TWECO FABRICATOR 181i 3-IN-1 Multi Process Welding Systems Instruction manual

3163339
FABRICATOR® 181i
3-IN-1 Multi Process Welding Systems
Operating Manual
English
Canadien Français
Americas Español
Revision: AH Issue Date: April 24, 2015 Manual No.: 0-5191
Tweco.com
WE APPRECIATE YOUR BUSINESS!
Congratulations on receiving your new Tweco product. We are proud to have you as our customer and will strive to provide you with the best service and support in the industry. This product is backed by our extensive warranty and world-wide service network.
We know you take pride in your work and we feel privileged to provide you with this high performance product that will help you get the job done.
For more than 75 years Tweco has provided quality products you can trust, when your reputation is on the line.
YOU ARE IN GOOD COMPANY!
Tweco is a Global Brand of Arc Welding Products for Victor Technologies Inc. We distinguish ourselves from our competition through market-leading innovation and truly dependable products that will stand the test of time.
We strive to enhance your productivity, efficiency and welding performance enabling you to excel in your craft. We design products with the welder in mind delivering- advanced features, durability, ease of use and ergonomic comfort.
Above all, we are committed to a safer working environment within the welding industry. Your satisfaction with this product and its safe operation is our ultimate concern. Please take the time to read the entire manual, especially the Safety Precautions.
If you have any questions or concerns regarding your new Tweco product, please contact our friendly and knowledgeable Customer Service Team at:
1-800-462-2782 (USA) and 1-905-827-4515 (Canada), or visit us on the web at www.Tweco.com
!
WARNINGS
Read and understand this entire Manual and your employer’s safety practices before installing, operating, or servicing the equipment.
While the information contained in this Manual represents the Manufacturer’s best judgment, the Manufacturer assumes no liability for its use.
Operating Manual Number 0-5191 for: Tweco Fabricator 181i Power Source Part Number: W1003180 Tweco Fabricator 181i Portable System Package Part Number: W1003181 Tweco Fabricator 181i Portable System Package with Cart Part Number: W1003182 Tweco Fabricator 181i Package w/Single Cylinder Cart Part Number: W1003183
Published by: Victor Technologies International, Inc. 16052 Swingley Ridge Road, Suite 300 St. Louis, MO 63017 USA
www.victortechnologies.com
Copyright © 2013 by Victor Technologies International, Inc.
® All rights reserved.
Reproduction of this work, in whole or in part, without written permission of the publisher is prohibited.
The publisher does not assume and hereby disclaims any liability to any party for any loss or damage caused by any error or omission in this Manual, whether such error results from negligence, accident, or any other cause.
Publication Date: August 10, 2011 Revision Date: April 24, 2015
Record the following information for Warranty purposes:
Where Purchased: ____________________________________
Purchase Date: ____________________________________
Equipment Serial #: ____________________________________
TABLE OF CONTENTS
SECTION 1:
SAFETY INSTRUCTIONS AND WARNINGS ....................................................... 1-1
1.01 Arc Welding Hazards ....................................................................................... 1-1
1.02 General Safety Information for Victor CS Regulator .......................................... 1-5
1.03 Principal Safety Standards .............................................................................. 1-7
1.04 Symbol Chart .................................................................................................. 1-8
1.05 Precautions De Securite En Soudage A L’arc .................................................. 1-9
1.06 Dangers relatifs au soudage à l’arc ................................................................. 1-9
1.07 Informations Générales de Sécurité .............................................................. 1-14
1.08 Principales Normes De Securite ................................................................... 1-16
1.09 Graphique de Symbole .................................................................................. 1-17
1.10 Declaration Of Conformity ............................................................................ 1-18
SECTION 2:
INTRODUCTION ..................................................................................... 2-1
2.01 How to Use This Manual ................................................................................. 2-1
2.02 Equipment Identification ................................................................................. 2-1
2.03 Receipt of Equipment ...................................................................................... 2-1
2.04 Description ..................................................................................................... 2-1
2.05 Transportation Methods .................................................................................. 2-1
2.06 User Responsibility ......................................................................................... 2-2
2.07 Fabricator 181i Portable System Package (Part No. W1003181) .................... 2-2
2.08 Duty Cycle ....................................................................................................... 2-3
2.09 Specifications ................................................................................................. 2-4
2.10 Options and Accessories ................................................................................ 2-5
SECTION 3:
INSTALLATION, OPERATION AND SETUP ........................................................ 3-1
3.01 Environment ................................................................................................... 3-1
3.02 Location .......................................................................................................... 3-1
3.03 Ventilation ....................................................................................................... 3-1
3.04 Electricity Supply Voltage .............................................................................. 3-1
3.05 Electromagnetic Compatibility ........................................................................ 3-3
3.06 Victor Regulator .............................................................................................. 3-4
3.07 Leak Testing the System ................................................................................. 3-6
3.08 When You Finish Using the Regulator ............................................................. 3-6
3.09 Storage of the Regulator ................................................................................. 3-6
3.10 Power Source Controls, Indicators and Features ............................................ 3-7
3.11 Attaching the Tweco Fusion 180A Gun .......................................................... 3-13
3.12 Torch Adapter Thumb Screw Replacement .................................................. 3-14
3.13 Installing 4" (100mm) Diameter Spool ......................................................... 3-16
3.14 Installing 8" (200mm) Diameter Spool .......................................................... 3-16
3.15 Inserting Wire into the Wire Feed Mechanism .............................................. 3-17
3.16 Feed Roller Pressure Adjustment .................................................................. 3-18
3.17 Changing the Feed Roll ................................................................................. 3-19
3.18 Wire Reel Brake ............................................................................................ 3-19
TABLE OF CONTENTS
3.19 Gas Regulator Operation ............................................................................... 3-20
3.20 Setup for MIG (GMAW) Welding with Gas Shielded MIG Wire ..................... 3-21
3.21 Setup for MIG (FCAW) Welding with Flux Core (Gasless) Wire .................... 3-22
3.22 Setup for SPOOL GUN MIG (GMAW) Welding with Gas Shielded MIG Wire . 3-24
3.23 Setup for LIFT TIG (GTAW) Welding ............................................................. 3-25
3.24 Setup for STICK (SMAW) Welding .............................................................. 3-27
SECTION 4:
BASIC WELDING GUIDE ............................................................................ 4-1
4.01 MIG (GMAW/FCAW) Basic Welding Technique ............................................... 4-1
4.02 MIG (GMAW/FCAW) Welding Troubleshooting ............................................... 4-6
4.03 Stick (SMAW) Basic Welding Technique ......................................................... 4-9
4.04 Effects of Stick Welding Various Materials ...................................................... 4-9
4.05 Stick (SMAW) Welding Troubleshooting ....................................................... 4-18
4.06 TIG (GTAW) Basic Welding Technique .......................................................... 4-20
4.07 TIG (GTAW) Welding Problems ..................................................................... 4-22
SECTION 5: Power Source PROBLEMS AND
ROUTINE SERVICE REQUIREMENTS .............................................................. 5-1
5.01 Power Source Problems ................................................................................. 5-1
5.02 Routine Service and Calibration Requirements ............................................... 5-2
5.03 Cleaning the Welding Power Source ............................................................... 5-5
5.04 Cleaning the Feed Rolls ................................................................................... 5-5
5.05 Volt-Ampere Curves ........................................................................................ 5-6
SECTION 6: KEY SPARE PARTS .......................................................................... 6-1
6.01 Tweco Fusion 180A MIG Gun Parts ................................................................ 6-1
6.02 Power Source ................................................................................................. 6-2
APPENDIX: FABRICATOR 181i CIRCUIT DIAGRAM .................................................... A-1
LIMITED WARRANTY TERMS ........................................................ INSIDE REAR COVER
INTERNATIONAL CONTACT INFORMATION ................................................. REAR COVER
This Page Intentionally Blank
Fabricator 181iFabricator 181i
!
SECTION 1:
SAFETY INSTRUCTIONS AND WARNINGS
WARNING
PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY. PACEMAKER WEARERS KEEP AWAY UNTIL CONSULTING YOUR DOCTOR. DO NOT LOSE THESE INSTRUCTIONS. READ OPERATING/INSTRUCTION MANUAL BEFORE INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT.
Welding products and welding processes can cause serious injury or death, or damage to other equipment or property, if the operator does not strictly observe all safety rules and take precautionary actions.
Safe practices have developed from past experience in the use of welding and cutting. These practices must be learned through study and training before using this equipment. Some of these practices apply to equipment connected to power lines; other practices apply to engine driven equipment. Anyone not having extensive training in welding and cutting practices should not attempt to weld.
Safe practices are outlined in the American National Standard Z49.1 entitled: SAFETY IN WELDING AND CUTTING. This publication and other guides to what you should learn before operating this equipment are listed at the end of these safety precautions. HAVE ALL INSTALLATION, OPERATION, MAINTENANCE, AND REPAIR WORK
PERFORMED ONLY BY QUALIFIED PEOPLE.

1.01 Arc Welding Hazards

WARNING
ELECTRIC SHOCK can kill.
Touching live electrical parts can cause fatal shocks or severe burns. The electrode and work circuit is electrically live whenever the output is ON. The input power circuit and machine internal circuits are also live when power is ON. In semi-automatic or automatic wire welding, the wire, wire reel, drive roll housing, and all metal parts touching the welding wire are electrically live. Incorrectly installed or improperly grounded equipment is a hazard.
1. Do not touch live electrical parts.
2. Wear dry, hole-free insulating gloves and body protection.
3. Insulate yourself from work and ground using dry insulating mats or covers.
4. Disconnect input power or stop engine before installing or servicing this equipment. Lock input power disconnect switch open, or remove line fuses so power cannot be turned ON accidentally.
5. Properly install and ground this equipment according to its Owner’s Manual and national, state, and local codes.
6. Turn OFF all equipment when not in use. Disconnect power to equipment if it will be left unattended or out of service.
7. Use fully insulated electrode holders. Never dip holder in water to cool it or lay it down on the ground or the work surface. Do not touch holders connected to two welding machines at the same time or touch other people with the holder or electrode.
8. Do not use worn, damaged, undersized, or poorly spliced cables.
9. Do not wrap cables around your body.
10. Ground the workpiece to a good electrical (earth) ground.
11. Do not touch electrode while in contact with the work (ground) circuit.
12. Use only well-maintained equipment. Repair or replace damaged parts at once.
13. In confined spaces or damp locations, do not use a welder with AC output unless it is equipped with a voltage reducer. Use equipment with DC output.
14. Wear a safety harness to prevent falling if working above floor level.
Manual 0-5191 1-1 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i
15. Keep all panels and covers securely in place.
WARNING
ARC RAYS can burn eyes and skin; NOISE can damage hearing. Arc rays from the welding process produce intense heat and strong ultraviolet rays that can burn eyes and skin. Noise from some processes can damage hearing.
1. Wear a welding helmet fitted with a proper shade of filter (see ANSI Z49.1 listed in Safety Standards) to protect your face and eyes when welding or watching.
2. Wear approved safety glasses. Side shields recommended.
AWS F2.2:2001 (R2010), Adapted with permission of the American Welding Society (AWS), Miami, Florida
Guide for Shade Numbers
Process
Shielded Metal Arc Welding (SMAW)
Electrode Size in.
(mm)
Less than 3/32 (2.4)
3/32-5/32 (2.4-4.0)
5/32-1/4 (4.0-6.4)
More than 1/4 (6.4)
3. Use protective screens or barriers to protect others from flash and glare; warn others not to watch the arc.
4. Wear protective clothing made from durable, flame-resistant material (wool and leather) and foot protection.
5. Use approved ear plugs or ear muffs if noise level is high.
WARNING
FUMES AND GASES can be hazardous to your health.
Welding produces fumes and gases. Breathing these fumes and gases can be hazardous to your health.
Arc Current
(Amperes)
Less than 60
60-160 160-250 250-550
Minimum
Protective
Shade
7
8 10 11
Suggested*
Shade No.
(Comfort)
­10 12 14
Gas Metal Arc Welding (GMAW) and Flux Cored Arc Welding (FCAW)
Gas Tungsten arc Welding (GTAW)
Air Carbon Arc Cutting (CAC-A)
Plasma Arc Welding (PAW)
Plasma Arc Cutting (PAC)
* As a rule of thumb, start with a shade that is too dark to see the weld zone. Then go to a lighter shade which gives sufficient view of the weld zone without going below the minimum. In oxyfuel gas welding, cutting, or brazing where the torch and/or the flux produces a high yellow light, it is desirable to use a filter lens that absorbs the yellow or sodium line of the visible light spectrum.
(Light)
(Heavy)
Less than 60
60-160 160-250 250-550
Less than 50
50-150 150-500
Less than
500
500-1000
Less than 20
20-100 100-400 400-800
Less than 20
20-40 40-60 60-80
80-300 300-400 400-800
7 10 10 10
8
8 10
10 11
6
8 10 11
4
5
6
8
8
9 10
­11 12 14
10 12 14
12 14
6 to 8
10 12 14
4 5 6 8
9 12 14
SAFETY INSTRUCTIONS AND WARNINGS 1-2 Manual 0-5191
Fabricator 181iFabricator 181i
1. Keep your head out of the fumes. Do not breathe the fumes.
2. If inside, ventilate the area and/or use exhaust at the arc to remove welding fumes and gases.
3. If ventilation is poor, use an approved air-supplied respirator.
4. Read the Material Safety Data Sheets (MSDSs) and the manufacturer’s instruction for metals, consumables, coatings, and cleaners.
5. Work in a confined space only if it is well ventilated, or while wearing an air-supplied respirator. Shielding gases used for welding can displace air causing injury or death. Be sure the breathing air is safe.
6. Do not weld in locations near degreasing, cleaning, or spraying operations. The heat and rays of the arc can react with vapors to form highly toxic and irritating gases.
7. Do not weld on coated metals, such as galvanized, lead, or cadmium plated steel, unless the coating is removed from the weld area, the area is well ventilated, and if necessary, while wearing an air­supplied respirator. The coatings and any metals containing these elements can give off toxic fumes if welded.
6. Be aware that welding on a ceiling, floor, bulkhead, or partition can cause fire on the hidden side.
7. Do not weld on closed containers such as tanks or drums.
8. Connect work cable to the work as close to the welding area as practical to prevent welding current from traveling long, possibly unknown paths and causing electric shock and fire hazards.
9. Do not use welder to thaw frozen pipes.
10. Remove stick electrode from holder or cut off welding wire at contact tip when not in use.
WARNING
FLYING SPARKS AND HOT METAL can cause injury.
Chipping and grinding cause flying metal. As welds cool, they can throw off slag.
1. Wear approved face shield or safety goggles. Side shields recommended.
2. Wear proper body protection to protect skin.
WARNING
WARNING
WELDING can cause fire or explosion. Sparks and spatter fly off from the welding
arc. The flying sparks and hot metal, weld spatter, hot workpiece, and hot equipment can cause fires and burns. Accidental contact of electrode or welding wire to metal objects can cause sparks, overheating, or fire.
1. Protect yourself and others from flying sparks and hot metal.
2. Do not weld where flying sparks can strike flammable material.
3. Remove all flammables within 35 ft (10.7 m) of the welding arc. If this is not possible, tightly cover them with approved covers.
4. Be alert that welding sparks and hot materials from welding can easily go through small cracks and openings to adjacent areas.
5. Watch for fire, and keep a fire extinguisher nearby.
Manual 0-5191 1-3 SAFETY INSTRUCTIONS AND WARNINGS
CYLINDERS can explode if damaged. Shielding gas cylinders contain gas under
high pressure. If damaged, a cylinder can explode. Since gas cylinders are normally part of the welding process, be sure to treat them carefully.
1. Protect compressed gas cylinders from excessive heat, mechanical shocks, and arcs.
2. Install and secure cylinders in an upright position by chaining them to a stationary support or equipment cylinder rack to prevent falling or tipping.
3. Keep cylinders away from any welding or other electrical circuits.
4. Never allow a welding electrode to touch any cylinder.
5. Use only correct shielding gas cylinders, regulators, hoses, and fittings designed for the specific application; maintain them and associated parts in good condition.
6. Turn face away from valve outlet when opening cylinder valve.
Fabricator 181i Fabricator 181i
!
7. Keep protective cap in place over valve except when cylinder is in use or connected for use.
8. Read and follow instructions on compressed gas cylinders, associated equipment, and CGA publication P-1 listed in Safety Standards.
WARNING
Engines can be dangerous.
WARNING
ENGINE EXHAUST GASES can kill.
Engines produce harmful exhaust gases.
1. Use equipment outside in open, well-ventilated areas.
2. If used in a closed area, vent engine exhaust outside and away from any building air intakes.
WARNING
ENGINE FUEL can cause fire or explosion. Engine fuel is highly flammable.
1. Stop engine before checking or adding fuel.
2. Do not add fuel while smoking or if unit is near any sparks or open flames.
3. Have only qualified people remove guards or covers for maintenance and troubleshooting as necessary.
4. To prevent accidental starting during servicing, disconnect negative (-) battery cable from battery.
5. Keep hands, hair, loose clothing, and tools away from moving parts.
6. Reinstall panels or guards and close doors when servicing is finished and before starting engine.
WARNING
SPARKS can cause BATTERY GASES TO EXPLODE; BATTERY ACID can burn eyes and skin.
Batteries contain acid and generate explosive gases.
1. Always wear a face shield when working on a battery.
2. Stop engine before disconnecting or connecting battery cables.
3. Do not allow tools to cause sparks when working on a battery.
4. Do not use welder to charge batteries or jump start vehicles.
5. Observe correct polarity (+ and –) on batteries.
3. Allow engine to cool before fueling. If possible, check and add fuel to cold engine before beginning job.
4. Do not overfill tank — allow room for fuel to expand.
STEAM AND PRESSURIZED HOT COOLANT
WARNING
can burn face, eyes, and skin.
5. Do not spill fuel. If fuel is spilled, clean up before starting engine.
WARNING
MOVING PARTS can cause injury.
Moving parts, such as fans, rotors, and belts can cut fingers and hands and catch loose clothing.
1. Keep all doors, panels, covers, and guards closed and securely in place.
2. Stop engine before installing or connecting unit.
SAFETY INSTRUCTIONS AND WARNINGS 1-4 Manual 0-5191
The coolant in the radiator can be very hot and under pressure.
1. Do not remove radiator cap when engine is hot. Allow engine to cool.
2. Wear gloves and put a rag over cap area when removing cap.
3. Allow pressure to escape before completely removing cap.
LEAD WARNING
!
!
WARNING: This product contains chemicals, including lead, known to the State of Califor­nia to cause birth defects and other repro­ductive harm. Wash hands after handling.
NOTE
Considerations About Welding And The Effects of Low Frequency Electric and Mag­netic Fields
The following is a quotation from the General Conclu­sions Section of the U.S. Congress, Office of Technology Assessment, Biological Effects of Power Frequency Electric & Magnetic Fields - Background Paper, OTA­BP-E-63 (Washington, DC: U.S. Government Printing Office, May 1989): “...there is now a very large volume of scientific findings based on experiments at the cel­lular level and from studies with animals and people which clearly establish that low frequency magnetic fields interact with, and produce changes in, biologi­cal systems. While most of this work is of very high quality, the results are complex. Current scientific understanding does not yet allow us to interpret the evidence in a single coherent framework. Even more frustrating, it does not yet allow us to draw definite conclusions about questions of possible risk or to offer clear science-based advice on strategies to minimize or avoid potential risks.”
To reduce magnetic fields in the workplace, use the following procedures.
Fabricator 181iFabricator 181i

1.02 General Safety Information for Victor CS Regulator

A. Fire Prevention
Welding and cutting operations use fire or combustion as a basic tool. The process is very useful when properly controlled. However, it can be extremely destructive if not performed cor rectly in the proper environment.
1. The work area must have a fireproof floor.
2. Work benches or tables used during welding or cutting operations must have fireproof tops.
3. Use heat resistant shields or other approved mate­rial to protect nearby walls or unprotected flooring from sparks and hot metal.
4. Keep an approved fire extinguisher of the proper size and type in the work area. Inspect it regu­larly to ensure that it is in proper working order. Know how to use the fire extin guisher.
5. Move combustible materials away from the work site. If you can not move them, protect them with fireproof covers.
WARNING
NEVER perform welding, heating, or cutting operations on a container that has held toxic, combustible or flammable liq uids, or vapors. NEVER perform welding, heating, or cutting operations in an area containing combustible vapors, flam mable liquids, or explosive dust.
1. Keep cables close together by twisting or taping them.
2. Arrange cables to one side and away from the operator.
3. Do not coil or drape cable around the body.
4. Keep welding Power Source and cables as far away from body as practical.
ABOUT PACEMAKERS:
The above procedures are among those also normally recommended for pacemaker wearers. Consult your doctor for complete information.
Manual 0-5191 1-5 SAFETY INSTRUCTIONS AND WARNINGS
B. Housekeeping
WARNING
NEVER allow oxygen to contact grease, oil, or
other flam mable substances. Although oxy­gen by itself will not burn, these substances become highly explosive. They can ignite and burn violently in the presence of oxygen.
Keep ALL apparatus clean and free of grease, oil and other flammable substances.
Fabricator 181i Fabricator 181i
!
!
!
!
C. Ventilation
WARNING
Ade quately ventilate welding, heating, and cutting work areas to prevent accumula­tion of explosive or toxic concen trations of gases. Certain combinations of metals, coatings, and gases generate toxic fumes. Use respiratory protection equipment in these circumstances. When welding/brazing, read and understand the Material Safety Data Sheet for the welding/brazing alloy.
D. Personal Protection
Gas flames produce infrared radiation which may have a harm ful effect on the skin and especially on the eyes. Select goggles or a mask with tempered lenses, shaded 4 or darker, to protect your eyes from injury and provide good visibility of the work.
Always wear protective gloves and flame-resistant clothing to protect skin and clothing from sparks and slag. Keep collars, sleeves, and pockets buttoned. DO NOT roll up sleeves or cuff pants.
When working in a non-welding or cutting environment, always wear suitable eye protection or face shield.
Art # A-12127
Figure 1-1: Gas Cylinders
WARNING
Cylinders are highly pressurized. Handle with care. Serious accidents can result from improper handling or mis use of compressed gas cylinders DO NOT drop the cylinder, knock it over, or expose it to excessive heat, flames or sparks. DO NOT strike it against other cylinders. Contact your gas supplier or refer to CGA P-1 “Safe Handling of Com­pressed Gases in Containers” publication.
NOTE
CGA P-1 publication is available by writing the Compressed Gas Association, 4221 Walney Road, 5th Floor, Chantilly,VA 20151­2923
WARNING
Practice the following safety and operation precautions EVERY TIME you use pressure regulation equipment. Deviation from the following safety and operation instructions can result in fire, explosion, damage to equipment, or injury to the operator.
E. Compressed Gas Cylinders
The Department of Transportation (DOT) approves the design and manufacture of cylinders that contain gases used for welding or cutting operations.
1. Place the cylinder (Figure 1-1) where you will use it. Keep the cylinder in a vertical position. Secure it to a cart, wall, work bench, post, etc.
2. Place the valve protection cap on the cylinder whenever mov ing it, placing it in storage, or not using it. Never drag or roll cylinders in any way. Use a suitable hand truck to move cylin ders.
3. Store empty cylinders away from full cylinders. Mark them “EMPTY” and close the cylinder valve.
4. NEVER use compressed gas cylinders without a pressure reducing regulator attached to the cylinder valve.
5. Inspect the cylinder valve for oil, grease, and damaged parts.
WARNING
DO NOT use the cylinder if you find oil, grease or damaged parts. Inform your gas supplier of this condition immediately.
SAFETY INSTRUCTIONS AND WARNINGS 1-6 Manual 0-5191
6. Momentarily open and close (called “cracking”) the cylinder valve to dislodge any dust or dirt that may be present in the valve.
CAUTION
Open the cylinder valve slightly. If you open the valve too much, the cylinder could tip over. When cracking the cylinder valve, DO NOT stand directly in front of the cylinder valve. Always perform cracking in a well ventilated area. If an acetylene cylinder sprays a mist when cracked, let it stand for 15 minutes. Then, try to crack the cylinder valve again. If this problem persists, contact your gas supplier.

