Toshiba TDP-P75 User Manual

English

Owner ’s Manual

DATA Projector
TDP-P75

English

SAFETY PRECAUTION

The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH
VOL TAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN
THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

WARNING: Handling the cord on this projector, or the cords associated with accessories

USA only

WARNING: The lamp used in this projector contains mercury . Disposal of mercury may be

USA only

sold with this projector, will expose you to lead, a chemical known to the State
of California to cause birth defects or other reproductive harm. Wash hands
after handling.

regulated due to environmental considerations. For disposal or recycling
information, please contact your local authorities or the Electronic Industries
Alliance: www.eiae.org.

MODEL NAME: TDP-P75

TRADE NAME: DATA PROJECTOR MODEL NAME: TDP-P75

Tested To Comply
With FCC Standards

FOR HOME OR OFFICE USE

FCC NOTICE: This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. This
equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.

However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

SAFETY PRECAUTION 2

USA only

English

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.

- Consult the dealer or an experienced radio/TV technician for help.
RESPONSIBLE PARTY: TOSHIBA AMERICA INFORMATION SYSTEMS, INC.

9470 Irvine Blvd., Irvine, CA 92618-1697 U.S.A
Phone: [phone]

WARNING: Changes or modifications made to this equipment, not expressly approved

USA only

Notice: This Class B digital apparatus complies with Canadian ICES-003. Cet

CANADA only

by Toshiba, or parties authorized by Toshiba, could void the user’s authority
to operate the equipment.

appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.

SAFETY PRECAUTION

3

English

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS

GIVEN IN THIS OWNER'S MANUAL AND THOSE MARKED ON THE UNIT.
RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

This set has been designed and manufactured to ensure personal safety. Improper use
can result in electric shock or fire hazard. The safeguards incorporated in this unit will
protect you if you observe the following procedures for installation, use and servicing. This
unit is fully transistorized and does not contain any parts that can be repaired by the user.

DO NOT REMOVE THE CABINET COVER OR YOU MAY BE EXPOSED TO
DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL ONLY.

1. Read owner's manual

After unpacking this product, read the
owner's manual carefully, and follow
all the operating and other
instructions.

2. Power sources

This product should be operated only
from the type of power source
indicated on the marking label. If you
are not sure of the type of power
supply to your home, consult your
product dealer or local power
company. For products intended to
operate from battery power or other
sources, refer to the operating
instructions.

3. Source of light

Do not look into the lens while the
lamp is on. The strong light from the
lamp may cause damage to your eyes
or sight.

4. Heat

The product should be situated away
from heat sources such as radiators,
heat registers, stoves, or other
products (including amplifiers) that
produce heat.

IMPORTANT SAFETY INSTRUCTIONS 4

English

5. Ventilation

Openings in the cabinet are provided
for ventilation to ensure reliable
operation of the product and protect it
from overheating. These openings
must not be blocked or covered. The
openings should never be blocked by
placing the product on a bed, sofa, rug
or other similar surface. This product
should not be placed in a built-in
installation such as a bookcase or
rack unless proper ventilation is
provided or the manufacturer's
instructions have been adhered to.

6. Water and moisture

Do not use this product near water (for
example, near a bath tub, wash bowl,
kitchen sink, or laundry tub; in a wet
basement; or near a swimming pool).

8. Power cord protection

Power-supply cords should be routed
so that they are not likely to be walked
on or pinched by items placed upon or
against them, paying particular
attention to cords at plugs,
convenience receptacles, and the
point where they exit from
the product.

9. Overloading

Do not overload wall outlets; extension
cords, or integral convenience
receptacles as this can result in a risk
of fire or electric shock.

7. Cleaning

Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners.
Use a soft cloth for cleaning.

10. Object and liquid entry

Never push objects of any kind into
this product through the openings, as
they may touch dangerous voltage
points or short-out parts that could
result in a fire or electric shock. Never
spill liquid of any kind on the product.

IMPORTANT SAFETY INSTRUCTIONS

5

English

11. Lightning storms

For added protection for this product
during a storm, or when it is left
unattended and unused for long
periods of time, unplug it from the
wall outlet. This will prevent damage
to the product due to lightning and
power line surges. However, while it
is thundering or lightning, do not
touch the apparatus and any
connected cable and/or equipment.
This will prevent you from receiving
the electric shock by an electric
surge.

12. Do not place the product
vertically.

Do not use the product in the upright
position to project pictures at the
ceiling, or any other vertical
positions. The product may fall over,
causing personal injury or product
damage.

14. Do not stack components.

Do not stack other equipment on this
product or stack this product on
other equipment. The top and
bottom surfaces of this product
develop heat and may damage the
other unit.

15. Accessories

Do not place this product on an
unstable cart, stand, tripod, bracket,
or table. The product may fall,
causing serious injury to a child or
adult, and serious damage to the
product. A product and cart
combination should be moved with
care. Quick stops, excessive force,
and uneven surfaces may cause the
product and cart combination to
overturn.

13. Attachments

Do not use attachments not
recommended by the product
manufacturer, as they may cause
hazards.

IMPORTANT SAFETY INSTRUCTIONS 6

S3125A

English

16. Damage requiring service

Unplug this product from the wall outlet
and refer servicing to qualified service
personnel under the following
conditions:

a) when the power-supply cord or plug is

damaged;

b) if liquid has been spilled or objects

have fallen into the product;

c) if the product has been exposed to rain

or water;

d) if the product does not operate

normally by following the operating
instructions (adjust only those controls
that are covered by the operating
instructions as an improper adjustment
of other controls may result in damage
and will often require extensive work
by a qualified technician to restore the
product to its normal operation);

e) if the product has been dropped or

damaged in any way; or

f) when the product exhibits a distinct

change in performance.

17. If glass components,
including the lens and lamp,
should break, contact your
dealer for repair service.

This product incorporates glass
components, including the lens and
lamp. If such parts should break,
please handle with care to avoid injury.
Contact your dealer for repair service.
The broken pieces of glass may cause
injury. In the unlikely event of the lamp
rupturing, thoroughly clean the area
around the projector and discard any
edible items placed in that area.

18. Servicing

Do not attempt to service this
product yourself, as opening or
removing covers may expose you
to dangerous voltage or other
hazards. Refer all servicing to
qualified service personnel.

19. Replacement parts

When replacement parts are
required, be sure the service
technician has used replacement
parts specified by the
manufacturer or that have the
same characteristics as the
original part. Unauthorized
substitutions may result in fire,
electric shock, or other hazards.
(The lamp is the only
user-replaceable part.)

