Packaged Heat Pumps

Voyager™ 12½ to 20 Tons — 60 Hz

September 2004

PKGP-PRC001-EN

Introduction

Packaged Rooftop Air Conditioners

Through the years, Trane has designed and developed the most complete line of Packaged Rooftop products available in the market today. Trane was the first to introduce the Micro—microelectronic unit controls—and has continued to improve and revolutionalize this design concept.

The ReliaTel control platform offers the same great features and functionality as the original Micro, with additional benefits for greater application flexibility.

Voyager continues to provide the highest standards in quality and reliability, comfort, ease of service, and the performance of Trane light commercial products.

Trane customers demand products that provide exceptional reliability, meet stringent performance requirements, and are competitively priced. Trane delivers with Voyager.

Voyager features cutting edge technologies: reliable compressors, Trane engineered ReliaTel controls, computeraided run testing, and Integrated Comfort™ Systems. So, whether you’re the contractor, the engineer, or the owner you can be certain Voyager Products are built to meet your needs.

It’s Hard To Stop A Trane.

Contents

Introduction

Features and Benefits

Application Considerations

Selection Procedure

Model Number Description

General Data

Performance Data

Cooling Performance Fan Performance Heating Performance

Controls

Electric Power

Dimension and Weights

14 17

PKGP-PRC0 01-EN

Mechanical Specifications

Features and Benefits

Factory Installed Options

• Black Epoxy Pre-Coated Coils

• High Efficiency Motors

• High Pressure Cutout

• Hinged Access Doors

• Powered or Unpowered Convenience Outlet

• Supply and/or Return Air Smoke Detector

• Through the Base Electrical with Circuit Breaker

• Through the Base Electrical With Disconnect Switch

• Through the Base Utilities Access

• Two-Inch Pleated Filters

Factory or Field Installed Options

• Clogged Filter/Fan Failure Switch

• Differential Pressure Switches

• Discharge Air Sensing Kit

• Downflow – Economizer

• Electric Heaters

• Frostat

• LonTalk® Communications Interface

• Oversized Motors

• Reference or Comparative Enthalpy

• Tool-less Hail Guards

• Trane Communications Interface (TCI)

Field Installed Options

• CO

Sensing

• Digital Display Zone Sensor

• Dual Thermistor Remote Zone Sensor

• High Static Drive

• Manual Outside Air Damper

• Motorized Outside Air Dampers

• Powered Exhaust

• Downflow – Roof Curb

• Horizontal – Economizer

• Remote Potentiometer

• Ventilation Override Accessory

• Zone Sensors

PKGP-PRC0 01-EN

Features and Benefits

Easy to Install, Service and Maintain

Because today’s owners are very costconscious when it comes to service and maintenance, the Trane Voyager was designed with direct input from service contractors. This valuable information helped to design a product that would get the serviceman off the job quicker and save the owner money. Voyager does this by offering:

Quality and Reliability

ReliaTel™ Controls (LCI-R)

ReliaTel controls provide unit control for heating, cooling and ventilating utilizing input from sensors that measure outdoor and indoor temperature.

ReliaTel™

Quality and Reliability are enhanced through ReliaTel control and logic:

—prevents the unit from short cycling,

considerably improving compressor life.

—ensures that the compressor will run

for a specific amount of time which allows oil to return for better lubrication, enhancing the reliability of the compressor.

Voyager with ReliaTel reduces the number of components required to operate the unit, thereby reducing possibilities for component failure.

ReliaTel Makes Installing and Servicing Easy

ReliaTel eliminates the need for field installed anti-shortcycle timer and time delay relays. ReliaTel controls provide these functions as an integral part of the unit. The contractor no longer has to purchase these controls as options and pay to install them.

The wiring of the low voltage connections to the unit and the zone sensors is as easy as 1-1, 2-2, and 3-3. This simplified system makes wiring easier for the installer.

ReliaTel Makes Testing Easy

ReliaTel requires no special tools to run the Voyager unit through its paces. Simply place a jumper between Test 1 and Test 2 terminals on the Low Voltage Terminal Board and the unit will walk through its operational steps automatically. — The unit automatically returns control to the zone sensor after stepping through the test mode a single time, even if the jumper is left on the unit.

As long as the unit has power and the “system on” LED is lit, ReliaTel is operational. The light indicates that the controls are functioning properly.

ReliaTel features expanded diagnostic capabilities when utilized with Trane Integrated Comfort™ Systems.

Some zone sensor options have central control panel lights which indicate the mode the unit is in and possible diagnostic information (dirty filters for example).

Other ReliaTel Benefits

The ReliaTel built-in anti-shortcycle timer, time delay relay and minimum “on” time control functions are factory tested to assure proper operation.

ReliaTel softens electrical “spikes” by staging on fans, compressors and heaters.

Intelligent Fallback is a benefit to the building occupant. If a component goes astray, the unit will continue to operate at predetermined temperature setpoint.

Intelligent Anticipation is a standard ReliaTel feature. It functions continuously as ReliaTel and zone sensor(s) work together in harmony to provide much tighter comfort control than conventional electro-mechanical thermostats.

The same ReliaTel Board fits all Voyager Packaged Gas/Electrics, Cooling with Electric Heat, and Heat Pump models. This provides standardization of parts for contractors. Less money is tied up in inventory with ReliaTel.

PKGP-PRC0 01-EN

Features and Benefits

Outstanding Standard and Optional Components

Black Epoxy Pre-Coated Coils

The pre-coated coils are an economical option for protection in mildly corrosive environments.

Cabinet Integrity

For added water integrity, Voyager has a raised 1 return of the downflow units to prevent water from blowing into the ductwork.

Clogged Filter/Fan Failure Switch

A dedicated differential pressure switch is available to achieve active fan failure indication and/or clogged filter indication.

The CO2 sensor has the ability to monitor space occupancy levels within the building by measuring the parts per million of CO As the CO damper modulates to meet the CO space ventilation requirements. The CO sensor kit is available as a field installed accessory.

Colored And Numbered Wiring

Save time and money tracing wires and diagnosing the unit.

Compressors

Voyager contains the best compressor technology available to achieve the highest possible performance. Dual compressors are outstanding for humidity control, light load cooling conditions and system back-up applications. Dual compressors are available on all models.

/8" lip around the supply and

Sensing

(Carbon Dioxide) in the air.

levels increase, the outside air

Condenser Coil

Voyager boasts a patent-pending 1+1+1 condenser coil, permanently gapped for easy cleaning.

Digital Display Zone Sensor

The Digital LCD (Liquid Crystal Display) zone sensor has the look and functionality of standard zone sensors. This sensor should be utilized with ReliaTel™ controls.

Discharge Air Sensing Kit

Provides true discharge air sensing in heating models. The kit is functional only with the ReliaTel Options Module.

Downflow And Horizontal Economizers

The economizers come with three control options — dry bulb is standard, enthalpy and differential enthalpy are optional.

Dual Thermistor Remote Zone Sensor

This sensor will reduce the total number of remote sensors to obtain space temperature averaging. This sensor should be utilized with ReliaTel controls.

Factory Built Roof Curbs

Available for downflow units. Only two roof curbs for the entire Voyager line simplifies curb selection.

Fresh Air

0 - 25% manual or 0 - 50% motorized outside air hoods are available.

High Static Drive Accessory

Available on many models, this high static drive accessory extends the capability of the standard motor. Avoid expensive motors and operating costs by installing this optimized sheave accessory.

Hinged Access Doors

These doors permit easy access to the filter, fan/heat, and compressor/control sections. They reduce the potential roof damage from screws or sharp access door corners.

LonTalk® Communications Interface

The LonTalk communications interface allows the unit to communicate as a Tracer™LCI-V device or directly with generic LonTalk Network Building Automation System Controls.

Power Exhaust Option

This option is available on downflow units and provides exhaust of the return air, when using a downflow economizer, to maintain proper building pressurization. Great for relieving most building overpressurization problems.

Quick-Access Panels

Remove three or fewer screws for access to the standardized internal components and wiring.

Quick-Adjust Idler Arm

With the Quick-Adjust Idler Arm, the belt and sheaves can be quickly adjusted without moving the mounted fan motor. The result is a major savings in time and money.

PKGP-PRC0 01-EN

Features and Benefits

Reference or Comparative Enthalpy

Measures and communicates humidity while maximizing comfort control.

Sloped Drain Pans

Standard on every unit.

Standardized Components

Components are placed in the same location on all Voyager units. Familiarize yourself with one Voyager and you are familiar with every Voyager.

Due to standardized components throughout the Voyager line, contractors/ owners can stock fewer parts.

Supply and/or Return Air Smoke Detector

With this option installed, if smoke is

detected, all unit operation will be shut down. Reset will be manual at the unit. Return Air Smoke Detectors require minimum allowable airflow when used

with certain models.

Tool-less Hail Guards

Tool-less, hail protection quality coil

guards shall be either factory or field-installed for condenser coil protection. This option protects the condenser coil from vandalism and/or hail damage.

Va riTra c

When Trane’s changeover VAV System for light commercial applications is coupled with Voyager, it provides the latest in technological advances for comfort management systems and can allow thermostat control in every zone served by VariTrac.

Ventilation Override Accessory

With the Ventilation Override Accessory installed, the unit can be set to transition to up to 3 different pre-programmed sequences for Smoke Purge, Pressurization, and Exhaust. The transition occurs when a binary input on the RTOM is closed (shorted). This would typically be a hard wired relay output from a smoke detector or fire control panel. The ventilation override kit is available as a field installed accessory.

Zone Sensors

Available in programmable, automatic and manual styles.

Rigorous Testing

The fan and idler arm assembly designs have been tested to over 300,000 cycles each. Our combined cycle testing is now over 7,000,000 cycles.

All of Voyager’s designs were rigorously rain tested at the factory to ensure water integrity.

Actual shipping tests were performed to determine packaging requirements. Units were test shipped around the country to determine the best packaging. Factory shake and drop tests were used as part of the package design process to help assure that the unit arrives at the job site in top condition.

Rigging tests include lifting a unit into the air and letting it drop one foot, assuring that the lifting lugs and rails hold up under stress.

We perform a 100% coil leak test at the factory. The evaporator and condenser coils are leak tested at 200 psig and pressure tested to 450 psig.

All parts are inspected at the point of final assembly. Sub-standard parts are identified and rejected immediately.

Every unit receives a 100% unit run test before leaving the production line to make sure it lives up to rigorous Trane requirements.

Voyager units incorporate either a one piece top or the Trane-Tite-Top (T part of the top (either two or three pieces) overlaps in such a way that water cannot leak into the unit. These overlapped edges are gasketed and sealed to ensure superior water integrity.

). Each

Trane Communication Interface (TCI)

Available factory or field installed. This module when applied with the ReliaTel™ easily interfaces with Trane’s Integrated Comfort

System.

PKGP-PRC0 01-EN

VariTrac™

Features and Benefits

Easy to Install and Service

Conversionless Units

The dedicated design units (either downflow or horizontal) require no panel removal or alteration time to convert in the field — a major cost savings during installation.

Horizontal units come complete with duct flanges so the contractor doesn’t have to field fabricate them. These duct flanges are a time and cost saver.

Easy Access Low Voltage Terminal Board

Voyager’s Low Voltage Terminal Board is external to the electrical control cabinet. It is extremely easy to locate and attach the thermostat wire. This is another cost and time saving installation feature.

Low Voltage Connections

The wiring of the low voltage connections to the unit and the zone sensors is as simple as 1-1, 2-2, and 3-3. This simplified system makes it easy for the installer to wire.

Electric Heaters

Electric heat modules are available within the basic unit. If ordering the Through the Base Electrical option with an Electrical Heater, the heater must be factory installed.

Powered or Unpowered Convenience Outlet

This option is a GFCI, 120v/15amp, 2 plug, convenience outlet, either powered or unpowered. This option can only be ordered when the Through the Base Electrical with either the Disconnect Switch, or Circuit Breaker, option is ordered. This option is available on all downflow models.

Single Point Power

A single electrical connection powers the unit.

Single Side Service

Single side service is standard on all units.

Through the Base Electrical with Circuit Breaker

This option is a factory installed thermal magnetic, molded case, HACR Circuit Breaker with provisions for through the base electrical connections. This option is available on all downflow models.

Through the Base Electrical with Disconnect Switch

Factory installed 3-pole, molded case, disconnect switch with provisions for through the base electrical connections are available. This option is available on all downflow models.

Through the Base Utilities Access

An electrical service entrance shall be provided allowing electrical access for both control and main power connections inside the curb and through the base of the unit. Option will allow for field installation of liquid-tight conduit and an external field installed disconnect switch.

Factory Installed Options

A wide variety of Factory Installed Options (FIOPs) are available.

Added Efficiency

Airflow

Airflow is outstanding. The Voyager can replace an older machine with old ductwork and, in many cases, improve the comfort through better air distribution.

High Efficiency Motors

This option is available with efficiency ratings from 86.5 up to 91.0. It is not available for all models.

U-shaped Airflow

U-shaped airflow allows for improved static capabilities.

Low Ambient Cooling

Cooling capabilities down to 0°F as standard.

Oversized Motors

Factory or field installed oversized motors available for high static applications.

One of our Finest Assets:

Trane Sales Representatives are a Support group that can assist you with: — Product — Application — Service — Training — Special Applications — Specifications — Computer Programs and much more

Voyager has the features and benefits that make it first class in the light commercial rooftop market. Designed with input from field contractors and engineers, its U-shaped airflow performance is outstanding.

