READ THIS MANUAL COVER TO COVER.
PAY ATTENTION to all WARNING and CAUTIONS
DO NOT use computer components not recommend by the
manufacture
Do not attempt to service the monitor your self. If a problem
occurs, contact the manufacture's authorized service center
ABOUT YOUR MONITOR
This monitor is a microprocessor-controlled, color monitor
which uses a TFT LCD panel. The monitor conforms to EPA
Energy Star and VESA DPMS ( Display Power Management
Signaling) power management standards. Our monitor also
provide one option to accept the video input (like NTSC or PAL
signal), you can switch these input signal through OSD and the
video OSD setting please refer to the Chapter 4.
RGB MODE
This monitor is equipped with a microprocessor that
identifies your computer’s video mode and allows user to adjust
the setting.
Table 1 shows standard video mode setting that have been
pre-adjusted at the factory for accurate video display. These
setting are stored in the monitor's memory
Overall Dimension (HxWxD): 483 x 354 x 50.3 mm
Shipping Weight (G/W): 9 Kg
Effective Display area (H/V): 337.92 x 270.34 mm
Display colors: 16.7M colors
Scan Frequencies:
Horizontal 31.47K to 80KHz
Vertical 60Hz to 75Hz
Number of Pixels: 1280x1024 pixels
Pixel pitch: 0.264x0.264 mm
Picture Tube: 17" TFT LCD panel
Power:
Input 110-240VAC(auto-sensing)
Frequency: 48-62Hz
Consumption 45Watts maximum (on)
RGB Connector: 15pin Mini D-sub (Standard)
BNC connector 6 x BNC connector
4 x camera input
1 x playback
1 x recorder
RGB Signals:
Video Analog RGB 0.7Vp-p/75Ω
Sync Separate
Display Data Channel:
Compatibility VESA DDC 1/2B
Open the shipping carton and check the contents. If any
items are missing or damaged, contact your dealer
immediately.
The package should include the following items
l 8U 17” Color TFT LCD Monitor
l Accessory Box:
1. VGA cable x 1
2. AC to DC adapter x 1
3. Power Cord x 1
4. User’s manual x 1
INSTALLING THE MONITOR
The monitor is equipped with an auto sensing power supply
for voltage ranges from 110~240VAC, 60/50Hz. Confirm the
line voltage designation on the rear panel of the monitor.
1. Before you connect the cables, make sure that the
monitor and the system unit power switches are OFF
2. Plug one end of the 15pin signal cable to the monitor and
the other end to the video signal connector at the rear of
the system. Tighten the two screws on the cable
connector on both ends, otherwise the screen will be
abnormal and LED light is yellow color, not the normal
green color.
3. Connect 4 cameras through BNC cable
4. Connect out BNC to recorder to record the screen
5. Connect the power to the monitor through the AC/DC
The OSD control functions of 17” Quad display LCD monitor are
located on the lower side. They are shown in the figure below
and described in the following paragraphs.
Menu ∇∆ - +
AV/PC Menu ?/CH1 ?/CH2 -/CH3 +/CH4 =/AUTO X
The first line is used for RGB OSD adjustment
The second line is used for security OSD adjustment
AV/PC: Switch the Screen between RGB and security
screen.
The RGB control key description:
1. : Power Switch
2. ﹣/+ : Decrement/Increment or Volume control
3. ∇/∆: Cursor Up/Down or Brightness control
4. MENU: Activate the on screen display function
As the security control key definition, please see the chapter 4.
The LCD monitor is designed to work with a range of
compatible video adapters on the market. Due to the possible
deviations between these video adapters, you may make
some adjustment to fit the monitor for adapter used.
ADJUSTMENT PROCEDURE
1. First, you must activate the OSD screen through pressing
the MENU key, the screen will show in the center of
screen as below:
Note: In the last paragraph, we will assume that you had
already done this procedure and only explain how to
change the setting.
2. Use the ∇ & ∆ key to select the required adjustment item
up or down.
3. Use the ﹣& + key to change the control value for
optimum viewing.
4. Each change that you had made will be automatically
saved into memory, If the screen display garbage and you
don't know how to restore to correct setting, please move
arrow to "Load Value" item then pressing "-" key to load
factory default.
1. Use the ∇ & ∆ key to move the 3to the \ icon, then
press “-” will automatically load the pre-define value for
each item.
2. Use this function only if you want to discard your new
setting.
UNDERSTAND THE DISPLAY RESOLUTION SETTING
To understand your display mode setting.
1. In the OSD screen, you will see the Horizontal frequency
(HF), Vertical frequency (VF), resolution and the monitor
Firmware version (ROM LEVEL). It is automatically
detected by the monitor user can not change this setting.
Note: we recommend to use auto adjustment item to fine
tune the monitor setting to get the better visual quality.
The LCD monitor is designed to work with a range of compatible
video display on the market. Due to the possible deviations
between these video source, you may make some adjustment
to fit the monitor for video usage.
ADJUSTMENT PROCEDURE
1. First, you must activate the OSD screen through pressing
the MENU key, the screen will show in the center of screen
as below:
Note: In the last paragraph, we will assume that you had already
done this procedure and only explain how to change the setting.
2. Use the ∇ & ∆ key to select the required adjustment item up
or down.
3. Use the ﹣& + key to change the control value for optimum
viewing.
4. Any change that you make will be automatically saved into
memory, If the screen display is not optimal and you don't
know how to restore the correct setting, please move the
arrow to "Load Value" item then press "-" key to load factory
default settings.
CAMERA SETUP
CAMERA CAM1
BRIGHTENSS 10
CONTRAST 22
SHARPNESS 55
SAT U 99
SAT V 82
HUE 01
LOAD DEFAULT
You can set up each camera brightness, contrast, sharpness, sat U,
Sat V and hue setting to the better visual quality.
The sub-menu of alarm is below
ALARM SETUP
AUDIBLE OFF/ON
It lets users to set up the audible on of off when camera signal is
missing.
The sub-menu of Playback is
CH1 CH2 CH3 CH4 PB OUT PWR PW
We also offer the hot key to let users easily operate the
LCD-1700VRQ machine.
Pressing ?/CH1 to let screen to display the channel 1 in full screen
Pressing ?/CH2 to let screen to display the channel 2 in full screen
Pressing ?/CH3 to let screen to display the channel 3 in full screen
Pressing +/CH4 to let screen to display the channel 4 in full screen
Pressing =/AUTO to let screen to display the screen as Channel, 1
Channel 2, Channel 3 , Channel 4, then Channel sequentially, the
duration is controlled by the DWELL setting in the system sub-menu.
Pressing to let screen to display 4 channel quad display.X
Recording the screen will always set as quad display, When you
playback the screen, we offered one hot key to let user to see the full
channel # display. For example, if you want to see the playback
channel 1 in full screen, just pressing ?/CH1, the screen will show
the full screen of channel 1.
Pin 1 Analog Red Input
Pin 2 Analog Green Input
Pin 3 Analog Blue Input
Pin 4 Ground
Pin 5 Digital Ground
Pin 6 Analog Red Ground
Pin 7 Analog Green Ground
Pin 8 Analog Blue Ground
Pin 9 NC
Pin 10 Sync Ground
Pin 11 Ground
Pin 12 SDA ( DDC Data)
Pin 13 H. Sync
Pin 14 V. Sync
Pin 15 SCL ( DDC CLK )
19