20. Safety check

Upon completion of any service or
repairs to this product, ask the
service technician to perform
safety checks to determine that the
product is in proper operating
condition.

IMPORTANT SAFETY INSTRUCTIONS

7

English

21. Do not leave thermal-paper
documents or easily
deformed items on top of the
unit or near the air exhaust
for long periods of time.

The heat from the unit could erase the
information on the thermal paper, or
cause deformation or warping.

22. Do not use the product in a
closed installation state.

Do not place the product in a box or in
any other closed installation state.
Otherwise it may overheat. This could
result in a risk of fire.

POWER SUPPLY CORD SELECTION

If your line voltage is 220 to 240V, use one of the following types of cable.

Plug
configuration

Use a 5A fuse approved by ASTA or BSI
to BSI362.

Always replace the fuse cover after
changing the fuse.

Plug type Line

voltage

EURO 220 - 240V Australian

UK 220 - 240V Switzerland

Plug
configuration

Plug type Line

240V
10A

240V
6A

North
American

240V
10A

voltage
200 - 240V

200 - 240V

200 - 240V

POWER SUPPLY CORD SELECTION 8

English

IMPORTANT PRECAUTIONS

Save Original Packing Materials

The original shipping carton and packing materials will come in handy if you ever
have to ship your projector. For maximum protection, repack the set as it was
originally packed at the factory.

Moisture Condensation

Never operate this unit immediately after moving it from a cold location to a warm
location. When the unit is exposed to such a change in temperature, moisture
may condense on the crucial internal parts. To prevent the unit from possible
damage, do not use the unit for at least 2 hours after there is an extreme or
sudden change in temperature.

Location and Installation

• Do not place in hot locations, such as near a heater. Doing so could cause
malfunction and shorten the life of the projector.

• Avoid locations with oil or cigarette smoke, which can affect the quality and
useful life of the product’s optical parts and darken the screen.

• Do not use the product vertically in any upright position or slantwise at an angle
of 20 degrees or more.

• Using this product near a TV or radio may cause interference in the image or
sound. If this happens, move it away from the TV or radio.

• In a high-altitude location where the air is thin, cooling efficiency is reduced;
therefore, use the projector in a cool area.

Avoid Volatile Liquids

Do not use volatile liquids, such as an insect spray, near the unit. Do not leave
rubber or plastic products touching the unit for a long time. They will leave marks
on the finish. If cleaning with a chemically saturated cloth, be sure to follow the
product's precautions.
In the spaces provided below, record the model and serial numbers located at the
bottom of your projector.

Model No. Serial No.
Retain this information for future reference.

IMPORTANT PRECAUTIONS

9

English

EXEMPTION CLAUSES

• T oshiba Corporation bears no responsibility in the case of damages arising from
natural disaster such as earthquakes, lightning, etc., fire not liable to Toshiba
Corporation, acts by third parties, other accidents, or use under abnormal
conditions including erroneous or improper operation and other problems.

• Toshiba Corporation bears no responsibility for incidental damages (lost profit,
work interruption, corruption or loss of the memory contents, etc.) arising from
the use of or the inability to use this unit.

• Toshiba Corporation accepts no liability whatsoever for any damages arising
from not having followed the descriptions in this Instruction Manual.

• Toshiba Corporation accepts no liability whatsoever for any damages arising
from malfunctions arising from combination with equipment or software that is
not related to Toshiba Corporation.

EXEMPTION CLAUSES 10

English

OTHER NOTES AND INFORMATION

Copyrights

Showing or transmitting commercial imaging software or broadcast or
cable-broad casting programs with the purpose of other than the personal and
private viewing, including modifying images using the freeze or screen size
functions, or displaying with the varying aspect ratio of the images, could violate
the direct or indirect copyrights of the imaging software or broadcast program,
etc., if done without first consulting with the copyright holder. For this reason,
please take appropriate measures before performing one of the actions listed
above, including obtaining a license from the copyright holder.

Disposal

This product contains substances which are harmful to humans and the
environment.

• The lamp contains inorganic mercury.

Please dispose of this product or used lamps in accordance with local regulations.

WEEE Directive

Following information is only for EU-member states:

The use of the symbol indicates that this product may not be
treated as household waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be
caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact
your local city office, your household waste disposal service or the shop where
you purchased the product.

Trademarks

• VGA, SVGA, XGA are trademarks or registered trademarks of International
Business Machines Corporation.

• DLP and Digital Light Processing, Digital Micromirror Device, DMD, and DLP
are trademakes of Texas Instruments.

• Macintosh is a registered trademark of Apple Computer, Inc.

• Windows is a registered trademark of Microsoft Corporation in the U.S. and
other countries.

• Adobe is a registered trademark and Acrobat Reader is a trademark of Adobe
Systems Incorporated.

OTHER NOTES AND INFORMATION

11

English

Notational Conventions Used in This Manual

• References to pages with related information are annotated as follows. For
example, if making a reference to page 36:

• The illustrations in this document are for reference purposes only and may not
reflect your package exactly.

p.36

REMOTE CONTROL BATTERIES

Caution

• Never throw batteries into a fire.

Note

• Be sure to use AAA batteries.

• Dispose of batteries in a designated disposal area.

• Attention should be drawn to the environmental aspects of battery disposal.

• Do not mix different battery types or combine used batteries with new ones.

• If the remote control does not operate correctly, or if the operating range
becomes reduced, replace both batteries with new ones.

• If the batteries are dead or if you will not be using the remote control for a long
time, remove the batteries to prevent battery acid from leaking into the battery
compartment.

Using the batteries improperly may cause them to explode or leak and lead to
burn or injury. If battery-leaking fluid contacts skin, wash the fluid off immediately
with clean water and consult a doctor. If the fluid is spilt on an instrument, avoid
contact and wipe it off using tissue paper.
(Dispose of the used tissue paper as flammable garbage after moistening with
water.)

