User Guide
Kasa Smart Wi-Fi Outdoor Plug
KP400
1910012470 REV1.0.0
Contents
About This Guide····················································· 1
Introduction································································ 2
Appearance································································ 3
Set Up Your Smart Plug······································· 4
Main Device Controls············································ 5
Configure Your Smart Plug································· 6
Create Scenes·························································· 8
Discover Kasa··························································· 9
Authentication·························································10
About This Guide
This guide provides a brief introduction to smart outdoor plug and the Kasa app, as well as regulatory information.
Please note that features of this product may vary slightly depending on the model and software version you have, and on your location, language and internet service provider. All images, parameters and descriptions documented in this guide are used for demonstration only.
Conventions
In this guide, the following convention is used:
Convention |
Description |
Teal |
Key information appears in teal, including management page text such as menus, items, buttons and so on. |
Underline |
Hyperlinks are in teal and underlined. You can click to redirect to a website. |
More Info
•Specifications can be found on the product page at https://www.tp-link.com.
•Our Technical Support and troubleshooting information can be found at https://www.tp-link.com/support.
1
Introduction
Extend your smart home to the outdoors with the weather-resistant smart outdoor plug. Power on your patio lights, holiday decorations, and more from the convenience of your smartphone. Turn each outlet on/off individually, set schedules, even use simple voice commands with Alexa, Google
Assistant, or Microsoft Cortana to control the devices connected to the plug.
•Double the Outlets - Access and use 2 outdoor devices from anywhere together or individually with one smart plug.
•Weather-resistant - IP64 rating ensures your outdoor plug is protected against entry of dust and splashes of water from any direction. Weatherresistant cover included.*
*When not in use, the sockets should be firmly capped with the included weather-resistant cover.
•Control from Anywhere - Turn your outlets on/off or set schedules from anywhere using your Kasa Smart app.
•Voice Control - Use voice commands to power up your smart plug with Alexa, Google Assistant or Microsoft Cortana.
•No Hub Required - This plug works with a secured 2.4GHz wireless network without the need for a separate hub.
•Set Schedules - Individually schedule each device connected to this plug to automatically switch on or off if you'er home or away.
2
Appearance
This smart outdoor plug has two individual smart outlets, each with a control button to turn on or off the plug-in device and a LED to show you the current status. The System LED
changes color according to different status. See the explanation below:
Smart Outlet x 2
Plug in your device and control it from your smartphone.
Each outlet is independently controllable.
LED of Smart Outlet x 2
Lit up when the corresponding smart outlet is on.
Control Button x 2
Press a control button to turn on or off the corresponding outlet.
Press and hold any one of the control buttons for 5s to reset Wi-Fi connection. Press and hold any one of the control buttons for 10s to factory reset your plug.
System LED
Orange
Rebooting.
Blinking Orange and Green
Setup mode initiated.
Blinking Green
Searching for Wi-Fi.
White
Connected to Wi-Fi network successfully.
Blinking Orange
Resetting.
Red
No Wi-Fi connection.
Provided clamp: |
|
|
|
|
|
Provided screw: |
||||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Unit: mm
Unit: mm
3
Set Up Your Smart Outdoor Plug
Follow the steps below to set up your plug via Kasa Smart app.
1. Download and install Kasa app |
2. Log in or sign up with TP-Link ID |
3. Add Device |
||||
Get the Kasa Smart app from the Apple App |
Open the app, and log in with your TP-Link ID. |
Tap the + button in the Kasa app, select Smart |
||||
Store or Google Play, or by scanning the QR |
If you don't have an account, create one first. |
Outdoor Plug and then follow step-by-step |
||||
code below. |
|
|
|
app instructions to complete the setup. |
||
|
|
|
|
Note: When not in use, the sockets should be firmly |
||
|
|
|
|
capped with the included weather-resistant cover. |
||
|
|
|
|
|
|
|
4
