Toshiba PDR-M5 User Manual
INSTRUCTION MANUAL
MODE D’EMPLOI
DIGITAL STILL CAMERA
PDR-M5
INSTRUCTION MANUAL
To ensure that you use the Toshiba
PDR-M5 Digital Still Camera safely
and correctly, read this Instruction
Manual carefully before you start using
the camera. Once you have finished
reading this Instruction Manual, keep it
handy at all times.
DIGITAL STILL CAMERA
PDR-M5
In the space provided below, please record the model and Serial No. of your camera.
Model No. PDR-M5 Serial No.
Please retain this information for future reference.
ENGLISH
Attention
For customers in the U.S.A.
DIGITAL STILL CAMERA PDR-M5
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Change the direction of the radio or TV antenna.
Move the equipment or the radio or TV. For example, if the equipment is to the right of the TV, move it to the left of
the TV.
Or, move the equipment farther away from the radio or TV.
• Plug the equipment into a different outlet. Don’t plug your radio or TV into the same circuit as your equipment.
• Ensure that all expansion slots (on the back or side of the equipment) are covered.
Also, ensure that all metal retaining brackets are tightly attached to the equipment.
• If these suggestions don’t help, consult your equipment dealer or experienced radio/TV technician for help.
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 1 -
Attention (continued)
CAUTION
If you modify the camera in any way, without getting approval from Toshiba Corporation, your camera may violate
FCC regulations. Violation of FCC regulations may cause the FCC to void your right to use the modified camera.
TOSHIBA AMERICA INFORMATION SYSTEMS, INC.
Getting Ready
Imaging Systems Division
9740 Irvine Boulevard,
Irvine, California 92618-1697
Phone Number: (800)288-1354
Basic
For customers in Canada
Photography
CAUTION
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Playing Back/
Erasing Images
Other
Applications
Additional
Information
- 2 -
Before Reading This Manual
IMPORTANT
Thank you for purchasing the Toshiba PDR-M5 Digital Still Camera.
To ensure that you use this camera safely and correctly, read this Instruction Manual carefully before you start using
the camera. Once you have finished reading this Instruction Manual, keep it handy at all times.
Trademark Information
• Macintosh and QuickTime are trademarks of Apple
Computer, Inc.
• MS-DOS, Windows, Windows NT are registered
trademarks of the Microsoft Corporation of the U.S.
registered in the USA and other countries.
Windows is an abbreviated term referring to the
Microsoft Windows Operating System.
• SmartMedia is a trademark of Toshiba Corporation.
• Other companies or product names are trademarks
or registered trademarks of the respective
companies.
Conventions Used In This Manual
• Indicates items or details that you should observe to
prevent loss of data, malfunction and impaired
performance. Also indicates information relating to
specifications and functions.
Memo
• Indicates extra useful information.
Indicates another page to refer to for extra
☞
information.
About OS Abbreviations
• Windows 98
This abbreviation stands for the Microsoft
Windows® 98 operating system.
• Windows 95
This abbreviation stands for the Microsoft
Windows® 95 operating system.
• Windows NT
This abbreviation stands for the Microsoft
Windows® NT Workstation 4.0 operating system.
®
®
®
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 3 -
Contents
The name in paretheses ( ) is the function name on the PDR-M5.
