … +250 °C/-15 … +170 °C (+5 … +482 °F/
+10 … +338 °F)

-15 … +250 °C/-15 … +170 °C (+5 … +482 °F/
+10 … +338 °F)

Vibration resistance mechanical vibrations with 4 g and 5 … 100 Hz
Shock resistance Acceleration 100 g/6 ms

16)

15)

28258-EN-081209

14)

Version for oxygen applications up to 60 °C (140 °F).

15)

Tested according to the regulations of German Lloyd, GL directive 2.

16)

Tested according to EN 60068-2-27.

58 VEGABAR 61 • Foun

dation Fieldbus

10 Supplement

Electromechanical data - version IP 66/IP 67

Cable

entry/plug

17)

- Single chamber housing l 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5

or:

l 1 x closing cap ½ NPT, 1 x blind plug ½ NPT

or:

l 1 x plug (depending on the version), 1 x blind

stopper M20 x 1.5

or:

l 2 x blind stopper M20 x 1,5

- Double chamber housing l 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; plug M12 x 1 for

VEGADIS 61 (optional)

or:

l 1 x closing cap ½ NPT, 1 x blind stopper

½ NPT, plug M12 x 1 for VEGADIS 61

(optional)

or:

l 1 x plug (depending on the version), 1 x blind

stopper M20 x 1.5; plug M12 x 1 for VEGADIS
61 (optional)

or:

l 2 x blind stopper M20 x 1.5; plug M12 x 1 for

VEGADIS 61 (optional)

Spring-loaded terminals for wire cross-sec-

tion

< 2.5 mm² (AWG 14)

Electromechanical data - version IP 66/IP 68, 1 bar

Cable entry

- Single chamber housing l 1 x IP 68 cable gland M20 x 1.5; 1 x blind
stopper M20 x 1.5

or:

l 1 x closing cap ½ NPT, 1 x blind plug ½ NPT

- Double chamber housing l 1 x IP 68 cable gland M20 x 1.5; 1 x blind
stopper M20 x 1.5; plug M12 x 1 for VEGADIS
61 (optional)

or:

l 1 x closing cap ½ NPT, 1 x blind stopper

½ NPT, plug M12 x 1 for VEGADIS 61

(optional)

17)

Depending on the version M12 x 1, according to DIN 43650, Harting, 7/
8" FF.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 59

10 Supplement

Connection cable

- Configuration four

wires, one suspension cable, one breather

capillary, screen braiding, metal foil, mantle

- Wire cross-section 0.5 mm² (AWG 20)

- Wire resistance < 0.036 Ω/m (0.011 Ω/ft)

- Tensile strength > 1200 N (270 pounds force)

- Standard length 5 m (16.4 ft)

- Max. length 1000 m (3281 ft)

- Min. bending radius at 25 °C/77 °F 25 mm (0.985 in)

- Diameter approx. 8 mm (0.315 in)

- Colour - standard PE Black

- Colour - standard PUR Blue

- Colour - Ex-version Blue

Electromechanical data - version IP 68

Cable entry/plug

18)

- External housing l 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5

or:

l 1 x plug (depending on the version), 1 x blind

stopper M20 x 1.5

Spring-loaded terminals for wire cross-sec­tion up to

Connection cable between IP 68 instrument and external housing:

- Configuration four wires, one suspension cable, one breather

- Wire cross-section 0.5 mm² (AWG 20)

- Wire resistance < 0.036 Ω/m (0.011 Ω/ft)

- Standard length 5 m (16.40 ft)

- Max. length 180 m (590.5 ft)

- Min. bending radius at 25 °C/77 °F 25 mm (0.985 in)

- Diameter approx. 8 mm (0.315 in)

- Colour - standard PE Black

- Colour - standard PUR Blue

- Colour - Ex-version Blue

2.5 mm² (AWG 14)

capillary, screen braiding, metal foil, mantle

Indicating and adjustment module

Voltage supply and data transmission through the sensor

Indication LC display in dot matrix

18)

Depending on the version M12 x 1, according to DIN 43650, Harting, 7/
8" FF.

