UNIVIEW nvr201-08lp Quick Manual

Manual Version:V1.03

1

NVR Quick Guide

Welcome

Thank you for choosing our product. This guide contains useful

information about using the device. Please read through this guide

before you start.

Notice

 All operations should comply with your local electrical safety

codes.

 We (including our dealers) shall not be held responsible for any

damage or loss caused by improper handling during the

installation or use of the device.

 The illustrations in this guide are for reference only and may be

different from the actual device. This guide is subject to

change without notice.

Packing List

Please check the items in your package carefully. Contact your dealer if

you find anything missing or damaged.

 Power adapter

 Hard disk data cable

 Hard disk power cable

 Mouse

 Screws

 User document

 Anti-counterfeiting notice

 Power cable (for some models only)

2

Installation

This NVR series has only one hard disk. Please follow the steps to install

the disk. A screwdriver is needed. The following figures are only for

illustration purpose.

1. Loosen the screws on the

bottom cover.

2. Fix the four screws on the

disk without fully tightening them.

3. Align holes on the disk with

holes on the bottom cover.

4. Secure the disk to the bottom

cover using four screws.

5. Connect the data and power

cables.

6. Place the cover in position and

then fix the four screws.