1.03 Principal Safety Standards

Safety in Welding and Cutting, ANSI Standard Z49.1, from American Welding Society, 550 N.W. LeJeune Rd., Miami, FL 33126.
Fabricator 181iFabricator 181i
Safety and Health Standards, OSHA 29 CFR 1910, from Superintendent of Documents, U.S. Government Printing Office, Washington, D.C. 20402.
Recommended Safe Practices for the Preparation for Welding and Cutting of Containers That Have Held Hazardous Substances, American Welding Society Standard AWS F4.1, from American Welding Society, 550 N.W. LeJeune Rd., Miami, FL 33126.
National Electrical Code, NFPA Standard 70, from National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
Safe Handling of Compressed Gases in Cylinders, CGA Pamphlet P-1, from Compressed Gas Association, 1235 Jefferson Davis Highway, Suite 501, Arlington, VA 22202.
Code for Safety in Welding and Cutting, CSA Standard W117.2, from Canadian Standards Association, Standards Sales, 178 Rexdale Boulevard, Rexdale, Ontario, Canada M9W 1R3.
Safe Practices for Occupation and Educational Eye and Face Protection, ANSI Standard Z87.1, from American National Standards Institute, 1430 Broadway, New York, NY 10018.
Cutting and Welding Processes, NFPA Standard 51B, from National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
Manual 0-5191 1-7 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i
Gas Tungsten Arc Welding (GTAW)
Air Carbon Arc Cutting (CAC-A)
Constant Current
Constant Voltage Or Constant Potential
High Temperature
Fault Indication
Arc Force
Touch Start (GTAW)
Variable Inductance
Voltage Input
Single Phase
Three Phase
Three Phase Static Frequency Converter­Transformer-Rectifier
Dangerous Voltage
Off
On
Panel/Local
Shielded Metal Arc Welding (SMAW)
Gas Metal Arc Welding (GMAW)
Increase/Decrease
Circuit Breaker
AC Auxiliary Power
Remote
Duty Cycle
Percentage
Amperage
Voltage
Hertz (cycles/sec)
Frequency
Negative
Positive
Direct Current (DC)
Protective Earth (Ground)
Line
Line Connection
Auxiliary Power
Receptacle Rating­Auxiliary Power
Art # A-04130_AB
115V 15A
t
t1
t2
%
X
IPM
MPM
t
V
Fuse
Wire Feed Function
Wire Feed Towards Workpiece With Output Voltage Off.
Preflow Time
Postflow Time
Spot Time
Spot Weld Mode
Continuous Weld Mode
Press to initiate wirefeed and welding, release to stop.
Purging Of Gas
Inches Per Minute
Meters Per Minute
Welding Gun
Burnback Time
Press and hold for preflow, release to start arc. Press to stop arc, and hold for preflow.
4 Step Trigger Operation
2 Step Trigger Operation
S
See Note
See Note
S
Note: For environments with increased hazard of electrical shock, Power Supplier bearing the mark conform to EN50192 when used in conjunction with hand torches with exposed tips, if equipped with properly installed standoff guides. Cannot be disposed with household garbage.

1.04 Symbol Chart

Note that only some of these symbols will appear on your model.
SAFETY INSTRUCTIONS AND WARNINGS 1-8 Manual 0-5191
Fabricator 181iFabricator 181i
!

1.05 Precautions De Securite En Soudage A L’arc

MISE EN GARDE
LE SOUDAGE A L’ARC EST DANGEREUX PROTEGEZ-VOUS, AINSI QUE LES AUTRES, CONTRE LES BLESSURES GRAVES POSSIBLES OU LA
MORT. NE LAISSEZ PAS LES ENFANTS S’APPROCHER, NI LES PORTEURS DE STIMULATEUR CARDI­AQUE (A MOINS QU’ILS N’AIENT CONSULTE UN MEDECIN). CONSERVEZ CES INSTRUCTIONS. LISEZ LE MANUEL D’OPERATION OU LES INSTRUCTIONS AVANT D’INSTALLER, UTILISER OU ENTRETENIR CET EQUIPEMENT.
Les produits et procédés de soudage peuvent sauser des blessures graves ou la mort, de même que des dommages au reste du matériel et à la propriété, si l’utilisateur n’adhère pas strictement à toutes les règles de sécurité et ne prend pas les précautions nécessaires.
En soudage et coupage, des pratiques sécuritaires se sont développées suite à l’expérience passée. Ces pratiques doivent être apprises par étude ou entraînement avant d’utiliser l’equipement. Toute personne n’ayant pas suivi un entraînement intensif en soudage et coupage ne devrait pas tenter de souder. Certaines pratiques concernent les équipements raccordés aux lignes d’alimentation alors que d’autres s’adressent aux groupes électrogènes.
La norme Z49.1 de l’American National Standard, intitulée “SAFETY IN WELDING AND CUTTING” présente les pratiques sécuritaires à suivre. Ce document ainsi que d’autres guides que vous devriez connaître avant d’utiliser cet équipement sont présentés à la fin de ces instructions de sécurité.
SEULES DES PERSONNES QUALIFIEES DOIVENT FAIRE DES TRAVAUX D’INSTALLATION, DE REPARATION, D’ENTRETIEN ET D’ESSAI.

1.06 Dangers relatifs au soudage à l’arc

AVERTISSEMENT
L’ELECTROCUTION PEUT ETRE MORTELLE.
Une décharge électrique peut tuer ou brûler gravement. L’électrode et le circuit de soudage sont sous tension dès la mise en circuit. Le circuit d’alimentation et les circuits internes de l’équipement sont aussi sous tension dès la mise en marche. En soudage automatique ou semi-automatique avec fil, ce dernier, le rouleau ou la bobine de fil, le logement des galets d’entrainement et toutes les pièces métalliques en contact avec le fil de soudage sont sous tension. Un équipement inadéquatement installé ou inadéquatement mis à la terre est dangereux.
1. Ne touchez pas à des pièces sous tension.
2. Portez des gants et des vêtements isolants, secs et
non troués.
3 Isolez-vous de la pièce à souder et de la mise à la
terre au moyen de tapis isolants ou autres.
4. Déconnectez la prise d’alimentation de l’équipement ou arrêtez le moteur avant de l’installer ou d’en faire l’entretien. Bloquez le commutateur en circuit ouvert ou enlevez les fusibles de l’alimentation afin d’éviter une mise en marche accidentelle.
5. Veuillez à installer cet équipement et à le mettre à la terre selon le manuel d’utilisation et les codes nationaux, provinciaux et locaux applicables.
6. Arrêtez tout équipement après usage. Coupez l’ali­mentation de l’équipement s’il est hors d’usage ou inutilisé.
7. N’utilisez que des porte-électrodes bien isolés. Ne jamais plonger les porte-électrodes dans l’eau pour les refroidir. Ne jamais les laisser traîner par terre ou sur les pièces à souder. Ne touchez pas aux porte­électrodes raccordés à deux sources de courant en même temps. Ne jamais toucher quelqu’un d’autre avec l’électrode ou le porte-électrode.
8. N’utilisez pas de câbles électriques usés, endom­magés, mal épissés ou de section trop petite.
Manual 0-5191 1-9 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i
9. N’enroulez pas de câbles électriques autour de votre corps.
10. N’utilisez qu’une bonne prise de masse pour la mise à la terre de la pièce à souder.
11. Ne touchez pas à l’électrode lorsqu’en contact avec le circuit de soudage (terre).
12. N’utilisez que des équipements en bon état. Réparez ou remplacez aussitôt les pièces endommagées.
LE RAYONNEMENT DE L’ARC PEUT BRÛLER LES YEUX ET LA PEAU; LE BRUIT PEUT ENDOMMAGER L’OUIE.
L’arc de soudage produit une chaleur et des rayons ultraviolets intenses, susceptibles de
AVERTISSEMENT
brûler les yeux et la peau. Le bruit causé par
13. Dans des espaces confinés ou mouillés, n’utilisez pas de source de courant alternatif, à moins qu’il soit muni d’un réducteur de tension. Utilisez plutôt une source de courant continu.
14. Portez un harnais de sécurité si vous travaillez en hauteur.
15. Fermez solidement tous les panneaux et les capots.
AWS F2.2 : 2001 (R2010), Modifié avec l’accord de l’American Welding Society (AWS), Miami, Florida
Guide de teinte des lentilles
Procédé
Taille de l’électrode
en mm (po)
certains procédés peut endommager l’ouïe.
1. Portez une casque de soudeur avec filtre oculaire de nuance appropriée (consultez la norme ANSI Z49 indiquée ci-après) pour vous protéger le visage et les yeux lorsque vous soudez ou que vous observez l’exécution d’une soudure.
Courant
d’arc
(ampères)
Gamme
d’intensité
minimum
Numéro de teinte
recommandée*
(Confort)
Soudage à l’arc avec électrode enrobée (procédé SMAW)
Soudage à l’arc sous gaz avec fil plein (procédé GMAW) et soudage avec fil fourré (procédé FCAW)
Soudage à l’électrode réfractaire (procédé GTAW)
Coupage à l’arc avec électrode de carbone et jet d’air (procédé AAC)
Soudage à l’arc au plasma (procédé PAW)
Coupage plasma (procédé PAC)
Moins de 2,4 (3/32)
3/32-5/32 (2,4-4,0)
5/32-1/4 (4,0-6,4)
Plus de 1/4 (6,4)
(Clair)
(Sombre)
Moins de 60
60-160 160-250 250-550
Moins de 60
60-160 160-250 250-550
Moins de 50
50-150 150-500
Moins de 500 500-
1000
Moins de 20
20-100 100-400 400-800
Moins de 20
20-40 40-60 60-80
80-300 300-400 400-800
7
8 10 11
7 10 10 10
8
8 10
10 11
6
8 10 11
4
5
6
8
8
9 10
­10 12 14
­11 12 14
10 12 14
12 14
6 à 8
10 12 14
4 5 6 8
9 12 14
* En règle générale, commencer avec une teinte plus foncée pour voir la zone de soudage. Réduire ensuite progressivement vers la teinte qui permet de voir la zone de soudage sans dépasser le minimum. Lors du soudage, du coupage ou du brasage au gaz oxygéné, la torche ou le fondant produit une puissante lumière jaune; il est préférable d’utiliser un filtre qui absorbe cette lumière jaune ou le sodium du spectre de la lumière visible.
SAFETY INSTRUCTIONS AND WARNINGS 1-10 Manual 0-5191
2. Portez des lunettes de sécurité approuvées. Des écrans latéraux sont recommandés.
3. Entourez l’aire de soudage de rideaux ou de cloisons pour protéger les autres des coups d’arc ou de l’éblouissement; avertissez les observateurs de ne pas regarder l’arc.
4. Portez des vêtements en matériaux ignifuges et dura­bles (laine et cuir) et des chaussures de sécurité.
5. Portez un casque antibruit ou des bouchons d’oreille approuvés lorsque le niveau de bruit est élevé.
AVERTISSEMENT
LES VAPEURS ET LES FUMEES SONT DANGEREUSES POUR LA SANTE.
Le soudage dégage des vapeurs et des fumées dangereuses à respirer.
1. Eloignez la tête des fumées pour éviter de les respi­rer.
2. A l’intérieur, assurez-vous que l’aire de soudage est bien ventilée ou que les fumées et les vapeurs sont aspirées à l’arc.
3. Si la ventilation est insatisfaisant, portez un respi­rateur à adduction d’air approuvé.
4. Lisez les fiches signalétiques et les consignes du fabricant relatives aux métaux, aux produits consummables, aux revêtements et aux produits nettoyants.
5. Ne travaillez dans un espace confiné que s’il est bien ventilé; sinon, portez un respirateur à adduction d’air. Les gaz protecteurs de soudage peuvent déplacer l’oxygène de l’air et ainsi causer des malaises ou la mort. Assurez-vous que l’air est propre à la respi­ration.
6. Ne soudez pas à proximité d’opérations de dégrais­sage, de nettoyage ou de pulvérisation. La chaleur et les rayons de l’arc peuvent réagir avec des vapeurs et former des gaz hautement toxiques et irritants.
7. Ne soudez des tôles galvanisées ou plaquées au plomb ou au cadmium que si les zones à souder ont été grattées à fond, que si l’espace est bien ventilé; si nécessaire portez un respirateur à adduction d’air. Car ces revêtements et tout métal qui contient ces éléments peuvent dégager des fumées toxiques au moment du soudage.
Fabricator 181iFabricator 181i
AVERTISSEMENT
LE SOUDAGE PEUT CAUSER UN INCENDIE OU UNE EXPLOSION
L’arc produit des étincellies et des pro­jections. Les particules volantes, le métal chaud, les projections de soudure et l’équi­pement surchauffé peuvent causer un incen­die et des brûlures. Le contact accidentel de l’électrode ou du fil-électrode avec un objet métallique peut provoquer des étincelles, un échauffement ou un incendie.
1. Protégez-vous, ainsi que les autres, contre les étin­celles et du métal chaud.
2. Ne soudez pas dans un endroit où des particules volantes ou des projections peuvent atteindre des matériaux inflammables.
3. Enlevez toutes matières inflammables dans un rayon de 10, 7 mètres autour de l’arc, ou couvrez-les soi­gneusement avec des bâches approuvées.
4. Méfiez-vous des projections brulantes de soudage susceptibles de pénétrer dans des aires adjacentes par de petites ouvertures ou fissures.
5. Méfiez-vous des incendies et gardez un extincteur à portée de la main.
6. N’oubliez pas qu’une soudure réalisée sur un pla­fond, un plancher, une cloison ou une paroi peut enflammer l’autre côté.
7. Ne soudez pas un récipient fermé, tel un réservoir ou un baril.
8. Connectez le câble de soudage le plus près possible de la zone de soudage pour empêcher le courant de suivre un long parcours inconnu, et prévenir ainsi les risques d’électrocution et d’incendie.
9. Ne dégelez pas les tuyaux avec un source de courant.
10. Otez l’électrode du porte-électrode ou coupez le fil au tube-contact lorsqu’inutilisé après le soudage.
11. Portez des vêtements protecteurs non huileux, tels des gants en cuir, une chemise épaisse, un pantalon revers, des bottines de sécurité et un casque.
Manual 0-5191 1-11 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i
AVERTISSEMENT
LES ETINCELLES ET LES PROJECTIONS BRULANTES PEUVENT CAUSER DES BLESSURES.
8. Lisez et respectez les consignes relatives aux bouteilles de gaz comprimé et aux équipements connexes, ainsi que la publication P-1 de la CGA, identifiée dans la liste de documents ci-dessous.
Le piquage et le meulage produisent des particules métalliques volantes. En refroi­dissant, la soudure peut projeter du éclats de laitier.
1. Portez un écran facial ou des lunettes protec­trices approuvées. Des écrans latéraux sont recommandés.
2. Portez des vêtements appropriés pour protéger la peau.
AVERTISSEMENT
LES BOUTEILLES ENDOMMAGEES PEU­VENT EXPLOSER
Les bouteilles contiennent des gaz protec­teurs sous haute pression. Des bouteilles endommagées peuvent exploser. Comme les bouteilles font normalement partie du procédé de soudage, traitez-les avec soin.
1. Protégez les bouteilles de gaz comprimé contre les sources de chaleur intense, les chocs et les arcs de soudage.
2. Enchainez verticalement les bouteilles à un support ou à un cadre fixe pour les empêcher de tomber ou d’être renversées.
3. Eloignez les bouteilles de tout circuit électrique ou de tout soudage.
4. Empêchez tout contact entre une bouteille et une électrode de soudage.
5. N’utilisez que des bouteilles de gaz protecteur, des détendeurs, des boyauxs et des raccords conçus pour chaque application spécifique; ces équipe­ments et les pièces connexes doivent être maintenus en bon état.
AVERTISSEMENT
LES MOTEURS PEUVENT ETRE DANGE­REUX
LES GAZ D’ECHAPPEMENT DES MOTEURS PEUVENT ETRE MORTELS.
Les moteurs produisent des gaz d’échappement nocifs.
1. Utilisez l’équipement à l’extérieur dans des aires ouvertes et bien ventilées.
2. Si vous utilisez ces équipements dans un endroit confiné, les fumées d’échappement doivent être envoyées à l’extérieur, loin des prises d’air du bâti­ment.
AVERTISSEMENT
LE CARBURANT PEUR CAUSER UN INCEN­DIE OU UNE EXPLOSION.
Le carburant est hautement inflammable.
1. Arrêtez le moteur avant de vérifier le niveau e car­burant ou de faire le plein.
2. Ne faites pas le plein en fumant ou proche d’une source d’étincelles ou d’une flamme nue.
3. Si c’est possible, laissez le moteur refroidir avant de faire le plein de carburant ou d’en vérifier le niveau au début du soudage.
4. Ne faites pas le plein de carburant à ras bord: pré­voyez de l’espace pour son expansion.
5. Faites attention de ne pas renverser de carburant. Nettoyez tout carburant renversé avant de faire démarrer le moteur.
6. Ne placez pas le visage face à l’ouverture du robinet de la bouteille lors de son ouverture.
7. Laissez en place le chapeau de bouteille sauf si en utilisation ou lorsque raccordé pour utilisation.
SAFETY INSTRUCTIONS AND WARNINGS 1-12 Manual 0-5191
AVERTISSEMENT
DES PIECES EN MOUVEMENT PEUVENT CAUSER DES BLESSURES.
Des pièces en mouvement, tels des ventila­teurs, des rotors et des courroies peuvent couper doigts et mains, ou accrocher des vêtements amples.
1. Assurez-vous que les portes, les panneaux, les capots et les protecteurs soient bien fermés.
2. Avant d’installer ou de connecter un système, arrêtez le moteur.
3. Seules des personnes qualifiées doivent démonter des protecteurs ou des capots pour faire l’entretien ou le dépannage nécessaire.
Fabricator 181iFabricator 181i
AVERTISSEMENT
LA VAPEUR ET LE LIQUIDE DE REFROI­DISSEMENT BRULANT SOUS PRESSION PEUVENT BRULER LA PEAU ET LES YEUX.
Le liquide de refroidissement d’un radiateur peut être brûlant et sous pression.
1. N’ôtez pas le bouchon de radiateur tant que le moteur n’est pas refroidi.
2. Mettez des gants et posez un torchon sur le bouchon pour l’ôter.
3. Laissez la pression s’échapper avant d’ôter complè­tement le bouchon.
4. Pour empêcher un démarrage accidentel pendant l’entretien, débranchez le câble d’accumulateur à la borne négative.
5. N’approchez pas les mains ou les cheveux de pièces en mouvement; elles peuvent aussi accrocher des vêtements amples et des outils.
6. Réinstallez les capots ou les protecteurs et fermez les portes après des travaux d’entretien et avant de faire démarrer le moteur.
AVERTISSEMENT
DES ETINCELLES PEUVENT FAIRE EXPLO­SER UN ACCUMULATEUR; L’ELECTROLYTE D’UN ACCUMU-LATEUR PEUT BRULER LA PEAU ET LES YEUX.
Les accumulateurs contiennent de l’élec­trolyte acide et dégagent des vapeurs explosives.
1. Portez toujours un écran facial en travaillant sur un accumu-lateur.
2. Arrêtez le moteur avant de connecter ou de décon­necter des câbles d’accumulateur.
3. N’utilisez que des outils anti-étincelles pour travailler sur un accumulateur.
4. N’utilisez pas une source de courant de soudage pour charger un accumulateur ou survolter momen­tanément un véhicule.
5. Utilisez la polarité correcte (+ et –) de l’accumulateur.
PLOMB AVERTISSEMENT
AVERTISSEMENT : Ce produit contient des
produits chimiques, notamment du plomb, reconnu par l’État de la Californie pour causer des malformations congénitales et d’autres dommages touchant le système reproductif. Se laver les mains après
manipulation.
REMARQUE
Facteurs relatifs au soudage et aux effets des champs magnétiques et électriques de basse fréquence
Voici une citation tirée du chapitre des conclusions générales du document de base de l’Office of Technology Assessment (bureau des évaluations technologiques) del’U.S. Congress, « Biological Effects of Power Frequency Electric & Magnetic Fields », OTA-BP-E-63 (Washington, DC : U.S. Government Printing Office, mai 1989) : « ... il existe de nos jours, un nombre très élevé de travaux scientifiques qui rapportent les résultats d’expériences menées au niveau cellulaire et d’études auprès d’homme et d’animaux qui établissent nettement le rapport entre les champs magnétiques de basse fréquence et les systèmes biologiques, soit par des interactions ou des modifications. Quoique la plupart de ces travaux soient de très bonne qualité, les résultats sont complexes. Àla lumière des connaissances scientifiques actuelles, il nous est encore impossible d’interpréter les évidences en un seul cadre de référence cohérent. La situation est toutefois très contrariante. En effet, il nous est aussi impossible
Manual 0-5191 1-13 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i
!
!
!
de tirer des conclusions définitives quant aux risques éventuels ou de proposer des stratégies fondées sur des faits scientifiques visant à atténuer ou éviter des risques potentiels ».
Pour atténuer les champs magnétiques sur les lieux detravail, respectez les procédures qui suivent :
1. Maintenez les câbles l’un près de l’autre en les entrelaçant ou les reliant ensemble au ruban.
2. Acheminez les câbles à un côté du soudeur, le plus loin possible.
3. N’enroulez pas de câble autour du corps.
4. Maintenez le bloc d’alimentation du poste desoudage et les câbles aussi loin que possible du corps.
STIMULATEURS CARDIAQUES :
Les procédures décrites ci-dessus sont habituellement celles recommandées pour les porteurs de stimulateurs cardiaques. Pour de plus amples renseignements, consulter unmédecin.
AVERTISSEMENT
N’effectuez JAMAIS d’opérations de soudage sur un récipient qui a contenu des liquides ou vapeurs toxiques, combustibles ou inflammables. N’effectuez JAMAIS d’opéra­tions de soudage dans une zone contenant des vapeurs combustibles, des liquides inflammables ou des poussières explosives.
B. Entretien des Locaux
AVERTISSEMENT
Ne laissez jamais l’oxygène en contact avec la graisse, l’huile ou d’autres substances inflammables. Bien que l’oxygène elle même ne brûle pas, ces substances peuvent deve­nir extrême ment explosives. Elles peuvent prendre feu et brûler violem ment en pré­sence d’oxygène.
Gardez TOUS les appareils propres et exempts de graisse, huile ou autres substances inflammables.