REMOTE CONTROL BATTERIES 12

English

Contents

SAFETY PRECAUTION ............................................ 2

IMPORTANT SAFETY INSTRUCTIONS .................. 4

POWER SUPPLY CORD SELECTION .................... 8

IMPORTANT PRECAUTIONS .................................. 9

EXEMPTION CLAUSES ........................................... 10

OTHER NOTES AND INFORMATION ..................... 11

REMOTE CONTROL BATTERIES ........................... 12

Overview.................................................................... 15

Shipping contents....................................................... 15

Projector exterior view................................................ 16

Controls and functions ........................................... 17

Remote control........................................................... 18

Preparing and using the remote control ..................... 19

Operating a computer using the remote control......... 21

Positioning your projector........................................... 22

Choosing a location................................................ 22

Projection distance and size .................................. 23

Connection ................................................................. 23

Connecting to a computer...................................... 24

Connecting to a Component Video device............. 24

Connecting Video and S-Video devices................. 25

Operation................................................................... 26

Start up....................................................................... 26

Adjusting the image.................................................... 27

Adjusting the height................................................ 27

Auto-adjusting the image ....................................... 27

Fine-tuning the image size and clarity.................... 27

Adjusting the volume.............................................. 28

Contents 13

English

Correcting keystone ...............................................28

Switching input signals ............................................... 28

Shutdown....................................................................29

Menu operation...........................................................30

Menu system.......................................................... 30

Using the menus ....................................................31

1. Image adjustment menu..................................... 32

2. Display setting menu.......................................... 33

3. Default setting menu ..........................................34

4. Information menu ...............................................35

Additional Information ............................................. 36

Care of the projector...................................................36

Cleaning the lens.................................................... 36

Cleaning the projector case....................................36

Storing the projector............................................... 37

Transporting the projector ...................................... 37

About the lamp............................................................37

Lamp warning message..............................................38

Replacing the lamp.....................................................38

Indicator lights.............................................................40

Troubleshooting ....................................................... 41

Specifications ........................................................... 42

Projector specifications...........................................42

Dimensions............................................................. 43

Signal timing........................................................... 43

Regulation statements............................................. 45

FCC statement ....................................................... 45

EEC statement ....................................................... 45

MIC statement........................................................ 45

Contents14

English

Overview

Shipping contents

The projector is shipped with a cable required for connection to a PC. Carefully
unpack and verify that you have all of the items shown below. If any of these
items are missing, please contact your place of purchase.

Projector Soft carry case Remote control

Y

A
L
P

T
U
P

N
I

Batteries Mouse remote

VGA cable Power cord*

control receiver

*The supplied power cord
will be suitable for your
region, and may differ from
that illustrated.

Owner’s manual CD Owner’s manual

X The Supplied CD-ROM

The supplied CD-ROM contains an owner’s manual, including information not
available for the printed Owner’s Manual (Getting started) and Acrobat®

TM

Reader

to view the manual.

Q Viewing the manual

Run the CD-ROM and double-click on Start.pdf. Acrobat® ReaderTM launches,
and the menu screen of the Owner’s manual appears. Click on your language.
The Owner’s Manual cover and list of bookmarks appear. Click on a bookmark

title to view that section of the man ual. Cl ic k o n to view a reference page

p.

with related information. See the Help menu for more information about
Acrobat® Reader

TM

.

Overview 15

English

r

Projector exterior view

Front / Upper side

Antitheft lock hole

AC IN socket

Rear side

USB terminal (For
service purpose only)

Rear IR remote sensor
S-Video terminal

Video terminal
Audio out terminal

Bottom side

Air intake

Monitor out terminal

Control panel

Focus ring and zoom
ring

Front IR remote senso
Projection lens

Lens cap

Front adjuster release button

RGB

signal input (PC/

YP

BPR/ YCBCR) terminal

Audio in terminal

Air exhaust

p.17

Front adjuster foot

Lamp cover

Overview16

Speaker
Tilt adjusterTilt adjuster

Tilt adjuster

English

Controls and functions

Control panel

10

9

7
8
1

2

3

1. ON/STANDBY button ,

p.29

Turns the projector on or off.

2. AUTO button

Automatically determines the best
picture settings for the displayed
image.

3. MENU button

Opens, saves and exits the on­screen menu.

4. 6 , 5, 3, 4 button

The directional buttons are used to
select the desired menu items and
to make adjustments when the on­screen menu is activated.
When the on-screen menu is not
activated, the 3 and 4 buttons
function as VOLUME decrease -
and VOLUME increase + hot

keys. ( )

p.27

p.27

4

p.26

5. INPUT button

Sequentially selects the input
signal RGB/YP
Video.

6. LAMP indicator

Indicates the status of the lamp.
Lights up or flashes when the lamp

6

5

has developed a problem.

7. TEMP indicator

Flashes red if the projector’s
temperature becomes too high.

8. ON indicator

Lights up or flashes when the
projector is under operation.

9. Zoom ring

Adjusts the size of the image.

10. Focus ring

Adjusts the focus of the projected
image.

p.28

BPR, Video, or S-

p.40

p.40

p.40

p.27

p.27

Overview 17

English

Remote control

ENTER

Front

Remote Control

Rear

Remote control transmitter

Laser emitter

Mouse remote control receiver

CAUTION Label (LASER)

(5)

(12)

(11)

(7)

(6)

R-CLICK

ESC

AUTO

INPUT

MENU

(8)

(15)

(9)

(10)
(1)
(3)

(2)

(13)

Remote Control

Y
A
L

P

T
U

P
N
I

LASER
WARNING

(4)

(14)

Battery
cover

Control
button cover

CAUTION Label (LASER)

Caution - use of controls or adjustments or performance of procedures othe r
than those specified herein may result in hazardous radiation exposure.

Name : Main Function

(1) ENTER button : Accepts the selected mode.
(2) MENU button : Displays menus.
(3) AUTO button : Auto-adjusting the image.
(4) ON/STANDBY button :Turns the power on/off (standby).
(5) Transmission indicator :Lights when remote control transmitting.
(6) INPUT button :Selects input.
(7) RETURN button :Goes back one screen.
(8) Selection button :Menu selections and adjustments,etc.
(9) LASER button :Displays laser point.

(10) button :This control functions as a computer’s [ ] button.
(1 1) button :This control functions as a computer’s [ ] button.

(12) PJ MODE button :Switches remote control mode.
(13) FREEZE button :Pauses image.
(14) MUTE button :Cuts off the picture and sound temporarily.
(15) L-CLICK button :Left button click of remote control mouse.

Overview18

English

Preparing and using the remote control

Q Loading dry-cell batteries into

the remote control

1. Remove the battery cover.

2. Insert the dry-cell batteries.

Be sure to align the plus and minus
ends of the batteries properly.

3. Replace the battery cover.

(1)

(2)

Q Operating the remote control

Point the remote control toward the
projectorfs infrared remote sensor, and
press a button on the remote control.