Preface
■ Attention ................................................................1
■ Before Reading This Manual ................................. 3
■ Contents ................................................................4
Getting Ready
■ Safety Precautions ................................................6
■ Using Your Camera Correctly..............................12
■ Features ..............................................................17
■ The Function Map ................................................18
Basic
Photography
■ Accessories .........................................................19
■ Names of Parts .................................................... 20
■ Attaching the Strap ..............................................24
■ Preparing the Battery ...........................................25
Playing Back/
Erasing Images
Other
Applications
Additional
Information
Loading the Battery ..............................................25
Removing the Battery ...........................................27
Charging the Battery.............................................27
■ Using the Power Outlet........................................29
■ About SmartMedia™ ........................................... 30
Notes on SmartMedia™ .......................................30
Loading SmartMedia™.........................................31
Removing SmartMedia™ .....................................32
Write Protection ....................................................34
■ Turning the Power ON/OFF.................................35
Turning the Power ON.......................................... 35
Turning the Power OFF ........................................35
■ LCD Monitor Display ............................................36
In Photography Mode ........................................... 36
In Playback mode .................................................37
Getting Ready
Basic Photography
■ How to Hold Your Camera...................................38
■ How to Press the Shutter Button ......................... 39
■ About the Color of the Viewfinder LED ................41
■ Photography (Auto Photography) ........................42
Using the Viewfinder .............................................42
Using the LCD Monitor ......................................... 43
■ Setting the Image Size and Quality ..................... 45
■ Zoom Photography ..............................................47
■ Digital Zoom Photography ...................................48
■ Close-up Photography
(Macro approximately Photography) ................... 49
■ Photography Using the Self-timer
(Self-timer Photography) ..................................... 50
■ Photography Using the Flash
(Flash Photography) ............................................ 51
■ Taking Photographs Continuously
(Burst Photography) ............................................ 54
■ Multi Image Photography
(Multi Photography) .............................................57
■ Long Exposure Photography
(Bulb Photography).............................................. 58
■ Making Movies.....................................................59
■ Taking Photographs Manually
(Manual Photography) ......................................... 60
■ Changing the Preset Conditions
(REC MENU) ....................................................... 65
- 4 -
Contents (continued)
The name in paretheses ( ) is the function name on the PDR-M5.
Playing Back/Erasing Images
■ Playing Back Photographed Images
(Single-Frame Playback) ..................................... 69
■ Playing Back Movies ...........................................70
■ Enlarging Photographed Images
(Zoom Playback) ................................................. 73
■ Displaying a List of Images
(Thumbnail Display)............................................. 74
■ Auto Playback (Slideshow) .................................. 75
■ Playback of Multi Image Pictures ........................76
■ Reducing the Image Size (Resize) ......................77
■ Compressing Images (Quality) ............................79
■ Copying Images...................................................81
■ Selecting the Folder to Play Back........................84
■ Erasing Images (Erase Frame) ...........................86
■ Erasing All Images in a Folder (Erase All) ...........88
■ Formatting the SmartMedia™ .............................89
■ Protecting Images................................................90
Protecting an Image .............................................90
Removing the Protection ......................................92
Other Applications
■ Basic Photographic Settings
(SET-UP mode) ...................................................93
AUTO-OFF ...........................................................94
SOUND ................................................................95
TIME ..................................................................... 95
LANGUAGE ..........................................................95
SCREEN ..............................................................96
IMAGE number.....................................................96
DEFAULT..............................................................97
■ Adjusting the LCD Monitor Brightness.................98
■ DISP Button and LCD Monitor Display ................ 99
■ Taking and Playing Back
Photographs on a TV.........................................100
■ Transferring Images to a PC.............................. 102
■ Separately Sold Accessories .............................103
■ Connecting to Other Devices.............................105
Additional Information
■ Specifications ....................................................106
■ Warnings and Messages Displayed
on LCD Monitor ................................................. 110
■ Troubleshooting................................................. 111
■ Glossary ............................................................ 114
■ Customer Support ............................................. 115
■ Demo Mode ....................................................... 116
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 5 -
Safety Precautions
Read these safety precautions carefully before using the PDR-M5. These instructions contain valuable information
on safe and proper use that will prevent harm and damage to the operator and other persons.
Make sure that you fully understand the following details (indications) before proceeding to the main descriptions in
this manual.
Getting Ready
Indication definitions
Graphic symbol definitions
Indication Meaning
This indicates the existence of a
Basic
DANGER
Photography
WARNING
CAUTION
Playing Back/
Erasing Images
*1: “Bodily injury” means injuries, burns, and shock which
does not require hospitalization or prolonged treatment.
*2: “Physical damage” means extended harm to home,
household effects, domesticated animals, and pets.
Other
Applications
Additional
Information
hazard that could result in death or
serious bodily injury, if the safety
instruction is not observed.
