TP-Link RE605X User Manual

AX1800 Wi-Fi 6
Range Extender

Works With Any
Wi-Fi Router

RE605X

‡

Wi-Fi 6

Dead-Zone Killer

Connect

More Devices

Uninterrupted

△

Streaming

§

Faster

Wi-Fi 6 Speed

Easy Setup

Within Minutes

Highlights

Extend AX1800 Wi-Fi to Your Whole Home

Works with any Wi-Fi router to eliminate Wi-Fi dead zones, and blanket your

home with stable, super-fast, seamless Wi-Fi via OneMeshTM .

Faster Wi-Fi 6 Speed

Turbocharge your devices with wireless speeds of up to 1.8 Gbps.

Larger Capacity△

Wi-Fi 6 builds a more ecient network that increases the average

throughput by 4 times and servers more devices.

Ultra-Low Latency

Take advantage of ultra-low latency to enjoy smoother online experience.

Save Clients’ Battery Power*

4k

Wi-Fi Coverage

Target Wake Time schedules the connection time of battery-powered

devices to reduce their power consumption.

RE605X

Adaptive Path Selection

INTERNET

Keep your network running at top-speed by automatically choosing the

fastest connection path to the router.

Access Point Mode

Create a new Wi-Fi access point to enhance your wired network with

Wi-Fi capability.

Easy Setup Within Minutes

Ethernet Cable

Easy setup and management via WPS button/Tether app/Web UI.

TP-Link AX1800 Wi-Fi 6 Range Extender

RE605X

Highlights

OneMesh

TM

RE605X is more than a traditional range extender. It creates a Mesh network

by connecting to a OneMesh

Wi-Fi Dead-Zone Killer

Eliminate weak signal areas with Wi-Fi coverage for the whole house.

Smart Roaming

TM

router for seamless whole-home coverage.

Wi-Fi 6 Range Extender

Enjoy uninterrupted streaming, surng, and more—even when moving

around your home.

One Wi-Fi Name

Stay connected to the same network name in every room.

Easy Setup and Unied Management

Push the WPS button to set up a Mesh network you can manage from

the Tether app or web UI.

Check more info about OneMesh technology and full list of OneMesh
extenders/routers at: https://www.tp-link.com/onemesh/re605x

*More compatible devices coming soon

PC

Secure One-touch Connection (WPS)

Instantly connect the extender to a router without

inference conguration.

Smart Signal Indicator

See signal to nd the best spot to extend Wi-Fi.

· Strong signal

· Weak signal

Gigabit Ethernet Port

Plug in to give wired device network access,

particularly ideal for high bandwidth consuming

devices.

4K

Smart TVGame Console

TP-Link AX1800 Wi-Fi 6 Range Extender

RE605X

Features

Ease of Use

· Intuitive Web UI– Ensures quick and simple installation without

hassle

· Fast Encryption – One-touch WPA wireless security encryption

with the WPS button

· Hassle-free Management with Tether App – Network

management is made easy with the TP-Link Tether App,
available on any Android or iOS device

· Online Upgrade – Keeps you informed of the latest rmware

and allows online updating on the web UI

Speed

· Ultimate Wireless Speed – Combined wireless speeds of up to

†

574 Mbps (over 2.4 GHz) and 1201 Mbps (over 5 GHz)

· Support Wi-Fi 6 – Turbocharge your devices with wireless

speeds of up to 1.8 Gbps

· Adaptive Path Selection – Keep your network running at

top-speed by automatically choosing the fastest connection
path to the router

Reliability

· Simultaneous Dual Band – Separate Wi-Fi bands enable more

devices to connect to your network without a drop in
performance

· Reliable Connection – Internal antennas for optimal Wi-Fi

coverage and reliable wireless connections

· Ultra-Low Latency – Take advantage of ultra-low latency to enjoy

smoother online experience

TP-Link AX1800 Wi-Fi 6 Range Extender

RE605X

Specications

Hardware

· Button: WPS Button, Reset Button

· Port: 1 Gigabit Ethernet Port

· Antenna: 2 External Antennas

· Power Consumption: 10W

· Dimensions (W × D × H): 2.9×1.8×4.9 in. (74.0×46×124.8 mm)

Wireless

· Wireless Standards: IEEE 802.11a/n/ac/ax 5 GHz, IEEE

802.11b/g/n/ax 2.4 GHz

· Frequency: 2.4 GHz and 5 GHz

· Signal Rate: 574 Mbps at 2.4 GHz, 1201 Mbps at 5 GHz

· Transmit Power: CE: 2.4 GHz ≤15dBm, 5 GHz ≤21dBm

· Reception Sensitivity:

5 GHz:

11ax HE80 MCS0: -87dBm, 11ax HE80 MCS11: -56dBm

11a 6Mbps: -93dBm, 11a 54Mbps: -75dBm

11ac HT20 MCS0: -92dBm, 11ac HT20 MCS8: -70dBm

11ac HT40 MCS0: -90dBm, 11ac HT40 MCS9: -66dBm

Others

· Certication

CE, RoHS

· System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or

Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux

Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari

4.0, or other Java-enabled browser

· Package Contents

Wi-Fi Range Extender RE605X

Quick Installation Guide

11ac HT80 MCS0: -87dBm, 11ac HT80 MCS9: -62dBm

LEDs

Reset Button

2.4 GHz:

11ax HE40 MCS0: -93dBm, 11ax HE40 MCS11: -63dBm

WPS Button

11g 54Mbps: -77dBm, 11n HT20 MCS7: -75dBm

Plug

11n HT40 MCS7: -72dBm

· Wireless Function: Enable/Disable Wireless Radio,

Wireless Statistics

Ethernet Port

· Wireless Security: 64/128-bit WEP, WPA/WPA2-PSK

encryptions

For more information, please visit

https://www.tp-link.com/home-networking/range-extender/re605x/

or scan the QR code left

Attention: This device may only be used indoors in all EU member states and EFTA countries.

Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies CO., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2020 TP-Link Technologies Co., Ltd. All rights reserved.

†

Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage per ft² are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials,

obstacles, volume and density of trac, and client location.

‡

The product may not be compatible with routers or gateways with rmware that has been altered, is based on open source programs, or is non-standard or outdated.

§

Smart Roaming is designed for devices that support the 802.11k/v standard.

△

Up to 4x Capacity refers to 4x increase in median throughput under dense environment compared to 11ac wave 2 range extender.

*Saving clients' battery power requires clients to also support the 802.11ax Wi-Fi standard. Actual power reduction may vary as a result of network conditions, client limitations, and environmental factors.