60 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

Adjustment elements 4 keys

Protection

class

- unassembled IP 20

- mounted into the sensor without cover IP 40

Materials

- Housing ABS

- Inspection window Polyester foil

Power supply

Operating voltage

- Non-Ex instrument 9 … 32 V DC

- EEx-ia instrument 9 … 24 V DC

- EEx-d instrument 9 … 32 V DC

Operating voltage with lighted indicating and adjustment module

- Non-Ex instrument 12 … 32 V DC

- EEx-ia instrument 12 … 24 V DC

- EEx-ia instrument 12 … 32 V DC

19)

20)

21)

22)

Power supply by/max. number of sensors

- H1 p ower supply max. 32 (max. 10 with Ex)

Electrical protective measures

Protection class

- Housing, standard IP 66/IP 67

- Aluminium and stainless housing (op-

IP 68 (1 bar)

23)

24)

tionally available)

- Transmitter in IP 68 version IP 68

- External housing IP 65

Overvoltage category III

Protection class II

10 Supplement

Approvals

Depending on the version, instruments with approvals can have different technical data.

19)

Is available at a later date for instruments with StEx, WHG or ship approval
as well as country-specific approvals such as those according to FM or

CSA.

20)

From measuring range 100 bar, 13 … 32 V DC.

21)

From measuring range 100 bar, 13 … 32 V DC.

22)

From measuring range 100 bar, 13 … 32 V DC.

23)

Instruments with gauge pressure measuring ranges cannot detect the am­bient pressure when submerged, e.g. in water. This can lead to falsification
of the measured value.

24)

Only with instruments with absolute pressure ranges.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 61

10 Supplement

For these instruments, the corres
These are part of the delivery or can be downloaded under

"serial number search" as well as via "Downloads" and "Approvals".

ponding approval documents have to be taken into account.

www.vega.com via "VEGA Tools" and

62 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

t

i

Simulate

ALARM

S

OutPV

FIELD-VALUE

M

od

e & Stat

us

PV

F-TIME

LOW-CUTOFF

L-TYPE

OUT-

SCALE

PV-SCALE

DIRECT

INDIRECT

INDIRECT

SQRT

bar % Lin%

Primary

Value

Secondary

Value 1

Secondary

Value 2

Sensor mounting

correction

AI 2

AI 3

AI 1

TB

Temperature

Sensor_Value

Linearizationadjustment

Channel = 1: Primary Value
Channel = 2: Secondary Value 1
Channel = 3: Secondary Value 2
Channel = 4: Temperature

10 Supplement

10.2 Information on Found

ation Fieldbus

Block diagram, measured value processing

The following illustration shows the Transducer Block and Function block in simplified form.

Fig. 29: Transducer Block VEGABAR 61
TB Transducer Block
AI Function Block (AI =Analogue Input)

Diagram, adjus

The following illustration shows the function of the adjustment:

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

tment

s 63

Secondary_value_2

scale_in_0 scale_in_100 Sensor_value

0 %

100 %

bar

0,500-0,500

0

%

100

%

scale_in_100scale_in_0

10 Supplement

Fig. 30: Adjustment VEGABAR 61

Parameter list

Th

e following list contains the most important parameters and their meaning:

l primary_value

- Process Value after

'Channel' = 1. Unit derives from 'Primary_value_unit'

l primary_value_unit

- Unit code of 'Primary_value'

min/max-adjustment and linearization. Selected as input to AIFB by setting

- %

l secondary_value_1

- Proc

l secondary_value_1_unit

- bar, PSI, …, m, ft, …; in case

l secondary_value_2

- Value after min/max-adjustment. Selec

l secondary_value_2_unit

- Selected unit code for "secondary_valu

l sensor_value

- Raw

64 VEGABAR 61 • Foun

ess pressure. Selected as input to AIFB by setting 'Channel' = 2. Unit derives from

'Secondary_value_1_unit'

- Unit code of 'Secondary_value_1'

corresponding values will be converted by density factor

from 'Secondary_value_2_unit'

'Sensor_range.unit'

sensor value, i.e. the uncalibrat

of length type engineering unit and access to parameters the

ted as input to AIFB by setting 'Channel' = 3. Unit derives

e_2"

ed measurement value from the sensor. Unit derives from

28258-EN-081209

dation Fieldbus

10 Supplement

l sensor_range

- "Sensor_range.un

- includes sensor unit: bar, PSI …; only unit p

l simulate_primary_value
l simulate_secondary_value_1
l simulate_secondary_value_2
l device status