This indicates the existence of a
hazard that could result in bodily
injury, if the safety instruction is not
observed.
This indicates the existence of a
hazard that could result in bodily
*1
or property damage *2.
injury
Graphic symbol Meaning
Indicates a prohibited action that must
not be carried out.
The actual prohibited action is
indicated in the symbol or nearby
graphically or described in text.
Indicates a necessary action that must
be carried out.
The actual necessary action is
indicated in the symbol or nearby
graphically or described in text.
Exemption Clauses
• Toshiba Corporation bears no responsibility in the case of
damages arising from earthquakes, fire not liable to
Toshiba Corporation, operating by third parties, other
accidents, or use under abnormal conditions including
erroneous or improper operation and other problems.
• Toshiba Corporation bears no responsibility for incidental
damages (lost profit, work interruption, corruption or loss
of the memory contents, etc.) arising from the use of or
the inability to use this unit.
• Toshiba Corporation accepts no liability whatsoever for
any damages arising from not having followed the
descriptions in this Instruction Manual.
• Toshiba Corporation accepts no liability whatsoever for
any damages arising from malfunctions arising from
combination with equipment or software that is not
related to Toshiba Corporation.
- 6 -
Safety Precautions (continued)
DANGER
DANGER
Do not heat, disassemble or throw the
battery into fire or water.
Doing might cause it to rupture, ignite or heat up,
resulting in fire or major injury.
Do not strike the battery with a hammer, or
step on, drop or subject the battery to
strong impact.
Doing so might cause it to rupture, ignite or heat
up, resulting in fire or major injury.
Use only the optional, recommended
battery charger. Do not use any other
battery charger.
Charging the battery by any other battery
charger might cause it to rupture, ignite or heat
up, resulting in fire or major injury.
Use the battery only for its originally
intended purpose.
Using the battery for any other purpose might
cause it to rupture, ignite or heat up, resulting in
fire or major injury.
(continued)
Do not carry the battery or store it together
with other metallic objects such as a ballpoint pen or necklace.
This might short-circuit the battery’s + and –
terminals. This might cause the battery to
rupture, ignite or heat up, resulting in fire or major
injury.
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 7 -
Safety Precautions (continued)
WARNING
WARNING
Should you ever notice smoke, a strange
odor or excessive heat coming from the
Getting Ready
camera, immediately turn OFF the power
and remove the battery and AC adapter.
Continued use in this state might cause fire,
electric shock or burns. For details on repair,
consult the store of purchase, or please contact
Basic
the technical support number.
Photography
If foreign objects or water have entered the
camera, immediately turn the power OFF
and remove the battery and AC adapter.
Continued use in this state might cause fire or
electric shock. For details on repair, consult the
store of purchase, or please contact the
Playing Back/
Erasing Images
technical support number.
If the camera has fallen or its case is
damaged, immediately turn the power OFF
and remove the battery and AC adapter.
Other
Continued use in this state might cause fire or
Applications
electric shock. For details on repair, consult the
store of purchase, or please contact the
technical support number.
Additional
Information
(continued)
Do not place the camera on wobbly,
inclined or unstable surfaces.
This might cause the camera to fall or tilt over.
Do not use in areas near water.
This might cause fire or electric shock. Take
special care during rain, snow, on the beach or
near the shore.
Do not use the camera in the bath or
shower.
This might cause a fire or electric shock.
Do not allow metallic objects or other
flammable foreign matter inside the
camera.
This might cause a fire or electric shock. Do not
open the SmartMedia™ cover, and insert or allow
such objects to fall inside.
- 8 -
Safety Precautions (continued)
WARNING
WARNING
Do not disassemble, change or repair the
camera.
This might cause fire or electric shock. For
details on repair and internal inspection, consult
the store of purchase, or please contact the
technical support number.
Do not touch power or TV antenna cords
during a thunderstorm.
This might cause electric shock.
Do not use the camera while you are
walking, driving or riding a motorcycle.
This might cause you to fall over or result in a
traffic accident.
Use only the specified batteries or the
specified AC adapter .