PKGP-PRC0 01-EN

Application Considerations

Application of this product should be within the cataloged airflow and cooling considerations.

Low Ambient Cooling

This Voyager line features, as standard, low ambient cooling down to 0°F. Contact your local Trane Representative for more assistance with low ambient cooling applications.

Barometric Relief

This product line offers an optional barometric relief damper included in the downflow economizer accessory. This accessory consists of gravity dampers which open with increased pressure. As the building air pressure increases, the pressure in the unit return air section also increases, opening the dampers and relieving the conditioned space.

NOTE: THE EFFECTIVENESS OF BAROMETRIC RELIEF DAMPER DURING ECONOMIZING OPERATION IS SYSTEM RELATED.

PRESSURE DROP OF THE RETURN AIR SYSTEM SHOULD BE CONSIDERED TO CONTROL BUILDING PRESSURIZATION.

Power Exhaust Accessory

The power exhaust accessory is available on all downflow units. This accessory can be field installed and will assist in relieving building pressurization.

Condensate Trap

The evaporator is a draw-thru configuration. A trap must be field provided prior to start-up on the cooling cycle.

Clearance Requirements

The recommended clearances identified with unit dimensions should be maintained to assure adequate serviceability, maximum capacity and peak operating efficiency. Actual clearances which appear inadequate should be reviewed with the local Trane sales personnel.

Unit Pitch

These units have sloped condensate drain pans. Units must be installed level, any unit slope must be toward access side of unit.

PKGP-PRC0 01-EN

Selection Procedures

Cooling Capacity

Step 1

Calculate the building’s total and sensible cooling loads at design conditions. Use the Tranecalculation form or any other standard accepted method.

Step 2

Given the following building requirements:

Electrical Characteristics: 460/60/3

Summer Design Conditions: Entering Evaporator Coil: 80 DB/ 67 WB Outdoor Ambient: 95 DB

Total Cooling Load: 172 MBh

Sensible Cooling Load: 122 MBh

Airflow: 6000 cfm

External Static Pressure: .50 in. w.g.

Rooftop - downflow configuration.

Accessories Economizer Supplementary Electric Heat

Heating Capacity 88 MBh 460 volt/3 phase Electric Supplemental Heat - at 6000 cfm

Size the equipment using Table PD-3. As a starting point, a rough determination of the size of the unit must be made. This selection will then be confirmed after examining the performance at the given conditions. Divide the total cooling load by nominal BTUH per ton (12 MBh per ton); then round up to the nearest unit size. 172 MBh/12 MBh = 14.33 (approx. 15 tons.)

Step 3

Table PD-3 shows that a WCD180B4 has a gross cooling capacity of 183.0 MBh and 129.0 MBh sensible capacity at 95 degree ambient and 6000 cfm with 80 DB/67 WB air entering the evaporator.

To Find Capacity at Intermediate Conditions

When the design conditions are between two numbers that are in the capacity table, interpolation is required to approximate the capacity.

Note: Extrapolation outside of the table conditions is not recommended.

Step 4

Verify that there will be enough capacity by determining net capacity. In order to select the correct unit which meets the building’s requirements, the fan motor heat must be deducted from the gross cooling capacity. The amount of heat that the fan motor generates is dependent on the effort by the motor cfm and static pressure. To determine the total unit static pressure, add the following:

External Static: 0.50 in.

Standard Filter 1 in: 0.11 in. (from table PD-13)

Economizer Return Air: 0.04 in. (from table PD-13)

Electric Heater Size 18 kW: .06 in.

Total Static Pressure: .71 in.

Note: The Evaporator Fan Performance Table PD-7 has already accounted for the pressure drop for standard filters and wet coils.

Therefore, the actual Total Static Pressure is .71 - .11 = .60. With 6000 cfm and .60 inches, Table PD-7 shows 2.66 Bhp.

The note below Table PD-7 gives a formula to calculate Fan Motor Heat:

3.15 x bhp = MBh

3.15 x 2.66 = 8.38 MBh

Now subtracting the fan motor heat from the gross cooling capacity of the unit:

Net Total Cooling Capacity =

183-8.38=170.62

Net Sensible Cooling Capacity=

129-8.38=120.62

Step 5

If the performance will not meet the required load of the building, try a selection at the next higher size unit.

Heating Capacity

Step 1

Calculate the building heating load using the Trane calculation form or other standard accepted method.

Step 2

Size the equipment using Table PD-16 to match the heating loads at design conditions.

Total Heating Load: 88 MBh

Outdoor Ambient (Winter) 17 DB

Indoor Return Temperature: 70 DB

Airflow: 6000 Cfm

Use the integrated portion of Table PD-16 for the WCD180B4 to determine capacity at winter design conditions. The mechanical heating portion of the heat pump will provide 45 MBh.

Step 3

Because 45 MBh is less than the building’s required heating capacity at winter design conditions, a supplementary heater must be selected.

88 MBh - 45 MBh = 43 MBh

From Table PD-20, at 480 volts, the 18 kW Heater will be adequate to do the job.

18 kW 61 MBh

From Table ED-3 select heater AYDHTRK418A (18 kW 460/60/3).

PKGP-PRC0 01-EN

Model Number Description

Packaged Heat Pump Unit Model Nomenclature

W C D 150 C 3 0 0 B A

12 3 456 7 8 9 10 11 12

Digits 1,2 Product Type

WC = Heat Pump, Packaged WF = With Factory Installed Options

Digit 3 - Airflow Configuration

D = Downflow H = Horizontal

Digits 4, 5, 6 - Nominal Gross Cooling Capacity (MBh)

150 = 12½ ton 180 = 15 ton 240 = 20 ton

Digit 7- Major Development Sequence

Digit 8 - Electrical Characteristics

3 = 208-230/60/3 4 = 460/60/3 W = 575/60/3

Digits 9, 10 - Factory Installed Options

00 = Packed Stock, No Options 0A= Factory Installed Downflow

Economizer 0B = Oversize Motor 0C = Downflow Economizer and Oversize

Motor 0F = Trane Communications Interface (TCI) 0G = Downflow Economizer and TCI

Digit 11- Minor Design Sequence

Digit 12- Service Digit

PKGP-PRC0 01-EN

General Data

(12½ Ton)

Table GD-1 — General Data

12½ Ton Downflow and Horizontal Units

Cooling Performance

Gross Cooling Capacity 152,00 152,000

EER Nominal CFM / ARI Rated CFM 4,400 / 4,400 4,400 / 4,400 ARI Net Cooling Capacity 144,000 144,000 Integrated Part Load Value System Power KW 15.16 15.16

Heating Performance

High Temp. Btuh Rating 135,000 132,000

System Power KW/COP 12.76/3.10 12.48/3.10

Low Temp. Btuh Rating 78,000 72,000

System Power KW/COP 10.88/2.1 10.55/2.0

HSPF (Btu/Watts-hr) — —

Compressor

No./Type 2/Scroll 2/Scroll

ARI Sound Rating (BELS)

Outdoor Coil — Type Hi-Performance Hi-Performance

Tube Size (in.) OD .375 .375 Face Area (sq ft) 23.96 23.96 Rows/FPI 2/16 2/16 Refrigerant Control Expansion Valve Expansion Valve

Indoor Coil — Type Hi-Performance Hi-Performance

Tube Size (in.) .375 .375 Face Area (sq ft) 15.83 17.50 Rows/FPI 2/15 2/15 Refrigerant Control Capillary Tube Capillary Tube Drain Connection No./Size (in.) 1/1.00 NPT 1/1.00 NPT

Outdoor Fan — Type Propeller Propeller

No. Used/Diameter (in.) 2/26 2/26 Drive Type/No. Speeds Direct/1 Direct/1 CFM 10,800 10,800 No. Motors/HP 2/.50 2/.50 Motor RPM 1,110 1,110

Indoor Fan — Type FC Centrifugal FC Centrifugal

No. Used 1 1 Diameter x Width (in.) 15 x 15 15 x 15 Drive Type/No. Speeds Belt/1 Belt/1 No. Motors 1 1 Motor HP (Standard/Oversized) 3.0/5.0 3.0/5.0 Motor RPM (Standard/Oversized) 1,740/3,450 1,740/3,450 Motor Frame Size (Standard/Oversized) 145T/145T 145T/145T

Filters — Type Furnished

(No.) Size Recommended (in.) (2) 20 x 20 x 2 (2) 20 x 20 x 2

Refrigerant Charge (Lbs of R-22)

Notes:

1. Cooling Performance and Heating Performance is rated at 95°F ambient, 80°F entering dry bulb, 67°F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Certified in accordance with the Unitary Large Equipment certification program, which is based on ARI Standard 340/360-93.

2. EER is rated at ARI conditions and in accordance with ASHRAE test procedures.

3. Integrated Part Load Value is based in accordance with ARI Standard 210/240 or 340. Units are rated at 80°F entering dry bulb, and 67°F entering wet bulb at ARI rated cfm.

4. Sound Rating shown is tested in accordance with ARI Standard 270 or 370.

5. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.

6. Optional 2 inch pleated filter also available.

WCD150B3, B4, BW WCH150B3, B4, BW

9.5 9.5

9.9 9.9

9.2 9.2

Throwaway Throwaway

(4) 20 x 25 x 2 (4) 20 x 25 x 2

11.1/11.4 Circuit 11.5/11.8 Circuit

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

General Data

(15, 20 Ton)

Table GD-2 — General Data

15 Ton Downflow and Horizontal Units 20 Ton Downflow and Horizontal Units

Cooling Performance

Gross Cooling Capacity 180,000 233,000 237,000

EER Nominal CFM / ARI Rated CFM 6,000 / 5,300 8,000 / 8,000 8,000/7,000 ARI Net Cooling Capacity 168,000 222,000 224,000 Integrated Part Load Value System Power KW 17.50 22.2 21.3

Heating Performance

High Temp. Btuh Rating 166,000 208,000 204,000

System Power KW/COP 15.69/3.10 19.65/3.10 19.29/3.10

Low Temp. Btuh Rating 88,000 118,000 118,000

System Power KW/COP 13.12/2.1 18.75/2.0 17.29/2.00

Compressor

No./Type 2/Scroll 2/Scroll 2/Scroll

Sound Rating (BELS)

Outdoor Coil — Type Hi-Performance Hi-Performance Hi-Performance

Tube Size (in.) OD .375 .375 .375 Face Area (sq ft) 27.12 35.3 35.3 Rows/FPI 3/16 3/16 3/16 Refrigerant Control Expansion Valve Expansion Valve Expansion Valve

Indoor Coil — Type Hi-Performance Hi-Performance Hi-Performance

Tube Size (in.) .375 .375 .375 Face Area (sq ft) 17.50 26.00 26.00 Rows/FPI 3/15 3/15 3/15 Refrigerant Control Short Orifice Capillary Tube Capillary Tube Drain Connection No./Size (in.) 1/1.00 NPT 1/1.00 NPT 1/1.00 NPT

Outdoor Fan — Type Propeller Propeller Propeller

No. Used/Diameter (in.) 2/26 2/28 2/28 Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 CFM 10,200 13,800 13,800 No. Motors/HP 2/.50 2/1.0 2/1.0 Motor RPM 1,100 1,125 1,125

Indoor Fan — Type FC Centrifugal FC Centrifugal FC Centrifugal

No. Used 1 11 Diameter x Width (in.) 15 x 15 18 x 18 18 x 18 Drive Type/No. Speeds Belt/1 Belt/1 Belt/1 No. Motors 1 1 1 Motor HP (Standard/Oversized) 3.0/5.0 5.0/7.5 5.0/7.5 Motor RPM (Standard/Oversized) 1,740/3,450 3,450/3,450 3,450/3,450 Motor Frame Size (Standard/Oversized) 145T/145T 184T/184T 184T/184T

Filters — Type Furnished

(No.) Size Recommended (in.) (2) 20 x 20 x 2 (4) 20 x 20 x 2 (8) 20 x 25 x 2

Refrigerant Charge (Lbs of R-22)

Notes:

2. EER is rated at ARI conditions and in accordance with ASHRAE test procedures.

3. Integrated Part Load Value is based in accordance with ARI Standard 210/240 or 340. Units are rated at 80°F entering dry bulb, and 67°F entering wet bulb at ARI rated cfm.

4. Sound Rating shown is tested in accordance with ARI Standard 270 or 370.

5. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.

6. Optional 2 inch pleated filter also available.

WC*180B3, B4, BW WCD240B3, B4, BW WCH240B3, B4, BW

9.6 9.8 10.5

10.0 9.7 10.3

9.2 9.4 9.4

Throwaway Throwaway Throwaway

(4) 20 x 25 x 2 (4) 20 x 25 x 2

19.9/9.9 Circuit 22.0/21.0 Circuit 22.0/21.0 Circut

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Performance Data

(12½ Ton)

Table PD-1 — Gross Cooling Capacities (MBh) 12½ Ton Downflow Three Phase WCD150B

Enter.