• Operating the projector from the front

Approx. 15°

A

p

p

r

o

x

.

5

m

T

U
P
N
I

• Operating the projector from the rear

Approx. 15°

A

p

p

r

o

x

.

5

m

T

U
P
N
I

Dry-cell batteries

• Remove batteries from remote control when not using for extended periods.

• If the remote control stops working, or if its range decreases, replace all the
batteries with new ones.

The remote control

• The remote control may fail to operate if the infrared remote sensor is exposed
to bright sunlight or fluorescent lighting.

• Do not drop or bang.

• Do not leave in hot or humid locations.

• Do not get wet or place on top of wet obj ects.

• Do not take apart.

• In rare cases, ambient conditions could impede the operation of the remote
control. If this happens, point the remote control at the main unit again, and
repeat the operation.

Overview 19

English

Preparing and using the remote control
(Continued)

Q Switching operation modes

Operation modes should be switched between projector operation and computer
operation.

Switching the remote control operation mode.

Pressing this button toggles the mode.
When this button is lit, the remote control is in [PJ Mode]
(Projector operation mode).
If no operations are made for 30 seconds, this light goes out,
and the remote switches back to [PC Mode] (Computer
operation mode).

[PJ Mode] : Functions as a select button.

If no menu is displayed, adjusts volume.

[PC Mode] : Functions as a mouse pointer control.

PJ MODE

R-CLICK

ESC

Pressing displays a laser pointer, regardless of the mode.

[PC Mode] : Functions as a down button. Used to go forward

on Microsoft® PowerPoint® slides, etc.

[PC Mode] : Functions as an up button. Used to go back on

Microsoft® PowerPoint® slides, etc.

INPUT AUTO

MENU

FREEZE

[PC Mode] : Functions as the right mouse button (R-CLICK).

[PC Mode] : Functions as a ESC button.

Pressing one of these buttons automatically sets the remote
control to [PJ Mode].
If no operations are made for 30 seconds, and the remote
switches back to [PC Mode].

The L-CLICK (left click) button on the back of the remote
control functions when in [PC Mode].

Notes

• With the exception of operating a PC with the remote control, all buttons are
used in [PJ Mode].

• Make sure there is nothing between the remote control and the IR sensor on the
projector that might obstruct the infrared beam.

Overview20

English

Operating a computer using the remote control

A computer can be operated using the projector’s remote control. This function is
available on any computer with the Windows 98/98SE, Windows Me, Windows
2000, or Windows XP OS, that is equipped with a USB port supporting the USB

1.1 (The mouse remote control is supported on OS 9 or OS X for the Macintosh).
The operation cannot be guaranteed for all the environments of computers.

1

Connecting a computer

Connect the supplied Mouse remote control receiver to the computer.

To USB port

Mouse remote control receiver

2

Operating a computer

The mouse remote control function is available when the remote control is set to
[PC Mode]. (See “Switching operation modes”.)
Point the Mouse remote control at the mouse remote control receiver, and
operate the remote controlfs buttons.

• Moving the mouse pointer

Move the pointer control button in the direction that you wish the mouse pointer
to move, then press.

• To left click

Press the L-CLICK button.

• To right click

Press the R-CLICK button.

• To drag and drop

Move the pointer control button in a (L-)clicked state, then when the pointer is
over the desired location, release the button.

• Using the computer’s up and down arrow key functions

Press the and buttons to switch PowerPoint® slides.

Remote Control Front

Remote Control Rear

Pointer control

R-CLICK

RETURN

ENTER

R-CLICK

R-CLICK

ESC

Overview 21

English

Positioning your projector

Choosing a location

Your projector is designed to be installed in one of four possible installation
locations:

1. Floor in front of screen;

2. Ceiling in front of screen;

3. Floor at rear of screen;

4. Ceiling at rear of screen.

Y our room layout or personal preference will dictate which installation location you
select. T a ke into consideration the size and position of your screen, the location of
a suitable power outlet, as well as the location and distance between the projector
and the rest of your equipment.

I. Floor front:
Select this location with the projector placed near
the floor in front of the screen. This is the most
common way to position.

II. Ceiling front:
Select this location with the projector suspended
from the ceiling in front of the screen.

Set in the Default setting > Projection mode
menu after you turn the projector on.

III. Floor rear:
Select this location with the projector placed near
the floor behind the screen.

Set in the Default setting > Projection mode
menu after you turn the projector on.

IV. Ceiling rear:
Select this location with the projector suspended
from the ceiling behind the screen.

Set in the Default setting > Projection mode
menu after you turn the projector on.

WARNING

• Always obey the instructions listed in IMPORTANT SAFETY INSTRUCTIONS
when placing the unit. Attempting to clean/replace the lamp at a high site by
yourself may cause you to drop down, thus resulting in injury.

• If you wish to mount the projector on the ceiling, be sure to ask your dealer to do
so. Mounting the projector on a ceiling requires special ceiling brackets (sold
separately) and specialized knowledge. Improper mounting could cause the
projector to fall, resulting in an accident.

Overview22

English

e

• If the projector is ceiling-mounted, install the breaker for turning off the power in
case of anomaly. Let everyone involved with the use of the projector know that
fact.

Projection distance and size

Use the figures, tables, and formulas below to determine the projection size and
projection distance.
(Projection sizes are approximate values for full-size picture with no keystone
adjustment.)

Screen

°

90

As seen from the sid

H

°

90

a is the distance (m) between the
lens and the screen, and
corresponds to a range of 1.15 m to

10.00 m. H is the height from the
image bottom to the center of the
lens.

Connection

When connecting a signal source to the projector, be sure to:

1. Turn all of the equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure that the cables are firmly inserted.

In the connections shown below, cables are not included with the projector (see

). Cables are commercially available from electronics stores.

p.15

As seen from above

Lens center

a

a (min length) =

a (max length) =

projection size
(inches)

30 1.00 1.22 7.54
36 1.20 1.47 9.05
40 1.33 1.63 10.06
60 2.00 2.44 15.09

80 2.66 3.26 20.12
100 3.33 4.07 25.15
150 5.00 6.11 37.72
200 6.66 8.14 50.29
250 8.33 10.18 62.87
300 9.99 --- 75.44

projection size (inches)

30.03

projection size (inches)

24.69

projection distance a (m) height
min length

(zooming
max)

max length
(zooming
min)

(H) (cm)

Overview 23

English

Connecting to a computer

VGA cable

Audio cable

• Signals are outputted from Monitor OUT terminal even in standby mode. From
AUDIO OUT terminal, no audio signal is outputted.