Use of a battery or AC adapter other than
specified, might cause fire, defects or
malfunctions.
(continued)
Keep the batteries out of the reach of
children.
If a child swallows a battery, this might result in
poisoning. If a child swallows a battery,
immediately consult a physician.
If battery fluid enters the eyes, immediately
rinse with fresh water and consult with a
physician to receive treatment.
If left untreated, damage to the eye could be
permanent.
Use the AC adapter only with the indicated
power supply voltage (120V AC).
Use with any other power supply voltage might
cause fire or electric shock.
(continued)
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 9 -
Safety Precautions (continued)
CAUTION
CAUTION
If you want to use the camera on an
airplane, consult with the airline and follow
Getting Ready
their instructions.
Use of this camera is sometimes restricted due
to potential radio interference.
Do not use the camera in humid, steamy,
Basic
smoky or dusty places.
Photography
This might cause fire or electric shock.
Do not leave the camera in places where
the temperature may rise significantly, such
as inside a car.
This might adversely affect the case or the parts
Playing Back/
inside, resulting in fire.
Erasing Images
Do not place or wrap the camera in cloth or
blankets.
This might cause heat to build up and deform the
Other
case, resulting in fire. Use the camera in a wellventilated place.
Applications
Additional
Information
(continued)
Before you move the camera, disconnect
cords and cables.
Failure to do this might damage cords and
cables, resulting in fire or electric shock.
Do not drop or subject the camera to strong
impact.
This might cause fire, electric shock or
malfunctions.
Before you carry out maintenance on the
camera, remove the battery and AC
adapter.
Leaving these attached might cause electric
shock.
Remove the batteries and AC adapter if
you plan not to use the camera for a long
time.
This might cause fire.
Insert the battery paying careful attention to
the polarity (+ or –) of the terminals.
Inserting the battery with its polarities inverted
might cause fire and injury, or damage the
surrounding areas.
- 10 -
Safety Precautions (continued)
CAUTION
CAUTION
Do not look at the sun through the camera
viewfinder.
This may cause injury of the eyes.
Do not use the flash close to anyone’s
eyes.
This might cause temporary damage to the
person’s eyesight.
Do not walk around with the camera
swinging from the strap.
This might subject the camera to shock as it
bumps into a person or an object, damaging the
camera or causing an injury.
Before you store or dispose of used
batteries insert them in their battery covers
or tape the plus (+) and (–) terminals with
insulating tape.
If stored or disposed of without doing this, the
batteries may make contact with metal objects,
resulting in fire or injury due to leaking of battery
fluid, overheating or bursting of the battery.
(continued)
(continued)
Do not subject the status display to impact.
If the status display is impacted, the glass on the
screen may be broken and internal fluid may
leak.
If the internal fluid enters your eyes or sticks to
your body or clothes, immediately rinse with
fresh water. If the internal fluid enters your eyes,
immediately consult a physician to receive
treatment.
Consult your dealer regarding the internal
cleaning of the camera once every two
years.
If dust is allowed to accumulate inside the
camera for a long time, this might result in fire or
defects. Consult your dealer regarding the
cleaning costs.
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 11 -
Using Your Camera Correctly
Notes On Handling Your Camera
When you use your camera, carefully read and strictly observe the Safety Precautions from page 6 onwards and
the notes described below.
Getting Ready
● Avoid using or storing the camera in the following places:
• Places subject to humidity, dust and dirt
• Places subject to direct sunlight
Basic
Photography
• Places subject to high or low temperature
• Places filled with highly flammable gas
• Places near gasoline, benzene or paint thinner
• Places subject to strong vibrations
• Places subject to smoke or steam
• Places subject to strong magnetic fields (such as near motors, transformers or magnets)
• Places contacting chemicals such as pesticides or next to rubber or vinyl products for long periods
Playing Back/
Erasing Images
Other
Applications
Additional
Information
● Do not expose the camera to sand.
The PDR-M5 is particularly sensitive to sand. If the camera comes into contact with sand, not only will the
camera become damaged, it will also no longer be repairable.