CFM Bulb 61 67 73 6 1 67 73 61 6 7 73 6 1 67 73 Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

4500 80 141.0 134.0 154.0 105.0 159.0 78.3 130.0 128.0 149.0 104.0 161.0 77.4 119.0 119.0 138.0 98.3 157.0 74.3 109.0 109.0 125.0 91.8 148.0 69.6

5000 80 145.0 141.0 156.0 108.0 160.0 79.2 134.0 134.0 152.0 109.0 162.0 79.5 124.0 124.0 141.0 104.0 160.0 77.2 114.0 114.0 128.0 97.5 151.0 72.9

5500 80 147.0 147.0 157.0 111.0 162.0 80.5 139.0 139.0 154.0 113.0 163.0 80.9 129.0 129.0 144.0 110.0 161.0 79.9 118.0 118.0 131.0 103.0 154.0 75.9

6000 80 150.0 150.0 158.0 113.0 162.0 81.2 144.0 144.0 156.0 117.0 164.0 82.1 133.0 133.0 147.0 115.0 162.0 82.1 122.0 122.0 133.0 108.0 156.0 78.7

Notes:

1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.

2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

3. MBH = Total Gross Capacity

4. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 140.0 113.0 153.0 90.8 158.0 57.9 128.0 106.0 149.0 83.3 160.0 56.3 116.0 99.8 137.0 83.3 157.0 53.5 104.0 93.3 124.0 77.1 148.0 48.9

85 146.0 146.0 155.0 124.0 160.0 94.3 139.0 139.0 150.0 125.0 162.0 95.8 129.0 129.0 138.0 119.0 158.0 94.9 119.0 119.0 125.0 113.0 148.0 90.2 90 153.0 153.0 156.0 143.0 162.0 111.0 148.0 148.0 151.0 145.0 163.0 114.0 140.0 140.0 139.0 139.0 158.0 114.0 130.0 130.0 129.0 129.0 148.0 111.0 75 143.0 119.0 154.0 93.5 159.0 59.0 132.0 113.0 152.0 87.2 161.0 57.4 119.0 106.0 141.0 88.6 159.0 54.8 107.0 99.5 127.0 82.3 151.0 50.9

85 150.0 150.0 157.0 128.0 162.0 97.0 145.0 145.0 153.0 131.0 164.0 98.4 135.0 135.0 142.0 127.0 160.0 98.9 125.0 125.0 129.0 120.0 152.0 95.3 90 156.0 156.0 158.0 148.0 164.0 112.0 153.0 153.0 155.0 153.0 165.0 118.0 146.0 146.0 146.0 146.0 161.0 120.0 136.0 136.0 136.0 136.0 152.0 118.0 75 145.0 124.0 155.0 96.1 160.0 60.0 135.0 119.0 153.0 90.7 162.0 58.5 122.0 112.0 144.0 93.8 160.0 55.7 110.0 105.0 130.0 87.4 154.0 52.4

85 153.0 153.0 158.0 132.0 164.0 97.4 149.0 149.0 155.0 137.0 165.0 101.0 140.0 140.0 145.0 134.0 162.0 102.0 130.0 130.0 132.0 128.0 154.0 100.0 90 159.0 159.0 160.0 152.0 166.0 115.0 157.0 157.0 157.0 157.0 166.0 121.0 151.0 151.0 151.0 151.0 163.0 125.0 141.0 141.0 141.0 141.0 154.0 124.0 75 147.0 128.0 156.0 98.4 160.0 60.0 138.0 125.0 155.0 92.7 163.0 59.5 125.0 118.0 147.0 88.6 161.0 57.2 112.0 111.0 132.0 92.4 155.0 52.5

85 156.0 156.0 159.0 135.0 164.0 98.4 153.0 153.0 157.0 142.0 166.0 103.0 145.0 145.0 148.0 141.0 163.0 106.0 134.0 134.0 134.0 134.0 156.0 104.0 90 160.0 160.0 161.0 156.0 166.0 116.0 160.0 160.0 160.0 160.0 167.0 123.0 155.0 155.0 155.0 155.0 165.0 129.0 146.0 146.0 146.0 146.0 157.0 130.0

85 95 105 115

Ambient Temperature (F)

Table PD-2 — Gross Cooling Capacities (MBh) 12½ Ton Horizontal Three Phase WCH150B

Enter.

CFM Bulb 61 67 73 61 67 73 61 67 73 61 67 73 Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

4500 80 141.0 134.0 154.0 105.0 160.0 78.3 130.0 128.0 149.0 104.0 161.0 77.5 119.0 119.0 138.0 98.4 157.0 74.3 109.0 109.0 124.0 91.9 148.0 69.6

5000 80 145.0 142.0 156.0 109.0 162.0 79.9 134.0 134.0 152.0 109.0 162.0 79.6 124.0 124.0 141.0 104.0 159.0 77.3 114.0 114.0 128.0 97.7 151.0 72.9

5500 80 147.0 147.0 157.0 111.0 162.0 80.8 139.0 139.0 154.0 114.0 163.0 81.0 129.0 129.0 144.0 110.0 161.0 80.1 118.0 118.0 130.0 103.0 154.0 76.0

6000 80 150.0 150.0 158.0 114.0 163.0 81.5 144.0 144.0 156.0 118.0 164.0 82.1 133.0 133.0 147.0 115.0 162.0 82.3 122.0 122.0 133.0 109.0 155.0 78.8

Notes:

1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.

2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

3. MBH = Total Gross Capacity

4. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 140.0 113.0 153.0 91.1 159.0 58.0 128.0 106.0 149.0 83.3 160.0 56.2 116.0 100.0 137.0 82.9 157.0 53.5 104.0 93.5 124.0 76.7 147.0 48.9

85 146.0 146.0 155.0 124.0 161.0 94.3 139.0 139.0 149.0 125.0 162.0 96.0 129.0 129.0 138.0 119.0 158.0 95.0 119.0 119.0 125.0 113.0 148.0 90.2 90 153.0 153.0 156.0 143.0 163.0 110.0 148.0 148.0 151.0 145.0 163.0 114.0 140.0 140.0 139.0 139.0 158.0 115.0 130.0 130.0 129.0 129.0 148.0 111.0 75 143.0 119.0 154.0 93.3 160.0 59.0 132.0 113.0 151.0 86.8 161.0 57.4 119.0 106.0 141.0 88.2 159.0 54.7 107.0 99.8 127.0 81.8 151.0 50.8

85 150.0 150.0 157.0 129.0 164.0 96.6 145.0 145.0 152.0 131.0 164.0 98.7 135.0 135.0 142.0 127.0 160.0 99.1 125.0 125.0 129.0 121.0 151.0 95.5 90 156.0 156.0 158.0 149.0 164.0 112.0 153.0 153.0 153.0 153.0 165.0 118.0 146.0 146.0 146.0 146.0 161.0 120.0 136.0 136.0 136.0 136.0 151.0 118.0 75 145.0 124.0 156.0 95.9 160.0 60.1 135.0 119.0 153.0 90.8 162.0 58.5 122.0 112.0 144.0 93.2 160.0 55.8 110.0 106.0 130.0 86.9 153.0 52.3

85 154.0 154.0 158.0 133.0 164.0 97.9 149.0 149.0 155.0 137.0 165.0 101.0 140.0 140.0 145.0 135.0 162.0 103.0 130.0 130.0 132.0 128.0 154.0 100.0 90 159.0 159.0 160.0 153.0 166.0 115.0 157.0 157.0 157.0 157.0 167.0 121.0 151.0 151.0 151.0 151.0 163.0 125.0 141.0 141.0 141.0 141.0 154.0 124.0 75 147.0 129.0 157.0 98.2 161.0 60.6 138.0 125.0 155.0 92.9 163.0 59.5 125.0 118.0 146.0 88.7 161.0 57.1 111.0 111.0 132.0 91.8 155.0 52.5

85 156.0 156.0 160.0 136.0 165.0 99.1 153.0 153.0 157.0 143.0 166.0 103.0 145.0 145.0 148.0 142.0 163.0 106.0 134.0 134.0 134.0 134.0 156.0 105.0 90 161.0 161.0 162.0 157.0 167.0 117.0 160.0 160.0 160.0 160.0 168.0 124.0 155.0 155.0 155.0 155.0 164.0 130.0 146.0 146.0 146.0 146.0 156.0 130.0

85 95 105 115

Ambient Temperature (F)

PKGP-PRC0 01-EN

Performance Data

(15 Ton)

Table PD-3 — Gross Cooling Capacities (MBh) 15 Ton Downflow and Horizontal Three Phase WC*180B

CFM Dry Entering Wet Bulb (F)

Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

5400

6000

6600

7200

Notes:

1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.

2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

3. MBH = Total Gross Capacity

4. SHC = Sensible Heat Capacity

Enter.

Bulb 61 67 73 61 67 73 61 67 73 61 67 73

75 162.3 130.3 184.5 103.3 194.1 71.1 150.5 124.1 176.5 99.0 190.3 68.4 137.5 117.3 163.6 93.0 185.5 65.5 124.8 110.8 149.4 94.8 176.1 61.2 80 163.8 154.2 185.1 126.5 195.7 95.8 152.7 148.2 176.7 122.2 191.5 92.1 139.3 139.3 163.8 116.2 186.0 88.8 129.4 129.4 150.0 109.7 176.4 84.3 85 170.5 170.5 185.5 148.7 197.4 115.8 161.6 161.6 177.1 145.3 192.1 113.7 151.3 151.3 164.3 139.4 186.7 111.8 141.5 141.5 151.0 133.1 176.7 107.3 90 181.0 181.0 186.7 170.9 201.0 136.9 173.5 173.5 178.5 168.4 194.9 135.7 163.7 163.7 166.9 163.2 187.1 133.8 153.8 153.8 153.7 153.7 177.0 130.2 75 167.0 137.5 187.0 106.7 195.3 71.7 154.8 131.2 179.7 102.8 191.7 69.1 141.4 124.3 167.8 97.3 187.5 66.4 128.5 117.7 153.8 90.9 178.8 62.4 80 169.2 163.7 187.6 131.0 197.2 98.1 156.0 156.0 180.0 128.0 193.2 95.1 145.5 145.5 168.0 122.6 188.3 91.8 135.3 135.3 154.1 116.1 179.2 87.6 85 177.5 177.5 188.5 154.8 199.6 118.6 168.9 168.9 180.6 152.9 194.1 116.7 158.3 158.3 168.8 147.9 188.7 116.2 148.1 148.1 155.5 141.6 179.6 112.5 90 186.6 186.6 190.1 178.4 202.6 140.1 180.0 180.0 182.7 177.5 197.3 140.3 171.1 171.1 171.0 171.0 189.9 139.5 161.1 161.1 161.2 161.2 180.0 136.8 75 170.8 144.2 188.9 110.1 196.2 72.6 158.6 137.9 182.2 106.4 192.7 70.2 144.9 131.0 171.3 101.3 188.8 67.3 131.8 124.4 157.2 95.0 180.7 63.4 80 173.6 172.6 189.7 134.9 198.3 99.3 162.1 162.1 182.7 133.3 194.4 97.9 151.1 151.1 171.5 128.5 190.0 94.7 140.6 140.6 157.6 122.2 181.2 90.5 85 182.5 182.5 191.0 160.1 200.5 120.2 175.0 175.0 183.6 159.7 195.9 119.6 164.6 164.6 172.7 155.9 190.8 119.7 154.0 154.0 159.6 149.9 181.6 117.1 90 190.6 190.6 192.9 184.7 202.3 140.8 184.9 184.9 186.2 185.4 199.1 144.1 177.1 177.1 177.0 177.0 192.1 144.4 167.4 167.4 167.3 167.3 182.6 142.8 75 174.0 150.5 190.0 112.2 196.9 73.6 162.1 144.4 184.2 109.7 193.5 71.2 148.1 137.4 174.0 105.0 189.9 68.2 134.8 130.7 160.2 98.8 182.1 64.2 80 176.7 176.7 191.4 138.3 199.1 100.2 167.6 167.6 184.8 137.8 195.7 99.2 156.3 156.3 174.3 134.1 190.7 97.2 145.4 145.4 160.6 128.0 182.9 93.4 85 186.4 186.4 192.9 164.7 201.5 121.7 179.6 179.6 186.0 165.5 197.7 122.4 170.1 170.1 175.9 163.3 192.4 122.8 159.4 159.4 163.2 157.7 183.5 121.0 90 193.8 193.8 195.1 190.1 203.3 143.0 188.6 188.6 188.5 188.5 200.6 147.4 181.9 181.9 181.7 181.7 193.9 148.7 172.6 172.6 172.5 172.5 184.6 148.2

85 95 105 115

Ambient Temperature ( F)

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Performance Data

(20 Ton)

Table PD-4 — Gross Cooling Capacities (MBh) 20 Ton Downflow Three Phase WCD240B

CFM Dry Entering Wet Bulb (F)

Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

7200 85 229.0 229.0 236.0 197.0 249.0 148.0 220.0 220.0 231.0 202.0 249.0 153.0 205.0 205.0 215.0 196.0 242.0 153.0 189.0 189.0 194.0 186.0 226.0 146.0

8000 85 234.0 234.0 241.0 207.0 250.0 150.0 228.0 228.0 235.0 213.0 252.0 158.0 215.0 215.0 221.0 210.0 244.0 159.0 197.0 197.0 197.0 197.0 230.0 155.0

8800 85 238.0 238.0 244.0 212.0 252.0 152.0 234.0 234.0 239.0 223.0 253.0 161.0 222.0 222.0 226.0 223.0 247.0 165.0 205.0 205.0 205.0 205.0 233.0 164.0

9600 85 241.0 241.0 245.0 222.0 253.0 155.0 239.0 239.0 242.0 231.0 255.0 165.0 229.0 229.0 229.0 229.0 249.0 170.0 212.0 212.0 212.0 212.0 236.0 171.0

Notes:

1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.