• Many laptops do not turn on their external video ports when connected to a
projector. Usually a key combination like FN + F5 or CRT/LCD key turns the
external display on/off. Locate a function key labeled CRT/LCD or a function key
with a monitor symbol on the laptop. Press FN and the labeled function key
simultaneously. Refer to your laptop’s documentation to learn your laptop’s key
combination.

• Audio out terminal accepts a stereo connector but signal is monaural.

• The output volume from the Audio out terminal can be adjusted by the volume
buttons.

VGA cable

Audio cable

Connecting to a Component Video device

Component Video cable

AV equipment

The projector is capable of accepting a Component Video signal. Use a
Component Video-VGA (Mini D-sub) cable to display these images.
The following standards are supported in the digital TV function:

• 480i • 480p

• 576i • 576p

• 720p (50/ 60 Hz) • 1080i (50/ 60 Hz)

Overview24

English

Connecting Video and S-Video devices

S-Video or Video devices

If the selected video image is not displayed after the projector is turned on and the
correct video source has been selected, check that the video source is turned on and
operating correctly. Also check that the signal cables have been connected correctly.

S-Video cable

or

Video cable

Audio cable

Overview 25

English

Operation

Start up

1. Switch all of the connected equipment on.

2. Plug the power cord into the projector and into a

3. Remove the lens cap. If it is left on, it could become

4. Press and hold the ON/STANDBY button on the

5. The start up procedure takes about 20 seconds

6. The projector will start to search for input

7. You can al so pre ss the INPUT button on the projector or remote control to

If the frequency/ resolution of the input signal exceeds the projector’s operating
range, you will see the message “Unsupported Signal” displayed on a blank screen.

wall socket. Turn on the wall socket switch (where
fitted). Check that the ON indicator on the
projector lights orange after power has been
applied.

deformed due to heat.

remote control or projector to start the unit. The
ON indicator flashes green and stays green
when the unit is on.

after pressing the ON/STANDBY button. In the
later stage of start up, a default Toshiba logo is
projected.

signals. The projector screen displays the
current input source being scanned at the upper left corner of the screen. If
no input source signal is detected, the search will continue until an input
source signal is detected.

select an input signal to display. For more information, refer to .

p.28

CAUTION

• Do not look into the lens while the lamp is on. The strong light from the lamp
may cause damage to your eyes or sight.

• Do not block the air intake or exhaust. Doing so could cause a fire due to
internal overheating.

• Do not place your hands, face, or other objects near the air exhaust. Doing
so could cause burns, deform/break the ob j e ct.

Operation26

English

Adjusting the image

Adjusting the height

The projector is equipped with 1 quick-relea se adjuster foot and 1 tilt adjuster
foot. The adjusters can be used to change the image height and projection angle.
To adjust the projector to your desired
image height and projection angle:

1. Lift the projector up to the desired
angle and press the front adjuster
button to release the adjuster. The
adjuster will drop into position.

2. Screw the tilt adjuster foot to fine
tune the horizontal angle.

To retract the feet, hold up the projector
while pressing the front adjuster button,
then slowly lower the projector. Screw the rear adjuster foot in a reverse direction.

If the screen and the projector are not perpendicular to each other, the projected
image becomes vertically trapezoidal. To correct this situation, adjust the value of
Keystone in the Picture menu, on the projector control panel or on the remote
control.

Auto-adjusting the image

In some cases, you may need to optimize the picture
quality. To do this, press the AUTO button on the
control panel of the projector or on the remote control.
Within 5 seconds, the built-in Intelligent Auto
Adjustment function will re-adjust the values of
Frequency, and Clock to provide the best picture
quality.

This function is only available when the Computer input
is selected.

The screen will be blank while the auto-adjustment is
functioning.

Fine-tuning the image size and clarity

1

2

1. Adjust the projected image to
the size that you need using the
zoom ring.

2. Then sharpen the image by
rotating the focus ring.

Operation 27

English

Adjusting the volume

The speaker volume can be adjusted when an audio signal is being input.

Correcting keystone

Keystone distortion refers to the situation where the projected image is noticeably
wider at either the top or bottom. It occurs when the projector is not perpendicular
to the screen.

To correct this:

1. Adjust the position of the projector.

2. Press the AUTO button on the remote control or the projector.
If the image is still distorted, you will need to manually correct it following steps.

• Press the MEMU button on the projector or the remote control. Go to the Image
adjustment --> Keystone menu and adjust the values by pressing 3 /

4 button on the projector or remote control.

For example,

Keystone

Press the 3 button on the

projector or remote control when
you are in the Image adjustment -

-> Keystone menu.

----------------------------------------------->

0

Keystone

-6

Press the

4 button on the

projector or remote control when
you are in the Image adjustment -­> Keystone menu.

Keystone

---------------------------------------------->

0

Switching input signals

The projector can be connected to multiple
devices at the same time. To sequentially select
input sources, press the INPUT button on the
projector control panel or the remote control. The
selected input signal will be displayed at the
upper left corner of the screen for 5 seconds.

Operation28

Keystone

+6

English

Shutdown

1. Press ON/STANDY and a

2. The ON indicator flashes orange

• To protect the lamp, the projector will not

• Do not unplug the pow er cord before the

Note

• Note that a lamp characteristics may rarely cause the brightness to fluctuate

• A lamp is consumable item. If used for extended periods, images will appear

• The DMD

CAUTION

• Do not block the projection lens from projecting as this could cause the blocking

• Do not look into the lens while the lamp is on. The strong light from the lamp may

• Do not block the air intake or exhaust. Doing so may cause damage to the

• Do not place your hands, face, or other objects near the air exhaust. Doing so may

confirmation prompt displays. Press

Press the [ON/STANDBY] button again to turn off.

ON/STANDY a second time to turn

the projector off.
and the lamp shuts down. The fans

will continue to run for approximately
90 seconds to cool down the
projector lamp.

respond to any commands during the
cooling process.

projector shutdown sequence is
complete or during the 90-second cooling down process.

slightly.
dark, and the lamp could burn out. This is characteristic of a lamp, and is not

malfunction. (The lifetime of the lamp depends on conditions of use.)

TM

is made using extremely advanced technology, but there may be
black spots (pixels that do not light) or bright spots (pixels that are constantly lit)
on the panel. Please note that these are not malfunctions.

object to become heated and deformed.

cause damage to your eyes or sight.

projector due to internal overheating.

cause burns, deform/break the object.

