RoboSHOT 40 UHD
©2018 Milestone AV Technologies.
Broadcast-Quality PTZ Camera
Superior Broadcast Quality Images at an Exceptional Price
RoboSHOT® 40 UHD is an outstanding broadcast-quality
PTZ camera with 40x zoom, genlock capabilities, silky-
smooth motor movement and outstanding image quality
– all at a surprisingly competitive price for the entry-level
broadcast PTZ camera market.
Whether it’s a television show, sporting event, government
meeting or wedding ceremony, RoboSHOT 40 UHD
promises truly brilliant 4K video footage for broadcasting,
streaming and recording.
Advanced Features with 4K Image Quality
Genlock
Designed with a genlock external sync port, the RoboSHOT 40 UHD camera provides accurate synchronization in multi-
camera broadcast environments. The camera also oers phase compensation to ne-tune and adjust the genlock signal.
IntelliZoom™ Image Processing
In addition to an incredible 30x zoom with 4K resolution at 30fps, you can achieve full high denition 40x zoom with
1080p/60fps performance with the latest advancements in intelligent zooming technology. Most digital zooms use
electronic cropping to get closer to the subject, resulting in fuzzy images. The RoboSHOT 40 UHD camera’s powerful
processor compares patterns found in adjacent pixels and creates new pixels to match selected patterns, resulting in
more realistic, higher-quality images.
Matching
Pattern
Categorization
IntelliZoom
Extracted pixel and
adjacent pixels
WDR OFF WDR ON
Database
process
Enhanced Wide Dynamic Range (WDR)
With its back-illuminated CMOS image sensor, RoboSHOT
40 UHD oers more powerful image signal processing (ISP)
– resulting in better light-gathering capabilities, incredible
contrast and sharp 4K video, even in dim lighting conditions.
Enhanced WDR helps correct for environments with uneven
lighting by making darker or over-bright areas in video more
visible and detailed. The RoboSHOT 40 UHD produces
brilliant images in varied light settings like sanctuaries or
outdoor live events. The WDR can be turned o and on via
the web-based user interface or through serial commands.
Spotlight Compensation Mode
Expect exceptional performance in the presence of high
intensity spotlights seen in performance halls, live event
venues, and night-time outdoor sporting events.
Silky-smooth & Silent Pan Tilt Zoom Motion
Experience the world’s smoothest pan, tilt and zoom
operation with Vaddio’s next generation silent motors paired
with Tri-Synchronous motion algorithms. Even at full zoom,
the RoboSHOT 40 UHD moves with no jitter or bouncing.
Flexible Mounting Options
Like most other RoboSHOT cameras, RoboSHOT 40 UHD
can be inverted, ceiling mounted or wall mounted for
maximum exibility.
Remote Management
RoboSHOT 40 UHD oers an intuitive user interface for
administrative control and remote operation via
web interface.
Professional Results for Any Market
Concert Halls and Auditoriums
With a powerful 40x zoom and spotlight
compensation mode, every part of your
auditorium is within reach including ever-
changing stage lighting.
House of Worship
Ideal for churches and worship areas, the 40x
zoom expands your reach to the nest detail.
And Enhanced WDR compensates for bright
windows and darker corners.
Live Events
When it comes to live events, this camera excels
– with incredibly fast, uid and accurate pan-
tilt-zoom motion. It’s the perfect solution for live
streaming outdoor sporting events, concerts,
programs and other special events. Even
with harsh spotlights, you can expect brilliant
4k images thanks to the camera’s spotlight
compensation feature, plus superb detail at
extreme distances with the expanded zoom.
Broadcast TV
Perfect for corporate broadcast, local tv stations
and campus news, RoboSHOT 40 UHD
cameras’ sophisticated CMOS image sensor
delivers gorgeous 4K images. Its silent operation
and ultra-smooth pan tilt zoom motion is ideal
for on-air broadcasting.
Technical Specications
Features
• Genlock signal for multi-camera synchronization
• Back-illuminated 8.51 Megapixel, ultra-high denition 1/2.5-type Exmor R CMOS sensor delivers native
2160p/30 (3840 x 2160) video
• 20x optical zoom with 30x lossless zoom at 3840 x 2160. Achieve 40x zoom at full HD resolution
• Horizontal eld of view: 70.2° (wide) to 4.1° (tele)
• Simultaneous IP streaming (RTSP or RTMP format with H.264 compression) up to 1080p/30
• Can be powered remotely with PoE++
Back of Camera
Connections, left to right
• Power Connector: 12 VDC, 3.0 amp
• OneLINK Port: HDBaseT output port carrying power, video and control . Also functions as
a standard Network port and can accept PoE++ if not using a OneLINK extender.
• HDMI Connector: HDMI video output to connect to a monitor display
• 3G-SDI
• Genlock sync port
• RS-232
• Camera resolution and frame rate settings
Ordering Information
Description
RoboSHOT 40 UHD PTZ Camera (Black) 999-9952-000 999-9952-001 999-9952-009
RoboSHOT 40 UHD PTZ Camera (White) 999-9952-000W 999-9952-001W 999-9952-009W
North America Europe/UK Australia/New Zealand
THE ART OF EASY | legrandav.com
131 Cheshire Lane, Suite 500, Minnetonka, MN 55305
USA P 800.572.2011 E av.vaddio.support@legrand.com
EMEA P +31.495.580.840 E av.emea.sales@legrand.com
APAC P +852.2145.4099 E av.asia.sales@legrand.com
©2018 Milestone AV Technologies. 180298 A 12/18 Vaddio is a registered trademark of Milestone AV
Technologies. All other brand names or marks are used for identication purposes and are trademarks of
their respective owners. All patents are protected under existing designations. Other patents pending.
