QUALITY
U.E.i. is committed to providing
a superior quality temperature
tester and placed a strong
emphasis on quality design,
forward thinking innovation, and
a systematic approach to product
development, to ensure that we
not only build a competitive
thermometer line, but a superior
one that creates real world
solutions.
The Apollo series offers logging
LOGGING
capabilities with 9,999 memory
positions, monitoring and uploading
data to a computer via USB can be
routine, helping to analyze system
performance trends with
the included software.
EXPECTATIONS
We include customers in this
process, by doing so we are
able to react to industry demands
and prioritize their requirements
into our product’s performance
helping us meet or exceed our
customer’
We also stand behind the Apollo
series with an industry leading
warranty
s changing expectations.
.
Conveniently located at the top
INPUT JACKS
allowing for unobstructed operation.
The Apollo II calculates differential T1
from T2, while the Apollo IV offers
simultaneous differential of
T1-T2 and T3-T4.
PROBE STORAGE
The Apollo series offers a unique
solution to storing probes. Now, just
wind the wires around the probes
and store away in the back storage
housing. This helps extend probe
life and keeps them ready for
the next job.
PERFORMANCE
The Apollo Digital Thermometer™
series was manufactured to
IIPP667
conform to the
meeting performance expectations
of water submersion and highpressure dust resistance. This
benchmark ensures the Apollo
will function as expected under the
most extreme working conditions.
7
standard,
The amber backlit display offers
DISPLA
large easy-to-read digits showing all
necessary information on screen
with a user-friendly navigation
to get to the functions
you need quickly.
Y
APOLLO I
DT301
APOLLO II
DT302
APOLLO IV
DT304
Functions
• Single Thermocouple input
• Temp range -346˚ to +2192˚F (J)
• Temp range -328˚ to +2498˚F (K)
• Data logging
• 9,999 Memory positions
• USB interface (software included)
• Thermocouple temperature offset
• MIN, MAX, AVG & Hold
• Probe Storage
• Accepts J, K, T and E type probes
• 5 year limited warranty
Safety Compliance
• IP67
• Water submersion (3’ for 30 min.)
• High pressure dust resistance
(max depression of 20 mbar for 8 hours)
• CAT 1 Overvoltage
• CE Certified
Accessories included
• 1 J type probe with clip
• 2 AAA batteries
• Quick Start Guide
• Owners Manual
Functions
• Dual Thermocouple input
• Differential T1-T2
• Temp range -346˚ to +2192˚F (J)
• Temp range -328˚ to +2498˚F (K)
• Data logging
• 9,999 Memory positions
• USB interface (software included)
• Thermocouple temperature offset
• MIN, MAX, AVG & Hold
• Probe Storage
• Accepts J, K, T and E type probes
• 5 year limited warranty
Safety Compliance
• IP67
• Water submersion (3’ for 30 min.)
• High pressure dust resistance
(max depression of 20 mbar for 8 hours)
• CAT 1 Overvoltage
• CE Certified
Accessories included
• 2 K type probes with lead wraps
• 2 AAA batteries
• Quick Start Guide
• Owners Manual
Functions
• Quad Thermocouple input
• Differential T1-T2 and T3-T4
• Temp range -346˚ to +2192˚F (J)
• Temp range -328˚ to +2498˚F (K)
• Data logging
• 9,999 Memory positions
• USB interface (software included)
• Thermocouple temperature offset
• MIN, MAX, AVG & Hold
• Probe Storage
• Accepts J, K, T and E type probes
• 5 year limited warranty
Safety Compliance
• IP67
• Water submersion (3’ for 30 min.)
• High pressure dust resistance
(max depression of 20 mbar for 8 hours)
CAT 1 Overvoltage
•
CE Certified
•
Accessories included
• 4 K type probes with lead wraps
• 2 AAA batteries
• Quick Start Guide
• Owners Manual
APOLLO SPECIFICATIONS
Measurement Range J-Type: -346˚ to +2192˚F (-210˚ to +1200˚C)
K-Type: -328˚ to +2498˚F (-200˚ to +1370˚C)
-Type: -418˚ to +752˚F (-250˚ to +400˚C)
T
E-Type: -238˚ to +1832˚F (-150˚ to +1000˚C)
isplay Resolution 0.1˚F/˚C < 1000˚
D
1.0˚F/˚C ≥ 1000˚
ccuracy J, K, T, and E-Type; ±[0.1% +1.0˚F (0.5˚C)]
A
[Below -148˚F (-100˚C): add 0.2% of reading
for J, K, and E-Type; and 0.1% of reading for T-Type]
Temperature 0.01% of reading 0.1˚F per ˚F(+0.05˚C per ˚C)
Coefficient for <+64˚F (+18˚C) or +82˚F (+28˚C)
[Below -148˚F (-100˚C): add 0.05% of reading
for J, K, and E-type; and 0.1% of reading for T-type]
Real Time About 1 second per day
Clock Tolerance
Maximum Differential 1V (maximum voltage difference between
Common Mode any pair of inputs)
Voltage
Temperature Scale ITS-90 (International Temperature Scale of 1990)
Applicable Standards N.I.S.T. Monograph 175 revised to ITS-90
Dimension 7.20” (H) x 3.70” (W) x 1.70” (D)
Weight Approx. 16.2 oz
Battery 2 x LR03 (AAA) type 1.5V
Certification CE
Safety IEC 1010-1 (2001), UL 3111-1 (6, 1994),
EN 61010-1 (2001), CSA C22.2
No. 1010.1 (1992)
CAT I Over Voltage (Installation) CATEGORY I,
Pollution Degree 2 per IEC 1010-1
Compliance IEC 60529: IP67 (Ingress Protection rating)
Water Immersion (3’ up to 30 min)
No ingress of dust (20mBar up to 8 hrs.)
Accuracy is specified for ambient temperatures between 64˚F (18˚C)
and 82˚F (28˚C) for a period of 1 year. The above specifications do not
include thermocouple error.
Calibration
The Apollo Digital Thermometer’s annual calibration, starting one year
after purchase, is recommended to ensure that the
thermometer performs to its accuracy specifications.
To calibrate the thermometer, contact your nearest UEi distributor or
UEi Service Center at 1-800-547-5740.