2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

3. MBH = Total Gross Capacity

4. SHC = Sensible Heat Capacity

Enter.

Bulb 61 67 73 61 67 73 61 67 73 61 67 73

75 212.0 177.0 233.0 137.0 243.0 89.7 198.0 173.0 228.0 133.0 244.0 87.3 179.0 164.0 211.0 130.0 239.0 83.1 160.0 154.0 189.0 115.0 225.0 76.8 80 219.0 218.0 234.0 165.0 246.0 122.0 204.0 204.0 229.0 168.0 247.0 123.0 188.0 188.0 212.0 160.0 240.0 118.0 172.0 172.0 190.0 150.0 225.0 112.0

90 238.0 238.0 238.0 227.0 252.0 174.0 234.0 234.0 233.0 233.0 252.0 183.0 222.0 222.0 222.0 222.0 242.0 186.0 206.0 206.0 206.0 206.0 227.0 181.0 75 218.0 193.0 237.0 144.0 244.0 91.2 204.0 185.0 232.0 139.0 246.0 89.1 184.0 175.0 216.0 131.0 242.0 85.0 162.0 162.0 193.0 128.0 229.0 78.8 80 224.0 224.0 239.0 173.0 247.0 123.0 213.0 213.0 233.0 176.0 249.0 126.0 196.0 196.0 217.0 170.0 243.0 124.0 180.0 180.0 195.0 160.0 230.0 117.0

90 242.0 242.0 245.0 238.0 253.0 178.0 240.0 240.0 240.0 240.0 254.0 190.0 231.0 231.0 231.0 231.0 246.0 195.0 216.0 216.0 216.0 216.0 232.0 193.0 75 223.0 201.0 238.0 148.0 245.0 93.4 209.0 196.0 235.0 145.0 248.0 90.6 189.0 186.0 220.0 138.0 244.0 86.8 168.0 168.0 196.0 136.0 232.0 80.6 80 229.0 229.0 241.0 177.0 248.0 139.0 220.0 220.0 236.0 184.0 250.0 128.0 204.0 204.0 221.0 180.0 246.0 129.0 186.0 186.0 199.0 170.0 233.0 122.0

90 245.0 245.0 247.0 245.0 255.0 181.0 245.0 245.0 245.0 245.0 256.0 195.0 238.0 238.0 238.0 238.0 249.0 203.0 224.0 224.0 224.0 224.0 236.0 205.0 75 226.0 208.0 241.0 151.0 246.0 94.2 214.0 206.0 236.0 148.0 249.0 91.4 191.0 191.0 223.0 144.0 245.0 88.6 174.0 174.0 199.0 143.0 235.0 82.4 80 232.0 232.0 243.0 185.0 250.0 126.0 226.0 226.0 238.0 190.0 251.0 115.0 211.0 211.0 225.0 189.0 247.0 123.0 193.0 193.0 203.0 179.0 235.0 127.0

90 248.0 248.0 247.0 247.0 256.0 184.0 248.0 248.0 248.0 248.0 258.0 200.0 243.0 243.0 243.0 243.0 252.0 210.0 231.0 231.0 231.0 231.0 239.0 215.0

85 95 105 115

Ambient Temperature (F)

Table PD-5 — Gross Cooling Capacities (MBh) 20 Ton Horizontal Three Phase WCD240B

CFM Dry Entering Wet Bulb (F)

Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

7200

8000

8800

9600

Notes:

1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.

2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

3. MBH = Total Gross Capacity

4. SHC = Sensible Heat Capacity

Enter.

Bulb 61 67 73 61 67 73 61 67 73 61 67 73

75 217.0 181.0 238.0 140.0 248.0 91.4 202.0 177.0 233.0 136.0 249.0 88.9 183.0 167.0 215.0 132.0 244.0 84.7 163.0 157.0 192.0 117.0 229.0 78.3 80 224.0 223.0 239.0 168.0 250.0 124.0 208.0 208.0 233.0 171.0 251.0 126.0 192.0 192.0 216.0 163.0 245.0 121.0 175.0 175.0 194.0 153.0 229.0 114.0 85 233.0 233.0 241.0 201.0 253.0 151.0 224.0 224.0 235.0 206.0 254.0 156.0 209.0 209.0 219.0 200.0 246.0 156.0 192.0 192.0 198.0 190.0 230.0 149.0 90 242.0 242.0 242.0 230.0 256.0 177.0 238.0 238.0 238.0 238.0 257.0 186.0 226.0 226.0 226.0 226.0 247.0 189.0210.0 210.0210.0 210.0 231.0 185.0

75 223.0 197.0 241.0 147.0 249.0 93.5 208.0 188.0 236.0 142.0 251.0 90.8 188.0 178.0 220.0 134.0 247.0 86.6 165.0 165.0 196.0 130.0 233.0 80.3 80 228.0 228.0 244.0 176.0 252.0 126.0 217.0 217.0 237.0 180.0 254.0 128.0 200.0 200.0 221.0 174.0 248.0 126.0 183.0 183.0 199.0 163.0 234.0 119.0 85 238.0 238.0 246.0 211.0 255.0 153.0 233.0 233.0 240.0 217.0 256.0 161.0 219.0 219.0 225.0 214.0 249.0 163.0 201.0 201.0 201.0 201.0 234.0 158.0 90 246.0 246.0 250.0 243.0 258.0 181.0 245.0245.0 245.0 245.0 259.0194.0 235.0235.0 235.0 235.0251.0 199.0 220.0220.0220.0 220.0 236.0 197.0 75 228.0 205.0 243.0 151.0 250.0 95.2 213.0 200.0 239.0 147.0 252.0 92.3 193.0 189.0 224.0 140.0 249.0 88.5 172.0 172.0 200.0 138.0 237.0 82.1 80 233.0 233.0 245.0 181.0 253.0 142.0 224.0 224.0 240.0 187.0 255.0 131.0 208.0 208.0 225.0 183.0 250.0 131.0 190.0 190.0 203.0 173.0 237.0 124.0 85 242.0 242.0 248.0 216.0 256.0 155.0 239.0 239.0 243.0 227.0 258.0 165.0 227.0 227.0 230.0 227.0 252.0 169.0 209.0 209.0 209.0 209.0 238.0 167.0 90 249.0 249.0 252.0 250.0 260.0 184.0 249.0249.0 249.0 249.0 261.0 199.0242.0242.0 242.0 242.0 254.0 207.0 228.0 228.0 228.0 228.0 240.0 208.0

75 231.0 212.0 245.0 153.0 251.0 96.0 218.0 210.0 241.0 151.0 253.0 93.1 195.0 195.0 227.0 146.0 250.0 90.3 177.0 177.0 203.0 146.0 239.0 84.0 80 237.0 237.0 247.0 188.0 254.0 128.0 230.0 230.0 243.0 194.0 256.0 117.0 215.0 215.0 229.0 193.0 251.0 125.0 196.0 196.0 207.0 183.0 240.0 130.0 85 245.0 245.0 249.0 226.0 258.0 158.0 243.0 243.0 246.0 236.0 260.0 168.0 233.0 233.0 233.0 233.0 253.0 173.0 216.0 216.0 216.0 216.0 241.0 175.0 90 253.0 253.0 252.0 252.0 261.0 187.0 253.0253.0 253.0253.0 263.0 204.0 247.0 247.0 247.0 247.0 256.0214.0 235.0 235.0 235.0 235.0 244.0 219.0

85 95 105 115

Ambient Temperature (F)

PKGP-PRC0 01-EN

Performance Data

(12½ Ton)

Table PD-6 — Evaporator Fan Performance — 12½ Ton — WC*150B

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

4000 — — 506 0.69 537 0.80 568 0.92 599 1.03 631 1.15 662 1.26 694 1.37 726 1.48 756 1.59 4500 511 0.87 541 0.98 572 1.09 603 1.21 634 1.32 664 1.43 693 1.55 721 1.68 749 1.81 777 1.94 5000 551 1.16 580 1.31 612 1.39 640 1.51 672 1.67 700 1.78 727 1.90 754 2.03 779 2.18 805 2.32 5500 597 1.54 626 1.68 656 1.80 682 1.89 709 2.04 738 2.22 763 2.34 788 2.46 813 2.60 837 2.76 6000 644 1.99 674 2.10 699 2.28 727 2.37 749 2.48 774 2.66 801 2.85 825 3.00 848 3.13 871 3.27

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

3 HP Standard Motor & Field Supplied Low Static Drive (1) 3 HP Standard Motor & Drive

External Static Pressure (Inches of Water)

3 HP Standard Motor & High

Static Drive Accessory

Table PD-6 — Evaporator Fan Performance — 12½ Ton — WC*150B — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

4000 786 1.70 815 1.82 843 1.94 870 2.06 897 2.20 923 2.34 949 2.48 974 2.64 998 2.80 1022 2.96 4500 806 2.06 833 2.18 860 2.30 886 2.43 912 2.56 937 2.69 962 2.83 986 2.98 1010 3.13 1033 3.28 5000 830 2.47 855 2.61 880 2.74 905 2.88 930 3.01 954 3.15 978 3.29 1001 3.43 1024 3.58 1047 3.73 5500 860 2.92 883 3.08 906 3.24 929 3.39 952 3.54 975 3.69 997 3.84 1020 3.99 1042 4.14 1064 4.29 6000 893 3.43 915 3.59 936 3.77 957 3.94 978 4.12 999 4.29 1020 4.46 1041 4.62 1062 4.78 1083 4.94

Notes: Fan motor heat (MBH) = 3.15 x Fan BHP. Data includes pressure drop due to wet coils and filters. No accessories or options are included in pressure drop data. Refer to Table PD-13 to determine add’l static pressure drop due to other options/accessories. Notes:

1. Field supplied fan sheave BK115 required. Field supplied belt may be necessary.

Factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions, Using the full horsepower range of our fan motors as shown in our tabulated data will not result in nuisance tripping or premature motor failure. Our product's warranty will not be affected.

1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00

3 HP Standard Motor & Drive 3 HP Standard Motor & High Static Drive Accessory

External Static Pressure (Inches of Water)

5 HP Oversized Motor & Drive

PKGP-PRC0 01-EN

Performance Data (15 Ton)

Table PD-7 — Evaporator Fan Performance — 15 Ton — WCD180B

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

4800 691 1.64 723 1.81 751 1.97 778 2.13 808 2.32 836 2.51 861 2.68 885 2.86 909 3.04 931 3.22 5400 769 2.29 799 2.48 826 2.66 850 2.83 874 3.02 900 3.23 926 3.45 950 3.65 972 3.86 993 4.05 6000 848 3.09 875 3.30 901 3.51 924 3.71 946 3.90 967 4.09 991 4.33 1014 4.57 1037 4.81 1058 5.04 6600 928 4.06 953 4.30 977 4.53 999 4.76 1020 4.97 1039 5.18 1059 5.39 1080 5.64 1101 5.90 1122 6.17 7200 1008 5.22 1031 5.48 1053 5.74 1075 5.99 1095 6.24 1113 6.46 1131 6.69 1149 6.93 1168 7.18 1188 7.46

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

3 HP Standard Motor Drive

5 HP Oversized Motor & Drive Field Supplied 7.5 HP Oversized Motor & Drive (3)

3 HP Standard Motor & Field Supplied High Static Drive (1)

Table PD-7 — Evaporator Fan Performance — 15 Ton — WCD180B — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

4800 954 3.41 976 3.60 998 3.78 1020 3.98 1041 4.17 1062 4.38 1082 4.57 1102 4.76 1120 4.95 1138 5.14 5400 1014 4.25 1035 4.46 1055 4.66 1074 4.87 1095 5.08 1114 5.30 1133 5.51 1153 5.73 1171 5.94 1190 6.16 6000 1077 5.26 1097 5.48 1116 5.71 1134 5.93 1153 6.16 1171 6.38 1189 6.61 1207 6.85 1224 7.08 1242 7.31 6600 1143 6.43 1161 6.67 1180 6.92 1197 7.17 1215 7.41 1232 7.66 1249 7.91 1266 8.15 1282 8.41 — — 7200 1207 7.74 1227 8.04 1245 8.32 1262 8.59 — — — — ————————

3 HP Standard Motor & Field Supplied High Static Drive (1)

Fan motor heat (MBH) = 3.15 x Fan BHP. Data includes pressure drop due to wet coils and filters. No accessories or options are included in pressure drop data. Refer to Table PD-13 to determine additional static pressure drop due to other options/accessories.

