Pneumatic Floor Nailer / Stapler

User Manual

[Revision 1.0 December 2017]

READ THIS MANUAL CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE – FAILURE TO DO SO

MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • Products covered by this manual

may vary in appearance, assembly, inclusions, specifications, description and packaging.

Pneumatic Floor Nailer / Stapler

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or SERIOUSLY INJURED if you do not follow instructions.

You CAN be KILLED or SERIOUSLY INJURED if you do not follow instructions.

You CAN be INJURED if you do not follow instructions or equipment damage may occur.

It is vital that you read and understand this user manual before using the product, including safety warnings, and any assembly and operating instructions. Keep the manual for future reference.

Safety precautions and recommendations detailed here must be fully understood and followed to reduce the risk of injury, fire, explosion, electrical hazard, and/or property damage.

Safety information presented here is generic in nature – some advice may not be applicable to every product. The term "equipment" refers to the product, be it electrical mains powered, battery powered or combustion engine powered.

• Before Use - If you are not familiar with the safe operation/handling of the equipment, or are in any way unsure of any aspect of suitability or correct use for your application, you should complete training conducted by a person or organization qualified in safe use and operation of this equipment, including fuel/electrical handling and safety.

• Do NOT operate the equipment in flammable or explosive environments, such as in the presence of flammable liquids, gases or dust. The equipment may create sparks or heat that may ignite flammable substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is damaged, malfunctioning or is in an excessively worn state.

• Do NOT allow others to use the equipment unless they have read this manual and are adequately trained.

• Keep packaging away from children risk of suffocation! Operators must use the equipment correctly. When using the equipment, consider conditions and pay due care to persons and property.

General Work Area Safety

• Work areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within operating range of the equipment or the general work area.

• If devices are provided for connecting dust extraction / collection facilities, ensure these are connected and used properly. Dust collection can reduce dust-related hazards.

General Personal Safety

• Wear appropriate protective equipment when operating, servicing, or when in the operating area of the equipment to help protect from eye and ear injury, poisoning, burns, cutting and crush injuries. Protective equipment such as safety goggles, respirators, non-slip safety footwear, hard hat, hearing protection etc should be used for appropriate equipment / conditions. Other people nearby should also wear appropriate personal protective equipment. Do not wear loose clothing or jewellery, which can be caught in moving parts. Keep hair and clothing away from the equipment.

• Stay alert and use common sense when operating the equipment. Do not over-reach. Always maintain secure footing and balance.

• Do not use the equipment if tired or under the influence of drugs, alcohol or medication.

• This equipment is not intended for use by persons with reduced physical, sensory or mental capabilities.

General Fuel Safety

• Petrol/fuel/gasoline is extremely flammable – keep clear of naked flames or other ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off the equipment immediately – if fuel gets on your clothing, change clothing.

• Do NOT smoke near fuel or when refuelling.

• Always shut off the engine before refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release slowly.

• Always refuel in well ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start or run the engine until all leaks are fixed.

General Carbon-Monoxide Safety

• Using a combustion engine indoors

CAN KILL IN MINUTES. Engine exhaust contains carbon-monoxide – a poison you cannot smell or see.

• Use combustion engines OUTSIDE only, and far away from windows, doors and vents.

General Equipment Use and Care

• The equipment is designed for domestic use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for misalignment or binding of moving parts, loose components, damage or any other condition that may affect its operation. If damaged, have the equipment repaired by an authorised service centre or technician before use.

• Prevent unintentional starting of the equipment - ensure equipment and power switches are in the OFF position before connecting or moving equipment. Do not carry equipment with hands or fingers touching any controls. Remove any tools or other items that are not a part of the equipment from it before starting or switching on.

• Do not force the equipment. Use the correct equipment for your application. Equipment will perform better and be safer when used within its design and usage parameters.

• Use the equipment and accessories etc. in accordance with these instructions, considering working conditions and the work to be performed. Using the equipment for operations different from those intended could result in hazardous situations.