Pay special attention when using the camera at the beach or where sand or sand dust is likely to be
present.
● Notes On Condensation
Due to a sudden change in temperature, such as when you move the camera from a cold location to a
warm one, water droplets (condensation) may form on the inside of the camera or on the lens. When this
occurs, switch the camera OFF, and wait an hour before using the camera. Condensation may also form
on the SmartMedia™ card. If this happens, remove the SmartMedia™, wipe off any water droplets and
wait a short time before using it again.
- 12 -
Using Your Camera Correctly (continued)
● Carrying Out Maintenance on Your Camera
• To prevent the lens, surface of the status display or viewfinder from being scratched, blow off any dust
on these parts with a blower brush and lightly wipe with a soft dry cloth.
• Clean the body of the camera with a soft dry cloth. Do not use volatile liquids such as paint thinner,
benzene or insecticide, as these may react with the camera body and cause deformation or remove
the coating.
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 13 -
Using Your Camera Correctly (continued)
Notes On Handling Batteries
The PDR-M5 camera uses a lithium-ion battery pack (PDR-BT1). (This manual simply refers to this battery pack as
the “battery”.) Other batteries cannot be used.
When you use the battery, carefully read and strictly observe the Safety Precautions from page 6 onwards and the
Getting Ready
notes described below.
* The battery is not fully charged when you buy your camera. Be sure to charge the battery before you use your
camera.
* Before you use a battery, be sure to remove the electrode cover.
Basic
Photography
Playing Back/
Erasing Images
Other
Applications
About Battery Use
• The battery gradually discharges even when not used. Charge the battery one or two days before use.
• To maximize the battery life, switch the camera OFF as often as possible when it is not being used.
• In cold locations, the number of frames that can be taken decreases. Take along a spare fully charged
battery. You can also increase the amount of power produced by putting the battery in your pocket or
another warm place to heat it and then loading it into the camera just before you take a picture. If you
are using a heating pad, do not place the battery directly against the pad.
• Always keep the terminals in a clean state.
• If the battery is used for a long time, the camera body and the battery itself will become warm. This is
normal and not a malfunction.
• At normal temperatures, this battery can be recharged at least 300 times for use. If the battery runs out
quickly, this indicates that the battery has reached the end of its effective life and should be replaced.
When Not Using the Battery For A Long Time
• If the battery is not to be used for a while, store it after there is no power left. If the battery is stored for
a long time in a fully charged state, its performance may be impaired.
• When the battery is to be stored for a long time, fully charge the battery and then use the battery until
there is no power left once every year and then store it.
Additional
Information
- 14 -
Using Your Camera Correctly (continued)
• When the battery is not in use, be sure to remove it from the camera body or battery charger (sold
separately). If the battery is left attached to the camera body or battery charger, a minute current will
flow even if the power is turned OFF. This will result in overdischarge and the battery may no longer be
useable.
• Store the battery in a cool place with the battery cover attached. We recommend a dry place with a
surrounding temperature of +59°F <+15˚C> to +77°F <+25˚C>. Avoid storing the battery in extremely
hot or cold places.
Charging the Battery
• When you use the battery for the first time or when the battery has not been used for a long time, be
sure to charge the battery before use.
• The battery can be charged within this camera body using the PDR-AC10 AC adapter supplied with
the PDR-M5 (see page 29). The battery takes about five hours to charge.
• If you use the PDR-CG1 battery charger (sold separately), the battery can be charged in about one
hour.
• This rechargeable battery does not need to be fully discharged or exhausted before being charged.
• The battery may feel warm after it has been charged or immediately after being used. This is normal
and not a malfunction.
• The battery can be charged at temperatures between +32°F <0°C> and +104°F <+40°C>, but should
be charged between +50°F <+10°C> and +86°F <+30°C> to obtain maximum battery performance.
• Do not recharge a fully charged battery.
Caution when disposing a battery
Batteries are included with this product. When they are no longer useable, you should
not throw them away. Instead, properly dispose of them as small chemical waste.