- "0: ""OK"" 13: ""non-specific error"" 17: ""Cal

""ROM memory fault"" 37: ""RAM memory fault"" 40: ""non-specific hardware fault"" 41: ""Sensor
element not found"" 42: ""No leaking pulse"" 43: ""No trigger signal"" 44: ""EMI error"" 113:
""Communication hardware fault"""

l linearization type

- Possible types of linearization are: linear, user defined, cylindrical lying container, spherical

container

- "0: ""Line

l curve_points_1_10

ar"" 1: ""User def"" 20: ""Cylindrical

- X and Y values

l curve_points_11_20

- X and Y values

l curve_points_21_30

- X and Y values for the user

l curve_points_31_33

it' refers to 'Sensor_value', 'Max/Min_peak_sensor_value', 'Cal_point_hi/lo'

art of DS-68 is writable

span too small"" 34: ""EEPROM memory fault"" 36:

lying container"" 21: ""Spherical container"""

for the user

for the user defined linearization curve

defined linearization curve

defined linearization curve

- X and Y values for the user defined linearization curve

l curve status

- Result of table plausibility check

- "0: ""Uninitialized"" 1: ""Good"" 2: ""Not monotonous

decreasing"" 4: ""Not enough values transmitted"" 5: ""Too many values transmitted"" 6:
""Gradient of edge too high"" 7: ""Values not excepted"" 8: ""Table currently loaded"" 9: ""Sorting
and checking table"""

l SUB_DEVICE_NUMBER
l SENSOR_ELEMENT_TYPE

- 0: "non-sp

l display_source_sel

- Selects the type of value that is displayed on the indication-/adjustement-module

- "0: ""Physical value"" 1: ""Percent

""Out(AI2)"" 9: ""Out(AI3)"""

l max_peak_sensor_value

- Holds the maximum sensor value. Write access resets to current value. Unit derives from

- Write

l min_peak_sen

- Holds the minimum sensor value. Write access resets to current value. Unit derives from

ecific"

ector

value"" 2: ""Lin percent value"" 6: ""Out(AI1)"" 7: ""Level"" 8:

'Sensor_range.unit'

access resets to current value

sor_value

'Sensor_range.unit'

increasing"" 3: ""Not monotonous

- Write access resets to current value

l CAL_POINT_HI

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 65

10 Supplement

- Highest calibrated value. For calibration

value (pressure) to the sensor and transfer this point as HIGH to the transmitter. Unit derives from
'Sensor_range.unit'

l CAL_POINT_LO

est calibrated value. For calibrati

- Low

(pressure) to the sensor and transfer this point as LOW to the transmitter. Unit derives from
'Sensor_range.unit'

l CAL_MIN_SPAN

- Minimum calibration span value allowed. Necessary to

two calibrated points (high and low) are not too close together. Unit derives from 'Sensor_range.
unit'

l SCALE_IN

- Min/max-adjustment: Upper

'Sensor_range.unit'

l trimmed_value

and lower calibrated points of the sensor. Unit derives from

- Sensor value after the trim processing. Unit derives

l sensor_sn

of the high limit point you give the high measurement

on of the low limit point you give the low measurement value

ensure that when calibration is done, the

from 'Sensor_range.unit'

- Sensor serial number

l temperature

- Proc

l temperature_unit

ess temperature. Selected

'Temperature.unit'

- Unit code of 'Temperature', 'Max/Min_peak_temperature_value'

as input to AIFB by setting 'Channel' = 4. Unit derives from

- °C, °F, K, °R

l max_peak_temperature_value

- Holds the maximum process temperature. Write access resets to current value. Unit derives
from 'Temperature.unit'

- Write access resets to current value

l min_peak_t

- Holds the minimum process temperature. Write access resets to current value. Unit derives

- Write

emperature_value

from 'Temperature.unit'

access resets to current value

66 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

10.3 Dimensions

~ 69 mm

(2.72")

ø 77 mm

(3.03")

112 mm (4

13

/

32

")

M20x1,5/
½ NPT

~ 69 mm

(2.72")

ø 77 mm

(3.03")

117 mm (4.61")