1.07 Informations Générales de Sécurité

A. Prévention D’incendie
Les opérations de soudage utilisent le feu ou la combustion comme outil de base. Ce processus est très utile quand il est cor rectement contrôlé.
1. La zone doit comporter un sol ignifugé.
2. Les établis ou tables utilisés pendant les opéra­tions de soudage doivent avoir un revêtement ignifuge.
3. Utilisez des écrans résistants à la chaleur ou en matériau approuvé pour protéger les cloisons proches ou le sol vul nérable des étincelles et du métal chaud.
4. Gardez un extincteur approuvé du bon type et de la bonne taille dans la zone de travail. Inspectez-le régulièrement pour vous assurer qu’il est en état de fonctionner. Apprenez à vous en servir.
5. Enlevez tous les matériaux combustibles de la zone de travail. Si vous ne pouvez pas les enlever, protégez-les avec une cou vre ignifuge.
C. Aération
AVERTISSEMENT
Ventilez les zones de soudage, chauffage et découpage de façon adéquate pour éviter l’accumulation de gaz explosifs ou toxiques. Certaines combinaisons de métaux, revête­ments et gaz génèrent des fumées toxiques: Utilisez un équipement de protection res­piratoire dans ces circonstances. Si vous soudez ou brasez, lisez et assimilez la fiche technique de sécurité de matériau relative à l’alliage de soudage/brasage.
D. Protection Personnelle
Les flammes de gaz produisent une radiation infrarouge qui peut avoir un effet néfaste sur la peau, et particu­lièrement sur les yeux. Choisissez des lunettes ou un masque avec des verres trempés assombris au niveau 4 ou plus sombre, pour protéger vos yeux des dommages et garder une bonne visibilité sur le travail.
Portez en permanence des gants de protection et des vête ments ignifuges pour la protection de la peau et des vêtements contre les étincelles et le laitier. Gardez col,
SAFETY INSTRUCTIONS AND WARNINGS 1-14 Manual 0-5191
Fabricator 181iFabricator 181i
!
!
!
manches et poches boutonnés. Il ne faut pas remonter vos manches ou les pantalons à revers.
Quand vous travaillez dans un environnement non dédié au soudage ou découpage, portez toujours une protection des yeux appropriées ou un masque facial.
AVERTISSEMENT
Mettez en pratique les procédures de sécurité et de mode opératoire suivantes à chaque fois que vous utilisez cet appareil de régulation de pression. Si vous déviez de ces procédures, cela peut entraîner incendie, explosion, dégâts matériels et/ou blessures corporelles pour l’opérateur.
E. Bouteilles de Gaz Comprimé
Le Département des Transports américain (DOT) approuve la conception et la fabrication des bouteilles qui contiennent les gaz utilisés pour les opérations de soudage ou de découpage.
AVIS
Ce document CGA p. t peut être obtenu en écrivant à “Compressed Gas Association”, 4221 Walney Roed, 5th Floor. Chantilly, VA
20151.2923, USA.
2. Placez le bouchon de protection de vanne sur la bouteille à chaque fois que vous la déplacez ou ne l’utilisez pas. Ne faites jamais glisser ou rouler d’aucune manière les bouteilles. Utilisez un diable approprié pour les déplacer.
3. Entreposez les bouteilles vides à l’écart des bou­teilles pleines. Marquez-les “VIDE” et refermez leur vanne.
4. N’utilisez JAMAIS des bouteilles de gaz comprimé sans un régulateur de pression en série sur la vanne de bouteille.
5. Inspectez la vanne de bouteille pour y détec­ter de l’huile ou de la graisse, ou dès pièces endommagées.
1. Placez la bouteille (Le schéma 1) là où elle sera uti­lisée. Gardez-la en position verticale. Fixez-la sur un chariot une cloison, un établi, etc.
Art # A-12127
Le schéma 1-1: Cylindres de gaz
AVERTISSEMENT
Les bouteilles sont sous haute pression. Manipu­lez-les avec précautions. Des accidents sérieux peuvent résulter d’une mauvaise manutention ou d’un mauvais emploi des bouteilles de gaz comprimé. NE faites PAS tomber la bouteille, ne la cognez pas, ne l’exposez pas à une chaleur excessive, aux flammes ou étincelles. NE la cognez PAS contre d’autres bouteilles. Contactez votre fournisseur de gaz ou reportez vous à la publication CGA P-1 “Manipulation sécurisée des gaz compri­més en conteneur” pour plus d’informations sur l’utilisation et la manutention des bouteilles.
AVERTISSEMENT
N’UTILISEZ PAS la bouteille si vous trou­vez de l’huile, de la graisse ou des pièces endommagées. Informez immédiate ment votre fournisseur de’ gaz de cet état.
6. Ouvrez et fermez momentanément la vanne de la bouteille, délogeant ainsi d’éventu lIes pous­sières ou saletés. qui pour raient être présentes dans la vanne.
MISE EN GARDE
Ouvrez la vanne de bouteille légèrement. Si vous l’ouvrez trop en grand, la bouteille pourrait se renverser. Quand vous ouvrez/ fermez rapidement la vanne de bouteille, ne vous tenez pas directement devant. Opérez toujours cette opération dans une zone bien ventilée. Si une bouteille d’acétylène crache un brouillard, laissez reposer pendant 15 minutes. Essayez de nouveau la vanne. Si le problème persiste, con tactez votre four­nisseur de gaz.
Manual 0-5191 1-15 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i

1.08 Principales Normes De Securite

Safety in Welding and Cutting, norme ANSI Z49.1, American Welding Society, 550 N.W. LeJeune Rd., Miami, FL 33128.
Safety and Health Standards, OSHA 29 CFR 1910, Supe­rintendent of Documents, U.S. Government Printing Office, Washington, D.C. 20402.
Recommended Safe Practices for the Preparation for Welding and Cutting of Containers That Have Held Hazardous Substances, norme AWS F4.1, American Welding Society, 550 N.W. LeJeune Rd., Miami, FL
33128. National Electrical Code, norme 70 NFPA, National Fire
Protection Association, Batterymarch Park, Quincy, MA 02269.
Safe Handling of Compressed Gases in Cylinders, docu­ment P-1, Compressed Gas Association, 1235 Jefferson Davis Highway, Suite 501, Arlington, VA 22202.
Code for Safety in Welding and Cutting, norme CSA W117.2 Association canadienne de normalisation, Stan­dards Sales, 276 Rexdale Boulevard, Rexdale, Ontario, Canada M9W 1R3.
Safe Practices for Occupation and Educational Eye and Face Protection, norme ANSI Z87.1, American National Standards Institute, 1430 Broadway, New York, NY
10018. Cutting and Welding Processes, norme 51B NFPA,
National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
SAFETY INSTRUCTIONS AND WARNINGS 1-16 Manual 0-5191

1.09 Graphique de Symbole

Seulement certains de ces symboles apparaîtront sur votre modèle.
Fabricator 181iFabricator 181i
SousTension
Hors Tension
Tension dangereuse
Augmentez/Diminuer
Disjoncteur
Source AC Auxiliaire
Fusible
Intensité de Courant
Tension
Hertz (cycles/sec)
Fréquence
Négatif
Positif
Courant Continue (DC)
X
%
Mono Phasé
Trois Phasé
Tri-Phase Statique
Fréquence Convertisseur Transformateur-Redresseur
Distant
Facteur de Marche
Pourcentage
Panneau/Local
Soudage Arc Electrique Avec Electrode Enrobé (SMAW)
Soudage á L’arc Avec Fil Electrodes Fusible (GMAW)
Soudage á L’arc Avec Electrode Non Fusible (GTAW)
Decoupe Arc Carbone (CAC-A)
Courant Constant
Tension Constante Ou Potentiel Constant
Haute Température
Déroulement du Fil
Alimentation du Fil Vers la Pièce de Fabrication Hors Tension
Torch de Soudage
Purge Du Gaz
Mode Continu de Soudure
Soudure Par Point
Duréc du Pulse
t
t1
Appuyez pour dèruarer l’alimentation du fils et la soudure, le relâcher pour arrêter.
Maintenez appuyez pour pré-dèbit, relailez pour initier l'arc. Appuyez pour arrêter l'arc, et mainteuir pour pré-dèbit.
Durée de Pré-Dèbit
Durée de Post-Dèbit
t2
Détente à 2-Temps
Détente à 4-Temps
Probléme de Terre
t
Terre de Protection
Ligne
Connexion de la Ligne
Source Auxiliaire
115V 15A
Note: Pour les environnements avec des risques de choc électrique, le fournisseur d'énergie portant la marque conforme
à EN50192 lorsqu'utilisé en conjonction avec des lampes de poche avec des conseils exposés, si équipés avec des guide à l'hauteur de buse correctement installé. Ne pas déposer avec les déchets ménagers.
Classement de Prise­Source Auxiliaire
Force d'Arc
Amorçage de L’arc au Contact (GTAW)
Inductance Variable
Tension
V
IPM
MPM
S
Pouces Par Minute
Mètres Par Minute
Voir Note
Voir Note
Art # A-07639_AB
S
Manual 0-5191 1-17 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i

1.10 Declaration Of Conformity

Declaration of Conformity
3163339
We Victor Technologies International Inc.
of 16052 Swingley Ridge Road Suite 300 Chestereld, MO 63033 U.S.A.
in accordance with the following Directive(s):
•2006/95/EC The Low Voltage Directive
•2004/108/EC The Electromagnetic Compatibility (EMC) Directive
hereby declare that:
Equipment: Arc Welding Power Source
Model Name/Number: Fabricator 181i
Market Release Date: January 16, 2014
is in conformity with the applicable requirements of the following harmonized standards:
  •EN 60974-10:2007 Arc Welding Equipment - Part 10: Electromagnetic compatibility (EMC) requirements
•EN 60974-1:2012 Arc Welding Equipment - Part 1: Welding power sources.
Classification: The equipment described in this document is Class A and intended for industrial use.
Manufacturer’s Authorized Representative
Steve Ward V.P. Europe and General Manager
Address:Victor Technologies International Inc.
Europa Building
Chorley N Industrial Park Chorley, Lancashire, England PR6 7BX
Date: November 18, 2014
Steve Ward (Full Name)
V.P. Europe and General Manager
(Position)
(Signature)
!
WARNING
This Class A equipment is not intended for use in residential locations where the electrical power is provided by the public low-voltage supply system. There may be potential difficulties in ensuring electromagnetic compatibility in those locations, due to conducted as well as radiated disturbances.
SAFETY INSTRUCTIONS AND WARNINGS 1-18 Manual 0-5191
Fabricator 181iFabricator 181i
Classication:TheequipmentdescribedinthismanualisClassAandintendedforindustrialuse.
!
WARNING
This Class A equipment is not intended for use in residential locations where the electrical power is provided by the public low-voltage supply system. There may be potential difcul­ties in ensuring electromagnetic compatibility in those locations, due to conducted as well as radiated disturbances.
Manual 0-5191 1-19 SAFETY INSTRUCTIONS AND WARNINGS
Fabricator 181i Fabricator 181i
This Page Intentionally Blank
SAFETY INSTRUCTIONS AND WARNINGS 1-20 Manual 0-5191
SECTION 2:
INTRODUCTION
Fabricator 181i

2.01 How to Use This Manual

This Manual usually applies to the part numbers listed on page i. To ensure safe operation, read the entire manual, including the chapter on safety instructions and warnings. Throughout this manual, the word WARNING, CAUTION and NOTE may appear. Pay particular attention to the information provided under these headings. These special annotations are easily recognized as follows:
WARNING
Gives information regarding possible electri­cal shock injury. Warnings will be enclosed in a box such as this.
!
WARNING
Gives information regarding possible per­sonal injury. Warnings will be enclosed in a box such as this.
CAUTION
Refers to possible equipment damage. Cau­tions will be shown in bold type.
NOTE
Offers helpful information concerning cer­tain operating procedures. Notes will be shown in italics.
You will also notice icons from the safety section appear­ing throughout the manual. These are to advise you of specific types of hazards or cautions related to the por­tion of information that follows. Some may have multiple hazards that apply and would look something like this:

2.03 Receipt of Equipment

When you receive the equipment, check it against the invoice to make sure it is complete and inspect the equipment for possible damage due to shipping. If there is any damage, notify the carrier immediately to file a claim. Furnish complete information concerning dam­age claims or shipping errors to the location in your area listed in the inside back cover of this manual. Include all equipment identification numbers as described above along with a full description of the parts in error.

2.04 Description

The Tweco Fabricator 181i is a self contained single phase multi process welding system that is capable of performing MIG (GMAW/FCAW), STICK (SMAW) and LIFT TIG (GTAW) welding processes. The Power Source is equipped with an integrated wire feed unit, digital voltage and amperage meters, and a host of other fea­tures in order to fully satisfy the broad operating needs of the modern welding professional. The Power Source is also fully compliant to Standard CSA E60974-1-00 and UL 60974.1.
The Fabricator 181i MIG provides excellent welding performance across a broad range of applications when used with the correct welding consumables and proce­dures. The following instructions detail how to correctly and safely set up the machine and give guidelines on gaining the best efficiency and quality from the Power Source. Please read these instructions thoroughly be­fore using this equipment.

2.05 Transportation Methods

!
Disconnect input power con­ductors from de-energized supply line before moving the welding Power Source.

2.02 Equipment Identification

The Power Source's identification number (specifica­tion or part number), model, and serial number usually appear on a nameplate attached to the machine. Equip­ment which does not have a nameplate attached to the machine is identified only by the specification or part number printed on the shipping container. Record these numbers for future reference.
Manual 0-5191 2-1 INTRODUCTION
Lift Power Source with handle on top of case. Use handcart or similar device of adequate capacity. If using a fork lift vehicle, secure the Power Source on a proper skid before transporting.
Fabricator 181i

2.06 User Responsibility

This equipment will perform as per the information contained herein when installed, operated, maintained and repaired in accordance with the instructions provided. This equipment must be checked periodically. Defective equipment (including welding leads) should not be used. Parts that are broken, missing, plainly worn, distorted or contaminated, should be replaced immediately. Should such repairs or replacements become necessary, it is recommended that such repairs be carried out by appropriately qualified persons approved by Tweco. Advice in this regard can be obtained by contacting an Accredited Tweco Distributor.
This equipment or any of its parts should not be altered from standard specification without prior written approval of Tweco. The user of this equipment shall have the sole responsibility for any malfunction which results from improper use or unauthorized modification from standard specification, faulty maintenance, damage or improper repair by anyone other than appropriately qualified persons approved by Tweco.

2.07 Fabricator 181i Portable System Package (Part No. W1003181)

A-12166
INTRODUCTION 2-2 Manual 0-5191
Fabricator 181i
A-10352
Duty Cycle (percentage)
Safe
Operating
Region
0
20 40 60
80
100
120 140 160 180
30
50
70
90
40
60
20
10
80 100
0
Welding Current (amps)
STICK (SMAW)
TIG (GTAW)
MIG (GMAW/FCAW)

2.08 Duty Cycle

The rated duty cycle of a Welding Power Source, is a statement of the time it may be operated at its rated weld­ing current output without exceeding the temperature limits of the insulation of the component parts. To explain the 10 minute duty cycle period the following example is used. Suppose a Welding Power Source is designed to operate at a 20% duty cycle, 180 amperes at 23 volts. This means that it has been designed and built to provide the rated amperage (180 A) for 2 minutes, i.e. arc welding time, out of every 10 minute period (20% of 10 minutes is 2 minutes). During the other 8 minutes of the 10 minute period the Welding Power Source must idle and be allowed to cool.
Manual 0-5191 2-3 INTRODUCTION
Figure 2-1: Fabricator 181i Duty Cycle
Fabricator 181i
2.09 Specifications
DESCRIPTION FABRICATOR 181i MULTI PROCESS 3 IN 1 WELDER
Power Source Part No. W1003180 Power Source Dimensions H16.14" x W8.27" x D17.72" (410mm x 210mm x 450mm) Power Source Mass 32.2lb(14.6kg) Cooling Fan Cooled Welder Type Multi Process Welding System Output Terminal Type DinseTM 50 Standards CSA E60974-1-00 / UL60974-1 / IEC 60974-1 Number of Phases Single Phase Nominal Supply Voltage 230V AC Supply Voltage Range 208-265V AC Supply Frequency 50/60Hz Welding Current Range (MIG Mode) 10-180A Wirefeed Speed Range 100 - 650 IPM MIG Welding Voltage Range 14.5 - 23V DC Nominal OCV 62V DC Effective Input Current (I
for MIG (GMAW/FCAW) for LIFT TIG (GTAW) for STICK (SMAW)
Maximum Input Current (I for MIG (GMAW/FCAW) for LIFT TIG (GTAW) for STICK (SMAW)
1eff
)
1max
15.9 Amps
14.3 Amps
17.2 Amps
)
35.6 Amps
28.6 Amps
35.7 Amps
Single Phase Generator Requirement 9 KVA MIG (GMAW/FCAW) Welding Output at 104°F
(40°C)
180A @ 20%, 23V 113A @ 60%, 19.7V 88A @ 100%, 18.4V
STICK (SMAW) Welding Output at 104°F (40°C).
175A @ 20%, 27V
101A @ 60%, 24V 78A @ 100%, 23.1V
LIFT TIG (GTAW) Welding Output at 104°F (40°C).
175A @ 25%, 17V 113A @ 60%, 14.5V 88A @ 100%, 13.5V
Protection Class IP23S
Table 2-1: Fabricator 181i Specification
INTRODUCTION 2-4 Manual 0-5191
Fabricator 181i
NOTE
The recommended time delay fuse or circuit breaker size is 50 amp. An individual branch circuit capable of carrying 50 amperes and protected by fuses or circuit breaker is recommended for this application. Fuse size is based on not more than 200 percent of the rated input amperage of the welding Power Source (Based on Article 630, National Electrical Code)
Tweco continuously strives to produce the best product possible and therefore reserves the right to change, improve or revise the speci fications or design of this or any product without prior notice. Such updates or changes do not entitle the buyer of equipment previously sold or shipped to the correspond­ing changes, updates, improvements or replacement of such items.
The values specified in the table above are optimal values, your values may differ. Individual equipment may differ from the above specifications due to in part, but not exclusively, to any one or more of the following; variations or changes in manufactured components, installation location and conditions and local power grid supply conditions.
The thermal protection switch is rated at 80°C.

2.10 Options and Accessories

DESCRIPTION PART NUMBER
Tweco Fusion 180A MIG Gun, 12ft (3.6m) Length Tweco Spool Gun 160A,12ft (3.6M) Length, suits 4" (100mm) spools for aluminum welding
TIG Torch, 17V, 12.5 ft, 8 pin and accessory kit with 1/16", 3/32", 1/8" thoriated tungstens; 1/16", 3/32", 1/8" collets; 1/16", 3/32", 1/8" collet bodies; No. 5, 6, 7 Alumina nozzle; short back cap; long back cap
Fabricator 141i-181i Carry Bag Basic 4 Wheel Cart Foot Control for remote amperage control when TIG welding Tweco WeldSkill Auto-Darkening Helmet Skull & Fire (USA Only) Drive Roll .023" - .035" (0.6-0.9mm) V groove for steel & stainless steel Drive Roll .023"- .030" (0.6-0.8mm) V groove for steel & stainless steel wires [Fitted] Drive Roll .035"/.045" (0.9/1.2mm) V groove for steel & stainless steel wires Drive Roll .030"-.035" (0.8-0.9mm) U grooved for aluminum wires Drive Roll .040"-.045" (1.0-1.2mm) U grooved for aluminum wires Drive Roll .030"-.035" (0.8-0.9mm) V knurled groove for flux cored wires Drive Roll .045" (1.2mm) V knurled groove for flux cored wire
F180TA-12-3035
SG160TA-12-3035
W4013802
W4015301 W4014700
600285 4100-1004 W4014800
7977036
7977660
7977731 7977264 7977732
704277
Stick Lead, 200A, 13ft, 50mm Dinse Ground Lead, 200A,10ft, 50mm Dinse Victor Argon Regulator/Flowgauge
Accessory Kit for TIG Torch with 1/16", 3/32", 1/8" thoriated tungstens; 1/16", 3/32", 1/8" collets; 1/16", 3/32", 1/8" collet bodies; No. 5, 6, 7 Alumina nozzle; short back cap; long back cap
Table 2-2: Fabricator 181i Options and Accessories List
Manual 0-5191 2-5 INTRODUCTION
WS200E13
WS200G10
0781-4169
P062900010
Fabricator 181i
This Page Intentionally Blank
INTRODUCTION 2-6 Manual 0-5191
SECTION 3:
!
INSTALLATION, OPERATION AND SETUP
Fabricator 181i

3.01 Environment

This Power Source is designed for use in environments with increased hazard of electric shock.
A. Examples of environments with increased hazard of
electric shock are:
1. In locations in which freedom of movement is restricted, so that the operator is forced to perform the work in a cramped (kneeling, sitting or lying) position with physical contact with conductive parts.
2. In locations which are fully or partially limited by conductive elements, and in which there is a high risk of unavoidable or accidental contact by the operator.
3. In wet or damp hot locations where humidity or perspiration considerable reduces the skin resistance of the human body and the insulation properties of accessories.
B. Environments with increased hazard of electric shock
do not include places where electrically conductive parts in the near vicinity of the operator, which can cause increased hazard, have been insulated.
G. The enclosure design of this Power Source meets the
requirements of IP23S as outlined in EN 60529. This provides adequate protection against solid objects (greater than 1/2", 12mm), and direct protection from vertical drops. Under no circumstances should the Power Source be operated or connected in a micro environment that will exceed the stated conditions. For further information please refer to EN 60529.
H. Precautions must be taken against the power source
toppling over. The power source must be located on a suitable horizontal surface in the upright position when in use.
WARNING
This equipment should be electrically connected by a qualified electrician.