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 15 -
Using Your Camera Correctly (continued)
Notes On Handling the AC Adapter
Be sure to use only the AC adapter (PDR-AC10) provided with your camera. Using a different AC adapter might
cause the camera to malfunction.
When you use the AC adapter, carefully read and strictly observe the Safety Precautions from page 6 onwards and
Getting Ready
the notes described below.
• The AC adapter is designed for use only in the U.S.A and Canada. It cannot be used overseas.
• Be sure that you do not allow the AC adapter to contact any other metal object as this might cause a
Basic
Photography
Playing Back/
Erasing Images
Other
Applications
short circuit.
• To connect the AC adapter, firmly insert the plug on the end of the cable into the DC IN 5V terminal. Do
not insert the plug into other terminals. This might cause the camera to malfunction.
• Before you disconnect the connector cable, turn the camera OFF and then disconnect the cable
holding it by its plug. Do not disconnect the connector cable by pulling the actual cable.
• Do not drop the AC adapter or subject it to strong impacts.
• Do not use the AC adapter in very hot and humid locations.
• Do not plug in the AC adapter while you are using the battery. Switch the camera OFF first.
• The AC adapter is for indoor use only.
• Use only the specified AC adapter. Do not use other AC adapters.
• The AC adapter may sometimes become warm during use. This is normal and not a malfunction.
• Buzzing or whirring noises may come from inside the camera. This is normal and not a malfunction.
• Do not use the AC adapter near a radio as it could interfere with radio signal reception.
• If you remove the battery or AC adapter while the camera is in operation, the date may be lost from
memory. If this happens, reset the date. (➲ Page 93)
Additional
Information
- 16 -
Features
Getting Ready
Photography interval of 1 second
Replay interval of 2 seconds
3
X zoom lens
USB interface compatible
● High definition 2.14 million pixels
● Extensive photographic functions
• Auto/Flash/Macro/Self-timer
• Movie photography
• Burst mode (4 frames in 1 second)
• Multi mode (16 continuous images
in one frame)
• Bulb mode for night and creative photography
• Color/Black-and-white photography etc.
● Image size and quality easily
selectable
•Size (still image:1600 x 1200/800 x 600 pixels)
• Quality (FINE/NORMAL/BASIC)
● Status display
• Settings can be verified even when LCD
*2
(movie :320 x 240 pixels/160 x 120 pixels)
monitor is OFF.
*1
*1
Photography
Basic
- Serial interface also compatible
Erasing Images
● SmartMedia™
• Expandable up to 64MB
● Compatibility
• Image recording method compliant with Exif
ver2.1 (JPEG)
*1
These figures may vary according to the
photography and playback conditions.
*2
Sound cannot be recorded.
Playing Back/
Applications
Other
Information
Additional
- 17 -
The Function Map
It is suggested that you look at the function map, below before using the PDR-M5.
Read these pages first.
Getting Ready
Let's learn about basic operation.
Basic
Photography
Utilizing the various photography modes.
Playing Back/
Erasing Images
Other
Applications
Long Exposure Photography (Bulb Photography) (P.58)
Additional
Information
Let's get ready to use the PDR-M5.
(P.19 – 37)
First, let's learn about the basic way of using the
PDR-M5.
Photography (P.42)
Playing Back Photographed Images (P.69)
Erasing Images (P.86)
You can choose various photography modes on the
PDR-M5.
Zoom Photography (P.47)
Digital Zoom Photography (P.48)
Close-up Photography (P.49)
Photography Using the Self-timer (P.50)
Photography Using the Flash (P.51)
Taking Photographs Continuously (P.54)
Multi Image Photography (Multi Photography) (P.57)
Making Movies (P.59)
Changing the photography settings.
You can change the settings for the image that you are
going to take according to your particular requirements,
location and other conditions.
Setting the Image Size and Quality
Manually setting the PDR-M5
Changing the Preset Conditions
Playing back your photographed images
You can choose various ways of playing back images
on the LCD monitor.
Enlarging Photographed Images
Playback of Multi Image Pictures
Playing Back Movies
Auto Playback
You can also do this.
The PDR-M5 also has lots of other features.
