Universal Remote Control (URS) MRF-350 User Manual

MRF-350 Installation Manual
Optimizing Narrow Band Reception with
the RFX-250 and MSC System Remotes
MRF-350 Installation Manual ©2006 - 2013 Universal Remote Control, Inc.
The information in this owner’s manual is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL.
The information in this owner’s manual may be subject to change without prior notice.
Complete Control is a registered trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks of their respective companies or organizations.
TABLE OF CONTENTS
Introduction 1
Features and Benefits 2
Parts Guide 2
Optimizing Range and Reliability 3
Connecting IR and Setting Output Levels 6
Front Blaster Overload 7
Disabling the Front Blaster - Step by Step via PC 7
Controlling An Array of Identical Components or Zones 8
Identical Components/Zone - Step by Step via PC 8
Programming For Multiple Equipment Locations 11
Frequently Asked Questions 12
Warranty 12
Limited Warranty Statement 13
End User Agreement 15
Specifications 15
MRF-350 BASE STATION
Page 1
1. MSC System remote controls send radio waves in every direction, so your client enjoys “No More Pointing” operation!
Introduction
The MRF-350 base station is an “addressable” base station like the MRF-300. RF Addressing gives you the ability to control as many as 90 identical compo­nents throughout a house. However, the MRF-350 is equipped with the Narrow Band RF reception, so is only compatible with MSC System remotes.
2. The RFX-250 RF Sensor can be freely positioned out of way of the interference the A/V components create, connecting to the MRF-350 via a 10’ cable (which can be extended).
3. The MRF-350’s built-in Front Blaster sends commands to components in the same cabinet space as the MRF-350.
MRF-350 BASE STATION
Page 2
Features and Benefits
Interference Rejection and Extended RF Range via RFX-250
The MRF-350 receives RF (radio frequency) signals via the RFX-250 RF Sensor. The RFX-250 displays RF interference via a bright red LED, which flickers when interference is present. Simply relocate the RFX-250 out of the interference.
Expand Range by Adding RFX-250 RF Sensors in Remote Areas
The MRF-350 can power up to three RFX-250 RF Sensors connected in parallel to the RF Input connector.
Variable IR Output Matches Rear Panel IR Inputs
The MRF-350 is equipped with adjustable IR line outputs, each output can be indi­vidually matched to rear panel IR inputs on any component that is designed to be operated by a standard IR repeater. The outputs utilize a 3.5mm jack.
Up To Fifteen Equipment Locations With Identical Components
Each MSC System remote is “addressable.” They can be programmed to specifi­cally control components in a particular room by installing a base station at each location. In operation it’s simple: when you select a device located in the Den, the MX series remote only sends commands to the Den. When you select a device located in the Family Room, the MX-3000 only sends commands to it.
A Single MRF-350 Can Control an Array of Identical Components or Identical Zones of a Multi Zone Preamp/Matrix Switcher
Each MRF-350 has six “addressable” IR Line Outputs. For example, you can con­trol up to six identical TV’s with one MRF-350 or route volume commands for a specific zone to a particular zone IR input on a multi-zone preamp. If you have more than six identical components or zones, up to 15 additional MRF-350s can be installed to control them (thus allowing up to 90 identical components or zones in one house).
IR Input for Keypads or IR Repeater Systems
The MRF-350 rear panel IR input will relay IR Data from IR repeaters or Multi­Zone Keypads to all IR line outputs (does not support IR routing). The 5V, 100 milliamp output will directly power some brands and models of keypad directly.
Parts Guide
The MRF-350 RF Base Station includes:
1 - RFX-250 RF Sensor with integrated
antenna 1 - Mounting plate for RFX-250 1 - MRF-350 Base Station 1 - Mounting Plate for wall mounting the
MRF-350 8 - Screws for wall mounting the two
mounting plates 1 - 9V-300mA Power Supply
6 - Visible Flashers with 10 foot plug in cables. 6 - Extra self adhesive pads for Emitters 1 - 12’Connecting Cable 1 - Adjustment Tool (Screwdriver for RF ID
and IR level adjustment)
2 - Depluggable screw connectors for RF
connections when extending wires.
MRF-350 BASE STATION
Page 3
Optimizing Range and Reliability
1. Power on all AV components, lower all dimmers to 50% and power on anything that may create RF Interference (particularly devices with high speed microprocessors or hard drives).
2. Check that the address wheel on the bottom of the MRF-350 is set to ID#0 (the interference “sniffing” position).
3. Connect the MRF-350 to its DC wall adapter and plug the wall adapter into a live AC outlet. Place the MRF-350 in a convenient central loca­tion in the equipment rack. Unlike an MRF-250, the MRF-350 can be placed next to components with hard drives or high speed micro­processors. There is no RF circuitry inside the MRF-350 itself.
4. Connect the RFX-250 to the MRF-350’s RF INPUT. You can connect to either the screw connector or the jack as shown:
Slide off the mounting plate to reveal the RF ID# rotary switch. Check that the arrow pointer in the center of the wheel is pointed to 0, the default “interence sniffing” posi­tion. If it is not, use a small flat blade screwdriver (included) to set the RF ID# to 0.
When connecting a single RFX-250 to the MRF-350 utilize the cable with 3.5 mm plugs on both ends. When you need a longer wire or are connecting up to three RFX-250s, use a cable with tinned ends. Cable can be extended as much as 200’, then con­nected to the removable screw connector plugs. If you use CAT 5 connect four conductors to GND (one from each twisted pair) and connect the remain­ing conductors two at a time to 5V and DATA .