• Always keep equipment components (engines, hoses, handles, controls, frames, housings, guards etc) and accessories (cutting tools, nozzles, bits etc) properly maintained. Keep the equipment clean and, where applicable, properly lubricated.

• Store the equipment out of reach of children or untrained persons. To avoid burns or fire hazards, let the equipment cool completely before transporting or storing. Never place or store the equipment near flammable materials, combustible gases or liquids etc.

• The equipment is not weather-proof, and should not be stored in direct sunlight, at high ambient temperatures or locations that are damp or humid.

• Do not clean equipment with solvents, flammable liquids or harsh abrasives.

• For specific equipment safety use and care, see Equipment Safety.

Pneumatic Floor Nailer / Stapler

General Electrical Safety

• Inspect electrical equipment, extension cords, power bars, and electrical fittings for damage or wear before each use. Repair or replace damaged equipment immediately.

• Ensure all power sources conform to equipment voltage requirements and are disconnected before connecting or disconnecting equipment.

• When wiring electrically powered equipment, follow all electrical and safety codes.

• Wherever possible, use a residual current device (RCD).

• High voltage / high current power lines may be present. Use extreme caution to avoid contact or interference with power lines. Electrical shock can be fatal.

General Electrical Safety

• Electrically grounded equipment must have an approved cord and plug and be connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and operate equipment by connecting and disconnecting the electrical cord.

• Do NOT use equipment that has exposed wiring, damaged switches, covers or guards.

• Do NOT use electrical equipment in wet conditions or in damp locations.

• Do NOT use electrical cords to lift, move or carry equipment.

• Do NOT coil or knot electrical cords, and ensure electrical cords are not trip hazards.

General Service Information

• The equipment must be serviced or repaired at authorised service centres by qualified personnel only.

• Replacement parts must be original equipment manufacturer (OEM) to ensure equipment safety is maintained.

• Do NOT attempt any maintenance or repair work not described in this manual.

• After use, the equipment and components may still be hot – allow the equipment to cool and disconnect spark plugs and/or electrical power sources and/or batteries from it before making adjustments, changing accessories or performing repair or maintenance.

• Do NOT make adjustments while the equipment is running.

• Perform service related activities in suitable conditions, such as a workshop.

• Replace worn, damaged or missing warning/safety labels immediately.

Pneumatic Floor Nailer / Stapler

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc, replace them.

Flammable Material Hazard

Flammable liquids, gases or

substances etc may present.

Avoid ignition sources and

open flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc

before using the product.

Use Hand Protection

Wear appropriate hand

protection and take due care

as the product or use of the

product may present hand

hazards.

Carbon-Monoxide Hazard

Do not use the product in confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be

fatal.

Electrocution / Electrical

Shock Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling

electrical products, cables,

plugs and leads. Electrical

shock can be fatal.

Toxic Fumes / Dust Hazard

Using the product or by-

products from use may

produce fumes, smoke or

particles that could be harmful

if inhaled. Wear appropriate

breathing protection and have

adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases or

substances etc may be

present. Avoid ignition sources

and open flames. Danger of

explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices

that can cause severe cut

injury to fingers, limbs etc.

Take due care when handling

and using the product.

Crush Hazard

The product may have blades,

edges or mechanical devices

that can cause severe crush

injury to fingers, limbs etc.

Take due care when handling

and using the product.

Single Operator Only

The product must be operated

by a single person only. More

than one person operating the

product may introduce

additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care

as the product or use of the

product may present face and

eye hazards.

Use Foot Protection Wear appropriate foot

protection and take due care

as the product or use of the

product may present foot

hazards.

Use Eye / Ear / Head

Protection

Wear appropriate eye and / or

ear and / or head protection

and take due care as the

product or use of the product

may present eye, hearing and

head hazards.

Running Hazard

Do not run on or near the product as doing so may

present a fall hazard.

Diving Hazard

Do not dive into the product as doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or

objects that can cause severe

injury to fingers, limbs, blood

etc. Take due care when

handling and using the

product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures

and hot surfaces that can

cause burn injuries.