1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00

5 HP Oversized Motor & Drive 5 HP Oversized Motor & Field Supplied High Static Drive (2)

7.5 HP Oversized Motor & Drive

Table PD-8 — Evaporator Fan Performance — 15 Ton — WCH180B

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

4800 637 1.36 670 1.50 700 1.63 743 1.88 801 2.32 850 2.72 884 3.01 908 3.17 931 3.32 953 3.47 5400 709 1.90 738 2.06 766 2.20 793 2.34 833 2.65 884 3.12 931 3.62 969 4.02 998 4.31 1019 4.49 6000 781 2.56 808 2.74 834 2.91 858 3.06 882 3.22 918 3.55 962 4.05 1009 4.63 1049 5.15 1081 5.57 6600 854 3.37 879 3.56 903 3.75 925 3.93 947 4.10 970 4.28 1001 4.62 1039 5.11 1082 5.72 1122 6.34 7200 927 4.33 951 4.55 973 4.76 994 4.96 1014 5.15 1035 5.34 1055 5.54 1081 5.85 1115 6.33 1152 6.94

3 HP Standard Motor & Field Supplied Low Static Drive (1)

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

3 HP Standard Motor & Drive

5 HP Oversized Motor & Drive

Table PD-8 — Evaporator Fan Performance — 15 Ton — WCH180B — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

4800 975 3.62 997 3.79 1018 3.95 1040 4.12 1061 4.29 1078 4.39 1082 4.25 1086 4.10 1094 4.04 1116 4.21 5400 1040 4.66 1060 4.83 1079 5.00 1098 5.18 1118 5.36 1137 5.54 1156 5.73 1174 5.91 1194 6.11 1212 6.28 6000 1107 5.89 1126 6.08 1144 6.28 1162 6.47 1180 6.66 1197 6.85 1214 7.04 1232 7.24 1250 7.44 1267 7.65 6600 1157 6.90 1186 7.36 1212 7.75 1230 7.99 1246 8.20 1263 8.42 1279 8.62 — — — — — — 7200 1191 7.62 1227 8.30 — — — — — — — — ————————

1. Field Supplied Fan Sheave BK95 (1" bore) required

2. Field Supplied Fan Sheave BK77 (1" bore) required.

1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00

5 HP Oversized Motor & Drive 5 HP Standard Motor & Field Supplied High Static Drive Accessory (3)

7.5 HP Oversized Motor & Drive 7.5 HP Oversized Motor with

External Static Pressure (Inches of Water)

5 HP Oversized Motor & Field Supplied High Static Drive (2)

External Static Pressure (Inches of Water)

7.5 HP Oversized Motor with Field Supplied High Static Drive (3) (4)

External Static Pressure (Inches of Water)

Notes:

1. Field Supplied Fan Sheave BK77(1"bore) required.

2. Field Supplied Motor Sheave 1VP50 (7/8" bore) required.

3. 7.5 hp motor kit BAYHSMT041 (208/460V), BAYHSMT042 (575V)

4. Field Supplied fan sheave BK115 (1" bore) required. Factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions, Using the full horsepower range of our fan motors as shown in our tabulated data will not result in nuisance tripping or premature motor failure. Our product's warranty will not be affected.

3 HP Standard Motor & Field

Supplied High Static Drive (2)

7.5 HP Oversized Motor & Drive (4)

Field Supplied High Static Drive (4) (5)

3. Field Supplied Motor Sheave 1VP50 (7/8" bore) required.

4. 7.5 hp motor kit BAYHSMT041 (208/460V), BAYHSMT042 (575V)

5. Field Supplied fan sheave BK115 (1" bore) required. Factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions, Using the full horsepower range of our fan motors as shown in our tabulated data will not result in nuisance tripping or premature motor failure. Our product's warranty will not be affected.

3 HP Standard Motor & Field Supplied High Static Drive (1)

5 HP Oversized Motor & Field Supplied High Static Drive (3)

PKGP-PRC0 01-EN

Performance Data (20 Ton)

Table PD-9 — Evaporator Fan Performance — 20 Ton — WC*240B

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

6400 — — 531 1.80 556 1.97 582 2.14 610 2.28 634 2.44 658 2.61 681 2.79 705 2.98 729 3.19 7200 552 2.23 576 2.16 605 2.60 631 2.81 655 3.00 678 3.18 701 3.36 722 3.55 743 3.74 763 3.94 8000 605 3.01 627 3.16 655 3.39 679 3.63 702 3.86 724 4.07 745 4.28 766 4.48 786 4.68 805 4.90 8800 648 3.83 678 4.10 705 4.34 729 4.61 751 4.87 771 5.12 791 5.36 811 5.59 830 5.81 848 6.03 9600 702 4.91 729 5.21 755 5.49 779 5.77 800 6.06 820 6.34 839 6.61 857 6.88 875 7.13 893 7.37

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

5 HP Standard Motor & Field Supplied Low Static Drive (1) 5 HP Standard Motor & Drive

Table PD-9 — Evaporator Fan Performance — 20 Ton — WC*240B — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

6400 753 3.39 776 3.59 799 3.80 822 4.02 844 4.24 865 4.47 886 4.69 906 4.92 925 5.16 944 5.40 7200 784 4.15 806 4.38 827 4.61 848 4.84 869 5.07 889 5.30 910 5.54 930 5.79 950 6.04 969 6.29 8000 824 5.11 842 5.32 860 5.55 880 5.80 899 6.06 918 6.31 937 6.56 956 6.81 974 7.07 993 7.33 8800 866 6.26 884 6.49 901 6.73 917 6.96 934 7.20 951 7.46 969 7.74 986 8.02 1004 8.30 — — 9600 910 7.61 927 7.85 943 8.10 960 8.35 975 8.61 — — ————————

1. Field supplied fan sheave BK190 required. Field supplied belt may be necessary.

2. 7.5 HP oversize motor with field supplied motor sheave 1VP50 required. Field supplied belt may be necessary.

Factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabulated data will not result in nuisance tripping or premature motor failure. Our product's warranty will not be affected.

1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00

5 HP Standard Motor & Drive 5 HP Standard Motor & High Static Drive Accessory

7.5 HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

(2) 7.5 HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

PKGP-PRC0 01-EN

Performance Data (12½ - 20 Tons)

Table PD-10 — Standard Motor & Drive/Fan Speed (RPM)

Tons Model No. Open Open Open Open Open Open Closed

12½ WC*150B 640 680 720 760 800 840 N/A 15 WC 20 WC

Factory set at 3 turns open.

Table PD-11 — Standard Motor With High Static Drive Fan Speed (RPM)

Tons Model No. Open Open Open Open Open Open Closed

12½ WC*150B 807 857 908 958 1009 1059 N/A 20 WC

Table PD-12 — Oversized Motor & Drive/Fan Speed (RPM)

Tons Model No. Open Open Open Open Open Open Closed

12½ WC*150B 869 923 978 1032 1087 1141 N/A 15 15 20 WC*240B 816 853 890 928 965 1002 N/A

Notes:

1. 5 hp oversized motor/drive.

2. 7.5 hp overized motor/drive.

Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn

*180B 679 721 764 806 849 891 N/A *240B 615 659 703 747 791 835 N/A

Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn

*240B 835 879 923 967 1011 1055 N/A

Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn

WC*180B 806 856 907 957 1008 1058 N/A

WC*180b 949 1008 1068 1127 1187 1246 N/A

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Performance Data (12½ - 20 Tons)

Table PD-13 — Static Pressure Drops Through Accessories (Inches Water Column)

Economizer with Electric Heater

Tons Model No. CFM Filters

12½ WC*150B 5000 0.07 0.11 0.26 0.03 — 0.04 0.05 0.06 —

15 WC*180B 6000 0.11 0.15 0.35 0.04 — 0.06 0.07 0.08 —

20 6400 0.06 0.01 0.22 0.04 — — 0.06 0.08 0.09

Notes:

1. OA = Outside Air and RA = Return Air.

2. Nominal KW ratings at 240, 480, 600 volts.

3. Tested with:2" filters 12½-20 tons.

4. Difference in pressure drop should be considered when utilizing optional 2” pleated filters.

Unit Standard 2 Inch

4000 0.05 0.08 0.20 0.02 — 0.03 0.03 0.04 —

6000 0.11 0.15 0.35 0.04 — 0.06 0.07 0.09 — 4800 0.07 0.10 0.24 0.03 — 0.04 0.04 0.05 —

7200 0.15 0.19 0.42 0.05 — 0.09 0.10 0.12 — 6400 0.07 0.11 0.22 0.04 — — 0.06 0.08 0.09

WCD240B 8000 0.11 0.15 0.31 0.05 — — 0.10 0.12 0.14

9600 0.16 0.02 0.44 0.07 — — 0.14 0.17 0.20

WCH240B 8000 0.09 0.13 0.31 0.05 — — 0.10 0.12 0.14

9600 0.13 0.17 0.44 0.07 — — 0.14 0.17 0.20

Pleated Filters4100% OA 100% RA 5-12 14-23 36 54 72

OA/RA Dampers

Accessory (kW)

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Performance Data (12½ Ton)

Table PD-14 — 12½ Ton Downflow Three Phase Heating Capacities (Net) WCD150B3, B4, BW at 5000 CFM

Outdoor Temp.

F. 60 70 75 80 60 70 75 80

-8 51.9 50.3 49.6 49 9.56 10.37 10.83 11.32

-3 56.8 55.3 54.6 54 9.61 10.45 10.92 11.42 2 62.1 60.7 60 59.4 9.74 10.55 11.03 11.53 7 67.9 66.4 65.7 65.1 9.85 10.72 11.2 11.71 12 74.1 72.6 71.9 71.1 9.98 10.87 11.36 11.88 17 80.7 79.1 78.3 77.6 10.13 11.03 11.53 12.06 22 87.8 86 85.1 84.3 10.3 11.22 11.72 12.26 27 95.3 93.3 92.3 91.4 10.48 11.41 11.92 12.48 32 103.2 101 99.9 98.9 10.68 11.62 12.14 12.7 37 111.1 108.6 107.4 106.3 10.89 11.84 12.37 12.94 42 119.2 116.4 115.1 113.9 11.11 12.07 12.61 13.18 47 138.6 135.3 133.8 132.3 11.93 12.96 13.53 14.14 52 148.1 144.5 142.9 141.2 12.2 13.25 13.83 14.43 57 155.6 151.4 149.4 147.4 12.46 13.49 14.06 14.67 62 168.8 164.2 161.9 159.7 12.8 13.86 14.43 15.04 67 179.3 174.3 171.8 169.4 13.17 14.24 14.82 15.44 72 189.9 184.5 181.8 179.1 13.55 14.64 15.23 15.85

For other airflow conditions, see heating capacity correction factor (Table PD-19). Net Heating Capacity and Power Input include indoor fan heat at nominal cfm and .35 inch ESP. To obtain net heating at other conditions, subtract fan heat at this condition and add fan heat at new condition. Heating capacities and powers are integrated to include the effects of defrost in the frost region. All heating capacities and power (kW) are at 70% OD relative humidity.

Integrated Heating Capacity (MBh/1000) Total Power in Kilowatts At

At Indicated Indoor Dry Bulb Temp. Indicated Indoor Dry Bulb Temp.

Table PD-15— 12½ Ton Horizontal Three Phase Heating Capacities (Net) WCH150B3, B4, BW at 5000 CFM

Outdoor Temp.

F. 60 70 75 80 60 70 75 80

-8 48.2 46.6 46 45.4 9.18 9.96 10.4 10.87

-3 52.7 51.3 50.6 50 9.23 10.03 10.48 10.96 2 57.7 56.3 55.7 55.1 9.35 10.13 10.58 11.07 7 63.1 61.7 61.1 60.4 9.46 10.29 10.75 11.24 12 68.9 67.5 66.8 66.1 9.58 10.43 10.9 11.4 17 75.2 73.6 72.9 72.1 9.73 10.59 11.07 11.58 22 81.8 80.1 79.3 78.4 9.88 10.77 11.25 11.77 27 88.9 87 86 85.1 10.06 10.96 11.45 11.98 32 96.3 94.2 93.1 92.1 10.25 11.16 11.66 12.2 37 103.7 101.4 100.2 99.1 10.45 11.37 11.88 12.42 42 111.3 108.7 107.5 106.3 10.67 11.6 12.11 12.66 47 137.3 133.9 132.4 130.9 11.53 12.52 13.07 13.66 52 146.8 143.1 141.4 139.8 11.8 12.8 13.36 13.96 57 154.4 150.1 148.1 146.1 12.04 13.04 13.6 14.19 62 167.7 162.9 160.7 158.4 12.37 13.39 13.95 14.55 67 178.1 173.1 170.6 168.2 12.72 13.76 14.33 14.93 72 188.8 183.4 180.7 178 13.1 14.15 14.73 15.33

For other airflow conditions, see heating capacity correction factor (Table PD-19). Net Heating Capacity and Power Input include indoor fan heat at nominal cfm and .40 inch ESP. To obtain net heating at other conditions, subtract fan heat at this condition and add fan heat at new condition. Heating capacities and powers are integrated to include the effects of defrost in the frost region. All heating capacities and power (kW) are at 70% OD relative humidity.

Integrated Heating Capacity (MBh/1000) Total Power in Kilowatts At

At Indicated Indoor Dry Bulb Temp. Indicated Indoor Dry Bulb Temp.

PKGP-PRC0 01-EN

Performance Data (15 Ton)

Table PD-16 — 15 Ton Downflow Three Phase Heating Capacities (Net) WC*180B3, B4, BW at 6000 CFM

Outdoor Temp.

