PVR04H1
System Overview
As the perfect solution to upgrade existing video surveillance
systems, PVR supports penta-brid access technolo
gy such as HDCVI,
AHD, TVI, CVBS and IP to effortlessly integrate with popular industry
formats, offering an affordable solution loaded with flexible options.
It supports up to 4/8/16 channels of HDCVI/AHD/TVI/CVBS inputs,
and 2/4/8 channels IP camera additionally, 16 channels local live-
view channels, and 16 playback channels. Designed as a full
compatibility product, PVR is able to provide end user the simplicity
of analog system, namely lower system cost, simple installation and
use of existing cable. It is ideal for a wide range of applications such
as public safety, retail store, transportation, home protection and
education.
Funcons
Smart H.264+
Smart Codec, H.264+ can reduce up to 70% bit rate and storage
requirements without having to invest in new cameras.
HDCVI/AHD/TVI/CVBS Auto-detect
The PVR can auto recognize the signal of front-camera without
any setting. It makes operation more friendly and convenient.
5MP Resolution
The PVR supports 5MP HD resolution (2560 x 1920) IPC input
for recording, live viewing.
Spot Output
It is made for a secondary monitor. This allows the operator to view one
special monitor that assigned to selected cameras or video inputs from
higher security areas.
Intelligent Video System (IVS)
With built-in intelligent video analytics, the PVR has the ability to detect
and analyze moving objects for improved video surveillance. The PVR
provides oponal standard intelligence at the edge allowing detecon of
mulple object behaviors such as abandoned or missing objects. IVS also
supports Tripwire analycs, allowing the camera to detect when a pre-
determined line has been crossed.
Face Detecon
It is a type technology being used in a variety of applicaons that search
or idenfy individuals which show front cameras.
Smart Search
This funcon helps you get more moon detect video during a short
me through drawing a region when playback. It is very useful when an
emergency occurs.
· Embedded processor
· H.264+/H.264 dual-stream video compression
· Support HDCVI/AHD/TVI/CVBS/IP video inputs
· Max 6/12/24 channels IP camera inputs, each channel up
to 5MP
· Max 24/48/96Mbps Incoming Bandwidth
· Smart Search and Intelligent Video System
PVR04/08/16H1
4/8/16 Channel Penta-brid 1080P Lite Mini 1U Digital Video Recorder
Series
Lite
Plug&Play
P2P
1080p
HDMI / VGA
4/8/16CH
Smart H.264+
