TEG-MGBS20D3
SFP Dual Wavelength Single-Mode LC Module
TEG-MGBS20D3 (v1.0R)
• Must pair with TEG-MGBS20D5 or other compatible module
• LC Simplex (single strand) connector-type
• Bi-Directional (WDM) SFP Module
• Spans distances up to 20 km (12.4 miles)
• Tx: 1310 nm / Rx: 1550 nm, +3.3 v Power Supply
TRENDnet’s TEG-MGBS20D3 when paired with the TEG-MGBS20D5 creates a long distance, single strand fiber solution with a range of up to 20 km
(12.4 miles). Alternatively grow your pre-existing two-strand fiber connection, and turn it into two separate single-strand fiber connections. The SFP
interface is compatible with standard SFP slots and offers a 1000BASE-LX SFP interface.
TEG-MGBS20D3
Hot-Pluggable SFP
Hot-pluggable SFP transceiver compatible with a MSA
compliant SFP slot
Bi-Directional Fiber
Transmit: 1310 nm / Receive: 1550 nm, pair with
TEG-MGBS20D5 or compatible SFP module
Fiber Distance
Supports networking for distances up to 20 km (12.4
miles)
Fiber Port
LC-type simplex connector
Operating Temperature
Rated for an operating temperature range of
0 to 70 °C (32 to 158 °F)
Fiber Applications
Long distance fiber networking for industrial,
manufacturing, corporate and educational
campus applications.
Fiber Mode / Distance
Single Mode transceiver spans distances up to
20 km (12.4 miles) and supports up to 1.25
Gbps throughput speeds.
Compatibility
Compatabile with TRENDnet SFP switches,
adapters and many third-party SFP solutions
Specifications
Standards
• IEEE 802.3z
• ANSI Fiber Channel compliant
• Class 1 Laser
Device Interface
• SFP MSA Compliant
• Simplex LC connector
Data Transfer Rate
• 1.25 Gbps
Wavelength
• TX: 1310 nm
• RX: 1550 nm
Optical Output Power
• -3 ~ -9 dBm
Distance
• 20 km (12.4 miles)
Special Features
• Hot pluggable
• Bi-directional (WDM) SFP module
TEG-MGBS20D3
Sensitivity
• -23 dBm
Power Consumption
• 0.8 watts
Operating Temperature
• 0 – 70 °C (32 - 158 °F)
Operating Humidity
• Max. 85% non-condensing
Dimensions
• 57 x 13 x 12 mm (2.2 x 0.5 x 0.5 in)
Weight
• 18 g (0.6 oz.)
Certifications
• CE
• FCC
Warranty
• 3 year limited
Package Contents
• TEG-MGBS20D3