3.03 Ventilation

WARNING

3.02 Location

Be sure to locate the welder according to the following guidelines:
A. In areas, free from moisture and dust. B. Ambient temperature between 32 to 104° F (0 to
40° C). C. In areas, free from oil, steam and corrosive gases. D. In areas, not subjected to abnormal vibration or
shock. E. In areas, not exposed to direct sunlight or rain. F. Place at a distance of 12" (300mm) or more from
walls or similar that could restrict natural air flow
for cooling.
Since the inhalation of welding fumes can be harmful, ensure that the welding area is effectively ventilated.

3.04 Electricity Supply Voltage

The Electricity Supply voltage should be within 208-265V
AC. Too low a voltage may cause poor welding performance in STICK mode. Too high a supply voltage will cause components to overheat and possibly fail.
The Welding Power Source must be:
• Correctly installed,if necessary,bya qualied
electrician.
• Correctlyearthed(electrically)inaccordancewith
local regulations.
• Connectedtothecorrectsizepowerpointandfuse
as per the Specifications on page 2-4.
Manual 0-5191 3-1 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
WARNING
The Fabricator 181i must be electrically connected by a qualified electrical trades-person. Damage to the PCA (Power Control Assembly) could occur if 265 VAC or higher is applied to the Primary Power Cable.
WARNING
ELECTRIC SHOCK can kill; SIGNIFICANT DC VOLTAGE is present after removal of input power. DO NOT TOUCH live electrical parts.
SHUT DOWN welding Power Source, disconnect input power employing lockout/tagging procedures. Lock-out/
tagging procedures consist of padlocking line disconnect switch in open position, removing fuses from fuse box, or shutting OFF and red-tagging circuit breaker or other disconnecting device.
Electrical Input Requirements
Operate the welding Power Source from a single-phase 50/60 Hz, AC power supply. The input voltage must match one of the electrical input voltages shown on the input data label on the unit nameplate. Contact the local electric utility for information about the type of electrical service available, how proper connections should be made, and inspection required. The line disconnect switch provides a safe and convenient means to completely remove all electrical power from the welding power source whenever necessary to inspect or service the unit.
Do not connect an input (WHITE or BLACK) conductor to the ground terminal. Do not connect the ground (GREEN) conductor to an input line terminal.
• Correctlyinstalled,ifnecessary,byaqualiedelectrician.
• Correctlyearthed(electrically)inaccordancewithlocalregulations.
• Connectedtothecorrectsizepowerpoint,fuseandprimarysupplyleadbasedonTable3-1.
WARNING
An electric shock or fire hazard is probable if the following electrical service guide recommendations are not followed. These recommendations are for a dedicated branch circuit sized for the rated output and duty cycle of the welding Power Source.
50 / 60 Hz Single Phase Supply
Supply Voltage 230V AC Input Current at Maximum Output 35.7 Amps
Maximum Recommended Fuse* or Circuit Breaker Rating *Time Delay Fuse, UL class RK5. Refer to UL248 Maximum Recommended Fuse^ or Circuit Breaker Rating ^Normal Operating , UL class K5. Refer to UL248
Minimum Recommended Input Cable Size 12 AWG Maximum Recommended Input Conductor Length 50 ft (15m) Minimum Recommended Grounding Conductor Size 12 AWG
50 Amps
50 Amps
Table 3-1: Electrical Service Guide
NOTE
Welding arc outs may be experienced if an extension cord is used when STICK welding when operation the Power Source on 208 VAC due to the lack of DC voltage at the STICK electrode.
INSTALLATION, OPERATION AND SETUP 3-2 Manual 0-5191
Fabricator 181i
Input Power
Each unit incorporates an INRUSH circuit. When the MAIN CIRCUIT SWITCH is turned ON, the inrush circuit provides pre-charging for the input capacitors. A relay in the Power Control Assembly (PCA) will turn ON after the input capacitors have charged to operating voltage (after approximately 5 seconds)
NOTE
Damage to the PCA could occur if 265V AC or higher is applied to the Primary Power Cord.
Primary Supply
Model
Fabricator 181i
Cord Size
(Factory Fitted)
12 AWG (3.3mm²)
Table 3-2: Primary Circuit Sizes to Achieve Maximum Current

3.05 Electromagnetic Compatibility

WARNING
Extra precautions for Electromagnetic Compatibility may be required when this Welding Power Source is used in a domestic situation.
A. Installation and Use - Users Responsibility
The user is responsible for installing and using the
welding equipment according to the manufacturer’s instructions. If electromagnetic disturbances are detected then it shall be the responsibility of the user of the welding equipment to resolve the situation with the technical assistance of the manufacturer. In some cases this remedial action may be as simple as earthing the welding circuit, see NOTE below. In other cases it could involve constructing an electromagnetic screen enclosing the Welding Power Source and the work, complete with associated input filters. In all cases, electromagnetic disturbances shall be reduced to the point where they are no longer troublesome.
NOTE
Minimum Primary
Current Circuit Size
(Vin/Amps)
208-230V/40A 180A @ 20% 175A @ 20% 208-230V/25A 175A @ 25%
MIG (GMAW/
FCAW)
B. Assessment of Area
Before installing welding equipment, the user shall
make an assessment of potential electromagnetic problems in the surrounding area. The following shall be taken into account
1. Other supply cables, control cables, signaling and telephone cables; above, below and adjacent to the welding equipment.
2. Radio and television transmitters and receivers.
3. Computer and other control equipment.
4. Safety critical equipment, e.g. guarding of industrial equipment.
5. The health of people around, e.g. the use of pacemakers and hearing aids.
6. Equipment used for calibration and measurement.
7. The time of day that welding or other activities are to be carried out.
8. The immunity of other equipment in the environment: the user shall ensure that other equipment being used in the environment is compatible: this may require additional protection measures.
Current & Duty Cycle
STICK (SMAW)
LIFT TIG
(GTAW)
The welding circuit may or may not be earthed for safety reasons. Changing the earthing arrangements should only be authorized by a person who is competent to assess whether the changes will increase the risk of injury, e.g. by allowing parallel welding
The size of the surrounding area to be considered
will depend on the structure of the building and other activities that are taking place. The surrounding area may extend beyond the boundaries of the premises.
C. Methods of Reducing Electromagnetic Emissions
current return paths which may damage the earth circuits of other equipment. Further
1. Electricity Supply
guidance is given in EN 60974-13 Arc Welding Equipment - Installation and use (under preparation).
Manual 0-5191 3-3 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
LOW PRESSURE GAUGE (DELIVERY)
HIGH PRESSURE GAUGE (SUPPLY)
INLET
CONNECTION
OUTLET
CONNECTION
PRESSURE ADJUSTING
SCREW
A-09414_AB
Welding equipment should be connected to the
Electricity Supply according to the manufacturer’s recommendations. If interference occurs, it may be necessary to take additional precautions such as filtering of the Electricity Supply. Consideration should be given to shielding the supply cable of permanently installed welding equipment in metallic conduit or equivalent. Shielding should be electrically continuous throughout it’s length. The shielding should be connected to the Welding Power Source so that good electrical contact is maintained between the conduit and the Welding Power Source enclosure.
2. Maintenance of Welding Equipment The welding equipment should be routinely
maintained according to the manufacturer’s recommendations. All access and service doors and covers should be closed and properly fastened when the welding equipment is in operation. The welding equipment should not be modified in any way except for those changes and adjustments covered in the manufacturer’s instructions. In particular, the spark gaps of arc striking and stabilizing devices should be adjusted and maintained according to the manufacturer’s recommendations.
3. Welding Cables The welding cables should be kept as short
as possible and should be positioned close together, running at or close to the floor level.
4. Equipotential Bonding Bonding of all metallic components in the
welding installation and adjacent to it should be considered. However. Metallic components bonded to the work piece will increase the risk that the operator could receive a shock by touching the metallic components and the electrode at the same time. The operator should be insulated from all such bonded metallic components.
5. Earthing of the Workpiece Where the workpiece is not bonded to earth
for electrical safety, nor connected to earth because of it’s size and position, e.g. ship’s hull or building steelwork, a connection bonding the workpiece to earth may reduce emissions in some, but not all instances. Care should be taken to prevent the earthing of the workpiece increasing the risk of injury to users, or damage to other electrical equipment. Where necessary, the connection of the workpiece to earth should be made by direct connection to the workpiece, but in some countries where direct connection is not permitted, the bonding should be achieved by suitable capacitance, selected according to national regulations.
6. Screening and Shielding Selective screening and shielding of other cables
and equipment in the surrounding area may alleviate problems of interference. Screening the entire welding installation may be considered for special applications.

3.06 Victor Regulator

Pressure regulator (Figure 3-1) attached to the cylinder valve reduce high cylinder pressures to suitable low working pressures for welding, cutting, and other applications.
INSTALLATION, OPERATION AND SETUP 3-4 Manual 0-5191
Figure 3-1: Victor CS Regulator
!
!
!
Art # A-09845
!
!
Use the regulator for the gas and pressure for which it is designed. NEVER alter a regulator for use with any other gas.
Regulators purchased with open 1/8”, 1/4”, 3/8”, or 1/2” NPT ports must be assembled to their intended system.
1. Note the maximum inlet pressure stamped on the regulator. DO NOT attach the regulator to a system that has a higher pressure than the maximum rated pressure stamped on the regulator.
2. The regulator body will be stamped “IN” or “HP” at the inlet port. Attach the inlet port to the system supply pressure connection.
WARNING
NOTE
Fabricator 181i
6. Carefully inspect the regulator for damaged threads, dirt, dust, grease, oil, or other flammable substances. Remove dust and dirt with a clean cloth. Be sure the inlet swivel filter is clean and in place. Attach the regulator (Figure 3-2) to the cylinder valve. Tighten securely with a wrench.
WARNING
DO NOT attach or use the regulator if oil, grease, flamma ble substances or damage is present! Have a qualified repair technician clean the regulator or repair any damage.
3. Wrap pipe threads with Teflon tape 1 1/2 to 2 turns to effect a seal. If other sealants are used, they must be compatible with the gas that will be used in the system.
4. If gauges are to be attached to the regulator and the regu lator is stamped and listed by a third party (i.e. “UL” or “ETL”). The following requirements must be met:
a) Inlet gauges over 1000 PSIG (6.87 mPa)
shall conform with the requirements of UL 404, “Indicating Pressure Gauges for Com­pressed Gas Service.”
b) Low pressure gauges must be UL recognized
for the class of regulator they are being used on according to UL252A.
DO NOT use a regulator that delivers pressure exceeding the pressure rating of the downstream equipment unless pro visions are made to prevent over­pressurization (i.e. system relief valve). Make sure the pressure rating of the down­stream equipment is compatible with the maximum delivery pressure of the regulator.
5. Be sure that the regulator has the correct pressure rating and gas service for the cylinder used.
WARNING
Figure 3-2: Regulator to Cylinder Valve
7. Before opening the cylinder valve, turn the regulator adjusting screw counterclockwise until there is no pressure on the adjusting spring and the screw turns freely.
8. Relief Valve (where provided): The relief valve is designed to protect the low pressure side of the regulator from high pres sures. Relief valves are not intended to protect down stream equipment from high pressures.
WARNING
DO NOT tamper with the relief valve or remove it from the regulator.
WARNING
Stand to the side of the cylinder opposite the regulator when opening the cylinder valve. Keep the cylinder valve between you and the regulator. For your safety, NEVER STAND IN FRONT OF OR BEHIND A REGULATOR WHEN OPENING THE CYLINDER VALVE!
Manual 0-5191 3-5 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
Art # A-09828
!
!
9. Slowly and carefully open the cylinder valve (Figure 3-3) until the maximum pressure shows on the high pressure gauge.
Figure 3-3: Open Cylinder Valve
10. On all cylinders, except acetylene, open the valve completely to seal the valve packing. On gaugeless regulators, the indicator will register the cylinder contents open.
11. On acetylene cylinders, open the valve 3/4 of a turn and no more than 1-1/2.
Acetylene delivery pressure must not exceed 15 PSIG (103 kPa) or 30 PSIG (207 kPa). Acetylene can dissociate (decompose with explosive violence) above these pressure limits.
WARNING
a) If the high-pressure gauge reading drops,
there is a leak in the cylinder valve, inlet fitting, or high-pressure gauge.
b) If the low-pressure gauge drops, there is a
leak in the down stream equipment, hose, hose fitting, outlet fitting or low-pressure gauge. Check for leaks using an approved leak detector solution.
c) If the high-pressure gauge drops and the
low-pressure gauge increases at the same time, there is a leak in the regulator seat.
d) If the regulator requires service or repair,
take it to a qualified repair technician.
5. Once leak testing has been performed and there are no leaks in the system, slowly open the cylinder valve and proceed.
If a leak has been detected anywhere in the system, dis continue use and have the system repaired. DO NOT use leaking equipment. Do not attempt to repair a leaking system while the system is under pressure.
WARNING

3.08 When You Finish Using the Regulator

1. Close the cylinder valve.
CAUTION
Keep the cylinder valve wrench, if one is required, on the cylinder valve to turn OFF the cylinder quickly, if necessary.
12. Attach the desired downstream equipment.

3.07 Leak Testing the System

Leak test the system before putting into operation.
1. Be sure that there is a valve in the downstream equipment to turn OFF the gas flow.
2. With the cylinder valve open, adjust the regulator to deliver the maximum required delivery pressure.
3. Close the cylinder valve.
4. Turn the adjusting screw/knob counterclockwise one turn.
INSTALLATION, OPERATION AND SETUP 3-6 Manual 0-5191
2. Open the valve on the downstream equipment. This drains all pressure from the system.
3. Close the valve on the downstream equipment.
4. Turn the adjusting screw counterclockwise to release the ten sion on the adjusting spring.
5. Check the gauges after a few minutes for verification that the cylinder valve is closed completely.

3.09 Storage of the Regulator

When the regulator is not in use and has been removed from the cylinder, it should be stored in an area where it will be pro tected from dust, oil, and grease. The inlet and outlet should be capped to protect against internal contamination and prevent insects from nesting.

