AC1750 Wi-Fi
Range Extender
Extend Powerful AC1750 Wi-Fi to
Your Whole Home
RE450
450Mbps+
1300Mbps
Gigabit
Port
Tether
App
Easy
Setup
Highlights
Extend Powerful AC1750 Wi-Fi to
Your Whole Home
The AC1750 Wi-Fi Range Extender connects to your router wirelessly,
strengthening and expanding its signal into areas it can’t reach on its own,
achieving speeds of 450Mbps on the 2.4GHz band and 1300Mbps on the
5GHz band.
Perfect Location at a Glimpse
An Intelligent Signal light helps you quickly nd the best location to install the
range extender.
INTERNET
4k
RE450
Existing Router Coverage
ROUTER
Expanded Extender Coverage
Good
connection
Too far away
from the router
TP-Link AC1750 Wi-Fi Range Extender
RE450
Features
Ease of Use
· Intuitive Web UI– Ensures quick and simple installation without
hassle.
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Easy On/O – LED On/O button allows users to turn LED on or
o
· Power On/O – Conveniently power on or o your extender as
required
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android or iOS device
Speed
· Ultimate Wireless Speed – Combined wireless speeds of up to
450Mbps (over 2.4GHz) and 1300Mbps (over 5GHz)
· Support 802.11 ac – Provides a data transfer rate 3 times
faster than 802.11n for each stream
Reliability
· Simultaneous Dual Band – Separate Wi-Fi bands enable more
devices to connect to your network without a drop in
performance
· Reliable Connection – Three adjustable external antennas for
optimal Wi-Fi coverage and reliable wireless connections
· Online Upgrade – Keeps you informed of the latest rmware and
allows online updating on the web UI
TP-Link AC1750 Wi-Fi Range Extender
RE450
Specications
Hardware
· Ethernet Port: 1 10/100/1000Mbps RJ45 Port
· Button: WPS Button, Reset Button, LED On/O Button,
Power On/O Button
· Antenna: 3 External Antennas
· Power Consumption: <13W
· Dimensions (W × D × H):
3.4×1.1×6.4 in. (86.4×29×163 mm)
Wireless
· Wireless Standards: IEEE 802.11a/n/ac 5GHz, IEEE
802.11b/g/n 2.4GHz
· Frequency: 2.4GHz and 5GHz
· Signal Rate: 450Mbps at 2.4GHz, 1300Mbps at 5GHz
· Transmit Power:
CE: <20dBm (2.4GHz), <23dBm (5GHz band1)
· Reception Sensitivity:
5GHz:
11a 6Mbps: -94dBm, 11a 54Mbps: -76dBm
2.4GHz:
Others
· Certication
CE, RoHS
· System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or
Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari
4.0, or other Java-enabled browser
· Package Contents
AC1750 Wi-Fi Range Extender RE450
Quick Installation Guide
11g 6Mbps: -90dBm, 11g 54Mbps: -76dBm,
11n HT20 MCS7: -73dBm, 11n HT40 MCS7: -70dBm
· Wireless Function: Enable/Disable Wireless Radio,
Wireless Statistics
· Wireless Security: 64/128-bit WEP, WPA/WPA2,
WPA/WPA2-PSK encryptions
For more information, please visit
http://www.tp-link.com/en/products/details/RE450.html
or scan the QR code left
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies CO., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2019 TP-Link Technologies Co., Ltd. All rights reserved.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network
conditions, including local interference, volume and density of trac, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.
www.tp-link.com