Operation 29

English

Menu operation

Menu system

The OSD menus will vary according to the selected signal type being used.

Sub-Menu PC

Image adjustment

menu

Display setting

menu

Default setting

menu

Information menu

Functions available when receiving different
signal types...

Video / S-Video /
Component Video

Picture mode
Keystone
Brightness
Contrast
H-position
V-position
Phase
Frequency

Volume
OSD time
Reset all
Screen size
Aspect ratio

Projection mode
Auto input search
Language
Start-up screen
Fan mode
Power on

Input
Resolution
Picture mode
Lamp time

Picture mode
Keystone
Brightness
Contrast
Color
Tint
Sharpness

Volume
OSD time
Reset all
Screen size
Aspect ratio

Input
Video mode
Picture mode
Lamp time

Operation30

English

Using the menus

The projector is equipped with on-screen display (OSD) menus for making
various adjustments and settings.
The following example describes the adjustment of the keystone.

1. Press the MENU button on the
projector or remote control to turn
the on-screen menu on.

2. Use 3 /4 button on the projector or
on the remote control to select

Image adjustment and

press 5 or 6 button to select
Keystone.

There are 10 different menu languages. Before making adjustments, you may
choose a suitable OSD language in the Default setting > Language

menu. (Refer to for more details.)

p.34

3. Adjust keystone values by
pressing 3/4 on the
projector or remote control.

4. Press the MENU button to
leave and save the settings.

Operation 31

English

1. Image adjustment menu

Some picture adjustments are available only when certain input ports are in use.
Unavailable adjustments are not shown on the screen.

FUNCTION DESCRIPTION

Picture mode

Keystone

Brightness

Contrast

Picture modes are provided so you can optimize your
projector image set-up to suit your program type.

•PC Signal Input

1. Bright: The brightness is emphasized in this mode.

2. Standard: The color saturation and brightness are well­balanced.

3. True color: Displaying images in their natural color.

4. Economic: Use this mode to reduce system noise and
reduce power consumption by 20%. The lamp life is also
extended with lower light output. (*)

•YPBPR/ S-Video/ Video Signal Input

1. Standard: It is suitable for enjoying TV movies.

2. Cinema: With a lower color temperature, it is suitable for
enjoying cinematic movies.

3. Economic: Use this mode to reduce system noise and
reduce power consumption by 20%. The lamp life is also
extended with lower light output. (*)

*Economic mode is effective from the next power on after turn
off (standby) the projector.

Corrects any keystone distortion of the image. Refer to

p.28

for more information.
Adjusts the brightness

of the image. The
higher the value, the
brighter the image.

-30

50

+70

And lower the setting,
darker the image. Adjust this control so the black areas of the
image appear just as black and that detail in the dark areas is
visible.

Adjusts the degree of
difference between
dark and light in the
image. The higher the

-30

50

+70

value, the greater the
contrast.

Operation32

English

H-position

V-position

Adjusts the horizontal
position of the projected
image.

-30 +30

Adjusts the vertical
position of the projected
image.

-30

This function allows you to adjust the
clock phase to reduce image distortion.

Phase

Frequency

Color

Tint

Sharpness

* Tint can be displayed and adjusted only when the video signal is set to NTSC or

NTSC 4.43.

Adjusts the horizontal width of the image.
Increases or decreases the color intensity of the image.
Adjusts the color tones of the image.*
Adjusts the image to make it look sharper or softer.

2. Display setting menu

Some picture adjustments are available only when certain input ports are in use.
Unavailable adjustments are not shown on the screen.

FUNCTION DESCRIPTION

Volume

OSD Time

Adjusts the volume level.

Sets the length of time the OSD will remain active after your
last button press. The range is from 5 to 60 seconds.

+30

Reset all

Screen size

Aspect ratio

Returns all settings to the factory preset values.

Makes the best fit of the image to the screen.

1. Full 2. Through
There are two aspect ratio settings.

1. 4 : 3 (Standard) 2. 16 : 9 (Wide screen)

Operation 33

English

3. Default setting menu

FUNCTION DESCRIPTION

Projection

mode

Auto input

search

Language

Start-up

screen

Fan mode

Power on

The projector can be installed on a ceiling or behind a screen,
or with one or more mirrors. Contact your dealer for the ceiling
mount bracket (optional accessory) if you need to install the
projector on your ceiling.

For more information, refer to .
Sets whether the projector searches automatically for input

signals. If the source scan is on, the projector will scan for input
signals until it acquires a signal. If the function is not activated,
the projector selects the last used input signal.

Language sets the language for the OSD control menus.
Use 3/ 4button on the projector or remote control to select
your desired language from among English, French, German,
Italian, Spanish, Russian, Traditional Chinese, Simplified
Chinese, Japanese, and Korean.

Enables the user to select which logo screen will appear during
projector start-up. Three modes are available: Default (Toshiba
logo), black screen or blue screen.

A mode used for extreme environments like high altitude. We
recommend you set High when your environment is higher
than 3000 feet above sea level.
Press 3 or 4button on the projector or remote control to
select.
Operation under high fan mode may cause a higher decibel
operating noise level because of increased fan speed neces­sary to improve overall system cooling and performance.
If you use this projector under other extreme environments
excluding the above, it may display auto shut-down symptoms,
which is designed to protect your projector from over-heating.
In cases like this, you should switch to High fan mode to solve
these symptoms. However, this is not to st ate that this projector
can operate under any and all harsh or extreme environments.

Set whether to turn on the power when the ON/STANDBY
button is pressed (Manual), or when the power cord is plugged
in (Auto).

p.22

Operation34

English

4. Information menu

This menu shows you the current operating status of the projector.

FUNCTION DESCRIPTION

Input

Resolution

Picture mode

Lamp time

Video mode

Shows the current signal source.
Shows the native resolution of the input signal.
Shows the selected mode in the Image adjustment menu.
Displays the number of hours the lamp has been used.
Shows the Video input system format, NTSC, SECAM or PAL.

Operation 35

English

Additional Information

Care of the projector

To care for your projector, clean the lens and projector case on a regular basis,
following the instructions below.

Never remove any parts of the projector except the user-replaceable lamp. Contact
your dealer if other parts need replacing.

Cleaning the lens

WARNING

• Request cleaning and maintenance of a ceiling-mounted unit from your
projector dealership. Attempting to clean/replace the lamp at a high site by
yourself may cause you to drop down, thus resulting in injury.

Clean the lens whenever you notice dirt or dust on the surface.