M20x1,5/
½ NPT

~ 87 mm (3.43")

M16x1,5

ø 84 mm

(3.31")

120 mm (4.72")

M20x1,5/
½ NPT

~ 116 mm (4.57")

ø 84 mm (3.31")

116 mm (4.57")

M20x1,5M20x1,5/

½ NPT

~ 59 mm

(2.32")

ø 80 mm

(3.15")

112 mm (4.41")

M20x1,5/
½ NPT

1

3

4

5

2

10 Supplement

Housing

Fig. 31: Housing
9 mm/0.35 in higher)
1 Plastic housing
2 Stainless steel housing

in protection class IP 66/IP 67

versions

protection IP 66/IP 67 (with integrated indicating and adjustment module the housing is

in

3 Special steel casting housing
4 Aluminium double chamber housing
5 Aluminium housing

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 67

117 mm (4.61")

120 mm (4.72")

~ 103 mm

(4.06")

~ 105 mm (4.13")

ø 77 mm

(3.03")

116 mm (4.57")

~ 150 mm (5.91")

ø 84 mm (3.31")

ø 84 mm

(3.31")

~ 93 mm

(3.66")

ø 80 mm

(3.15")

112 mm (4.41")

M20x1,5/
½ NPT

M20x1,5

M20x1,5/
½ NPT

M16x1,5

4

2 3

M20x1,5M20x1,5

1

10 Supplement

Housing in protection IP 66/IP 68 (1 bar)

Fig. 32: Housing

versions

in

protection IP 66/IP 68, 1 bar (with integrated indicating and adjustment module the

housing is 9 mm/0.35 in higher)

1 Stainless steel housing
2 Special steel casting housing
3 Aluminium double chamber housing
4 Aluminium housing

68 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

IP 68 version with external housing

1

2

65 mm

(2 9/16")

68 mm

(2

43

/

64

")

92 mm

(3

5

/

8

")

42mm

(1 21/32")

40mm

(1 37/64")

90 mm (3 35/64")

110 mm (4 21/64")

~ 66 mm (2 19/32")

59 mm (2

21

/

64

")

10 Supplement

Fig. 33: IP 68 version with external
1 Lateral cable outlet
2 Axial cable outlet

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

housing

s 69

122mm (4

51

/

64

")

122mm (4

51

/

64

")

51mm

(2

1

/

64

")

3

5

/

8

"

7

1

/

2

"

1/

8

"

1/

8

"

4xø

5

/

8

"

4xø

5

/

8

"

4

3

/

4

"

6“ 5“

3

/

4

"

2“

1/

8

"

4xø

5

/

8

"3

7

/

8

"

3

/

4

"

3

5

/

8

"

1/

8

"

4xø

5

/

8

"4

3

/

4

"

3

/

4

"

3

/

4

"

7

1

/

2

"

1/

8

"

4xø

5

/

8

"6“ 5“

3

/

4

"

6"

5

"

6"

DN PN D k

b

FR 25 40 115 18 85

FB 40 40 150 18 110

FC 50 40 165 20 125

d2

4xø14

4xø18
4xø18

d4

68

88

102

f

2

3
3

FK 80 40 200 24 160 8xø18 138 3

FD 50 40 165 20 125

FG 50 40 165 20 125
FH 80 40 200 24 160

4xø18

4xø18
8xø18

102

102
138

3

3
3

RL

-

-

-

100

50

200

-

d5

-

-

-

76

48,3

48,3

-

dM

-

ED 20 40 105 18 75 4xø14 58 2 - - -

EG 32 40 140 18 100 4xø18 78 2 - - -

-

-

72

FU 80 40 200 24 160 8xø18 138 3 200 76 72

F1 1" 150

FJ 80 40 200 24 160 8xø18 138 3 50 76 72

- - -

F5 2" 150

" lbs D b k d2 d4 f RL d5 dM

- - -

F7 2" 150

2" 1,9" -

FS 3" 150

- - -

FQ 3" 150

6" 2,9" -

47

FE 50 40 165 20 125 4xø18 102 3 100 48,3 47

47

-

EE 100 40 235 24 190 8xø22 162 3 100 76 72

d2

d4

k
D

f

b

ED, FR, EG, FB, FC,

FH, F1, F5, FS, EE

d5

RL

FD, FE, FG, FJ, FK

F7, FU, FQ

3

3

1

2

10 Supplement

VEGABAR 61 - flange

version

Fig. 34: VEGABAR 61 - flange version
1 Flange connection
2 Flange fitting according to ANSI B16.5
3 Diaphragm diameter