3.10 Power Source Controls, Indicators and Features

18
Fabricator 181i
4
5
1
14
13
FAULT
2
44
33
3
22
11
WIRESPEED INDUCTANCE
WIRESPEED
POWER
A
V
66
77
88
22
11
99
10 10
10 10
DOWNSLOPE (S)
DOWNSLOPE(S)
ARC FORCE (%)
ARCFORCE(%)
99
2
2
SOFT
INDUCTANCE
MIG
MIG
LIFT TIG
STICK
STICK
2T
2T
4T
4T
4
6
6
8
8
-
HARD+ SOFT
HARD
12
11
10
15
16
17
9
8
7
6
Art #
A-12167
Figure 3-4: Front Panel
Figure 3-6: Wire Feed Compartment Control
Art #
A-10354
Figure 3-5: Rear Panel
19
20
21
Art #
A-10355
Manual 0-5191 3-7 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
1. Power Indicator
The power indicator is illuminated when the Electricity Supply is applied to the Power Source and when the ON/OFF switch located on the rear panel is in the ON position.
2. Digital Wirespeed/Amperage Meter (Left Digital Display)
This digital meter displays preview Wirespeed in MIG mode only then actual amperage (weld current) once an arc has been established. It also displays preview amperage in both the STICK and LIFT TIG modes only then actual amperage (weld current) once an arc has been established.
At times of non-welding, the amperage meter will display a preview value in both STICK and LIFT TIG modes. This value can be adjusted by varying the amperage potentiometer (Control No. 3). At times of non-welding, the amperage meter will preview a wirefeed speed value (Inches Per Minute) in MIG mode only. This can be identified as preview wirefeed speed by a decimal point at the lower right hand side of the display.
When welding, the amperage meter will display actual amperage (weld current) in all modes.
At the completion of welding, the amperage meter will hold the last recorded amperage value for a period of approximately 10 seconds in all modes. The amperage meter will hold the value until; (1) any of the front panel controls are adjusted in which case the Power Source will revert to preview mode, (2) welding is recommenced, in which case actual welding amperage will be displayed, or (3) a period of 10 seconds elapses following the completion of welding in which case the Power Source will return to preview mode.
NOTE
The preview functionality provided on this power source is intended to act as a guide only. Some differences may be observed between preview values and actual welding values due to factors including the mode of welding, differences in consumables/gas mixtures, individual welding techniques and the transfer mode of the welding arc (ie dip versus spray transfer). Where exact settings are required (in the case of procedural work), it is recommended that alternate measurement methods be utilized to ensure output values are accurate.
3. Wirespeed/Amperage Control
In MIG mode, the Wirespeed/Amperage control knob adjusts the speed of the wire feed motor (which in turn adjusts the output current by varying the amount of MIG wire delivered to the welding arc). The optimum wire speed depends upon the material type and the welding application. The setup chart on the inside of the wire feed compartment door provides a brief summary of the required settings for a basic range of MIG (GMAW/FCAW) welding applications.
In STICK and LIFT TIG modes, the Wirespeed/ Amperage control knob adjusts the amount of amperage (weld current) delivered to the welding arc by the Power Source. It directly adjusts the Power Source to deliver the desired level of weld current.
4. MIG Gun Adaptor (Tweco Style)
The MIG Gun adaptor is the connection point for the Tweco Fusion MIG Gun. Connect the MIG Gun by pushing the MIG Gun connector into the brass MIG Gun Adaptor firmly and screw the locking screw in the MIG Gun Adapter within the Wire Feed Compartment to secure the Tweco Fusion MIG Gun in position. Failure to properly lock the MIG Gun into the MIG Gun Adapter will result in the MIG Gun being pushed out of the MIG Gun Adapter by the MIG welding wire or lack of shielding gas (porosity in the weld) at the weld zone.
5. Positive Welding Output Terminal
The positive welding terminal is used to connect the welding output of the Power Source to the appropriate welding accessory such as the MIG Gun (via the MIG Gun polarity lead), electrode holder lead or work lead. Positive welding current flows from the Power Source via this heavy duty bayonet type terminal. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
CAUTION
Loose welding terminal connections can cause overheating and result in the male plug being fused in the bayonet terminal.
INSTALLATION, OPERATION AND SETUP 3-8 Manual 0-5191
Fabricator 181i
6. MIG Gun Polarity Lead
The polarity lead is used to connect the MIG Gun to the appropriate positive or negative output terminal (allowing polarity reversal for different welding applications). In general, the polarity lead should be connected in to the positive welding terminal (+) when using steel, stainless steel or aluminum electrode wire. When using flux cored (gasless) wire, the polarity lead is generally connected to the negative welding terminal (-). If in doubt, consult the manufacturer of the electrode wire for the correct polarity. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
CAUTION
Loose welding terminal connections can cause overheating and result in the male plug being fused in the bayonet terminal.
7. Negative Welding Output Terminal
The negative welding terminal is used to connect the welding output of the Power Source to the appropriate welding accessory such as the MIG Gun (via the MIG Gun polarity lead), TIG Torch or work lead. Negative welding current flows to the Power Source via this heavy duty bayonet type terminal. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
CAUTION
Loose welding terminal connections can cause overheating and result in the male plug being fused in the bayonet terminal.
8. Remote Control and Spool Gun Socket
The 8 pin socket is used to connect the Tweco Fusion MIG Gun, remote control device or spool gun plug to the welding Power Source. To make connections, align keyway, insert plug, and rotate threaded collar fully clockwise.
2
1
5
4
8
7
Art # A-10421_AC
1
2
3
3
6
4
5 6 7 8
Remote Wirespeed in MIG (GMAW/FCAW) mode
Remote Amps in LIFT TIG (GTAW) mode
Trigger Switch
WV
Remote Volts in MIG (GMAW/FCAW)
Negative Spool Gun Motor Positive
Figure 3-7: Remote Control Socket
Socket Pin
1 Spool gun motor (0V) 2
3 4
Trigger Switch Input Trigger Switch Input Spool gun motor (+24V DC)
Function
5 6
5k ohm (maximum) connection to 5k ohm remote control potentiometer. Zero ohm (minimum) connection to 5k ohm remote control potentiometer. Wiper arm connection to 5k ohm potentiometer for the remote control of the Wirespeed in MIG mode.
7
Wiper arm connection to 5k ohm potentiometer for the remote control of the Amperage (Weld Current) in LIFT TIG mode.
8
Wiper arm connection to 5k ohm remote control Volts MIG mode potentiometer.
Table 3-3
Manual 0-5191 3-9 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
Note that the Local/ Remote Switch (Control No. 18) located in the wirefeed compartment should be set to Remote for remote amperage/voltage controls to operate.
9. Multifunction Control - Voltage, Down Slope & Arc Force
The multifunction control knob is used to adjust Voltage (MIG Mode), Down slope (LIFT TIG Mode) and Arc Force (STICK Mode) depending on the welding mode selected.
NOTE
The preview functionality provided on this power source is intended to act as a guide only. Some differences may be observed between preview values and actual welding values due to factors including the mode of welding, differences in consumables/gas mixtures, individual welding techniques and the transfer mode of the welding arc (ie dip versus spray transfer). Where exact settings are required (in the case of procedural work), it is recommended that alternate measurement methods be utilized to ensure output values are accurate.
When MIG Mode is Selected
In this mode the control knob is used to adjust the MIG welding voltage of the Power Source. The welding voltage is increased by turning the knob clockwise or decreased by turning the knob counterclockwise. The optimum voltage level required will depend on the type of welding application. The setup chart on the inside of the wire feed compartment door provides a brief summary of the required output settings for a basic range of MIG welding applications.
When STICK Mode is Selected
In this mode the multifunction control knob is used to adjust arc force. Arc force control provides an adjustable amount of welding force (or “dig”) control. This feature can be particularly beneficial in providing the operator the ability to compensate for variability in joint fit-up in certain situations with particular electrodes. In general increasing the arc force control toward ‘10’ (maximum arc force) allows greater penetration control to be achieved. Arc force is increased by turning the control knob clockwise or decreased by turning the knob counterclockwise.
When LIFT TIG Mode is Selected
In this mode the multifunction control knob is used to adjust down slope. Down slope allows the user to select the ramp down time of the amperage at the completion of the weld. The main function of down slope is to allow the welding current to be gradually reduced over a pre-set time frame such that the welding pool is given time to cool sufficiently.
Note that when in 2T normal mode (Control No. 11), the Power Source will enter down slope mode as soon as the trigger switch is released (ie if the multifunction control knob is set to 5, the Power Source will ramp down from the present welding current to zero over 5 seconds). If no down slope time is set then the welding output will cease immediately. If the Power Source is set to 4T latch mode, to enter down slope mode the trigger must be held in for the selected time period (ie press and release trigger to commence welding, then press and hold trigger again to enter down slope mode). Should the trigger be released during the down slope phase (4T only), the output will cease immediately.
10. Arc Control (Inductance)
The arc control operates in MIG mode only and is used to adjust the intensity of the welding arc. Lower arc control settings make the arc softer with less weld spatter. Higher arc control settings give a stronger driving arc which can increase weld penetration. Soft means maximum inductance while Hard means minimum inductance.
11. Trigger Mode Control (MIG and LIFT TIG Mode only)
The trigger mode control is used to switch the functionality of the of the MIG or TIG Trigger Switch between 2T (normal) and 4T (latch mode)
INSTALLATION, OPERATION AND SETUP 3-10 Manual 0-5191
Fabricator 181i
2T (Normal Mode)
In this mode, the MIG or TIG Trigger Switch must remain depressed for the welding output to be active. Press and hold the MIG or TIG Trigger Switch to activate the Power Source (weld). Release the MIG or TIG Trigger Switch to cease welding.
4T (Latch Mode)
This mode of welding is mainly used for long welding runs to reduce operator fatigue. In this mode the operator can press and release the MIG or TIG Trigger Switch and the output will remain active. To deactivate the Power Source, the trigger switch must again be depressed and released, thus eliminating the need for the operator to hold the MIG or TIG Trigger Switch
Note that when operating in LIFT TIG mode, the Power Source will remain activated until the selected Downslope time has elapsed (refer Control No. 9).
12. Process Selection Control
The process selection control is used to select the desired welding mode. Three modes are available, MIG, LIFT TIG and STICK modes. Refer to section 3.15 or 3.16 for MIG (GMAW/FCAW) set up details, section 3.17 for LIFT TIG (GTAW) set-up details or section 3.18 for STICK (SMAW) set-up details.
Note that when the Power Source is powered OFF the mode selection control will automatically default to MIG mode. This is necessary so as to prevent inadvertent arcing should an electrode holder be connected to the Power Source and mistakenly be in contact with the work piece during power up.
13. Digital Voltage Meter (Right Digital Display)
The digital voltage meter is used to display the both the preview voltage (MIG mode only) and actual output voltage (all modes) of the Power Source.
At times of non-welding, the voltage meter will display a preview value in MIG mode. This value can be adjusted by varying the multifunction control knob (Control No. 9). Note that in STICK and LIFT TIG modes, the voltage meter will not preview welding voltage but will display Open Circuit Voltage in STICK mode and 0V in LIFT TIG mode. When welding, the voltage meter will display actual welding voltage in all modes.
At the completion of welding, the digital voltage meter will hold the last recorded voltage value for a period of approximately 10 seconds in all modes. The voltage meter will hold the value until; (1) any of the front panel controls are adjusted in which case the Power Source will revert to preview mode, (2) welding is recommenced, in which case actual welding amperage will be displayed, or (3) a period of 10 seconds elapses following the completion of welding in which case the Power Source will return to preview mode.
NOTE
The preview functionality provided on this power source is intended to act as a guide only. Some differences may be observed between preview values and actual welding values due to factors including the mode of welding, differences in consumables/gas mixtures, individual welding techniques and the transfer mode of the welding arc (ie dip versus spray transfer). Where exact settings are required (in the case of procedural work), it is recommended that alternate measurement methods be utilized to ensure output values are accurate.
14. Thermal Overload Indicator
This welding Power Source is protected by a self resetting thermostat. The indicator will illuminate if the duty cycle of the Power Source has been exceeded. Should the thermal overload indicator illuminate the output of the Power Source will be disabled. Once the Power Source cools down this light will go OFF and the over temperature condition will automatically reset. Note that the power switch should remain in the on position such that the fan continues to operate thus allowing the Power Source to cool sufficiently. Do not switch the Power Source OFF should a thermal overload condition be present.
Manual 0-5191 3-11 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
!
15. Gas Inlet (MIG mode only for MIG Gun or Spool Gun operation)
The Gas Inlet connection is used to supply the appropriate MIG welding gas to the Power Source. Refer to section 3.15 or 3.16 for MIG (FCAW/GMAW) set up details.
WARNING
Only Welding Shielding Gases specifically designed for arc welding applications should be used.
16. ON / OFF Switch
This switch is used to turn the Power Source ON/OFF.
WARNING
When the front digital displays are lit, the machine is connected to the Mains supply voltage and the internal electrical components are at Mains voltage potential.
17. Intelligent Fan Control
The Fabricator 181i is designed with an intelligent fan control. It automatically switches the cooling fan OFF when it is not required. This has two main advantages; (1) to minimize power consumption, and (2) to minimize the amount of contaminants such as dust that are drawn into the Power Source.
Note that the fan will only operate when required for cooling purposes and will automatically switch OFF when not required.
Note in STICK mode the fan operates continuously.
18. Local / Remote Switch (located in wirefeed compartment)
The local/ remote switch is used only when a remote control device (such as a TIG Torch with remote current control) is fitted to the Power Source via the remote control socket (Control No. 8). When the local/ remote switch is in the remote position, the Power Source will detect a remote device and work accordingly. When in the local mode, the Power Source will not detect the remote device and will operate from the Power Source controls only. Note that the trigger will operate at all times on the remote control socket irrespective of the position of the local/ remote switch (ie in both local and remote modes).
Should a remote device be connected and the local/ remote switch set to remote, the maximum setting of the Power Source will be determined by the respective front panel control, irrespective of the remote control device setting. As an example, if the output current on the Power Source front panel is set to 50% and the remote control device is set to 100%, the maximum achievable output from the Power Source will be 50%. Should 100% output be required, the respective front panel control must be set to 100%, in which case the remote device will then be able to control between 0-100% output.
19. Burnback Control (located in wirefeed compartment)
The Burnback control is used to adjust the amount of MIG wire that protrudes from the MIG Gun after the completion of MIG welding (commonly referred to as stick-out). To decrease the Burnback time (or lengthen the amount of wire protruding from the MIG Gun at the completing of welding), turn the Burnback control knob counterclockwise . To increase the Burnback time (or shorten the amount of wire protruding from the MIG Gun at the completing of welding), turn the Burnback Control knob clockwise.
INSTALLATION, OPERATION AND SETUP 3-12 Manual 0-5191
Fabricator 181i
Art #
A-10356_AB
MIG Gun Adaptor
MIG Gun Connector
MIG Gun Connector
Thumb Screw
8 pin socket
8 pin plug
20. MIG Gun & Spool Gun Switch
The MIG Gun / Spool Gun switch is used to switch welding mode between MIG Gun functionality and Spool Gun functionality
21. 10A Fuse
The 10A fuse is used to protect the spool gun motor.

3.11 Attaching the Tweco Fusion 180A Gun

Fit the Tweco Fusion MIG Gun to the Power Source by pushing the MIG Gun connector into the MIG Gun Adaptor and tightening the Locking Screw to secure the MIG Gun in the MIG Gun Adapter.
Connect the 8 pin plug by aligning the keyway then inserting the 8 pin plug into the 8 pin socket and rotate threaded collar fully clockwise to lock the plug into position.
Figure 3-8: Attaching MIG Gun
Manual 0-5191 3-13 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
Art # A-11482_AB

3.12 Torch Adapter Thumb Screw Replacement

1. Place unit on its back.
2. Remove 2 screws in bottom of the front panel. A securing block will become detached and fall free from the front panel as you turn each screw out. Set these aside for reassembly. Leave screws sitting in the pockets of the panel.
Screws
Art # A-11483
Securing Block
3. Open the wire compartment door and release the tension knob so the pressure arm and tension knob hang downwardly.
Tension Knob
Pressure Arm
Art # A-11484
INSTALLATION, OPERATION AND SETUP 3-14 Manual 0-5191
Fabricator 181i
4. Gently push the bottom of the front panel upward until the thumb screw is fully exposed.
Thumb Screw Fully Exposed
Art # A-11485_AB
5. Remove damaged thumb screw and replace with new one.
Art # A-11486
Push Upward
6. To reassemble, reverse steps 1 through 4.
Manual 0-5191 3-15 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
Art #
A-10357
Friction Washer
4”100mm Diameter spool
Nut with Nylon Insert
Spring
Plastic Spacer
Brass Flat Washer
Flat Washer

3.13 Installing 4" (100mm) Diameter Spool

As delivered from the factory, the Power Source is fitted with a Wire Spool Hub which accepts a 8" (200mm) diameter spools. In order to fit a 4" (100mm) diameter spool assemble parts in the sequence shown below in Figure 3-9.
Adjustment of the nut with nylon insert will control the MIG Wire Spool Brake. Clockwise rotation of this nut with nylon insert tightens the brake. The brake is correctly adjusted when the spool stops within 4" (100mm) to 8" (200mm) (measured at the outer edge of the spool) after MIG Gun trigger is released. Wire should be slack without becoming dislodged from the spool.
CAUTION
Overtension of brake will cause rapid wear of mechanical WIREFEED parts, overheating of electrical components and possibly an increased incidence of electrode wire Burnback into contact tip.
Figure 3-9: 4" (100mm)Diameter Spool Installation

3.14 Installing 8" (200mm) Diameter Spool

As delivered from the factory, the Power Source is set for a 8" (200mm) diameter spool. In order to re-fit a 8" (200mm) spool assemble parts in the sequence shown below in Figure 3-10. Adjustment of the nut with nylon insert will control the MIG Wire Spool Brake. Clockwise rotation of this nut with
nylon insert tightens the brake. The Brake is correctly adjusted when the spool stops within 3/8" (10mm) to 3/4" (20mm) (measured at the outer edge of the spool) after MIG Gun trigger is released. Wire should be slack without becoming dislodged from the spool.
CAUTION
Overtension of brake will cause rapid wear of mechanical WIREFEED parts, overheating of electrical components and possibly an increased incidence of electrode wire Burnback into contact tip.
Ensure that the alignment pin on the wire spool hub aligns with the hole allocated in 8" (200mm) diameter spool.
This alignment pin can be removed by unscrewing in an counterclockwise direction and locating in the appropriate position.
NOTE
INSTALLATION, OPERATION AND SETUP 3-16 Manual 0-5191
8” (200mm) diameter spool
Spool Hub Nut
Alignment pin
Alternate Alignment Pin Position
Wire Spool Hub
Friction Washer
Plastic Spacer
Spring
Flat Washer
Nut with Nylon Insert
Brass Flat Washer
Art #
A-10358
Figure 3-10: 8" (200mm) Diameter Spool Installation
Fabricator 181i

3.15 Inserting Wire into the Wire Feed Mechanism

Release the tension from the Pressure Roller Arm by turning the adjustable Wire Drive Tension Screw in an counterclockwise. Then to release the pressure roller arm push the tension screw toward the front of the machine which releases the pressure roller arm (Figure 3-11). With the MIG welding wire feeding from the bottom of the spool (Figure 3-12) pass the electrode wire through the inlet guide, between the rollers, through the outlet guide and into the MIG Gun.
Re-secure the pressure roller arm and wire drive tension screw and adjust the pressure accordingly (Figure 3-11). Remove the contact tip from the MIG Gun. With the MIG Gun lead reasonably straight, feed the wire through the MIG Gun by depressing the trigger switch. Fit the appropriate Velocity contact tip.
WARNING
Before connecting the work clamp to the work make sure the Electricity Supply is switched OFF. The electrode wire will be at welding voltage potential while it is being fed through the system. Keep MIG Gun away from eyes and face.
Manual 0-5191 3-17 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
MIG Welding Wire
Art #
A-10360
Art #
A-10359_AB
Wire Drive Tension Screw
Pressure Roller Arm
Outlet Guide
Inlet Guide
Figure 3-11: Wire Drive Assembly Components
Figure 3-12: MIG Welding Wire - Installation

3.16 Feed Roller Pressure Adjustment

The pressure (top) roller applies pressure to the grooved feed roller via an adjustable pressure screw. These devices should be adjusted to a minimum pressure that will provide satisfactory WIREFEED without slippage. If slipping occurs, and inspection of the wire contact tip reveals no wear, distortion or burn back jam, the conduit liner should be checked for kinks and clogging by metal flakes and swarf. If it is not the cause of slipping, the feed roll pressure can be increased by rotating the pressure screw clockwise.
Before changing the feed roller ensure that the Electricity Supply to the Power Source is switched OFF.
The use of excessive pressure may cause rapid wear of the feed rollers, shafts and bearing.
INSTALLATION, OPERATION AND SETUP 3-18 Manual 0-5191
WARNING
CAUTION
Fabricator 181i
GROOVE “B”GROOVE “A”
ZE
Art #

3.17 Changing the Feed Roll

To change feed roll remove the feed roll retaining screw by turning in an counterclockwise direction. Once the feed roll is removed then to replace feed roll simply reverse these directions.
A dual groove feed roller is supplied as standard. It can accommodate 023"(0.6mm) -.030" (0.8mm) diameter hard wires. Select the roller required with the chosen wire size marking facing outward.
GROOVE “B” SIZE
Figure 3-13: Dual Groove Feed Roller
Feed Roll
Retaining Screw
Feed Roll
Figure 3-14: Changing the Feed Roll
GROOVE “A” SI
A-09583
A-09584_AC

3.18 Wire Reel Brake

The wire reel hub incorporates a friction brake which is adjusted during manufacture for optimum breaking. If it is considered necessary, adjustment can be made by turning the large nut inside the open end of the hub clockwise to tighten the brake. Correct adjustment will result in the wire reel circumference continuing no further than 3/8" (10mm) - 3/4" (20mm) after release of the trigger. The electrode wire should be slack without becoming dislodged from wire spool.
Overtension of brake will cause rapid wear of mechanical WIREFEED parts, overheating of electrical components and possibly an increased incidence of electrode wire Burnback into contact tip.
Manual 0-5191 3-19 INSTALLATION, OPERATION AND SETUP
CAUTION
Fabricator 181i
Wire Reel Brake Adjustment Nut
Art #
A-10361
Figure 3-15: Wire Reel Brake

3.19 Gas Regulator Operation

With the regulator connected to cylinder or pipeline, and the adjustment screw/knob fully disengaged, pressurize as follows:
1. Stand to one side of regulator and slowly open the cylinder valve. If opened quickly, a sudden pressure surge may damage internal regulator parts.
2. With valves on downstream equipment closed, adjust regulator to approximate working pressure. It is recommended that testing for leaks at the regulator connection points be carried out using a suitable leak detection solution or soapy water.
3. Purge air or other unwanted welding grade shielding gas from equipment connected to the regulator by individually opening then closing the equipment control valves. Complete purging may take up to ten seconds or more, depending upon the length and size of the hose being purged.
Adjusting Flow Rate
With the regulator ready for operation, adjust working flow rate as follows:
1. Adjust the gas flow rate. The recommended rate for MIG welding is 28-46 CFH. The recommended rate for LIFT TIG welding is 10-28 CFH.
NOTE
It may be necessary to re-check the shielding gas regulator flow rate following the first weld sequence due to back pressure present within shielding gas hose assembly.
Shutdown
Close cylinder valve whenever the regulator is not in use. To shut down for extended periods (more than 30 minutes).
1. Close cylinder or upstream valve tightly.
2. Open downstream equipment valves to drain the lines. Bleed gas into a well ventilated area and away from any ignition source.
3. After gas is drained completely, disengage adjusting screw and close downstream equipment valves.
4. Before transporting cylinders that are not secured on a cart designed for such purposes, remove regulators.
INSTALLATION, OPERATION AND SETUP 3-20 Manual 0-5191
Fabricator 181i

3.20 Setup for MIG (GMAW) Welding with Gas Shielded MIG Wire

A. Select MIG mode with the process selection control. (Refer to Section 3.10 for further information) B. Connect the MIG Gun Polarity Lead to the positive welding terminal (+). If in doubt, consult the electrode
wire manufacturer. Welding current flows from the Power Source via heavy duty bayonet type terminals. It is
essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection. C. Fit the MIG Gun to the Power Source. (Refer to section 3.07 Attaching the Tweco Fusion 180A MIG Gun). D. Connect the work lead to the negative welding terminal (-). If in doubt, consult the electrode wire manufacturer.
Welding current flows from the Power Source via heavy duty bayonet type terminals. It is essential, however,
that the male plug is inserted and turned securely to achieve a sound electrical connection. E. Fit the gas regulator/flow gauge to the shielding gas cylinder (refer to Section 3.14) then connect the shielding
gas hose from the rear of the Power Source to the regulator/flow gauge outlet. F. Refer to the Weld Guide located on the inside of the wirefeed compartment door for further information.
G. Switch the LOCAL/REMOTE switch inside the wire feed
compartment to LOCAL to use the Power Sources Wirespeed and
Voltage controls.
H. Switch the MIG GUN/SPOOL GUN switch inside
the wire feed compartment to MIG GUN.
!
Before connecting the work clamp to the work make sure the Electricity Supply is switched OFF. Secure the welding grade shielding gas cylinder in an upright position by chaining it to a suitable
stationary support to prevent falling or tipping.
CAUTION
Loose welding terminal connections can cause overheating and result in the male plug being fused in the terminal.
Remove any packaging material prior to use. Do not block the air vents at the front or rear of the Welding Power Source.
WARNING
Manual 0-5191 3-21 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
Art #
A-10362
Shielding Gas Hose Fitted with 5/8"-18 UNF
connection
Primary Cord
Work Lead
Negative Welding Terminal (-)
Positive Welding Terminal (+)
MIG Gun Polarity Lead
MIG Gun
8 pin Plug
Secure the gas cylinder in an upright position by chaining it to a stationary support to prevent falling or tipping.
Figure 3-16: Setup for MIG Welding with Gas Shielded MIG Wire

3.21 Setup for MIG (FCAW) Welding with Flux Core (Gasless) Wire

A. Select MIG mode with the process selection control (refer to Section 3.10.12 for further information). B. Connect the MIG Gun Polarity Lead to the negative welding terminal (-). If in doubt, consult the electrode
wire manufacturer. Welding current flows from the Power Source via heavy duty bayonet type terminals. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
C. Connect the work lead to the positive welding terminal (+). If in doubt, consult the electrode wire manufacturer.
Welding current flows from the Power Source via heavy duty bayonet type terminals. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
D. Refer to the Weld Guide located on the inside of the wirefeed compartment door for further information.
E. Switch the LOCAL/REMOTE switch inside the
wire feed compartment to LOCAL to use the Power Sources Wirespeed and Voltage controls.
F. Switch the MIG GUN/SPOOL GUN switch inside
the wire feed compartment to MIG GUN.
WARNING
Before connecting the work clamp to the work make sure the Electricity Supply is switched OFF.
INSTALLATION, OPERATION AND SETUP 3-22 Manual 0-5191
Fabricator 181i
(+)
CAUTION
Loose welding terminal connections can cause overheating and result in the male plug being fused in the terminal.
Remove any packaging material prior to use. Do not block the air vents at the front or rear of the Welding Power Source.
Positive Welding Terminal
MIG Gun
Negative Welding Terminal (-)
8 pin Plug
MIG Gun Polarity Lead.
Work Lead
Figure 3-17: Setup for MIG (FCAW) Welding with Flux Cored (Gasless) Wire
A-09587_AD
Manual 0-5191 3-23 INSTALLATION, OPERATION AND SETUP
Fabricator 181i

3.22 Setup for SPOOL GUN MIG (GMAW) Welding with Gas Shielded MIG Wire

Set the Process Selection Control to MIG for Spool Gun welding. For setup and operation of the spool gun, please refer to the spool gun operations manual. Switch the MIG GUN/SPOOL GUN switch inside the wire feed compartment to SPOOL GUN. Connect the shielding gas for the to the Shielding Gas Inlet on the rear panel of the Power
Source.
1. Make sure the welding power source is turned OFF before connecting the welding gun.
2. Open side panel and loosen thumb screw.
Art #
A-10363
3. Insert the back end of the Spool gun into the gun receiving bushing.
4. Tighten thumb screw and replace side panel.
5. Connect gas supply fitting and tighten with a wrench.
6. Align Control Plug to panel fitting and tighten securely.
INSTALLATION, OPERATION AND SETUP 3-24 Manual 0-5191
Fabricator 181i

3.23 Setup for LIFT TIG (GTAW) Welding

A. Select LIFT TIG mode with the process selection control (refer to Section 3.10.12 for further information). B. Connect the TIG Torch to the negative welding terminal (-). Welding current flows from the Power Source via
heavy duty bayonet type terminals. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
C. Connect the work lead to the positive welding terminal (+). Welding current flows from the Power Source via
heavy duty bayonet type terminals. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
D. Connect the TIG torch trigger switch via the 8 pin socket located on the front of the Power Source as shown
below. The TIG torch will require a trigger switch to weld in LIFT TIG Mode.
NOTE
A Tweco 17V TIG torch with an 8 pin plug must be used to turn the weld current ON/OFF via the TIG torch trigger switch to TIG weld OR a Tweco Foot Control with an 8 pin plug must be used to turn the weld current ON/OFF as well as providing remote control of the weld current.
E. Fit the gas regulator/flow gauge to the shielding gas cylinder (refer to Section 3.14) then connect the shielding
gas hose from the TIG torch to the regulator/flow gauge outlet. Note that the TIG torch shielding gas hose is connected directly to the regulator/flow gauge. The Power Source is not fitted with a shielding gas solenoid to control the gas flow in LIFT TIG mode therefore the TIG torch will require a gas valve.
!
Before connecting the work clamp to the work and inserting the electrode in the TIG Torch make sure the Electricity Supply is switched OFF.
Secure the welding grade shielding gas cylinder in an upright position by chaining it to a stationary support to prevent falling or tipping.
WARNING
Manual 0-5191 3-25 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
Art #
A-10364
(+)
CAUTION
Remove any packaging material prior to use. Do not block the air vents at the front or rear of the Welding Power Source.
Loose welding terminal connections can cause overheating and result in the male plug being fused in the terminal.
F. Switch the LOCAL/REMOTE switch inside the wire feed compartment to LOCAL to use
the Power Sources Amperage control or REMOTE for remote amperage using a Foot Control.
Positive welding terminal
MIG Gun polarity lead not connected.
.
Work lead
Note: A Tweco 17V TIG torch with an 8 pin plug must be used to turn the weld current on/o via the TIG torch trigger switch to TIG weld OR a Tweco Foot Control with an 8 pin plug must be used to
TIG Torch
turn the weld current on/o as well as providing remote control of the weld current.
Figure 3-18: Setup for TIG Welding
Connect to shielding gas regulator/ow gauge. Secure the gas cylinder in an upright position by chaining it to a stationary support to prevent falling or tipping.
Negative welding terminal (-).
INSTALLATION, OPERATION AND SETUP 3-26 Manual 0-5191
Fabricator 181i
Art #
A-10365
Negative Welding Terminal (-)
Positive Welding Terminal
(+)
Work Lead
Electrode Holder
MIG Gun polarity lead not connected.

