Universal Remote Control (URS) TKP-2000 User Manual
Owner’s Manual
TKP-2000
Network Keypad
TKP-2000 Installation Manual ©2011-2013 Universal Remote Control, Inc.
The information in this Owner’s Manual is copyright protected. No part of this
manual may be copied or reproduced in any form without prior written
consent from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN
THIS MANUAL.
The information in this Owner’s Manual may be subject to change without
prior notice.
Total Control is a registered trademark of Universal Remote Control,
Inc.
URC Control the Experience is a registered trademark of Universal
Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks
of their respective companies or organizations.
Universal Remote Control,Inc.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OF CONTENTS
Congratulations! 1
Features and Benefits 2
Parts List 2
TKP-2000 Product Description 3
Displaying the Settings Screen 4
Adjusting Sleep Settings 4
Button Light Settings 4
Setting Date and Time 4
Sound 5
Adjusting Brightness 5
System 5
Network 5
Factory Default 6
Exit 6
Frequently Asked Questions 7
Specifications 7
Limited Warranty Statement 8
End User Agreement 10
Federal Communication Commission
Interference Statement 11
Regulatory Information to the user 12
Declaration of Conformity 13
Page 1
TKP-2000 NETWORK KEYPAD
Congratulations!
You've purchased a unique synthesis of hardware and software engineering,
the Total Control TKP-2000 Network Keypad. The TKP-2000 achieves a
magnificent combination of power and flexibility by simplifying and
automating the operation of even the most complex systems.
The TKP-2000 has the ability to control audio video components, energy
management devices, multi-zone matrixes, PCs, iPods and whole house
URC Lighting. It communicates over the Local Area Network (LAN) to the
MRX Advanced System Controller.
An MRX Advanced System Controller is REQUIRED for the TKP-2000 to
operate. The combination of the TKP-2000 and MRX-10 create a robust and
powerful system to control the Total Control product line and your home
theatre equipment.
Page 2
TKP-2000 NETWORK KEYPAD
Features and Benefits
Two-Way Control Of Devices
With the URC two-way database you can control (with feedback)
all compatible brands of receivers, lighting systems, alarms and thermostats.
Two-Way Control of Media on PSX-2 and SNP-1
The high speed of the LAN enables the TKP-2000 to display lists of
artists, albums or songs and to display the cover art of the selected
album on the Now Playing screen of the remote control from the
PSX-2 Personal Server or from the SNP-1 Streaming Network Player.
Backlit Color LCD screen
The TKP-2000 has a programmable 3.5” color LCD screen and backlit
"hard" buttons. When any button is pressed the color LCD screen
will turn on, and the "hard" buttons will illuminate.
User Configurable Information Feeds for News, Sports, Stocks and
Weather
The well known URC modules for News, Sports, Weather and Stocks
are all available, configured for the TKP-2000 screen. Of course these
are all user configurable.
No batteries to replace...Ever!
The TKP-2000 is powered over the Ethernet cable it's connected to,
so you never have to worry about replacing batteries.
Parts List
The TKP-2000 Network Keypad includes:
1 - TKP-2000 In-Wall Network Keypad
1 - Owner's Manual
4 - Screws for mounting to a wall box
TKP-2000 Product Description
The TKP-2000 consists of a 3.5” color touchscreen and 6 customizable
buttons. Your whole house custom installer can request custom buttons
specific to your Total Control setup.
Power: Turn ON the room where the TKP-2000 is located (or any other
room if using the Rooms Menu)
Lights: Press to control URC Lighting throughout your home.
Main: Press to view the main screen and control the Total Control system.
Vol+, Vol- and Mute: Easily adjust the volume settings for any zone.
LAN port: This is connected by your whole house custom installer to
your home network via Ethernet cable to a PoE (Power over
Ethernet) switch.
Page 3
TKP-2000 NETWORK KEYPAD