CAUTION: HOT SURFACE! Before cleaning the lens, turn the projector off,

unplug the power cord, and allow the projector to cool for at least one hour.

1. Use a canister of compressed air to remove dust (available from building
hardware or photographic suppliers).

2. If there is stubborn dirt or smudge marks, use a photographic lens brush or a
clean, soft lens cloth (moistened with lens cleaner, if necessary) to gently
wipe the lens surface.

NEVER touch the lens with your bare hands or rub the lens with abrasive
materials (products such as paper towels can damage the lens coating).
ALWAYS use a photographic lens brush or lens cleaning cloth and solution.

NEVER attempt to clean the lens while the projector is on or while it is still hot
from previous use.

Cleaning the projector case

CAUTION: HOT SURFACE! Before cleaning the lens, turn the projector off,

unplug the power cord, and allow the projector to cool for at least one hour.

1. To remove dirt or dust, wipe the case with a soft, dry, lint-free cloth.

2. If the soiling is severe, dip the cloth in a neutral detergent diluted in water,
wring well, and gently wipe off the dirt, then finish up by wiping with a dry
cloth.

Never use wax, alcohol, benzene, thinner, or other chemical detergents. These
products can damage the case.

Additional Information36

English

Storing the projector

If you need to store the projector for an extended time, follow these guidelines:

1. Make sure the temperature and humidity of the storage area are within the
recommended range for the projector. Please refer to the Specifications
page in this manual or consult your dealer.

2. Retract the adjuster feet.

3. Remove the batteries from the remote control.

4. Pack the projector in its original packing or equivalent packing materials.

T ransporting the projector

Ship the projector in its original packing. If you carry the projector yourself, use
the supplied soft carrying case.

About the lamp

The product’s light source is a mercury lamp that lights at increased internal
pressure. Be sure to fully understand the following characteristics of the lamp and
handle it with extreme care.

• The lamp may burst with a loud noise due to impact or deterioration, or fail to

light at the expiration of its life.

• How long it takes before the lamp bursts or the life expires may vary greatly by

lamp. Some may burst shortly after first use.

• Burst is likely to happen if the lamp is used after the replacement period has

elapsed.

• When the lamp bursts, the broken pieces of glass may get inside the product

or be released outside from the openings for ventilation.

• When the lamp bursts, a slight amount of mercury gas enclosed in the lamp

along with glass dust may be released from the openings for ventilation.

Q Replace the lamp when a sign appears on the screen.

• When the replacement time approaches, the message will appear on the

screen.

• The risk of burst will increase if the lamp is continuously used without being

replaced.

• Frequently check the used hours and prepare spares when the replacement

time approaches.

Q When the lamp is broken

• If glass components, including a lamp and a lens, should break, handle the

broken pieces with care to avoid injury and contact your dealer for repair
service.

• In the event of lamp burst, unplug the product from the wall outlet, leave and

completely ventilate the room. Then, thoroughly clean the area around the
projector and discard any edible items placed in that area.

• When the lamp bursts, consult a doctor if glass dust or mercury gas gets into

your eyes or you breathe it.

Additional Information 37

English

Lamp warning message

The following Lamp warning displays will remind you to change the lamp. The
lamp hour information is also available in the Information > Lamp time

menu.

Message Status

Replacing the lamp

CAUTION: HOT SURFACE! The lamp may be very hot after use. Before

replacing the lamp, turn off the projector, unplug the power cord, and allow the
projector to cool for at least 45 minutes.

The lamp unit contains mercury. Disposal of mercury may be regulated due to
environmental considerations. Dispose of the used lamp unit by the approved
method for your area. Contact your local authorities or www.eiae.org (USA only).

A lamp is consumable supplies. If used for extended periods, images will appear
dark, and the lamp could burn out. This is characteristic of a lamp, and is not
malfunction. (The lifetime of the lamp depends on condition of use.) If this
happens, replace it with a new one.

The lamp has been in operation for 2000
hours. Install a new lamp for optimal
performance.

WARNING

• If the projector is mounted on the ceiling, ask your Toshiba dealership to
replace the lamp. Replacing the lamp at a high site by yourself may cause
you to drop down, thus resulting in injury.

• When replacing, always use lamp “TLPLW7” (sold separately).

CAUTION

• If you have been using the projector, the lamp will be very hot, and may cause
burn injuries. Wait for the lamp to cool (for at least 45 minutes) before
replacing it.

• If the lamp should break, please handle with care to avoid injury due to broken
pieces and contact your dealer for repair service.

Additional Information38

English

Step 1. Turn the power off and disconnect the projector from the wall socket.
Step 2. Protect the projector's surface by clearing a flat open area on your desk and

placing a soft item on the desk for padding.

Step 3. Turn the p rojector over. Then loosen the screws and re move the lamp cover. If

the lamp is hot, avoid burns by waiting for 45 mi nutes until the lamp has c ooled.

Step 4. Loosen the screw fixing the lamp to the projector. If

the screw is not loosened completely, the lamp
cannot be removed. Be careful not to lose the screw
as it is needed to hold the replacement lamp in pl ace.
It is strongly recommended that you use a magnetic­head screwdriver.

Step 5. Lift the handle so that it stands up. Use the handle

to slowly pull the lamp out of the projector.

• Pulling it too quickly may cause the lamp to break and
scatter broken glass in the projector.

• Do not place the lamp in locations where water might
splash on it, children can reach it, or near flammable
materials.

• Do not insert your hands into the projector after the lamp
is removed. If you touch the optical components inside,
it could cause color unevenness and distortion of the
projected images.

Step 6. Insert a new lamp. Ensure the handle is fully laid flat and locked in place.

Reinsert and tighten the screw firmly.

• Loose screw may cause a bad connection, which could result in malfunction.

• Do not over tighten the screw.

Step 7. Reinstall the lamp cover and tighten the screws.
Step 8. Restart t he projector.

Do not turn the power on with the lamp cover
removed.

Step 9. Resetting the lamp counter
See the lamp’s manual for instructions on
resetting the lamp timer.

Do not reset if the lamp is not replaced as this
could cause damage.

Additional Information 39

English

Indicator lights

The front of the projector has three lights that indicate its status. Check the
following for information about the indicator lights. If an abnormal condition is
indicated, turn off the projector and contact your dealer.