3.24 Setup for STICK (SMAW) Welding

A. Connect the Electrode Holder lead to the positive welding terminal (+). If in doubt, consult the electrode
manufacturer. Welding current flows from the Power Source via heavy duty bayonet type terminals. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
B. Connect the work lead to the negative welding terminal (-). If in doubt, consult the electrode manufacturer.
Welding current flows from the Power Source via heavy duty bayonet type terminals. It is essential, however, that the male plug is inserted and turned securely to achieve a sound electrical connection.
WARNING
Before connecting the work clamp to the work and inserting the electrode in the electrode holder make sure the Electricity Supply is switched OFF.
CAUTION
Remove any packaging material prior to use. Do not block the air vents at the front or rear of the Welding Power Source.
C. Switch the LOCAL/REMOTE switch inside the wire feed compartment to LOCAL to use
the Power Sources Amperage control or REMOTE for remote amperage control using a Hand Pendant Control.
Figure 3-19: Setup for Manual Arc Welding.
Manual 0-5191 3-27 INSTALLATION, OPERATION AND SETUP
Fabricator 181i
This Page Intentionally Blank
INSTALLATION, OPERATION AND SETUP 3-28 Manual 0-5191
Fabricator 181i
Shielding Gas
SECTION 4:
BASIC WELDING GUIDE

4.01 MIG (GMAW/FCAW) Basic Welding Technique

Two different welding processes are covered in this section (GMAW and FCAW), with the intention of providing the very basic concepts in using the MIG mode of welding, where a welding MIG Gun is hand held, and the electrode (welding wire) is fed into a weld puddle, and the arc is shielded by an inert welding grade shielding gas or inert welding grade shielding gas mixture.
GAS METAL ARC WELDING (GMAW): This process, also known as MIG welding, CO2 welding, Micro Wire Welding, short arc welding, dip transfer welding, wire welding etc., is an electric arc welding process which fuses together the parts to be welded by heating them with an arc between a solid continuous, consumable electrode and the work. Shielding is obtained from an externally supplied welding grade shielding gas or welding grade shielding gas mixture. The process is normally applied semi automatically; however the process may be operated automatically and can be machine operated. The process can be used to weld thin and fairly thick steels, and some non-ferrous metals in all positions.
Shielding Gas
Molten Weld Metal
Solidified Weld Metal
Nozzle
Electrode
Arc
Base Metal
GMAW Process
Art # A-8991_AB
Figure 4-1
FLUX CORED ARC WELDING (FCAW): This is an electric arc welding process which fuses together the parts to be welded by heating them with an arc between a continuous flux filled electrode wire and the work. Shielding is obtained through decomposition of the flux within the tubular wire. Additional shielding may or may not be obtained from an externally supplied gas or gas mixture. The process is normally applied semi automatically; however the process may be applied automatically or by machine. It is commonly used to weld large diameter electrodes in the flat and horizontal position and small electrode diameters in all positions. The process is used to a lesser degree for welding stainless steel and for overlay work.
Nozzle (Optional)
Flux Cored Electrode
Arc
Base Metal
Art # A-08992_AB
Slag
(Optional)
Molten Metal
Molten Slag
Solidified Weld Metal
FCAW Process
Figure 4-2
Manual 0-5191 4-1 BASIC WELDING GUIDE
Fabricator 181i
10° to 20° Longitudinal
Direction of Travel
Position of MIG Gun
The angle of MIG Gun to the weld has an effect on the width of the weld.
Push
Vertical
Drag/Pull
Art # A-07185_AB
Figure 4-3
The welding Gun should be held at an angle to the weld joint. (See Secondary Adjustment Variables below) Hold the MIG Gun so that the welding seam is viewed at all times. Always wear the welding helmet with proper
filter lenses and use the proper safety equipment.
CAUTION
Do not pull the welding MIG Gun back when the arc is established. This will create excessive wire extension (stick-out) and make a very poor weld.
The electrode wire is not energized until the MIG Gun trigger switch is depressed. The wire may therefore be placed on the seam or joint prior to lowering the helmet.
5° to 15°
Longitudinal
Angle
90°
Transverse
Angle
Direction of
Travel
10°
Longitudinal Angle
30° to 60°
Transverse
Angle
Angle
30° to 60° Transverse
Angle
Direction of Travel
Art # A-08993
Butt & Horizontal Welds
Figure 4-4
5° to 15°
Longitudinal Angle
30° to 60°
Transverse Angle
Direction of
Travel
Art # A-08994
Horizontal Fillet Weld
Figure 4-5
BASIC WELDING GUIDE 4-2 Manual 0-5191
Transverse Angle
Vertical Fillet Welds
Figure 4-6
30° to 60°
Overhead Weld
Figure 4-7
Art # A-08995
5° to 15° Longitudinal Angle
Art # A-08996
Fabricator 181i
Distance from the MIG Gun Nozzle to the Work Piece
The electrode wire stick-out from the MIG Gun nozzle should be between 3/8" (10mm) to 3/4" (20.0mm). This distance may vary depending on the type of joint that is being welded.
Travel Speed
The speed at which the molten pool travels influences the width of the weld and penetration of the welding run.
MIG Welding Variables
Most of the welding done by all processes is on carbon steel. The items below describe the welding variables in short-arc welding of 24 ga. (0.6mm) to ¼” (6.4mm) mild sheet or plate. The applied techniques and end results in the MIG process are controlled by these variables.
Preselected Variables
Preselected variables depend upon the type of material being welded, the thickness of the material, the welding position, the deposition rate and the mechanical properties. These variables are:
Type of electrode wire
Size of electrode wire
Type of gas (not applicable to self shielding wires FCAW)
Gas flow rate (not applicable to self shielding wires FCAW)
Primary Adjustable Variables
These control the process after preselected variables have been found. They control the penetration, bead width, bead height, arc stability, deposition rate and weld soundness. They are:
Arc Voltage
Welding current (wire feed speed)
Travel speed
Secondary Adjustable Variables
These variables cause changes in primary adjustable variables which in turn cause the desired change in the bead formation. They are:
1. Stick-out (distance between the end of the contact tube (tip) and the end of the electrode wire). Maintain at about 3/8" (10mm) stick-out
2. Wire Feed Speed. Increase in wire feed speed increases weld current, Decrease in wire feed speed decreases weld current.
Gas Nozzle
Tip to
Work Distance
Average Arc Length
Electrode Stick-Out
Contact Tip (Tube) Electrode Wire
Actual Stick-out
Art # A-08997_AD
Figure 4-8
3. Nozzle Angle. This refers to the position of the welding MIG Gun in relation to the joint. The transverse angle is usually one half the included angle between plates forming the joint. The longitudinal angle is the angle between the centre line of the welding MIG Gun and a line perpendicular to the axis of the weld. The longitudinal angle is generally called the Nozzle Angle and can be either trailing (pulling) or leading (pushing). Whether the operator is left handed or right handed has to be considered to realize the effects of each angle in relation to the direction of travel.
Manual 0-5191 4-3 BASIC WELDING GUIDE
Fabricator 181i
Transverse
Longitudinal Angle
Angle
Direction of Gun Travel
Axis of Weld
Transverse and Longitudinal Nozzle Axes
Figure 4-9
Art # A-08998_AB
Leading or “Pushing”
Angle
(Forward Pointing)
Nozzle Angle, Right Handed Operator
90°
Figure 4-10
Trailing or “Pulling”
Angle
(Backward Pointing)
Art # A-08999_AC
Establishing the Arc and Making Weld Beads
Before attempting to weld on a finished piece of work, it is recommended that practice welds be made on a sample metal of the same material as that of the finished piece.
The easiest welding procedure for the beginner to experiment with MIG welding is the flat position. The equipment is capable of flat, vertical and overhead positions.
For practicing MIG welding, secure some pieces of 16 ga. (1.6mm) or 1/8" (3.2mm) mild steel plate 6” (150mm) x 6” (150mm). Use 0.035” (0.9mm) gas shielded steel or gasless flux cored wire.
Setting of the Power Source
Power source and Wirefeeder setting requires some practice by the operator, as the welding plant has two control settings that have to balance. These are the Wirespeed control (refer to section 3.06.3) and the welding Voltage Control (refer to section 3.06.9). The welding current is determined by the Wirespeed control, the current will increase with increased Wirespeed, resulting in a shorter arc. Less wire speed will reduce the current and lengthen the arc. Increasing the welding voltage hardly alters the current level, but lengthens the arc. By decreasing the voltage, a shorter arc is obtained with a little change in current level.
When changing to a different electrode wire diameter, different control settings are required. A thinner electrode wire needs more Wirespeed to achieve the same current level.
A satisfactory weld cannot be obtained if the Wirespeed and Voltage settings are not adjusted to suit the electrode wire diameter and the dimensions of the work piece.
If the Wirespeed is too high for the welding voltage, “stubbing” will occur as the wire dips into the molten pool and does not melt. Welding in these conditions normally produces a poor weld due to lack of fusion. If, however, the welding voltage is too high, large drops will form on the end of the wire, causing spatter. The correct setting of voltage and Wirespeed can be seen in the shape of the weld deposit and heard by a smooth regular arc sound. Refer to the Weld Guide located on the inside of the wirefeed compartment door for setup information.
Electrode Wire Size Selection
The choice of Electrode wire size and shielding gas used depends on the following
• Thicknessofthemetaltobewelded
• Typeofjoint
• CapacityofthewirefeedunitandPowerSource
• Theamountofpenetrationrequired
• Thedepositionraterequired
• Thebeadproledesired
• Thepositionofwelding
• Costofthewire
BASIC WELDING GUIDE 4-4 Manual 0-5191
Tweco MIG, Lift TIG, Stick Wire Selection Chart
Art # A-10366_AB
Fabricator 181i
Table 4-1: MIG, Lift TIG, Stick Welding Set up Chart
Manual 0-5191 4-5 BASIC WELDING GUIDE
Fabricator 181i
!

4.02 MIG (GMAW/FCAW) Welding Troubleshooting

Solving Problems Beyond the Welding Terminals
The general approach to fix Gas Metal Arc Welding (GMAW) problems is to start at the wire spool then work through to the MIG Gun. There are two main areas where problems occur with MIG, Porosity and Inconsistent wire feed
Solving Problems Beyond the Welding Terminals - Porosity
When there is a gas problem the result is usually porosity within the weld metal. Porosity always stems from some contaminant within the molten weld pool which is in the process of escaping during solidification of the molten metal. Contaminants range from no gas around the welding arc to dirt on the work piece surface. Porosity can be reduced by checking the following points.
FAULT CAUSE
1 Limited or no shielding gas flows
out of the MIG Gun nozzle.
2 Shielding gas cylinder contents
and flow gauge.
3 Gas leaks. Check for gas leaks between the regulator/cylinder connection and
4 Internal gas hose in the Power
Source.
5 Welding in a windy environment. Shield the weld area from the wind or increase the gas flow. 6 Welding dirty, oily, painted,
oxidized or greasy plate.
7 Distance between the MIG Gun
nozzle and the work piece.
8 Maintain the MIG Gun in good
working order.
Check that the MIG Gun connection is fully engaged into the MIG Gun Adapter. The o-rings in the MIG Gun connection must seal the shielding gas within the MIG Gun Adapter so the shielding gas flows into the MIG Gun and out thru the MIG Gun nozzle.
Ensure that the shielding gas cylinder is not empty and the flow meter is correctly adjusted to workshop welding: 28-35 CFH or outdoors welding: 35-46 CFH.
in the gas hose to the Power Source. Ensure the hose from the solenoid valve to the MIG Gun adaptor
has not fractured and that it is connected to the MIG Gun adaptor.
Clean contaminates off the work piece.
Keep the distance between the MIG Gun nozzle and the work piece to a minimum. Refer to section 2.03
A Ensure that the gas holes are not blocked and gas is exiting out of
the MIG Gun nozzle.
B Do not restrict gas flow by allowing spatter to build up inside the
MIG Gun nozzle.
C Check that the MIG Gun O-rings are not damaged.
Table 4-2: Solving Problems beyond the Welding Terminals-Porosity
WARNING
Disengage the feed roll when testing for gas flow by ear.
BASIC WELDING GUIDE 4-6 Manual 0-5191
Solving Problems Beyond the Welding Terminals - Inconsistent Wire Feed
Wire feeding problems can be reduced by checking the following points.
FAULT CAUSE
Fabricator 181i
1 Feed roller driven by motor in the
cabinet slipped.
2 Wire spool unwinds and tangles. Wire spool brake is too loose. 3 Worn or incorrect feed roller size A Use a feed roller matched to the size you are welding.
4 Wire rubbed against the misaligned
guides and reduced wire feed-ability.
5 Liner blocked with swarf A Increased amounts of swarf are produced by the wire
6 Incorrect or worn contact tip A The Velocity contact tip transfers the weld current
Wire spool brake is too tight.
B Replace feed roller if worn.
Misalignment of inlet/outlet guides.
passing through the feed roller when excessive pres­sure is applied to the pressure roller adjuster.
B Swarf can also be produced by the wire passing
through an incorrect feed roller groove shape or size.
C Swarf is fed into the conduit liner where it accumu-
lates thus reducing wire feed-ability.
to the electrode wire. If the hole in the contact tip is too large then arcing may occur inside the contact tip resulting in the wire jamming in the contact tip
B When using soft wire such as aluminum it may be-
come jammed in the contact tip due to expansion of the wire when heated. A Velocity contact tip designed for soft wires should be used.
7 Poor work lead contact to work piece If the work lead has a poor electrical contact to the
work piece then the connection point will heat up and result in a reduction of power at the arc.
8 Bent liner This will cause friction between the wire and the liner
thus reducing wire feed-ability.
Table 4-3: Wire Feeding Problems
Manual 0-5191 4-7 BASIC WELDING GUIDE
Fabricator 181i
Basic MIG Welding Troubleshooting
FAULT CAUSE REMEDY
1 Undercut A Welding arc voltage too high. A Decrease voltage or increase the wire feed
speed.
B Incorrect MIG Gun angle B Adjust angle. C Excessive heat input C Increase the MIG Gun travel speed and/or
decrease welding current by decreasing the voltage or decreasing the wire feed speed.
2 Lack of penetration A Welding current too low A Increase welding current by increasing wire
feed speed and increasing voltage.
B Joint preparation too narrow or
gap too tight
C Shielding gas incorrect C Change to a gas which gives higher penetration.
3 Lack of fusion Voltage too low Increase voltage. 4 Excessive spatter A Voltage too high A Decrease voltage or increase the wirespeed
B Voltage too low B Increase the voltage or decrease wirespeed.
5 Irregular weld shape A Incorrect voltage and current
settings. Convex, voltage too
low. Concave, voltage too high. B Wire is wandering. B Replace Velocity contact tip. C Incorrect shielding gas C Check shielding gas.
D Insufficient or excessive heat
input
6 Weld cracking A Weld beads too small A Decrease travel speed
B Weld penetration narrow and
deep C Excessive weld stresses C Increase weld metal strength or revise design
B Increase joint angle or gap.
control.
A Adjust voltage and current by adjusting the
voltage control and the wirespeed control.
D Adjust the wirespeed control or the voltage
control.
B Reduce current and voltage and increase MIG Gun
travel speed or select a lower penetration shielding gas.
D Excessive voltage D Decrease voltage.
E Cooling rate too fast E Slow the cooling rate by preheating part to be
welded or cool slowly.
7 Cold weld puddle A Loose welding cable connection. A Check all welding cable connections.
B Low primary voltage B Contact supply authority. C Fault in power source C Have an Accredited Tweco Service Provider to
test then replace the faulty component.
8 Arc does not have a crisp
sound that short arc ex­hibits when the wirefeed speed and voltage are adjusted correctly.
9 Poor weld result from
setup chart parameters
BASIC WELDING GUIDE 4-8 Manual 0-5191
The MIG Gun has been con-
nected to the wrong voltage
polarity on the front panel.
Contact tip has arc marks in the
bore causing excessive drag on
the wire
Table 4-4: MIG Welding Problems
Connect the MIG Gun to the positive (+) welding terminal for solid wires and gas shielded flux cored wires. Refer to the electrode wire manufacturer for the correct polarity.
Replace the contact tip with only a Genuine Tweco Velocity contact tip.
Fabricator 181i

4.03 Stick (SMAW) Basic Welding Technique

Size of Electrode
The electrode size is determined by the thickness of metals being joined and can also be governed by the type of welding machine available. Small welding machines will only provide sufficient current (amperage) to run the smaller size electrodes.
For thin sections, it is necessary to use smaller electrodes otherwise the arc may burn holes through the job. A little practice will soon establish the most suitable electrode for a given application.
Storage of Electrodes
Always store electrodes in a dry place and in their original containers.
Electrode Polarity
Electrodes are generally connected to the ELECTRODE HOLDER with the Electrode Holder connected positive polarity. The WORK LEAD is connected negative polarity and is connected to the work piece. If in doubt consult the electrode data sheet or your nearest Accredited Tweco Distributor.