Displaying a List of Images (P.74)
Erasing All Images at once
Changing the size of Images
Copying Images to another SmartMedia™
Changing PDR-M5 camera Settings
Taking and Playing Back Photographs on a TV
Protecting Images
Compressing Images
Transferring Images
- 18 -
(P.45)
(P.60)
(P.65)
(P.70)
(P.73)
(P.75)
(P.76)
(P.88)
(P.90)
(P.77)
(P.79)
(P.81)
(P.93)
(P.100)
(P.102)
Accessories
Make sure that you have all of the items below before you start using your camera.
PDR-BT1 lithium-ion
battery pack (1)
SmartMedia™
(8MB, 3.3V) (1)
• Anti-static case (1)
• Labels (2)
• Write-protect stickers (4)
PDR-AC10 AC adapter (1) Video cable (1)
USB cable Serial cable Adapter cable for
Software application
(CD-ROM)
• Instruction Manual (this manual)
• Warranty Card
• Software Manual
Strap (1)
Macintosh
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 19 -
Names of Parts
Getting Ready
Basic
Photography
Playing Back/
Erasing Images
Other
Applications
Additional
Information
Mode dial
For enlarged view ( P.22)
Strap attachment
Shutter button
Flash control sensor
Self-timer lamp
Adapter ring
attachment
( P.103)
Flash
Flash switch
Strap attachment
Viewfinder window
Terminal cover
• DIGITAL terminal
• VIDEO terminal
• DC IN 5V terminal
Lens
Lens cap
- 20 -
Names of Parts (continued)
Getting Ready
Diopter adjustment knob
Self-timer button
Image Quality button
Flash button
LCD monitor
Status display
( P.23)
Viewfinder LED
Viewfinder
MENU button
Macro button
Tripod mount
- 21 -
Function button
ENTER button
Press the center of the button.
(Use this button to fix a selection.)
Press the button on the required side.
(Use these buttons to select an item
or an image.)
SmartMedia™ cover
SmartMedia™ cover release knob
Battery cover
(cross pad) button
Zoom key
DISP button
Erase button
Telephoto (zoom)
Press "T".
Wide
Press "W".
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
Names of Parts (continued)
Mode dial
Getting Ready
Basic
Photography
Manual mode ( P. 60)
Manually sets white balance,
aperture value, exposure and
AF/AE (auto-focus/auto-exposure)
position.
Playing Back/
Erasing Images
Other
Applications
Additional
Information
Auto Photography mode ( P. 42)
This is the most commonly used
photography mode.
In this mode, exposure
(combination of shutter speed and
aperture) is automatically
controlled to facilitate
photography.
Power OFF ( P. 35)
Switches the power OFF.
SET-UP mode ( P. 93)
Sets basic camera settings
(power OFF time, sound, time,
display language, screen color,
image number, reset).
PC mode ( P. 102)
Transfers images to a PC.
For details, refer to the Manual
for the Software Application.
Playback mode ( P. 69)
Selects the image playback or
protect mode, resize,
compression and other settings.
- 22 -
Names of Parts (continued)
Status display
This display indicates the camera’s status. You can verify the camera’s status even if the LCD monitor is
not on.
The text, numbers and icons that are displayed in the status display vary according to the setting.
The status display backlight lights for about five seconds in the following instances:
• When the shutter button is pressed
• When one of the self-timer, image quality or flash buttons is pressed
Remaining battery power
Image quality ( P. 45)
★★★: FINE
★★: NORMAL
★: BASIC
Self-timer photography ( P. 50)
Macro approximately photography ( P. 49)
: SmartMedia™ loaded symbol
Multi photography ( P. 57)
Burst photography ( P. 54)
Image size ( P. 45)
HALF: 800 x 600 pixel (still image), 160 x 120 pixel (movie)
FULL: 1600 x 1200 pixel (still image), 320 x 240 pixel (movie)
Making movies ( P. 59)
Flash photography ( P. 51)
No indication: Auto
: Slow synchro
: Forced flash
: Suppressed flash
: Red-eye reduction
- 23 -
Example of counter display
(The display varies according to the mode dial setting.)
