DATASHEET
4K Ultra HD Vandal-resistant Fisheye Fixed
Dome Camera
IPC868ER-VF18-B
Key Features
Optics
Ultra wide angle lens, 360°panoramic image
Embedded infrared light, 360°fill-in light, Up to 10 m (33 ft) IR distance
2D/3D DNR (Digital Noise Reduction)
Compression
Max. 4000 * 3000 resolution
Ultra265,H.265, H.264, MJPEG
Built-in microphone & speaker, two-way talk supported
ROI (Region of Interest)
Distortion correction supported
Network
ONVIF Conformance
Structure
Support PoE power supply
Wide temperature range: -30°C to 60°C (-22°F to 140°F)
2
DATASHEET
IPC868ER-VF18-B
Camera
Image sensorq
1/1.7", progressive scan,12.0 megapixel, CMOS
Lens
1.8mm@ F2.4
Shutter
Auto/Manual, shutter time：1/6 s ~1/100000 s
Minimum Illumination
Colour: 0.05 Lux (F2.4, AGC ON)
0 Lux with IR
Day / Night
IR-cut filter for day & night function
Digital noise reduction
2D/3D DNR
S/N Ratio
>52dB
IR Range
Up to 10 m (33 ft)
Defog
Digital Defog
WDR
DWDR
Video
Compression
Ultra265, H.265, H.264,MJPEG
H.264 code profile
Baseline profile, Main Profile, High Profile
Fisheye Frame Rate
Main Stream :15 fps(4000×3000, 3000×3000), 25 fps(2560×2560);
Sub Stream: 15 fps(2000×1500, 2000×2000), 25 fps(2000×2000);
Third Stream: 15 fps(720×576, 320×288)
Panorama
25 fps(3000×2000);
15 fps(4000×3000,3000×2000,3000×1500)
Frame Rate PTZ
15 fps(1920×1080)
ROI
Up to 8 areas
BLC
Supported
OSD
Up to 8 OSDs
Privacy Mask
Up to 8 areas
Motion Detection
Up to 4 areas
Audio
Audio Compression
G.711
Two-way audio
Supported
Suppression
Supported
Sampling Rate
8 KHZ
Storage
Edge Storage
Micro SD, up to 128GB
Network Storage
ANR
Network
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x,
SNMP
Wide voltage range of ±25%
IK10
IP66
Specifications
3
DATASHEET
Compatible Integration
ONVIF(Profile S, Profile G), API
Live View Display
Mount Type
Support table, wall, and ceiling
Display Mode
Support 10 display modes in total (including display modes of mount types and decoding modes):
Display Mode:Original Image, Fisheye+4PTZ, Panoramic
Preview Mode: Original Image , 360°Panoramic+1PTZ, 180°Panoramic, Fisheye+3PTZ , Fisheye+4PTZ, 360°
Panoramic+6PTZ, Fisheye+8PTZ
Interface
Audio I/O
Audio interface
Input: impedance 35 kΩ; amplitude 2 V [p-p]
Output: impedance 600 Ω; amplitude 2 V [p-p]
Alarm I/O
2 / 1
Multiple Alarm linkage editable
Built-in Mic
Supported
Built-in Speaker
Supported
Serial
1 channel RS485 interface
Network
1 RJ45 10M/100M Base-TX Auto-adaptive Ethernet
Video Output
1 BNC, impedance 75 Ω; amplitude 1 V [p-p]
General
Power
DC12V±25%, PoE（IEEE802.3af）
Power consumption: Max. 21W
Dimensions (Ø x H)
Φ149mm x 55mm (Φ5.87” x 2.17”)
Weight
0.5kg(1.1lb)
Working Environment
-35℃~60℃(-31°F ~ 140°F), Humidity :10%~90% RH
Ingress Protection
IP66
Vandal Resistant
IK10
Reset Button
Supported
Dimensions
4
DATASHEET
Installation mode
Accessories
Description
Ceiling mount
Mounting pedestal is included in the product package
TR-UM06-C-IN junction box and TR-A01-IN waterproof joint
for the junction is optional
TR-JB04-A-IN junction box and TR-A01-IN waterproof joint
for the junction is optional
Wall mount
TR-JB07/WM04-IN
For outdoor wall installation, excluding junction box
TR-JB07/WM04-A-IN
For outdoor wall installation, including junction box
TR-A01-IN waterproof joint for the junction is optional
Pole mount
TR-WM03-A-IN +TR-UP06-IN
For indoor wall installation, excluding junction box
T TR-JB07/WM04-A-IN (Or TR-WM04-IN)+TR-UP06-IN
For indoor wall installation, including junction box
TR-UF45-F-IN+TR-CE45-IN
For indoor wall installation, including junction box
Zhejiang Uniview Technologies Co.,Ltd.
South Tower, Building 10, Wanlun Science Park, 88 Jiangling Road, Hangzhou, P.R.China 310051
Email：overseasbusiness@uniview.com;globalsupport@uniview.com
http://www.uniview.com
© 2017 Zhejiang Uniview Technologies Co.,Ltd. All rights reserved.
*Product specifications and availability are subject to change without notice.