F. 60 70 75 80 60 70 75 80

-8 61.6 60.4 59.9 59.6 11.35 12.19 12.67 13.20

-3 67.6 66.4 65.9 65.5 11.55 12.39 12.88 13.41 2 74.0 72.8 72.3 71.9 11.74 12.62 13.12 13.65 7 80.8 79.6 79.1 78.6 11.94 12.84 13.34 13.88 12 88.0 86.8 86.2 85.7 12.15 13.06 13.57 14.12 17 95.8 94.3 93.7 93.2 12.36 13.29 13.81 14.37 22 104.1 102.5 101.8 101.1 12.59 13.54 14.07 14.63 27 113.0 111.2 110.3 109.6 12.84 13.80 14.33 14.91 32 122.3 120.3 119.3 118.4 13.10 14.07 14.61 15.20 37 131.6 129.8 128.3 127.3 13.36 14.35 14.90 15.50 42 141.3 138.8 137.6 136.5 13.63 14.64 15.20 15.81 47 172.0 168.8 167.3 165.8 14.97 16.07 16.68 17.34 52 183.8 180.3 178.6 177.1 15.31 16.42 17.05 17.71 57 196.1 192.2 190.4 188.6 15.66 16.80 17.43 18.10 62 208.6 204.3 202.3 200.3 16.04 17.19 17.83 18.51 67 217.8 212.8 210.4 208.0 16.35 17.50 18.13 18.80 72 230.9 225.6 222.9 220.4 16.79 17.95 18.59 19.27

Integrated Heating Capacity (MBh/1000) Total Power in Kilowatts At

At Indicated Indoor Dry Bulb Temp. Indicated Indoor Dry Bulb Temp.

PKGP-PRC0 01-EN

Performance Data

(20 Ton)

Table PD-17 — 20 Ton Downflow Three Phase Heating Capacities (Net) WCD240B3, B4, BW at 8000 CFM

Outdoor Temp.

F. 60 70 75 80 60 70 75 80

-8 78.1 75.8 74.9 74.0 16.7 17.8 18.4 19.1

-3 86.8 84.4 83.4 82.5 16.8 17.9 18.6 19.3 2 96.0 93.6 92.4 91.4 16.9 18.1 18.7 19.5 7 106.4 103.8 102.0 100.9 17.1 18.3 18.9 19.7 12 119.9 117.1 115.8 114.6 17.3 18.6 19.2 20.0 17 131.0 128.0 126.6 125.3 17.5 18.8 19.5 20.2 22 142.5 139.4 137.9 136.4 17.7 19.0 19.8 20.5 27 154.5 151.2 149.6 148.0 18.0 19.3 20.0 20.8 32 167.2 163.6 161.7 160.0 18.3 19.6 20.3 21.1 37 180.8 176.9 174.8 172.9 18.5 19.8 20.5 21.3 42 194.0 189.8 187.5 185.5 18.7 20.0 20.7 21.5 47 213.9 209.0 206.6 204.3 18.9 20.2 20.9 21.7 52 228.5 223.1 220.4 217.8 19.0 20.4 21.1 21.9 57 243.4 237.4 234.5 231.7 19.4 20.8 21.5 22.3 62 262.1 255.5 252.3 249.1 19.9 21.2 21.9 22.7 67 278.3 271.2 267.7 264.1 20.3 21.7 22.4 23.2 72 295.6 288.1 284.3 280.5 20.8 22.2 23.0 23.8

Integrated Heating Capacity (MBh/1000) Total Power in Kilowatts A

At Indicated Indoor Dry Bulb Temp. Indicated Indoor Dry Bulb Temp.

Table PD-18 — 20 Ton Horizontal Three Phase Heating Capacities (Net) WCH240B3, B4, BW at 8000 CFM

Outdoor Temp.

F. 60 70 75 80 60 70 75 80

--8 77.7 75.4 74.5 73.6 15.4 16.4 17.0 17.6

-3 86.3 84.0 82.9 82.0 15.5 16.5 17.1 17.8 2 95.5 93.0 92.0 90.9 15.6 16.7 17.3 18.0 7 105.9 103.2 101.5 100.4 15.8 16.9 17.5 18.2 12 109.9 107.3 106.1 105.0 16.0 17.1 17.8 18.4 17 120.0 117.3 116.1 114.8 16.2 17.3 18.0 18.7 22 130.6 127.7 126.4 125.0 16.4 17.6 18.2 18.9 27 141.6 138.5 137.1 135.6 16.6 17.8 18.5 19.2 32 153.2 149.9 148.2 146.6 16.9 18.1 18.7 19.5 37 179.7 175.9 173.8 172.0 17.6 18.9 19.6 20.4 42 192.9 188.7 186.5 184.5 17.9 19.2 19.9 20.7 47 210.6 205.8 203.4 201.1 18.3 19.6 20.3 21.0 52 225.0 219.6 217.0 214.4 19.0 20.3 21.0 21.8 57 239.6 233.7 230.9 228.0 19.4 20.7 21.4 22.2 62 256.8 250.3 247.2 244.0 19.8 21.1 21.9 22.6 67 272.6 265.7 262.3 258.8 20.3 21.6 22.3 23.1 72 289.6 282.2 278.5 274.8 20.8 22.1 22.9 23.7

Integrated Heating Capacity (MBh/1000) Total Power in Kilowatts At

At Indicated Indoor Dry Bulb Temp. Indicated Indoor Dry Bulb Temp.

PKGP-PRC0 01-EN

Performance Data (12½ - 20 Tons)

Table PD-19— Heating Capacity Correction Factors

% Variation of Nominal CFM - 20 - 10 0 + 10 + 20

Total Gross Capacity Multiplier .96 .98 1.0 1.01 1.02

Table PD-20 — Auxiliary Electric Heat Capacity

Total

Tons Model No. Input

12½, 15 WC

20 WC

Notes:

1. Does not include indoor fan power or heat.

2. Heaters are rated at 240v, 480v. and 600v. For other than rated voltage, CAP =( )2 x rated cap.

Unit KW MBh No. of KW MBh KW MBh

*150B3, B4, BW 36.00 123.00 2 18.00 61.00 18.00 61.00

*180B3, B4, BW 54.00 184.00 2 36.00 123.00 18.00 61.00

* 240B3, B4, BW 54.00 184.00 2 36.00 123.00 18.00 61.00

18.00 61.00 1 18.00 61.00 — —

36.00 123.00 2 18.00 61.00 18.00 61.00

72.00 246.00 2 36.00 123.00 36.00 123.00

Output

Voltage

Rated Voltage

Stages Input

Stage 1 Stage 2

Output

Input

Output

Table PD-21 —Electric Heater Voltage Correction Factors (Applicable to Auxiliary Heat Capacity)

Nominal Distribution Capacity Voltage Voltage Multiplier

240 230 0.92

480 460 0.94

600 575 0.92

208 0.75

240 1.00

440 0.84

480 1.00

540 0.81

600 1.00

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Table PD-22— Air Temperature Rise Across Electric Heaters (Degree F)

12½ Ton 15 Ton 20 Ton

5000 CFM 6000 CFM 8000 CFM

KW Stages WC

9.00 1 — — —

17.30 1 — — —

18.00 1 11.4 9.5 —

27.00 2 — — —

36.00 2 23.0 19.0 14.2

54.00 2 34.1 28.4 21.3

72.00 2 — — 28.5

Three Phase Three Phase Three Phase

*150B WC*180B WC*240B

Table PD-23 — Electric Heater Temperature Rise Correction Factors

% Variation From Nominal CFM - 20 - 15 - 10 - 5 0 +5 +10 +15 +20

Temperature Rise Multiplier 1.25 1.17 1.11 1.05 1.00 0.95 0.91 0.87 0.83

Controls

Field Installed Control Options

Zone Sensors

Zone sensors are the building occupant’s comfort control devices. They replace the conventional electro-mechanical thermostats. The following zone sensor options are available for Voyager units with the ReliaTel™ control:

Manual Changeover

Heat, Cool or Off System Switch. Fan Auto or Off Switch. One temperature setpoint lever.

Manual/Automatic Changeover

Auto, Heat, Cool or Off System Switch. Fan Auto or Off Switch. Two temperature setpoint levers. Optional Status Indication LED lights, System On, Heat, Cool, or Service.

Remote Sensor

Sensor(s) available for all zone sensors to provide remote sensing capabilities.

Dual Thermistor Remote Zone Sensor

This sensor will allow the customer to reduce the total number of remote sensors to obtain space temperature averaging. This sensor should be utilized with ReliaTel controls.

Digital Display Zone Sensor

The Digital LCD (Liquid Crystal Display) zone sensor has the look and functionality of standard zone sensors. This sensor includes a digital display of set point adjustment and space temperature in F (Fahrenheit) or C (Celsius). Includes FAN and SYSTEM buttons (supports the service functions of the standard sensor). E-squared memory stores last programmed set points. Requires 24 VAC (Volts AC). This sensor should be utilized with ReliaTel™ controls.

Programmable Night Setback

Auto or manual changeover with sevenday programming. Keyboard selection of

Heat, Cool, Fan, Auto, or On. All programmable sensors have System On, Heat, Cool, Service LED/indicators as standard. Night Setback Sensors have one (1) Occupied, one (1) Un-occupied, and two (2) Override programs per day.

Integrated Comfort

System

Sensor(s) available with optional temperature adjustment and override buttons to provide central control through a Trane Integrated Comfort

system.

CO2 Sensing

The CO has the ability to

sensor

monitor space occupancy levels within the building by measuring the parts per million of CO

(Carbon

Dioxide) in the air. As the CO increase, the outside air damper

levels

modulates to meet the CO2 space ventilation requirements. The CO kit is available as a field installed

sensor

accessory.

Economizer Controls

The standard equipment offering is a fixed dry bulb changeover control. In addition, there are two optional controls, Enthalpy and Differential Enthalpy Control.

Enthalpy Control

Replaces the dry bulb control with a wet bulb changeover controller which has a fully adjustable set point. Enthalpy control offers a higher level of comfort control, along with energy savings potential, than the standard dry bulb control. This is due to the additional wet bulb sensing capability.

Differential Enthalpy

Replaces the standard dry bulb control with two enthalpy sensors that compare total heat content of the indoor air and outdoor air to determine the most efficient air source. This control option offers the highest level of comfort control, plus energy efficiency, available.

Remote Potentiometer

Minimum position setting of economizer can be remotely adjusted with this accessory.

Differential Pressure Switches

This factory or field-installed option allows individual fan failure and dirty filter indication. The fan failure switch will disable all unit functions and “flash” the Service LED on the zone sensor. The dirty filter switch will light the Service LED on the zone sensor and will allow continued unit operation.

Trane Communication Interface (TCI)

This factory or field-installed microprocessor interface allows the unit to communicate to Trane’s Integrated Comfort

system.

PKGP-PRC0 01-EN

Electrical Data

Table ED-1 — Unit Wiring

Standard Indoor Fan Motor Oversize Indoor Fan Motor

Tons Model No. Voltage Range Ampacity Circuit Breaker

12½ WC

15 WC

20 WC

Note:

1. HACR type circuit breaker per NEC.

Unit Operating Circuit or Maximum Circuit or Maximum

WC*150B3 187-253 66.0 80 72.0 80

*150B4 414-506 31.0 40 34.0 40

*150BW 517-633 25.0 30 28.0 35

WC*180B3 187-253 76.0 90 82.0 100

*180B4 414-506 39.0 45 42.0 50

*180BW 517-633 31.0 35 33.0 40

WC*240B3 187-253 96.0 125 103.0 125

*240B4 414-506 49.0 60 53.0 60

*240BW 517-633 38.0 45 41.0 50

Unit Minimum Maximum Fuse Size Minimum Maximum Fuse Size

Ampacity Circuit Breaker

*Indicates both downflow and horizontal units.

Table ED-2 — Electrical Characteristics — Power Exhaust Accessory

Accessory

Tons Voltage Phase HP RPM FLA LRA

12½, 15, 20

Operating

208-230 1 3/4 1040 6.6 13.5 460 1 3/4 1040 3.2 8.4 575 1 3/4 1040 2.1 5.2

Amps

PKGP-PRC0 01-EN

Electrical Data

Table ED-3 — Unit Wiring With Electric Heat (Single Point Connection)

Standard Indoor Motor Oversize Indoor Motor

Tons With Model No. KW Rating1Stages MCA Max Circuit Breaker

12½

Notes:

1. Heater kw ratings are at 208/240 for 208/230V unit 480V for 460 V unit

2. HACR type circuit breaker per NEC.

To Use Heater Heater Control Max Fuse Size or Max Fuse Size or

208/230 Volts Three Phase

AYDHTRK318A 13.5/18.0 1 113/120 125/125 119/127 125/150

WCD150B3 AYDHTRK336A 27.0/36.0 2 160/175 175/175 166/181 175/200

AYDHTRK354A 40.5/54.0 2 207/229 225/250 213/235 225/250

AYHHTRN318A 13.5/18.0 1 113/120 125/125 119/127 125/150

WCH150B3 AYHHTRP336A 27.0/36.0 2 160/175 175/175 166/181 175/200

AYHHTRP354A 40.5/54.0 2 207/229 225/250 213/235 225/250

AYDHTRK318A 13.5/18.0 1 122/130 125/150 129/136 150/150

WCD180B3 AYDHTRK336A 27.0/36.0 2 169/184 175/200 175/190 175/200

AYDHTRK354A 40.5/54.0 2 216/238 225/250 222/244 225/250

AYHHTRN318A 13.5/18.0 1 122/130 125/150 129/136 150/150

WCH180B3 AYHHTRP336A 27.0/36.0 2 169/184 175/200 175/190 175/200

AYHHTRP354A 40.5/54.0 2 216/238 225/250 222/244 225/250

AYDHTRL336A 27.0/36.0 2 190/204 200/225 197/212 200/225

WCD240B3 AYDHTRL354A 40.5/54.0 2 237/258 250/300 244/266 250/300

AYDHTRK372A 54.0/72.0 2 284/312 300/350 291/320 300/350

AYHHTRN336A 27.0/36.0 2 190/204 200/225 197/212 200/225

WCH240B3 AYHHTRN354A 40.5/54.0 2 237/258 250/300 177/266 250/300

AYHHTRN372A 54.0/72.0 2 284/312 300/350 224/320 300/350

MCA Max Circuit Breaker

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Electrical Data

Table ED-3 — Unit Wiring With Electric Heat (Single Point Connection, Continued)