70 VEGABAR 61 • Foun

according to DIN 2501

28258-EN-081209

dation Fieldbus

3

5

/

8

"

7

1

/

2

"

1/

8

"

1/

8

"

4xø

5

/

8

"

4xø

5

/

8

"

4

3

/

4

"

6 6

3

/

4

"

3

7

/

8

"

2

9

/

32

"

2

43

/

64

"

3

15

/

32

"

4

1

/

64

"

4

1

/

64

" 1

29

/

32

" 1

31

/

32

"

3

15

/

16

"

7

7

/

8

"

3

15

/

16

"

1

31

/

32

"

1

27

/

32

"

1

27

/

32

"

1

27

/

32

"

1

29

/

32

"

1

29

/

32

"

2

63

/

64

" 2

53

/

64

"

2

53

/

64

"

2

53

/

64

"

2

63

/

64

"

4

1

/

64

"

4

1

/

64

"

5

7

/

16

"

5

7

/

16

"

5

7

/

16

"

5

7

/

16

"

3

5

/

64

"

1/

8

"

5/

64

"

5/

64

"

5/

64

"

1/

8

"

1

/

8

"

1/

8

"

1/

8

"

1/

8

"

1/

8

"

1/

8

"

1/

8

"

4xø

5

/

8

"

4xø

35

/

64

"

4xø

35

/

64

"

4xø

45

/

64

"

4xø

45

/

64

"

4xø

45

/

64

"

4xø

45

/

64

"

4xø

45

/

64

"

4xø

45

/

64

"

8xø

45

/

64

"

8xø

45

/

64

"

8xø

45

/

64

"

3

7

/

8

"

2

61

/

64

"

4

21

/

64

"

4

59

/

64

"

4

59

/

64

"

4

59

/

64

"

4

59

/

64

"

6

19

/

64

"

6

19

/

64

"

6

19

/

64

"

3

15

/

16

"

3

11

/

32

"

3

/

4

"

3

5

/

8

"

1/

8

"

4xø

5

/

8

"4

3

/

4

"

3

/

4

"

3

/

4

"

7

1

/

2

"

1/

8

"

4xø

5

/

8

"6 6

3

/

4

"

4

9

/

64

"

4

17

/

32

"

5

33

/

64

"

5

29

/

32

"

6

1

/

2

"

6

1

/

2

"

6

1

/

2

"

6

1

/

2

"

7

7

/

8

"

7

7

/

8

"

7

7

/

8

"

45

/

64

"

45

/

64

"

45

/

64

"

45

/

64

"

25

/

32

"

25

/

32

"

25

/

32

"

15

/

16

"

15

/

16

"

15

/

16

"

25

/

32

"

6"

5"

6

"

D

N PN D k b

FR 25 40

FB 40 40

FC 50 40

d2 d4 f

FK 80 40

1

/

8

"

8xø

45

/

64

"6

19

/

64

"7

7

/

8

" 7

7

/

8

" 2

63

/

64

"

15

/

16

"

80 40

FD 50 40

FG 50 40
FH 80 40

RL

-

-

-

-

d5

-

-

-

-

dM

-

ED 20 40 - - -

EG 32 40 - - -

-

-

FU

F1 1" 150

FJ 80 40

- - -

F5 2" 150

" lbs D b k d2 d4 f RL d5 dM

- - -

F7 2" 150

2" 1,9" -

FS 3" 150

- - -

FQ 3" 150

6" 2,9" -

FE 50 40

-

6

3

/

8

"

1/

8

"

8

xø

55

/

64

"7

31

/

64

"9

1

/

4

"

15

/

16

"

EE 100 40 - - -

d2

d4

k
D

f

b

ED, FR, EG, FB, FC,

FH, F1, F5, FS, EE

d5

RL

FD, FE, FG, FJ, FK

F7, FU, FQ

122mm (4

51

/

64

")

122mm (4

51

/

64

")

5

1mm

(2

1

/

64

")

