User Guide
Kasa Cam
1910012655 REV2.0.0
Contents
About This Guide····················································· 1
Introduction································································ 2
Appearance································································ 3
Set Up Your Camera·············································· 4
Use Your Camera····················································· 6
Authentication·························································10
About This Guide
This guide provides a brief introduction to the Kasa Cam and the Kasa app, as well as regulatory information.
Features available in Kasa Smart may vary by model and software version. Kasa Smart availability may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Kasa Smart experience.
Conventions
In this guide, the following convention is used:
Convention |
Description |
Teal |
Key information appears in teal, including management page text such as menus, items, buttons and so on. |
Underline |
Hyperlinks are in teal and underlined. You can click to redirect to a website. |
More Info
•Specifications can be found on the product page at https://www.tp-link.com.
•Our Technical Support and troubleshooting information can be found at https://www.tp-link.com/support/.
•A TP-Link Community is provided for you to discuss our products at https://community.tp-link.com.
•Frequently Asked Questions (FAQs) can be found at https://www.tp-link.com/support/faq/.
1
Introduction
With the Kasa Cam connected to your home network, you can see what happens in your home even when you're away. This keeps your home safe and give yourself a little peace of mind — all while seeing every detail on your phone.
You can set up and use your Kasa Cam alone, or use it together with other smart home devices including plugs, bulbs, switches and more. All these can be achieved on the Kasa app, which provides:
•Simple Setup - Easily connects your camera to your home network and place it almost anywhere.
•Live Video and Two-Way Audio - View 1080P full HD video and connect with your family instantly from anywhere at any time with your phone.
•Free Cloud Storage – Record up to two days of video activity per camera at no cost and save favorite moments to your phone. Upgrade options available.
•Activity Detection – Immediately alert you whenever it detects motion, keeping you and your family aware of what's going on.
2
Appearance
Kasa Cam has a system LED that changes color according to its status, a microphone, a USB micro port and a RESET button. See the explanation below:
System LED
•Solid amber:
Rebooting
•Alternating amber and green:
SoftAP Mode
•Flashing red:
Connecting to Wi-Fi
•Flashing green:
Connected to Wi-Fi
•Solid green:
Bound to Cloud
•Flashing amber:
Resetting to SoftAP/Factory mode
RESET Button
Note: You need to remove the magnetic housing to see the RESET button.
•Press and hold for 3 to 15 seconds:
Reset to SoftAP mode
•Press and hold for over 15 seconds:
Reset to Factory mode
USB Micro Port
Connect the USB cable and power adapter provided.
Microphone
Built-in internal microphone.
Note: Do NOT insert objects into the hole.
3
Set Up Your Camera
Follow the steps below to get started with your new camera.
Step 1. Download Kasa |
Step 2. Log In |
Step 3. Start Setup |
|||||||
Get the Kasa Smart app from the Apple App |
Open the app, and log in with your TP-Link ID. |
Tap the |
|
|
button in the Kasa app and select |
||||
|
|
||||||||
|
|
||||||||
Store or Google Play, or by scanning the QR |
If you don't have an account, create one first. |
Cameras > Kasa Cam. |
|||||||
code below. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4