Standard Indoor Motor Oversize Indoor Motor

Tons With Model No. KW Rating1Stages MCA Max Circuit Breaker

12½

Notes:

1. Heater kw ratings are at 480V for 460V unit

2. HACR type circuit breaker per NEC.

To Use Heater Heater Control Max Fuse Size or Max Fuse Size or

460 Volts Three Phase

AYDHTRK418A 18.0 1 58 60 61 70

WCD150B4 AYDHTRK436A 36.0 2 85 90 88 90

AYDHTRK454A 54.0 2 112 125 115 125

AYHHTRP418A 18.0 1 58 60 61 70

WCH150B4 AYHHTRP436A 36.0 2 85 90 88 90

AYHHTRP454A 54.0 2 112 125 115 125

AYDHTRK418A 18.0 1 66 70 69 70

WCD180B4 AYDHTRK436A 36.0 2 93 100 96 100

AYDHTRK454A 54.0 2 120 125 123 125

AYHHTRP418A 18.0 1 66 70 69 70

WCH180B4 AYHHTRP436A 36.0 2 93 100 96 100

AYHHTRP454A 54.0 2 120 125 123 125

AYDHTRL436A 36.0 2 104 110 107 110

WCD240B4 AYDHTRL454A 54.0 2 131 150 134 150

AYDHTRK472A 72.0 2 158 175 161 175

AYHHTRN436A 36.0 2 104 110 107 110

WCH240B4 AYHHTRN454A 54.0 2 131 150 134 150

AYHHTRN472A 72.0 2 158 175 161 175

MCA Max Circuit Breaker

PKGP-PRC0 01-EN

Electrical Data

Table ED-3 — Unit Wiring With Electric Heat (Single Point Connection, Continued)

Standard Indoor Motor Oversize Indoor Motor

Tons With Model No. KW Rating1Stages MCA Max Circuit Breaker

12½

Notes:

1. Heater kw ratings are at 600V for 575V unit

2. HACR type circuit breaker per NEC.

To Use Heater Heater Control Max Fuse Size or Max Fuse Size or

575 Volts Three Phase

AYDHTRKW18A 18.0 1 47 50 49 50

WCD150BW AYDHTRKW36A 36.0 2 69 70 71 80

AYDHTRKW54A 54.0 2 90 90 93 100

AYHHTRNW18A 18.0 1 47 50 49 50

WCH150BW AYHHTRQW36A 36.0 2 69 70 71 80

AYHHTRPW54A 54.0 2 90 90 93 100

AYDHTRKW18A 18.0 1 52 60 54 60

WCD180BW AYDHTRKW36A 36.0 2 74 80 76 80

AYDHTRKW54A 54.0 2 96 100 98 100

AYHHTRNW18A 18.0 1 52 60 54 60

WCH180BW AYHHTRQW36A 36.0 2 74 80 76 80

AYHHTRPW54A 54.0 2 96 100 98 100

AYDHTRLW36A 36.0 2 81 90 84 90

WCD240BW AYDHTRLW54A 54.0 2 103 110 106 110

AYDHTRKW72A 72.0 2 125 125 128 150

AYHHTRNW36A 36.0 2 81 90 84 90

WCH240BW AYHHTRNW54A 54.0 2 103 110 106 110

AYHHTRNW72A 72.0 2 125 125 128 150

MCA Max Circuit Breaker

PKGP-PRC0 01-EN

Electrical Data

Table ED-4 — Electrical Characteristics — Evaporator Fan Motors — 60 Cycle

Standard Evaporator Fan Motor Oversized Evaporator Fan Motor

Tons Model No. No. Volts Phase HP FLA LRA No. Volts Phase HP FLA LRA

12½ WC

15 WC

20 WC

Unit

WC*150B3 1 208-230 3 3.00 10.6 81.0 1 208-230 3 5.00 16.7 109.8

*150B4 1 460 3 3.00 4.8 40.5 1 460 3 5.00 7.6 54.9

*150BW 1 575 3 3.00 3.9 31.0 1 575 3 5.00 6.1 41.6

WC*180B3 1 208-230 3 3.00 10.6 81.0 1 208-230 3 5.00 16.7 109.8

*180B4 1 460 3 3.00 4.8 40.5 1 460 3 5.00 7.6 54.9

*180BW 1 575 3 3.00 3.9 31.0 1 575 3 5.00 6.1 41.6

WC*240B3 1 208-230 3 5.00 16.7 109.8 1 208-230 3 7.50 17.6 120.4

*240B4 1 460 3 5.00 7.6 54.9 1 460 3 7.50 8.6 74.0

*240BW 1 575 3 5.00 6.1 41.6 1 575 3 7.50 7.0 60.0

Amps Amps

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Electrical Data

Table ED-5 — Electrical Characteristics — Compressor Motor And Condenser Motor — 60 Cycle

Tons Model No. No. Volts Phase HP

Unit

12½ WC

*150B3 2 208-230 3 6.00 3450 21.7 156 2 1 .50 3.2 8.8 *150B4 2 460 3 6.00 3450 10.0 75 2 1 .50 1.6 4.0

RPM RLA LRA No. Phase HP FLA LRA

WC*150BW 2 575 3 6.00 3450 8.2 54 2 1 .50 1.3 3.2 WC

15 WC

*180B3 2 208-230 3 5.70/9.00 3450/3500 30.1/20.4 225/156 2 1 .50 3.2 8.8 *180B4 2 460 3 5.70/9.00 3450/3500 15.6/10.8 114/75 2 1 .50 1.6 4.0

WC*180BW 2 575 3 5.70/9.00 3450/3500 12.1/8.5 80/54 2 1 .50 1.3 3.2 WC

20 WC

Notes: 1 Amp draw for each motor; multiply value by numbers of motors to determine total amps.

2. HP for each compressor.

*240B3 2 208-230 3 9.00 3500 30.1 225 2 1 1.00 5.5 18.3 *240B4 2 460 3 9.00 3500 15.8 114 2 1 1.00 2.9 9.3

WC*240BW 2 575 3 9.00 3500 12.2 80 2 1 1.00 2.0 5.7

Amps

Condenser Fan MotorsCompressor Motors

Amps

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Jobsite Connections

DISCONNECT

SWITCH

(BY OTHERS)

ZONE SENSORS

For specific wiring information, see the installation instructions. All wiring except power wires is low voltage. All customer supplied wiring to be copper and must conform to NEC or CEC and local electrical codes. Wiring shown dotted is to be furnished and installed by the customer.

ROOFTOP

UNIT

Zone Sensors —Typical Number Of Wires

A— Manual Changeover ....................................... 6

Manual/Auto Changeover ............................... 7

Manual/Auto Changeover with

Status Indication LED’s ........................... 10

Programmable Night Setback with

Status Indication LED’s ............................. 7

B— 3 Power Wires + 1 Ground Wire (three phase)

2 Power Wires + 1 Ground Wire (single phase)

PKGP-PRC0 01-EN

Typical Wiring (12½ - 20 Tons)

PKGP-PRC0 01-EN

Typical Wiring (12½ - 20 Tons)

PKGP-PRC0 01-EN

Typical Wiring

(12½ - 20 Tons)

PKGP-PRC0 01-EN

Typical Wiring

(12½ - 20 Tons)

PKGP-PRC0 01-EN

Dimensional

All dimensions are in inches.

Data

(12½, 15 Ton)

Note: Duct flanges mount 7-7/16" down inside the curb on the 1½" curb flanges. See recommended duct dimensions on the next page. Roofcurb is intended for downflow use only.

Downflow Unit Clearance

PKGP-PRC0 01-EN

Dimensional

All dimensions are in inches.

Downflow Duct Connections — Field Fabricated

7 7/16"

Data

14 1/16"

59 7/16"

RETURN

17 7/8"

52 1/2"

(12½, 15 Ton)

26 5/16"

SUPPLY

1 1\2" PERIMETER CURB FLANGE

Note: Duct flanges mount 7-7/16" down inside the curb on the 1½" curb flanges. Roofcurb is intended for downflow use only.

Horizontal Unit Supply/Return and Unit Clearance

PKGP-PRC0 01-EN

All dimensions are in inches.

Dimensional Data (20 Ton)

Note: Duct flanges mount 7-7/16" down inside the curb on the 1½" curb flanges. See recommended duct dimensions on the next page. Roofcurb is intended for downflow use only.

Downflow Unit Clearance

PKGP-PRC0 01-EN

Dimensional

RETURN

SUPPLY

1 1\2" PERIMETER CURB FLANGE

73 7/16"

19 5/16"

26 5/16"

66 1/2"

14 1/16"

7 7/16"

All dimensions are in inches.

Downflow Duct Connections — Field Fabricated

Data

(20 Ton)

Note: Duct flanges mount 7-7/16" down inside the curb on the 1½" curb flanges. Roofcurb is intended for downflow use only.

Horizontal Unit Supply/Return and Unit Clearance

PKGP-PRC0 01-EN

Dimensional

(12½ - 20 Tons)

All dimensions are in inches.

Data

Accessories

Note: When applying economizer to horizontal units, connecting ductwork must be run full size to allow proper operation of Economizer Damper.

Table DD-1

Tons A B

12½, 15 171/2 53¾ 36 20 19

Notes:

1. Horizontal dimension only. Downflow economizer is width of end panel.

2. Power exhaust is applied on downflow economizer only.

/2 64¾ 39

PKGP-PRC0 01-EN

Dimensional

Factory Installed

All dimensions are in inches.

Data

Options (FIOPS)

Table DD-2

Unit Model # A B C

WCD150-180 42 WCD240 291/2 56 381/2

PKGP-PRC0 01-EN

Dimensional

Factory Installed

Hinged Access Door

Data

Fan Failure Switch

Clogged Filter Switch

Options (FIOPS)

Disconnect Switch or Circuit Breaker

Powered Or Unpowered Convenience Outlet

Trane Communication Interface

Supply and/or Return Smoke Detectors

Black Epoxy Coated Outdoor Coils

Hinged Access Door

Through the Base Electrical

High Pressure Cut Out

PKGP-PRC0 01-EN

Dimensional Data (12½ - 20 Tons)

Table DD-3 — 12½-20 Tons

TonsTons

Tons

TonsTons

ABCDF G H E JEK

12½, 15 26 20 26

PKGP-PRC0 01-EN

22 28

11/

15/

Downflow OnlyDownflow Only

Downflow Only

Downflow OnlyDownflow Only

Condensate Drain LocationCondensate Drain Location

Condensate Drain Location

Condensate Condensate

Condensate

Condensate Condensate Drain Size Drain Size

Drain Size

Drain Size Drain Size

62 76

54 68

11/

1 NPT — 25 1 NPT — 26

Condensate Drain LocationCondensate Drain Location

DownflowDownflow

Downflow

DownflowDownflow

Horizontal Horizontal

Horizontal

Horizontal Horizontal

—5 —5

Weights (12½ - 20 Tons)

Table W-1 — Accessory Net Weights (Lbs)

Economizer

Unit Power Roof Motor Static

Tons Model No. Net Ship Manual Motorized Exhaust

Outside Air Damper Oversized High

Curb

Adder Drive

12½,15 WCD150,180B 65 205 32 60 95 205 5 10/NA 20 WCD240B 80 265 32 75 95 235 5 10

12½,15 WCH150,180B 50 150 32 60 — — 5 10/NA 20 WCH240B 65 210 32 75 — — 5 15

Table W-1 — (Continued)

Electric Heaters

Tons Model No. Sensors 240/480V

Unit All Zone 5-18 kW 23-36 kW 54 kW 72 kW

12½,15 WCD150,180B 1 28/21 31/27 38/32 — 20 WCD240B 1 — 33/27 40/32 43/34

12½,15 WCH150,180B 1 28/21 31/27 38/32 — 20 WCH240B 1 — 33/27 40/32 43/34

Notes:

1. Net weight should be added to unit weight when ordering factory installed economizer or oversize motor.

2. For 600V heaters net weights are same as 480V heaters.

3. To estimate shipping weight add 5 lbs to net weight.

4. Downflow only.

2 3

240/480V

2 3

240/480V

2 3

240/480V

2 3

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Weights

(12½ - 20 Tons)

Table W- 2 — Maximum Unit Weights, Corner Weights (Lbs) And Center Of Gravity Dimensions (In.)

Tons Model No. Shipping Net A B C D Length Width

12½ WC*150 1719 1351 465 344 231 311 46 29 15 WC 20 WC*240 2467 2008 707 510 331 460 51 34

Note:

1. Corner weights are given for information only. 12½-20 ton models must be supported continuously by a curb or equivalent frame support.

Unit Maximum Weights (Lbs) Corner Weights (Lbs)

*180 1860 1492 678 227 383 204 44 28

Center of Gravity (In.)

*Indicates both downflow and horizontal units.