Time display (in [ ], [ ]
or [ ] mode)
Possible number of shots
(in [ ] or [ ] mode: during
still image photography)
Possible photographic time (seconds)
(in [ ] or [ ] mode: when
making movies)
PC indication (in [ ] mode)
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
Attaching the Strap
Strap adjuster
Fastener
This strap is handy for carrying your camera around.
To prevent your camera from dropping during photography, hang the strap around your neck.
Getting Ready
Basic
Photography
Playing Back/
Erasing Images
Other
Applications
Additional
Information
Pass the leading end of the strap through the strap
attachment q, and then pass through both ends of
the strap adjuster w.
Pass the leading end through the fastener and pull
tight.
Attach the strap in the same way on the strap
attachment on the opposite side of the camera.
Memo
• You will find it handy if you tie the lens cap to the strap or strap attachment.
- 24 -
Preparing the Battery
This camera uses a lithium-ion battery pack (PDR-BT1). Other batteries cannot be used. For details on handling
batteries, be sure to read page 14.
Loading the Battery
IMPORTANT
• Before you load or remove the battery, be sure to turn the camera OFF. If the battery is loaded or
removed with the power ON, the date setting may return to its default or the camera settings may be
reset (SET-UP ➲ Page 93, Manual Photography ➲ Page 60).
Remove the battery cover from the battery.
Store the battery cover in a safe place to prevent it from becoming
lost.
Slide the battery cover q, and open the battery cover
w.
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 25 -
Preparing the Battery (continued)
Load the battery in the battery compartment making
sure that it is loaded in the correct direction as shown
in the figure on the right.
Getting Ready
Basic
Photography
Playing Back/
Erasing Images
Other
Applications
Insert the terminal (metal-colored part) first when loading the battery.
Close the battery cover q, and slide the battery cover
w.
Make sure that the battery cover is firmly closed.
Additional
Information
- 26 -
Preparing the Battery (continued)
Removing the Battery
Reverse the procedure for “Loading the Battery” and remove the battery.
IMPORTANT
• When removing the battery, take care not to drop it by mistake.
• Store batteries with the electrode cover attached.
Charging the Battery
When you use the battery for the first time or when the battery has not been used for a long time, be sure to charge
the battery before use. The following describes how to charge the battery in the camera body.
Set the mode dial to [ ].
Connect the AC adapter to the camera and to the power outlet.
Connecting the AC Adapter ➲ Page 29
☞
While the battery is being charged, the viewfinder LED turns red. When the battery is fully charged, the
LED turns green.
Generally, it takes about five hours to fully charge the battery.
IMPORTANT
• If the viewfinder LED blinks red after eight hours have passed since charging started, the battery is
probably malfunctioning. Remove the battery from the camera body and stop charging. Replace the
battery with a new one.
Getting Ready
Photography
Basic
Erasing Images
Playing Back/
Applications
Other
Information
Additional
- 27 -
Preparing the Battery (continued)
Battery Wear
When the power is ON, the remaining battery power is displayed on the LCD monitor and the status
display.
Getting Ready
Basic
Photography
Playing Back/
Erasing Images
Other
Applications
LCD Monitor
No indication
Memo
• When you use the camera for the first time or if you have left the camera for a long time without the
battery loaded, set the date (
• The battery can be charged in about one hour if the battery charger (PDR-CG1) (sold separately) is
used.
• The following shows the approximate number of images that can be photographed continuously using
a fully charged battery in room temperature with the flash used for half of the images. Note, however,
that these figures vary according to the operating temperature of the camera and the detail of the
image being photographed, or length of time viewing the images in play mode.
With the LCD monitor on: Approx. 160 images
With the LCD monitor off: Approx. 240 images
Status Display
Blinks twice
➲
Remaining Battery Power
Sufficient battery power
Half battery power or less
Little battery power left (Power is cut.)
Either recharge, or replace with a new battery.
No battery power left (Power does not turn ON.)
Either charge, or replace with a new battery.
Page 95).
Additional
Information
- 28 -
Loading...