Flying Debris Hazard

Be aware that the product or

use of the product may

present hazards produced by

flying debris. Wear appropriate

clothing and protectiove

devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts

to stop fully before handling

the product, adjusting,

maintenence etc.

Pneumatic Floor Nailer / Stapler

Carbon-Monoxide Hazard

Do not use the product in confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be

fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical devices that can pull in objects and can cause severe injury to

fingers, limbs etc. Take due

care when handling and using

the product.

Slope / Fall Injury Hazard

Be aware that using the

product on sloping surfaces or

in slippery conditions may

present additional dangers

from falls and contact with

blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

maneouvres as this may result

in severe injury due to falling, product breakage or collapse

etc.

Electrocution / Electrical Shock Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do

NOT use in rain, damp or wet

conditions. Electrical shock

can be fatal.

Electrocution / Electrical

Shock Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product.

Always disconnect the product

from the electrical supply

before handling the product,

adjusting, maintenence etc.

Power Line Electrocution

Hazard

High voltage / high current

power lines may be present.

Use extreme caution to avoid

contact or interference with

power lines. Electrical shock

can be fatal.

"Kick-Back" Hazard

High level of "kick-back"

hazard that can cause the

machine to suddenly rotate

towards operator. Kick-back

injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch

to move people.

Winch Lift Hazard

Do NOT LIFT load vertically.

Use machine to PULL only.

Cable Hazard

Ensure that load bearing cable

is not kinked or knotted.

Winch Cable Hazard Ensure that there is a

minimum number of cable

coils on winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye

protection for welding. Dorect

exposure to weld arcs may

cause permanent eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser, or allow

others to.

Pneumatic Floor Nailer / Stapler

Equipment Safety

Nail guns launch fasteners at very high velocities that can cause serious injury if proper safety precautions are not followed. It is extremely important that you read and fully understand the

information in this section and all other safety warnings / recommendations and usage instructions before using the equipment. • ENSURE THAT NO PART OF ANY HUMAN, ANIMAL OR CLOTHING IS

PLACED IN/NEAR THE AREA WHERE NAILS ARE FIRED OUT OF THE TOOL, REGARDLESS OF WHETHER YOU THINK THE TOOL IS EMPTY OR LOADED WITH NAILS.

Operator

• If you are untrained in the use of a nail gun, it is highly recommended that you be trained/instructed by a suitably qualified or experienced person before using the tool.

• NEVER operate the tool when tired, or under the influence of any substance (medication, alcohol, drugs etc) that may impair your judgement, alertness, physical strength, vision or dexterity.

• Maintain sure-footing and balance always when using or handling the tool and have full awareness of your surroundings and any possible hazards.

• Prolonged tool use may lead to health complications, such as carpal tunnel syndrome, due to vibration. To help reduce the possibility of such conditions, wear gloves, take breaks frequently, keep fingers and hands warm, and maintain the equipment for optimal operation and minimal vibration. It is recommended to seek medical advice if you feel numbness or burning sensations in fingers/hands.

Clothing and Protective Equipment – All Operators and Assistants

• Wear AS/NZS 1337.6 (ANSI Z87.1) approved impact resistant safety goggles, or safety glasses with adequate top and side protection.

• Wear suitable hearing protection.

• Wear suitable head protection, such as a safety approved hard hat.

• Wear heavy-duty, non-slip leather or protective gloves.

• Wear approved heavy-duty safety boots, with steel toe-caps and non-slip soles.

• Wear suitable overalls or work clothing that fits snugly, but does not restrict movement. Avoid loose

fitting clothing, scarves, jewellery etc and keep long hair contained to avoid getting caught or pulled by the tool etc.

Work Area Safety

• NEVER use oxygen, carbon-dioxide, combustible gases or any other bottled gas as a pressure source for the tool – explosion and serious personal injury could result.

• Use ONLY air hoses that are rated in excess of 150% the maximum system air pressure.

• Connect the tool to the air supply with a coupling that allows all pressure to escape from the tool when

the coupling is disconnected.