PKGP-PRC0 01-EN

Table W-3 — Factory Installed Options (FIOPS) Net Weights (Lbs)

Accessory Weight Unit Model Number High Efficiency Motors

Hinged Doors 27 All WC* units

Powered Convenience Outlet 38 All WC* units

Through the Base Electrical 23 All WC* units

Unit Mounted Circuit Breaker 5 All WC* units except those with 54&72 kW heaters

Unit Mounted Disconnect 5 All WC* units except those with 54&72 kW heaters

Smoke Detectors

Supply/Return 5 All WC* units

Tool-less Hail Guard 38 WC*150,180

Notes:

1. Weights for FIOP accessories not listed are >5 lbs.

2. Net weight should be added to unit weight when ordering factory installed accessories.

3. See Table W-1 for standard factory installed economizer and oversized motors.

4. Standard factory installed motors are already included in unit net and shipping weights. Values shown for high efficiency motors are in addition to the standard motor weight.

49 WC*150-180 standard size motor

0 WC*210-240 oversize motor

10 All WC* units with 54&72 kW heaters & 208/230V

43 WC*240

WC*210-240 standard size motor WC*150-180 oversize motor

& 208/230V

1,2,3

Mechanical Specifications

General

The units shall be dedicated downflow or horizontal airflow. The operating range shall be between 115°F and 0°F in cooling as standard from the factory for all units. Cooling performance shall be rated in accordance with ARI testing procedures. All units shall be factory assembled, internally wired, fully charged with R-22, and 100 percent run tested to check cooling operation, fan and blower rotation and control sequence, before leaving the factory. Wiring internal to the unit shall be colored and numbered for simplified identification. Units shall be UL listed and labeled, classified in accordance to UL 1995/CAN/CSA No. 236-M90 for Heat Pumps. Canadian units shall be CSA Certified.

Casing

Unit casing shall be constructed of zinc coated, heavy gauge, galvanized steel. Exterior surfaces shall be cleaned, phosphatized, and finished with a weather-resistant baked enamel finish. Unit’s surface shall be tested 500 hours in a salt spray test in compliance with ASTM B117. Cabinet construction shall allow for all maintenance on one side of the unit. In order to ensure a water and air tight seal, service panels shall have lifting handels and no more thatn three screws to remove. All exposed vertical panels and top covers in the indoor air section shall be insulated with a 1/2 inch, 1 pound density foil-faced, fire-resistant, permanent, odorless, glass fiber material. The base of the downflow unit shall be insulated with 1/2 inch, 1 pound density foil-faced, closed-cell material. The downflow unit’s base pan shall have no penetrations within the perimeter of the curb other than the raised 1 supply/return openings to provide an added water integrity precaution, if the condensate drain backs up. The base of the unit shall have provisions for forklift and crane lifting.

/8 inch high

Unit Top

The top cover shall be one piece, or where seams exist, double hemmed and gasket sealed to prevent water leakage.

Filters

Two inch standard filters shall be factory supplied on all units. Optional two inch pleated media filters shall be available.

Compressors

External high pressure cutout shall be provided on all 15 and 20 models. Low pressure switches shall be standard. All units shall have direct-drive, hermetic, scroll type compressors with centrifugal type oil pumps. Motor shall be suction gas-cooled and shall have a voltage utilization range of plus or minus 10 percent of nameplate voltage. Internal overloads shall be provided with the scroll compressors. Crankcase heaters shall be utilized with all scroll compressors.

Refrigerant Circuits

Each refrigerant circuit shall have independent fixed orifice or thermostatic expansion devices, service pressure ports, and refrigerant line filter driers factory installed as standard. An area shall be provided for replacement suction line driers.

Evaporator and Condenser Coils

Internally finned, 3/8" copper tubes mechanically bonded to a configured aluminum plate fin shall be standard. Coils shall be leak tested at the factory to ensure the pressure integrity. The evaporator coil and condenser coil shall be leak tested to 200 psig and pressure tested to 450 psig. All dual compressor units shall have intermingled evaporator coils. Sloped condensate drain pans are standard. Patent-pending 1+1+1 condenser coil, permanently gapped for easy cleaning is available.

Outdoor Fans

The outdoor fan shall be direct-drive, statically and dynamically balanced, draw-through in the vertical discharge position. The fan motor(s) shall be permanently lubricated and shall have built-in thermal overload protection.

Indoor Fan

Units above shall have belt driven, FC centrifugal fans with adjustable motor sheaves. Units with standard motors shall have an adjustable idler-arm assembly for quick-adjustment of fan belts and motor sheaves. All motors shall be thermally protected. Oversized motors shall be available for high static application. All indoor fan motors meet the U.S. Energy Policy Act of 1992 (EPACT).

Controls

Unit shall be completely factory wired with necessary controls and contactor pressure lugs or terminal block for power wiring. Unit shall provide an external location for mounting a fused disconnect device. ReliaTel controls shall be provided for all 24 volt control functions. The resident control algorithms shall make all heating, cooling, and/or ventilating decisions in response to electronic signals from sensors measuring indoor and outdoor temperatures. The control algorithm maintains accurate temperature control, minimizes drift from set point, and provides better building comfort. A centralized control shall provide anti-short cycle timing and time delay between compressors to provide a higher level of machine protection.

Defrost Controls

Adaptive demand defrost shall be provided to permit defrost wherever coil icing conditions begin to significantly reduce unit capacity.

PKGP-PRC0 01-EN

Mechanical Specifications

Factory Installed Options

Black Epoxy Pre-Coated Coils

The black epoxy coils have a thermoset vinyl coating that is bonded to the aluminum fin stock prior to the finstamping process. The pre-coated coils are an economical option for protection in mildly corrosive environments.

Hinged Access Doors

Sheet metal hinges are available on the Filter/Evaporator Access Door and the Compressor/Control Access Door. This option is available on all downflow models.

High Efficiency Motors

This option is available with efficiency ratings from 86.5 up to 91.0. It is not available for all models.

High Pressure Cutout

This option is offered for units that do not have High Pressure cutout as standard. The Voyager units with High Pressure Cutout as standard are WC*180-240B.

Powered or Unpowered Convenience Outlet

This option is a GFCI, 120v/15amp, 2 plug, convenience outlet, either powered or unpowered. When the convenience outlet is powered, a service receptacle disconnect will be available. The convenience outlet is powered from the line side of the disconnect or circuit breaker, and therefore will not be affected by the position of the disconnect or circuit breaker. This option can only be ordered when the Through the Base Electrical with either the Disconnect Switch, or Circuit Breaker, option is ordered. This option is available on all downflow models.

Supply and/or Return Air Smoke Detector

With this option installed, if smoke is detected, all unit operation will be shut down. Reset will be manual at the unit. Return Air Smoke Detectors require minimum allowable airflow when used with certain models. See the Installation, Operation, and Maintenance (IOM) manual for the models affected and the minimum allowable airflow required. This option is available on all downflow models.

Through the Base Electrical with Circuit Breaker

This option is a thermal magnetic, molded case, HACR Circuit Breaker with provisions for through the base electrical connections. The circuit breaker will be installed in a water tight enclosure in the unit with access through a swinging door. Factory wiring will be provided from the switch to the unit high voltage terminal block. The circuit breaker will provide overcurrent protection, be sized per NEC and UL guidelines, and be agency recognized by UL/CSA. This option is available on all downflow models.

Through the Base Electrical With Disconnect Switch

Three-pole, molded case, disconnect switch with provisions for through the base electrical connections are available. The disconnect switch will be installed in the unit in a water tight enclosure with access through a swinging door. Factory wiring will be provided from the switch to the unit high voltage terminal block. The switch will be UL/CSA agency recognized. Note: The disconnect switch will be sized per NEC and UL guidelines but will not be used in place of unit overcurrent protection. This option is available on all downflow models.

Through the Base Utilities Access

Two-Inch Pleated Filters

Two inch pleated media filters shall be available on all models.

PKGP-PRC0 01-EN

Mechanical Specifications

Factory or Field Installed Options

Clogged Filter/Fan Failure Switch

A dedicated differential pressure switch is available to achieve active fan failure indication and/or clogged filter indication. These indications will be registered with either a zone sensor with status indication lights or an Integrated Comfort™ System.

Differential Pressure Switches

These options allow for individual fan failure and dirty filter indication. The fan failure switch will disable all unit functions and “flash” the Service LED on the zone sensor. The dirty filter switch will light the Service LED on the zone sensor and will allow continued unit operation.

Discharge Air Sensing Kit

This kit provides true discharge air sensing in heating models. This sensor is a status indicator readable through Tracer™or Tracker™. The kit is functional only with the ReliaTel Options Module.

Economizer - Downflow

The assembly includes fully modulating 0-100 percent motor and dampers, barometric relief, minimum position setting, preset linkage, wiring harness with plug, fixed dry bulb and spring return actuator. The barometric relief damper shall be standard with the downflow economizer and shall provide a pressure operated damper that shall be gravity closing and shall prohibit entrance of outside air during the equipment “off” cycle. Solid state enthalpy and differential enthalpy control shall be field-installed

Electric Heaters

Electric heat modules shall be available for installation within the basic unit. Electric heater elements shall be constructed of heavy-duty nickel chromium elements internally delta connected for 240 volt, wye connected for 480 and 600 volt. Staging shall be achieved through ReliaTel. Each heater package shall have automatically reset high limit control operating through heating element contactors. All heaters shall be individually fused from the factory, where required, and shall meet all NEC and CEC requirements when properly installed. Power assemblies shall provide single-point connection. Electric heat modules shall be UL listed or CSA certified. If ordering the Through the Base Electrical option with an Electric Heater, the heater must be factory installed.

Frostat

This option is to be utilized as a safety device. The Frostat opens when temperatures on the evaporator coil fall below 10°F. The temperature will need to rise to 50°F before closing. This option should be utilized in low airflow or high outside air applications.

LonTalk® Communications Interface

The LonTalk communications interface, when installed in a Voyager unit, allows the unit to communicate as a Tracer™LCIV device or directly with generic LonTalk Network Building Automation System Controls.

Oversized Motors

Oversized motors shall be available for high static applications.

Reference or Comparative Enthalpy

Reference Enthalpy is used to measure and communicate outdoor humidity. The unit receives and uses this information to provide improved comfort cooling while using the economizer. Comparative Enthalpy measures and communicates humidity for both outdoor and return air conditions, and return air temperature. The unit receives and uses this information to maximize use of economizer cooling, and to provide maximum occupant comfort control. Reference or Comparative Enthalpy option shall be available when a factory or field installed Downflow Economizer is ordered. This option is available on all downflow models.

Tool-less Hail Guards

Tool-less, hail protection quality coil guards are available for condenser coil protection.

Trane Communication Interface

This factory or field-installed option shall be provided to interface ReliaTel™ controlled units with the Trane Integrated Comfort

systems.

PKGP-PRC0 01-EN

Mechanical Specifications

Field Installed Options

CO2 Sensing

The CO2 sensor has the ability to monitor space occupancy levels within the building by measuring the parts per million of CO As the CO2 levels increase, the outside air damper modulates to meet the CO space ventilation requirements.

Digital Display Zone Sensor

Dual Thermistor Remote Zone Sensor

This sensor will allow the customer to reduce the total number of remote sensors to obtain space temperature averaging. This sensor should be utilized with ReliaTel controls.

High Static Drive

The high static drive option shall allow the standard motor on the 12½ and 20 ton units to operate with improved external static capabilities.

Manual Outside Air Damper

The rain hood and screen shall provide up to 25 percent outside air.

Motorized Outside Air Dampers

Manually set outdoor air dampers shall provide up to 50 percent outside air. Once set, outdoor air dampers shall open to set position when indoor fan starts. The damper shall close to the full closed position when indoor fan shuts down.

(Carbon Dioxide) in the air.

Powered Exhaust

The powered exhaust shall provide exhaust of return air, when using an economizer, to maintain better building pressurization.

Roof Curb - Downflow

The roof curb shall be designed to mate with the downflow unit and provide support and a water tight installation when installed properly. The roof curb design shall allow field-fabricated rectangular supply/return ductwork to be connected directly to the curb. Curb design shall comply with NRCA requirements. Curb shall be shipped knocked down for field assembly and shall include wood nailer strips.

Economizer - Horizontal

The horizontal economizer shall contain the same features as the downflow economizer with the exception of barometric relief.

Remote Potentiometer

The minimum position setting of the economizer shall be adjusted with this accessory.

Ventilation Override Accessory

With the Ventilation Override Accessory installed, the unit can be set to transition up to 3 different pre-programmed sequences for Smoke Purge, Pressurization, and Exhaust. The transition occurs when a binary input on the RTOM is closed (shorted). This would typically be a hard wired relay output from a smoke detector or fire control panel.

Zone Sensors

This option shall be provided to interface with the Micro equipped Voyagers and shall be available in either manual, automatic, programmable with night setback, with system malfunction lights or remote sensor options.

PKGP-PRC0 01-EN

Trane A business of American Standard Companies www.trane.com

For more information contact your local dealer (distributor), local district office, or e-mail us at comfort@trane.com

Literature Order Number

File Number

Supersedes

Stocking Location

PKGP-PRC0 01-EN

PL-UN-PKGP-WCD/WCH12½-20TONS-PRC001-EN 09-04

PKGP-PRC001-EN 05-04

09-04 Webb/Mason

Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice.

Trane WCH150B3, WCD150B3, WCH150B4, WCH150BW, WCD240B3 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