3

1

2

3

10 Supplement

VEGABAR 61 - flange

Fig. 35: VEGABAR 61 - flange version
1 Flange connection

version

according to DIN 2501
2 Flange fitting according to ANSI B16.5
3 Diaphragm diameter

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 71

4

31

/

64

" 1

13

/

16

" 1

1

/

32

"

5

33

/

64

" 2

3

/

64

" 1

17

/

64

"

6

9

/

64

" 2

3

/

4

" 1

31

/

32

"

DNmmPN G1 D2L2

RT 25 40 Rd52x1,6

Rd58x1,6

Rd78x1,6

G1
Rd52x1,6

Rd58x1,6

Rd78x1,6

114 46Mb26

RQ 32 40 140 52 32

RW 50 25 156 70 50

DN

inch

PN dD
RH 25 40
RH 32 40
RH 50 25

Mb

2

23

/

64

"1

1

/

8

"2

31

/

64

"

DN PN D LMb

RA 25 6... 400

DN

mm

inch

PN D L

Mb

RA 25 6…400 63 28,5 60

6

9

/

64

" 2

33

/

64

" 2

7

/

32

" 2

13

/

64

" 2

61

/

64

" 1

57

/

64

"

DNmmPN L dD

RH 2“ 40 156 64 56,3

D2D1

56 75Mb48

DN

inch

PN L dD

RH 2“ 40

D2D1 Mb

106 mm (4 11/64")

3

2

D

Mb

L

D

d

Mb

D2

D1

L

Mb

D2

L2

g

G1

1

106 mm (4 11/64")

106 mm (4 11/64")

10 Supplement

VEGABAR 61 - tube iso

lating diaphragm 1

Fig. 36: VEGABAR 61 - tube isolating diaphragm
1 Tube
2 Tube isolating diaphragm Tri-Clamp

72 VEGABAR 61 • Foun

isolating diaphragm for mounting between flanges, cell design

dation Fieldbus

28258-EN-081209

4

31

/

64

" 5

3

/

64

" 1

1

/

32

"

6

9

/

64

" 6

11

/

16

" 1

31

/

32

"

6

17

/

32

" 7

11

/

64

" 3

3

/

16

"

DNmmPN G1 LGL

RE 25 40 Rd52x

1

/

6

Rd78x

1

/

6

Rd110x

1

/

4

G1

Rd52x

1

/

6

Rd78x

1

/

6

Rd110x

1

/

4

114 128Mb26

RP 50 25 140 170 50

RO 80 25 156 182 81

DN

inch

PN LGD
RH 25 40
RH 50 25
RH 80 25

Mb

4

3

/

32

"

25

/

64

"

DNmmPN G1 MbL
RK
RS

10 40

RD44x

1

/

6

RD28x

1

/

8

RD28x

1

/

8

RD44x

1

/

6

104
104

10

20 40 20

DN

inch

PN G1 dD

RK

10 40

4

3

/

32

"

25

/

32

"RS 20 40

106 mm (4

11

/

64

")

1

Mb

L

G1

LG

2

106 mm (4 11/64")

L

10 Supplement

VEGABAR 61 - tube iso

lating diaphragm 2

Fig. 37: VEGABAR 61 - tube isolating diaphragm
1 Tube

isolating diaphragm with threaded socket according to DIN 11851

2 Tube isolating diaphragm with threaded socket according to DIN 11864-1

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 73

128 mm

(5

3

/

64

")

M55x2

ø 56mm

(2

13

/

64

")

ø 44,5mm

(3

3

/

4

")

~ 132 mm

(5

13

/

64

")

ø 38,5 mm

(1

33

/

64

")

10 Supplement

VEGABAR 61 - tube iso

lating diaphragm 3

Fig. 38: VEGABAR 61 - tube isolation diaphragm - ECO

74 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

RV

115 mm (4

17

/

32

")

ø 78 mm

(3 5/64")

10 Supplement

VEGABAR 61 - hygienic fi

tting

Fig. 39: VEGABAR 61 - RV = bolting according to DIN 11851

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 75

135 mm (5

5

/

16

")

100 mm (3

15

/

16

")

b

4

17

/

32

"

45

/

64

" 2

43

/

64

"

5

29

/

32

"