• ALWAYS assume the tool is loaded with fasteners. Keep the tool pointed away from yourself and others at all times.

• Disconnect the tool from the air supply before performing any tool maintenance, clearing a jammed fastener, moving the tool to another location, handing the tool to another person, or making adjustments.

Operational Safety

• Do NOT use the tool if the trigger or any safety guard or mechanism is not installed or is not operating correctly, or the tool is leaking air – have the tool inspected and repaired at an authorised service centre before using it again.

• Do NOT connect the tool to air pressures potentially exceeding 200PSI (13.8 bar).

• Remove all fasteners from the tool before connecting it to the air supply. The tool driving mechanism

Pneumatic Floor Nailer / Stapler

may cycle when tool is connected to the air supply.

• Use the tool with the correct types and sizes of fastener. Do NOT load different size/types of fasteners at the same time.

• Do NOT attempt to drive fasteners into material that they are not designed to penetrate, such as metal, concrete, tiles etc.

• Do NOT drive fasteners on top of other fasteners.

• Strike the activator / plunger using rubber mallets only.

• Do NOT use the tool as a hammer for aligning floor boards etc.

Transportation Safety

• Always remove all fasteners from the tool before transporting or working on it (adjusting etc).

• Always disconnect the tool from the air supply before transporting or working on it.

Pneumatic Floor Nailer / Stapler

Table of Contents

Safety ............................................................................................................................................. 2

Safety Symbols ......................................................................................................................... 4

Equipment Safety .......................................................................................................................... 6

Parts Identification ........................................................................................................................ 9

Operation ..................................................................................................................................... 10

Air Supply................................................................................................................................ 10

Loading Fasteners .................................................................................................................. 10

Nailing and Stapling ................................................................................................................ 11

Removing Jammed Fasteners ................................................................................................. 11

Maintenance and Troubleshooting ............................................................................................ 13

Daily Cleaning / Inspection ...................................................................................................... 13

Troubleshooting ................................ ................................................................ ...................... 13

Specifications ............................................................................................................................. 14

Pneumatic Floor Nailer / Stapler

No.

Name

No.

Name

Tool Body

Board Foot

Magazine

Board Stop

Magazine Cover

Tools / Accessories (may be supplied) (not shown) O-ring and gasket set (for technician use)

Mallet Replacement Board Foot Air Tool Lubricating Oil 3 / 4 / 5mm Allen Key Multi-Purpose Spanner

Top Handle

Air Inlet

Centre Handle

Activator

5 6 7

Parts Identification

It is strongly recommended that you familiarise yourself with all major components of the tool before using it or performing any maintenance tasks.

Products detailed in this manual may vary in appearance, inclusions, description and packaging

from those shown or described.

Pneumatic Floor Nailer / Stapler

A C C

Loading Nails

Loading Staples

Operation

Nail guns launch fasteners at very high velocities that can cause serious injury if proper safety precautions are not followed. It is extremely important that you read and fully understand the

information in this section and all other safety warnings / recommendations and usage instructions before using the equipment. • ENSURE THAT NO PART OF ANY HUMAN, ANIMAL OR CLOTHING IS

PLACED IN/NEAR THE AREA WHERE NAILS ARE FIRED OUT OF THE TOOL, REGARDLESS OF WHETHER YOU THINK THE TOOL IS EMPTY OR LOADED WITH NAILS. • Use ONLY air hoses that are

rated in excess of 150% the maximum system air pressure. • Disconnect the tool from the air supply before performing any tool maintenance, clearing a jammed fastener, moving the tool to another location, handing the tool to another person, or making adjustments.

Air Supply

This tool is designed to operate on clean, dry, compressed air at regulated pressures between 70 and 100 PSI (4.8 to 6.9 Bar). The preferred air supply should include a filter, pressure regulator, and automatic oiler located as close to the tool as possible (within 5m (15') is ideal).