When the projector is in a normal state:

POWER TEMP LAMP State Remark

Orange Off Off

Flashing

Green

Green Off Off

Flashing

Orange

When the projector is in an abnormal state:

POWER TEMP LAMP State Remark

Off Off Red

Red Red Off
Red Red Green
Red Red Red

Off Red Off
Off Red Green

Green Red Off

Green Red Green

Off Off

Off Off

Standby mode --­The projector is powering

up.
The projector is under

normal operation.
The projector needs to cool

down for 90 seconds after
the power is turned off.

The lamp has exceeded its
usage life.

The internal temperature is
too high.

• The intake ventilation or
the exhaust ventilation is
blocked.

• The projector may be in a
poorly ventilated location.

• The ambient temperature
may be too high.

The fans are not working.

Cannot turn off the
projector.

---

Cannot turn on the
projector.

Solution:

• Install a new lamp.
Solution:

• Make sure the ventilation
holes are not blocked.

• Relocate the projector.

• Stop using the projector
until the ambient
temperature falls within
the specified range. The
maximum operating
temperature is specified
as 35°C (95°F).

• Make sure the power
supply is stable.

• Check if there is an
obeject stuck in the fans.

• Contact your dealer.

Additional Information40

English

Troubleshooting

Problem Cause Remedy

There is no power from the power

The projector
does not turn
on.

No picture.

Image is
unstable.

Picture is
blurred.

Remote control
does not work
correctly

cord.

Attempting to turn the projector on
again during the cooling process.

The lamp cover is not securely
attached.

The video source is not turned on
or connected correctly.

The projector is not correctly
connected to the input source
device.

The input signal has not been
correctly selected.

The connection cables are not
securely connected to the
projector or the signal source.

The projection lens is not
correctly focused.

The projector and the screen are
not aligned properly.

The lens cap is still attached to
the lens

The batteries are out of power.

There is an obstacle between the
remote control and the projector.

You are too far away from the
projector.

Plug the power cord into the AC inlet on
the projector, and plug the power cord
into to a power outlet. If the power outlet
has a switch, make sure it is switched

on.

p. 26

Wait until the cooling-down process is
completed.

Correctly attach the lamp cover.
Turn the video source on and check that

the signal cable is connected correctly.

p. 23

Check the connection.

Select the correct input signal with the
INPUT buttons on the remote control or

INPUT on the projector.

Correctly connect the cables to the
appropriate terminals.

Adjust the focus of the lens using the
focus ring.

Adjust the projection angle and direction
as well as the height of this unit if

necessary.

Remove the lens cap.
Replace both of the batteries with new

ones.

Remove the obstacle.
Stand within 5 meters (16.4 feet) of the

projector.

p. 27

p. 27

p. 19

p. 19

p. 23

p. 28

Troubleshooting 41

English

Specifications

Projector specifications

All specifications are subject to change without notice.

General

Product name DATA Projector
Model name TDP-P75

Optical

Display system 1-CHIP DMD 1024 x 768 XGA
Lens F/Number F=2.4 to 2.6, f= 18.6 to 22.7 mm
Lamp 200W lamp

Electrical

Power supply AC100 ~ 240V, 3.5A, 50/60 Hz (Automatic)
Power consumption 280 W (Max)

Mechanical

Dimensions 238 mm (W) x 86.8 mm (H) x 180 mm (D)
Weight 4.2 lbs (1.9 Kg)

Input terminal

RGB/ YP
S-VIDEO Mini DIN 4-pin port x 1
VIDEO RCA x 1
Audio in Mini stereo
USB Mini type B (Service purpose only)

Output terminal

Monitor out Mini D-sub 15-pin (female)
Audio out Mini stereo (variable)

Output

Speaker 1 watt x 1

Environmental requirements

Operating altitude and
temperature

Operating relative
humidity

BPR input Mini D-sub 15-pin (female)

0~35°C for height: 0~2,500 feet
0~30°C for height: 0~2,500~3,000 feet
0~30°C for height: 3,000~10,000 feet (Plase
switch the High fan speed mode on.)

10% ~ 90% (without condensation)

Specifications42

English

Dimensions

238

180

86.8

Signal timing

Supported timing for PC input

Horizontal

Resolution

Frequency

(kHz)

720 x 400 37.927 85.039 35.500 720 x 400_85

31.469 59.940 25.175 VGA_60

640 x 480

800 x 600

1024 x 768

(native)

1280 x 1024 63.981 60.020 108.000 SXGA3_60

To achieve the best quality projected image, please use the projector's native
resolution of 1024 x 768.

37.861 72.809 31.500 VGA_72

37.500 75.000 31.500 VGA_75

43.269 85.008 36.000 VGA_85

37.879 60.317 40.000 SVGA_60

48.077 72.188 50.000 SVGA_72

46.875 75.000 49.500 SVGA_75

53.674 85.061 56.250 SVGA_85

48.363 60.004 65.000 XGA_60

56.476 70.069 75.000 XGA_70

60.023 75.029 78.750 XGA_75

68.667 84.997 94.500 XGA_85

Vertical

Frequency

(Hz)

Pixel

Frequency

(MHz)

Unit: mm

Mode

Supported signal format for Component-YPBPR Input

Signal Format

480i(525i)@60Hz 15.73 59.94

480p(525p)@60Hz 31.47 59.94

576i(625i)@50Hz 15.63 50.00
576p(625p)@50Hz 31.25 50.00
720p(750p)@60Hz 45.00 60.00
720p(750p)@50Hz 37.50 50.00

1080i(1125i)@60Hz 33.75 60.00
1080i(1125i)@50Hz 28.13 50.00

Horizontal Frequency

(kHz)

Vertical Frequency (Hz)

Specifications 43

English

Supported signals for Video and S-Video inputs

Video mode

NTSC 15.73 60 3.58

PAL 15.63 50 4.43

SECAM 15.63 50 4.25 or 4.41

PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58

PAL-60 15.73 60 4.43

NTSC4.43 15.73 60 4.43

Horizontal

Frequency (kHz)

Vertical

Frequency (Hz)

Color sub-carrier
Frequency (MHz)

Specifications44

English

Regulation statements

FCC statement

CLASS B: This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:

— Reorient or relocate the receiving antenna.
— Increase the distance between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

— Consult the dealer or an experienced radio/TV technician for help.

EEC statement

This machine was tested against the 89/336/EEC (European Economic
Community) for EMC (Electronic Magnetic Compatibility) and fulfills these
requirements.

MIC statement

B class equipment (Household purpose info/telecommunications
equipment)

As this equipment has undergone EMC registration for household purpose, this
product can be used in any area including residential area.

Regulation statements 45