4.04 Effects of Stick Welding Various Materials

High Tensile and Alloy Steels
The two most prominent effects of welding these steels are the formation of a hardened zone in the weld area, and, if suitable precautions are not taken, the occurrence in this zone of under-bead cracks. Hardened zone and under­bead cracks in the weld area may be reduced by using the correct electrodes, preheating, using higher current settings, using larger electrodes sizes, short runs for larger electrode deposits or tempering in a furnace.
Manganese Steels
The effect on manganese steel of slow cooling from high temperatures is to embrittle it. For this reason it is absolutely essential to keep manganese steel cool during welding by quenching after each weld or skip welding to distribute the heat.
Cast Iron
Most types of cast iron, except white iron, are weldable. White iron, because of its extreme brittleness, generally cracks when attempts are made to weld it. Trouble may also be experienced when welding white-heart
malleable, due to the porosity caused by gas held in this type of iron.
Copper and Alloys
The most important factor is the high rate of heat conductivity of copper, making pre-heating of heavy sections necessary to give proper fusion of weld and base metal.
Types of Electrodes
Arc Welding electrodes are classified into a number of groups depending on their applications. There are a great number of electrodes used for specialized industrial purposes which are not of particular interest for everyday general work. These include some low hydrogen types for high tensile steel, cellulose types for welding large diameter pipes, etc The range of electrodes dealt with in this publication will cover the vast majority of applications likely to be encountered; are all easy to use.
Arc Welding Practice
The techniques used for arc welding are almost identical regardless of what types of metals are being joined. Naturally enough, different types of electrodes would be used for different metals as described in the preceding section.
Manual 0-5191 4-9 BASIC WELDING GUIDE
Fabricator 181i
Art # A-07688
Art # A-07689
Art # A-07690
Welding Position
The electrodes dealt with in this publication can be used in most positions, i.e. they are suitable for welding in flat, horizontal, vertical and overhead positions. Numerous applications call for welds to be made in positions intermediate between these. Some of the common types of welds are shown in Figures 4-15 through 4-22.
Art # A-07687
Figure 4-11: Flat Position, Down Hand Butt Weld
Art A-07691
Figure 4-15: Vertical Position, Butt Weld
Figure 4-12: Flat Position, Gravity Fillet Weld
Figure 4-13: Horizontal Position, Butt Weld
Figure 4-14: Horizontal-Vertical (HV) Position
Art # A-07692
Figure 4-16: Vertical Position, Fillet Weld
Art# A-07693
Figure 4-17: Overhead Position, Butt Weld
Art # A-07694
Figure 4-18: Overhead Position, Fillet Weld
BASIC WELDING GUIDE 4-10 Manual 0-5191
Fabricator 181i
Open Square Butt
Single Vee Butt Joint
Not less than
Joint Preparations
In many cases, it will be possible to weld steel sections without any special preparation. For heavier sections and for repair work on castings, etc., it will be necessary to cut or grind an angle between the pieces being joined to ensure proper penetration of the weld metal and to produce sound joints.
In general, surfaces being welded should be clean and free of rust, scale, dirt, grease, etc. Slag should be removed from oxy-cut surfaces. Typical joint designs are shown in Figure 4-19.
Joint
Gap varies from 1/16" (1.6mm) to 3/16" (4.8mm) depending on plate thickness
Single Vee Butt Joint
Lap Joint
Fillet Joint
Corner Weld
Not less than
45°
(Fillet both sides of the
1.6mm (1/16”)
Double Vee Butt Joint
1/16" (1.6mm)
Tee Joints
joint)
Edge Joint
70°
Not less than
70°
1/16" (1.6mm) max
1/16" (1.6mm) max
Plug Weld Plug Weld
Art # A-10367
Figure 4-19: Typical Joint Designs for Arc Welding
Arc Welding Technique - A Word to Beginners
For those who have not yet done any welding, the simplest way to commence is to run beads on a piece of scrap plate. Use mild steel plate about 1/4" (6.4mm) thick and a 1/8"(3.2mm) electrode. Clean any paint, loose scale or grease off the plate and set it firmly on the work bench so that welding can be carried out in the downhand position. Make sure that the work clamp is making good electrical contact with the work, either directly or through the work table. For light gauge material, always clamp the work lead directly to the job, otherwise a poor circuit will probably result.
Manual 0-5191 4-11 BASIC WELDING GUIDE
Fabricator 181i
The Welder
Place yourself in a comfortable position before beginning to weld. Get a seat of suitable height and do as much work as possible sitting down. Don't hold your body tense. A taut attitude of mind and a tensed body will soon make you feel tired. Relax and you will find that the job becomes much easier. You can add much to your peace of mind by wearing a leather apron and gauntlets. You won't be worrying then about being burnt or sparks setting alight to your clothes.
Place the work so that the direction of welding is across, rather than to or from, your body. The electrode holder lead should be clear of any obstruction so that you can move your arm freely along as the electrode burns down. If the lead is slung over your shoulder, it allows greater freedom of movement and takes a lot of weight off your hand. Be sure the insulation on your cable and electrode holder is not faulty, otherwise you are risking an electric shock.
Striking the Arc
Practice this on a piece of scrap plate before going on to more exacting work. You may at first experience difficulty due to the tip of the electrode "sticking" to the work piece. This is caused by making too heavy a contact with the work and failing to withdraw the electrode quickly enough. A low amperage will accentuate it. This freezing-on of the tip may be overcome by scratching the electrode along the plate surface in the same way as a match is struck. As soon as the arc is established, maintain a 1/16"(1.6mm) to 1/8"(3.2mm) gap between the burning electrode end and the parent metal. Draw the electrode slowly along as it melts down.
Another difficulty you may meet is the tendency, after the arc is struck, to withdraw the electrode so far that the arc is broken again. A little practice will soon remedy both of these faults.
Art # A-10368
1/16" (1.6mm)
Figure 4-20: Striking an Arc
Arc Length
The securing of an arc length necessary to produce a neat weld soon becomes almost automatic. You will find that a long arc produces more heat. A very long arc produces a crackling or spluttering noise and the weld metal comes across in large, irregular blobs. The weld bead is flattened and spatter increases. A short arc is essential if a high quality weld is to be obtained although if it is too short there is the danger of it being blanketed by slag and the electrode tip being solidified in. If this should happen, give the electrode a quick twist back over the weld to detach it. Contact or "touch-weld" electrodes such as E7014 Stick electrodes do not stick in this way, and make welding much easier.
Rate of Travel
After the arc is struck, your next concern is to maintain it, and this requires moving the electrode tip towards the molten pool at the same rate as it is melting away. At the same time, the electrode has to move along the plate to form a bead. The electrode is directed at the weld pool at about 20º from the vertical. The rate of travel has to be adjusted so that a well-formed bead is produced.
If the travel is too fast, the bead will be narrow and strung out and may even be broken up into individual globules. If the travel is too slow, the weld metal piles up and the bead will be too large.
BASIC WELDING GUIDE 4-12 Manual 0-5191
Fabricator 181i
20°-30°
Making Welded Joints
Having attained some skill in the handling of an electrode, you will be ready to go on to make up welded joints.
A. Butt Welds
Set up two plates with their edges parallel, as shown in Figure 4-21, allowing 1/16"(1.6mm) to 3/32"(2.4mm) gap between them and tack weld at both ends. This is to prevent contraction stresses from the cooling weld metal pulling the plates out of alignment. Plates thicker than 1/4" (6.4mm) should have their mating edges beveled to form a 70º to 90º included angle. This allows full penetration of the weld metal to the root. Using a 1/8"(3.2mm) E7014 Stick electrode at 100 amps, deposit a run of weld metal on the bottom of the joint.
Do not weave the electrode, but maintain a steady rate of travel along the joint sufficient to produce a well­formed bead. At first you may notice a tendency for undercut to form, but keeping the arc length short, the angle of the electrode at about 20º from vertical, and the rate of travel not too fast, will help eliminate this. The electrode needs to be moved along fast enough to prevent the slag pool from getting ahead of the arc. To complete the joint in thin plate, turn the job over, clean the slag out of the back and deposit a similar weld.
Electrode
Tack Weld
Figure 4-21: Butt Weld
Tack Weld
Art # A-07698
Art # A-07697_AB
Figure 4-22: Weld Build up Sequence
Heavy plate will require several runs to complete the joint. After completing the first run, chip the slag out and clean the weld with a wire brush. It is important to do this to prevent slag being trapped by the second run. Subsequent runs are then deposited using either a weave technique or single beads laid down in the sequence shown in Figure 4-22. The width of weave should not be more than three times the core wire diameter of the electrode. When the joint is completely filled, the back is either machined, ground or gouged out to remove slag which may be trapped in the root, and to prepare a suitable joint for depositing the backing run. If a backing bar is used, it is not usually necessary to remove this, since it serves a similar purpose to the backing run in securing proper fusion at the root of the weld.
B. Fillet Welds
These are welds of approximately triangular cross-section made by depositing metal in the corner of two faces meeting at right angles. Refer to Figure 4-14.
A piece of angle iron is a suitable specimen with which to begin, or two lengths of strip steel may be tacked together at right angles. Using a 1/8"(3.2mm) E7014 Stick electrode at 100 amps, position angle iron with one leg horizontal and the other vertical. This is known as a horizontal-vertical (HV) fillet. Strike the arc and immediately bring the electrode to a position perpendicular to the line of the fillet and about 45º from the vertical. Some electrodes require to be sloped about 20º away from the perpendicular position to prevent slag from running ahead of the weld. Refer to Figure 4-23. Do not attempt to build up much larger than 1/4"(6.4mm)width with a 1/8"(3.2mm) electrode, otherwise the weld metal tends to sag towards the base, and undercut forms on the vertical leg. Multi-runs can be made as shown in Figure 4-24. Weaving in HV fillet welds is undesirable.
Manual 0-5191 4-13 BASIC WELDING GUIDE
Fabricator 181i
45° from vertical
60° - 70° from line of weld
Art # A-07699_AB
6
3
1
5
2
4
Figure 4-24: Multi-runs in HV Fillet Weld
Art # A-07700_AB
Figure 4-23: Electrode Position for HV Fillet Weld
C. Vertical Welds
1. Vertical Up
Tack weld a three feet length of angle iron to your work bench in an upright position. Use a 1/8"(3.2mm)
E7014 Stick electrode and set the current at 100 amps. Make yourself comfortable on a seat in front of the job and strike the arc in the corner of the fillet. The electrode needs to be about 10º from the horizontal to enable a good bead to be deposited. Refer Figure 4-25. Use a short arc, and do not attempt to weave on the first run. When the first run has been completed de-slag the weld deposit and begin the second run at the bottom. This time a slight weaving motion is necessary to cover the first run and obtain good fusion at the edges. At the completion of each side motion, pause for a moment to allow weld metal to build up at the edges, otherwise undercut will form and too much metal will accumulate in the centre of the weld. Figure 4-26 illustrates multi-run technique and Figure 4-27 shows the effects of pausing at the edge of weave and of weaving too rapidly.
Art # A-07701
Figure 4-25: Single Run Vertical Fillet Weld
Art # A-07702
Art # A-07703
Figure 4-27: Examples of Vertical Fillet Welds
Figure 4-26: Multi Run Vertical Fillet Weld
BASIC WELDING GUIDE 4-14 Manual 0-5191
Fabricator 181i
2. Vertical Down
The E7014 Stick electrode makes welding in this position particularly easy. Use a 1/8"(3.2mm) electrode
at 100 amps. The tip of the electrode is held in light contact with the work and the speed of downward travel is regulated so that the tip of the electrode just keeps ahead of the slag. The electrode should point upwards at an angle of about 45º.
3. Overhead Welds
Apart from the rather awkward position necessary, overhead welding is not much more difficult that
downhand welding. Set up a specimen for overhead welding by first tacking a length of angle iron at right angles to another piece of angle iron or a length of waste pipe. Then tack this to the work bench or hold in a vice so that the specimen is positioned in the overhead position as shown in the sketch. The electrode is held at 45º to the horizontal and tilted 10º in the line of travel (Figure 4-28). The tip of the electrode may be touched lightly on the metal, which helps to give a steady run. A weave technique is not advisable for overhead fillet welds. Use a 1/8"(3.2mm) E6013 Stick electrode at 100 amps, and deposit the first run by simply drawing the electrode along at a steady rate. You will notice that the weld deposit is rather convex, due to the effect of gravity before the metal freezes.
Art # A-07704
Figure 4-28: Overhead Fillet Weld
Distortion
Distortion in some degree is present in all forms of welding. In many cases it is so small that it is barely perceptible, but in other cases allowance has to be made before welding commences for the distortion that will subsequently occur. The study of distortion is so complex that only a brief outline can be attempted hear.
The Cause of Distortion
Distortion is caused by:
A. Contraction of Weld Metal:
Molten steel shrinks approximately 11 per cent in volume on cooling to room temperature. This means that a cube of molten metal would contract approximately 2.2 per cent in each of its three dimensions. In a welded joint, the metal becomes attached to the side of the joint and cannot contract freely. Therefore, cooling causes the weld metal to flow plastically, that is, the weld itself has to stretch if it is to overcome the effect of shrinking volume and still be attached to the edge of the joint. If the restraint is very great, as, for example, in a heavy section of plate, the weld metal may crack. Even in cases where the weld metal does not crack, there will still remain stresses "Locked-up" in the structure. If the joint material is relatively weak, for example, a butt joint in 5/64" (2.0mm) sheet, the contracting weld metal may cause the sheet to become distorted.
Manual 0-5191 4-15 BASIC WELDING GUIDE
Fabricator 181i
Upsetting
Weld
B. Expansion and Contraction of Parent Metal in the Fusion Zone:
While welding is proceeding, a relatively small volume of the adjacent plate material is heated to a very high temperature and attempts to expand in all directions. It is able to do this freely at right angles to the surface of the plate (i.e., "through the weld", but when it attempts to expand "across the weld" or "along the weld", it meets considerable resistance, and to fulfill the desire for continued expansion, it has to deform plastically, that is, the metal adjacent to the weld is at a high temperature and hence rather soft, and, by expanding, pushes against the cooler, harder metal further away, and tends to bulge (or is "upset". When the weld area begins to cool, the "upset" metal attempts to contract as much as it expanded, but, because it has been "upset" it does not resume its former shape, and the contraction of the new shape exerts a strong pull on adjacent metal. Several things can then happen.
The metal in the weld area is stretched (plastic deformation), the job may be pulled out of shape by the powerful contraction stresses (distortion), or the weld may crack, in any case, there will remain "locked-up" stresses in the job. Figures 4-29 and 4- 30 illustrate how distortion is created.
Art # A-07705_AB
Weld
Art # A-07706_AC
Permanent Upset
Expansion with compression
Hot
Hot
Cool
Figure 4-29: Parent Metal Expansion
Figure 4-30: Parent Metal Contraction
Contraction with tension
Overcoming Distortion Effects
There are several methods of minimizing distortion effects.
A. Peening
This is done by hammering the weld while it is still hot. The weld metal is flattened slightly and because of this the tensile stresses are reduced a little. The effect of peening is relatively shallow, and is not advisable on the last layer.
B. Distribution of Stresses
Distortion may be reduced by selecting a welding sequence which will distribute the stresses suitably so that they tend to cancel each other out. See Figures 4-30 through 4-33 for various weld sequences. Choice of a suitable weld sequence is probably the most effective method of overcoming distortion, although an unsuitable sequence may exaggerate it. Simultaneous welding of both sides of a joint by two welders is often successful in eliminating distortion.
C. Restraint of Parts
Forcible restraint of the components being welded is often used to prevent distortion. Jigs, positions, and tack welds are methods employed with this in view.
D. Presetting
It is possible in some cases to tell from past experience or to find by trial and error (or less frequently, to calculate) how much distortion will take place in a given welded structure. By correct pre-setting of the components to be welded, constructional stresses can be made to pull the parts into correct alignment. A simple example is shown in Figure 4-31.
E. Preheating
Suitable preheating of parts of the structure other than the area to be welded can be sometimes used to reduce distortion. Figure 4-32 shows a simple application. By removing the heating source from b and c as soon as welding is completed, the sections b and c will contract at a similar rate, thus reducing distortion.
BASIC WELDING GUIDE 4-16 Manual 0-5191
Fabricator 181i
Art # A-07707
Figure 4-31: Principle of Presetting
Art # A-07708
B
Dotted lines show effect if no preheat is used
Weld
C
PreheatPreheat
Figure 4-32: Reduction of Distortion by Preheating
Art # A-07709
Art # A-07710_AB
4
Art # A-07711_AB
Figure 4-35: Step back Sequence
1
2
Block Sequence. The spaces between the welds are filled in when the welds are cool.
3
Figure 4-34: Welding Sequence
1
2
3
Figure 4-33: Examples of Distortion
Art # A-07428_AB
Figure 4-36: Chain Intermittent Welding
Art # A-07713_AB
Figure 4-37: Staggered Intermittent Welding
Manual 0-5191 4-17 BASIC WELDING GUIDE
Fabricator 181i
Insufficient Gap
Incorrect Sequence
Art # A-05866_AC

4.05 Stick (SMAW) Welding Troubleshooting

FAULT CAUSE REMEDY
1 Welding current
varying
2 A gap is left by
failure of the weld metal to fill the root of the weld.
3 Non-metallic par-
ticles are trapped in the weld metal.
ARC FORCE control knob is set at a value that causes the welding current to vary ex­cessively with the arc length.
Reduce the ARC FORCE control knob until welding current is reasonably constant while prohibiting the electrode from sticking to the work piece when you “dig” the electrode into the workpiece.
A Welding current too low A Increase welding current.
B Electrode too large for joint. B Use smaller diameter electrode.
C Insufficient gap. C Allow wider gap.
A Non-metallic particles may
be trapped in undercut from
A If a bad undercut is present clean slag bout and
cover with a run from a smaller gauge electrode.
previous run.
B Joint preparation too re-
stricted.
C Irregular deposits allow slag
B Allow for adequate penetration and room for clean-
ing out the slag.
C If very bad, chip or grind out irregularities.
to be trapped.
D Lack of penetration with slag
trapped beneath weld bead.
D Use smaller electrode with sufficient current to give
adequate penetration. Use suitable tools to remove all slag from comers.
E Rust or mill scale is prevent-
E Clean joint before welding.
ing full fusion.
F Wrong electrode for position
in which welding is done.
F Use electrodes designed for position in which
welding is done, otherwise proper control of slag is difficult.
Figure 1 - Example of insufficient gap or incorrect sequence
4 A groove has been
A Welding current is too high. A Reduce welding current. formed in the base metal adjacent to
B Welding arc is too long. B Reduce the length of the welding arc. the toe of a weld and has not been filled by the weld metal (undercut).
C Angle of the electrode is
incorrect.
D Joint preparation does not
allow correct electrode angle.
C Electrode should not be inclined less than 45° to
the vertical face.
D Allow more room in joint for manipulation of the
electrode.
E Electrode too large for joint. E Use smaller gauge electrode.
F Insufficient deposit time at
edge of weave.
G Power Source is set for MIG
F Pause for a moment at edge of weave to allow weld
metal buildup.
G Set Power Source to STICK (SMAW) mode.
(GMAW) welding.
BASIC WELDING GUIDE 4-18 Manual 0-5191
FAULT CAUSE REMEDY
Lack of fusion caused by dirt,
Fabricator 181i
5 Portions of the
weld run do not fuse to the surface of the metal or edge of the joint.
6 Gas pockets or
voids in weld metal (porosity)
A Small electrodes used on
A Use larger electrodes and preheat the plate.
heavy cold plate. B Welding current is too low. B Increase welding current. C Wrong electrode angle. C Adjust angle so the welding arc is directed more
into the base metal.
D Travel speed of electrode is
D Reduce travel speed of electrode.
too high. E Scale or dirt on joint surface. E Clean surface before welding.
electrode angle incorrect, rate of travel too high
Art # A-05867_AC
Lack of side fusion, scale dirt, small electrode, amperage too low
Lack of inter-run fusion
Lack of root fusion
Figure 2: Example of Lack of Fusion
A High levels of sulfur in steel. A Use an electrode that is designed for high sulfur
steels. B Electrodes are damp. B Dry electrodes before use. C Welding current is too high. C Reduce welding current.
7 Crack occurring in
weld metal soon after solidification commences
D Surface impurities such as
D Clean joint before welding.
oil, grease, paint, etc.
E Welding in a windy environ-
E Shield the weld area from the wind.
ment.
F Electrode damaged ie flux
coating incomplete.
F Discard damaged electrodes and only use elec-
trodes with a complete flux coating. A Rigidity of joint. A Redesign to relieve weld joint of severe stresses or
use crack resistance electrodes. B Insufficient throat thickness. B Travel slightly slower to allow greater build up in
throat. C Weld current is too high. C Decrease welding current.
Slag trapped in
Not cleaned, or incorrect electrode
undercut
Art # A-05868_AC
Slag trapped in root
Figure 3: Example of Slag Inclusion
8 The Stick elec-
Manual 0-5191 4-19 BASIC WELDING GUIDE
trode is difficult to run with multiple arc-outs when welding
The Stick electrode being used is not suitable for use with this machine.
Table 4-6: Welding Problems - Stick (SMAW)
Use E6013 or E7018 Stick electrodes for steel or
300 series stainless steel Stick electrodes for 300
series stainless steel.
Fabricator 181i

4.06 TIG (GTAW) Basic Welding Technique

Gas Tungsten Arc Welding (GTAW) or TIG (Tungsten Inert Gas) as it is commonly referred to, is a welding process in which fusion is produced by an electric arc that is established between a single tungsten (non-consumable) electrode and the work piece. Shielding is obtained from a welding grade shielding gas or welding grade shielding gas mixture which is generally Argon based. A filler metal may also be added manually in some circumstances depending on the welding application.
Art # A-10369_AB
Gas Cup
Either Ceramic,
Work Piece
Can Be Any Commercial
Metal
Welds Made With or Without
Addition of Filler Metal
High Impact or
Water Cooled
Metal
Tungsten Electrode
Non-Consumable
Inert Gas
Shields Electrode
and Weld Puddle
Figure 4-38: TIG Welding Application Shot
Tungsten Electrode Current Ranges
Electrode Diameter DC Current (Amps)
0.040” (1.0mm) 30-60 1/16” (1.6mm) 60-115 3/32” (2.4mm) 100-165
1/8” (3.2mm) 135-200 5/32” (4.0mm) 190-280 3/16” (4.8mm) 250-340
Table 4-7: Current Ranges for Various Tungsten Electrode Sizes
Guide for Selecting Filler Wire Diameter
Filler Wire Diameter DC Current Range (Amps)
1/16” (1.6mm) 20-90 3/32” (2.4mm) 65-115
1/8” (3.2mm) 100-165 3/16” (4.8mm) 200-350
Table 4-8: Filler Wire Selection Guide
BASIC WELDING GUIDE 4-20 Manual 0-5191
Tungsten Electrode Types
Fabricator 181i
Electrode Type
(Ground Finish)
Thoriated 2%
Zirconated 1%
Ceriated 2%
Welding Application Features Color Code
DC welding of mild steel, stainless steel and copper
High quality AC weld­ing of aluminum, magnesium and their alloys.
AC & DC welding of mild steel, stainless steel, copper, alumi­num, magnesium and their alloys
Excellent arc starting, Long life, High current carrying capacity
Self cleaning, Long life, Maintains balled end, High current car­rying capacity.
Longer life, More stable arc, Easier starting, Wider current range, Narrower more concentrated arc.
Table 4-9
NOTE
The Fabricator 181i is not suited for AC TIG welding.
Red
White
Grey
Base Metal
Thickness
0.040”
1.0mm
0.045”
1.2mm 1/16”
1.6mm
1/8”
3.2mm 3/16”
4.8mm
1/4”
6.4mm
TIG Welding is generally regarded as a specialized process that requires operator competency. While many of the principles outlined in the previous Arc Welding section are applicable a comprehensive outline of the TIG Welding process is outside the scope of this Operating Manual. For further information please refer to www.thermalarc. com or contact Tweco.
DC Current
for Mild
Steel
35-45 40-50
45-55 50-60
60-70 70-90
80-100 90-115
115-135 140-165
160-175 170-200
DC Current
for Stainless
Steel
20-30 25-35
30-45 35-50
40-60 50-70
65-85
90-110
100-125 125-150
135-160 160-180
Tungsten Electrode Diameter
0.040”
1.0mm
0.040”
1.0mm 1/16”
1.6mm 1/16”
1.6mm 3/32”
2.4mm
1/8”
3.2mm
Table 4-10
Filler Rod
Diameter (if
required)
1/16”
1.6mm 1/16”
1.6mm 1/16”
1.6mm 3/32”
2.4mm
1/8”
3.2mm 5/32”
4.0mm
Argon Gas Flow Rate
CFH
10-15 Butt/Corner
10-15 Butt/Corner
15 Butt/Corner
15 Butt/Corner
20 Butt/Corner
20 Butt/Corner
Joint Type
Lap/Fillet
Lap/Fillet
Lap/Fillet
Lap/Fillet
Lap/Fillet
Lap/Fillet
Manual 0-5191 4-21 BASIC WELDING GUIDE
Fabricator 181i