All compressed air contains moisture and other contaminates that are detrimental to internal components of the tool. An in-line filter and oiler will remove most of these contaminates and provide necessary lubrication which will significantly prolong the life of the tool. If an in-line oiler is not available, place 10 to 15 drops of air tool lubricating oil into the tool air inlet at the beginning of each workday.

Do not over-lubricate the tool. Excess oil will be vented with exhaust air when over-lubricated, which could stain materials. Purge excess oil first before you begin nailing by unloading any fasteners from

the tool, then "firing" the tool several times. The tool is equipped with a ¼" male NPT type "quick connector". The tool must always be connected to the

air supply with a coupling that allows all pressure in the tool to escape when the coupling is disconnected.

Loading Fasteners

Do not load fasteners of different lengths. • Do not load both staples and nails together.

1. Disconnect the tool from the air supply.

2. Pull out the magazine cover (A) until it locks in the fully

open position.

3. Place the fasteners into the magazine (B).

4. Make sure that the fasteners are placed correctly:

• Load staples over the rail (B) in the magazine.

• Load nails down one side of the rail (B), with the "L" part

of the head on the rail in the magazine.

5. Close the magazine cover until it locks in place.

6. Reconnect the tool to the air supply.

Pneumatic Floor Nailer / Stapler

37mm (1.5")

50mm (2")

20mm (3/4")

17mm (11/16")

25mm (1")

A B C

Nailing and Stapling

1. Fit the floor boards together and ensure that they are snug – use the mallet as required.

2. Position the tool over the tongued edge of the floor board (X), pressing the board stop (A) against the front of the floor board.

3. Put some downward pressure onto the tool to keep it steady. Ensure the board foot (B) is sitting flat on the floor board.

4. Strike the activator (C) with the rubber mallet (do NOT use excessive force; use ONLY a rubber mallet and strike with the soft end). The tool will then drive the nail or staple in at 45°. The correct nail length for various floor thickness is shown below.

Nailing Pre-Finished Flooring – The tool is designed for installing both unfinished and pre-finished

hardwood flooring. Care must be used however when installing pre-finished flooring to ensure that the finish is not damaged by the tool. It is recommended that the tool be inspected for damage, especially the board foot and tested on a sample section to be certain that the tool and the technique used do not mar the finish. This procedure should be followed before each job due to variations in flooring.

Removing Jammed Fasteners

You must remove jammed fasteners before using the tool any further, otherwise personal injury and/or damage to the tool may result.

A fastener jam will prevent the tool from operating normally. To remove jammed fasteners:

1. Disconnect the tool from the air supply.

2. Open the magazine, and remove the fasteners.

3. For the jammed fasteners, attempt to remove them with pliers or similar, however, do not use excessive

force. If it is not possible to remove the fasteners directly:

a. Remove the 2 screws (A) securing the board stop (B) using a 4mm Allen key. b. Remove the 3 screws (C) securing the fastener drive plate (D) using a 5mm Allen key. With the

fastener drive plate loose it should be possible to easily remove the jammed fasteners.

4. After removing the jammed fasteners, re-install the fastener guide plate and board stop, then load the

magazine and re-connect the tool to the air supply.

Pneumatic Floor Nailer / Stapler

A B C

Pneumatic Floor Nailer / Stapler

Problem

Possible Cause

Possible Solution

Air leaking from top or bottom of the tool.



Loose screws.



Worn or damaged O-rings/seals.



Tighten the screws.



Replace O-rings and seals.

Tool not operating, or is operating sluggishly.



Inadequate air supply.



Inadequate lubrication.



Worn or damaged O-ring/seals.



Verify that there is adequate air supply and pressure.



Put 10 to 15 drops of oil into the air inlet.



Replace O-rings and seals.

Tool jams frequently.



Incorrect fasteners.



Damaged fasteners.



Nail magazine or nose screws loose.



Nail magazine is dirty.



Pusher spring damaged.



Driver is worn or damaged.



Use correct size/type of fasteners.



Replace with undamaged fasteners.



Tighten screws.



Clean nail magazine.



Replace spring.



replace.

Unimac NALFLRUMCA2XH User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
