Universal Remote Control (URS) KP-4000 User Manual

KP-4000 Installation Manual
Network Keypad
KP-4000 Installation Manual ©2010 Universal Remote Control, Inc.
The information in this manual is copyright protected. No part of this man­ual may be copied or reproduced in any form without prior written consent from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPER­ATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL.
The information in this manual may be subject to change without prior notice.
Complete Control is a registered trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks of their respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OF CONTENTS
Introduction 1
Features and Benefits 2
Parts Guide 2
Network Requirements and Power Options 3
Installation Notes 5
MAC Address Labels/Reset Button 5
Connections 5
IR OUT/RFTX-1 6
12V Power 7
In-Wall Installation 8
CCP MAC Address Discovery 9
Displaying the Settings Screen 10
Adjusting Sleep Settings 10
Button Light Settings 10
Setting Date and Time 10
Sound 11
Adjusting Brightness 11
System 11
Network 11
Factory Default 12
Exit 12
Frequently Asked Questions 13
Specifications 13
USA Limited Warranty Statement 14
Federal Communication Commission Interference Statement
15
Warning 15
FCC Caution 15
KP-4000 NETWORK KEYPAD
Introduction
The KP-4000 is a Network Keypad with the ability to control audio video components, energy management devices, multizone matrixes, PCs, iPods, and whole house URC Lighting. MAC addressing enables the use of multiple KP-4000’s and multiple MRX-1’s to control as many components as needed throughout the house.
1. The KP-4000 communicates over the LAN (Local Area Network) to IP controlled components and the URC MRX-1 Network Base Station.
2. The MRX-1 receives com­mands and controls the com­ponents via IR or Serial.
MRX-1 Network Base Station
IR Controlled Device
Router
PoE Injector
3. Self-adhesive “Flashers” affix to the Infrared sensors on the front panels of your client’s compo­nents. The Flashers relay com­mands to components. The flash­ers plug in to the MRX-1 rear flasher line outputs via their 10 foot cables. The MRX-1can also connect to components with rear panel IR Inputs via its adjustable IR Line Outputs.
Page 1
KP-4000 NETWORK KEYPAD
Features and Benefits
2-Way IP and RS-232 Home Theater AVRS
Via the unique URC 2-Way database, installers can drag and drop 2-Way pre-programmed modules into any KP-4000 for multi-zone receivers with either IP or via the MRX-1, RS-232 control.
2-Way IP Control of Media on PCs and iPods
The high speed of the LAN enables the KP-4000 to display lists of artists, albums or songs and to display the cover art of the selected album on the Now Playing screen of the remote control from the PSX-2 Personal Server or from a PC.
User Configurable Internet RSS for News, Sports, Stocks and Weather
The well known URC modules for News, Sports, Weather and Stocks are all available updated to the KP-4000 screen and of course, are completely user set.
User set Scenes for URC Lighting via RFTX-1
Your client can fully control the lighting in their home without expensive black boxes and exotic wiring. A lighting system can be as simple as a single URC RF lamp dimmer on a lamp that they’d love to control without getting out of a chair.The KP-4000’s optional RFTX-1 transmitter directly controls URC RF Dimmers and Switches. Your client can brighten, dim, and recall scenes, and they can store new scenes whenever they like, without a PC or a pro­grammer. They simply manually adjust each dimmer to the new set­ting, then press and hold a scene button on their KP-4000 (just like storing radio stations in a car radio!).
Local Control via RFTX-1 & MRF Base Station
Via an optional RFTX-1 transmitter, low cost wireless control of a local stack of components can be done via a standard MSC-400, MRF-350 or MRF-260.
Parts Guide
The KP-4000 Network Keypad includes:
1 - KP-4000 Network Base Station 1 - Owner’s Manual 4 - Screws for mounting to a wall box
Page 2
KP-4000 NETWORK KEYPAD
Network Requirements and Power Options
The KP-4000 must be connected to the same Local Area Network as the MRX-1 to function correctly. Additionally, in order for your client to enjoy internet features such as RSS feeds, the Local Area Network must be connected to the Internet.
You have three options to power the KP-4000. The KP-4000 is a PoE (power over ethernet) device and can be powered as shown by either a PoE switch or a PoE injector (PoE injectors may be separate­ly ordered from URC). This has the advantage that a single CAT 5 cable to the KP-4000 supplies all connections needed!
However, should you be installing a KP-4000 in a system where it is convenient to run an additional two conductor wire to the KP-4000 for power, you may power a KP-4000 from any 12V wall adapter with a 1 amp rating (12v wall adapters may be separately ordered from URC).
Option 1: PoE Switch
PoE Switch (not included)
KP-4000
Router
1. Connect the CAT 5 cable (RJ45) to the LAN connection on the rear of the KP-4000.
2. Plug the other end of the CAT 5 cable to the PoE switch (not included), which will power the KP-4000 and ensure that the PoE switch is properly configured and connected to the Router.
Page 3