4.07 TIG (GTAW) Welding Problems

FAULT CAUSE REMEDY
1 Excessive bead build up or
poor penetration or poor fusion at edges of weld.
2 Weld bead too wide and
flat or undercut at edges of weld or excessive burn through.
3 Weld bead too small or
insufficient penetration or ripples in bead are widely spaced apart.
4 Weld bead too wide or
excessive bead build up or excessive penetration in butt joint.
5 Uneven leg length in fillet
joint
6 Electrode melts or oxidizes
when an arc is struck.
Welding current is too low
Welding current is too high
Travel speed too fast Reduce travel speed.
Travel speed too slow Increase travel speed.
Wrong placement of filler rod
A TIG Torch lead
connected to positive welding terminal.
Increase weld current and/or faulty joint preparation.
Decrease weld current.
Re-position filler rod.
A Connect TIG Torch lead to negative welding
terminal.
B No gas flowing to weld-
ing region.
C TIG Torch is clogged
with dust or dirt.
D
Gas hose is cut. D Replace gas hose.
E Gas passage contains
impurities.
F Gas regulator turned
OFF.
G TIG Torch valve is
turned OFF.
H The electrode is too
small for the welding current.
I Power Source is set for
MIG welding.
B Turn TIG Torch gas valve ON. Check the gas
lines for kinks or breaks and gas cylinder contents.
C Clean TIG Torch.
E Disconnect gas hose from the rear of Power
Source then raise gas pressure and blow out impurities.
F Turn ON.
G Turn ON.
H Increase electrode diameter or reduce the
welding current.
I Set Power Source to LIFT TIG mode.
BASIC WELDING GUIDE 4-22 Manual 0-5191
FAULT CAUSE REMEDY
Fabricator 181i
7 Dirty weld pool A Electrode contaminated
by contact with work piece or filler rod mate­rial.
B Work piece surface has
foreign material on it.
C Gas contaminated with
air.
8 Poor weld finish Inadequate shielding
gas.
9 Arc start is not smooth. A Tungsten electrode is
too large for the weld­ing current.
B The wrong electrode
is being used for the welding job.
C Gas flow rate is too
high.
A Clean the electrode by grinding off the con-
taminates.
B Clean surface.
C Check gas lines for cuts and loose fitting or
change gas cylinder.
Increase gas flow or check gas line for gas flow problems.
A Select the right size electrode. Refer to Table
4-7 Current Ranges for Various Tungsten Electrode Size.
B Select the right electrode type. Refer to Table
4-9 Tungsten Electrode Types.
C Select the right rate for the welding job. Refer
to Table 4-10.
10 Arc flutters during TIG
welding.
11 Tungsten blackens due to
lack of shielding gas
D Incorrect shielding gas
is being used.
E Poor work clamp con-
nection to work piece.
Tungsten electrode is too large for the weld­ing current.
A Gas valve on the TIG
Torch has not been turned ON.
B Gas cylinder valve OFF
or TIG Torch hose not connected to regulator
Table 4-11: TIG (GTAW) Welding Problems
D Select the right shielding gas.
E Improve connection to work piece.
Select the right size electrode. Refer to Table 4-7 Current Ranges for Various Electrode Size.
A Turn ON TIG Torch gas valve before you
commence welding.
B Turn ON gas cylinder valve or connect TIG
Torch hose to regulator.
Manual 0-5191 4-23 BASIC WELDING GUIDE
Fabricator 181i
This Page Intentionally Blank
BASIC WELDING GUIDE 4-24 Manual 0-5191
SECTION 5: POWER SOURCE PROBLEMS AND
ROUTINE SERVICE REQUIREMENTS

5.01 Power Source Problems

FAULT CAUSE REMEDY
1 Electricity Supply is ON,
power indicator is illumi­nated however the Power Source will not commence welding when the torch trig­ger switch is depressed.
A Power Source is not in the cor-
B Faulty torch trigger. B Repair or replace torch trigger
rect mode of operation.
Fabricator 181i
A Set the Power Source to the correct
mode of operation with the process selection switch.
switch/lead.
2 Fault Indicator is illuminat-
ed and the Power Source will not commence weld­ing when the torch trigger switch is depressed.
3 The Power Source will not
feed wire in MIG mode.
4 Welding wire continues to
feed when torch trigger is released.
5 Welding arc cannot be
established in MIG mode.
Duty cycle of Power Source has been exceeded.
A Electrode wire stuck in conduit
liner or contact tip (burn-back jam).
B MIG GUN/SPOOL GUN switch
is switched to SPOOL GUN.
A Trigger mode selection switch
is in 4T latch mode.
B Torch trigger leads shorted. B Repair or replace torch trigger
A MIG Gun polarity lead is not
connected into a welding out­put terminal.
B Poor or no work lead contact. B Clean work clamp area and ensure
Leave the Power Source switched ON and allow it to cool. Note that fault indicator must be extinguished prior to commencement of welding.
A Check for clogged / kinked MIG Gun
conduit liner or worn contact tip. Replace faulty components.
B Switch the MIG GUN/SPOOL GUN
switch to MIG GUN.
A Change the trigger mode selection
switch from 4T latch mode to 2T normal mode.
switch/lead.
A Connect the MIG Gun polarity lead
to either the positive welding output terminal or the negative welding output terminal as required.
good electrical contact.
6 Inconsistent wire feed. A Worn or dirty contact tip. A Replace if necessary.
B Worn feed roll. B Replace. C Excessive brake tension on wire
reel hub.
D Worn, kinked or dirty conduit
liner
7 No gas flow in MIG mode. A Gas hose is damaged. A Replace or repair.
B Gas passage contains impuri-
ties.
C Gas regulator turned OFF. C Turn ON regulator. D Empty gas cylinder. D Replace gas cylinder.
Manual 0-5191 5-1 TROUBLE SHOOTING AND SERVICE
C Reduce brake tension on spool hub
D Clean or replace conduit liner
B Disconnect gas hose from the rear
of Power Source and blow out impurities.
Fabricator 181i
FAULT CAUSE REMEDY
8 Gas flow continues after
the torch trigger switch has been released (MIG mode).
Gas valve has jammed open due to impurities in the gas or the gas line.
Have an accredited Tweco service provider repair or replace gas valve.
9 Power indicator will not
illuminate and welding arc cannot be established.
10 TIG electrode melts when
arc is struck.
11 Arc flutters during TIG
welding.
The Electricity Supply voltage has exceeded voltage limits of the Power Source.
TIG Torch is connected to the (+) VE terminal.
Tungsten electrode is too large for the welding current.
Table 5-1
Ensure that the Electricity Supply voltage is within 208-265 VAC.
Connect the TIG Torch to the (-) VE terminal.
Select the correct size of tungsten electrode. Refer to Table 4-7.

5.02 Routine Service and Calibration Requirements

WARNING
There are extremely dangerous voltage and power levels present inside this Power Source. Do not at­tempt to open or repair unless you are an accredited Tweco Service Provider. Disconnect the Welding Power Source from the Electricity Supply Voltage before disassembling.
Routine Inspection, Testing & Maintenance
The inspection and testing of the Power Source and associated accessories shall be carried out in accordance with Section 5 of EN 60974-1: Safety in Welding and Allied Processes-Part 2 Electrical. This includes an insulation resistance test and an earthing test to ensure the integrity of the Power Source is compliant with Tweco's original specifications.
If equipment is to be used in a hazardous location or environments with a high risk of electrocution as outlined in EN 60974-1, then the above tests should be carried out prior to entering this location.
A. Testing Schedule
1. For transportable equipment, at least once every 3 months; and
2. For fixed equipment, at least once every 12 months.
The owners of the equipment shall keep a suitable record of the periodic tests and a system of tagging, includ­ing the date of the most recent inspection.
A transportable Power Source is deemed to be any equipment that is not permanently connected and fixed in the position in which it is operated.
NOTE
Please refer to local guidelines for further information.
B. Insulation Resistance
Minimum insulation resistance for in-service Tweco Power Sources shall be measured at a voltage of 500V between the parts referred to in Table 6-1below. Power Sources that do not meet the insulation resistance requirements set out below shall be withdrawn from service and not returned until repairs have been performed such that the requirements outlined below are met.
TROUBLE SHOOTING AND SERVICE
5-2 Manual 0-5191
Fabricator 181i
Components to be Tested
Input circuit (including any connected control circuits) to welding circuit (including any connected control circuits)
All circuits to exposed conductive parts Welding circuit (including any connected control circuits) to any auxiliary
circuit which operates at a voltage exceeding extra low voltage Welding circuit (including any connected control circuits) to any auxiliary
circuit which operates at a voltage not exceeding extra low voltage Separate welding circuit to separate welding circuit
Table 5-2: Minimum Insulation Resistance Requirements: Tweco Power Sources
C. Earthing
The resistance shall not exceed 1Ω between any metal of a Power Source where such metal is required to be earthed, and -
1. The earth terminal of a fixed Power Source; or
2. The earth terminal of the associated plug of a transportable Power Source
Note that due to the dangers of stray output currents damaging fixed wiring, the integrity of fixed wiring sup­plying Tweco welding Power Sources should be inspected by a licensed electrical worker in accordance with the requirements below -
Minimum Insulation
Resistance (MΩ)
5
2.5
10
1
1
1. For outlets/wiring and associated accessories supplying transportable equipment - at least once every 3 months; and
2. For outlets/wiring and associated accessories supplying fixed equipment - at least once every 12 months.
D. General Maintenance Checks
Welding equipment should be regularly checked by an accredited Tweco Service Provider to ensure that:
1. Flexible cord is of the multi-core tough rubber or plastic sheathed type of adequate rating, correctly connected and in good condition.
2. Welding terminals are in suitable condition and are shrouded to prevent inadvertent contact or short circuit.
3. The Welding System is clean internally, especially from metal filing, slag, and loose material.
E. Accessories
Accessory equipment, including output leads, electrode holders, torches, wire feeders and the like shall be inspected at least monthly by a competent person to ensure that the equipment is in a safe and serviceable condition. All unsafe accessories shall not be used.
F. Repairs
If any parts are damaged for any reason, it is recommended that replacement be performed by an accredited Tweco Service Provider.
Manual 0-5191 5-3 TROUBLE SHOOTING AND SERVICE
Fabricator 181i
Power Source Calibration
A. Schedule
Output testing of all Tweco Power Sources and applicable accessories shall be conducted at regular intervals to ensure they fall within specified levels. Calibration intervals shall be as outlined below -
1. For transportable equipment, at least once every 3 months; and
2. For fixed equipment, at least once every 12 months.
If equipment is to be used in a hazardous location or environments with a high risk of electrocution as outlined in EN 60974-1, then the above tests should be carried out prior to entering this location.
B. Calibration Requirements
Where applicable, the tests outlined in Table 6-3 below shall be conducted by an accredited Tweco service agent.
Testing Requirements
Output current (A) to be checked to ensure it falls within applicable Tweco Power Source specifications Output Voltage (V) to be checked to ensure it falls within applicable Tweco Power Source specifications Motor Speed (RPM) of wire drive motors to be checked to ensure it falls within required Tweco Power Source
/ wire feeder specifications Accuracy of digital meters to be checked to ensure it falls within applicable Tweco Power Source specifica-
tions
Table 5-3: Calibration Parameters
Periodic calibration of other parameters such as timing functions are not required unless a specific fault has been identified.
C. Calibration Equipment
All equipment used for Power Source calibration shall be in proper working condition and be suitable for conducting the measurement in question. Only test equipment with valid calibration certificates (NATA certi­fied laboratories) shall be utilized.
TROUBLE SHOOTING AND SERVICE
5-4 Manual 0-5191
Fabricator 181i

5.03 Cleaning the Welding Power Source

WARNING
There are dangerous voltage and power levels present inside this product. Do not attempt to open or repair unless you are a qualified electrical tradesperson. Disconnect the Welding Power Source from the Electricity Supply Voltage before disassembling.
To clean the Welding Power Source, open the enclosure and use a vacuum cleaner to remove any accumulated dirt, metal filings, slag and loose material. Keep the shunt and lead screw surfaces clean as accumulated foreign material may reduce the welders output welding current.

5.04 Cleaning the Feed Rolls

Clean the grooves in the drive rolls frequently. This can be done by using a small wire brush. Also wipe off, or clean the grooves on the upper feed roll. After cleaning, tighten the feed roll retaining knobs.
CAUTION
Do not use compressed air to clean the Welding Power Source. Compressed air can force metal particles to lodge between live electrical parts and earthed metal parts within the Welding Power Source. This may result in arcing between this parts and their eventual failure.
Manual 0-5191 5-5 TROUBLE SHOOTING AND SERVICE
Fabricator 181i

5.05 Volt-Ampere Curves

Voltage-Amperage Curves shows maximum voltage and amperage output capabilities of welding power source. Curves of other settings fall between curves shown.
TROUBLE SHOOTING AND SERVICE
Art # A-11296
Figure 5-1: Fabricator 181i Volt-Ampere Curves
5-6 Manual 0-5191

SECTION 6: KEY SPARE PARTS

6.01 Tweco Fusion 180A MIG Gun Parts

Fabricator 181i
Torch Part No: F180TA-12-3035
Art# A-11672_AB
Item
No.
1 Velocity Nozzle**
2 Velocity Contact Tip**
3 Handle / Trigger Repair Kit F80 4 Conduit Assembly* WS42-3035-15
5A Tweco Rear Connector 350-174H
5
5B Tweco Control Wire 35K-350-1 5C Tweco Control Wire & Plug WS-354-TA-LC
Description Part No.
VNS-50
VNS-50F
VNS-62
VNS-62F
VNS-37
VNS-37F
VNS-75FAS
VTS-23 VTS-30 VTS-35 VTS-40 VTS-45
VTS-364
VTSA-364
VTS-52
VTS-116
VTSA-116
VTS-564
Table 6-1: Tweco Fusion 180A MIG Gun Parts
Figure 6-1
** Patent Pending
* Refer to Tweco Catalog No. 64-2103 for additional options.
Manual 0-5191 6-1 KEY SPARE PARTS
Fabricator 181i

6.02 Power Source

A-11243_AC
Art #
Figure 6-2
31
KEY SPARE PARTS 6-2 Manual 0-5191
FABRICATOR 181i POWER SOURCE SPARE PARTS
ITEM PART NUMBER DESCRIPTION
1 W7004962 PCB,Power,181i 2 W7004963 PCB,Control,181i 3 W7003033 Solenoid,Valve,24VDC 4 W7004970 PCB,Display,181i 5 W7004969 PCB,Remote Interface,181i 6 W7004905 Wiredrive Assy,w/ Motor,181i 7 W7004906 Feedroll retaining thumb screw 8 7977036 Feed Roll .024(0.6mm)-.030"(0.8mm) V groove Installed
9 W7004947 Fan,24VDC,4.75"x4.75"x1",181i 10 W7003010 Rectifier Bridge,1000V,50A 11 W7003215 Connector,Gas Inlet,5/8"-18UNF 12 W7004909 Dinse,Socket,181i 13 W7004955 Connector,Dinse,181i 14 W7004942 Socket,8 Pin,w/ Harness 15 W7003053 Switch,On/Off,250V 16 W7004911 CT Sensor,Output,181i 17 W7004912 Wire Hub Assy,181i 18 W7005552 Panel, Front 19 W7005555 Panel, Rear 20 W7004922 Handle,181i 21 W7005554 Side and Top Panels (not shown) 22 W7004966 Adapter,Tweco 4,181i 23 W7004925 Guide,Inlet,.023-.045,181i 24 W7004967 Guide,Inlet,.023-.045,181i 25 W7005553 Panel,Door (not shown) 26 W7004928 Panel,Base,181i 27 870734 Knob,1/4" IDx.72" ODx.9" H 28 W7004972 Knob,1/4" IDx1" ODx0.9" H 29 W7004957 Panel,Front Control,181i 30 W7004953 Push Button Actuator 31 OTWAK/1S Screw,Locking,MIG Gun 32 W7004961 Thermistor,NTC,K45 47K,181i 33 W7004940 PCB Burnback Potentiometer 34 W7004968 PCB,Spool Gun,181i 35 W7004979 Fuse Holder,181i 36 W7004982 Fuse,10 Amp 37 9-0025 Power Cord,12AWG,NEMA 6-50P (not shown) 38 W7005550 Label,Setup Chart,181i,English (not shown) 39 W7005551 Label,Setup Chart,181i,French (not shown) 40 W7004960 Inductor,181i (not shown) 41 W7004951 Spool Hub,181i 42 W7004943 Switch,250V/2A,181i 43 W7004983 Shoulder strap, 181i (not shown)
Table 6-2
Fabricator 181i
Manual 0-5191 6-3 KEY SPARE PARTS
Fabricator 181i
This Page Intentionally Blank
KEY SPARE PARTS 6-4 Manual 0-5191
CONNECTOR LAYOUT DIAGRAM
DRIE
M

I N
I
M
OURCE
GUN
DY
OT
UN
CRNTC
ON

Art # A-11230_AC
1 SPOOL GUN (0V)
2 TORCH SWITCH (+24VDC)
3 TORCH SWITCH RIN (0VDC)
4 SPOOL GUN (+24VDC)
5
6 REMOTE CONTROL IN (+15VDC)
7 (REMOTE AMPS/WIRESPEED) POT WIPER
8 (REMOTE VOLTAGE) POT WIPER
FUSE
BLACK
RED
OT
1
RED
BLK
YEL
BURN BACK PCB 5
3 +24VDC1
1 +12VDC
2 RETURN
Current Sensor
1
Fabricator 181i

APPENDIX: FABRICATOR 181i CIRCUIT DIAGRAM

Manual 0-5191 A-1
APPENDIX
This Page Intentionally Blank
This Page Intentionally Blank

TWECO - LIMITED WARRANTY TERMS

LIMITED WARRANTY: Tweco ®, Inc, A Victor Technologies Company, warrants to customers of its authorized distributors hereafter “Purchaser” that its products will be free of defects in workmanship or material. Should any failure to conform to this warranty appear within the time period applicable to the Tweco products as stated below, Tweco shall, upon notification thereof and substantiation that the product has been stored, installed, oper­ated, and maintained in accordance with Tweco’s specifications, instructions, recommendations and recognized standard industry practice, and not subject to misuse, repair, neglect, alteration, or accident, correct such defects by suitable repair or replacement, at Tweco’s sole option, of any components or parts of the product determined by Tweco to be defective.
TWECO MAKES NO OTHER WARRANTY, EXPRESS OR IMPLIED. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHERS, INCLUDING, BUT NOT LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
LIMITATION OF LIABILITY: TWECO SHALL NOT UNDER ANY CIRCUMSTANCES BE LIABLE FOR SPECIAL, INDI­RECT OR CONSEQUENTIAL DAMAGES, SUCH AS, BUT NOT LIMITED TO, LOST PROFITS AND BUSINESS INTER­RUPTION. The remedies of the Purchaser set forth herein are exclusive and the liability of Tweco with respect to any contract, or anything done in connection therewith such as the performance or breach thereof, or from the manufacture, sale, delivery, resale, or use of any goods covered by or furnished by Tweco whether arising out of contract, negligence, strict tort, or under any warranty, or otherwise, shall not, except as expressly provided herein, exceed the price of the goods upon which such liability is based. No employee, agent, or representative of Tweco is authorized to change this warranty in any way or grant any other warranty.
PURCHASER’S RIGHTS UNDER THIS WARRANTY ARE VOID IF REPLACEMENT PARTS OR ACCESSORIES ARE USED WHICH IN TWECO’S SOLE JUDGMENT MAY IMPAIR THE SAFETY OR PERFORMANCE OF ANY TWECO PRODUCT. PURCHASER’S RIGHTS UNDER THIS WARRANTY ARE VOID IF THE PRODUCT IS SOLD TO PUR­CHASER BY NON-AUTHORIZED PERSONS.
The warranty is effective for the time stated below beginning on the date that the authorized distributor delivers the products to the Purchaser. Notwithstanding the foregoing, in no event shall the warranty period extend more than the time stated plus one year from the date Tweco delivered the product to the authorized distributor.
WARRANTY SCHEDULE
5 Years Parts* / 3 Years Labor
ArcMaster, Excelarc, Fabricator, Fabstar, PowerMaster
Portafeed, Ultrafeed, Ultima 150, WC 100B
* 5 years on the Original Main Power Transformer and Inductors not mounted on PCBoards.
* 3 years on Power Supply Components
2 Years Parts and Labor Unless specified
Auto-Darkening Welding Helmet (electronic Lens), ** 1 Month Harness Assy
Victor Regulator for Fabricator 181i (No labor)
1 Years Parts and Labor Unless specified
95S, Water recirculators
All Plasma Welding consols (i.e WC-1 Controller, WT Timer,
WF-100 Capstain Feeder, etc)
180 days parts and Labor Unless specified
Plasma Welding Torch and leads packages
Gas Regulators "Supplied with power sources" (No Labor)
90 days parts / No Labor
Remote Controls
MIG and TIG Torches (Supplied with power sources)
Replacement repair parts
30 days parts / No Labor
MIG Torch for Fabricator 181i
5-2-1 years Parts / No Labor
FirePower® Welders
5 Years Parts / No Labor
Victor® Professional
Victor Technologies limited warranty shall not apply to:
Consumable Parts for MIG, TIG, Plasma welding, Plasma cutting and Oxy fuel torches, O-rings, fuses, filters or other parts that fail due normal wear
* Warranty repairs or replacement claims under this limited warranty must be submitted by an authorized Victor Technologies repair facility within thirty (30) days of the repair.
* No employee, agent, or representative of Victor Technologies is authorized to change this warranty in any way or grant any other warranty, and Victor Technologies shall not be bound by any such attempt. Correction of non-conformities, in the manner and time provided herein, constitutes fulfillment of Victor Technologies’s obligations to purchaser with respect to the product.
* This warranty is void, and seller bears no liability hereunder, if purchaser used replacement parts or accessories which, in Victor Technologies's sole judgment, impaired the safety or performance of any Victor Technologies product. Purchaser’s rights under this warranty are void if the product is sold to purchaser by unauthorized persons.
THE AMERICAS
Denton, TX USA U.S. Customer Care
Ph 1-800-426-1888 (tollfree) Fax: 1-800-535-0557 (tollfree)
International Customer Care
Ph 1-940-381-1212 Fax: 1-940-483-8178
Miami, FL USA Sales Office, Latin America
Ph 1-954-727-8371 Fax: 1-954-727-8376
Oakville, Ontario, Canada Canada Customer Care
Ph 1-905-827-4515 Fax: 1-800-588-1714 (tollfree)
EUROPE
Chorley, United Kingdom Customer Care
Ph +44 1257-261755 Fax: +44 1257-224800
Milan, Italy Customer Care
Ph +39 0236546801 Fax: +39 0236546840
ASIA/PACIFIC
Cikarang, Indonesia Customer Care
Ph 6221-8990-6095 Fax: 6221-8990-6096
Rawang, Malaysia Customer Care
Ph +603 6092-2988 Fax: +603 6092-1085
Melbourne, Australia Australia Customer Care
Ph 1300-654-674 (tollfree) Ph 61-3-9474-7400 Fax: 61-3-9474-7391
International
Ph 61-3-9474-7508 Fax: 61-3-9474-7488
Shanghai, China Sales Office
Ph +86 21-64072626 Fax: +86 21-64483032
Singapore Sales Office
Ph +65 6832-8066 Fax: +65 6763-5812
INNOVATION TO SHAPE THE WORLD
U.S. Customer Care: 800-426-1888 / FAX 800-535-0557 Canada Customer Care: 905-827-4515 / FAX 800-588-1714 International Customer Care: 940-381-1212 / FAX 940-483-8178
© 2012 Victor Technologies International, Inc. www.victortechnologies.com Printed in China
Loading...