45

/

64

" 3

15

/

32

"

6

1

/

2

"

25

/

32

" 4

1

/

64

"

DNmmPN

bD

ZA 25 40

115 18d468

ZB 40 40

150 18 88

ZC 50 40

165 20 102

d2k

85 14

110 18

125 18

ZD 80 40

200 24 138

160 18

DN

inch

PN

bD
ZA 25 40
ZB 40 40

ZC 50 40

d4

3

11

/

32

"

35

/

64

"

4

21

/

64

"

45

/

64

"

4

59

/

64

"

45

/

64

"

7

7

/

8

"

15

/

16

" 5

7

/

16

"

ZD 80 40

6

19

/

64

"

45

/

64

"

d2

k

d4

d2

k

D

10 Supplement

VEGABAR 61 - cell isolatin

g diaphragm

Fig. 40: VEGABAR 61 - ZA = cell isolating diaphragm DN 25/PN 16, ZB = cell
= cell isolating diaphragm DN 50/PN 16, ZD = cell isolating diaphragm DN 80/PN 16

76 VEGABAR 61 • Foun

isolating diaphragm DN 40/PN 16, ZC

28258-EN-081209

dation Fieldbus

VEGABAR 61 - threaded version

SW32

SW41

SW55

SW55

G¾B

G1B

1½”NPTG1½B

ø 22 mm

(0.87")

ø 32 mm

(1.26")

20 mm

(0.79")

~105 mm

(4.13")

~105 mm

(4.72")

~105 mm

(4.13")

~120 mm

(4.72")

ø 25 mm

(0.98")

ø 39 mm

(1.54")

28 mm

(1.1")

ø 40 mm

(1.58")

ø 60 mm

(2.36")

30 mm

(1.18")

ø 40 mm

(1.58")

ø 60 mm

(2.36")

30 mm

(1.18")

GB

GC

GD/GF GN

SW 41 mm

G1B

76 mm

(2.99")

28 mm

(1.1")

GE

ø 30 mm

(1.18")

10 Supplement

Fig. 41: VEGABAR 61 - threaded version

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 77

SW27

G1A

ø 26 mm

(1

1

/

32

")

L

10 Supplement

VEGABAR 61 - Threaded version

Fig. 42: VEGABAR 61 - threaded version with

with temperature adapter

temperature adapter. The length depends on the respective

temperature stage, e.g. L = 152 mm (6 in) at 200 °C (392 °F)

78 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

10.4 Industrial property rights

10 Supplement

10.5 Trademark

VEGA produc
Further information see http://www.vega.com.

Only in U.S.A.: Further information see patent label at the sensor
housing.

VEGA Produktfamilien sind weltweit geschützt durch gewerbliche
Schutzrechte.

Nähere Informationen unter http://www.vega.com.

Les lignes de produits VEGA sont globalement protégées par des
droits de propriété intellectuelle. Pour plus d'informations, on pourra
se référer au site http://www.vega.com.

VEGA lineas de productos están protegidas por los derechos en el
campo de la propiedad industrial. Para mayor información revise la
pagina web http://www.vega.com.

Линии продукции фирмы ВЕГА защищаются по всему миру
правами на интеллектуальную собственность. Дальнейшую
информацию смотрите на сайте http://www.vega.com.

VEGA系列产品在全球享有知识产权保护。
进一步信息请参见网站<http://www.vega.com>。

All brands used as well as trade and company names are property of
their lawful proprietor/originator.

t lines are global protected by industrial property rights.

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 79

10 Supplement

80 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

10 Supplement

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 81

10 Supplement

82 VEGABAR 61 • Foun

28258-EN-081209

dation Fieldbus

10 Supplement

28258-EN-081209

VEGABAR 61 • Foundation Fieldbu

s 83

VEGA G rieshaber KG

ISO 9001

Am Hohenstein 113
77761 Schiltach

Germany
Phone [phone]
Fax [phone]
E-mail: [e-mail]

www.vega.com

Printing date:

All statements concerning scope of delivery, application,

practical use

and operating conditions of the sensors and

processing systems correspond to the information avail-

able at the time of printing.

© VEGA Grieshaber KG, Schiltach/Germany 2008

Subject to change without prior notice 28258-EN-081209
